OWNER’S MANUAL

Please read before using this equipment.

Cat. No. 20-228

DX-398

All-Band Shortwave Receiver

with Radio Data System

FEATURES

Your RadioShack DX-398 All-Band
Shortwave Receiver with Radio Data
System brings you the voices of the
world. In the 14 international short­wave (SW) bands, you can hear news
broadcasts and other programs from
sources around the world, such as the
British Broadcasting Corporation, Ra­dio Cairo, and Radio Beijing. You can
set your receiver so it displays Radio
Data System (RDS) call letters of
those stations that transmit an RDS
signal.

You can get emergency information
firsthand by listening to amateur radio
broadcasts, including single sideband
(SSB) voice transmissions.

In the longwave (LW) band, you can
hear ship-to-shore calls, other marine
and aeronautical services, and some­times even hurricane reports. You can
also tune to local broadcasts in the FM
and medium-wave (MW) bands. (In the
United States, we commonly call the
MW band the AM band.)

In addition, you can connect a cassette
recorder to the receiver’s record line
out and standby jacks so you can di­rectly record your favorite programs
live or at a preset time.

Your receiver’s features include:

Large, Fast-Response Display

—
shows the time, band and frequency,
signal strength, and other indicators.

212 Preprogrammed Shortwave
Stations —

let you rapidly tune to the
most popular U.S. and international
shortwave stations.

Three Timer Alarms

— let you set the
buzzer to sound or the radio to turn on
daily at up to three specified times.

Record Line Out and Standby Jacks

— let you connect a tape recorder so
you can record broadcasts live or at a
preset time.

Dual Time

— includes a primary and a
secondary clock, so you can set one to
your local time and the other to UTC
(Coordinated Universal Time — for­merly known as Greenwich Mean
Time) or to the local time of a city in an­other time zone.

World Time Zone

— provides the cor­rect time for 42 cities worldwide, once
you set your local time.

Search Tuning

— scans up or down

the band for the next station.

Memory Tuning

— stores up to 306
frequencies so you can quickly select
your favorite stations.

Digital Synthesized Radio

sures accurate, stable tuning.

© 1997, 1999 Tandy Corporation.

RadioShack is a registered trademark used by Tandy Corporation.

2

— en-

All Rights Reserved.

Priority Button

— lets you quickly

store and recall your favorite station.

Auto Tuning System (ATS)

ceiver finds the stations with strong
signals and stores them in memory in
order by signal strength.

— the re-

and select up to nine MW/FM frequ en­cies in two pages, nine LW frequencies
in one page, and 261 SW frequencies
in 29 pages.

Rotary Tuning Dial

ally tune desired frequencies. You can
select a higher tuning increment for
faster tuning or a lower one for fine tun­ing, or lock the dial to prevent acciden­tally changing the tuned frequency.

Memory Lock

frequency changes.

Control Lock

setting changes.

Sleep Timer

er so it turns itself off after a length of
time you set, so you can fall asleep as
you listen to it.

MW Step Setting

change the frequency step setting to
match the MW (AM) broadcast fre­quency step used by many other coun­tries.

RF Gain Control

receiver’s sensitivity when you listen to
SW/LW/MW broadcasts, to provide
the best possible reception.

— lets you set the receiv-

— lets you manu-

— prevents accidental

— prevents accidental

— lets you easily

— lets you adjust the

Edit

— lets you create and edit station
names for FM/MW/LW bands, page
names for SW bands, and home/world
city names for easy identification.

Tone Control

tone setting for different types of
broadcasts such as news, music, and
so on.

Battery Power/Signal Strength Indi­cator

— displays the battery’s power

and the strength of the received signal.

Memo Label

information such as the memory loca­tion numbers of your favorite stations.

Three Power Options

er the receiver from internal batteries,
standard AC power (with an optional
AC adapter), or your vehicle’s battery
(with an optional DC cigarette lighter
adapter).

— lets you adjust the

— lets you record helpful

— let you pow-

Narrow/Wide Control

duce interference from adjacent sta­tions when you listen to SW, MW (AM),
and LW broadcasts.

Page Memory Location

store and select frequencies in storage
locations called

pages

— lets you re-

— lets you

. You can store

3

Your receiver is preset to cover the
following bands:

THE FCC WANTS YOU
TO KNOW

Band (Meters) Frequency Range

(MHz)

120 ................................ 2.300–2.495

90 .................................. 3.200–3.400

75 .................................. 3.900–4.000

60 .................................. 4.750–5.060

49 .................................. 5.900–6.200

41 .................................. 7.100–7.350

31 .................................. 9.400–9.990

25 .............................. 11.600–12.100

21 .............................. 13.500–13.870

19 .............................. 15.100–15.800

16 .............................. 17.480–17.900

15 .............................. 18.900–19.020

13 .............................. 21.450–21.750

11 .............................. 25.600–26.100

This equipment complies with Part 15
of the FCC Rules. Operation is subject
to the following two conditions: (1)
This device may not cause harmful in­terference, and (2) this device must
accept any interference received, in­cluding interference that may cause
undesired operation.

Your receiver might cause TV or radio
interference even when it is op erating
properly. To determine whether your
receiver is causing the interference,
turn it off. If the interference goes
away, your receiver is causing it.

Try to eliminate the interference by:

• moving your receiver away from
the TV or radio

• connecting your receiver to an
outlet that is on a different electri­cal circuit from the TV or radio

• contacting your local RadioShack
store for help

If you cannot eliminate the interfer­ence, the FCC requires that you stop
using your receiver. Changes or modi­fications not expressly approved by
RadioShack could void the user’s
FCC authorization to operate this
equipment.

4
