Parkside PABS 10.8 A1 User Manual
LITHIUM-ION CORDLESS DRILL
PABS 10.8 A1
LITHIUM-ION CORDLESS DRILL
Operation and Safety Notes
Translation of original operation manual
LITHIUM-IONEN-AKKU BOHRSCHRAUBER
Bedienungs- und Sicherheitshinweise
Originalbetriebsanleitung
6
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of the
device.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.
GB / IE Operation and Safety Notes Page 5
DE / AT / CH Bedienungs- und Sicherheitshinweise Seite 15
1
12
11
10
9
2
3
4
5
6
7
8
A B C D
13
14
15
16
1
4
2
Table of contents
Introduction
Intended purpose ..........................................................................................................Page 6
Equipment Components ................................................................................................Page 6
Items supplied ................................................................................................................Page 6
Technical Data ..............................................................................................................Page 6
General safety advice for electrical power tools
1. Workplace safety .....................................................................................................Page 7
2.
Electrical safety .........................................................................................................Page 8
3. Personal safety ..........................................................................................................Page 8
4.
Careful handling and use of electrical power tools ...............................................Page 8
5. Use and handling of the cordless electrical power tool ........................................Page 9
Safety advice relating to cordless drill drivers ............................................................Page 9
Attention - Service lines! ................................................................................................Page 10
Original ancillaries / accessories .................................................................................Page 10
Before first use
Removing / charging / inserting rechargeable battery pack ......................................Page 10
Checking the battery status ..........................................................................................Page 10
Changing tools ..............................................................................................................Page 10
2 Gear Drive .................................................................................................................Page 11
Torque control / drill step ..............................................................................................Page 11
Preparing the tool for use
Changing the direction of rotation / unlocking the device .........................................Page 11
Switching ON / OFF .....................................................................................................Page 11
Activating the lock .........................................................................................................Page 11
Tips and Tricks ...............................................................................................................Page 11
Cleaning and Maintenance ........................................................................Page 12
Service .........................................................................................................................Page 12
Warranty ...................................................................................................................Page 12
Disposal ......................................................................................................................Page 13
Declaration of Conformity / Manufacturer .................................Page 14
5 GB/IE
Introduction
The following icons / symbols are used in this instruction manual:
Read instruction manual!
Observe caution and safety notes! For indoor use only!
Caution – electric shock!
Danger to life!
Explosive material!
Lithium-ion cordless drill
PABS 10.8 A1
Introduction
Before you use it for the first time, it is es-
sential that you make yourself fully familiar
with the functions of the appliance and
find out how to correctly handle electrically powered
tools. Read the following directions for use as well as
the safety instructions. Keep these instructions. When
handing the device on to a third party, hand these
instructions on, too.
Keep children away from electrical
power tools!
Check that the device, mains lead
and plug are in good condition!
4
Bit garage
5
Direction of rotation switch/lock
6
ON / OFF switch
7
Soft-grip
8
Battery pack
9
Battery unlocking button
10
Light
11
Torque control / drill step
12
Quick-action drill chuck
13
Power supply unit
14
Status LED red
15
Battery charge status indicator green
16
Charging cap
Intended purpose
This appliance is designed for drilling and screwing
into wood, plastic and metal. Use the appliance only
as described and only for the purposes indicated.
Any other uses, and modifications to the appliance,
are deemed to be improper usage and may result
in serious physical injury. The manufacturer accepts
no responsibility for damage(s) resulting from
improper usage. The appliance is not intended for
commercial use.
