7.1ch THX Certified Digital Surround
Receiver and Speaker Package
HT-S990THX
Contents
Introduction ..................................... 2
Connection .................................... 19
AV Receiver (HT-R940)
Front Speakers (SKF-940F)
Center Speaker (SKC-940C)
Surround Speakers (SKM-940S)
Surround Back Speakers (SKB-940)
Powered Subwoofer (SKW-940)
Instruction Manual
Thank you for purchasing an Onkyo 7.1ch THX Certified Digital Surround Receiver and Speaker Package. Please read this manual thoroughly before
making connections and plugging in the unit.
Following the instructions in this manual will enable
you to obtain optimum performance and listening
enjoyment from your new 7.1ch THX Certified Digital Surround Receiver and Speaker Package.
Please retain this manual for future reference.
Turning On & First Time Setup..... 34
Basic Operation
Playing your AV components....... 37
Listening to the Radio.................. 39
Enjoying the Listening Modes ..... 45
Recording ...................................... 52
Advanced Operation..................... 53
Troubleshooting ............................ 60
Specifications................................ 64
E
n
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS APPARATUS
TO RAIN OR MOISTURE.
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK). NO
USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE
PERSONNEL.
Important Safety Instructions
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
AVIS
RISQUE DE CHOC ELECTRIQUE
OUVRIR
NE PAS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding
type plug has two blades and a third grounding
prong. The wide blade or the third prong are provided for your safety. If the provided plug does not
fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the
manufacturer.
12.
Use only with the cart, stand,
PORTABLE CART WARNING
tripod, bracket, or table specified by the manufacturer, or
sold with the apparatus.
When a cart is used, use caution when moving the cart/
apparatus combination to
avoid injury from tip-over.
S3125A
13. Unplug this apparatus during lightning storms or
when unused for long periods of time.
14. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
15. Damage Requiring Service
Unplug the apparatus from the wall outlet and refer
servicing to qualified service personnel under the
following conditions:
A. When the power-supply cord or plug is damaged,
B. If liquid has been spilled, or objects have fallen
into the apparatus,
C. If the apparatus has been exposed to rain or
water,
D. If the apparatus does not operate normally by
following the operating instructions. Adjust only
those controls that are covered by the operating
instructions as an improper adjustment of other
controls may result in damage and will often
require extensive work by a qualified technician
to restore the apparatus to its normal operation,
E. If the apparatus has been dropped or damaged in
any way, and
F. When the apparatus exhibits a distinct change in
performance this indicates a need for service.
16. Object and Liquid Entry
Never push objects of any kind into the apparatus
through openings as they may touch dangerous voltage points or short-out parts that could result in a
fire or electric shock.
The apparatus shall not be exposed to dripping or
splashing and no objects filled with liquids, such as
vases shall be placed on the apparatus.
Don’t put candles or other burning objects on top of
this unit.
17. Batteries
Always consider the environmental issues and follow local regulations when disposing of batteries.
18. If you install the apparatus in a built-in installation,
such as a bookcase or rack, ensure that there is adequate ventilation.
Leave 20 cm (8") of free space at the top and sides
and 10 cm (4") at the rear. The rear edge of the shelf
or board above the apparatus shall be set 10 cm (4")
away from the rear panel or wall, creating a flue-like
gap for warm air to escape.
2
Precautions
1. Recording Copyright
only, recording copyrighted material is illegal without the permission of the copyright holder.
2. AC Fuse
serviceable. If you cannot turn on the unit, contact
your Onkyo dealer.
3. Care
over with a soft cloth. For stubborn stains, use a soft
cloth dampened with a weak solution of mild detergent and water. Dry the unit immediately afterwards
with a clean cloth. Don’t use abrasive cloths, thinners, alcohol, or other chemical solvents, because
they may damage the finish or remove the panel lettering.
4. Power
WARNING
BEFORE PLUGGING IN THE UNIT FOR THE
FIRST TIME, READ THE FOLLOWING SECTION CAREFULLY.
AC outlet voltages vary from country to country.
Make sure that the voltage in your area meets the
voltage requirements printed on the unit’s rear panel
(e.g., AC 230–240 V, 50 Hz or AC 120 V, 60 Hz).
The power cord plug is used to disconnect this unit
from the AC power source. Make sure that the plug
is readily operable (easily accessible) at all times.
Pressing the [STANDBY/ON] button to select
Standby mode does not fully shutdown the unit. If
you do not intend to use the unit for an extended
period, remove the power cord from the AC outlet.
5. Never Touch this Unit with Wet Hands
handle this unit or its power cord while your hands
are wet or damp. If water or any other liquid gets
inside this unit, have it checked by your Onkyo
dealer.
6. Handling Notes
• If you need to transport this unit, use the original
• Do not leave rubber or plastic items on this unit
• This unit’s top and rear panels may get warm
• If you do not use this unit for a long time, it may
—The AC fuse inside the unit is not user-
—Occasionally you should dust the unit all
packaging to pack it how it was when you originally bought it.
for a long time, because they may leave marks on
the case.
after prolonged use. This is normal.
not work properly the next time you turn it on, so
be sure to use it occasionally.
—Unless it’s for personal use
—Never
For U.S. models
FCC Information for User
CAUTION:
The user changes or modifications not expressly
approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
NOTE:
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
For Canadian Models
NOTE:
COMPLIES WITH CANADIAN ICES-003.
For models having a power cord with a polarized plug:
CAUTION:
MATCH WIDE BLADE OF PLUG TO WIDE SLOT,
FULLY INSERT.
THIS CLASS B DIGITAL APPARATUS
TO PREVENT ELECTRIC SHOCK,
Modèle pour les Canadien
REMARQUE:
LA CLASSE B EST CONFORME À LA NORME
NMB-003 DU CANADA.
Sur les modèles dont la fiche est polarisée:
ATTENTION:
TRIQUES, INTRODUIRE LA LAME LA PLUS
LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER
JUSQU’AU FOND.
CET APPAREIL NUMÉRIQUE DE
POUR ÉVITER LES CHOCS ÉLEC-
3
Precautions
—Continued
Speaker Precautions
For British models
Replacement and mounting of an AC plug on the power
supply cord of this unit should be performed only by
qualified service personnel.
IMPORTANT
The wires in the mains lead are coloured in accordance
with the following code:
Blue: Neutral
Brown: Live
As the colours of the wires in the mains lead of this
apparatus may not correspond with the coloured markings identifying the terminals in your plug, proceed as
follows:
The wire which is coloured blue must be connected to
the terminal which is marked with the letter N or
coloured black.
The wire which is coloured brown must be connected to
the terminal which is marked with the letter L or
coloured red.
IMPORTANT
The plug is fitted with an appropriate fuse. If the fuse
needs to be replaced, the replacement fuse must
approved by ASTA or BSI to BS1362 and have the same
ampere rating as that indicated on the plug. Check for
the ASTA mark or the BSI mark on the body of the fuse.
If the power cord’s plug is not suitable for your socket
outlets, cut it off and fit a suitable plug. Fit a suitable
fuse in the plug.
For European Models
Declaration of Conformity
We,
ONKYO EUROPE
ELECTRONICS GmbH
LIEGNITZERSTRASSE 6,
82194 GROEBENZELL,
GERMANY
declare in own responsibility, that the ONKYO product
described in this instruction manual is in compliance with the
corresponding technical standards such as EN60065,
EN55013, EN55020 and EN61000-3-2, -3-3.
