CORDLESS STAPLER PAT 12 A1
CORDLESS STAPLER
Translation of the original instructions
AKKU-TACKER
Originalbetriebsanleitung
BATTERIDREVEN HÆFTEPISTOL
Oversættelse af den originale driftsvejledning
IAN 329403_2001
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Vouw vóór het lezen de pagina met de afbeeldingen open en maak u vertrouwd met alle functies van het
apparaat.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.
GB / IE/NI Translation of the original instructions Page 1
DK Oversættelse af den originale driftsvejledning Side 13
DE / AT / CH Originalbetriebsanleitung Seite 25
A
B
12V max.
10,8V
All Parkside tools and the chargers PLGK12A1/A2/B2/PDSLG 12 A1 of the
X12V Team series are compatible with the PAPK12A1/A2/B1 battery pack.
Charging times
Charging currents
max. 2.4 A
Charger
PLGK 12 A1/A2
max. 4.5 A
Charger
PLGK 12 B2
max. 4,5 A
Charger
PDSLG 12 A1
2 Ah
Battery pack
PAPK 12 A1
60 min
2,4 A
60 min
2,4 A
60 min
2,4 A
2 Ah
Battery pack
PAPK 12 A2
60 min
2,4 A
45 min
3,5 A
45 min
3,5 A
4 Ah
Battery pack
PAPK 12 B1
120 min
2,4 A
60 min
4,5 A
60 min
4,5 A
Contents
Introduction ............................................................ 2
Intended use ........................................................................2
Features ...........................................................................2
Package contents ....................................................................2
Technical data ......................................................................2
General power tool safety warnings ....................................... 3
1. Work area safety ..................................................................4
2. Electrical safety ...................................................................4
3. Personal safety ....................................................................4
4. Power tool use and care ............................................................5
5. Use and handling of the cordless electrical power tool .....................................5
6. Service ..........................................................................5
Appliance-specific safety instructions for electric staple guns ...................................6
Safety guidelines for battery chargers ....................................................6
Original accessories/auxiliary equipment .................................................7
Before use .............................................................7
Removing/charging/inserting the battery pack .............................................7
Checking the battery charge level .......................................................7
Filling the magazine shaft ..............................................................7
Setting the impact force ...............................................................8
Use ................................................................... 8
Switching on ........................................................................8
Troubleshooting .....................................................................8
Maintenance and cleaning ................................................ 8
Kompernass Handels GmbH warranty ..................................... 9
Service ...............................................................10
Importer .............................................................10
Disposal .............................................................. 10
Original declaration of conformity ........................................11
Ordering a replacement battery ..........................................12
Telephone ordering .................................................................12
PAT 12 A1
GB│IE│NI
│
1 ■
CORDLESS STAPLER
PAT 12 A1
Introduction
Congratulations on the purchase of your new tool.
You have chosen a high-quality product. The
operating instructions are part of this product. They
contain important information about safety, usage
and disposal. Before using the product, please
familiarise yourself with all operating and safety
instructions. Use the product only as described and
for the range of applications specified. Please also
pass these operating instructions on to any future
owner.
Intended use
This cordless staple/nail gun is intended for
stapling cardboard, insulating material, leather,
material (textiles or natural fibres) and comparable
materials onto softwoods or woodke material in
private households. The tool is only for use in dry
rooms. Any other use of or modification to the tool
is deemed to be improper and carries the risk of
serious personal injury. The manufacturer accepts
no responsibility for any damage attributable to
misuse. This tool is not intended for commercial use.
Features
Impact force control
Battery display LED
Trigger
Release buttons
Battery pack*
Belt clip
Magazine slider
Release
Magazine shaft
Fill level indicator (wire staples)
Stapler nose
Face plate
Red charge control LED
Green charge control LED
High-speed charger*
Package contents
1 cordless stapler
400 staples 10 mm
100 nails 15 mm
1 belt clip
1 carrying case
1 set of operating instructions
■ 2 │ GB
│IE│
NI
Technical data
Cordless Stapler PAT 12 A1
Rated voltage 12 V (DC)
Operations up to 140 impacts/min
Magazine shaft capacity 100 pcs
Battery PAPK 12 B1*
Type
Rated voltage 12 V
Capacity 4000 mAh
Cells 6
LITHIUM ION
(DC)
PAT 12 A1
High-speed battery charger PLGK 12 B2*
INPUT
Rated voltage 220–240 V ∼ (AC),
50–60 Hz
Power consumption 75 W
OUTPUT
Rated voltage 12 V
(DC)
Rated current 4.5 A
Charging time approx. 60 min
Fuse (internal) 3.15 A
T3.15A
Protection class II /
(double insulation)
* BATTERY AND CHARGER ARE NOT SUPPLIED
Wire staples
Staple width 11.4 mm outside
Typ 53
6–14 mm
Staple length 6–14 mm
Nail length 14–15 mm
Typ 47
14–15 mm
Noise emission value
Noise measurement value determined in accordance with EN 60745. The A-rated noise level of
the power tool is typically as follows:
Sound pressure level L
Uncertainty K
Sound power level L
Uncertainty K
= 84.1 dB (A)
pA
= 3 dB
pA
= 95.1 dB (A)
WA
= 3 dB
WA
Wear hearing protection!
