IntelliVue MX600 and MX700 Patient Monitor

Philips 865241, 865242 Technical Data Sheet

The Philips IntelliVue MX6001 and MX700 patient monitors offer a flexible and modular monitoring

solution, designed to suit a broad spectrum of needs. The monitors can be connected to the Philips Multi-

Measurement Module (MMS) family with its extensions, plug-in measurement modules and the

IntelliVue anesthetic gas modules to extend its functionality with plug-and-play convenience.

Dedicated configurations are available for the anesthesia, critical and cardiac, and neonatal care

environments. The integrated PC (iPC) allows access to relevant patient information residing on the

hospital’s intranet.

Not available in all geographies, please check for availability.

Features

• Intuitive user interface.

• Simple menu hierarchy gives fast access to all basic monitoring tasks.

• Screen layouts are easily adjustable, allowing flexible display of measurement information.

• Previous/Next Screen function provides access to the ten most recently used screens including the

last three modified screens.

• Temperature, height, and weight can be configured

either in metric or imperial units. Pressure measurements can be displayed in kPa or mmHg.

Gases can be displayed in kPa or mmHg.

• Patient data management with tabular and graphic

trends, and high resolution trends to track changes with beat-to-beat resolution.

Page 2

• Drug, ventilation, hemodynamic, and oxygenation calculations.

• User or case-specific profiles enable rapid case turnover.

• Patented automatic alarm limits help clinicians provide care more

efficiently.

• Event Surveillance including Neonatal Event Review for automatic

detection of patient status deterioration.

• Bed-to-bed overview provides clinicians with an overview of all the

patient beds in their care.

• Choice of input devices: Touchscreen, trimknob, remote control,

trackball, mouse, keyboard or barcode reader.

• Capable of functioning in a wireless infrastructure.

• Graphical measurement window shows which measurements are being measured by which device, making it easier to resolve

measurement label conflicts.

• Timers application allows you to set timers to notify you when a

specific time period has expired.

• Second independent display capability using the iPC.

• The iPC can host Windows applications and safely share the display with the MX600 and MX700s’ realtime system or drive a second

display, independent of size and resolution. The content displayed on the second display can be different from the content on the main

display of the MX600 and MX700 and can show either realtime vital signs information, PC applications or both at the same time. A

separate isolated LAN interface allows access to the hospital’s backbone independent of the MX600 and MX700. Six USB interfaces

provide connectivity to external computer devices, for example, printers or input devices such as the touch interface of the selected

display

• Bedside information access using the iPC or Portal technology.

Intended Use

The IntelliVue MX600 and MX700 are intended to be used for monitoring, recording, and alarming of multiple physiological

parameters of adults, pediatrics, and neonates in hospital environments by trained health care professionals.

U.S. Federal Law restricts this device to sale by or on the order of a physician.

as practices and technologies advance, protecting long-term

investments.

Main Components

Display

The monitors have a color 15” LCD TFT display with a wide viewing

angle, providing high resolution waveform and data presentation. The MX600 and MX700 integrate the display and the processing unit

into one device. One external slave display can be connected to a builtin DVI-I port.

A second independent display can be connected via the iPC. Multiple display resolutions including widescreen formats are supported on the

iPC.

Integrated PC (iPC)

The iPC is a fan-less, medical grade PC residing within the MX600 and

MX700 and as such designed for continuous operation in the patient vicinity.

The iPC uses MS Windows 7 (or XP) as operating system and can host respective applications. These applications can either be:

– Windows applications, such as Internet Explorer, – Philips applications such as iSite clients or an application launch pad,

– Third party applications or – Hospital owned and developed software.

The iPC is designed as an “open” PC and such can be serviced and maintained by the hospital’s IT department as well as by Philips.

A separate isolated LAN interface allows access to the hospital’s backbone independent of the MX600 and MX700.

The iPC can safely share the main display with the MX600 and MX700 (single display setup) and/or be used with a standard or a medical grade

display (dual display setup), either provided by Philips or another manufacturer. The iPC supports displays with or without touch

operation. The iPC has six USB 2.0 ports (five at the rear and one at the side of

the monitor) supporting High-Speed mode for computer peripherals such as keyboard, mouse, barcode reader, touch display etc.

Modularity

The monitor is available in a choice of models - MX600 and MX700 to suit different needs throughout the care environment. All the

models offer the same comprehensive range of measurements. The monitor’s functionality can be extended by connecting Philips plug-

in modules, the multi-measurement module (MMS) family with extensions, and anesthetic gas modules with plug-and-play convenience.

The monitors are available as standalone or networked solutions. The monitors’ modular design allows new capabilities to be added in

the future as monitoring requirements change. This upgradability gives the security of knowing that the monitor can be enhanced and updated

User Interface

The color graphical user interface is designed for fast and intuitive operation, and ensures that clinicians quickly feel at ease using the

monitor. SmartKeys with intuitive icons allow monitoring tasks to be performed

quickly and easily, directly on the monitor screen. Waves and numerics are color-coded.

The MX600 and MX700 display up to six waves simultaneously. For 12lead ECG monitoring it can display 12 real-time ECG waves, with a

rhythm strip and all ST values.

Page 3

Flexible screen layout allows optimal use of the available display space,

for example, waves can be overlapped or wave size can adjust dynamically depending on the number of waves configured for the

space. The Basic Help provides on-screen operating help, explaining INOP

and alarm messages.

appear on the screen. The MX600 requires a USB-compatible off-the-

shelf keyboard.

Barcode Reader

A USB barcode reader in “keyboard emulation mode” can be used via a

USB connection.

Touchscreen Operation

The MX700 monitor is supplied as standard with a touchscreen display

with a resistive surface.

Trimknob Operation

The Trimknob is used to operate the MX600 monitor. The MX700 can

also be operated via the Trimknob.

