Pilz PDP67 F 8DI ION User Manual

Operating Manual PDP67 F 8DI ION

Operating Manual PDP67 F 8DI ION

PDP67 F 8DI ION

Decentralised periphery

Operating Manual — No. 1001643-EN-07

This document is a translation of the original document.

All rights to this documentation are reserved by Pilz GmbH & Co. KG. Copies may be made
for internal purposes.

Suggestions and comments for improving this documentation will be gratefully received.

Pilz

®

, PIT®, PMI®, PNOZ®, Primo®, PSEN®, PSS®, PVIS®, SafetyBUS p®, SafetyEYE®,
SafetyNET p®, the spirit of safety® are registered and protected trademarks of
Pilz GmbH & Co. KG in some countries.

SD means Secure Digital.

Preface

Contents

Contents

Contents Page

Chapter 1 Introduction

1.1 Validity of documentation 1-1

1.1.1 Retaining the documentation 1-1

1.2 Overview of documentation 1-2

1.3 Definition of symbols 1-3

Chapter 2 Overview

2.1 Unit structure 2-1

2.1.1 Scope of supply 2-1

2.1.2 Unit features 2-1

2.2 Front view 2-2

Chapter 3 Safety

3.1 Intended use 3-1

3.2 Safety regulations 3-2

3.2.1 Use of qualified personnel 3-2

3.2.2 Warranty and liability 3-2

3.2.3 Disposal 3-2

Chapter 4 Function description

4.1 Unit properties 4-1

4.1.1 Operation 4-1

4.1.1.1 Inputs 4-1

4.1.1.2 Outputs 4-1

4.1.2 Data download 4-1

4.1.3 Diagnostics 4-2

Chapter 5 Installation

5.1 General installation guidelines 5-1

5.1.1 Dimensions 5-1

Chapter 6 Wiring

6.1 General wiring guidelines 6-1

6.2 Connector pin assignment 6-2

6.3 Wiring examples 6-3

6.3.1 Example: Single-channel, failsafe input de­vice, without test pulse

6.3.2 Example: Dual-channel input devices,
without test pulses

6.3.3 Example: Single-channel, failsafe input de­vice, with test pulse

6.3.4 Example: Dual-channel, failsafe input de­vice, with test pulse

6-3

6-4

6-5

6-7

Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

1

Contents

Chapter 7 Operation

7.1 Messages 7-1

7.1.1 Display elements for device diagnostics 7-1

Chapter 8 Technical details

8.1 Technical details 8-1

8.2 Order reference 8-3

Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany

2

Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

1 Introduction

1.1 Validity of documentation

11000IntroductionIntroduction1-1.1Validity of docume ntation1100Validi ty of document ation1-Einf Gltigkeit der Dokumentati onPDP67_VA

This documentation is valid for the products PDP67 F 8DI ION, PDP67

Einf Einleitung

1.1.1 Retaining the documentation

Retaining the documentation1-Einf Aufbewahren

F 8DI ION VA. It is valid until new documentation is published.

This operating manual explains the function and operation, describes
the installation and provides guidelines on how to connect the product.

This documentation is intended for instruction and should be retained
for future reference.

Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

1-1

1 Introduction

1.2 Overview of documentation

1.2Overview of documentation1200Overview of documentation1-Einf_Uebersicht_über_die_Doku_6_Inbetriebnahme

1 Introduction

The introduction is designed to familiarise you with the contents, struc­ture and specific order of this manual.

2 Overview

This chapter provides information on the product's most important fea­tures.

3 Safety

This chapter must be read as it contains important information on in­tended use.

4 Function Description

This chapter describes the product's mode of operation.

5 Installation

This chapter explains how to install the product.

6 Commissioning

This chapter describes the product's commissioning and wiring.

7 Operation

This chapter describes how to operate the product and gives tips in the
case of a fault.

8 Technical Details

This chapter contains the product's technical details and order refer­ence.

1-2

Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

1 Introduction

1.3 Definition of symbols

1.3Definition of symbols1300Definition of symbols1-Einfhrung Zeichen

Information that is particularly important is identified as follows:

DANGER!

