Philips VR616, VR639 User Manual

6 head HiFi VCR

• Turbo Drive with Tape Position Indicator

• Digital Studio Picture Control

• Turbo Timer with Net Name Detection

• Record Link

• Follow TV

• Audio Stereo Cinch Outputs

• Front A/V

Silver Shadow

VR 620

6 head HiFi VCR

Product Highlights

• Tape List

Philips’Tape List offers a convenient and easy to use tape content information system for your most frequently used tapes (up to 9). You can use any tape, even those with existing recordings.To browse through the content of your most frequently used tapes, simply press the Tape List button on the remote control.The complete tape content overview will be shown on the TV screen. And you have immediate access to any recording just by selecting the desired recording (from the information displayed on your TV screen). On top of that you can edit the titles whenever you want to.

• Digital Studio Picture Control

Digital Studio Picture Control keeps checking the quality of your videotapes and reproduces the best possible picture performance. Philips’ Digital Studio Picture Control optimises the playback quality. It measures the characteristics of the tape, adapts the resolution and reduces the picture noise.

• Turbo Timer with Net Name Detection

Is Timer Programming complicated? No! Is Timer Programming time consuming? No! Just press the Turbo Timer button on the remote control, select the TV channel you want to record (directly by its name), set the start and the end time.That’s it. All it takes is only a few seconds.

• Record Link

Your satellite receiver is equipped with a Timer function? Connect both your VCR and the satellite receiver with a SCART cable and make use of the „Record Link“ function. You just have to activate it and switch your VCR to std-by. As soon as the satellite receiver gets active, the VCR switches on and is set in the record mode. At the end of the recording it returns automatically to Stand-by.

• Multibrand TV Remote Control

Should we say it? Our remote-controls can communicate with more than 190 different brands of TVs.

Product information

Reception - Installation

• Tuner: Hyperband, UHF,VHF

• Tuning - presets: PLL, CH entry, 99 presets

• TV Related Functions: 16:9 (pin 8),Analogue Direct Record,Analogue Follow TV

• Time/Date Download: PDC (Time/Date),Text (Time)

User Interface

• Record Speed: Long Play, Standard Play

• Record Speed Selection: Auto LP, Per Menu

• Picture Improvement System: Digital Studio Picture Control

• Audio Recording Level: Automatic

• Archiving System: Tape List

• Special Features: Auto Standby On/Off, Child Lock, Display On/Off

On Tape Standard

• Additional Playback Standard: BLACK & WHITE, NTSC Playback on PAL TV

Remote Control Unit

• Remote Control - Type Number: RT123/111

• Remote Control - Codes: VCR1,VCR2,TV-Multicode

Connectors Rear

• EXT1: Black, Euro CVBS in/out

• EXT2: Black, Euro Decoder, RGB loop through

• Rear Audio Connector: Cinch Stereo Out

• Terrestrial Antenna In/Out: 75 Ohms (IECtype)

• Mains Connector: Standard (IECtype)

Connectors Front

• Front A/V Connectors: Cinch CVBS In, Cinch Stereo In

Tape Deck

• Number of Video / FM Audio / Flying Erase Heads: 4 / 2 / 0

•Play:+1, -1, Repeat

• Additional Playback Feature: Perfect Still, Multiple Search Speed, Multiple slow

Motion Speed

• Index Related Functions: Blank Tape Search, Next/Prev. index search

• Head Cleaning Mode: Automatic

• Tape Length Recognition: Automatic

• Tape Counter: Linear Relative (h.m.s),Time left (h.m.),Tape Position Indicator

• Winding / Rewinding Time (E180): 100 sec .

• Automatic Functions at Tape End: Rewind after Play, Eject after Record

Programming

• Number of Events: 6/month

• Record Control & Transmitter Identification:

Net-name detection, PDC,VPS

• Special Timer Programming: Turbo Timer

• Record Link: SCART 2

General

• Voltage: 198-264 V

• Frequency: 50Hz

• Backup Presets: 1yr

• Backup Clock - Calendar - Timer Event: 3hrs

• Power Consumption Play / Std-By / Low Power Std-By in W: 16 / 4.4 / <4

• Set Size - W x D x H in mm: 380 x 260 x 93

• Packaging - W x D x H in mm: 450 x 382 x 180

• Weight Including / Excluding package in kg: 5.5 / 3.6

• Equipment Supplied: Antenna, Mains cord, Batteries

VR 620

Subject to modification without notice

Show View and Video+ are registered Trademarks of Gemstar Development Cooperation.

VR620/39 VR620/16 VR620/07 VR620/02

Tuning/Install Features Auto Tuning, Auto Tuning, Auto Install, Auto Tuning,

Manual Store, Plug &Play, Manual Store, Plug &Play, Manual Store, Plug &Play, Manual Store, Plug &Play,

Welcome Screen Welcome Screen Welcome Screen Welcome Screen

TV Systems Off Air PAL B/G PAL B/G PAL I PAL B/G

PAL I SECAM B/G SECAM L/L’

Sound Systems German Stereo, German Stereo, German Stereo, German Stereo,

Mono, NICAM Mono, NICAM Mono, NICAM Mono Modulator Splitter Pal G Pal I Pal G Modulator Features – Electr. On/Off switch, Auto Seek, Electr. On/Off switch,

Manual Frequency Electr. On/Off switch, Manual Frequency

Adjustment Manual Frequency Adjustment

Adjustment Frequency Adj. Range – Ch 21 - Ch 55 Ch 21 - Ch 55 Ch 21 - Ch 55 Preadj. modulation frequency – 591.25 MHz (Ch 36) 583.25 MHz (Ch 35) 591.25 MHz (Ch 36) OSD Menu Languages Czech, Danish, Dutch, Czech, Danish, Dutch, English Czech, Danish, Dutch,

English, Finnish, French, English, Finnish, French, English, Finnish, French,

German, Hungarian, German, Hungarian, German, Hungarian,

Italian, Norwegian, Italian, Norwegian, Italian, Norwegian, Polish, Portuguese, Polish, Portuguese, Polish, Portuguese,

Russian Cyrillic, Slovak, Russian Cyrillic, Slovak, Russian Cyrillic, Slovak,

Spanish, Swedish Spanish, Swedish Spanish, Swedish Record / Playback Standard MESECAM, PAL, SECAM PAL PAL PAL Programming System Showview Showview Video Plus +, Showview

ShowView Mapping, Showview Mapping, ShowView Mapping, ShowView mapping,

Daily/Weekly, Pro- Daily/Weekly, Pro- Daily/Weekly, Pro- Daily/Weekly, Pro-

gramming by Net-Name gramming by Net-Name gramming by Net-Name gramming by Net-Name