Hardkeys

To guarantee immediate access to the functions Audio Off/Paused,

Alarms On/Off/Paused and Main Screen with the Trimknob operation, hardkeys are located next to the Trimknob

Remote Control

The IntelliVue Remote Control 865244 provides direct access to 5 hardkeys, a navigation knob and a

numeric keypad which can also be used for alphanumeric entry. The hardkeys include

“Silence”, “Alarms Off / Pause Alarms”, “Back Key”, “MainScreen”, and a “SmartKeys” key that

displays a block of configurable smart keys. The remote control is connected to the MX600 and

MX700 monitors via USB interface or SRR interface (wireless) and used for remote operation

of the monitor.

Input Devices

Supported input devices include USB-compatible

off-the-shelf computer accessories such as mouse, keyboard, trackball or barcode reader. All input devices can be used

individually or in combination.

Mouse

Any specified USB mouse or trackball may be used for data entry.

Computer Keyboard

A computer keyboard can be connected to the monitor via a USB connection and used for data entry.

Multi-Measurement Module

The M3001A Multi-

Measurement Module (MMS) can be

connected without cables onto the side of

the Flexible Module Rack (FMS). The MMS

can also be connected to the monitor or FMS

with cables in order to place it in patient vicinity. It sends measurement waves and numerics to

the monitor screen and generates alarms and INOPs. Patient demographic details are stored in the MMS. Eight hours of patient

trends can be transferred to the monitor. The MMS provides measurement data for Electrocardiogram (ECG)/ Arrhythmia, Respiration, Oxygen Saturation of Arterial Blood (SpO

Non-invasive Blood Pressure (NBP), and Invasive Pressure or

Temperature. It features 12-lead ECG capability, multi-lead arrhythmia, and 12-lead ST analysis.

An MMS Extension can optionally be slotted onto the MultiMeasurement Module to add:

• an additional Invasive Pressure and Temperature Measurement, a third Invasive Pressure or Temperature Measurement (one at a time)

and optionally a Cardiac Output/Continuous Cardiac Output measurement (M3012A)

, or

• an additional Invasive Pressure Measurement, a third Invasive Pressure or Temperature Measurement (one at a time), an integrated

mainstream or sidestream CO

measurement and optionally a

Cardiac Output/Continuous Cardiac Output measurement (M3014A), or

• an additional Invasive Pressure or Temperature measurement (one at

a time) and a Microstream® CO

measurement (M3015A), or

• a dual Invasive Pressure and Temperature measurement and a

Microstream® CO

measurement (M3015B).

Keyboard

If alpha or numeric data entry is required, for example to enter patient demographics, for the MX700 a pop-up keyboard will automatically

Microstream is a registered trademark of Oridion Systems Ltd.

Page 4

X2 Multi-Measurement Module

IntelliVue X2 Multi-Measurement Module

Flexible Module Rack FMS-4

Optional Flexible Module Rack FMS-4 E04 with MMS Mount

The M3002A X2 Multi-Measurement

Module can be connected without

cables onto the side of the Flexible Module

Rack (FMS). The X2 can also be connected

to the monitor or FMS with cables in order to

place it in patient vicinity. It sends

measurement waves and numerics to the

monitor screen and generates alarms and INOPs. Up to 24 hours of patient trends are stored in the X2, as well as patient demographic

details. Eight hours of patient trends can be transferred to the host monitor.

The X2 provides measurement data for Electrocardiogram (ECG)/ Arrhythmia, Respiration, Oxygen Saturation of Arterial Blood (SpO

, Non-Invasive Blood Pressure (NBP), and Invasive Pressure or

Temperature. It features 12-lead ECG capability, multi-lead arrhythmia,

and 12-lead ST analysis. An MMS Extension can optionally be slotted onto the X2 to add:

• an additional Invasive Pressure and Temperature Measurement, a third Invasive Pressure or Temperature Measurement (one at a time)

and optionally a Cardiac Output/Continuous Cardiac Output measurement (M3012A)

, or

• an additional Invasive Pressure Measurement, a third Invasive Pressure or Temperature Measurement (one at a time), an integrated

mainstream or sidestream CO

measurement and optionally a

Cardiac Output/Continuous Cardiac Output measurement (M3014A), or

• an additional Invasive Pressure or Temperature measurement (one at

a time) and a Microstream® CO

measurement (M3015A), or

• a dual Invasive Pressure and Temperature measurement and a

Microstream® CO

measurement (M3015B).

The X2 can also be used as a stand-alone monitor.

Flexible Module Rack with Plug-In Modules

The Flexible Module Rack FMS-4 (865243) has four slots for plug-in

measurement modules. The optional Flexible Module Rack with MMS mount gives the possibility to mount an MMS, X2 and MMS Extensions

onto the side of the Flexible Module Rack.

Individual plug-in measurement modules are available to measure:

– M1006B Invasive Blood Pressure

– M1011A Intravascular Oxygen Saturation Module (SO

)

– M1012A Cardiac Output/Continuous Cardiac Output

– M1014A Spirometry – M1018A Transcutaneous Gas

– M1020B SpO

– M1021A Mixed Venous Oxygen Saturation (SvO2)

– M1027A Electroencephalograph (EEG) – M1029A Temperature

– M1034A Bispectral Index (BIS

TM)2

Additional plug-in modules available are:

– M1116B Thermal Array Recorder – M1032A VueLink Device Interface.

– 865115 EC10 IntelliBridge

Microstream is a registered trademark of Oridion Systems Ltd.

Bispectral Index and BIS are registered trademarks of Aspect Medical Systems, Inc.

Page 5

IntelliVue Anesthetic Gas Modules

Versatile IntelliVue G1 and G5 gas modules measure the five most commonly used anesthetic gases, as well as N2O and CO2. They all

provide inspiration and expiration values for display on Philips IntelliVue patient monitors and the values required for MAC calculation in the

IntelliVue patient monitors. The IntelliVue G1 gas module measures the single agent chosen by the clinician. The IntelliVue G5 features

automatic agent identification and mixed-agent measurement capability. Advanced O2 technology based on paramagnetic measurements is

optional with the G1 and included standard with the G5. Additionally, the AGM (Anesthetic Gas Module) offers auto-ID and

single agent measurement capabilities.

Mounting

The standard mounting options enable flexible, space saving placement

of the monitors for an ergonomic work space.