This warning must be heeded! It warns of a hazardous situation
that poses an immediate threat of serious injury and death and
indicates preventive measures that can be taken.

WARNING!

This warning must be heeded! It warns of a hazardous situation
that could lead to serious injury and death and indicates preven­tive measures that can be taken.

CAUTION!

This refers to a hazard that can lead to a less serious or minor
injury plus material damage, and also provides information on
preventive measures that can be taken.

NOTICE

This describes a situation in which the unit(s) could be damaged
and also provides information on preventive measures that can
be taken. It also highlights areas within the text that are of partic­ular importance.

INFORMATION

This gives advice on applications and provides information on
special features.

Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

1-3

1 Introduction

1-4

Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

2 Overview

2.1 Unit structure

22000OverviewOverview2-2.1Unit structure2100Unit structure2-

2.1.1 Scope of supply

Scope of supply2-Eigenschaften

2.1.2 Unit features

Unit features2-Gerätemerkmale_Verwendung_PDP_VA

 Decentralised input module PDP67 F 8DI ION/PDP67 F 8DI ION VA
 4 blind plugs 380 324

Verwendung/Bildunterschrift_PDP_DI

Geraetemerkmale_Zusatz BA Einleitung

Gertemerkmale_PDP_IP67

Application of the products PDP67 F 8DI ION, PDP67 F 8DI ION VA:

Decentralised input module for connection to a Pilz control system, for
use in a rugged industrial environment up to protection type IP67.

The product has the following features:

 Protection type IP67
 8 inputs for connecting 8 single-channel or 4 dual-channel sensors
 8 outputs, which can be configured as

– Standard outputs
– Test pulse outputs
– 24 V outputs

 LED for:

– Operating status
– Connection status
–Fault
– Input status at each input

Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

2-1

2 Overview

2.2 Front view

2.2Front view2200Front view2-Klemmenbelegung PDP67 8DI ION

Legende PDP IP67

Key:

 X1 ... X4:

Inputs

 X5:

Interface to the control system or to X6 on the upstream module

 X6:

Interface to X5 on the downstream module

 LEDs:

–Device
–Fault
–Traffic
– IO0 ... IO7

2-2

Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

3 Safety

3.1 Intended use

33000SafetySafety3-3.1Intended use3100Intended use3-Bestimmung/Gertebeschreibung_PDP_DI

Bestimmung/Gertebeschreibung_PDP_DI_HP_Anschluss_Multi

Bestimmung/Gerätebeschreibung_EMV+Ausschluss

The products PDP67 F 8DI ION, PDP67 F 8DI ION VA are decentralised
input modules designed for use in a rugged industrial environment up to
protection type IP67.

The module can be connected to a link module PNOZ ml2p or PNOZ
mml2p from the configurable control system PNOZmulti.

Intended use includes making the electrical installation EMC-compliant.
The product is designed for use in an industrial environment. It is not
suitable for use in a domestic environment, as this can lead to interfer­ence.

The following is deemed improper use in particular:

 Any component, technical or electrical modification to the product
 Use of the product outside the areas described in this manual
 Use of the product outside the technical details (see chapter entitled

“Technical Details”)

Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

3-1

3 Safety

3.2 Safety regulations

3.2Safety regulations3200Safety regulations3-

3.2.1 Use of qualified personnel

Use of qualified personnel3-Sich Qualif. Personal

The products may only be assembled, installed, programmed, commis­sioned, operated, maintained and decommissioned by competent per­sons.

A competent person is someone who, because of their training, experi­ence and current professional activity, has the specialist knowledge re­quired to test, assess and operate the work equipment, devices,
systems, plant and machinery in accordance with the general standards
and guidelines for safety technology.

It is the company's responsibility only to employ personnel who:

 Are familiar with the basic regulations concerning health and safety /

accident prevention

 Have read and understood the safety guidelines given in this descrip-

tion

 Have a good knowledge of the generic and specialist standards ap-

plicable to the specific application.

3.2.2 Warranty and liability

Warranty and liability3-Sich Gewhrleistung_ohne_Veränderungen...