GROEBENZELL, GERMANY
K. MIYAGI
ONKYO EUROPE ELECTRONICS GmbH
This product incorporates copyright protection technology that is protected by U.S. patents and other
intellectual property rights. Use of this copyright
protection technology must be authorized by Macrovision Corporation, and is intended for home and
other limited consumer uses only unless otherwise
authorized by Macrovision. Reverse engineering or
disassembly is prohibited.
Placement
• The speaker cabinets are made out of wood and are
therefore sensitive to extreme temperatures and
humidity, do not put them in locations subject to
direct sunlight or in humid places, such as near an air
conditioner, humidifier, bathroom, or kitchen.
• Do not put water or other liquids close to the speakers. If liquid is spilled over the speakers, the drive
units may be damaged.
• Speakers should only be placed on sturdy, flat surfaces that are free from vibration. Putting them on
uneven or unstable surfaces, where they may fall and
cause damage, will affect the sound quality.
• Subwoofer is designed to be used in the upright vertical position only. Do not use it in the horizontal or
tilted position.
• If the unit is used near a turntable, CD player or
DVD player, howling or slipping of sound may
occur. To prevent this, move the unit away from the
turntable, CD player or DVD player otherwise lower
the unit’s output level.
Using Close to a TV or Computer
TVs and computer monitors are magnetically sensitive
devices and as such are likely to suffer discoloration or
picture distortion when conventional speakers are
placed nearby. To prevent this, the SKF-940F and SKC940C feature internal magnetic shielding. In some situations, however, discoloration may still be an issue, in
which case you should turn off your TV or monitor, wait
15 to 30 minutes, and then turn it back on again. This
normally activates the degaussing function, which neutralizes the magnetic field, thereby removing any discoloration effects. If discoloration problems persist, try
moving the speakers away from your TV or monitor.
Note that discoloration can also be caused by a magnet
or demagnetizing tool that’s too close to your TV or
monitor.
Input Signal Warning
The speakers can handle the specified input power when
used for normal music reproduction. If any of the following signals are fed to them, even if the input power is
within the specified rating, excessive current may flow in
the speaker coils, causing burning or wire breakage:
1.
Interstation noise from an untuned FM radio.
2.
Sound from fast-forwarding a cassette tape.
3.
High-pitched sounds generated by an oscillator, electronic musical instrument, and so on.
4.
Amplifier oscillation.
5.
Special test tones from audio test CDs and so on.
6.
Thumps and clicks caused by connecting or disconnecting audio cables (Always turn off your amplifier
before connecting or disconnecting cables.)
7.
Microphone feedback.
4
Package Contents
Make sure you have the following items:
AV receiver (HT-R940)
Remote controller & two batteries (AA/R6)
Subwoofer (SKW-940)
(Red) (White)
Speaker cable for front speakers 15 ft. (4.5 m)
Indoor FM antenna
AM loop antenna
THX Ultimate Demo Disc
Front speakers (SKF-940F)
Center speaker (SKC-940C)
(Green)
Speaker cable for center speaker 10 ft. (3 m)
(Blue) (Gray)
(Brown) (Tan)
Speaker cables for surround speakers 30 ft. (9 m)
RCA cable for subwoofer connection 10 ft. (3 m)
* In catalogs and on packaging, the letter at the end of the
product name indicates the color. Specifications and operation are the same regardless of color.
Surround and Surround back speakers
(SKM-940S/SKB-940)
5
Features
Amplifier
• 7-channel amplifier
• 110 watts minimum continuous power per channel, 8
ohm loads, 2 channels driven at 1 kHz, with a maximum total harmonic distortion of 0.9%
• WRAT (Wide Range Amplifier Technology)
• Optimum Gain Volume Circuitry
Processing
• THX*1 Surround EX
• Dolby*2 Digital EX and Dolby Pro Logic IIx
• DTS, DTS-ES Matrix/Discrete, DTS Neo:6, and
DTS 96/24
• Neural Surround
• Re-EQ*5 Function
• Linear PCM 192 kHz/24-bit D/A converters on all
channels
• Pure Audio listening mode (not North American
model)
•Powerful and highly accurate 32-bit DSP processing
*3
*4
(North American models only)
*1
THX is a trademark of THX Ltd. THX may be registered
in some jurisdictions. All rights reserved. Surround EX is a
trademark of Dolby Laboratories. Used with permission.
*2
Manufactured under license from Dolby Laboratories.
“Dolby”, “Pro Logic” and the double-D symbol are registered trademarks of Dolby Laboratories.
*3
“DTS,” “DTS 96/24,” “DTS-ES,” and “Neo:6” are trademarks of DTS, Inc.
*4
Neural Surround name and related logos are trademarks
owned by Neural Audio Corporation.
*5 Re-Equalization and the “Re-EQ” logo are trademarks of
THX Ltd.
Audio/Video
• HDTV-capable component video (3 inputs, 1 output)
• Composite and S-video to component video conversion
•3 S-Video inputs, 2 outputs
•4 assignable digital inputs (3 optical, 1 coaxial)
• Subwoofer pre out
• Color-coded 7.1 multichannel input for use with
Super Audio CD and DVD-Audio
• A/B speaker drive
• Color-coded speaker terminal posts
Tuner
• 40 AM/FM presets
• AM/FM auto tuning
• RDS (Radio Data System) (Europe only)
Remote Controller
• Preprogrammed for use with other AV components
Speaker
THX Home Media
Before any home theater component can be THX
Home Mediacertified, it must incorporate all the features above and also pass a rigorous series of quality
and performance tests. Only then can a product feature the THX logo, which is your guarantee that the
Home Theatre products you purchase will give you
superb performance for many years to come. THX
Home Media requirements cover every aspect of the
product including pre-amplifier performance and
operation, and hundreds of other parameters in both
the digital and analog domain.
• Color-coded banana-plug compatible speaker posts
and speaker cables
• Subwoofer Auto standby function
• Magnetically shielded front and center speakers
6
Getting Started in Five Easy Steps
1. Hookup
Connect the AV receiver to your AV system.
☞ page 19
COMPONENT
VIDEO
DIGITAL IN
OUT
IN 3
IN 2 IN 1
COA
Y
XIAL
OPTICAL
1
2
3
REMOTE
CONTROL
P
B
PR
IN IN
OUT
LRLRL
CD TAPE
VIDEO 2 VIDEO 1
V
S
IN IN IN
IN IN
R
VIDEO 2 VIDEO 1 DVD
2. Turning On
With the hookup complete, you’re ready to switch on.
☞ page 34
SURROUND BACK
SURROUND
FRONT
SPEAKERS
ANTENNA
FMAM75
L
MONITOR
DVD
OUT
R
OUT
SURROUND
SURR BACK
CENTER
FRONT
OUT
L
R
SUB
WOOFER
CENTER
SPEAKERS
SPEAKERS A
SPEAKER
L
R
FRONT
SPEAKERS B
PRE OUT
L
SUB
WOOFER
R
AC OUTLET
AC 120V
60Hz
SWITCHED
120W1A MAX.
AV RECEIVER
3. First Time Setup
A few simple settings to get the very best from your system.
