Parkside PAS 3.6 A1 User Manual
LITHIUM CORDLESS SCREWDRIVER PAS 3.6 A1
LITHIUM CORDLESS SCREWDRIVER
Operation and Safety Notes
Translation of original operation manual
LITHIUM-AKKUSCHRAUBER
Bedienungs- und Sicherheitshinweise
Originalbetriebsanleitung
6
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of the
device.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.
GB / IE Operation and Safety Notes Page 5
DE / AT / CH Bedienungs- und Sicherheitshinweise Seite 13
1
2
3
9
8
7
6
4
5
A B
10
9
8
1
D
C
E
Table of contents
Introduction
Intended purpose ..........................................................................................................Page 6
Equipment Components ................................................................................................Page 6
Included items ...............................................................................................................Page 6
Technical Data ..............................................................................................................Page 7
General safety advice for electrical power tools
1. Workplace safety .....................................................................................................Page 7
2.
Electrical safety .........................................................................................................Page 8
3. Personal safety ..........................................................................................................Page 8
4.
Careful handling and use of electrical power tools ...............................................Page 8
5. Use and handling of the cordless electrical power tool ........................................Page 9
Safety advice relating to cordless drill drivers ............................................................Page 9
Original ancillaries / accessories .................................................................................Page 10
Before first use
Charging the rechargeable battery on the device (see Fig. D) .................................Page 10
Changing the bits / screwdriver bit inserts ...................................................................Page 10
Preparing the tool for use
Switching on / off the cordless screwdriver .................................................................Page 10
Changing the direction of rotation ...............................................................................Page 10
Switching on / off the LED lights ...................................................................................Page 10
Tips and Tricks ...............................................................................................................Page 11
Maintenance and cleaning .........................................................................Page 11
Service .........................................................................................................................Page 11
Warranty ...................................................................................................................Page 11
Disposal ......................................................................................................................Page 12
Conformity Declaration / Manufacturer ..........................................Page 12
5 GB/IE
Introduction
The following pictograms are used in these operating instructions / on the device:
Read instruction manual! Safety class II
Observe caution and safety notes!
Caution – electric shock!
Danger to life!
Risk of explosion! For indoor use only!
n
V
mA
A / Ah
V
Nom. no-load speed
0
Volt (AC)
~
Milliamps / Amps / Amp-hours
Direct current
(Type of current and voltage)
Lithium cordless screwdriver
PAS 3.6 A1
Introduction
Before you use it for the first time, it is es-
sential that you make yourself fully familiar
with the functions of the appliance and
find out how to correctly handle electrically powered
tools. To do this, read the following operating instructions carefully. Retain these instructions for future
reference. Additionally, pass them on to whoever
might acquire the appliance at a future date.
Keep children away from electrical
power tools!
Wear hearing protection, dust
protection mask, protective glasses
and protective gloves.
Check that the device, mains lead and
plug are in good condition!
Dispose packaging and appliance in
an environmentally-friendly way!
Do not dispose of rechargeable
batteries with your household refuse!
Equipment Components
1
Direction of rotation switch / lock
2
Direction indicator (clockwise)
3
Battery display
4
Direction indicator (anticlockwise)
5
Charging socket (device)
6
ON / OFF switch (LED lights)
7
ON / OFF switch
8
LED lights
9
Tool holder
10
Mains adapter
Included items
Intended purpose
This device is intended for driving screws into wood,
plastic and metal. Use the appliance only as described
and only for the purposes indicated. The device is
not intended for commercial use. Any other uses, and
modifications to the appliance, are deemed to be
improper usage and may result in serious physical
injury. The manufacturer accepts no responsibility
for damage(s) resulting from improper usage.
6 GB/IE
1 Lithium cordless screwdriver PAS 3.6 A1
1 Mains adapter PAS 3.6 A1 - 1
1 Carry case
26 Bits x 25 mm
2 Bits x 50 mm
1 Bit extension (see Fig. C)
1 Operating instructions
Introduction / General safety advice for electrical power tools
Technical Data
PAS 3.6 A1 cordless screwdriver:
Rated voltage: 3.6 V
Rechargeable battery
(integrated): LITHIUM
Rechargeable battery
capacity: 1350 mAh
No-load speed: n
200 min
0
Torque: max. 4 Nm
Tool holder: 6.35 mm (
1
-1
/4“)
Note: If you wish to make an accurate assessment
of the vibration loads experienced during a particular
period of working, you should also take into account
the intervening periods of time when the device is
switched off or is running but is not actually in use.
This can result in a much lower vibration load over
the whole of the period of working.
General safety advice for
electrical power tools
PAS 3.6 A1-1 mains adapter:
INPUT:
Rated voltage: 230 - 240 V~ 50 / 60 Hz
Rated power: 5,5 W
OUTPUT:
Rated voltage: 6,2 V
Rated power: 400 mA
Charging time: approx. 3 hrs.
Protection class: II /
Noise and vibration data:
Measured values for noise are determined in accordance with EN 60745. The A-weighted noise level
of the electrical power tool are typically:
Sound pressure level: 55 dB(A)
Sound power level: 80 dB(A)
Uncertainty K: 3 dB
Total vibration (vector sum of three directions) is
calculated in accordance with EN 60745:
Screwing: Vibration emission value
a
= 2.101 m / s2,
h, D
uncertainty K = 1.5 m / s
WARNING!
The vibration level given in these
2
instructions has been measured in accordance with
a standardised measurement procedure specified
in EN 60745 and can be used to compare devices.
Different uses of the device give rise to different
vibration levels and in many cases they may exceed
the values given in these instructions. It is easy to
underestimate the vibration load if the electrical power
tool is used regularly in particular circumstances.
WARNING!
Read all the safety advice
and instructions! Failure to observe the safety
advice and instructions may result in electric shock,
fire and / or serious injury.
Keep all the safety advice and instructions
in a safe place for future reference!
The term “electrical tool” used in the safety advice
refers to electrical tools powered by mains electricity (by means of a mains lead) and electrical tools
powered by rechargeable batteries (without a
mains lead).
1. Workplace safety
a) Keep your working area clean and
well lit. Untidy or poorly lit working areas
can lead to accidents.
b)
inflammable liquids, gases or dusts.
c)
Distractions can cause you to lose control of
Do not work with the device
in potentially explosive environments in which there are
Electrical power tools create sparks, which can
ignite dusts or fumes.
Keep children and other
people away while you are
operating the electrical tool.
the device.
7 GB/IE