Applications for Specific Care Settings

Anesthesia Features

•The IntelliVue G1 and G5 and the Anesthetic Gas Module (AGM)

measure the five most commonly used anesthetic gases, as well as N2O and CO2.

•The BIS module assesses the level of consciousness in the OR, providing a measure of the effect of anesthetic agents.

• VueLink provides an external device interfacing capability to Anesthesia Machines and other external instruments which have a

serial RS-232 and/or analog output. It generates alarms and provides up to two waves and six numerics, depending on the device.

•The IntelliBridge EC10 Module provides external device interface capability to external devices at the bedside which have a serial RS-

232 and/or LAN output.

•The EEG module determines coma prognosis and extent of cerebral

insult. CSA information can be either permanently displayed on specially designed screens or viewed in a separate window.

• Screens provide flexible viewing of patient information during different procedures or phases of an anesthesia case.

• Respiratory Loops The IntelliVue Patient monitor can generate three types of

respiratory loops and display one real-time loop and up to 6 stored loops simultaneously. This assists in early detection of patient airway

problems (for example, atelectasis, bronchospasm) and ventilator problems (for example, leaks and kinked tubes).

•The Spirometry Module provides airway pressure, volume and flow measurements to monitor changes in respiratory status.

Critical and Cardiac Care Features

• The monitor performs multi-lead arrhythmia detection analysis on the patient’s ECG waveform at the bedside. It analyzes for ventricular

arrhythmias, calculates heart rate, and generates alarms, including

asystole, bradycardia, and ventricular fibrillation.

•Up to 12leads of ST segment analysis can be performed on adult

patients at the bedside, measuring ST segment elevation and depression and generating alarms and events. The user can trend ST

changes, set high and low alarm limits, and set both ST and isoelectric measurement points. ST points can be set either relative to the J-

point or directly by selecting a numeric value.

• QT/QTc interval monitoring provides the measured QT interval,

the calculated heart-rate corrected QTc value and a

ΔQTc value,

which tracks variation in the QT interval in relation to a baseline

value.

•SO

and ScvO2 measurements provide guidance for the treatment of

sepsis treatment protocols.

•The Parameter Histogram View of the Vital Signs Trend allows the

clinician to see, at a glance, the stability of the patient's condition for a selected time period.

• ST Map application shows ST changes over time in two multi-axis spider diagrams.

• 12-lead ECG data can be measured, using either the EASI placement method with five standard electrodes or conventional electrode

placement with 10 electrodes. 12 real-time ECG waveforms can be displayed simultaneously on all

IntelliVue models.

• High performance pulse oximetry technologies perform accurately

even in cases with low perfusion.

• Choice of Microstream, sidestream and mainstream CO

monitoring

for high quality measurements with intubated and non-intubated patients.

• Continuous cardiac output and advanced hemodynamic assessment are provided using the PiCCOTM method without a pulmonary

catheter.

• Clinical calculations enable stored and manually entered data to be

used to perform hemodynamic, ventilation and oxygenation calculations. Calculated data is displayed in both indexed and non-

indexed format.

• BIS monitoring provides sedation assessment in critical and cardiac

care environments.

• Spirometry measurements help to manage ventilator settings and

weaning.

Neonatal Monitoring Features

• Transcutaneous gas (TcGas) monitoring helps to optimize

respiratory therapy in neonates.

EASI-derived 12-lead ECGs and their measurements are approximations to conventional 12-lead ECGs. As the 12-lead ECG derived with EASI is not exactly identical to the 12-lead conventional ECG obtained from an electrocardiograph, it should not be used for diagnostic purposes. PiCCO

is a trademark of Pulsion Medical Systems AG.

Page 6

• Dual-Pulse Oximetry capability allows the clinician to measure pre

and post-ductal saturations.

• The Oxygen CardioRespiroGram (oxyCRG) screens provide a

simultaneous presentation of up to three High-Resolution Trends:

• beat-to-beat heart rate (btbHR)

• an oxygenation measurement trend (SpO

or tcpO2)

• compressed respiration rate.

• This customized display gives clinicians a convenient overview of the neonatal patient’s most important vital signs, helping them to identify

significant events.

• Continuous oxyCRG recordings can be made at the bedside on the

M1116B Recorder.

•Dual SpO

measurement provides clinical support through

comparison and trending of the pulse oximetry values from two distinct patient sites.

• Trended values can also be viewed in the form of a histogram. The SpO2 histograms can be trend histograms or real-time histograms

with 1-second samples.

• In Event Surveillance, in the NER group, you can run a Car Seat

Assessment Record (CAR). This is a special period of event surveillance for neonates during a car seat test. During the CAR

period, a real-time SpO

histogram is also generated with 1-second

samples.

IntelliVue Applications

Clinical Decision Support

Clinicians are continuously drawing mental images from their observations of patients’ vital signs. The IntelliVue’s clinical decision

support applications offer this dynamic “minds eye view” directly on the monitoring screen display.

ProtocolWatch

ProtocolWatch allows clinicians to run clinical protocols that can monitor developments in the patient’s condition. The SSC Sepsis

Protocol runs on the ProtocolWatch application and is used in screening for severe sepsis and monitoring its treatment.

ST Map

ST Map provides a graphical display that can help clinicians to recognize ST changes and their location in the heart more easily. ST Map collects

ST values created from the frontal (limb leads) and horizontal (chest leads) plane into an integrated display. The maps are multi-axis

portraits of the patient’s ST segments as measured with the ST/AR arrhythmia algorithm.

Horizon Display

Horizon trends provide clinicians with a graphical visualization tool that allows the end user to detect at a glance the patients’ current clinical

status. By combining parameters together on the display, the clinician is assisted in their cognitive process of pattern recognition.

Loops

Up to six loops of each type can be stored and compared to detect respiratory changes more easily.

Screen Display Flexibility

Up to 20 different screens can be created per monitor, which means that the clinician has the ability to have a screen created to match a

specific clinical scenario on which the data that matters is displayed. This streamlines the information that needs to be processed and

interpreted to make the right decision at the right time.

Tr en d s

• A choice of four standard trend database configurations is provided,

designed to suit specific application areas. Patient data from up to 16 measurement numerics can be sampled every 12 seconds, one

minute, or five minutes, and stored for a period ranging from four to 48 hours.