Equipment Components
1
Gear selector switch
2
Button for rechargeable battery LED
3
Rechargeable battery LED (status indication)
6 GB/IE
Items supplied
1 Cordless drill driver PABS 10.8-A1
1 Rechargeable battery pack PABS 10.8-A1-1
1
Power supply unit PABS 10.8-A1-2 with charging cap
2 Bits in bit garage (CR-VPH1, CR-VPH2)
1 Carry case
1 Directions for use
Technical Data
Lithium-Ion Cordless Drill PABS 10.8-A1:
Nominal voltage: 10.8 V
Idle-running speed: 1st gear: 400 min-1
2nd gear: 1300 min
-1
Drill chuck
clamping range: max. 10 mm
Introduction / General safety advice for electrical power tools
Maximum
drill diameter:
Steel: 8 mm
Wood: 20 mm
Rechargeable battery pack PABS 10.8-A1-1
Type: LITHIUM-ION
Nom. voltage: 10,8 V
Capacity: 1300 mAh
Power supply unit PABS 10.8 -LI-2:
INPUT:
Nominal voltage: 230 V ~ / 50 Hz
OUTPUT:
Nominal voltage: 12 V
Rated current: 0.6 A
Charging time: approx. 3 hours
Noise / vibration data:
Measured values for noise are determined in accordance with EN 60745. The A-weighted noise level
of the electrical power tool are typically:
Sound pressure level: 70 dB(A)
Sound power level: 80 dB(A)
Uncertainty K: 3 dB
Wear ear protection!
the values given in these instructions. It is easy to
underestimate the vibration load if the electrical power
tool is used regularly in particular circumstances.
Note: If you wish to make an accurate assessment
of the vibration loads experienced during a particular
:
period of working, you should also take into account
the intervening periods of time when the device is
switched off or is running but is not actually in use.
This can result in a much lower vibration load over
the whole of the period of working.
General safety advice for
electrical power tools
WARNING!
and instructions! Failure to observe the safety
advice and instructions may result in electric shock,
fire and / or serious injury.
Keep all the safety advice and instructions
in a safe place for future reference!
The term “electrical tool” used in the safety advice
refers to electrical tools powered by mains electricity (by means of a mains lead) and electrical tools
powered by rechargeable batteries (without a
mains lead).
Read all the safety advice
Total vibration (vector sum of three directions) is
calculated in accordance with EN 60745:
Drilling in metal: Vibration emission value
a
= 1.944 m / s2,
h, D
uncertainty K= 1.5 m / s
2
,
Screwing: Vibration emission value
a
= 2.101 m / s2,
WARNING!
h
uncertainty K= 1.5 m / s
The vibration level given in these
2
.
instructions has been measured in accordance with
a standardised measurement procedure specified
in EN 60745 and can be used to compare devices.
Different uses of the device give rise to different
vibration levels and in many cases they may exceed
1. Workplace safety
a) Keep your working area clean and
well lit. Untidy or poorly lit working areas
can lead to accidents.
b)
inflammable liquids, gases or dusts.
c)
Distractions can cause you to lose control of
Do not work with the device
in potentially explosive environments in which there are
Electrical power tools create sparks, which can
ignite dusts or fumes.
Keep children and other
people away while you are
operating the electrical tool.
the device.
7 GB/IE
General safety advice for electrical power tools
2. Electrical safety
a)
The mains plug on the device must match
the mains socket. The plug must not
be modified in any way. Do not use
an adapter plug with devices fitted
with a protective earth. Unmodified
plugs and matching sockets reduce the risk of
electric shock.
b) Avoid touching earthed surfaces such
as pipes, radiators, ovens and refrigerators with any part of your body.
There is an increased risk of electric shock if
your body is earthed
c) Keep the device away from rain or
moisture. Water entering an electrical device
increases the risk of electric shock.
d)
device, to hang up the device or to pull
e) When working outdoors with an
f) Use a residual current device (RCD)
Do not use the mains lead for
any purpose for which it was
not intended, e.g. to carry the
the mains plug out of the mains socket.
Keep the mains lead away from heat,
oil, sharp edges or moving parts of the
device. Damaged or tangled mains leads
increase the risk of electric shock.
electrical power tool always use extension cables that are also approved
for use outdoors. The use of an extension
cable suitable for outdoor use reduces the risk
of electric shock.
for protection if operating the electrical power tool in a moist environment
is unavoidable. The use of an RCD reduces
the risk of electric shock.
.
b) Wear personal protective
equipment and always wear
safety glasses. The wearing of
personal protective equipment such as dust
masks, non-slip safety shoes, safety helmets or
ear protectors, appropriate to the type of electrical power tool used and work undertaken,
reduces the risk of injury.
c) Avoid unintentional operation of the
device. Check that the electrical power
tool is switched off before you connect
it to the mains, pick it up or carry it.
