PLRDVD7
OWNER’S MANUAL
Mobile Video System
• Digital Audio Out-Coaxial
• DVD Player
• Multi Color TFT Monitor
• Multi-subtitle Languages Function
• Multi-audio Languages Function
• Multi-angle Function
• Parental Control
• Remote Control
www.pyleaudio.com
FEATURES
Compatible with PAL DVD (Video
CD) and NTSC DVD (Video CD)
This player can play discs recorded in
either PAL or NTSC format.
• A single LSI chip now integrates all
major DVD playback circuit functions
including MPEG2 decoder, video D/A
converter, and audio decoders.
• L/R stereo analog audio outputs for
connection to existing head unit aux
inputs. Video output is composite
video.
• Supplied remote handles
multi-function software (multi-language
audio-track/subtitle, multi-angle, multistory, etc.), plus all basic functions.
USE THIS PRODUCT SAFELY
When Driving
Keep the volume level low enough to be
aware of road and traffic conditions.
When Car Washing
Do not expose the product to water or
excessive moisture. This could cause
electrical shorts, fire or other damage.
Protect the Disc Mechanism
Avoid inserting any foreign objects into
the slot of this player.
Failure to observe this may cause
malfunction due to the precise
mechanism of this unit.
Use Authorized Service Centres
Do not attempt to disassemble or adjust
this precision product. Please refer to
the Service Centre list included with this
product for service assistance.
For Installation
The unit should be installed in a
horizontal position with the front end up
at a convenient angle, but not more than
30°.
When Parked
Parking in direct sunlight can produce
very high temperatures inside your
vehicle. Give the interior a chance to
cool down before starting playback.
Use the Proper Power Supply
This product is designed to operate with
a 12 volt DC, negative ground battery
system (the regular system in a North
American car).
2
CONTENTS
Safety Information ........................................................................................4
Disc Notes .....................................................................................................5
The Player......................................................................................................6
Installation .....................................................................................................8
Replacing the Car Demo Lamp ...................................................................9
Electric Connection ....................................................................................10
Remote Control...........................................................................................11
Location and Function of Keys.............................................................................11
Preparing the Remote Control..............................................................................13
Loading/Ejecting a disc..............................................................................13
Loading a Disc ......................................................................................................13
Ejecting a Disc ......................................................................................................13
Operation .....................................................................................................14
Basic Play .............................................................................................................14
Menu Function......................................................................................................16
On-Screen Display Function.................................................................................16
Multi-audio Language Function............................................................................17
Title Menu Function ..............................................................................................18
Multi-Subtitle Language Function ........................................................................18
Multi-angle Function .............................................................................................18
MP3 Disc Play.......................................................................................................18
Setup ............................................................................................................19
Initial Setup ...........................................................................................................19
General Setup.......................................................................................................19
Speaker Setup ......................................................................................................21
Audio Setup ..........................................................................................................21
Preferences Setup ................................................................................................22
Defaults Table .......................................................................................................24
Trouble Shooting.........................................................................................25
Specifications..............................................................................................26
3
SAFETY INFORMATION
CAUTION:
MOBILE DVD PLAYER IS A CLASS I
LASER PRODUCT. HOWEVER THIS
MOBILE DVD PLAYER USES A
VISIBLE/INVISIBLE LASER BEAM
WHICH COULD CAUSE HAZARDOUS
RADIATION EXPOSURE IF DIRECTED.
BE SURE TO OPERATE THE MOBILE
DVD PLAYER CORRECTLY AS
INSTRUCTED.
USE OF CONTROLS OR
ADJUSTMENTS OR PERFORMANCE OF
PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE.
DO NOT OPEN COVERS AND - DO NOT
REPAIR YOURSELF. REFER SERVICING
TO QUALIFIED PERSONNEL.
WARNING:
• TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, DO NOT EXPOSE
THIS EQUIPMENT TO RAIN OR
MOISTURE.
• TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, AND ANNOYING
INTERFERENCE, USE ONLY THE
RECOMMENDED ACCESSORIES.
• THIS DEVICE IS INTENDED FOR
CONTINUOUS OPERATION.
Region Management Information
Region Management Information:
This Mobile DVD Player is designed and
manufactured to respond to the Region
Management Information that is recorded
on a DVD disc. If the Region number
described on the DVD disc does not
correspond to the Region number of this
Mobile DVD Player, this Mobile DVD
Player cannot play this disc.