Total vibration value
Vibration values determined in accordance with
EN 60745:
Vibration emission value a
= 3.65 m/s
h,W
Uncertainty K = 1.5 m/s
2
2
NOTE
► The vibration emission value specified in these
instructions has been measured in accordance
with a standardised measuring procedure and
can be used to make equipment comparisons.
The specified vibration emission value can also
be used to make an initial exposure estimate.
WARNING!
► The vibration emission value varies in accord-
ance with the use of the power tool and may
be higher than the value specified in these
instructions in some cases. Regular use of the
power tool in such a way may cause the user
to underestimate the vibration. Try to keep the
vibration loads as low as possible. Examples
of measures for reducing the vibration load
are wearing gloves when using the tool and
limiting the working time. Wherein all states
of operation must be included (e.g. times
when the power tool is switched off and
times where the power tool is switched on
but running without load).
General power tool
safety warnings
WARNING!
► Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result in electric shock, fire and/or
serious injury.
Save all warnings and instructions for future
reference.
The term "power tool" in the warnings refers to your
mains-operated (corded) power tool or batteryoperated (cordless) power tool.
PAT 12 A1
GB│IE│NI
│
3 ■
1. Work area safety
a) Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools cre-
ate sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
2. Electrical safety
a) Power tool plugs must match the outlet.
Never modify the plug in any way.
Do not use any adapter plugs with earthed
(grounded) power tools. Unmodified plugs
and matching outlets will reduce risk of electric
shock.
b) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of elec-
tric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord
for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp
edges or moving parts. Damaged or entangled
cords increase the risk of electric shock.
e) When operating a power tool outdoors, use
an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces
the risk of electric shock.
f) If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD re-
duces the risk of electric shock.
3. Personal safety
a) Stay alert, watch what you are doing and
use common sense when operating a power
tool. Do not use a power tool while you are
tired or under the influence of drugs, alcohol
or medication. A moment of inattention while
operating power tools may result in serious
personal injury.
b) Use personal protective equipment. Always
wear eye protection. Protective equipment such
as a dust mask, non-skid safety shoes, hard hat,
or hearing protection used for appropriate
conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the
switch is in the off-position before connecting
to the power source and/or battery pack,
picking up or carrying the tool. Carrying
power tools with your finger on the switch or
energising power tools that have the switch on
invites accidents.
d) Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key
left attached to a rotating part of the power tool
may result in personal injury.
e) Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewel-
lery or long hair can be caught in moving parts.
g) If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used.
Use of dust collection can reduce dust-related
hazards.
■ 4 │ GB
│IE│
NI
PAT 12 A1
4. Power tool use and care
a) Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at
the rate for which it was designed.
b) Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot
be controlled with the switch is dangerous and
must be repaired.
c) Disconnect the plug from the power source
and/or the battery pack from the power tool
before making any adjustments, changing
accessories, or storing power tools. Such
preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool. Power tools are
dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment
or binding of moving parts, breakage of parts
and any other condition that may affect the
power tool’s operation. If damaged, have the
power tool repaired before use. Many acci-
dents are caused by poorly maintained power
tools.
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to
control.
g) Use the power tool, accessories and tool bits,
etc., in accordance with these instructions,
taking into account the working conditions
and the work to be performed. Use of the
power tool for operations different from those
intended could result in a hazardous situation.
5. Use and handling of the cordless
electrical power tool
a) Charge a rechargeable battery unit using
only the charger recommended by the manufacturer. Chargers are often designed for a
particular type of rechargeable battery unit.
There is the danger of fire if other types of rechargeable battery units are used.
b) Only the rechargeable battery units supplied
are to be used with an electrical power tool.
The use of other rechargeable battery units may
lead to the danger of injury or fire.
c) When they are not being used, store re-
chargeable battery units away from paperclips, coins, keys, nails, screws or other small
metal objects that could cause the contacts
to be bridged. Short-circuiting the contacts of
a rechargeable battery unit may result in heat
damage or fire.
d) Fluids may leak out of rechargeable battery
units if they are misused. If this happens,
avoid contact with the fluid. If contact occurs,
flush the affected area with water. Seek additional medical help if any of the fluid gets into
your eyes. Escaping battery fluid may cause
skin irritation or burns.
