Rockwell Automation 1792D-OB4D User Manual

Installation Instructions

ArmorBlock MaXum 8 Output Module
Series B

(Cat. No. 1792D-0B8D)

42335

This ArmorBlock MaXum™ I/O module (Cat. No. 1792D-0B8D) is a
stand-alone 24V dc I/O product which communicates via a
DeviceNet™ network. The sealed housing of this module requires no
enclosure.

This module has 8 outputs. Outputs are self-protected 24V dc and
provide up to 1A each. Diagnostic features included are short circuit
and no load detection reported to the point level. Local logic control
has been added to the Series B version of this product.

Publication 1792D-IN003B-EN-P - September 2000

2 ArmorBlock MaXum 8 Output Module Series B

Check Package Contents

Your package contains:

• 1 ArmorBlock MaXum Module

• Installation Instructions

IMPORTANT

Cable bases are ordered and shipped separately.

European Communities (EC) Directive Compliance

If this product has the CE mark it is approved for installation within
the European Union and EEA regions. It has been designed and
tested to meet the following directives.

EMC Directive

This product is tested to meet the Council Directive 89/336/EC
Electromagnetic Compatibility (EMC) by applying the following
standards, in whole or in part, documented in a technical
construction file:

• EN 50081-2 EMC — Generic Emission Standard, Part 2 —
Industrial Environment

• EN 50082-2 EMC — Generic Immunity Standard, Part 2 —
Industrial Environment

This product is intended for use in an industrial environment.

Low Voltage Directive

This product is tested to meet Council Directive 73/23/EEC Low
Voltage, by applying the safety requirements of EN 61131-2
Programmable Controllers, Part 2 - Equipment Requirements and
Tests.

For specific information required by EN 61131-2, see the appropriate
sections in this publication, as well as the Allen-Bradley publication
Industrial Automation Wiring and Grounding Guidelines For Noise
Immunity, publication 1770-4.1.

Publication 1792D-IN003B-EN-P - September 2000

ArmorBlock MaXum 8 Output Module Series B 3

Install Your ArmorBlock MaXum I/O Module

To install the module you must:

• Set the node address

• Mount the module to the cable base

• Connect the output cord sets to the MaXum module

• Communicate with your ArmorBlock MaXum I/O module

More detailed information about each of these steps is in the
following procedures.

Set the Node Address

Valid node addresses are 00 to 63.

Set the node address using the rotary switches, RSNetWorx for
DeviceNet™ software, or another software configuration tool. Setting
the switches between 64 to 99 lets the software have address control.

Each module is shipped with the node address set to 63. The
switches are located on the underside of the module. The two
switches are:

• MSD (most significant digit)

• LSD (least significant digit)

To reset the node address, use a small blade screwdriver to rotate the
switches. Line up the small black dot on the switch with the number
setting you wish to use.

The rotary switches are read at module power up only. Settings
between 64 and 99 cause the module to use the last valid node
address stored internally. Example: The last setting was 40. If a
change is made to 68, and then you power up, the address will
default to 40.

Publication 1792D-IN003B-EN-P - September 2000

4 ArmorBlock MaXum 8 Output Module Series B

Refer to the illustration of the node address below.

41462

The module is equipped with AutoBaud detect. AutoBaud lets the
module read the settings already in use on your DeviceNet network
and automatically adjusts to follow those settings.

Mount the Module to the Cable Base

This module mounts to the following cable bases:

• 1792D-CBFM for KwikLink™ flat media installation

• 1792D-CB12 for 12mm drop cable installation

• 1792D-CB18P for round media DeviceNet connection

• or other optional cable base assembly

IMPORTANT

Publication 1792D-IN003B-EN-P - September 2000

The cable base should already be mounted. See
publications 1792D-IN009B-EN-P (CBFM & CB12)
or 1792D-IN036B-EN-P (CB18, CB18P) for more
information on installing the cable base.

To install the module:

ArmorBlock MaXum 8 Output Module Series B 5

IMPORTANT

Proper alignment of the screws is necessary to
complete the connections between the module
contacts and cable contacts.

1. Position the module over the mounted cable base. Align the

three captive screws in the module with the accepting
receptacles in the base.

2. Tighten the screws with a torque of 8 inch-pounds to secure

the module to the base.

IMPORTANT

1.9in.

48.26mm

Dimensions change according to the cable base
and module combination used.

6.85in.
174mm

2.7in.

68.6mm

Align the
screws to
properly
assemble
the
module to
the base.

Assembled
dimensions
in (mm).