This product incorporates copyright
protection technology that is protected
by method claims of certain U.S. patents
and other intellectual property rights
owned by Macrovision Corporation and
other rights owners. Use of this
copyright protection technology must be
authorized by Macrovision Corporation,
and is intended for home and other
limited viewing uses only unless
otherwise authorized by Macrovision
Corporation. Reverse engineering or
disassembly is prohibited.
4
DISC NOTES
Disc formats supported by this player
DVD
12 cm disc
(Single-sided disc only)
Video CD
12 cm disc
CD
12 cm disc
MP3
12 cm disc
Discs which cannot be played with this
player
• DVD-ROM
• DVD-R/DVD-RAM
• CDV
• CD-G
Handling and Cleaning
• Dirt, dust, scratches and warping disc
will cause misoperation.
• Do not place stickers or make
scratches on discs.
• Do not warp discs.
• A disc should always be kept in its
case when not in use to prevent from
damaging.
• Do not place discs in the following
places:
1. Direct sunlight
2. Dirty, dusty and damp areas
3. Near car heaters
4. On the seats or dashboard
Disc Cleaning
Use a dry soft cloth to wipe the surface.
If the disc is quite dirty, use a soft cloth
slightly moistured with isopropyl (rubbing)
alcohol. Never use solvents such as
benzine, thinner or conventional record
cleaners as they may mar the surface of
the disc.
Note:
A disc may become somewhat scratched
(although not enough to make it
unusable) depending on your handle it
and conditions in the usage environment.
Note these scratches are not an
indication of any problem with the player.
Label side up
Do not touch
the underside
of the disc
Do not bend
Wipe the disc from center
toward the outside edge
Preparing New Discs with Rough
Spots
A new disc may have rough edges on its
inside and outside edges. If a disc with
rough edges is used, the proper setting
will not be performed and the player will
not play the disc. Therefore, remove the
rough edges in advance by using a ball
point pen or pencil as shown below. To
remove the rough edges, press the side
of the pen or pencil against the inside
and outside edges of the disc.
Rough spots on
outside edge
Ball point pen
or pencil
Rough spots
on inside edge
5
THE PLAYER
5 3 10 201 48 11 9 2 7 6 5 22
14
15
14
15
16 17 18 19
6
THE PLAYER
12
13
7 INCH TFT COLOR MONITOR
1. POWER ( )
2. EJECT (
3. MENU
4. MOD
5. Car Dome Lamp
6. Light Switch
7. VOLUME +
8. VOLUME -
9. IR
10. Indicator Light for DVD
11. Indicator Light for AV
12. Disc slot
13. 7 inch TFT Color Monitor
14. Earphone volume control knob
)
15. Jacks for Earphone
16. DC 12V IN
17. AV IN
18. AV OUT
19. DIGITAL AUDIO
20. INFRARED TRANSMITTING
WINDOW (For the unit with infrared
transmitting function only)
21. Open button: Press the button to
eject the screen display from the base
at a little angle.
7
INSTALLATION
Tapping Screws (ø4x10)
Fig. 1
Mounting Bracket
Levers
Slots
DVD Bracket
Mounting Bolts (M3.5x10)
Rubber Caps
Fig. 2
1. Determine the mounting location and drill four mounting holes (See Fig.1).
2. Attach the mounting bracket to the holes with the tapping screws (ø4x10).
3. Let the two levers aim at the slots on the DVD bracket to fix the display unit.
4. Open the monitor to display the five screw holes.
5. Attach the unit to the bracket with the mounting bolts (M 3.5x10).
6. Insert five rubber caps to the screw holes.
7. When the installation has completed, you can also turn the display upward or
downward, left or right to adjust the viewing angle. (See the arrowhead symbol in
Fig.2).
8
REPLACING THE CAR DOME LAMP
Follow the directions shown below for a new lamp changing.
1. Press the open button to eject the screen display and turn it upward.
2. Position light switch to “OFF”.
3. Push back the lamp cover and open it. (Refer to the following figure)
4. Remove and discard the old lamp.
5. Install a new bulb.
6. Close the cover.
Bulb
Light Switch
Bulb Specification
Diameter: ø8mm
Length: 28mm
Voltage Spec.: DC12V, 5W
Lamp Cover
CAR DOME LAMP WIRING
Line for Car Dome Lamp
Note:
