PAT 4 A1
GB│IE│NI
│
1 ■
CORDLESS STAPLER PAT 4 A1
Introduction
Congratulations on the purchase of your new appliance. You have
selected a high-quality product. The operating instructions are part of
this product. They contain important information about safety, usage
and disposal. Before using the product, please familiarise yourself
with all operating and safety instructions. Use the product only as
described and for the range of applications specified. Please also
pass these operating instructions on to any future owner.
Intended use
This cordless tacker is intended for stapling cardboard, insulating
material, leather, material (textiles or natural fibres) and comparable
materials onto softwoods or wood-like material in private households. The appliance is only for use in dry rooms. Any other uses
of or modification to the appliance is deemed to be improper and
carries the risk of serious personal injury. The manufacturer accepts
no responsibility for damage(s) attributable to misuse. This appliance
is not intended for commercial use.
Features
Trigger
Charging socket (device)
Magazine slider
Release
Magazine shaft
Fill level indicator (wire staples)
Tacker nose
Charger
On/Off switch
Battery charge level indicator
■ 2 │ GB
│IE│
NI
PAT 4 A1
Package contents
1 cordless stapler PAT 4 A1
1 charger PAT 4 A1-1
1000 staples 8 mm
1 set of operating instructions
Technical details
Cordless stapler: PAT 4 A1
Rated voltage: 4 V (DC)
Battery (integrated): LITHIUM ION
Cells: 1
Capacity: 1300 mAh
Magazine shaft capacity: 100 pcs
Wire staples:
Staple width: 11.4 mm outside
Staple length: 4–10 mm
Typ 53
4–10 mm
Battery charger: PAT 4 A1-1
INPUT:
Rated voltage: 100–240 V ~, 50/60 Hz (AC)
Rated power
consumption: 0.2 A
Polarity: positive
OUTPUT:
Rated voltage: 5 V
Rated current: 600 mA
Charging time: approx. 180 min
Protection class: II /
PAT 4 A1
(double insulation)
Lithium
(DC)
GB│IE│NI
│
3 ■
Noise emission value:
the measured values for sound comply with EN 60745. The A-weighted single-event noise level, standardised to 1 s, is typically:
Sound pressure level: L
Uncertainty: K
Sound power level: L
= 65.4 dB (A)
pA
= 3 dB
pA
= 76.4 dB (A)
WA
Uncertainty: KWA = 3 dB
Wear hearing protection!
Vibration values determined in accordance with EN 60745:
Vibration emission value a
Uncertainty K = 1.5 m/s
= 2.235 m/s
h
2
2
NOTE
► The vibration emission value specified in these instructions
has been measured in accordance with a standardised
measuring procedure and can be used to make equipment
comparisons. The specified vibration emission value can also
be used to make an initial exposure estimate.
WARNING!
► The vibration emission value varies in accordance with the use
of the power tool and may be higher than the value specified
in these instructions in some cases. Regular use of the power
tool in such a way may cause the user to underestimate the
vibration. Try to keep the vibration loads as low as possible.
Examples of measures for reducing the vibration load are
wearing gloves when using the tool and limiting the working
time. All states of operation must be taken into consideration
(e.g. times when the power tool is switched off and times
where the power tool is switched on but running without load).
■ 4 │ GB
│IE│
NI
PAT 4 A1
General Power Tool Safety
Warnings
WARNING!
► Read all safety warnings and all instructions. Failure to
follow the warnings and instructions may result in electric
shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated
(corded) power tool or battery-operated (cordless) power tool.
1. Work area safety
a) Keep work area clean and well lit. Cluttered or dark areas invite
accidents.
b) Do not operate power tools in explosive atmospheres, such as
in the presence of flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power
tool. Distractions can cause you to lose control.
2. Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug
in any way.
Do not use any adapter plugs with earthed (grounded) power
tools.Unmodified plugs and matching outlets will reduce risk of
electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as
pipes, radiators, ranges and refrigerators. There is an increased
risk of electric shock if your body is earthed or grounded.
PAT 4 A1
GB│IE│NI
│
5 ■
c) Do not expose power tools to rain or wet conditions. Water
entering a power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pull-
ing or unplugging the power tool. Keep cord away from heat,
oil, sharp edges or moving parts. Damaged or entangled cords
increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord
suitable for outdoor use. Use of a cord suitable for outdoor use
reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use
a residual current device (RCD) protected supply. Use of an RCD
reduces the risk of electric shock.
3. Personal safety
a) Stay alert, watch what you are doing and use common sense
when operating a power tool. Do not use a power tool while
you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may
result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection.
Protective equipment such as dust mask, non-skid safety shoes, hard
hat, or hearing protection used for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-po-
sition before connecting to power source and/or battery pack,
picking up or carrying the tool. Carrying power tools with your
finger on the switch or energising power tools that have the switch on
invites accidents.
d) Remove any adjusting key or wrench before turning the power
tool on. A wrench or a key left attached to a rotating part of the
power tool may result in personal injury.
