CORDLESS SCREWDRIVER PAS 4 B3
CORDLESS SCREWDRIVER
Translation of the original instructions
AKKU-SCHRAUBER
Originalbetriebsanleitung
IAN 303832
ΕΠΑΝΑΦΟΡΤΙΖΟΜΕΝΟ ΚΑΤΣΑΒΙΔΙ
Μετάφραση των αυθεντικών οδηγιών λειτουργίας
Before reading, unfold both pages containing illustrations and familiarise yourself with all functions of the
device.
Πριν ξεκινήσετε την ανάγνωση, ανοίξτε τις δυο σελίδες με τις εικόνες και εξοικειωθείτε με όλες τις
λειτουργίες της συσκευής.
Klappen Sie vor dem Lesen die beiden Seiten mit den Abbildungen aus und machen Sie sich anschließend
mit allen Funktionen des Gerätes vertraut.
GB / IE / NI/CY Translation of the original instructions Page 1
GR / CY Μετάφραση των αυθεντικών οδηγιών λειτουργίας Σελίδα 13
DE / AT / CH Originalbetriebsanleitung Seite 27
9a
9b
A B
C D
E
F
III
II
I
Contents
Introduction ......................................................2
Intended use ................................................................ 2
Notes on trademarks ......................................................... 2
Features ................................................................... 2
Package contents ............................................................ 2
Technical data .............................................................. 2
General Power Tool Safety Warnings ................................3
1. Work area safety .......................................................... 3
2. Electrical safety ........................................................... 3
3. Personal safety ............................................................ 4
4. Power tool use and care .................................................... 4
5. Use and handling of the cordless electrical power tool ............................. 5
6. Service .................................................................. 5
Safety guidelines for screw drivers ............................................... 6
Extended safety guidelines .................................................... 6
Safety guidelines for the cutting attachment ........................................ 6
Safety guidelines for battery chargers ............................................ 6
Before use .......................................................7
Charging the appliance battery (see fig. A) ........................................ 7
Assemble the attachments ..................................................... 7
Changing bits/screw driver bits (see fig. D) ........................................ 8
Replacing the cutting blade (see figs. E + F) ....................................... 8
Operation .......................................................8
Switching the cordless screwdriver on/off ......................................... 8
Changing the direction of rotation ............................................... 8
Tips and tricks ............................................................... 8
Maintenance, storage and cleaning ..................................9
Disposal .........................................................9
Kompernass Handels GmbH warranty ..............................10
Service .........................................................11
Importer .......................................................11
Translation of the original Conformity Declaration .....................12
PAS 4 B3
GB│IE│NI│CY
│
1 ■
CORDLESS SCREWDRIVER
PAS 4 B3
Introduction
Congratulations on the purchase of your new appliance. You have chosen a high-quality product. The
operating instructions are part of this product. They
contain important information about safety, usage
and disposal. Before using the product, please
familiarise yourself with all operating and safety instructions. Use the product only as described and for
the range of applications specified. Please also pass
these operating instructions on to any future owner.
Intended use
This appliance is designed for screwing into
wood, plastic and metal. The cutting attachment is
designed exclusively for cutting soft materials, such
as card and similar materials up to a thickness of 6
mm. Use this product only as described and for the
areas of applications specified. The appliance is
not intended for commercial use. Any other usage
or modification of the appliance is deemed to be
improper and carries a significant risk of accidents.
The manufacturer accepts no responsibility for
damage(s) attributable to misuse.
Notes on trademarks
USB® is a registered trademark of USB Implementers Forum, Inc.
All other names and products may be trademarks
or registered trademarks of their respective owner.