Cable Base
1792D-CBFM is used

42336

for this example.

Publication 1792D-IN003B-EN-P - September 2000

6 ArmorBlock MaXum 8 Output Module Series B

Connect the Output Cord Sets to the MaXum Module

This module uses 5 pin micro (12mm) style PCB mounted connectors.

Eight micro caps cover the connectors on your module. Remove the
caps and connect your cables to the appropriate ports.

Use the micro caps to cover and seal unused ports. A pinout diagram
for the connectors is shown below.

Output Micro-Connector

(View into Sockets)
Pin 1 Not Used
Pin 2 Not Used
Pin 3 Auxiliary Power Ground
Pin 4 Output A
Pin 5 Not Used

41452

Please refer to publication 889-5.0 for Rockwell Automation cables
and cord sets offerings.

ATTENTION

!

Publication 1792D-IN003B-EN-P - September 2000

ATTENTION:

• Make sure all connectors and caps are
securely tightened to properly seal the
connections against leaks and maintain
IP67 requirements.

• For maximum noise immunity, input and
output cable return wires must be
properly terminated. When inputs and
outputs are connected in loopback, return
wires should be connected together.

• I/O cable length should be less than 30
meters.

ArmorBlock MaXum 8 Output Module Series B 7

I/O connectors for this module are shown below.

Connector A
Output 0

Connector B
Output 1

Connector C
Output 2

Connector D
Output 3

Auxiliary Power

Logic Status

O-0 O-7

O-1 O-6

O-2

O-3

O-5

O-4

Net/Mod Status

Connector H
Output 7

Connector G
Output 6

Connector F
Output 5

Connector E
Output 4

42337

DeviceNet Cable

DeviceNet cables are described in the installation publications for the
cable base assembly of your choice. Refer to the following
publications:

• 1792D-IN009B-EN-P ArmorBlock MaXum Cable Base
Installation Guide

• DN-6.7.2 DeviceNet Cable Planning and Installation Manual

Publication 1792D-IN003B-EN-P - September 2000

8 ArmorBlock MaXum 8 Output Module Series B

Communicate with Your ArmorBlock MaXum
I/O Module

This ArmorBlock module’s I/O is exchanged with the master through
a poll, change-of-state, or cyclic connection.

The module consumes and produces output data as follows:

Type of I/O Connections Consumes Produces

Cyclic 1 Bytes 2 Bytes

Polled 1 Bytes 2 Bytes

Change-of-State 1 Bytes 2 Bytes

Cyclic - allows configuration of the block as an I/O client. The block
will produce and consume its I/O cyclically at the rate configured.

Polled - a master initiates communication by sending its polled I/O
message to the module. This 8 output module consumes the
message, updates outputs and produces a response. The response
has output faults and the status of the Auxiliary power.

Change-of-state - productions occur when an input changes or a
fault condition occurs. If no input or fault condition change occurs
within the expected packet rate, a heartbeat production occurs. This
heartbeat production tells the scanner module that the I/O module is
alive and ready to communicate.

Refer to the table below for the word/bit definitions.

Bit 0706050403020100

Produces 0 OFLT7 OFLT6 OFLT5 OFLT4 OFLT3 OFLT2 OFLT1 OFLT0

Produces 1 RSVP OPWR RSVP RSVP RSVP RSVP RSVP RSVP

Consumes 0 O7 O6 O5 O4 O3 O2 O1 O0

Where: OFLT = Output Fault OPWR = Output Power O = Output RSVP = Reserved

Publication 1792D-IN003B-EN-P - September 2000

ArmorBlock MaXum 8 Output Module Series B 9

Byte Bit Description

Produces 0 00-07 Output no load or overload fault (OFLT): When the bit is set

Produces 1 00-05, 0706Reserved

Consumes 0 00-07 Output bits: When the bit is set (1), the output will be turned

(1), an output fault has occurred. OFTO corresponds to
output 0, OFT1 corresponds to output 1, OFT2 corresponds
to output 2, OFT3 corresponds to output 3, OFT4
corresponds to output 4, OFT5 corresponds to output 5,
OFT6 corresponds to output 6, and OFT7 corresponds to
output 7.

Output Power Fault (OPWR): When the bit is set (1),
Auxiliary Power is not present.

on. Bit 00 corresponds to output 0, bit 01 corresponds to
output 1, bit 02 corresponds to output 2, bit 03
corresponds to output 3, bit 04 corresponds to output 4, bit
05 corresponds to output 5, bit 06 corresponds to output 6,
bit 07 corresponds to output 7.