• Tabular Trends (Vital Signs) show data for up to 16 measurement numerics in tabular form. Tabular Trends can either be viewed in a

separate window or permanently displayed on specially designed screens.

– Each NBP measurement generates a column in the Vital Signs trend

table. The values for the other measurements are added to provide

a complete vital signs set for the NBP measurement time.

•With Graphic Trends, up to three rows of measurement trends can

be displayed in graphic form, each combining up to three measurements. Graphical Trends can either be viewed in a separate

window or permanently displayed on specially designed screens.

• Screen Trends permanently display trend data for periodic and

aperiodic parameters in graphical format on special screens. The displayed time period can be set to 30 min, 1 h, 2 h or 4 h.

• High Resolution Trends allow the user to track fast-changing measurement trends with beat-to-beat resolution (four samples/

second). The number of High Resolution Trends available for display depends on the wave option purchased.

• Horizon Trends show the deviation from a stored baseline.

• Trended values can be viewed in the form of a histogram. The SpO

histograms can be Tren d H ist o g r a ms with 1-second samples.

• Navigation arrows provide easy access to the stored trends. Trend

data can be documented on a locally or remotely connected printer.

•With Event Surveillance, changes in patients’ condition are

automatically detected and an electronic record of data called an Episode is stored. The Episode can store:

Page 7

– 15 seconds of high-resolution wave trace,

– four minutes of data sampled four times a second, or – 20 minutes of data sampled every 12 seconds.

Event triggers can use the preset alarm limits or they can be userdefined. With user-defined triggers, event episodes are stored even

when alarms are paused. A Manual Event SmartKey enables manual episode storage.

Event Annotation allows immediate or retrospective annotation of events using a user-defined list of event markers such as “ventilated”.

Events can be stored in a database for retrospective review, and episode data including graphic event reviews can be documented on a

local or central printer. In addition, episode data without graphic elements can be documented on the M1116B Recorder Module.

Events are also marked on the Event Line of an Information Center. The standard Event Surveillance package includes one Event Group plus

the OxyCRG Group. Up to 50 event episodes can be stored over a 24 hour-period.

Patient Data Documentation

• An extensive range of Patient Reports can be printed: – Event Review and Episode Reports

– 12-lead ECG Reports – Vital Signs

–Graphic Trends – Cardiac Output Reports

– Wedge Procedure Reports –Calculations Reports

– EEG Report – Histogram Reports

– Loops Report – ST Map Reports

– QT Reports –Alarm Limit Reports

– Drug Calculator Reports –Real-time Wave Reports

– Oxy CRG Reports

Report templates can be defined in advance, enabling print-outs

tailored to each hospital’s specific requirements to be started quickly. Reports can be printed on locally or centrally-connected printers, and

they can be initiated manually or automatically at user-defined intervals.

Recordings

The M1116B plug-in recorder records numerics for all active

measurements and up to three wave forms. It can be used for local recording in the FMS.

Alarms

The alarm system can be configured to present either the traditional HP/Agilent/Philips alarm sounds or sounds compliant with the ISO/

IEC 9703-2 Standard. Alarm limits are permanently visible on the main screen. When an

alarm limit is exceeded, it is signalled by the monitor in the following ways:

• an alarm tone sounds, graded according to severity

• an alarm message is shown on the screen, color-coded according to

severity

• the numeric of the alarming measurement flashes on the screen

• alarm lamps flash for red and yellow alarms and are illuminated for technical INOPs

The alarm limit review page offers an overview of alarm limit settings and the possibility to modify these settings for all parameters.

A “SmartAlarm Delay” algorithm helps to reduce the number of pulse oximetry nuisance alarms.

If the monitor is connected via a network to a central monitoring station, alarming is simultaneous at the monitor and at the Information

Center. The nurse call relay has active open and closed contacts and a user-

definable delay time.

• Alarms are graded and prioritized according to severity:

• Red Alarms*** identify a potentially life threatening situation for a patient.

• Yellow A l a r m s ** indicate conditions violating preset vital signs limits.

• Yellow A l a r m s * indicate arrhythmia alarms.

• Technical Alarms (INOPS) are triggered by signal quality problems,

equipment malfunction or equipment disconnect.

• The Audio off/Pause Alarms function (equivalent to Silence/Suspend with previous monitor generations) allows the user to switch off

alarm tones with one touch or click while retaining visual alarm messages.

All alarms can be paused indefinitely or for a period of one, two, three, five, or 10 minutes depending on their configuration.

Alarm strip recordings are available on the M1116B Recorder Module or on a centrally-connected recorder.

Patented automatic alarm limits automatically adapt the alarm limits to the patient’s currently measured vital signs within a safe margin defined

individually for each patient. Visual and/or audible latching and non-latching alarm handling is

available.

Not available in the U.S.A.

Page 8

Patient Transfers

• The Universal Admit, Discharge and Transfer (ADT) feature means that all ADT information is shared between the networked monitor

and the Information Center. Information need only be entered once.

• Patients can be transferred by disconnecting the MMS or X2 from a

monitor, and then reconnecting it at a new monitor. Patient demographics are stored in the MMS and the X2, so they do not have

to be re-entered at the new monitor.

Profiles

Profiles are predefined configuration settings for Screens, measurement

settings, and monitor properties. Each Profile can be designed for a specific application area and patient category, for example OR adult, or

ICU neo-natal. Profiles enable a quick reaction to patient and care location changes: activating a Profile with a particular patient category

(Adult, Pediatric or Neonatal) automatically applies suitable alarm and safety limits and saves time usually spent carrying out a complete set-up

procedure. Profiles can be created directly on the monitor or remotely on a

personal computer and transferred to the monitor using the Support Tool. A selection of Profiles for common monitoring situations is

provided with the monitor. These profiles can be changed, added to, renamed, or deleted.

Networking Capabilities

The monitor can operate as part of a networked system (wired & wireless) using the Philips IntelliVue Clinical Network interface.