Features
Rotation direction switch/safety lock-out
Motor direction indicator for clockwise rotation
Battery charge level indicator
Motor direction indicator for anticlockwise
rotation
Charging socket (appliance)
ON/OFF switch
LED lamps
Tool holder
Charger
9a
USB plug of the charging cable
9b
Micro USB plug of the charging cable
Torque attachment
Lock button
Eccentric attachment
Angle attachment
Cutting attachment
Bits and bit extension
Package contents
1 cordless screwdriver
1 charger
1 carrying tool bag
1 charging cable
26 bits x 25 mm
2 bits x 50 mm
1 bit extension
1 torque attachment
1 eccentric attachment
1 angle attachment
1 cutting attachment
1 set of operating instructions
Technical data
Cordless screwdriver: PAS 4 B3
Nominal voltage: 4 V (DC)
Battery (integrated):
Battery capacity: 1500 mAh
Rated idle speed: n
Torque: max. 5.0 Nm
Tool holder: 6.35 mm (¼")
Use only the following charger to charge the
cordless tool:
PAS 4 B3-2:
Safety transformer:
Switched-mode power supply:
INPUT:
Rated voltage: 100–240V ∼ 50/60Hz
(AC)
Rated current: max. 0.3 A
(1 cell)
200 rpm
0
■ 2 │ GB
│IE│NI│
CY
PAS 4 B3
OUTPUT:
Rated voltage: 5.0 V
(DC)
Rated current: 1700 mA
Charging time: approx. 1 hr
Protection class: II /
(double insulation)
Noise and vibration data:
The measured values have been determined in
accordance with EN60745. The A-rated noise
level of the tool is typically:
Sound pressure level: L
= 67.8dB (A)
pA
Sound power level: LWA = 78.8 dB (A)
Uncertainty K: K
pA/WA
= 3 dB
Vibration values (vector total of three directions)
determined in accordance with EN 60745:
Screws:
Vibration emission value: a
Uncertainty: K = 1.5 m/s
= 0.79 m/s
h
2
NOTE
►
The vibration level specified in these instructions has been measured in accordance with
a standardised measuring procedure and
can be used for equipment comparisons. The
specified vibration emission value can also
be used to make an initial exposure estimate.
General Power Tool
Safety Warnings
WARNING!
► Read all safety warnings and all instruc-
tions. Failure to follow the safety information
and instructions may result in electric shock,
fire and/or serious injury.
Save all warnings and instructions for future
reference.
The term "power tool" in the warnings refers to your
mains-operated (corded) power tool or batteryoperated (cordless) power tool.
2
1. Work area safety
a) Keep your work area clean and well lit.
Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmo-
spheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c) Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
WARNING!
► The vibration level will vary according to the
use of the power tool and may sometimes
be higher than the value specified in these
instructions.
Regular use of the power tool in this way may
cause the user to underestimate the vibration. To estimate the vibration load during a
specific working period accurately, periods
during which the appliance is switched off
(or running, but not being used) must also
be taken into account. This can significantly
reduce the vibration load over the total working period.
PAS 4 B3
2. Electrical safety
a) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets
will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of elec-
tric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
GB│IE│NI│CY
│
3 ■
d) Do not abuse the mains cable. Never use the
cable for carrying, pulling or unplugging the
power tool. Keep mains cable away from heat,
oil, sharp edges or moving parts. Damaged
or entangled cables increase the risk of electric
shock.
e) When working outdoors with an electrical
power tool always use extension cords that
are also suitable for use outdoors. The use
of an extension cord suitable for outdoor use
reduces the risk of electric shock.
f) If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces
the risk of electric shock.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away
from moving parts. Loose clothes, jewellery or
long hair can be caught in moving parts.
g) If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. The
use of an extraction system can reduce hazards
caused by dust.
h) Do not allow yourself to get lulled into a false
sense of security and do not ignore the safety
regulations for power tools, even if you are
familiar with the power tool after repeated
use. Careless handling can lead to serious
injuries within a fraction of a second.