■ 6 │ GB
│IE│
NI
PAT 4 A1
e) Do not overreach. Keep proper footing and balance at all
times. This enables better control of the power tool in unexpected
situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep
your hair, clothing and gloves away from moving parts. Loose
clothes, jewellery or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction
and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards.
4. Power tool use and care
a) Do not force the power tool. Use the correct power tool for
your application. The correct power tool will do the job better
and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and
off. Any power tool that cannot be controlled with the switch is
dangerous and must be repaired.
c) Disconnect the plug from the power source and/or the battery
pack from the power tool before making any adjustments,
changing accessories or storing power tools. Such preventive
safety measures reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children. Do not al-
low persons unfamiliar with the power tool or these instructions
to operate the power tool. Power tools are dangerous in the
hands of untrained users.
e) Maintain power tools. Check for misalignment or binding of
moving parts, breakage of parts and any other condition that
may affect the power tool’s operation. If damaged, have the
power tool repaired before use. Many accidents are caused by
poorly maintained power tools.
PAT 4 A1
GB│IE│NI
│
7 ■
f) Keep cutting tools sharp and clean. Properly maintained cutting
tools with sharp cutting edges are less likely to bind and are easier
to control.
g) Use the power tool, accessories and tool bits, etc. in accord-
ance with these instructions, taking into account the working
conditions and the work to be performed. Use of the power
tool for operations different from those intended could result in a
hazardous situation.
5. Use and handling of the cordless electrical
power tool
a) Charge a rechargeable battery unit using only the charger
recommended by the manufacturer. Chargers are often de-
signed for a particular type of rechargeable battery unit. There is
the danger of fire if other types of rechargeable battery units are
used.
b) Only the rechargeable battery units supplied are to be used
with an electrical power tool. The use of other rechargeable battery units may lead to the danger of injury or fire.
c) When they are not being used, store rechargeable battery
units away from paperclips, coins, keys, nails, screws or other
small metal objects that could cause the contacts to be bridged.
Short-circuiting the contacts of a rechargeable battery unit may result in heat damage or fire.
d) Fluids may leak out of rechargeable battery units if they are
misused. If this happens, avoid contact with the fluid. If contact
occurs, flush the affected area with water. Seek additional
medical help if any of the fluid gets into your eyes. Escaping
battery fluid may cause skin irritation or burns.
■ 8 │ GB
│IE│
NI
PAT 4 A1
CAUTION! RISK OF EXPLOSION! Never charge
non-rechargeable batteries!
Protect the rechargeable battery from heat, for example
from continuous exposure to sunlight, fire, water and
moisture. There is a risk of explosion.
6. Service
a) Have your power tool serviced by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the power
tool is maintained.
Appliance-specific safety instructions for tackers
■ Always check that the power tool contains staples.Careless
handling of the tacker can lead to unexpected ejection of staples,
which could cause injuries.
■ Never aim the power tool at yourself or other people in
the vicinity.Unintended triggering will cause a staple to be shot
out, which can lead to injuries.
■ Do not activate the power tool until it is pressed firmly
against the workpiece.If the power tool is not in contact with
the workpiece, the staple can rebound off the fastening point.
■ Disconnect the power tool from the mains or battery if a
staple becomes jammed in the power tool.If the tacker is
connected to a power source, it could be unintentionally activated while removing a jammed staple.
■ Be careful when removing a jammed staple.The system may
be live and the staple could be forcefully ejected while you are
attempting to unblock the jam.
■ Never use this tacker for fastening electrical cables.It is not
suitable for the installation of electrical lines, can damage the insulation of electrical cables and thus cause electrical shocks and
increase the risk of fire.
PAT 4 A1
GB│IE│NI
│
9 ■
Safety guidelines for battery chargers
■ This appliance may be used by children aged
8 years and above and by persons with limited
physical, sensory or mental capabilities or lack of
experience and knowledge, provided that they are
under supervision or have been told how to use the
appliance safely and are aware of the potential
risks. Do not allow children to use the appliance as
a plaything. Cleaning and user maintenance tasks
may not be carried out by children unless they are
supervised.
The charger is suitable for indoor use only.
■ If the connecting cable needs to be replaced,
this must be carried out by the manufacturer or
an official representative in order to avoid safety
hazards.
■ 10 │ GB
│IE│
NI
PAT 4 A1
Before use
Charging the appliance battery
NOTE
► The battery is supplied partially charged.
Before first use, charge the battery in the charger for at least
3 hours. This guarantees full battery power. You can charge
the lithium-ion battery at any time without shortening its service life. Interrupting the charging process does not damage
the battery.
► If the battery charge level indicator
use, the battery has 30% of its capacity and needs to be
charged.
Start charging
♦ Connect the charger to the charging socket on the
device.
♦ Connect the charger
source.
■ The battery charge level indicator
ing. The indicator emits a red light during the charging process.
Once the display lights up green, the battery is fully charged.
to a 100 - 240 V ~ 50/60 Hz power
Stop charging
♦ Disconnect the charger from the mains power supply.
♦ Disconnect the charger
device.
NOTE
► The power tool does not work whilst charging.