This includes:

• DHCP protocol support (as an alternative to BootP in certain

network designs)

• 802.1x basic support on wireless networks

•WMM on wireless networks

• QoS Tagging

• Systemic Vascular Resistance (SVR)

• Systemic Vascular Resistance Index (SVRI)

• Pulmonary Vascular Resistance (PVR)

• Pulmonary Vascular Resistance Index (PVRI)

• Left Cardiac Work (LCW)

• Left Cardiac Work Index (LCWI)

• Left Ventricular Stroke Work (LVSW)

• Left Ventricular Stroke Work Index (LVSWI)

• Right Cardiac Work (RCW)

• Right Cardiac Work Index (RCWI)

• Right Ventricular Stroke Work (RVSW)

• Right Ventricular Stroke Work Index (RVSWI)

• Extra Vascular Lung Water Index (EVLWI)

• Intrathoracic Blood Volume Index (ITBVI)

• Global End Diastolic Volume Index (GEDVI)

Oxygenation Calculations:

• Arterial Oxygen Content (CaO2)

• Venous Oxygen Content (CvO

• Arteriovenous Oxygen Content (CavO

• Oxygen Availability (DO

• Oxygen Availability Index (DO

• Oxygen Consumption (VO

• Oxygen Consumption Index (VO

• Oxygen Extraction Ratio (O

)

ER)

• Alveolar-Arterial Oxygen Difference (AaDO

• Percent Arteriovenous Shunt (Qs/Qt) Ventilation Calculations:

• Minute Volume (MINVOL)

•Compliance (COMP)

• Dead Space (Vd)

• Dead Space/Tidal Volume Ratio (Vd/TV)

• Alveolar Ventilation (ALVENT)

)

Other Bed Overview Capability

The alarm status of beds in the same Care Group on the hospital network can be permanently displayed on the screen of each monitor

in the Care Group. The user can also view measurement data from all other monitors connected to the hospital network. Other Bed

information can either be viewed in a separate window or permanently displayed on specially designed screens.

Clinical Calculation Set

The clinical calculation set consists of: Hemodynamic, Oxygenation, and Ventilation calculations.

Hemodynamic Calculations:

• Cardiac Index (C.I.)

•Stroke Volume (SV)

• Stroke Index (SI)

Page 9

Drug Calculator

The drug calculator allows you to calculate the fourth value when three of the following values are entered: dose, amount, volume, rate of

infusion. A titration table and drip table can be displayed and printed.

Measurement units can be converted (for example, lbs to kg). The drug calculator can also be configured to include a list of

commonly used drugs using the support tool.

the alarm relay and alarms are triggered by criteria defined by the user.

It has active open and closed contacts and a user-definable delay time.

RS232 Interface (Standard)

The standard RS232 port can be used to connect:

– an anesthetic gas module – a touchscreen

– a barcode reader

Service Features

• The Support Tool helps technical personnel to:

– carry out configuration, upgrades and troubleshooting via the

network, or on an individual monitor

– share configuration settings between monitors – back up the monitor settings

– document configuration settings

• A password-protected Service Mode ensures that only trained staff

can access service tests and tasks

• The Configuration Mode is password-protected and allows trained

users to customize the monitor configuration

Device Connections

The monitor can be connected to:

• Multi-Measurement Module (MMS) family (M3001A, M3002A), and its extensions (M3012A, M3014A, M3015A)

• External devices via Vuelink and/or IntelliBridge EC10 Module

• Flexible Module Rack

• Anesthetic Gas Modules

• Information Center (for example, M3150B)

•Slave Display

Network Interface

The network interface provides the system with networking capability

via a wired network connection.

MIB/RS232 Interface (optional)

MIB, Medical Information Bus (IEEE P1073), is a standard for interfacing

medical devices, allowing full integration of these devices. Additional MIB/RS232 I/O boards can be installed. The MIB ports can be

independently configured to be used for:

– input for connection to a touchscreen.

– numeric, wave and alarm data export using a computer interface,

to an automated anesthesia record keeper or a personal computer

(not available in all countries) – connection to an anesthetic gas module

– Data Out can be configured up to two times for each monitor.

Note that only the first MIB/RS232 port configured to Data Out

(that is, the first one to receive a request) provides wave export. A

second MIB/RS232 port configured to Data Out will only export

numerics

Device Interface (USB Interfaces)

This interface allows connection of USB devices (Mouse, Keyboard,

Barcode Scanner, PCL5-supported Printer) to the monitor. Because the patient monitor software only supports two input devices,

only two input devices can be connected to the USB interface on the connector board. For this purpose, the four USB ports are divided into

two groups, and only one input device per group is allowed.

Specifications

Wireless Network

Option J35 enables the monitor to function within a wireless

infrastructure. The infrastructure is based on an IEEE 802.11 a/b/g network in the 2.4 GHz or 5 GHz bands (ISM). Additional components

are required to complete the system. Please refer to the M3185A IntelliVue Clinical Network Technical Data Sheet for further

information.

Flexible Nurse Call Relay

The Flexible Nurse Call Relay board provides a means for alarms generated on the monitor to be signalled on an external device such as

a nurse call system, a beeper or a light. It provides three general alarm relays and one power fail alarm. The external device is connected to

Monitor Specifications

See the individual Data Sheets for measurement module, X2, MMS

extension, and plug-in module specifications.

Safety Specifications

The monitors, together with the Multi-Measurement Module

(M3001A), the X2 Multi-Measurement Module (M3002A) and the Flexible Module Rack (865423), all modules and MMS extensions,

comply with the Medical Device Directive 93/42/EEC (CE

0366

) and with IEC 60601-1:1988 + A1:1991 + A2:1995; EN60601-1:1990 +

A1:1993 + A2:1995; UL 60601-1:2003; CAN/CSA C22.2#601.1-M90 + Suppl. No 1-94 + Am.2; IEC 60601-1-1:2000; EN 60601-1-1:2001; IEC

60601-1-2:2000 +A1:2004; EN 60601-1-2:2001 +A1:2006.

Page 10

All applied parts are Type CF unless otherwise specified. They are

protected against damage from defibrillation and electrosurgery. The possibility of hazards arising from software errors was minimized

in compliance with ISO/EN 14971 and IEC/EN60601-1-4.