Color Connection
Red Power Supply
White Interior Light System
Black Ground
9
ELECTRIC CONNECTION
DC 12V IN
DIGITAL AUDIO
CIGARETTE LIGHTER
VIDEO OUT
AUDIO L OUT
VIDEO IN
YELLOW
AUDIO L IN
WHITE
AUDIO R IN
RED
YELLOW
AUDIO R OUT
WHITE
RED
10
REMOTE CONTROL
LOCATION AND FUNCTION KEYS
8
4
1
3
7
11
14
15
18
19
23
25
9
5
2
6
10
12
13
16
17
20
2421
22
28
29
32
2726
3130
11
REMOTE CONTROL
1. POWER Press POWER to turn the unit ON or OFF.
2. EJECT Press to eject the disc.
3. MUTE Press to mute the sound.
4. SUBTITLE Changing of the SUBTITLE language on multi-subtitle language
5. ANGLE Changing of the view angle on multi-angle DVD disc.
6. DISPLAY Display statistical disc information during playback.
7. MODE Changing between DVD mode and AV mode.
8. SETUP Display the SETUP menu.
9. PAL/NTSC Switch between PAL mode and NTSC mode.
10. AUDIO Changing of the AUDIO soundtrack on multi-audio soundtrack
11. TITLE Display the TITLE menu that is stored in DVD disc.
12. MENU Display the adjustment items, such as Bright, Contrast, Color,
/ , / In case of MENU mode, / , / , buttons served as cursor
13.
14. ENTER Confirm the Track/Chapter selected with the numeric buttons or
15. / Changing for slow forward/reverse playback motion.
16. Press to play the disc.
17. / Press to search forward rapidly & to search reverse rapidly.
18. / Press to skip to the next track & press to skip back one
19. Press it to stop playback.
20. Press it to pause playback.
21. 0 - 9 Numeric buttons
22. 10+ Digital selecting button, cooperatively used with numeric buttons.
23. CLEAR When you input a number in error, press the button to clear it.
24. VOLUME+/- Press VOLUME+/- button to increase or decrease the volume
25. ZOOM Allows the picture to be increased in size.
26. RESUME When in stop mode, press the button, then play can be resumed
27. GOTO Disc search button, cooperatively used with numeric buttons.
28. PBC Changing between PBC ON and PBC OFF on the VCD disc.
29. RANDOM Allows the track played in random order.
30. PROGRAM Allows the track played in the order you programmed.
31. REPEAT Switch the Repeat mode of discs.
32. A-B A-B repeat allows a passage to be repeated continuously.
DVD disc.
DVD disc. Changing of the sound mode of the VCD/CD disc.
Tint, Transmit, Screen and etc.
buttons to select item left/right, ahead/back.
selected with the cursor buttons on screen display.
track.
level.
from the stop point.
12
REMOTE CONTROL
Preparing the Remote Control
Inserting the Batteries
1. Open the battery compartment cover.
2. Insert the new batteries. Make sure
that the positive and negative
terminals of the batteries are oriented
as indicated.
3. Close the cover
Battery: Two AAA size battery.
Using the Remote Control
Face the remote control towards the
player front face IR mark (remote control
signal reciver).
Operation angle: About ± 30 degree in
each the direction of the front of the IR
mark.
LOADING/EJECTING A DISC
Loading a Disc
When you have installed the unit and all
connections have completed, you can
load a disc as follows:
1. Turn the ignition on the the accessory
position.
2. Press the POWER button (1).
3. Insert the disc with printed side facing
up into the disc slot (2) (see below).
4. The player will start playback
automatically.
1 2 3
Ejecting a Disc
Press (EJECT) button (3) to eject the
disc.
13
OPERATION
BASIC PLAY
STOPPING PLAY
- Brief press the (Stop) button to stop
the unit playback, when the
button is pressed, normal playback will
continue.
- Press (Stop) button twice to stop
the playback and go back to initial
Track/Chapter.
RAPID FORWARD/RAPID REVERSE
Press & during play. Each time
the button is pressed, the speed of rapid
forward/reverse changes according to
the disc as follow.
DVD:
Normal Playback 2X 4X 6X 8X
VCD/CD:
Normal Playback 1X 2X 3X 4X
MP3:
Normal Playback 2X 4X 6X 8X
SKIPPING TRACK
Press / buttons on the remote
control during playback.
Press
to skip to next track, and
to back one track.
Note: For some VCD 2.0 dics
(PBC-playback control),
may be unavailable.
SLOW MOTION PLAY
Press
/ during play.
Each time the button is pressed, the
speed of slow forward/reverse changes
according to the disc as follow.
DVD:
Normal Playback 2X 4X 8X
(Play)
/ buttons
PAUSE
Pressing on the remote control during
playback will stop play temporary. To
return to normal playback, press
on
the remoter control.
MUTE
Will mute the sound, but the disc
continues playing. When you unmute the
sound (press MUTE again), sound will
resume.
REPEAT
FOR DVD:
Press the REPEAT button to select
repeat mode as follow.