CAUTION! RISK OF EXPLOSION!
Never charge non-rechargeable
batteries.
Protect the rechargeable battery from heat (for example, from continuous exposure to sunlight), fire, water and
moisture. There is a risk of explosion.
6. Service
a) Have your power tool serviced by a qualified
repair person using only identical replacement parts. This will ensure that the safety of
the power tool is maintained.
PAT 12 A1
GB│IE│NI
│
5 ■
Appliance-specific safety instructions
for electric staple guns
■ Always assume that the power tool con-
tains staples. Careless handling of the staple
gun can lead to unexpected ejection of staples
which could cause injuries.
■ Never aim the power tool at yourself or
other people in the vicinity. Unintended trig-
gering will cause a staple to shoot out, which
can lead to injuries.
■ Do not activate the power tool until it is
pressed firmly against the workpiece. If the
power tool is not in contact with the workpiece,
the staple can rebound off the fastening point.
■ Disconnect the power tool from the mains
or battery if a staple becomes jammed in
the power tool. If the staple gun is connected
to a power source, it could be unintentionally
activated while removing a jammed staple.
■ Be careful when removing a jammed
staple. The system may be live and the staple
could be forcefully ejected while you are attempting to unblock the jam.
■ Never use this staple gun for fastening
electrical cables. It is not suitable for the
installation of electrical lines, can damage the
insulation of electrical cables and thus cause
electrical shocks and increase the risk of fire.
Safety guidelines for battery
chargers
■ This tool may be used by children
aged 8 years and above and by
persons with limited physical, sensory or mental capabilities or lack of
experience and knowledge, provided that they are under supervision
or have been told how to use the
appliance safely and are aware
of the potential risks. Do not allow
children to use the tool as a toy.
Cleaning and user maintenance
tasks may not be carried out by
children unless they are supervised.
■ To avoid potential risks, damaged
power cords should be replaced
by the manufacturer, their customer
service department or a similarly
qualified person.
The charger is suitable for
indoor use only.
WARNING!
■ Do not operate the tool with a damaged
power cord or mains plug. Damaged power
cords can result in danger to life due to
electric shock.
■ 6 │ GB
│IE│
NI
ATTENTION!
► This charger can only charge the following
batteries: PAPK 12 A1/PAPK 12 A2/
PAPK 12 B1.
► A current list of battery compatibility can be
found at www.Lidl.de/Akku.
PAT 12 A1
Original accessories/auxiliary
equipment
■ Only use the accessories and additional
equipment that are specified in the operating instructions and are compatible
with the tool.
WARNING!
■ Do not use any accessories that are not
recommended by PARKSIDE. This can
lead to an electric shock and fire.
Before use
Removing/charging/inserting the
battery pack
CAUTION!
► Always unplug the charger before you remove
the battery pack
charger.
NOTE
► The battery is supplied partially charged.
Ideally, charge the battery completely before
use. You can charge the lithium-ion battery
at any time without shortening its service life.
Interrupting the charging process does not
damage the battery.
► Never charge the battery pack if the ambient
temperature is below 10°C or above 40°C.
If a lithium-ion battery is going to be stored
for an extended period, the charge level
should be checked regularly. The optimum
charge level is between 50% and 80%. The
storage climate should be cool and dry and
the ambient temperature should be between
0°C and 50°C.
from or connect it to the
♦ Insert the battery pack
charger
♦ Insert the power plug into the socket. The red
charge control LED
♦ The green charge indicator LED
that the charging process is complete and the
battery pack
♦ Push the battery pack
.
is ready for use.
into the high-speed
lights up.
indicates
into the tool.
Checking the battery charge level
♦ Press the stapler nose onto a hard surface
to check the charge level of the battery. The
status/remaining charge will be shown on the
battery display LED as follows:
RED/ORANGE/GREEN = maximum charge
RED/ORANGE = medium charge
RED = low charge – charge the battery
Filling the magazine shaft
Remove the battery before carrying out any
work on the power tool (e.g. maintenance,
changing tools, etc.) as well as during the
transport and storage of the power tool.
Unintentional activation of the trigger can result in
injury.
♦ Remove the battery pack
♦ Turn the tool over.
♦ Press in the releases
♦ Pull the magazine slider
A).
♦ Fill the magazine shaft
from the tool.
(see fig. A).
backwards (see fig.
with staples or nails.
♦ To remove the battery pack
lease buttons and pull the battery pack
out of the tool.