☞ page 35
4. Playing Your AV Components
Enjoying movies and music.
☞ page 37
5. Using the Listening Modes
Time to really enjoy your home theater system!
☞ page 45
Digital Input
Input Display
7
Enjoying Home Theater
Speaker Sets A and B
You can use two sets of speakers with the AV receiver:
Speaker set A
*While speaker set B is on, speaker set A is reduced to 5.1-channel playback.
Speaker set B
*Only analog input sources are output by speaker set B.
AV receiver
SPEAKERS
AB
Front left and right speakers (SKF-940F)
These output the overall sound. Their role in a home theater is to provide a solid anchor for the sound image. They should be positioned
facing the listener at about ear level, and equally spaced from the TV.
Angle them inward.
Center speaker (SKC-940C)
This speaker enhances the front
left and right speakers, making
sound movements distinct and
providing a full sound image. For
movies it’s used mainly for dialog.
Position it close to your TV facing
forward at about ear level, or at
the same height as the front left
and right speakers.
should be used in your main listening room for up to 7.1-channel playback.
can be used in another room and offers 2-channel stereo playback.
Speaker set A Speaker set B Indicator Output
Remote
controller
or
On
Off
Corner
speaker set A
On
Off Set A: 7.1 channels
On Set B: 2 channels
Off No sound
and
speaker set B
A B
.
Set A: 5.1 channels
Set B: 2 channels
A
B
Speaker Set A: Main Room
Surround left and right speakers
(SKM-940S)
These speakers are used for precise
sound positioning and to add realistic
ambience. Position them at the sides
of the listener, or slightly behind, about
2–3 feet (60–100 cm) above ear level.
Ideally they should be equally spaced
from the listener.
Subwoofer (SKW-940)
The subwoofer handles the bass
sounds of the LFE (Low-Frequency
Effects) channel. In general, a
good bass sound can be obtained
by installing the subwoofer in a
front corner, or at one-third the way
along the wall, as shown.
Speaker Set B: Sub Room
8
1/3 wall
length
Surround back left and right speakers (SKB-940)
These speakers further enhance the realism of surround
sound and improve sound localization behind the listener.
Position them behind the listener about 2–3 feet (60–100 cm)
above ear level.
THX recommends that they be placed as close as possible in
order to make advantage of their proprietary ASA (Advanced
Speaker Array) technology. If this condition is not possible,
adjust the SB Spc (Surround Back Spacing) setting via the
THX Audio (see page 51).
* While speaker set B is on, these speakers output no sound.
Contents
Introduction
Important Safety Instructions ....................2
Precautions .................................................3
Speaker Precautions ..................................4
Package Contents.......................................5
Features .......................................................6
Enjoying Home Theater..............................8
Speaker Sets A and B ................................... 8
Getting to Know the AV Receiver............10
Remote Controller.....................................13
Speakers ....................................................18
Connection
Connecting Your Speakers ......................19
Connecting Antennas...............................20
Connecting Your Components ................22
About AV Connections ................................22
Connecting Audio and Video Signals
to the AV Receiver .................................... 23
Which Connections Should I Use?..............23
TV or Projector
DVD player
VCR or DVD Recorder for Playback ...........27
VCR or DVD Recorder for Recording.......... 28
Camcorder, Games Console,
or Other Device.........................................28
Satellite, Cable, Set-top box,
or Other Video Source ..............................29
CD Player or Turntable................................30
HDD-compatible Component ......................31
Cassette, CDR, MiniDisc, or
DAT Recorder ........................................... 32
Connecting the Power Cord of Another
Component ...............................................32
Connecting Onkyo Components
Connecting the Power Cord ........................33
..........................................24
.................................................25
..........33
Turning On & First Time Setup
Basic Operation
Playing Your AV Components ................ 37
Basic AV Receiver Operation ..................... 37
Using the Multichannel DVD Input.............. 38
Displaying Source Information.................... 38
Listening to the Radio.............................. 39
Listening to AM/FM stations ....................... 39
Presetting Radio Stations ........................... 40
Common Functions.................................. 43
Setting the Display Brightness.................... 43
Adjusting the Bass and Treble.................... 43
Muting the AV Receiver .............................. 43
Using the Sleep Timer ................................ 44
Using Headphones ..................................... 44
Adjusting Speaker Levels ........................... 44
Enjoying the Listening Modes
Using the Listening Modes...................... 45
Selecting Listening Modes.......................... 45
About the Listening Modes ......................... 47
Using the Late Night Function .................... 49
Using the Re-EQ ........................................ 49
Using the Audio Adjust Settings ................. 49
Using the THX Audio Settings .................... 51
Recording.................................................. 52
Advanced Operation
Advanced Setup ....................................... 53
Advanced Speaker Settings ....................... 53
Digital Input Signal Formats ....................... 56
Correcting Sound and Picture Sync ........... 56
Controlling Other Components............... 57
Entering Remote Control Codes................. 57
Remote Control Codes for Onkyo
Components Connected via .............. 58
Resetting REMOTE MODE Buttons ........... 58
Resetting the Remote Controller ................ 58
Turning On the AV Receiver ....................34
First Time Setup........................................35
Assigning Digital Inputs to Input Sources....35
Changing the Input Display .........................35
Component Video Setup .............................36
Troubleshooting ....................................... 60
If you can’t resolve an issue, try resetting the AV
receiver by holding down the [VIDEO 1] button
and pressing the [STANDBY/ON] button.
Specifications ........................................... 64
9
Getting to Know the AV Receiver
Front Panel
North American Model
2
1
3 5 6 74
STANDBY/ON
PHONES
Other Models
STANDBY/ON
PURE AUDIO
PHONES
STANDBY
STANDBY
DVDMULTI CH C
VCR
SPEAKERS
SPEAKERS
TONE
DVDMULTI CH C
VCR
TONE
VIDEO
VIDEO
3VIDEO 2VIDEO 1
LISTENING MODE
3VIDEO 2VIDEO 1
LISTENING MODE
TUNERTAPE
D
DIGITAL
DISPLAYTHX DIMMER MEMORY
INPUT
TUNERTAPE
D
DIGITAL
DISPLAYTHX RT/RTY/TP MEMORY
INPUT
CLEAR
TUNING
MODEAB
CLEAR
TUNING PRESET
TUNING PRESET
TUNING
MODEAB
MASTER VOLUME
ENTER
SETUPRETURN
VIDEO 3 INPUT
VIDEO
AUDIOLR
TJKLMNOPQ8 9RS
MASTER VOLUME
ENTER
SETUPRETURN
VIDEO 3 INPUT
VIDEO
AUDIOLR
For detailed information, see the pages in parentheses.
A
STANDBY/ON button (34)
Sets the AV receiver to On or Standby.
B
STANDBY indicator (34)
Lights up when the AV receiver is on Standby and
flashes while a signal is being received from the
remote controller.
Remote-control sensor (13)
C
Receives control signals from the remote controller.
Display
D
See “Display” on page 11.
Input selector buttons (37)
E
Select the input sources.
The [MULTI CH] button selects the multichannel
DVD input.
10
(European model only)
OU
F
Arrow/TUNING/PRESET and ENTER buttons
When AM or FM is selected, the TUNING [ ]
[] buttons are used for radio tuning, and the PRESET [ ] [ ] buttons are used to select radio pre-
sets (see page 40). With the setup menus, they work
as arrow buttons and are used to select and set
items. The ENTER button is also used with the
setup menus.