CHAPTER REPEAT ON TITLE REPEAT ON
REPEAT OFF
FOR VCD/CD:
Press the REPEAT button to select
repeat mode as follow.
REP-ONE REP-ALL REPEAT OFF
1. Continuously repeat at the current
chapter/track, when selected REPONE mode.
2. Select REP-ALL mode to continuously
repeat all chapter/track on the current
disc.
3. When the player finishes playback the
current discc last chapter/track, it will
stop and display the elapsed time.
When REPEAT OFF mode is selected,
REP-ONE & REP-ALL disappears
from screen display.
4. REPEAT feature does not support
VCD2.0 (with PBC ON).
A-B
A-B repeat allows a passage to be
repeated continuously. Press A-B button
at the start of the required passage, then
press A-B button again at the end of the
passage. To revert to normal playing,
press A-B button again. Each time the
button pressed, the screen will display
as follows:
A TO B SET A A TO B SET B A TO B CANCELLED
14
OPERATION
DISC SEARCH (GOTO)
FOR DVD
Press GOTO button twice, the screen will
display the following message:
TITLE 01/01 TIME -- : -- : --
00:00:25
You can select the item you want to
watch through TIME setting by using
numeric buttons and ENTER key.
FOR CD/VCD (WITH PBC OFF):
Press GOTO button once, the screen will
display the following message:
GOTO -- : --
00:00:25
Use numeric buttons to input the time
directly.
ZOOM
Allows the picture to be incresed in size.
Press ZOOM to toggle among 1.5 scale,
2.0 scale and 3.0 scale.
RANDOM
Press RANDOM button, track selection
will be made in random order. The display
screen will show “SHUFFLE ON” on the
screen. Press RANDOM button again,
“SHUFFLE OFF” appears and release
the mode.
PROGRAM
In stop mode, press PROGRAM button,
the screen will display “PROGRAM
P00:00”. For example: press numeric
button 4 and
P01:04” appears. It means track 4 will be
played first.
MODE SELECTION
Press MOD button on the front panel of
the unit or MODE button on the remote
control to select among DVD and AV
mode. When select one mode, the
corresponding indicator on the front panel
will be illuminated.
button, “PROGRAM
VOLUME LEVEL ADJUSTMENT
Press VOL +/VOL - on the front panel or
VOLUME +/- on the remote control to
increase or decrease the volume level.
LIGHT SWITCH
The two car dome lamps on the unit will
be on in some needed situations. There
are three settings for the car dome lamp
operation: OFF, AUTO, and ON, refer to
the light switch.
A. OFF: To turn off the lamp.
B. AUTO: To make the lamp turned on
only when car doors are opened.
C. ON: To turn on the lamp.
JACK FOR EARPHONE (
)
There are two jacks for earphone. You
can connect an earphone to anyone of
the jacks to receive sound signal.
EARPHONE VOLUME ADJUSTMENT
Slide the knob on the side of the DVD unit
to increase or decrease the volume level
of the earphone.
REMOTE SENSOR (IR)
Point the remote handset to the remote
sensor IR on the front panel. Receive the
signal from remote handset.
TURNING THE UNIT ON/OFF
Press the
(POWER) button on the front
panel or on the remote control to turn the
unit on or off.
Monitor Release
Press the button on the unit to eject the
screen display from the base at a little
angle. Then you can easily turn the display
upward or downward for good viewing.
INFRARED TRANSMITTING WINDOW
There are six infrared transmitting lights
inside the window on the unit, the user
can put on the infrared wireless
headphones supplied with the unit and
hear the sound signal emitting from the
window.
SPEAKER ON/OFF SWITCH:
When you eject the monitor and turn it
upward, you will see a speaker on/off
switch on the base. Press it to switch the
speakers on/off.
15
OPERATION
MENU FUNCTION
Press the MENU button on the unit or on
the remote control during DVD, AV mode
to display the adjustment items on the
screen.
MENU
BRIGHT 20
CONTRAST 25
COLOR 45
TINT 10
TRANSMIT ON
SCREEN 16:9
Press MENU button repeatedly to
select among BRIGHT, CONTRAST,
COLOR and TINT (For the unit with NTSC
system) items and etc. Press VOL+/VOL-
buttons on the unit or VOLUME +/-
buttons on the remote control to adjust
the corresponding item.
Note: When you set the TV TYPE item
to “PAL ” in “PREFERENCES SETUP”,
there is no “TINT” item to display.
The TRANSMIT item is effective when
the unit has the infrared transmitting
function. In TRANSMIT item, there is ON
or OFF to be selected. When set it to ON,
the sound signal can be emitted from the
infrared transmitting window on the unit
and you can use the infrared wireless
headphone to hear the sound signal.