3. Personal safety
a) Stay alert, watch what you are doing and
use common sense when operating a power
tool. Do not use a power tool while you are
tired or under the influence of drugs, alcohol
or medication. A moment of inattention while
operating power tools may result in serious
personal injury.
b) Use personal protective equipment. Always
wear eye protection. Protective equipment such
as a dust mask, non-skid safety shoes, a hard
hat, or hearing protection, depending on the
type and use of the electric tool, will reduce the
risk of personal injuries.
c) Prevent unintentional starting. Ensure the
switch is in the off position before connecting
to power source and/or battery pack, picking
up or carrying the tool. Carrying the power
tool with your finger on the ON/OFF switch or
connecting the power tool to the mains supply
whilst it is switched on can lead to serious accidents.
d) Remove any adjusting key or wrench before
turning the power tool on. A tool or wrench
attached to a rotating component of the power
tool can cause serious injuries.
e) Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.
4. Power tool use and care
a) Do not overload the power tool. Use the
correct power tool for your application.
The correct power tool will do the job better
and more safely at the rate for which it was
designed.
b) Do not use the power tool if the switch does
not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous
and must be repaired.
c) Disconnect the plug from the power source
and/or remove a removable battery pack
before making any adjustments, changing
accessories, or storing the power tool. This
precaution is intended to prevent you from
unintentionally starting the device.
d) Store idle power tools out of the reach of
children. Do not allow anyone to operate the
device who is not familiar with the device or
who has not read these instructions. Power
tools are dangerous if used by people who are
inexperienced.
e) Look after power tools and accessories with
care. Check for misalignment or binding of
moving parts, breakage of parts and any
other condition that may affect the power
tool's operation. Arrange for damaged
components to be repaired before using the
power tool. Many accidents are caused by
poorly maintained power tools.
■ 4 │ GB
│IE│NI│
CY
PAS 4 B3
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to
control.
g) Use the power tool, accessories and accessory
tools etc. in accordance with these instructions,
taking into account the working conditions
and the work to be performed. The use of
power tools for purposes other than those
intended can result in hazardous situations.
h) Keep the handles and handle surfaces dry,
clean and free from oil and grease. Slippery
handles and handle surfaces do not allow safe
use and operation of the power tool in unforeseen situations.
5. Use and handling of the cordless
electrical power tool
a) Charge the rechargeable battery unit using
only the charger recommended by the manufacturer. Chargers are often designed for a
particular type of rechargeable battery unit.
There is a risk of fire if the battery charger specified for a particular type of battery is used with
other batteries.
b) Only the rechargeable battery units supplied
are to be used with an electrical power tool.
The use of other rechargeable batteries may
result in injury or a fire hazard.
c) When they are not being used, store re-
chargeable battery units away from paper
clips, coins, keys, nails, screws or other small
metal objects that could cause the contacts
to be bridged. Short-circuiting the contacts of
a rechargeable battery unit may result in heat
damage or fire.
d) Fluids may leak out of rechargeable battery
units if they are misused. If this happens,
avoid contact with the fluid. If contact occurs,
flush the affected area with water. Seek additional medical help if any of the fluid gets into
your eyes. Escaping battery fluid may cause
skin irritation or burns.
CAUTION! RISK OF EXPLOSION!
Never charge non-rechargeable
batteries!
■ Protect the rechargeable battery from heat,
for example from continuous exposure to
sunlight, fire, water and moisture. There is a
risk of explosion.
6. Service
a) Have your power tool serviced by a qualified
repair person using only identical replacement parts. This will ensure that the safety of
the power tool is maintained.
PAS 4 B3
GB│IE│NI│CY
│
5 ■
Safety guidelines for screw drivers
WARNING!
■ Hold power tool by insulated gripping
surfaces, when performing an operation
where the fastener may contact hidden
wiring or its own cord. If a screw comes into
contact with a live wire, this may make exposed metal parts of the power tool live and
could give the operator an electric shock.
Extended safety guidelines
■ Do not use a damaged or modified battery.
Damaged or modified batteries may behave
unexpectedly and cause fires, explosions or
pose a risk of injury.
■ Do not expose a battery to fire or exces-
sively high temperatures. Fire or temperatures
in excess of 130°C (265°F) can cause an
explosion.
■ Follow all instructions regarding charging
and never charge the battery or the cordless
tool outside of the temperature range given in
the operating instructions. Incorrect charging
or charging outside of the permissible temperature range can destroy the battery and increase
the risk of fire.