3.2.3 Disposal

Disposal3-Si ch Entsorgung

All claims to warranty and liability will be rendered invalid if:

 The product was used contrary to the purpose for which it is intended
 Damage can be attributed to not having followed the guidelines in the

manual or

 Operating personnel are not suitably trained.

 In safety-related applications, please comply with the mission time t

M

in the safety-related characteristic data.

 When decommissioning, please comply with local regulations regard-

ing the disposal of electronic devices (e.g. Electrical and Electronic
Equipment Act).

3-2

Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

4 Function description

4.1 Unit properties

44000Function descriptionFunction description4-4.1Unit properties4100Unit properties4-

4.1.1 Operation

Operation4-Funktionen_PDP_DI_Konfiguration

The functions of the inputs and outputs are configured in the system
software.

4.1.1.1 Inputs

Inputs4-Funktionen_PDP_DI_Eingänge

Single and dual-channel sensors can be connected to the inputs, with
or without test pulses.

Input signals must show a “High” (“1” signal) of 15 VDC (+15 ... +30 VDC)
and a “Low” (“0” signal) of 0 VDC (-3 ... +5 VDC).

4.1.1.2 Outputs

Outputs4-Funktionen_PDP_DI_Ausgänge

The input status is signalled to the control system via the bus.

Green LEDs indicate the status of the inputs.

Test pulses can be used to check the inputs for shorts across contacts
and correct functionality.

The outputs can be used as standard outputs, as test pulse outputs or
as 24 VDC outputs.

The test pulse outputs are suitable for testing the sensor wiring. All safe­ty-related inputs must operate in accordance with the failsafe principle
(on switching off).

Two test pulses are available on each plug-in connector; these test puls­es are permanently assigned to the inputs. The assignment of the test
pulses to the inputs cannot be changed in the system software's config­urator.

If the test pulse outputs are not being used, they can be configured as
standard outputs or 24 VDC outputs in the system software's configu­rator.

Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

4-1

4 Function description

4.1 Unit properties

4.1.2 Data download

Data download4-Funktionen_PDP_Datenübertragung

Communication with the control system is via a safe data link. Data is
exchanged cyclically.

4.1.3 Diagnostics

Diagnostics4-Funktionen_PDP_DI_Diagnose

The status and error messages shown by the LEDs are saved in an error
stack. The system software can read this error stack.

4-2

Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

5 Installation

60

4,5

123

133

4,5

29,6

5,6

22,1

5.1 General installation guidelines

55000InstallationInstallation5-5.1General installation guidelines5100General installation guidelines5-Montagefläche_PDP

The product must be fastened to a flat mounting surface, so that there
is no strain on the housing when the module is screwed down. The
mounting distances will depend on which plug-in connectors are used
and on the bending radius of the cables.

Montage_PDP - Vorgehensweise

Montage_PDP - Vorgehensweise_Funktionserde an Schraube

Unused connectors should be sealed using blind plugs.

To install the system, proceed as follows:

 Fit 2 x M4 internal threads on the mounting surface.
 Use two fixing screws to attach the product to the mounting plate.
 With shielded cables, connect the functional earth to the upper fixing

screw X0.

5.1.1 Dimensions

Dimensions5-Abmessungen_PDP 67_8DI ION

Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

5-1

5 Installation

5-2

Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

6 Wiring

6.1 General wiring guidelines

66000WiringWiring6-6.1General wiring gu idelines6100Ge neral wiring guidelin es6-Verdrahtung_PDP_DI

Please note:

 Information given in the “Technical details” must be followed.
 In safety-related applications, it is essential that short circuits and

open circuits are unable to cause a hazardous condition within a
plant. The way in which this is done will depend on the degree of haz­ard from the plant section, the switching frequency of the sensors and
the level of safety of the sensors and actuators.

 Please refer to the link module's operating instructions for details of

the maximum cable length.

 Pilz pre-assembled cable can be used to connect the inputs and out-

puts (see order reference).

 We recommend you use pre-assembled Pilz connectors to connect

the inputs and test pulse outputs (see order reference).