In SCREEN item, you can select
appropriate TV aspect ratio (4:3 or 16:9)
using the VOL +/VOL- buttons on the unit
or VOLUME +/- buttons on the remote
control.
ON-SCREEN DISPLAY FUNCTION
Press the DISPLAY button during
playback to display the contents of the
current disc on the screen.
Example:
DVD:
(1) Press DISPLAY for the first time:
TITLE 01/03 CHAPTER 002/025
00:02:25
Title Number, Total Title Number, Chapter
Number, Total Chapter Number of this
Title of the disc currently being played
will be shown on the screen, along with
the elapsed time.
(2) Press DISPLAY for the second time:
TITLE REMAIN
01:46:58
(3) Press DISPLAY for the third time:
CHAPTER ELAPSED
00:00:24
(4) Press DISPLAY for the fourth time:
CHAPTER REMAIN
00:01:39
(5) Press DISPLAY for the fifth time:
The message on the screen will be cleared.
VCD:
(1) Press DISPLAY for the first time:
SINGLE ELAPSED
00:00:25
16
OPERATION
(2) Press DISPLAY for the second time:
SINGLE REMAIN
00:03:15
(3) Press DISPLAY for the third time:
TOTAL ELAPSED
00:00:25
(4) Press DISPLAY for the fourth time:
TOTAL REMAIN
00:40:35
(5) Press DISPLAY for the fifth time:
The message on the screen will be cleared.
CD:
(1)Press DISPLAY for the first time:
SINGLE ELASPED
00:00:25
TRACK : 01/14
(2)Press DISPLAY for the second time:
SINGLE REMAIN
00:03:15
TRACK : 01/14
(3)Press DISPLAY for the third time:
TOTAL ELASPED
00:00:25
TRACK : 01/14
(4) Press DISPLAY for the fourth time:
TOTAL REMAIN
00:40:35
TRACK : 01/14
(5) Press DISPLAY for the fifth time:
The message on the screen will be cleared.
MP3 (When set to NO MENU in SMART
NAV item):
(1) Press DISPLAY for the first time:
CHAPTER ELASPED 00:00:25
TRACK : 01/123
(2) Press DISPLAY for the second time:.
CHAPTER REMAIN 00:04:25
TRACK : 01/123
(3) Press DISPLAY for the third time:
The message on the screen will be cleared.
MULTI-AUDIO LANGUAGE FUNCTION
For DVD:
Press AUDIO on the remote control
during playback.
Each time the button is pressed, the
audio soundtrack language changes in
sequential order.
Notes:
- The language number is different
according to the disc.
- Some disc only contain one language
soundtrack.
- When no different language
soundtrack are recorded,
displayed at screen left top corner.
For VCD/CD:
Press AUDIO on the remote control
during playback.
It is possible to switch the sound
between monaural and stereo sound.
17
will be
OPERATION
MONO LEFT MONO RIGHT STEREO
TITLE MENU FUNCTION
(FOR DVD ONLY)
If the DVD has multiple titles recorded on
the disc. It can select preferred title from
the title menu to start playback.
- Press TITLE during playback.
The title menu is display.
- Press the cursor button shown in
screen display, select preferred title
by the cursor button and confirmed
by ENTER key.
MULTI-SUBTITLE LANGUAGE
FUNCTION
(FOR DVD ONLY)
Press SUBTITLE during playback.
Each time the button is pressed, the
subtitle language changes in sequential
order.
Notes:
- The language number is different
according to the disc.
- Some discs only contain one subtitle
language.
- When no different subtitle language
are recorded,
will be displayed at
screen left top corner.
MULTI-ANGLE FUNCTION
(FOR DVD ONLY)
Press ANGLE during playback.
Each time the button is pressed, the
angle changes in sequential order.
Notes:
- The angle number is different
according to the disc.
- The function only works for discs
having scenes recorded at different
angles.
- When no different angle are recorded,
will be displayed at screen left top
corner.
MP3 DISC PLAY
MP3 disc is playing as the format of
FOLDER.
For example:
SMART NAVI
ROOT
CD01
CD02
CD03
CD04
CD05
PLAY MODE
In stop mode, use
remote control to select the item or folder
(such as CD01, CD02...), and press
ENTER button on the remote control to
confirm, then select the desired track
(such as 001 PLUMT, 002 RZID...) on the
current folder to play.
Pressing REPEAT button repeatedly can
select three kinds of repeat play mode.
REP-ONE:
Play the same song over and again.