, press the re-
PAT 12 A1
GB│IE│NI
│
7 ■
Setting the impact force
NOTE
► Select the lowest impact force sufficient for
stapling. Take into account the length of the
staples or nails you are using as well as hardness of the material you are working with.
Increasing the impact force
♦ Turn the impact force control clockwise.
Reducing the impact force
♦ Turn the impact force control
NOTE
► Ensure the correct position for the nails (see
main diagram, face plate
♦ After filling, push the release
zine shaft as far as the stop until it clicks into
place.
NOTE
► The fill level indicator shows whether the
magazine contains staples.
anticlockwise.
on the tool).
into the maga-
Use
Switching on
♦ Press the stapler nose onto the part of the
material that you want to staple until it is pushed
in a few millimetres.
♦ Press the trigger
.
Troubleshooting
Cause
A staple is blocking the tool.
Solution
♦ Remove the battery pack
♦ Turn the tool over.
♦ Press in the releases
♦ Pull the magazine slider
release the tension.
♦ Remove the staple.
WARNING!
■ Do not hold the power tool by the trigger
the staple is jammed in the power tool. While
removing a jammed staple, the trigger can
be accidentally activated.
from the tool.
(see fig. A).
backwards. This will
Maintenance and cleaning
WARNING! RISK OF INJURY!
Always switch the tool off and
remove the battery before carrying
out any work on it.
■ The tool is maintenance-free.
■ The tool must always be kept clean, dry and
free from oil or grease.
■ Use a soft, dry cloth to clean the housing.
■ Never permit liquids to penetrate inside the tool.
■ If a lithium-ion battery is going to be stored for
an extended period, the charge level should be
checked regularly. The optimum charge level is
between 50% and 80%. The optimum storage
environment is cool and dry.
NOTE
► Replacement parts not listed (such as carbon
brushes, switches) can be ordered via our
service hotline.
if
■ 8 │ GB
│IE│
NI
PAT 12 A1
Kompernass Handels GmbH
warranty
Dear Customer,
This appliance has a 3-year warranty valid from
the date of purchase. If this product has any faults,
you, the buyer, have certain statutory rights. Your
statutory rights are not restricted in any way by the
warranty described below.
Warranty conditions
The warranty period starts on the date of purchase.
Please keep your receipt in a safe place. This will
be required as proof of purchase.
If any material or manufacturing fault occurs within
three years of the date of purchase of the product,
we will either repair or replace the product for you
or refund the purchase price (at our discretion).
This warranty service requires that you present the
defective appliance and the proof of purchase (receipt) within the three-year warranty period, along
with a brief written description of the fault and of
when it occurred.
If the defect is covered by the warranty, your product will either be repaired or replaced by us. The
repair or replacement of a product does not signify
the beginning of a new warranty period.
Warranty period and statutory claims for
defects
The warranty period is not prolonged by repairs
effected under the warranty. This also applies to
replaced and repaired components. Any damage
and defects present at the time of purchase must
be reported immediately after unpacking. Repairs
carried out after expiry of the warranty period shall
be subject to a fee.
Scope of the warranty
This appliance has been manufactured in accordance with strict quality guidelines and inspected
meticulously prior to delivery.
The warranty covers material faults or production
faults. The warranty does not extend to product
parts subject to normal wear and tear or to fragile
parts which could be considered as consumable
parts such as switches or parts made of glass.
The warranty does not apply if the product has
been damaged, improperly used or improperly maintained. The directions in the operating
instructions for the product regarding proper use
of the product are to be strictly followed. Uses
and actions that are discouraged in the operating
instructions or which are warned against must be
avoided.
This product is intended solely for private use and
not for commercial purposes. The warranty shall
be deemed void in cases of misuse or improper
handling, use of force and modifications / repairs
which have not been carried out by one of our
authorised Service centres.
The warranty period does not apply to
■ Normal reduction of the battery capacity
overtime
■ Commercial use of the product
■ Damage to or alteration of the product by the
customer
■ Non-compliance with safety and maintenance
instructions, operating errors
■ Damage caused by natural hazards
Warranty claim procedure
To ensure quick processing of your case, please
observe the following instructions:
■ Please have the till receipt and the item number
(e.g.IAN12345) available as proof of purchase.
■ You will find the item number on the type plate
on the product, an engraving on the product,
on the front page of the operating instructions
(below left) or on the sticker on the rear or
bottom of the product.
■ If functional or other defects occur, please
contact the service department listed either by
telephone or by e-mail.
■ You can return a defective product to us free of
charge to the service address that will be provided to you. Ensure that you enclose the proof
of purchase (till receipt) and information about
what the defect is and when it occurred.
PAT 12 A1
GB│IE│NI
│
9 ■
Loading...