This ISM device complies with Canadian ICES-001. C’est appareil ISM est conforme a la norme NMB-001 du Canada.

Physical Specifications

Product

MX600/700 Monitors <9.5 kg

M3001A Multi-Measurement Module

Max

We ig ht

<20.9 lb

<650 g <1.4 lb

W x H x D

<392 x 321 x 163 mm

15.43 x 12.63 x 6.41 in

188 x 96.5 x 51.5 mm

7.4 x 3.8 x 2 in

(MMS) M3002A

Multi-Measurement Module

<1.25 kg

<2.8 lb

188 x 99 x 86 mm

7.4 x 3.9 x 3.4 in (MMS)

M3012A Hemodynamic MMS

<550 g

1.2 lb

<190 x 98 x 40 mm <7.5 x 4 x 1.6 in

Extension M3014A

Capnography MMS

<500 g

<1.1 lb

<190 x 98 x 40 mm

<7.5 x 4 x 1.6 in Extension

M3015A Microstream CO

MMS

<550 g <1.21 lb

<190 x 98 x 40 mm

<7.5 x 4 x 1.6 in

Extension865423

Flexible Module Rack (FMS-4)

< 1100 g

(2.4 lbs)

With MMS-mount

232 x 139 x 188 mm

9 x 5.5 x 7.4 in

without MMS-mount

194 x 139 x 110 mm

7.6 x 5.5 x 4.3 in

M1006B Invasive Press Module

190 g (6.7 oz)

36 x 99.6 x 97.5 mm

1.4 x 3.9 x 3.8 in

Option #C01:

225 g (7.9 oz)

M1029A Temperature Module

M1012A Cardiac Output Module

215 g (7.6 oz)

225 g (7.9 oz.)

36 x 99.6 x 97.5 mm,

1.4 x 3.9 x 3.8 in

36 x 99.6 x 97.5 mm

1.4 x 3.9 x 3.8 in

Product

M1014A

Spirometry Module M1018A

Transcutaneous Gas Module

M1020B SpO

Module

M1021A Mixed Venous Oxygen

Max

Weight

250 g

(8.8 oz.) 350 g

(11.3 oz)

<250 g <8.8 oz

460 g (13.04 oz)

Saturation Module M1011A

Module

<200g

(7.1 oz)

- Optical Module <200g

(7.1 oz)

M1027A

Electroencephalograph

210 g

(7.4 oz) Module

M1034A BIS Interface Module

215 g

7.6 oz

BISx 499 g

1.1 lb

- DSC Digital Signal Converter

130 g

(4.6 oz)

(without

cabling)

M1032A Vuelink Module

865115 IntelliBridge EC10 Module

865114 IntelliBridge EC5 ID-Module

M1116B Thermal Array Recorder

240 g

(8.4 oz)

200 g

(7.0 oz)

35 g

(1.1 oz)

507.5 g

1.1 lbs

Module 865244

Remote Control

<250 g

(8.8 oz)

W x H x D

36 x 99.6 x 97.5 mm

1.4 x 3.9 x 3.8 in

72.5 x 99.6 x

97.5 mm,

2.9 x 3.9 x 3.8 in

36 x 99.6 x 97.5 mm

1.4 x 3.9 x 3.8 in

72.5 x 99.6 x 97.5 mm

2.9 x 3.9 x 3.8 in)

36 x 99.6 x 102.5 mm

1.4 x 3.9 x 4.0 in

50 x 30 x 120 mm

2.0 x 1.2 x 4.7 in

36 x 99.6 x 97.5 mm

1.4 x 3.9 x 3.8 in

36 x 99.6 x 97.5 mm

1.4 x 3.9 x 3.8 in

95.3 x 63.5 mm (diameter x height)

3.8 x 2.5 in

66 x 25 x 107 mm

2.6 x 1.0 x 4.25 in

36 x 99.6 x 97.5 mm

1.4 x 3.9 x 3.8 in

36 x 99.6 x 102.5 mm

1.4 x 3.9 x 4.0 in

35 x 17 x 57 mm

1.4 x 0.7 x 2.1 in

73 x 99.6 x 97 mm

2.9 x 3.6 x 3.9 in.

53 x 165 x 23 mm

2.1 x 6.5 x 0.9 in

Page 11

Environmental Specifications

MX600/700 Monitors

Item Condition Range

Temperature

Range

Operating 0 to 40°C (32 to 100°F)

with iPC installed: 0 to 35°C (32 to 95°F)

Storage -20 to 60°C (-4 to

140

Humidity Range Operating 15 % to 95 % Relative

Humidity (RH) (non

condensing)

Storage 5 % to 95 % Relative

Humidity (RH)

Altitude Range Operating -500 m to 3000 m

(10000 ft)

Storage -500 m to 4600 m

(15000 ft)

Ingress

IPx1

Protection

Remote Control 865244 Item Condition Range

Temperature Range

Operating 0 to 40°C (32 to 100°F) Storage -20 to 60°C (-4 to

140

Humidity Range Operating 15 % to 95 % Relative

Humidity (RH) (non condensing)

Storage 5 % to 95 % Relative

Humidity (RH)

Altitude Range Operating -500 m to 3000 m

(10000 ft)

Storage -500 m to 4600 m

(15000 ft)

Flexible Module Rack (FMS-4) 865243

Item Condition Range

Temperature

Range

Operating 0 to 40°C (32 to 100°F)

Storage -20 to 60°C (-4 to

140

Humidity Range Operating 15 % to 95 % Relative

Humidity (RH) (non

condensing)

Storage 5 % to 95 % Relative

Humidity (RH)

Altitude Range Operating -500 m to 3000 m

(10000 ft)

Storage -500 m to 4600 m

(15000 ft)

Ingress

IPx1

protection

Performance Specifications

MX600/700 Performance Specifications

Power

Specifications

Power

Consumption

<200 W average

Line Voltage 100 to 240 V

Current 1.9 to 0.9 A Frequency 50/60 Hz

WXGA Display 15 inch

389 mm active matrix color LCD (TFT) Resolution 1280 x 768

Refresh rate 59.9 Hz Useful screen 334 x 200.45 mm

Pixel size 0.261 x 0.261

Indicators Alarms Off red (crossed out alarms

symbol) LED

Alarms red/yellow/light blue

(cyan) LED

On/Standby/Error green/red LED

integrated in power

switch

External Power green LED

Page 12

MX600/700 Performance Specifications

Sounds Audible feedback for user input

Prompt tone

QRS tone, or SpO2 modulation tone 4 different alarm sounds

Remote tone for alarms on other beds in network

Tone for Timer expired

Tr en d s Resolution 12, or 16 numerics @

12 sec, 1 minute, 5minute resolution

Information Multiple choices of

number of numerics,

resolution and duration depending on trend

option and application area.