FOLDER REP:
Play all songs in the current directory
in sequence, over and again.
FOLDER:
Play all songs in the current directory
once.
When select PLAY MODE , press
change between the following mode:
SINGLE REP-ONE FOLDER FOLDER REP
DISC SCAN DISC DISC REP
SHUFFLE ON PROGRAM PXXX
In the playback, use
item ahead or back.
: Rapid reverse, : Rapid advance
Note: The FOLDER cannot be selected
during playing. It can be selected after
(Stop) button pressed.
MP3 001 PLUMT
MP3 002 RZID
MP3 003 ASCIS
MP3 004 DCYI
MP3 005 BFZ
DISC
/ , / on the
/ to
or to skip an
18
SETUP
INITIAL SETUP
SETUP MENU --- MAIN PAGE
GENERAL SETUP
SPEAKER SETUP
AUDIO SETUP
PREFERENCES
EXIT SETUP
1. Press SETUP in the stop mode.
(Press the stop button twice to ensure
the player is in STOP mode.)
2. The initial SETUP menu is displayed.
3. Select the preferred item by using the
/ buttons.
4. Press ENTER buttons.
a. GENERAL SETUP
This setup page includes all the
item of TV display & audio output
feature. The detail please refer to
GENERAL SETUP MENU.
b. SPEAKER SETUP
This is to activate the audio output
from DOLBY AC3 5.1 DOWNMIX
to 2 channel mode. Please refer to
SPEAKER SETUP MENU.
c. AUDIO SETUP
This setup page includes all the
items for AUDIO. Please refer to
AUDIO SETUP MENU.
d. PREFERENCE SETUP
This setup page includes all the
configuration of support feature.
The detail please refer to
PREFERENCES SETUP MENU.
GENERAL SETUP
--- GENERAL PAGE ---
TV DISPLAY
PIC MODE
ANGLE MARK
OSD LANG
CAPTIONS
SCR SAVER
MAIN PAGE
Video Material
4:3
16:9
Normal
TV display setup
This is to select the appropriate TV
aspect (4:3 or 16:9) according to the
connected TV set.
Normal/PS (For 4:3 TV)
Played back in the PAN & SCAN style.
(If connected to wide-screen TV, the left
and right edges are cut off.)
Normal/LB (For 4:3 TV)
Played back in letterbox style.
(If connected to wide-screen TV, black
bands appear at top and bottom of the
screen.)
Wide (For 16:9 TV)
Select when a wide-screen TV set is
connected.
NORMAL/PS
NORMAL/LB
WIDE
TV Screen
4:3 Wide (16:9)
Pan Scan Letter-box
19
SETUP
--- GENERAL PAGE ---
TV DISPLAY
PIC MODE
ANGLE MARK
OSD LANG
CAPTIONS
SCR SAVER
MAIN PAGE
PIC mode setup
Select AUTO, the player PIC mode will
depend on DVD disc.
Select HI-RES format for best image
resolution.
Select N-FLICKER format on format on
image or picture under noise affect.
--- GENERAL PAGE ---
AUTO
HI-RES
N-FLICKER
--- GENERAL PAGE ---
TV DISPLAY
PIC MODE
ANGLE MARK
OSD LANG
CAPTIONS
SCR SAVER
MAIN PAGE
OSD LANG type setup
Select the preferred OSD (On Sreen
Display) language by using the
buttons.
--- GENERAL PAGE ---
TV DISPLAY
PIC MODE
ENGLISH
FRENCH
GERMAN
ITILAIN
SPANISH
/
TV DISPLAY
PIC MODE
ANGLE MARK
OSD LANG
CAPTIONS
SCR SAVER
MAIN PAGE
ANGLE MARK display setup
If it is set to ON, when the multi-angle
DVD disc is playing, (the angle mark)
will appear on the screen; if it is set to
OFF, the mark will not appear.
ON
OFF
ANGLE MARK
OSD LANG
CAPTIONS
SCR SAVER
MAIN PAGE
CAPTIONS setup
Activate the CAPTIONS feature by
selecting ON. And deactive this feature
by selecting OFF.
20
ON
OFF
SETUP
--- GENERAL PAGE ---
TV DISPLAY
PIC MODE
ANGLE MARK
OSD LANG
CAPTIONS
SCR SAVER
MAIN PAGE
SCR SAVER setup
Select the SCR SAVER ON/OFF.
ON
OFF
SPEAKER SETUP
--- SPEAKER SETUP PAGE ---
DOWNMIX
MAIN PAGE
LT/RT
STEREO
AUDIO SETUP
--- AUDIO SETUP ---
SPDIF
OP MODE
DYNAMIC
LPCM OUTPUT
MAIN PAGE
SPDIF
This is to activate the digital audio
output on or off.