CAUTION!

The supply voltages for an external device must be extra low
voltages with safe electrical separation (PELV or SELV) in
accordance with VDE 0100, Part 410.

CAUTION!

In order to guarantee protection type IP67, unused connectors
should be sealed using the blind plugs supplied.

CAUTION!

Make sure that the plug-in connectors are connected to the sen­sors correctly. Once you have run a function test to check that
the connectors are connected to the sensors correctly, the
inputs should be labelled. If the inputs are connected to the sen­sors incorrectly, life-threatening situations may arise on the
plant.

Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

6-1

6 Wiring

2

3

4

1

5

2

3

4

1

5

2

3

4

1

5

6.2 Connector pin assignment

6.2Connector pin assignment6200Connector pin assignment6-Anschluss_PDP_DI_Schnittstellenbelegung

Inputs/outputs
X1 to X4

5-pin M12 female connec­tor
A-coded

Assignment

1: Test pulse x / 24 VDC / ST output.
2: Input X
3: 0 V
4: Input X + 1
5: Test pulse X + 1 / 24 VDC / ST output

Interface to the link mod­ule: X5

5 pin M12 male connector
A-coded

Interface to the next de­centralised module: X6

5-pin M12 female connec­tor
A-coded

Assignment

1: VCC
2: CAN­3: GND
4: CAN+
5: Shield

Assignment

1: VCC
2: CAN­3: GND
4: CAN+
5: Shield

6-2

Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

6 Wiring

6.3 Wiring examples

6.3Wiring examples6300Wiring examples6-

6.3.1 Example: Single-channel, failsafe input device, without test pulse

Example: Single-channel, failsafe input device, without test pulse6-Bsp 1: einkan fehlersich Sensor ungetaktet

Features:

 Depending on the application area and its respective regulations, this

connection diagram is suitable for input devices with frequent and
infrequent operation in accordance with EN ISO 13849-1 up to PL
d and EN IEC 62061 up to SIL CL 2.

 The input device must be approved for failsafe applications.

Bsp: WARNUNG Kurzschluss Bsp. 1

 Please read the instructions provided with the input device.

WARNING!

Short circuits between the cable to the input device and the 24 V
line or between cables to various input devices will not be
detected. Depending on the application, serious injury or death
may result.
Avoid short circuits by

 Appropriate wiring
 Wiring in accordance with the requirements of IEC 61076-2-

101 and IEC 60204-1, clause 14.1.1 and 14.1.2

Bsp 1: einkan fehlersich Sensor ungetaktet_Zeichnung

Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

6-3

6 Wiring

24 V

Single-channel, fail­safe input device

Please ensure safety regulations and EMC guidelines are met!

6.3 Wiring examples

6-4

Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

6 Wiring

6.3 Wiring examples

6.3.2 Example: Dual-channel input devices, without test pulses

Example: Dual-channel input devices, without test pulses6-Bsp 2: zweikan Sensor ungetaktet

Features:

 This type of connection is mainly used for signal inputs with frequent

operation.

 Depending on the application area and its respective regulations, this

connection diagram is suitable for input devices with frequent ope­ration and diverse channels in accordance with EN ISO 13849-1 up
to PL e and EN IEC 62061 up to SIL CL 3, provided the functionality

of both input device channels is monitored in the user program via a
feasibility check.

 The input device must be approved for failsafe applications.
 If you are using input devices with different (diverse) channels, adja-

cent inputs may be used. The user program will detect short circuits

Bsp: WARNUNG Kurzschluss Bsp. 1

via the feasibility check.

Bsp 2: zweikan Sensor ungetaktet_Zeichnung

WARNING!

Short circuits between the cable to the input device and the 24 V
line or between cables to various input devices will not be
detected. Depending on the application, serious injury or death
may result.
Avoid short circuits by

 Appropriate wiring
 Wiring in accordance with the requirements of IEC 61076-2-

101 and IEC 60204-1, clause 14.1.1 and 14.1.2

Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

6-5

6 Wiring

Dual-channel input device
with different
(diverse) channels

24 V

24 V

Please ensure safety regulations and EMC guidelines are met!