The DeviceNet Network uses advanced network technology,
producer/consumer communication, to increase network
functionality and throughput. Visit our web site at
http://www.ab.com/networks

for producer/consumer technology

information and updates.

Troubleshoot with the Indicators

This module has the following indicators:

• Network/Module status indicator

• Logic status indicators

• Auxiliary status indicator

• Individual point status indicators

Publication 1792D-IN003B-EN-P - September 2000

10 ArmorBlock MaXum 8 Output Module Series B

The following illustration describes module status indicators.

Point LED Indicator for
output 0

Connector A

Point LED Indicator for
output 1

Connector B

Point LED Indicator for
output 2

Connector C

Point LED Indicator for
output 3

Connector D

Module Status Indicators

Auxiliary Power

Logic Status

O-0 O-7

O-1 O-6

O-2

O-3

O-5

O-4

Net/Mod Status

Point LED Indicator for
output 7

Connector H

Point LED Indicator for
output 6

Connector G

Point LED Indicator for
output 5

Connector F

Point LED Indicator for
output 4

Connector E

42337

LED Assignments

The following table describes the network and module status
indicator.

Net/Mod Status Indicator

Indication Status:

Off No power or auto bauding

Flashing Green/Off On line but not connected

Solid Green On line, link OK, connected

Flashing Red Recoverable fault - module configuration error

I/O connection fault - one or more I/O connections in the timed-out
state

Solid Red Unrecoverable fault

Communication failure - duplicate node address present or incorrect
baud rate

Green to Red to Off At powerup only - LED test

Publication 1792D-IN003B-EN-P - September 2000

ArmorBlock MaXum 8 Output Module Series B 11

The following table describes logic status indicators.

Logic Status Indicators

State Status

Off Logic is disabled

Solid Green Logic is enabled

Flashing Green Local forces are applied and local logic is enabled

The following table describes auxiliary status indicators.

Auxiliary Status Indicators

Indication Status

None No Auxiliary power

Solid Green Auxiliary power present

The following table describes I/O status indicators.

I/O Status Indicators

Function Module Status Indicator Point Indicator Condition

Outputs Green

Green
Module Status blink red
Module Status blink red
Module Status blink red
Module Status blink red

None
Ye ll ow
Orange
Red
Orange
Red

Output not energized
Output energized
Output shorted-auto restart
Output shorted-latching
output no load-auto restart
Output no load-latching

For more information on indications, see the Technical Data,
publication 1792-TD001B-EN-P.

Publication 1792D-IN003B-EN-P - September 2000

12 ArmorBlock MaXum 8 Output Module Series B

Specifications

8 Output Module - Cat. No. 1792D-0B8D

Output Specifications Max. Min.

Outputs per block 8 sourcing outputs labeled O0 through O7

Output Auxiliary Voltage 30V 10V

On-state Voltage Drop 1V -

On-state Current 1A -

Off-state Leakage 1.5mA -

Module Current (all outputs) 4.0A -

Surge Current - for 10 ms,
repeatable every 2s

No Load Sense Current (On-state) 0.18A -

Indicators Net/Mod Status - red/green

Communication Rate

DeviceNet Power Voltage

Auxiliary Power Voltage

Dimensions (assembled to base)
inches - (millimeters)

Current

Current

2.4A -

Logic Status - red/green
Auxiliary Power - green
Point LED - yellow/orange/red

• 125Kbps @ 500 meters (1600 feet)
for thick cable, flat media length 375
meters (1230 feet)

• 250Kbps @ 200 meters (600 feet) for
thick cable, flat media length 150
meters (492 feet)

• 500Kbps @ 100 meters (330 feet) for
thick cable, flat media length 75
meters (246 feet)

25V dc max
75mA

30V dc
4A

1.9H x 2.7W x 6.85D
(48.26)H x (68.6)W x (174)D

11V dc min
150mA

10V dc
4A

Publication 1792D-IN003B-EN-P - September 2000

ArmorBlock MaXum 8 Output Module Series B 13

8 Output Module - Cat. No. 1792D-0B8D

Environmental Conditions
Operational Temperature

Storage Temperature
Relative Humidity
Shock Operating

Non-operating

Vibration

Conductors Publication DN-6.7.2

Enclosure Meets or exceeds IP67

General Specifications

Agency Certification
(when product is marked)

o

-25 to 60

C (-13 to 140oF)

o

C (-13 to 176oF)