For example: neonatal 12 numerics,

9hours @ 12secs. intensive care:

16 numerics, 48 hours @ 5 minutes.

anesthesia: 16 numerics, 5 hours

@ 12 seconds. High Res Trend

Waves

Measurements

available

HR, SpO2, Resp, tcpO2,

Pulse, Perf, tcpO

, A BP, P A P, C V P,

ICP, CPP, BIS, CCO,

AWP, Anesthetic

Agents, Delta SpO

inO

Resolution Measurement samples

are taken at a

resolution of four

samples per second

Update speed waves are drawn at a

speed of 3 cm/minute

MX600/700 Performance Specifications

Events Information trigger condition and

time, event

classification and associated detailed view

of episode data

Episode data configurable, either:

4 minutes of high resolution trend or

20 minutes of numerics trend @

12 sec. resolution or 15 seconds of 4 waves

@ 125 samples/ sec. (Snapshot)

including all current numerics, alarms and

inops

Capacity (max) 25 or 50 events for

either 8 or 24 hours

Alarm Signal System delay less than 3 seconds

Pause duration 1,2,3 minutes or

infinite, depending on

configuration

Extended alarm

5 or 10 minutes

pause

Review Alarms Information all alarms / inops, main

alarms on/off, alarm silence and time of

occurrence

Capacity 300 items

Real Time Clock Range from: January 1, 1997,

00:00 to: December 31,

2080, 23:59

Accuracy better than 4 seconds

per day

Hold Time infinite if powered by

AC; otherwise at least 48 hours (typical:

>72 hours) Buffered

Memory

Hold Time if powered by AC:

infinite

without power: at least

48 hours

Contents Active settings, trends,

patient data, realtime

reports, events, review

alarms

Page 13

865244 Remote Control Performance Specifications

Power (when not connected to

Two AA primary cells

the USB interface of the monitor)

Interface Specifications

MX600/700 Interface Specifications

Network Standard 100-Base-TX (IEEE

802.3 Clause 25)

Connector RJ45 (8 pin) Isolation basic insulation

(reference voltage: 250 V; test voltage:

1500 V) RS232

(Standard)

Connector RJ45 (8-pin)

Power none

Isolation basic insulation

(reference voltage:

250 V; test voltage:

1500 V) MIB/RS232

(optional I/O board)

Standard IEEE 1073-3.2-2000

Connector RJ45 (8 pin) Mode Software-controllable

BCC (RxD/TxD cross

over) or

DCC (RxD/TxD

straight through)

Power 5V ±5%, 100mA

(max.)

Isolation basic insulation

(reference voltage:

250 V; test voltage:

1500 V)

USB Interface (4 ports)

Standard USB 2.0 full-speed

(embedded host)

Connector USB series “Standard

A” receptacle

Power Low power port 4.4 V

min; max. load for all

ports together 500 mA

Isolation none

Flexible Nurse

Call Relay (optional I/O

board)

Connector 20 pin MDR (Mini D-

Ribbon), active open

and closed contacts.

3.5 mm phone jack,

active closed contact

only

Contact <=100mA, <= 24 V DC

MX600/700 Interface Specifications

Isolation basic insulation

Delay < (Configured Latency

Basic Nurse Call

Connector Modular Jack 6P6C,

Relay

Contact <=100mA, <=24V DC

Isolation basic insulation

Delay <[Configured Latency

IntelliVue

Ty p e Internal WMTS

Instrument Te l e m e t r y

Technology compatible with Philips

Wireless Network (USA

only)

Frequency Band WMTS, 1395-

IntelliVue Instrument

Ty p e Internal ISM Adapter

Technology compatible with Philips Te l e m e t r y Wireless

Network (except USA)

IntelliVue 802.11

Frequency Band 2.4 GHz ISM

Ty p e Internal Wireless Bedside Adapter

(Wireless Network

Technology IEEE 802.11a/b/g

Frequency Band 2.4 GHz and 5 GHz Adapter)

Short Range

Radio Interface

Ty p e Internal SRR interface

Technology IEEE 802.15.4

Frequency band 2.4 GHz ISM (2.400 -

Modulation

technique

Effective radiated

power

(reference voltage:

250 V; test voltage: 1500 V)

+0.5 sec)

active open and closed

contact

(reference voltage:

250 V; test voltage: 1500 V)

+0.5] sec

Adapter

Cellular Telemetry System (CTS), cellular

infrastructure

1400 MHz and 14271432 MHz

Cellular Telemetry

System (CTS), cellular infrastructure

Adapter

ISM Band

2.483 GHz) DSSS (O -QPSK)

max. 0 dBm (1 mW)

Page 14

MX600/700 Interface Specifications

Measurement Link (MSL)

Connectors ODU out (Proprietary)

Voltage 56 V ±10 %

Power 45 W

Power Sync. RS-422 compliant input

78.125 kHz (typical)

LAN signals IEEE 802.3 10-Base-T

compliant

Serial signals RS-422 compliant

Video Interface (standard)

(only compatible with selected

displays)

Connector DVI-I (digital and

analog, single link)

Digital video signals single link TMDS

Analog video signals 0.7 Vpp@75

HSYNC/VSYNC

TTL signals

DDC signals none

DDC power 5V ±5% @0-55 mA

ECG Sync Output/Analog ECG Output (1/4” stereo phone jack

with tip, ring, sleeve) General Connector 1/4” phone each with

tip, ring, sleeve Isolation functional isolation

Analog ECG Output (ring, tip) (Ring/Channel 2 is configurable to either Analog ECG Output or Digital Pulse Output)