G
MASTER VOLUME control (37)
Sets the volume of the AV receiver to –∞ dB, –83 dB
through +16 dB (relative display).
The volume level can also be displayed as an absolute value. See “Vol Display” on page 51.
H
PHONES jack (44)
This 1/4-inch phone jack is for connecting a standard pair of stereo headphones for private listening.
Getting to Know the AV Receiver
—Continued
SPEAKERS A and B buttons (8, 37)
I
Turn speaker sets A and B on or off.
TONE, [–], and [+] buttons (43)
J
Used to adjust the bass and treble.
THX button (45)
K
Selects the THX listening mode.
LISTENING MODE [ ]/[ ] buttons (45)
L
Select the listening modes.
DISPLAY button (38)
M
Displays various information about the currently
selected input source.
DIGITAL INPUT button (35, 56)
N
Used to assign the digital inputs and to specify the
format of digital input signals.
DIMMER or RT/PTY/TP button (42, 43)
O
Adjusts the display brightness.
On the European model, this is the RT/PTY/TP but-
ton, and it’s used with RDS (Radio Data System).
See “Using RDS (European Models Only)” on
page 41.
MEMORY button (40)
P
Used when storing or deleting radio presets.
TUNING MODE button (39)
Q
Selects the Auto or Manual tuning mode for AM
and FM radio.
RETURN button
R
Selects the previously displayed setup menu.
SETUP button
S
Used to access the setup menus.
VIDEO 3 INPUT (28, 52)
T
Used to connect a camcorder, games console, and so
on. There are jacks for composite video and analog
audio.
U
PURE AUDIO button and indicator (45)
The North American model doesn’t have this button
and indicator.
Selects the Pure Audio listening mode. The indicator lights up when this mode is selected.
Display
2134
5
For detailed information, see the pages in parentheses.
1
A and B speaker indicators (8, 37)
Indicator A lights up when speaker set A is on. Indicator B lights up when speaker set B is on.
2
MUTING indicator (43)
Flashes while the AV receiver is muted.
3
Listening mode and format indicators (45)
Show the selected listening mode and the format of
digital audio signals.
4
Radio indicators
TUNED (39):
tion.
Lights up when tuned to a radio sta-
6
RDS (European models only) (41):
when tuned to a radio station that supports RDS
(Radio Data System).
MEMORY (40):
stations.
FM STEREO (39):
reo FM station.
SLEEP indicator (44)
5
Lights up when the Sleep function has been set.
Message area
6
Displays various information about the selected
input source.
Lights up when presetting radio
Lights up when tuned to a ste-
Lights up
AUTO (39):
Auto Tuning is selected, and disappears when Manual Tuning mode is selected.
For AM and FM radio, lights up when
11
Getting to Know the AV Receiver
Rear Panel
—Continued
1 3 42 5
ANTENNA
DIGITAL IN
COA
XIAL
OPTICAL
1
2
3
REMOTE
CONTROL
IN 3
COMPONENT
IN 2 IN 1
IN IN
L
R
CD TAPE
VIDEO
OUT
OUT
Y
VIDEO 2 VIDEO 1
P
B
V
PR
S
L
L
R
R
VIDEO 2 VIDEO 1 DVD
FMAM75
IN IN IN
OUT
IN IN
OUT
FRONT
7 8 9 J K L N
A
DIGITAL IN OPTICAL 1, 2, 3, and COAXIAL
These optical and coaxial digital audio inputs are
for connecting components with optical or coaxial
digital audio outputs, such as CD and DVD players.
B
COMPONENT VIDEO
A DVD player, TV, or other component that supports component video can be connected here.
C
AM ANTENNA
These push terminals are for connecting an AM
antenna.
D
FM ANTENNA
This jack is for connecting an FM antenna.
E
MONITOR OUT
The S-Video or composite video output should be
connected to a video input on your TV or projector.
F
FRONT SPEAKERS A, SURROUND
SPEAKERS, CENTER SPEAKER, and
SURROUND BACK SPEAKERS
These terminal posts are for connecting speaker
set A.
G
H
REMOTE CONTROL
This Remote Interactive jack can be connected
to the jack on another -capable Onkyo component. To use , you must make an analog audio
connection (RCA) between the AV receiver and the
other component, even if they are connected digitally.
CD IN
This analog audio input is for connecting a CD
player’s analog audio output.
6
PRE OUT
SUB
WOOFER
FRONT
SPEAKERS A
SPEAKERS B
L
R
SURROUND BACK
SPEAKERS
L
MONITOR
DVD
OUT
R
SURROUND
SURR BACK
CENTER
SUB
WOOFER
SURROUND
SPEAKERS
L
R
FRONT
CENTER
SPEAKER
L
R
AV RECEIVER
AC OUTLET
AC 120V
SWITCHED
120W 1A MAX.
60Hz
M
I
TAPE IN/OUT
This analog audio input and output are for connecting a recorder with an analog audio input and output, such as a cassette deck, MD recorder, etc.
J
VIDEO 1 IN/OUT and VIDEO 2 IN
The VIDEO 1 inputs and outputs can be used to
connect a VCR. The VIDEO 2 inputs can be used to
connect another video source (e.g., cable/satellite
receiver, set-top box, etc).
K
DVD IN
These jacks can be used to connect a DVD player
with an analog multichannel audio output for SACD
and DVD-Audio playback.
L
SUBWOOFER PRE OUT
A powered subwoofer can be connected here.
M
FRONT SPEAKERS B
These push terminals are for connecting speaker
set B.
N
AC OUTLET
This switched AC outlet can be used to supply
power to another AV component. The type of outlet
depends on the country in which you purchased
your AV receiver.
12
See pages 19–33 for hookup information.
Remote Controller
Installing the Batteries
To open the battery compartment, press
1
the small hollow and slide open the cover.
Insert the two supplied batteries (AA/R6)
2
in accordance with the polarity diagram
inside the battery compartment.
Slide the cover shut.
3
Aiming the Remote Controller
When using the remote controller, point it toward the AV
receiver’s remote control sensor, as shown below.
Remote control sensor
AV receiver
STANDBY indicator
Approx. 16 ft.
(5 m)
Notes:
• The remote controller may not work reliably if the AV
receiver is subjected to bright light, such as direct sunlight or inverter-type fluorescent lights. Keep this in
mind when installing.
• If another remote controller of the same type is used in
the same room, or the AV receiver is installed close to
equipment that uses infrared rays, the remote controller may not work reliably.
• Don’t put anything on top of the remote controller,
such as a book or magazine, because a button may be
pressed continuously, thereby draining the batteries.
• The remote controller may not work reliably if the AV
receiver is installed in a rack behind colored glass
doors. Keep this in mind when installing.
• The remote controller will not work if there’s an obstacle between it and the AV receiver’s remote control
sensor.
Notes:
• If the remote controller doesn’t work reliably, try
replacing the batteries.
• Don’t mix new and old batteries or different types of
batteries.
• If you intend not to use the remote controller for a long
time, remove the batteries to prevent damage from
leakage or corrosion.
• Expired batteries should be removed as soon as possible to prevent damage from leakage or corrosion.