6.3 Wiring examples

6-6

Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

6 Wiring

6.3 Wiring examples

6.3.3 Example: Single-channel, failsafe input device, with test pulse

Example: Single-channel, failsafe input device, with test pulse6-Bsp 3: einkan fehlersich Sensor getaktet

Features:

 Depending on the application area and its respective regulations, this

connection diagram is suitable in accordance with EN ISO 13849-1
up to PL d and EN IEC 62061 up to SIL CL 2.

 The input device must be approved for failsafe applications.
 Test pulses can be used to check the inputs for short circuit to 24 V

and correct functionality. Short circuits that short out the input device
(cable from the test pulse to the input device and cable from the input
device to the input) will not be detected.

 Please read the instructions provided with the input device.

Bsp: ACHTUNG Kurzschluss Bsp. 3

 Only input devices with N/C contacts can be tested.

Bsp 3: einkan fehlersich Sensor getaktet_Zeichnung

CAUTION!

Short circuits between the cable to the input device and the 24 V
line or between cables to various input devices will not be
detected.
Avoid short circuits by

 Appropriate wiring
 Wiring in accordance with the requirements of IEC 61076-2-

101 and IEC 60204-1, clause 14.1.1 and 14.1.2

Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

6-7

6 Wiring

Test pulse T0

Single-channel, fail­safe input device

Please ensure safety regulations and EMC guidelines are met!

6.3 Wiring examples

6-8

Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

6 Wiring

Dual-channel input device
with diverse channels

Test pulse T1
Test pulse T0

Test pulse T1

Test pulse T0

Dual-channel input device
with identical channels

Please ensure safety regulations and EMC guidelines are met!

6.3 Wiring examples

6.3.4 Example: Dual-channel, failsafe input device, with test pulse

Example: Dual-channel, failsafe input device, with test pulse6-Bsp 4: zweikan fehlersich Sensor getaktet

Features:

 Depending on the application area and its respective regulations, this

connection diagram is suitable in accordance with EN ISO 13849-1
up to PL e and EN IEC 62061 up to SIL CL 3.

 The input device must be approved for failsafe applications.
 This type of connection is mainly used for signal inputs with infrequent

operation.

 As the test pulses are permanently assigned to the inputs, all short

circuits will be detected, with the exception of short circuits that short
out the input device (cable from the test pulse to the input device and

Bsp 4: zweikan fehlersich Sensor getaktet_Zeichnung

cable from the input device to the input).

Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

6-9

7 Operation

7.1 Messages

77000OperationOperation7-7.1Messages71 00Messages7-Bet rieb_Meldungen_PD P_DI

The module is ready for operation when the "Ready" LED on the link
module is lit continuously.

7.1.1 Display elements for device diagnostics

Display elements for device diagnostics 7-Anzeige Legende 3x

Legend:

Betrieb_Anzeige_PDP_DI

LED on

LED flashes

LED off

LED LED status Meaning

Device Green The unit is ready for operation

Green The supply voltage is/was too low.

Once the fault has been rectified, the LED will not stop flashing until the system
has been switched off and then on again.

The unit is not ready for operation

FAULT Red Internal error

No error

Traffic Yellow Connection to control system established

Yellow Error in the connection to the control system. Flashing stops a max. of 1 min.

after the fault has been rectified.

No connection to control system established

Input LEDs Green 1 signal is present

Green Link module has detected a pulse error.

Once the fault has been rectified, the decentralised input module will continue
to work normally after a wait of just a few seconds.

