Installation and Assembly:
Universal Articulating Swivel Arm for 32" - 50" Flat Panel
Displays
Models: PLA50, PLA50-S
Maximum Load Capacity: 150 lb (68 kg)
2300 White Oak Circle • Aurora, Il 60502 • (800) 865-2112 • Fax: (800) 359-6500 • www.peerlessmounts.com
ISSUED: 05-03-06 SHEET #: 202-9127-5 06-29-11
NOTE: Read entire instruction sheet before you start installation and assembly.
WARNING
• Do not begin to install your Peerless product until you have read and understood the instructions and warnings
contained in this Installation Sheet. If you have any questions regarding any of the instructions or warnings, for US
customers please call Peerless customer care at 1-800-865-2112, for all international customers, please contact
your local distributor.
• This product should only be installed by someone of good mechanical aptitude, has experience with basic building
construction, and fully understands these instructions.
• Make sure that the supporting surface will safely support the combined load of the equipment and all attached
hardware and components.
• Never exceed the Maximum Load Capacity. See page one.
• If mounting to wood wall studs, make sure that mounting screws are anchored into the center of the studs. Use of
an "edge to edge" stud fi nder is highly recommended.
• Always use an assistant or mechanical lifting equipment to safely lift and position equipment.
• Tighten screws fi rmly, but do not overtighten. Overtightening can damage the items, greatly reducing their holding
power.
• This product is intended for indoor use only. Use of this product outdoors could lead to product failure and personal
injury.
• This product was designed to be installed on the following wall construction only;
WALL CONSTRUCTION HARDWARE REQUIRED
• Wood Stud Included
• Wood Beam Included
• Solid Concrete Included
• Cinder Block Included
• Brick Contact Qualifi ed Professional
• Other or unsure? Contact Qualifi ed Professional
Tools Needed for Assembly
• stud fi nder ("edge to edge" stud fi nder is
recommended)
• drill
• 3/16" drill bit for wood studs
• 3/8" masonry drill bit for concrete
• 7/16" socket wrench with extension (recommended)
for wood screws
• 10 mm socket wrench for concrete anchors
• level
• phillips screwdriver
Accessories
• External Wall Plate (WSP716, WSP716-S, WSP724,
WSP724-S) (Metal Stud not evaluated by UL)
Table of Contents
Parts List.................................................................................................................................................................................3
Installation to Wood Stud Wall ................................................................................................................................................4
Installation to Solid Concrete or Cinder Block ........................................................................................................................5
2 of 10
ISSUED: 05-03-06 SHEET #: 202-9127-4 06-29-11
Before you start make sure all parts listed are included with your product.
A
N
retainer plug
1
590-1007
590-1007
T
W
Parts List
PLA50 PLA50-S
Description Qty Part # Part #
wall plate 1 201-1095 201-4095
B tilt-roll assembly 1 201-1093 201-4093
C arm assembly 1 201-1094 201-4094
D wall support arm axle 1 201-1041 201-1041
E vinyl trim 3 600-1012 600-1012
F M10 x 15 mm screw bolt 8 520-9262 520-9262
G .505 x .75 x .062" nylon washer 1 540-1074 540-1074
H tilt adjustment knob 1 560-0108 560-0108
I carriage bolt 3/8"-16 x 3-1/4" 1 520-1315 520-1315
J 1.525 x 2 x .062" delrin washer 2 540-1070 540-1070
K #8-32 x .375" socket head cap screw 1 520-1210 520-1210
L plastic finishing cap 8 590-1123 590-1123
M holding pin 1 580-1166 580-1166
-
O 5/16 x 3" wood screw 6 520-1243 520-1243
P .250 x 1 x .068" washer 6 540-1063 540-1063
Q 9/64" allen wrench 1 560-9728 560-9728
R cable management clips 4 590-1166 590-1166
S cable tie 4 590-1168 590-1168
36" polyester mesh sleeve 1 600-1015 600-1015
U 6 mm allen wrench 1 560-9716 560-9716
anchor 6 590-0321 590-0321
Some parts may appear slightly different than illustrated.
A
B
-
C
D
E
F
IJ K
O
QW
G
H
LMN
P
U
S
R
T
3 of 10
ISSUED: 05-03-06 SHEET #: 202-9127-4 06-29-11
