Oster CKSTSK12S-TECO User Manual

Download

For product questions contact:

Sunbeam Consumer Service USA : 1.800.334.0759 Canada : 1.800.667.8623 www.oster.com

Para preguntas sobre los productos, comuníquese a:

Sunbeam Consumer Service EE.UU.: 1.800.334.0759 Canadá : 1.800.667.8623 www.oster.com

STRAIN & POUR ELECTRIC SKILLET SARTÉN ELÉCTRICO CON ESCURRIDOR PARA LĺQUIDOS

User Guide / Guía del usuario:

TITANIUM INFUSED

Safety

Seguridad

How to use

Cómo usar

Cleaning

Limpieza

Recipes Recetas

Printed in China / Impreso en China P.N. 192110 CKSTSK12S-TECO_17ESM1 CSH-SL0717-OST52255

Warranty

Garantía

www.oster.com

IMPORTANT SAFEGUARDS

When using your electric skillet, basic safety precautions should always be followed, including the following:

1. Read all instructions before using this appliance.

2. Be sure that handles are assembled and fastened properly per this manual. See instructions regarding assembly of handles on page 5.

3. Do not touch hot surfaces, use handles.

4. To protect against electric shock, do not immerse the variable temperature control, cord or plug in water or other liquids.

5. This appliance is not to be used by children or by persons with reduced physical, sensory or mental capabilities.

6. Close supervision is necessary when any appliance is used near children. Children should not play with the appliance.

7. Unplug the appliance from the outlet when not in use and before cleaning. Allow appliance to cool before putting on or taking o parts and before cleaning appliance.

8. Do not operate any appliance with a damaged CORD or PLUG, or after the appliance malfunctions, or has been damaged in any manner. Return to an authorized Oster service facility for examination, repair or electrical or adjustment. Do not attempt to replace or splice a damaged cord.

9. The use of accessory attachments not recommended by the appliance manufacturer may cause injuries.

10. Do not use outdoors.

11. Do not let cord hang over edge of table or counter or touch hot surfaces.

12. Do not place on or near a hot gas or electric burner or in a heated oven.

13. Use extreme caution when moving the appliance if it contains hot oil or any other hot liquid.

14. Always attach the variable temperature control to the appliance rst, then plug into the wall outlet. To disconnect, switch o, remove plug from the wall outlet, then remove the variable temperature control from the appliance.

15. Only use the appliance with the OSTER® Strain & Pour Electric Skillet variable temperature control probe P/N 193787.

16. Do not use appliance for anything other than its intended use.

17. Do not cook with the OSTER® Strain & Pour Electric Skillet or the OSTER® Electric Skillet variable temperature control probe standing on temperature sensitive surfaces.

18. To prevent the risk of burns, never ll oil in the skillet pan more than 1/2 inch (12.7 mm) high.

19. This appliance is not intended for deep frying foods.

SAVE THESE INSTRUCTIONS

THIS UNIT IS INTENDED FOR

HOUSEHOLD USE ONLY.

POLARIZED PLUG

This appliance has a polarized plug, (one blade is wider than the other). As a safety feature to reduce the risk of electrical shock, this plug is intended to t in a polarized outlet only one way. If the plug does not t fully in the outlet, reverse the

plug. If it still does not t, contact a qualied electrician. Do not attempt to defeat this safety feature or modify the plug in any way. If the plug ts loosely into the AC outlet or if the AC outlet feels warm do not use that outlet.

POWER CORD INSTRUCTIONS:

A short power-supply cord or detachable power-supply cord is provided to reduce risks resulting from becoming entangled in or tripping over a longer cord. Longer detachable power-supply cords or extension cords are available and may be used if care is exercised in their use. If a long detachable power-supply cord or extension cord is used on short-cord models:

a. The marked electrical rating of the detachable power-supply cord or extension cord

should be at least as great as the electrical rating of the appliance;

b. When the product is of the grounded type, the extension cord shall be a grounding type

3-wire cord; and

c. The longer cord should be arranged so that it will not drape over the counter top or table

top where it can be pulled on by children or tripped over unintentionally.