--- AUDIO SETUP ---
SPDIF
OP MODE
DYNAMIC
LPCM OUTPUT
OFF
ON
LINE OUT
RF REMOD
This is to activate the audio output from
DOLBY AC3 5.1 DOWNMIX to 2 channel
mode. Select the preferred SPEAKER
connection by using the cursor buttons.
- Select the LT/RT to activate the Dolby
surround compatible output.
- Select the STEREO to activate simple
stereo mode.
MAIN PAGE
OP MODE
There are two operating modes for the
Dolby Digital decoder: LINE OUT and
RF REMOD.
21
SETUP
--- AUDIO SETUP ---
SPDIF
OP MODE
DYNAMIC
LPCM OUTPUT
FULL
6/8
4/8
2/8
OFF
MAIN PAGE
Dynamic Range Control
Select DYNAMIC and adjust the dynamic
range of a Dobly Digital encoded
program. There are 8 steps between full
compression and off compression.
--- AUDIO SETUP ---
PREFERENCES SETUP
--- PREFERENCES PAGE ---
TV TYPE
AUDIO
SUBTITLE
DISC MENU
PARENTAL
PASSWORD
DEFAULTS
SMART NAV
LOGO
MAIN PAGE
TV type setup
This player can play discs recorded in
either PAL or NTSC format.
Select NTSC format, when you
connected to NTSC TV.
Select PAL format, when you connected
to PAL TV.
Select AUTO format, the player TV output
format will be according to the DVD disc
format.
AUTO
NTSC
PAL
SPDIF
OP MODE
DYNAMIC
LPCM OUTPUT
LPCM 48K
LPCM 96K
MAIN PAGE
LPCM OUTPUT
Select the LPCM OUTPUT between
LPCM 48K and LPCM 96K.
--- PREFERENCES PAGE ---
TV TYPE
AUDIO
SUBTITLE
DISC MENU
PARENTAL
PASSWORD
DEFAULTS
SMART NAV
LOGO
MAIN PAGE
ENGLISH
FRENCH
SPANISH
CHINESE
JAPANESE
GERMAN
ITALIAN
AUDIO language setup
Select the preferred AUDIO soundtrack
by using the cursor buttons.
22
SETUP
--- PREFERENCES PAGE ---
TV TYPE
AUDIO
SUBTITLE
DISC MENU
PARENTAL
PASSWORD
DEFAULTS
SMART NAV
LOGO
MAIN PAGE
ENGLISH
FRENCH
SPANISH
CHINESE
JAPANESE
GERMAN
ITALIAN
OFF
SUBTITLE language setup
Select the preferred SUBTITLE language
by using the cursor buttons.
--- PREFERENCES PAGE ---
TV TYPE
AUDIO
SUBTITLE
DISC MENU
PARENTAL
PASSWORD
DEFAULTS
SMART NAV
LOGO
MAIN PAGE
ENGLISH
FRENCH
SPANISH
CHINESE
JAPANESE
GERMAN
ITALIAN
--- PREFERENCES PAGE ---
TV TYPE
AUDIO
SUBTITLE
DISC MENU
PARENTAL
PASSWORD
DEFAULTS
SMART NAV
LOGO
MAIN PAGE
1 G
2
3 PG
4 PG 13
5
6 PG-R
7 NC-17
8 ADULT
NO PARENTAL
PARENTAL
Select suitable parental guidance by the
cursor buttons and conformed by
pressing ENTER button.
--- PREFERENCES PAGE ---
TV TYPE
AUDIO
SUBTITLE
DISC MENU
PARENTAL
PASSWORD
DEFAULTS
SMART NAV
LOGO
MAIN PAGE
CHANGE
DISC MENU language setup
Select the preferred DISC MENU
language by using the cursor buttons.
PASSWORD
Select CHANGE and press ENTER
button. Type the old password (The initial
factory code is 3308) and key in 4
characters password now you want to
use, and retype again to confirm key in
correctly.
23
SETUP
--- PREFERENCES PAGE ---
TV TYPE
AUDIO
SUBTITLE
DISC MENU
PARENTAL
PASSWORD
DEFAULTS
SMART NAV
LOGO
MAIN PAGE
RESET
DEFAULTS
Select reset to become factory initial
setting.
--- PREFERENCES PAGE ---
TV TYPE
AUDIO
SUBTITLE
DISC MENU
PARENTAL
PASSWORD
DEFAULTS
SMART NAV
LOGO
MAIN PAGE
NO MENU
WITH MENU
SMART NAV
In this item, you can select NO MENU
mode or WITH MENU mode.