0 signal is present

Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

7-1

7 Operation

7-2

Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

8 Technical details

8.1 Technical details

88000Technical detailsTechnical details8-8.1Technical details8100Technical details8-][Technische Daten_PDP_DI

Technical details

Application range Standard/Failsafe
Electrical data

Internal supply voltage Supply
Supply voltage U
Voltage tolerance -30 %/+25 %
Power consumption at U

Inputs

Number 8
Input voltage 24 V DC
Input current 3.0 mA
Potential isolation between input and internal bus voltage no

Outputs (configurable as semiconductor outputs or
test pulse outputs)

Voltage 24 V DC
Number of positive-switching single-pole semiconductor
outputs
Short circuit-proof yes
Potential isolation between semiconductor output and in-

ternal bus voltage
Potential isolation between semiconductor output and in-

put
Typ. output current at “1” signal and rated voltage of sem­iconductor output
Permitted current range 0.00 - 0.60 A
Residual current at “0” signal 0.02 mA
Permitted loads inductive, capacitive, resistive
Max. internal voltage drop 200 mV
Terminal voltage when switching off inductive loads -45 V
Number of test pulse outputs 8
Number of outputs that can be configured as test pulses 8
Max. output current at “1” signal 0.50 A
Short circuit-proof yes
Max. cable runs between test pulse output and input 20 m

Hardware processing times

Max. processing time for input when signal changes from
“1” to “0”

Max. processing time for input when signal changes from
“0” to “1”

Min. processing time for input when signal changes from
“1” to “0”
Min. processing time for input when signal changes from
“0” to “1”

Environmental data

Climatic suitability EN 60068-2-78
Ambient temperature in accordance with EN 60068-2-14 -30 - 60 °C
Storage temperaturein accordance withEN 60068-2-1/-2 -40 - 70 °C
Climatic suitability in accordance with EN 60068-2-78 93 % r. h. at 40 °C
Condensation temporary No. 773600
EMC EN 55011: class A, EN 61000-4-11, EN 61000-4-2, EN

DC 24 V

B

B

1.2 W

8

no

no

0.50 A

1.000 ms

1.200 ms

0.50 ms

0.70 ms

61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6,
EN 61000-4-8, EN 61000-4-9

Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

8-1

8 Technical details

8.1 Technical details

Environmental data

Vibration to EN 60068-2-6
Frequency 10 - 55 Hz
Max. acceleration 1g
Shock stress

EN 60068-2-27 15g

11 ms

EN 60068-2-29 10g

16 ms

Protection typein accordance withEN 60529
Housing IP67
Terminals IP67
Airgap creepage in accordance with IEC 60664-1
Overvoltage category III
Pollution degree 2

Mechanical data
Connection type M12 No. 773600

Stainless steel 1.4305 No. 773614

Housing material
Top Valox 855
Labelling bracket (accessories) PC
Dimensions
Height 133.0 mm
Width 60.0 mm
Depth 30.0 mm
Weight 250 g

Si-Kennzahlen_alle

Safety characteristic data

Unit Operating mode EN ISO 13849-

1: 2006

EN 954-1
Category

EN IEC 62061
SIL CL

PFH [1/h] EN ISO

PL

Input

SC inputs single-channel PL d (Cat. 2) Cat. 2 SIL CL 2 9.06E-09 20
SC inputs dual-channel PL e (Cat. 4) Cat. 4 SIL CL 3 1.24E-09 20

Bus interface

Bus interface PL e (Cat. 4) Cat. 4 SIL CL 3 1.94E-09 20

Si_Kennzahlen_Erläuterung_1

All the units used within a safety function must be considered when cal-

Technische Daten_Satz No rmen

culating the safety characteristic data.

The standards current on 2010-03 apply.

13849-1:
2006

[year]

T

M

8-2

Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

8 Technical details

8.2 Order reference

8.2Order reference8200Order reference8-Bestelldaten PDP67 F 8DI ION

Order reference

Product type Features Order no.

PDP67 F 8DI ION Decentralised input module 773 600
PDP67 F 8DI ION VA Decentralised input module, V2A ring nut 773 614

Bestelldaten Zubehör PD P67 F 8DI ION

Order reference: accessories for PDP67 F 8DI ION

Product type Features Order no.

Caps for IP67 modules Blind plugs 380 324

Order reference: Cable

Product type Features Order no.