13
Remote Controller
—Continued
Using the Remote Controller
Including the AV receiver, the remote controller can be
used to control up to seven different components. The
remote controller has a specific operating mode for use
with each type of component. Modes are selected by
using the six REMOTE MODE buttons.
■
RECEIVER/TAPE Mode
In RECEIVER/TAPE mode, you can control
the AV receiver and an Onkyo cassette
recorder connected via .
■
DVD and CD/MD/CDR/HDD Modes
With these modes, you can control a DVD
player and CD, MD, CDR, or HDD player
or recorder. By entering the appropriate
remote control code, you can control Onkyo
components or components made by other
manufacturers (see page 57).
■
TV, VCR and SAT/CABLE Modes
With these modes, you can control a TV,
VCR, and satellite or cable receiver. You
must enter the appropriate remote control
code first (see page 57).
RECEIVER
TAPE
DVD
M D/CDR
C
D
HDD
TV
VCR
CABLE
SAT
RECEIVER/TAPE Mode
RECEIVER/TAPE mode is used to control the AV
receiver. It can also be used to control an Onkyo cassette
recorder connected via .
RECEIVER
TAPE
K
L
M
N
1
2
3
1
2
3
4
5
6
ON/STANDBY
INPUT SELECTOR
123
V
1
456
789
10 11 12
+
10
D TUN
--/---
TV
INPUT
GUIDE
TOP MENU
SP A / B
PLAYLIST/CAT PLAYLIST/CAT
V
MULTI CH
0
DIMMER
VOL
2
ENT
ENTER
REMOTE MODE
DVD
RECEIVER
TAPE
M
D/CDR
C D
HDD
V
3
TV
DVD
VCR
C DTAPE TUNER
CABLE
SAT
CLR
SLEEP
CH
DISC
VOL
ALBUM
PREVIOUS
MENU
MUTING
1
REMOTE MODE
RECEIVER
TAPE
2
Press one of the REMOTE MODE
buttons to select a mode.
DVD
M D/CDR
D
C
HDD
TV
VCR
CABLE
SAT
Use the buttons supported by
that mode to control the component.
RECEIVER/TAPE mode:
see right column
DVD mode:
see page 16
CD/MD/CDR/HDD mode:
see page 17
TV, VCR, SAT/CABLE modes:
see page 59
7
4
LISTENING MODE
SURROUND
8
9
J
Buttons
or TAPE input is selected.
STEREO
SUBTITLE
AUDIO REPEAT
TEST TONE
PLAY MODE
DISPLAY
1, 2, 3
, and 4 are used when the TUNER
CH SEL
RC
RANDOM
LEVEL
L NIGHT
-
650M
SETUPRETURN
O
+
-
LEVEL
Re-EQ
HDDDVDVCR
P
Q
Note:
Some of the remote controller operations described in
this manual may not work as expected with other components.
14
Remote Controller
—Continued
For detailed information, see the pages in parentheses.
A
ON/STANDBY button (34)
Sets the AV receiver to On or Standby.
B
INPUT SELECTOR buttons (37)
Used to select the input sources.
MULTI CH button (38)
C
Selects the multichannel DVD input.
DIMMER button (43)
D
Adjusts the display brightness.
E
SP A/B button (8, 37)
Used to turn speaker sets A and B on or off.
F
Arrow [ ]/[ ]/[ ]/[ ] and ENTER buttons
Used to select and adjust settings.
G
RETURN button
Selects the previously displayed setup menu.
LISTENING MODE buttons (45)
H
Used to select the listening modes. These buttons
work in all remote controller modes.
STEREO button
Selects the Stereo listening mode.
SURROUND button
Selects the Dolby and DTS listening modes and the
Neural Surround listening mode (North American
model only).
[ ]/[ ] buttons
Used to select the available listening modes.
I
TEST TONE, CH SEL, LEVEL-, and LEVEL+
buttons (34, 44, 54)
Used to adjust the level of each speaker.
J
DISPLAY button (38)
Displays various information about the selected
input source.
REMOTE MODE buttons (14)
K
Used to select the remote controller modes. When a
remote controller button is pressed, the REMOTE
MODE button for the currently selected mode lights
up.
L
SLEEP button (44)
Used with the Sleep function.
VOL [ ]/[ ] button (37)
M
Adjusts the volume of the AV receiver regardless of
the currently selected remote controller mode.
MUTING button (43)
N
Mutes or unmutes the AV receiver.
SETUP button
O
Used to access the setup menus.
P
Re-EQ button (49)
Used with the Re-EQ function.
Q
L NIGHT button (49)
Used with the Late Night function.
■
Buttons used when the TUNER input is
selected
To select the Tuner (AM/FM) as the input
source, press:
RECEIVER
1
Number and D TUN buttons (40)
Used to select AM and FM radio stations directly.
2
CH +/– button (40)
Used to select radio presets.
3
Arrow [ ]/[ ]/[ ]/[ ] and ENTER buttons
For AM and FM, the Up and Down [ ]/[ ] buttons are used for tuning.
■
Buttons used when the TAPE input is
selected
To select your Cassette deck as the input
source, press:
RECEIVER
Playback buttons
4
On twin cassette decks, only deck B can be controlled.
Play [ ] button
Starts playback.
Stop [ ] button
Stops playback.
Reverse Play [ ] button
Starts reverse playback.
Rewind and FF [ ]/[ ] buttons
The Rewind [ ] button starts rewind. The FF
[] button starts fast forward.
8
TUNER
7
TAPE
15
Remote Controller
DVD Mode
—Continued
By default, the remote controller is set to control an
Onkyo DVD player.
To select your DVD player as the input source, press:
6
REMOTE MODE
RECEIVER
TAPE
V
3
DVD
C DTAPE TUNER
CLR
ENT
SLEEP
CH
DISC
ALBUM
or
DVD
M
D/CDR
C D
HDD
TV
VCR
CABLE
SAT
VOL
PREVIOUS
MENU
MUTING
SETUPRETURN
5
MULTI CH
DVD
K
L
M
1
2
3
4
5
6
RECEIVER
DVD
ON/STANDBY
INPUT SELECTOR
123
V
1
V
2
456
MULTI CH
789
10 11 12
+
0
10
D TUN
--/---
DIMMER
TV
VOL
INPUT
GUIDE
TOP MENU
SP A / B
ENTER
PLAYLIST/CAT PLAYLIST/CAT
7
LISTENING MODE
SURROUND
8
9
J
STEREO
RANDOM
SUBTITLE
AUDIO REPEAT
TEST TONE
CH SEL
PLAY MODE
DISPLAY
LEVEL
L NIGHT
-
LEVEL
Re-EQ
HDDDVDVCR
+
N
O
P
Q
-
650M
RC
ON/STANDBY button
A
Sets the DVD player to On or Standby.
B
Number buttons
Used to enter title, chapter, and track numbers and
times for locating specific points.
C
DISC +/– button
Selects discs on a DVD changer.
D
TOP MENU button
Selects a DVD’s top menu.
E
Arrow [ ]/[ ]/[ ]/[ ] and ENTER buttons
Used to navigate DVD menus and the DVD player’s
onscreen setup menus.
F
RETURN button
Exits the DVD player’s onscreen setup menus.