Gain error <15 %

Baseline offset <100 mV

Bandwidth 1 to 100 Hz

Output voltage

±4 V (min) swing

Signal delay <20 ms

Signal delay with

<30 ms older versions of

the M3001A MMS [identifiable with

the serial number prefix DE227 or

DE441 and option string #A01]

MX600/700 Interface Specifications

Digital Pulse Output

(ring) (Ring/Channel 2

is configurable to either Analog

ECG Output or Digital Pulse

Output)

Output low voltage

<0.4 V @ I=-1 mA level

Output high voltage

>2.4 V @ I=1 mA level

Pulse Width 100 ms±10 ms (active

high)

Pulse Rise Time <1 ms

Signal delay <25 ms

Signal delay with

< 35 ms

older versions of the M3001A MMS

[identifiable with the serial number

prefix DE227 or DE441 and option

string #A01]

Flexible Module Rack (FMS-4) 865243

Interface Specifications

Measurement

Link (MSL)

Connectors ODU out (Proprietary)

Voltage 56 V ±10 %

Power 45 W

Power Sync. RS-422 compliant input

78.125 kHz (typical)

LAN signals IEEE 802.3 10-Base-T

compliant

Serial signals RS-422 compliant

iPC Specifications

iPC Components Specification

Processor Intel Core 2 Duo SP9300/SP9400

Disk Drive Solid State Disk - 100 GB or bigger RAM 4GB

iPC Interfaces

Ethernet LAN

Connector RJ-45

LAN signals IEE 802.3 1000-Base-T compliant Reinforced insulation IEC60601-1 A-k compliant

USB

The iPC and the Wireless LAN are mutually exclusive

Page 15

iPC Interfaces

6 external ports (5 rear, 1 right side)

USB 2.0 supporting high speed mode

Type A connectors

Audio

Microphone input stereo 3.5 mm audio jack headphone output stereo 3.5 mm audio jack

DVI Video with DVI-I connector

DVI supports resolutions up to

1920x1200

VGA supports resolutions up to

2048x1536

Ordering Information

Ordering information for the 865241 (MX700) and 865242 (MX600) is

given here. See the individual Data Sheets for detailed ordering information for the multi-measurement module family, MMS extensions

and plug-in modules.

Basic Functionality 865241 & 865242

General/ICU Configuration

H10

Neonatal Configuration H20 OR/Anesthesia Configuration H30

Cardiac Configuration H40 4 Real-time Wave Segments A04

6 Real-time Wave Segments A06

a One Hxx option and one Axx must be chosen. If AGM is required, H30 must be

ordered.

Measurement Capability Options

Measurement Capability 865241 & 865242

Support two additional Pressures M06 Support one additional Sp02 M20

Application Options

Clinical Applications 865241 & 865242

Neonatal CDS Package C04

Drug Calculator C05 Basic Event Surveillance C06

Parameter Histograms C09

iPC Options

iPC Performance Options 865241 & 865242

Integrated PC (iPC) PC0

ProtocolWatch

Application Options 865241 & 865242

Severe Sepsis Screening P01 SSC Sepsis Protocol P02

Hardware Options

Hardware Add-Ons 865241 & 865242

Remote Control E00

4-slot Rack with MMS Mount E04

Interface Options

Interfaces 865241 & 865242

RS232/MIB Interfacea

J13

IntelliVue 802.11 Bedside Adapter J35 IntelliVue Instrument Telemetry 1.4 GHz J45

IntelliVue Instrument Telemetry 2.4 GHz J47 Short Range Radio J46

a Hardware supports multiple boards of this type.

Measurement Options

Measurements Option Measurement Modules

Multi-Measurement Module, for Resp, ECG (inc. EASI), NBP, SpO

(FAST SpO

(#A01), Masimo SET

(#A03)), and Pressure/

M3001A

A01,

A03

Te m p e r a t u r e , Nellcor OxiMax Technology,

A04

See the MMS Data Sheet for details.

Add Press/Temp C06 Add Press/Temp and

C18

Conventional 12 lead ECG X2 Multi-Measurement Module,

for Resp, ECG (inc. EASI), NBP, SpO2 (FAST SpO2 (#A01),

M3002A A01,

or A03

Masimo SET (#A03)), and Pressure/Temperature.

Nellcor OxiMax Technology,

A04

See the X2 Data Sheet for details.

MMS Extensions

Microstream CO2 Extension M3015A

Add Press/Temp C06

Page 16

Measurements Option

Microstream CO2 Extension

M3015B C08 (with dual Invasive Pressure and

Temperature measurements) Hemodynamic Extension

M3012A

(with Press, Temp, Press/Temp)

Add C.O. C05

Add C.O./CCO C10

Capnography Extension M3014A

Add Press, Press/Temp and

C05 C.O.

Add Press and Press/Temp C07 Add Press, Press/Temp and

C10

C.O./CCO

Flexible Module Rack

Flexible Module Rack (865243), for up to four plug-in modules

Measurement Modules

See the individual module Data Sheets for details.

Invasive Blood Pressure M1006A/B

M1011A

Cardiac Output with CCO M1012A

Spirometry M1014A Transcutaneous Gases M1018A

SpO2 (FAST SpO2) M1020B A01 SpO2 (Nellcor Compatible) M1020B A02

SpO2 (Masimo SET) M1020B A03 SvO

M1021A

EEG M1027A Te m p e r a t u r e M1029A

Vue Lin k M1032A BIS Module M1034A

BISx M1034AX Thermal Array Recorder M1116B

IntelliBridge EC10 865115

Gas Modules

IntelliVue G1 M1013A IntelliVue G5 M1019A

Anesthetic Gas Module M1026B

Measurement Capability Options

Support two additional IBPs M06 Support one additional Sp02 M20

a may not be available in all countries. b Option #C01 provides an analog output signal

Philips IntelliVue MX600, IntelliVue MX700 User manual

Specifications and Main Features

Frequently Asked Questions

User Manual