-25 to 80
Up to 100%
30g peak acceleration, 11 (+1) ms pulse width
50g peak acceleration, 11 (+1) ms pulse width
Tested 10g @ 10-500 Hz per IEC 68-2-6

• CSA certified

• CSA Class 1, Division 2, Groups A, B,

C, D certified

• UL listed

• CE marked for all applicable directives

Technical Data (user information) Publication 1792-TD001B-EN-P

Publication 1792D-IN003B-EN-P - September 2000

14 ArmorBlock MaXum 8 Output Module Series B

Hazardous Location Approval

The following information applies only to products marked
with Hazardous Location Approval, when operating in
hazardous locations:

Products marked “CL I, DIV 2, GP A, B, C, D” are suitable for use in
Class I Division 2 Groups A, B, C, D, Hazardous Locations and
nonhazardous locations only. Each product is supplied with markings
on the rating nameplate indicating the hazardous location
temperature code. When combining products within a system, the
most adverse temperature code (lowest “T” number) may be used to
help determine the overall temperature code of the system.
Combinations of equipment in your system are subject to
investigation by the local Authority Having Jurisdiction at the time of
installation.

WARNING

!

WARNING

EXPLOSION HAZARD -

• Do not disconnect equipment unless power
has been removed or the area is known to be
nonhazardous.

• Do not disconnect connections to this
equipment unless power has been removed
or the area is known to be nonhazardous.
Secure any external connections that mate to
this equipment by using screws, sliding
latches, threaded connectors, or other means
provided with this product.

• Substitution of components may impair
suitability for Class I, Division 2.

• If this product contains batteries, they must
only be changed in an area known to be
nonhazardous.

Use supply wires suitable for 30°C above
surrounding ambient.

!

Publication 1792D-IN003B-EN-P - September 2000

ArmorBlock MaXum 8 Output Module Series B 15

WARNING

When used in a Class I, Division 2, hazardous
location, this equipment must be mounted in a
suitable enclosure with proper wiring method that
complies with the governing electrical codes.

!

Les informations suivantes ne concernent que les produits
marqués pour une utilisation en environnements dangereux :

Les produits marqués « CL I, DIV 2, GP A, B, C, D » ne conviennent
qu’à une utilisation en environnements de Classe I Division 2
Groupes A, B, C, D dangereux et non dangereux. Chaque produit est
livré avec des marquages sur sa plaque d’identification qui indiquent
le code de température pour les environnements dangereux. Lorsque
plusieurs produits sont combinés dans un système, le code de
température le plus défavorable (code de température le plus faible)
peut être utilisé pour déterminer le code de température global du
système. Les combinaisons d’équipements dans le système sont
sujettes à inspection par les autorités locales qualifiées au moment de
l’installation.

AVERTISSEMENT

!

RISQUE D’EXPLOSION -

• Couper le courant ou s’assurer que
l’environnement est classé non dangereux
avant de débrancher l’équipement.

• Couper le courant ou s’assurer que
l’environnement est classé non dangereux
avant de débrancher les connecteurs. Fixer
tous les connecteurs externes reliés à cet
équipement à l’aide de vis, loquets
coulissants, connecteurs filetés ou autres
moyens fournis avec ce produit.

• La substitution de composants peut rendre cet
équipement inadapté à une utilisation en
environnement de Classe I, Division 2.

• S’assurer que l’environnement est classé non
dangereux avant de changer les piles.

Publication 1792D-IN003B-EN-P - September 2000

AVERTISSEMENT

!

Utiliser des fils d’alimentation qui conviennent à
une température de 30°C au-dessus de la
température ambiante.

AVERTISSEMENT

Pour une utilisation en environnement de classe i,
division 2 dangereux, cet equipement doit etre
monte dans un boitier avec un cablage approprie
conforme aux normes electriques en vigueur.

!

This product has been tested at an Open DeviceNet Vendor
Association, Inc. (ODVA) authorized independent test laboratory and
found to comply with ODVA Conformance Test. Please contact the
ODVA website (http://www.odva.org) for listing of products tested by
ODVA independent test labs for further details.

ArmorBlock and ArmorBlock MaXum, and KwikLink are trademarks of Rockwell Automation.
RSNetWorx for DeviceNet is a trademark of Rockwell Software, Inc.
DeviceNet is a trademark of Open DeviceNet Vendor Association (ODVA).

Publication 1792D-IN003B-EN-P - September 2000 PN 957400-09

Supersedes Publication 1792D-IN 003A-US-P - May 2000 © 2000 Rockwell International Corporation. Printed in USA