G
Playback buttons
From left to right: Pause, Play, Stop, Fast Reverse,
Fast Forward, Previous, and Next.
H
SUBTITLE button
Selects subtitles.
AUDIO button
I
Selects foreign language soundtracks and audio formats (e.g., Dolby Digital or DTS).
DISPLAY button
J
Displays information about the current disc, title,
chapter, or track, including elapsed time, remaining
time, total time, and so on.
K
CLR button
Cancels functions and clears entered numbers.
MENU button
L
Displays a DVD’s menu.
SETUP button
M
Used to access the DVD player’s onscreen setup
menus.
RANDOM button
N
Used with the random playback function.
O
REPEAT button
Used with the repeat playback functions.
P
VCR, DVD, and HDD buttons
Used to select VCR, HDD (hard disk drive), or
DVD playback on a VCR/DVD recorder with a
built-in hard disk drive.
Q
PLAY MODE button
Selects play modes on components with selectable
play modes.
16
Remote Controller
—Continued
CD/MD/CDR/HDD Mode
By default, the remote controller is set to control an
Onkyo CD player.
To select the input source, press:
9
C D
RECEIVER
TAPE
7
TAPE
7
or
* If you’re using an MD, CDR, or HDD component, you
must change the Input Display (see page 35).
ON/STANDBY
1
INPUT SELECTOR
2
3
123
V
1
V
2
456
MULTI CH
789
10 11 12
+
0
10
D TUN
--/---
DIMMER
TV
VOL
INPUT
GUIDE
TOP MENU
4
SP A / B
ENTER
PLAYLIST/CAT PLAYLIST/CAT
CD player
MD or CD recorder
Next generation HDD-
2
compatible component
V2
REMOTE MODE
DVD
RECEIVER
TAPE
M
D/CDR
C D
HDD
V
3
TV
DVD
VCR
C DTAPE TUNER
CABLE
SAT
CLR
ENT
SLEEP
CH
DISC
VOL
ALBUM
PREVIOUS
MENU
MUTING
SETUPRETURN
M D/CDR
C D
HDD
G
8
9
E
ON/STANDBY button
A
Sets the component to On or Standby.
B
Number buttons
Used to enter track numbers and times for locating
specific points on CD/MD players.
C
DISC/ALBUM +/– button
Selects discs on a CD changer, or the next or previous album on an HDD-compatible component.
D
Arrow [ ]/[ ] and ENTER buttons
Used to navigate menus on an HDD-compatible
component.
E
Playback buttons
From left to right: Pause, Play, Stop, Fast Reverse,
Fast Forward, Previous and Next.
F
DISPLAY button
Displays information about the current disc or track
on a CD player or MD/CD recorder, including
elapsed time, remaining time, total time, and so on.
On an HDD-compatible component, it turns on the
back light for 30 seconds.
G
CLR button
Cancels functions and clears entered numbers on a
CD player or MD/CD recorder.
H
MENU button
Used to navigate menus on an HDD-compatible
component.
I
PLAYLIST [ ]/[ ] buttons
Selects the previous or next playlist on an HDDcompatible component.
RANDOM button
J
Used with the random/shuffle playback function.
K
REPEAT button
Used with the repeat playback functions.
L
PLAY MODE button
Used to select play modes on components with
selectable play modes.
LISTENING MODE
SURROUND
STEREO
RANDOM
SUBTITLE
F
AUDIO REPEAT
TEST TONE
CH SEL
PLAY MODE
DISPLAY
-
LEVEL
LEVEL
Re-EQ
L NIGHT
HDDDVDVCR
-
650M
RC
J
+
K
L
17
Speakers
Subwoofer (SKW-940)
For detailed information, see the pages in parentheses.
■ Front
1
■ Rear
(Not North American model)
A
Standby/on indicator
Red: Subwoofer in standby mode
Green: Subwoofer on
With the Auto Standby function, the SKW-940
automatically turns on when an input signal is
detected in Standby mode. When there’s no input
signal for a while, the SKW-940 automatically
enters Standby mode.
B
OUTPUT LEVEL control (37)
This control is used to adjust the volume of the subwoofer.
C
LINE INPUT (19)
This RCA input should be connected to the subwoofer pre out on the AV receiver with supplied
RCA cable.
D
POWER switch (Not North American model)
(34)
Press this switch to the ON position to turn on the
power. Press it to the OFF position to turn off the
power.
243
To AC outlet
■ Attaching and detaching the speaker grilles
Front, Center, and Surround speakers have detachable grilles.
Use the following method to attach or detach the grilles.
1. While holding the bottom edge of the speaker grille with
your both hands, pull it gently toward you to remove the
bottom of the grille.
2. In the same way, gently pull the upper edge of the speaker
grille toward you to remove it from the main unit.
3. To replace the grill, push the projections at the corners
into the grille plug holes on the speaker cabinet.
Note:
The Auto Standby function turns the subwoofer on when
the input signal exceeds a certain level. If the Auto
Standby function does not work reliably, try slightly
increasing or decreasing the subwoofer output level on
the AV receiver (page 54).
ReplacementRemoval
18
Connecting Your Speakers
M
S
Speaker Connection Precautions
Read the following before connecting your speakers:
•You can connect speakers with an impedance of
8 ohms or higher
impedance, and use the amplifier at high volume levels for a long period of time, the built-in protection
circuit may be activated.
• Disconnect the power cord from the wall outlet before
making any connections.
•Pay close attention to speaker wiring polarity. In other
words, connect positive (+) terminals to only positive
(+) terminals, and negative (–) terminals to only negative (–) terminals. If you get them the wrong way
around, the sound will be out of phase and will sound
unnatural.
• Unnecessarily long, or very thin speaker cables may
affect the sound quality and should be avoided.
• Be careful not to short the
positive and negative wires.
Doing so may damage the AV
receiver.
• Don’t connect more than one
cable to each speaker terminal. Doing so may damage the
AV receiver.
• Don’t connect one speaker to several terminals.
. If you use speakers with a lower
Connecting Speaker Set A
The AV receiver’s positive (+) speaker terminals and
speaker’s positive (+) terminals are color-coded for ease
of identification. (The negative (–) speaker terminals are
all black.) Match the color of each cable to the corresponding speaker terminal.
Speaker terminal Color
Front left White
Front right Red
Center Green
Surround left Blue
Surround right Gray
Surround back left Brown
Surround back right Tan
On the AV receiver, unscrew the terminal. Fully
1
insert the bare wires. Make sure that the bare wire
is touching the inside of the pole. Screw the terminal tight.
On the speakers, loosen the binding posts.
2
Insert the speaker wires
into the binding posts as
shown, then tighten the
binding posts.
Using the supplied RCA cable, connect the AV
3
receiver’s SUBWOOFER PRE OUT to LINE
INPUT on the subwoofer.
Make sure the cable is plugged all the way.
Subwoofer Front Right Center Front Left
Connecting Speaker Set B (sold
separately)
Green
Red
LINE INPUT
SURROUND BACK
SURROUND
FRONT
SPEAKERS
SPEAKERS
SPEAKERS A
L
ONITOR
OUT
R
PRE OUT
URROUND
SURR BACK
CENTER
L
SUB
L
WOOFER
R
R
SUB
WOOFER
DVD
SURROUND BACK
L
R
PRE OUT
SUB
WOOFER
CENTER
SPEAKER
L
R
AC OUTLET
AC 230-240V
50Hz
FRONT
SWITCHED
100WMAX.
