Small, Light, Easy to Use –– And Exceptional Image Quality
Full-HD Images plus the Versatility and
Mobility to Cover All Kinds of Events
Newsgathering for TV
Traffic S tudie s and
Monitoring and
Recording at
Construction Sites
The Inter val REC
1
automatically
function*
records fr ames at preset
intervals.
*1 The maximum recording interval is 24 hours. *2 In HE (extended time) mode using a 32GB SDHC Memory Card.
Crime Surveillance
Records in H D quality
for up to 12 hours*
features a Ti me stamp
function.
2
and
and News paper We bsites
In addition to r ecording full-HD
motion imag es, the AG-HMC40
shoots still i mages at the
equivale nt of 10.6-megapixel
resolution (approx.).
Record ing at Hal ls and
Other Venues
Add the option al XLR
adapter for
professional-quality
audio recording.
Newly developed 1/4.1-inch 3.05-megapixel, progressive 3MOS sensors.
Also records still images with 10.6-megapixel resolution (approx.)
12x Leica Dicomar zoom lens with Optical Image Stabilizer (OIS)
Professional-quality PH mode and reliable SD memory card recording
Wide-ranging functions include a detachable XLR adapter (option),
waveform monitor, and camera remote
Smooth, easy operation with a manual focus ring and touch panel
Outstanding mobility with a small body that weights just 2.16 lbs
SD Memory Card Recorder: Lower Operating Costs, Better for the Environment
SD Reduce s Total Cost of Own ership
(1) Faster, easier edit ing because digit ization is not neces sary
(2) Lower media costs because memory cards are reusable
(3) Lower ma intenance costs be cause there is no movin g
mechanism
By reducin g editing, media and ma intenance costs,
AVCCAM can help improve yo ur bottom line. Users can
also take advant age of a special 3-year fr ee-repair
service p rogram that Panasonic of fers for AVCCAM
equipment.
02
The SD Memory Card Helps Preserve the Environment
with Its Reusability and Low Power Consumption
The SDHC /SD Memory Car d media for the AVCCAM camco rder is
totally fre e from abrasion and d ropout. There is no d rive mechanism
required , as there is for tape and d isc-based
recorde rs, so power consum ption is low and
size and weig ht are reduced. Mal functions are les s likely to
occur, and th ere is no need to replac e heads or transpor t
compone nts. This translat es into lower costs and e asier
maintenan ce, greater energy sav ings, and less waste w hen
the unit is eve ntually dispose d of. All of these features h elp to
conserve the environment.
Wedding s and
eddin
and
Events
In addition to manual
n to man
focus, the AG -HMC40's
the AG-HMC4
ow light capabilities,
low light ca pabilities,
wide a
ens and lon
wide angl e lens and long
mes ma
record time s make the
ride and gro om lo
bride and g room look
t
t.
their best.
Reuse
Recording Initialization
SD Memory Card
Student Video Production
Students of a ny age will
tudents of any age will
apprecia te its compact
reciate its co m
and lightw eight body.
nd lightweight body.
There's no need f or video
turing (digitizing), so
capturing (digitizing), so
editing is qu ick and easy.
editing i
The record ed images can
e recorded images can
be viewed on a m onitor or
e viewed on a monitor or
com
computer.
Style 1
With handle detached,
this super-compact camera
fits eas ily into a bag or
pack for h ighest mobili ty.
t
r v
uick and ea s
You can use AG-HMC40
three different ways
5.31
he
inches
11.9 7 inch es
(5.35 inches wide)
s
Styl
Style 3
With th e optional XLR ad apter mounte d on the handle,
With th
the AG-H MC40 has outs tandi ng audio specs , plus the
he A
ability to add two external phantom microphones or line
inputs with level controls.
Style 2
le
With ha ndle in place, t he AG-HMC40 is ea sy to carry and
With han
easy to us e, even when shoot ing at diffic ult angl es.
easy to u
03
Superb Full-HD Image Quality
A Small Camcorder That's Packed with Image-enhancing Technologies
3MOS System with Full-HD Sampling and Pro Tuning
Sharp, Crisp Rendering of Every Subject
New Leica Dicomar Lens
Featuring 13 elements in 10 groups, the newly developed Leica Dicomar
lens is ideal for full-HD recording. The new lens system uses low-dispersion
glass and aspherical lenses to reduce color aberration and boost resolution.
Use of a special multi-coating process dramatically reduces flare and ghosts.
The result: sharp, crisp, beautifully rendered pictures with vivid colors,
delicate nuances, and exceptional shading. This advanced lens also lets you
capture 40.8mm wide-angle shots (35mm lens equivalent)
such a compact unit.
HD Lens Unit (13 Elements in 10 Groups)
Low-dispersion Glass
Reduces color aberration to
produce clear images.
Highly Refractive Lens
Makes it possible to fit a 12x optical zoom
in a compact unit.
Aspherical Lenses
Enhances resolution and contrast.
-
unusual for
Multi-coated Lens
Surfaces
Reduces flare and ghosts.
Up to 120x Zoom Power
12x Optical Zoom and 10x Digital Zoom
Even at the 490mm zoom setting (35mm lens equivalent), this advanced
12x optical zoom lens is free of image degradation. And the AG-HMC40 is
also equipped with a digital zoom that instantly magnifies the image by any of
three fixed values. 2x, 5x or 10x. Use it together with the 12x optical zoom
lens, and you get super magnification equivalent to a 120x zoom, without the
drop in light intensity that happens when using a lens extender.
*The image quality decreases as the digital zoom magnification increases.
Image with Wide-angle
Image with 12x optical zoom
Image with 12x optical zoom x
10x digital zoom (120x)
Take Clear Shots While Walking or Zooming
Optical Image Stabilizer (OIS)
Because the hand-shake correction is done by actually driving the lens,
there's none of
You can capture
hand-shake is typically a big problem
indoors in dim lighting, or shooting outdoors at night.
*Hand-shake from strong vibrations may remain. Also, visible differences may be slight under some conditions.
Image with OIS OFF Image with OIS ON
