Rockwell Automation 1792D2B0LP User Manual

Installation Instructions

ArmorBlock LP2 2 Sinking Input Module

(Cat. No. 1792D-2BOLP)

I0 I1

Network Status

Module Status

41954

This ArmorBlock LP2™ I/O module (Cat. No. 1792D-2B0LP) is a
stand-alone 24V dc I/O product which communicates via a DeviceNet
network. The sealed housing of this module requires no enclosure.

This module has 2 sinking inputs.

Package Contents

Your package contains:

• 1 ArmorBlock MaXum Module

• Installation Instructions

Publication 1792D-5.43 - July 1999

2 ArmorBlock LP2 2 Sinking Input Module

European Communities (EC) Directive Compliance

If this product has the CE mark it is approved for installation within the
European Union and EEA regions. It has been designed and tested to meet
the following directives.

EMC Directive

This product is tested to meet the Council Directive 89/336/EC
Electromagnetic Compatibility (EMC) by applying the following
standards, in whole or in part, documented in a technical construction file:

• EN 50081-2 EMC — Generic Emission Standard, Part 2 — Industrial
Environment

• EN 50082-2 EMC — Generic Immunity Standard, Part 2 — Industrial
Environment

This product is intended for use in an industrial environment.

Low Voltage Directive

This product is tested to meet Council Directive 73/23/EEC Low Voltage,
by applying the safety requirements of EN 61131-2 Programmable
Controllers, Part 2 - Equipment Requirements and Tests.

For specific information required by EN 61131-2, see the appropriate
sections in this publication, as well as the Allen-Bradley publication
Industrial Automation Wiring and Grounding Guidelines For Noise
Immunity, publication 1770-4.1.

This equipment is classified as open equipment and must be mounted in an
enclosure during operation to provide safety protection.

Install Your ArmorBlock LP2 I/O Module

To install the module you must:

• Set the node address and baud rate.

• Mount the module.

• Connect the input cord sets to the LP2 module.

• Communicate with your ArmorBlock LP2 module.

Each of these steps is discussed in detail in the following procedures.

Publication 1792D-5.43 - July 1999

ArmorBlock LP2 2 Sinking Input Module 3

Set the Node Address and Baud Rate

Set the node address using RSNetWorx for DeviceNet™ software,
DeviceNetManager™ software, or another software configuration tool.
The module is equipped with AutoBaud detect. AutoBaud lets the module
read the settings already in use on your DeviceNet network and
automatically adjusts to follow those settings.

Mount the Module

1. Attach the module using the dimensions shown below.

I0 I1

4.21 in
107mm

Network Status

1.95 in

49.5mm

Module Status

12 in
305mm

0.25 in

6.25mm

1.02 in

41954

26.0mm

2. Connect the grey DeviceNet cable to the DeviceNet trunk. Use the
1485P-P1R5-MN5R1 T-Part tap to make the connection to round
media. Use the 1485P-P1E4-R5 to connect to the Kwik Link flat media
system.