SPEAKERS B
AV RECEIVER
SPEAKERS
Surround
Back Right
SURROUND
SPEAKERS
Ta n
FRONT
SPEAKERS A
Brown
Surround
Back Left
L
R
CENTER
SPEAKER
Surround
Right
Gray
White
Blue
Surround
Left
Strip 3/8" (10 mm) of insu-
1
lation from the ends of the
3/8" (10 mm)
speaker cables, and twist
the bare wires tightly, as
shown.
While pressing the lever, insert
2
the wire into the hole, and then
release the lever.
Make sure that the terminals are
gripping the bare wires, not the
insulation.
Note:
When speaker set B is turned on, speaker set A is reduced
to 5.1-channel playback.
19
Connecting Antennas
This section explains how to connect the supplied indoor
FM antenna and AM loop antenna, and how to connect
commercially available outdoor FM and AM antennas.
The AV receiver won’t pick up any radio signals without
any antenna connected, so you must connect the antenna
to use the tuner.
AM antenna push terminals
FM antenna jack
FRONT
DIGITAL IN
COA
XIAL
OPTICAL
1
2
3
REMOTE
CONTROL
COMPONENT
VIDEO
OUT
IN 3
IN 2 IN 1
IN IN
OUT
LRLRL
CD TAPE
Y
B
P
PR
ANTENNA
FMAM75
VIDEO 2 VIDEO 1
DVD
V
S
IN IN IN
OUT
IN IN
FRONT
OUT
R
VIDEO 2 VIDEO 1 DVD
SURROUND BACK
SURROUND
SPEAKERS
SPEAKERS
L
MONITOR
OUT
R
SURROUND
SURR BACK
CENTER
SUB
WOOFER
CENTER
SPEAKERS A
SPEAKER
L
R
FRONT
SPEAKERS B
PRE OUT
L
SUB
WOOFER
R
AC OUTLET
AC 120V
60Hz
SWITCHED
120W1A MAX.
AV RECEIVER
Connecting the Indoor FM Antenna
The supplied indoor FM antenna is for indoor use only.
Attach the FM antenna, as shown.
1
■
American Model
Connecting the AM Loop Antenna
The supplied indoor AM loop antenna is for indoor use
only.
Assemble the AM loop antenna, inserting
1
the tabs into the base, as shown.
Connect both wires of the AM loop
2
antenna to the AM push terminals, as
shown.
(The antenna’s wires are not polarity sensitive, so
they can be connected either way around).
Make sure that the wires are attached securely and
that the push terminals are gripping the bare
wires, not the insulation.
Insert the plug fully
into the jack.
■
Other Models
Insert the plug fully
into the jack.
Once your AV receiver is ready for use, you’ll
need to tune into an FM radio station and adjust
the position of the FM antenna to achieve the best
possible reception.
Use thumbtacks or something similar to
2
fix the FM antenna into position.
Thumbtacks, etc.
Push Insert wire Release
Once your AV receiver is ready for use, you’ll
need to tune into an AM radio station and adjust
the position of the AM antenna to achieve the best
possible reception.
Keep the antenna as far away as possible from
your AV receiver, TV, speaker cables, and power
cords.
If you cannot achieve good reception with the supplied
indoor AM loop antenna, try using it with a commercially available outdoor AM antenna (see page 21).
Caution:
Be careful that you don’t injure yourself
when using thumbtacks.
If you cannot achieve good reception with the supplied
indoor FM antenna, try a commercially available outdoor FM antenna instead (see page 21).
20
Connecting Antennas
—Continued
Connecting an Outdoor FM Antenna
If you cannot achieve good reception with the supplied
indoor FM antenna, try a commercially available outdoor FM antenna instead.
FM 75
Notes:
• Outdoor FM antennas work best outside, but usable
results can sometimes be obtained when installed in an
attic or loft.
•For best results, install the outdoor FM antenna well
away from tall buildings, preferably with a clear line
of sight to your local FM transmitter.
• Outdoor antenna should be located away from possible noise sources, such as neon signs, busy roads, etc.
•For safety reasons, outdoor antenna should be situated
well away from power lines and other high-voltage
equipment.
• Outdoor antenna must be grounded in accordance
with local regulations to prevent electrical shock hazards.
Connecting an Outdoor AM Antenna
If good reception cannot be achieved using the supplied
AM loop antenna, an outdoor AM antenna can be used in
addition to the loop antenna, as shown.
Outdoor antenna
Insulated antenna cable
AM loop antenna
Outdoor AM antennas work best when installed horizontally outside, but good results can sometimes be obtained
indoors by mounting horizontally above a window. Note
that the AM loop antenna should be left connected.
Outdoor antenna must be grounded in accordance with
local regulations to prevent electrical shock hazards.
■
Using a TV/FM Antenna Splitter
It’s best not to use the same antenna for both FM and TV
reception, as this can cause interference problems. If circumstances demand it, use a TV/FM antenna splitter, as
shown.
TV/FM antenna splitter
To AV receiver To TV (or VCR)
21
Connecting Your Components
About AV Connections
• Before making any AV connections, read the manuals
supplied with your other AV components.
• Don’t connect the power cord until you’ve completed
and double-checked all AV connections.
Optical Digital Jacks
The AV receiver’s optical digital jacks have shutter-type
covers that open when an optical plug is inserted and
close when it’s removed. Push plugs in all the way.
Caution:
plug straight when inserting and removing.
AV Cables and Jacks
Video
Component
video cable
To prevent shutter damage, hold the optical
Cable Jack Description
Y
P
B
P
R
Y
P
B
R
P
AV Connection Color Coding
RCA-type AV connections are usually color coded: red,
white, and yellow. Use red plugs to connect right-channel audio inputs and outputs (typically labeled “R”). Use
white plugs to connect left-channel audio inputs and outputs (typically labeled “L”). And use yellow plugs to
connect composite video inputs and outputs.
Left (white)
Right (red)
(Yellow)
• Push plugs in all the way to make
good connections (loose connections can cause noise or malfunctions).
•To prevent interference, keep
audio and video cables away from
power cords and speaker cables.
Component video separates the luminance (Y) and
Y
color difference signals (PR, PB), providing the best
P
B
picture quality. (Some TV manufacturers label their
component video jacks slightly differently.)
PR
Analog audio
Composite video
Left (white)
Right (red)
(Yellow)
Right!
Wrong!
S-Video cable
Composite
video cable
Audio
Optical digital
audio cable
Coaxial digital
audio cable
Analog audio
cable (RCA)
Multichannel
analog audio
cable (RCA)
S-Video separates the luminance and color signals
S
and provides better picture quality than composite
video.
Composite video is commonly used on TVs, VCRs,
V
and other video equipment. Use only dedicated
composite video cables.
Cable Jack Description
OPTICAL
This offers the best sound quality and allows you to
enjoy Dolby Digital and DTS. The audio quality is
the same as for coaxial.
COA
XIAL
This offers the best sound quality and allows you to
enjoy Dolby Digital and DTS. The audio quality is
the same as for optical.
L
R
This cable carries analog audio. It’s the most common connection format for analog audio and can be
found on virtually all AV components.