PSS SB BUSCABLE LC Cable, shielded 1 - 100 m 311 074
PSS67 I/O Cable Cable 1 - 30 m 380 320
PSS67 Cable M8sf M12sm Cable, straight M12 connector, straight M8 socket, 4-pin 3 m 380 200
PSS67 Cable M8sf M12sm Cable, straight M12 connector, straight M8 socket, 4-pin 5 m 380 201
PSS67 Cable M8sf M12sm Cable, straight M12 connector, straight M8 socket, 4-pin 10 m 380 202
PSS67 Cable M8sf M12sm Cable, straight M12 connector, straight M8 socket, 4-pin 30 m 380 203
PSS67 Cable M8sf M12sm Cable, straight M12 connector, angled M8 socket, 4-pin 3 m 380 204
PSS67 Cable M8sf M12sm Cable, straight M12 connector, angled M8 socket, 4-pin 5 m 380 205
PSS67 Cable M8sf M12sm Cable, straight M12 connector, angled M8 socket, 4-pin 10 m 380 206
PSS67 Cable M8sf M12sm Cable, straight M12 connector, angled M8 socket, 4-pin 30 m 380 207
PSS67 Cable M12sf

M12sm
PSS67 Cable M12sf
M12sm
PSS67 Cable M12sf

M12sm
PSS67 Cable M12sf

M12sm
PSS67 Cable M12sf
M12sm
PSS67 Cable M12sf

M12sm
PSS67 Cable M12sf

M12sm
PSS67 Cable M12sf
M12sm

Cable, straight M12 connector, straight M12 socket, 5-pin 3 m 380 208

Cable, straight M12 connector, straight M12 socket, 5-pin 5 m 380 209

Cable, straight M12 connector, straight M12 socket, 5-pin 10 m 380 210

Cable, straight M12 connector, straight M12 socket, 5-pin 30 m 380 211

Cable, angled M12 connector, angled M12 socket, 5-pin 3 m 380 212

Cable, angled M12 connector, angled M12 socket, 5-pin 5 m 380 213

Cable, angled M12 connector, angled M12 socket, 5-pin 10 m 380 214

Cable, angled M12 connector, angled M12 socket, 5-pin 30 m 380 215

Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

8-3

8 Technical details

8.2 Order reference

Order reference: Adapters

Product type Features Order no.

PSEN ma adapter Adapter for connection to safety switch PSENmag and PIT en1.0 380 300
PSEN cs adapter Adapter for connection to safety switch PSENcode 380 301

Order reference: Connectors

Product type Features Order no.

PSS67 M12 connector Connector, M12, straight, 5-pin, A-coded 380 308
PSS67 M12 connector Socket, M12, straight, 5-pin, A-coded 380 309
PSS67 M12 connector Connector, M12, angled, 5-pin, A-coded 380 310
PSS67 M12 connector Socket, M12, angled, 5-pin, A-coded 380 311
PSS67 M8 connector Connector, M8, straight, 4-pin 380 316
PSS67 M8 connector Socket, M8, straight, 4-pin 380 317
PSS67 M8 connector Connector, M8, angled, 4-pin 380 318
PSS67 M8 connector Socket, M8, angled, 4-pin 380 319

8-4

Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

© Pilz GmbH & Co. KG, 2011

1001643-EN-07, 2013-04 Printed in Germany

...

In many countries we are
represented by our subsidiaries
and sales partners.

Please refer to our homepage
for further details or contact our
headquarters.

Technical support

[phone]
[e-mail]

are registered and protected trademarks

®

, the spirit of safety

®

, SafetyNET p

®

, SafetyEYE

®

, SafetyBUS p

®

, PVIS

®

, PSS

®

, PSEN

®

, Primo

®

, PNOZ

®

, PMI

®

Pilz GmbH & Co. KG
Felix-Wankel-Straße 2
73760 Ostfildern, Germany
Telephone: [phone]
Telefax: [phone]
E-Mail: [e-mail]
Internet: www.pilz.com

, PMCprotego

®

, PIT

®

, Pilz

®

InduraNET p

of Pilz GmbH & Co. KG in some countries. We would point out that product features may vary from the details stated in this document, depending on the status at the time of publication and the scope

of the equipment. We accept no responsibility for the validity, accuracy and entirety of the text and graphics presented in this information. Please contact our Technical Support if you have any questions.