--- PREFERENCES PAGE ---
TV TYPE
AUDIO
SUBTITLE
DISC MENU
PARENTAL
PASSWORD
DEFAULTS
SMART NAV
LOGO
MAIN PAGE
ORIG LOGO
CUST LOGO
LOGO
Select ORIG LOGO (original picture when
the unit turns on) or CUSTLOGO
(customer-set picture when the unit turns
on).
DEFAULTS TABLE
General Setup
Speaker Setup
Audio Setup
Preferences TV Type AUTO
24
TV Display Normal/PS
PIC Mode AUTO
Angle Mark ON
OSD Language
English
Captions OFF
SCR Saver OFF
Downmix Stereo
SPDIF OFF
OP Mode Line Out
Dynamic FULL
LPCM Output
LPCM 96K
Audio English
Subtitle English
DISC Menu English
Parental 6 PG-R
Password 3308
Smart NAV With Menu
Logo Orig Logo
TROUBLE SHOOTING
If it appears that your DVD unit is faulty,
first consult this checklist. It may be that
something simple has been overlooked.
Under no circumstances should you
try to repair the player yourself, as this
will invalidate the warranty. Only
qualified service personnel can remove
the cover or service this player.
NO POWER
• Check if the on/off button on the front
of the player is set to on.
• Check if AC or DC power plug of the
mains unit is properly connected.
• Check if there is power at the AC or
DC outlet.
NO PICTURE
• Check if the mode it set to proper state,
such as DVD mode and AV mode.
• Check the video connection.
DISTORTED PICTURE
• Check the disc for fingerprints and
clean with soft cloth, wiping from centre
to edge.
• Sometimes a small amount of picture
distortion may appear. This is not a
malfunction.
COMPLETELY DISTORTED PICTURE
• The disc format is not according to the
TV-set used (PAL/NTSC).
NO COLOR IN PICTURE
• The disc format is not according to the
TV-set used (PAL/NTSC).
DISC DOES NOT PLAY
• Ensure the disc label is upwards.
• Clean the disc.
• Check if the disc is defective by trying
another disc.
NO SOUND
• Check audio connections.
• If using a HIFI amplifier, try another
sound source.
DISTORTED SOUND FROM HIFI
AMPLIFIER
• Check to make sure that no audio
connections are made to the amplifier
phono input.
NO RETURN TO START-UP SCREEN
WHEN DISC IS REMOVED
• Press POWER to turn off the unit, then
press it again to turn on the unit.
THE PLAYER DOES NOT RESPOND TO
THE REMOTE CONTROL
• Aim the remote control directly at the
sensor on the front of the player.
• Avoid all obstacles which may interfere
with the signal path.
• Inspect or replace the remote control
batteries.
DISTORTED OR B/W PICTURE
• The disc format is not according to the
TV-set used (PAL/NTSC).
NO AUDIO AT DIGITAL OUTPUT
• Check the digital connections
• Check the Digital Audio menu to make
sure that the digital output is correctly
set.
• Check if the audio format of the
selected audio language matches your
receiver’s capabilities.
BUTTONS DO NOT WORK
• Turn the player off and on with the
power on/off button on the front of the
player.
25
SPECIFICATIONS
Supply Voltage : 12V DC (11V-15V), test voltage 14.4V, negative ground
Current Consumption : Less than 2A
Signal System : Compositive video 1.0Vp-p 75Ω
Discs Played : (1) DVD-VIDEO Disc
Audio Output Level : 10kΩ (2 ch 2.0 Vrms)
Audio Signal Output
Characteristics : (1) Frequency Response 20 Hz - 20 KHz
: (3) Wow and Flutter Below measurable limits
Note:
Specifications and design are subject to modification, without notice, due to
improvements in technology.
5” (12 cm) single-sided, single-layer
5” (12 cm) single-sided, double-layer
(2) Compact Disc (CD-DA/CD-R/CD-RW/MP3)
(3) 5” (12cm) VIDEO CD
: (2) S/N Ratio 80 dB (JIS)
This product incorporates copyright protection technology that is
protected by method claims of certain U.S. patents and other intellectual
property rights owned by Macrovision Corporation and other rights
owners. Use of this copyright protection technology must be authorized
by Macrovision Corporation, and is intended for home and other limited
viewing uses only unless otherwise authorized by Macrovision
Corporation. Reverse engineering or disassembly is prohibited.
26
www.pyleaudio.com
88-V1343-33
Loading...