Accidents can happen if you carry the device
with your finger on the ON / OFF switch or with
the device switched on.
d) Remove any setting tools or spanners
before you switch the device on. A tool
or spanner left attached to a rotating part of a
device can lead to injury.
e) Avoid placing your body in an unnat-
ural position. Keep proper footing
and balance at all times. By doing this
you will be in a better position to control the
device in unforeseen circumstances.
f) Wear suitable clothing. Do not wear
loose clothing or jewellery. Keep your
hair, clothing and gloves clear of moving parts. Loose clothing, jewellery or long
hair can become trapped in moving parts.
g) If vacuum dust extraction and collection
devices are fitted do not forget to
that they are properly connected and
correctly used. The use of these devices
reduces the hazard presented by dust.
check
4. Careful handling and use
of electrical power tools
3. Personal safety
a) Remain alert at all times, watch what
you are doing and always proceed
with caution. Do not use the device if
you are tired or under the influence of
drugs, alcohol or medication. One mo
of carelessness when using the device can lead
to serious injury.
8 GB/IE
ment
a) Do not overload the device. Always
use an electrical power tool that is
intended for the task you are undertaking. By using the right electrical power
tool for the job you will work more safely and
achieve a better result.
b) Do not use an electrical power tool if
its switch is defective. An electrical power
General safety advice for electrical power tools
tool that can no longer be switched on and off
is dangerous and must be repaired.
Pull the mains plug out of the socket
c)
and / or remove the rechargeable battery before you make any adjustments
to the device, change accessories or
when the device is put away. This pre-
caution is intended to prevent the device from
unintentionally starting.
d)
When not in use always ensure that
electrical power tools are kept out of
reach of children. Do not let anyone use
the device if he or she is not familiar
with it or has not read the instructions
and advice. Electrical power tools are dan-
gerous when they are used by inexperienced
people.
e) Look after the device carefully. Check
that moving parts are working properly and move freely. Check for any
parts that are broken or damaged
enough to detrimentally affect the
functioning of the device. Have damaged parts repaired before you use
the device. Many accidents have their origins
in poorly maintained electrical power tools.
f) Keep cutting tools clean and sharp.
Carefully maintained cutting tools with sharp
cutting edges are less likely to jam and are
easier to control.
g) Use the electrical power tool, accesso-
ries, inserted tools etc. in accordance
with these instructions and advice, and
the stipulations drawn up for this particular type of device. In doing this, take
into account the working conditions
and the task in hand. The use of electrical
power tools for purposes other than those intended can lead to dangerous situations.
5. Use and handling of the cordless electrical power tool
a) Charge a rechargeable battery unit
using only the charger recommended
by the manufacturer. Chargers are often
designed for a particular type of rechargeable
battery unit. There is the danger of fire if other
types of rechargeable battery units are used.
b) Only the rechargeable battery units
supplied are to be used with an electrical power tool. The use of other recharge-
able battery units may lead to the danger of
injury or fire.
c) When they are not being used, store
rechargeable battery units away from
paperclips, coins, keys. nails, screws
or other small metal objects that could
cause the contacts to be bridged. Short-
circuiting the contacts of a rechargeable battery
unit may result in heat damage or fire.
d) Fluids may leak out of rechargeable
battery units if they are misused. If
this happens, avoid contact with the
fluid. If contact occurs, flush the affected area with water. Seek additional
medical help if any of the fluid gets
into your eyes. Escaping battery fluid may
cause skin irritation or burns.
Safety advice relating
to cordless drill drivers
Securely support the workpiece. A workpiece
held in a clamp or vice is kept more securely in
place than one held by your hand.
WARNING!
Harmful / noxious dusts generated from your
work represent a risk to the health of the person
operating the device and to anyone near the
work area.
Do not drill any material containing
asbestos. Asbestos is a known carcinogen.
Hold the electrical power tool firmly.
High reaction torques may occur momentarily
during tightening or loosening of screws.
If the inserted tool jams, switch off the
electrical power tool immediately. Be
prepared for high reaction torques as they may
cause kickback. The inserted tool may jam if
the electrical power tool is overloaded or is
held at an angle to the workpiece.
POISONOUS DUSTS!
Wear safety glasses and a dust
mask!
9 GB/IE
Loading...