Safety guidelines for the cutting
attachment
DANGER!
■ Always use cutting blades of the correct size
and with an appropriate central fixing bore.
Safety guidelines for battery chargers
■ This appliance may be used by
children aged 8 years and above
and by persons with limited physical, sensory or mental capabilities
or lack of experience and knowledge, provided that they are under supervision or have been told
how to use the appliance safely
and are aware of the potential
risks. Do not allow children to
use the appliance as a plaything.
Cleaning and user maintenance
tasks may not be carried out by
children unless they are supervised.
The charger is suitable for
indoor use only.
DANGER!
■ Keep your hands clear of the cutting area
and the cutting blade.
■ Before carrying out any work on the appli-
ance, ensure that the rotation direction switch
is in the middle. This prevents unintentional
switching on.
■ Do not cut unless the blade guard is fully
functional. Defective blade guards will not
protect you against unintentional contact with
the cutting blade.
■ Before each use, check whether the blade
guard is perfect condition and that the cutting
blade is firmly fitted.
■ 6 │ GB
│IE│NI│
CY
■ If the connecting cable needs to
be replaced, this must be carried
out by the manufacturer or an
official representative in order to
avoid safety hazards.
PAS 4 B3
Before use
Assemble the attachments
Charging the appliance battery
(see fig. A)
NOTE
The battery is supplied partially charged.
►
Before first use, charge the battery in the
charger for at least 1 hours. This guarantees
full battery power. Li-ion batteries can be
charged at any time without adversely
affecting their service life. Interruption of the
charging process will not damage the
battery.
► If the battery charge level indicator lights
up red during use, the battery is at less than
30% of its capacity and needs to be
charged.
► Never charge the cordless appliance when
the ambient temperature is below 10°C or
above 40°C. If a lithium-ion battery is to be
stored for an extended period, the charge
level should be checked regularly. The
optimum charge level is between 50% and
80%. The storage climate should be cool and
dry and the ambient temperature should be
between 0°C and 50°C.
Start charging:
♦ Connect the micro USB plug of the charging
9b
cable
♦ Connect the USB plug of the charging cable 9a
to the charger .
♦ Connect the charger to a 100–240 V ∼
50/60 Hz power source.
The battery is fully charged when the battery level
display changes from red to green.
to the charging socket .
Usage:
- With the torque attachment
soon as the screw is tight. Set the required torque
from one of the 10 levels.
- The eccentric attachment
even in locations that are close to the wall.
- The angle attachment
right angles.
- The cutting attachment
materials, such as card and similar materials up to
a thickness of 6 mm.
Assembly:
NOTE
Before carrying out any work on the appli-
►
ance, ensure that the rotation direction switch
is in the middle. This prevents unintentional
switching on.
♦ Start by removing the rubber cap from the tool
holder (see fig. B).
♦ Now you can fit the supplied attachments to the
appliance in 45° steps. Fit the attachment onto
the appliance so that the attachment clicks into
place. (see fig. C, example: torque attachment
).
Dismantling:
♦ To remove the attachments from the appliance,
press the release button and pull the attachment off forwards.
♦ Afterwards, replace the rubber cap on the tool
holder.
screwing stops as
allows you to screw
allows you to screw at
allows you to cut soft
Stopping charging:
♦ Disconnect the charger from the mains
power supply.
♦ Disconnect the micro USB plug of the charging
9b
cable
from the charging socket .
PAS 4 B3
GB│IE│NI│CY
│
7 ■
Changing bits/screw driver bits
(see fig. D)
Inserting:
♦ Insert the bit into the tool holder .
Removal:
♦ Pull the bit out of the tool holder .
Operation
Switching the cordless screwdriver
on/off
Switching on:
♦ To start the appliance, press the ON/OFF
switch
and keep it pressed in.
Replacing the cutting blade
(see figs. E + F)
NOTE
Before carrying out any work on the
►
appliance, ensure that the rotation direction
switch is in the middle. This prevents
unintentional switching on.