Thank you for purchasing the OSTER® Strain & Pour Skillet.

Before you use this product for the rst time, please take a few moments to read these instructions and keep it for reference. Pay particular attention to the Safety Instructions provided. Please review the product service and warranty statements. Please do not return to the place of purchase. To learn more about Oster® products, please visit us at www.oster.com or call us at 1-800-334-0759.

www.oster.com

Congratulations on your purchase of a Titanium Infused DuraCeramic™ appliance!

This appliance features a Titanium-Infused DuraCeramic™ nonstick natural ceramic coating which is 8X more durable than other nonstick coatings. This means there’s no aking or peeling o to worry about. Furthermore, the ultra-durable ceramic coating cooks faster than other nonstick coatings, saving time and energy. The natural Titanium- Infused DuraCeramic™ nonstick coating also oers greater health and benets as it’s free of PTFE and PFOA. 8X More Durable – Titanium-Infused DuraCeramic™!

LEARNING ABOUT YOUR STRAIN & POUR ELECTRIC SKILLET

HOW TO:

ASSEMBLING THE HANDLES

NOTE: Do not use the skillet without handles attached.

1. Unpack your unit and locate the handles and 4 Phillips screws included.

2. Place the skillet face down onto a clean, at surface.

3. Place one handle onto the mounting studs making sure the holes align with the holes under skillet pan.

4. Using a Phillips-head screwdriver, attach 2 screws and at washers through holes in the leg into the skillet. Do not overtighten.

CAUTION: Overtightening can result in stripping of screws or

nuts or cracking of handle or feet.

5. Repeat the procedure with the second handle.

6. Place the skillet on upright position.

1. Tempered glass lid *

2. Lid handle

3. Thumb pads

4. a) Large straining holes

4. b) Small straining holes

* These parts can be replaced on oster.com or by calling 1-800-334-0759

5. Cool-touch handles *

6. Pour spout

7. Temperature probe *

8. Temperature control knob

www.oster.com

INTRODUCTION

Before using your new appliance, wash the inside of the pan with warm, soapy water; rinse and dry thoroughly. Remove the temperature controller before washing the skillet.

CAUTION: Do not immerse variable temperature control, power cord or plug in water or any other liquids.

The OSTER® Strain & Pour Electric Skillet is now ready for use.

USING THE OSTER® ELECTRIC SKILLET

1. Place the unit--with the drain spout facing away from you--on a at, level, heat-resistant surface, allowing enough space around the unit for heat to ow without causing damage to walls or cabinets.

CAUTION: Hot steam escapes through the straining holes and

drain spout during the cooking cycle.

2. Push the temperature controller rmly into its socket found at the side of the appliance.

3. Make sure the variable temperature control is set to O and plug cord into a standard 120 Volt AC outlet.

CAUTION: Always plug temperature control probe into skillet

rst, then plug power cord into wall outlet.

4. Set the temperature by turning the knob on the temperature controller. The indicator light will illuminate. Turn the knob until the desired temperature is opposite the indicator light. When the skillet reaches the chosen cooking temperature, the indicator light will turn o. During cooking, the light will blink on and o, indicating that the temperature is being maintained. Guidance in the choice of temperatures is provided later in this book.

5. Do not cook with the Electric Skillet standing on temperaturesensitive surfaces.

6. For simmering, set the temperature control to 300˚F, wait until contents boil, then set the temperature controller to WARM.

NOTE: Use only nylon, wood or heatproof plastic cooking

utensils. Do not use metal utensils, as they may scratch the ceramic surface.

7. When cooking is nished, either turn the variable temperature control to the Warm setting to keep food at serving temperature or turn to O position if ready to serve. The On indicator light will shut o.

8. To remove the temperature controller, rst unplug from the wall outlet, and then gently remove the variable temperature control probe from the skillet.

CAUTION: The probe is hot after use. Allow to cool before

handling.

9. Preheating is not required when using this product.

NOTE: During initial use, a slight smoke and/or odor may be present; this is normal due to the manufacturing process and is no reason for concern.

6 7

www.oster.com

RECOMMENDED COOKING

TEMPERATURE GUIDE

The cooking temperatures listed below are estimates. Adjust the cooking temperature according to your recipe or preference.

