Cost-effective and secure
The best choice for low cost secure printing
The Aficio™SP C430DN/SP C431DN provide an excellent solution for cost-efficient colour printing. With
printing costs amounting to a significant percentage of your company’s turnover, a low cost per print is
simply essential. In addition, your confidential documents require protection. The SP C431DN supplies
security features such as Enhanced Locked Print NX as standard. High quality, fast printing at up to 40
colour pages per minute (SP C431DN), along with a 50-second warm-up time, optimise office productivity.
Low Total Cost of Ownership: low cost per print and high duty cycle.
Document protection: Enhanced Locked Print NX is standard (SP C431DN).
Productive: up to 40 colour or B/W pages per minute (SP C431DN).
User-friendly: easy-to-use operation panel.
Flexible printing: wide range of media possibilities.
Productivity and performance
LOW TOTAL COST OF OWNERSHIP
A number of features contribute to a low Total Cost of Ownership. Affordable in-house document creation
means there is no need for outsourcing. A high duty cycle results in minimal maintenance. Long yield of
consumables leads to a low cost per print. And built-in duplexing reduces paper consumption.
DOCUMENT PROTECTION
The SP C431DN offers extensive security features as standard. Protect confidential and proprietary
information with Enhanced Locked Print NX. Your document will not print until you enter your ID and
password on the printer. For organisation-wide document protection, network administrators can even
set this as the default.
HIGH PRODUCTIVITY
The Aficio™SP C430DN/SP C431DN are fast, efficient and productive. After a warm-up time of 50
seconds, the first B/W print is ready in 10 seconds; the first colour page in 15 seconds. The SP C430DN
prints 35 colour and B/W pages per minute; the SP C431DN is even faster, printing 40 colour and B/W
pages per minute. What’s more, there is no reduction in print speed in duplex mode. For efficient
networking, a Network Interface Card is provided as standard.
EASY OPERATION AND MAINTENANCE
Operation of both devices is straightforward via an intuitive 4-line LCD operation panel which clearly
displays all functions. Toner and paper replacement are simple tasks as the devices are accessible from
top and front. Animated procedures help you troubleshoot in seconds.
FLEXIBLE MEDIA HANDLING
Looking for an affordable colour printer product that can handle many different media types? With the
SP C430DN/SP C431DN you can print covers and flyers on heavy paper up to 256 g/m². Or print on your
preferred envelopes, labels, card stock and transparencies. Output quality is an excellent 1,200 x 1,200
dpi. Paper capacity is an outstanding 2,300 sheets when the three additional paper trays are installed.
EASILY ACCESSIBLE
Front/top accessibility means these devices can be located against a wall or even in a corner. No parts
stick out and get in the way. The front-loading paper tray slides back underneath the machine so you will
never accidentally knock or damage it.
ENVIRONMENTALLY FRIENDLY
At Ricoh we help you lower the environmental impact of your office as well as lowering your Total Cost
of Ownership. The SP C430DN/SP C431DN have eco-friendly and money-saving features such as low
power consumption, fast duplex printing, ultra-low sleep mode, short warm-up time and increased toner
yield. Thus they save paper, time and energy while reducing waste and costs. In addition, Ricoh products
are Energy Star compliant. This means less CO2 is produced in providing the energy needed to run Ricoh
devices.
GENERAL
Technology: 4 drums tandem method, laser beam
scanning, electro photographic printing and
dual component toner development
Print speed: Full colour: 35/40 prints per minute
B/W: 35/40 prints per minute
Warm-up time: Less than 50 seconds
First print speed: Full colour: Less than 15 seconds
B/W: Less than 10 seconds
Dimensions (W x D x H): 444 x 658 x 490 mm
Weight: 57 kg
Power source: 220 - 240 V, 50 - 60 Hz
Power consumption: Maximum: 1,510 W
Energy saver mode: Less than 6 W
Duty cycle: 150,000 pages per month
PAPER HANDLING
Paper input capacity: Standard: 1 x 550-sheet paper tray
100-sheet bypass tray
Maximum: 2,300 sheets
Paper output capacity: Standard: 500 sheets
Paper size: Paper trays: A6 - A4
Bypass tray: A6 - A4
Paper weight: Paper trays: 52-220 g/m²
Bypass tray: 52-256 g/m²
Duplex tray: 60-163 g/m²
Media: Plain paper, recycled paper, middle thick
paper, thick paper, thin paper, transparencies,
letterheads, labels, coated paper, waterproof
paper, pre-printed paper, envelopes
CONTROLLER
Processor: 600MHz
Printer language: Standard: PCL5c, PCL6, PostScript 3, PDF,
XPS
Option: PictBridge
Resolution: 600 dpi (1-bit)/600 dpi (2-bit)/1,200 dpi
Memory: Standard: 384/768 MB
Maximum: 768 MB
Hard Disk Drive: 80 GB (standard for SP
C431DN)
Drivers: PCL5c/PCL6: Windows® 2000/XP/Vista/
Server 2003/2003R2/Server 2008
PostScript 3: Windows® 2000/XP/Vista/
Server 2003/2003R2/Server 2008, Macintosh
8.6 – 9.2.x (OS X Classic), Macintosh X
v10.1/10.2/10.3 or later (native mode), UNIX
Fonts: PCL: 45 fonts + 13 fonts (International Fonts)
PostScript 3: 136 fonts
CONNECTIVITY
Network protocol: TCP/IP (IPv4, IPv6), AppleTalk, IPX/SPX
Supported environments: Windows® 2000/XP/Vista/Server 2003/2008
(32 bit, 64 bit)
Novell® NetWare® 6.5 or later
Macintosh 8.6 or later
Interface: Standard: Ethernet 10 base-T/100 base-TX,
USB 2.0 (Type A & B), Option: Bi-directional
IEEE 1284, Wireless LAN (IEEE 802.11a/b/g),
Gigabit Ethernet
Additional feature: PDF Direct Print
CONSUMABLES
Toner1:
Black: 21,000 sheets
C, M, Y: 24,000 sheets
OTHER OPTIONS
Internal options: Wireless LAN (IEEE 802.11a/b/g)
External options: 550-sheet paper tray (max. 3)
1
The SP C430DN/SP C431DN ships with a starter kit.
2
Declared yield value in accordance with ISO/IEC 19798.
3
Optional for SP C430DN only.
For availability of models, options and software, please consult your local Ricoh
supplier.
Camera Direct Print Card
HDD Encryption
Data Overwrite Security Unit
Bi-directional IEEE 1284
Gigabit Ethernet
NetWare
3
HDD
256 MB Memory
512 MB Memory
VM Card
3
3
3
Caster table
Low cabinet
High cabinet
ISO9001 certified, ISO14001 certified
All brand and/or product names are trademarks of their respective owners. Specifications
and external appearance are subject to change without notice. The colour of the actual
product may vary from the colour shown in the brochure. The images in this brochure
are not real photographs and slight differences in detail might appear.
Copyright © 2009 Ricoh Europe PLC. All rights reserved. This brochure, its contents and/
or layout may not be modified and/or adapted, copied in part or in whole and/or
incorporated into other works without the prior written permission of Ricoh Europe PLC.
www.ricoh-europe.com