It is not unusual for the handle to heat up a little during charging.
from the charging socket on the
lights up red during
shows the progress of charg-
PAT 4 A1
GB│IE│NI
│
11 ■
Operation
Filling the magazine shaft
♦ Before commencing work with the appliance, set the on/off
switch
♦ Turn the appliance around.
♦ Press the release
♦ Pull the magazine slider
♦ Fill the magazine shaft
♦ After filling, push the release
far as the stop until it clicks into place.
NOTE
to “0”.
together (see Fig. A).
backwards (see Fig. A).
with staples (see Fig. B).
into the magazine shaft as
► The fill level indicator
contains staples.
shows whether the magazine
Use
Switch on
♦ To switch the appliance on, set the on/off switch to “I”.
♦ Press the tacker nose
you want to staple until it is pushed in a few millimetres.
♦ Press the trigger
♦ To switch the appliance off, set the on/off switch
Troubleshooting
Cause:
A staple is blocking the appliance.
■ 12 │ GB
│IE│
NI
onto the location on the material that
.
to “0”.
PAT 4 A1
Solution:
♦ Open the release
♦ Remove the staple.
WARNING!
■ Do not hold the power tool by the trigger
is jammed in the power tool. While removing a jammed
staple, the trigger can be accidentally activated.
. This will remove the tension.
if the staple
Maintenance and cleaning
■ The appliance must always be kept clean, dry and free from oil
or grease.
■ Use a soft, dry cloth to clean the housing.
NOTE
► Replacement parts not listed (such as switches) can be ordered
via our service hotline.
Kompernass Handels GmbH warranty
Dear Customer,
This appliance has a 3-year warranty valid from the date of purchase.
If this product has any faults, you, the buyer, have certain statutory
rights. Your statutory rights are not restricted in any way by the warranty described below.
Warranty conditions
The validity period of the warranty starts from the date of purchase.
Please keep your original receipt in a safe place. This document will
be required as proof of purchase.
If any material or production fault occurs within three years of the
date of purchase of the product, we will either repair or replace the
PAT 4 A1
GB│IE│NI
│
13 ■
product for you at our discretion. This warranty service is dependent
on you presenting the defective appliance and the proof of purchase
(receipt) and a short written description of the fault and its time of
occurrence.
If the defect is covered by the warranty, your product will either be
repaired or replaced by us. The repair or replacement of a product
does not signify the beginning of a new warranty period.
Warranty period and statutory claims for defects
The warranty period is not prolonged by repairs effected under the
warranty. This also applies to replaced and repaired components.
Any damage and defects present at the time of purchase must be
reported immediately after unpacking. Repairs carried out after expiry of the warranty period shall be subject to a fee.
Scope of the warranty
This appliance has been manufactured in accordance with strict quality guidelines and inspected meticulously prior to delivery.
The warranty covers material faults or production faults. The warranty
does not extend to product parts subject to normal wear and tear
or fragile parts such as switches, batteries, baking moulds or parts
made of glass.
The warranty does not apply if the product has been damaged,
improperly used or improperly maintained. The directions in the
operating instructions for the product regarding proper use of the
product are to be strictly followed. Uses and actions that are discouraged in the operating instructions or which are warned against must
be avoided.
This product is intended solely for private use and not for commercial
purposes. The warranty shall be deemed void in cases of misuse or
improper handling, use of force and modifications / repairs which
have not been carried out by one of our authorised Service centres.
■ 14 │ GB
│IE│
NI
PAT 4 A1
Warranty claim procedure
To ensure quick processing of your case, please observe the following instructions:
■ Please have the till receipt and the item number (e.g. IAN
12345) available as proof of purchase.
■ You will find the item number on the type plate, an engraving on
the front page of the instructions (bottom left), or as a sticker on
the rear or bottom of the appliance.
■ If functional or other defects occur, please contact the service
department listed either by telephone or by e-mail.
■ You can return a defective product to us free of charge to the ser-
vice address that will be provided to you. Ensure that you enclose
the proof of purchase (till receipt) and information about what the
defect is and when it occurred.
You can download these instructions along with many
other manuals, product videos and software on
www.lidl-service.com.
Service
Service Great Britain
Tel.: 0871 5000 720 (£ 0.10/Min.)
E-Mail: kompernass@lidl.co.uk
Service Ireland
Tel.: 1890 930 034
(0,08 EUR/Min., (peak))
(0,06 EUR/Min., (off peak))
E-Mail: kompernass@lidl.ie
IAN 277756
PAT 4 A1
GB│IE│NI
│
15 ■
Importer
Please note that the following address is not the service address.
Please use the service address provided in the operating instructions.
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
www.kompernass.com
Disposal
The packaging is made from environmentally friendly
material and can be disposed of at your local recycling
plant.
Do not dispose of power tools in your normal
household waste!
European Directive 2012/19/EU requires that worn-out power
tools be collected separately and recycled in an environmentally
compatible manner.
Your local community or municipal authorities can provide information on how to dispose of the worn-out appliance.
■ 16 │ GB
│IE│
NI
PAT 4 A1
Loading...