Food

Bacon 350º F 5 – 8 Minutes

Eggs (Fried) 300º F 3 – 5 Minutes

Eggs (Scrambled) 325º F 2 – 3 Minutes

Pancakes 375º F 1 – 3 Minutes

Hamburger (1/2-inch Thick) 375º F

Ham (1/2-inch – 1/4 -inch Slices) 325º F 10 – 20 Minutes

Potatoes (Country Fried) (Crispy Brown)

Sausage 340º F 12 – 15 Minutes

Fish 375º F 5 – 8 Minutes

Pork Chops (Breaded) (Brown)

Cube or Minute Steak 400º F 2 – 4 Minutes

Liver (Calf’s, Lamb or Tender Beef) 350º F 5 – 10 Minutes

French Toast 325º F 4 – 6 Minutes

Crusty Chicken (Use 4 Tbsp. Oil) Do Not add water

Temperature

325º F 350º F

375º F 225º F

400º F 300º F

Approximate Time

Rare 4 – 8 Minutes Well Done 9 – 12 Minutes

10 – 12 Minutes 10 – 12 Minutes

10 – 15 Minutes 30 – 40 Minutes

12 – 18 Minutes 10 – 15 Minutes

DRAINING EXCESS LIQUID/OIL

The tempered glass lid of your Strain & Pour Electric Skillet is designed with two ergonomic thumb tabs on each side that, along with its integrated straining holes and drain spout, make it easier to strain excess liquid.

1. Make sure the lid is securely in place.

2. Unplug power cord from electrical outlet.

3. Remove variable temperature control probe from the unit.

4. Firmly hold both handles with your hands then place one thumb on top of each thumb tab on the lid.

5. Pressing the thumb tabs rmly, while still holding the handles, tilt the skillet away from you and drain any excess liquid through the spout into a bowl.

CAUTION: Burn hazard. Contents of skillet and its outer surfaces

are hot. Always pour away from your body.

6. Carefully, place skillet back in cooking position. You can remove the lid to check food or add ingredients.

7. To continue cooking, place lid over the skillet pan and plug control into the skillet then plug unit into wall outlet.

8. Set temperature control to desired setting to continue cooking.

8 9

www.oster.com

CARE & CLEANING

Your Titanium Infused DuraCeramic™ Skillet should be cleaned after every use.

1. Turn the variable temperature control to O. Unplug the skillet and allow it to cool completely before cleaning.

NOTE: To protect the Titanium Infused DuraCeramic™ coating,

do not run cold water over cooking surface immediately after use.

2. Remove variable temperature control probe. DO NOT IMMERSE VARIABLE TEMPERATURE CONTROL PROBE, cord or plug in water or any other liquid.

3. The skillet and the lid are HAND WASH ONLY. Wash with hot, soapy water; skillet may be immersed in water. Rinse and dry thoroughly.

4. DO NOT use steel wool or other metal pads as this may scratch the surface.

NOTE: Never use abrasive cleaning agents to clean your

appliance as this may damage the surfaces.

5. Wipe the temperature control with a damp cloth and wipe dry.

CAUTION: The VARIABLE TEMPERATURE CONTROL PROBE must always be completely dry before use.

For proper care of your Titanium Infused DuraCeramic™ coated skillet, follow the following steps if stubborn stains appear:

1. Sprinkle some baking soda on the stained area.

2. Add enough water to moisten the baking soda, making a paste like texture.

3. Let sit for a few minutes (for tougher stains let sit up to an hour).

4. Lightly scrub with a plastic scouring pad or damp cloth and dry thoroughly.

5. Repeat if necessary.

Should any stubborn stains appear, they will not aect the performance and nonstick quality of the Titanium Infused DuraCeramic™ coating.

STORAGE & MAINTENANCE

• Unplug unit and allow to cool. Never store unit while it is hot.

• Clean and thoroughly dry the skillet before storing.

• For convenience, the temperature control probe can be stored inside the covered electric skillet.

• To avoid scratching the nonstick surface, place a paper towel into the skillet.