♦ Start by connecting the cutting attachment
to the appliance. This blocks the motor spindle
and allows the screw to be removed.
♦ Unscrew the screw (I).
♦ Remove the cutting blade (II) by pulling it
downwards.
♦ Push in a new cutting blade (II) from below
ensuring that the ground edge of the blade
faces you.
Turn around the blade (II) until it fits onto the
tool fitting (III).
♦ Tighten the screw (I).
♦ The attachment can now be used again.
CAUTION!
► There is an arrow ( ) on the blade guard
of the cutting attachment. This shows you
the recommended running direction of the
cutting blade.
Switching off:
♦ Release the ON/OFF switch to switch off the
appliance.
Changing the direction of rotation
Clockwise:
♦ Push the rotation direction switch to the left.
♦ Press the ON/OFF switch . The clockwise
rotation indicator lights up. You can now
screw in the screws.
Anti-clockwise:
♦ Push the rotation direction switch to the right.
♦ Press the ON/OFF switch . The anticlockwise
rotation indicator
unscrew the screws.
Safety lock-out:
♦ Push the rotation direction switch into the
middle position. The ON/OFF switch is
blocked.
NOTE
►
When the ON/OFF switch is locked it is
still possible to activate the LED lamps .
To do this, press the ON/OFF switch .
lights up. You can now
Tips and tricks
Screw bits are labelled according to their dimensions and their shape. If you are unsure, always try
the particular screw bit out to see whether it sits in
the screw head without any free play.
■ 8 │ GB
│IE│NI│
CY
PAS 4 B3
Maintenance, storage and
cleaning
Do not dispose of batteries in your
normal household waste!
WARNING! RISK OF ELECTRIC
SHOCK! Before cleaning, disconnect
the charger
NOTE
Before carrying out any work on the
►
appliance, ensure that the rotation direction
switch
unintentional switching on.
The cordless screwdriver is maintenance-free.
■ The appliance must always be kept clean, dry
and free from oil or grease.
■ Never allow liquids to get into the appliance.
■ Use a cloth to clean the housing. Never use
petrol, solvents or cleansers which can damage
plastic.
WARNING!
■ Remove the attachments before cleaning.
Clean them with a dry cloth.
■ Always ensure the appliance and attach-
ments are clean, free of dust and dry before
storing.
is in the middle. This prevents
from the mains socket.
Disposal
The packaging is made from environmen-
tally friendly material and can be disposed
of at your local recycling plant.
Do not dispose of power tools in
your normal household waste!
In accordance with European Directive
2012/19/EU
Equipment and its integration into national law,
used power tools must be disposed of separately
and recycled in an environmentally friendly manner.
Your local community or municipal authorities
can provide information on how to dispose of the
appliance.
on Waste Electrical and Electronic
NOTE
The integrated rechargeable battery in this
►
appliance cannot be removed for disposal.
► The integrated lithium-ion battery may only
be removed by trained personnel. To remove
the battery from the housing, the battery must
be empty and the screws unscrewed from the
housing. The connections on the battery must
individually disconnected and isolated.
Defective or worn-out rechargeable batteries must
be recycled according to Directive 2006/66/EC.
Take the battery pack and/or appliance to a
nearby collection facility.
Please consult your local authorities regarding
suitable disposal of worn out power tools/battery packs.The integrated lithium-ion battery may
only be removed by trained personnel. To remove
the battery from the housing, the battery must be
empty and the screws unscrewed from the housing.
The connections on the battery must individually
disconnected and isolated.
Dispose of the packaging in an
environmentally friendly manner.
Note the labelling on the packaging
and separate the packaging material
components for disposal if necessary.
The packaging material is labelled
with abbreviations (a) and numbers
(b) with the following meanings:
1–7: Plastics,
20–22: Paper and cardboard,
80–98: Composites
Your local community or municipal
authorities can provide information on
how to dispose of the worn-out
product.
PAS 4 B3
GB│IE│NI│CY
│
9 ■
Loading...