This cable carries multichannel analog audio and is
typically used to connect DVD players with a 7.1channel analog audio output. Several standard analog audio cables can be used instead of a multichannel cable.
Note:
The AV receiver does not support SCART connections.
22
Connecting Your Components
—Continued
Connecting Audio and Video Signals to the AV Receiver
By connecting both the audio and video outputs of your DVD player and other AV components to the AV receiver, you
can switch the audio and video signals simultaneously simply by changing the input source on the AV receiver.
: Signal Flow
Video
Video
DVD player, etc.
Audio
Speakers (see page 19
for hookup details)
Audio
TV, projector,
etc.
Which Connections Should I Use?
The AV receiver supports several connection formats for compatibility with a wide range of AV equipment. The format
you choose will depend on the formats supported by your other components. Use the following sections as a guide.
For video components, such as a DVD player, you must make an audio connection and a video connection.
Video Connection Formats
Video equipment can be connected to the AV receiver by
using any one of the following video connection formats:
composite video, S-Video, or component video, the
latter offering the best picture quality.
A video signal connected to a V or S IN jack will be converted—composite video to S-Video or S-Video to composite video—but only for the MONITOR OUT jacks,
not the VIDEO 1 OUT V and S jacks.
Note:
The AV receiver can be set to upconvert composite
video and S-Video input signals and output them from
the COMPONENT VIDEO OUT (see page 36).
For optimum video performance, THX recommends
that video signals pass through without upconversion
(i.e., Composite video input to Composite video output; S-Video input to S-Video output; Component
video input to Component video output).
Audio Connection Formats
When choosing a connection format, bear in mind that
the AV receiver doesn’t convert between formats.
For example, audio signals connected to an OPTICAL or
COAXIAL digital input are not output by the analog
TAPE OUT, so if you want to record from, for example,
your CD player, in addition to connecting it to a digital
input, you must also connect it to the analog CD IN.
Audio Signal Flow Chart
CD player,
etc.
Output
IN
AV Receiver
Optical
Optical
Coaxial
Coaxial
Analog
Analog
Multichannel
Multichannel
Video Signal Flow Chart
DVD player,
etc.
S-Video
S-Video
S-Video
S-Video
IN
Composite
Composite
Composite
Composite
Output
AV Receiver
MONITOR OUT
Input
TV, projec-
tor, etc.
page 36
Component
Component
Component
Component
OUT
Input
Cassette
recorder, etc.
Analog
23
Connecting Your Components
C
cab
—Continued
Connecting a TV or Projector
Step 1: Video Connection
Choose a video connection that matches your TV ( , , or ), and then make the connection.
Step 2: Audio Connection
Choose an audio connection that matches your TV ( , , or ), and then make the connection.
A B
a b c
•With connection , you can listen to and record audio from your TV and listen via speaker set B.
•To enjoy Dolby Digital and DTS, use connection or . (For recording, use and , or and .)
a
b
a c
Connection AV receiver Signal flow TV Picture quality
A
B
C
a
b
c
b
c
A
COMPONENT VIDEO OUT
MONITOR OUT S
MONITOR OUT V
VIDEO 2 IN L/R
DIGITAL IN COAXIAL
DIGITAL IN OPTICAL 2
IN 3
L
R
COMPONENT
IN 2 IN 1
IN IN
CD TAPE
DIGITAL IN
COA
XIAL
OPTICAL
1
2
3
REMOTE
CONTROL
VIDEO
OUT
⇒
⇒
⇒
⇐
⇐
⇐
OUT
Y
P
B
V
PR
S
L
L
R
R
Component video input
S-Video input Better
Composite video input
Analog audio L/R output
Digital coaxial output
Digital optical output
ANTENNA
FMAM75
FRONT
MONITOR
DVD
OUT
SURROUND
VIDEO 2 VIDEO 1
IN IN IN
OUT
IN IN
OUT
VIDEO 2 VIDEO 1 DVD
SURROUND BACK
SPEAKERS
L
R
CENTER
SUB
WOOFER
SURR BACK
Best
Standard
C
C
B
B
a
OUT
Connect one or the other
Connection must be assigned (see page 35)
b
If your TV has no audio outputs, connect an audio output from your VCR or cable or satellite
Hint!
receiver to the AV receiver and use its tuner to listen to TV programs through the AV receiver (see
pages 27 and 29).
24
OPTICAL
OUT
YCOAXIAL
PB
R S VIDEO
COMPONENT VIDEO IN
P
LR
AUDIO
OUT
IN
TV, projector,
etc.
VIDEO
IN
Connecting Your Components
a
—Continued
Connecting a DVD player
Step 1: Video Connection
Choose a video connection that matches your DVD player ( , , or
A B C
You must connect the AV receiver to your TV via the same type of connection.
Step 2: Audio Connection
Choose an audio connection that matches your DVD player ( , , or ), and then make the connection.
), and then make the connection.
b c
•With connection , you can listen to and record audio from a DVD and listen via speaker set B.
•To enjoy Dolby Digital and DTS, use connection or . (For recording, use and , or and .)
a
b c a b a c
• If your DVD player has main left and right outputs and multichannel left and right outputs, be sure to use the
main left and right outputs for connection .
Connection AV receiver Signal flow DVD player Picture quality
A
B
C
a
b
c
COMPONENT VIDEO IN 1
DVD IN S
DVD IN V
DVD IN FRONT
DIGITAL IN COAXIAL
DIGITAL IN OPTICAL 1
b
c
A
COA
XIAL
OPTICAL
DIGITAL IN
1
2
3
REMOTE
CONTROL
a
IN 3
L
R
COMPONENT
IN 2 IN 1
IN IN
CD TAPE
OUT
VIDEO
⇐
⇐
⇐
⇐
⇐
⇐
OUT
Y
P
B
PR
L
R
Component video output
S-Video output Better
Composite video output
Analog audio L/R output
Digital coaxial output
Digital optical output
SURROUND BACK
MONITOR
OUT
SURROUND
L
R
CENTER
SUB
WOOFER
SPEAKERS
SURR BACK
ANTENNA
FMAM75
VIDEO 2 VIDEO 1
V
S
IN IN IN
IN IN
L
R
VIDEO 2 VIDEO 1 DVD
DVD
OUT
FRONT
OUT
a
C
C
B
B
Best
Standard
OUT
Connect one or the other
Connection must be assigned (see page 35)
c
OPTICAL
OUT
LR
YCOAXIAL
PB
R S VIDEO
COMPONENT VIDEO OUT
P
AUDIO
OUT
OUT
VIDEO
OUT
DVD player
To connect a DVD player or DVD-Audio/SACD-capable player with a
multichannel analog audio output, see page 26.
25
Connecting Your Components
—Continued
Hooking Up the Multichannel DVD Input
If your DVD player supports multichannel audio formats such as DVD-Audio or SACD, and it has a multichannel
analog audio output, you can connect it to the AV receiver’s multichannel DVD input.
Use a multichannel analog audio cable, or several normal audio cables, to connect the AV receiver’s DVD IN FRONT
L/R, CENTER, SURROUND L/R, SURR BACK L/R, and SUBWOOFER jacks to the 7.1-channel analog audio output
on your DVD player. If your DVD player has a 5.1-channel analog audio output, don’t connect anything to the AV
receiver’s SURR BACK L/R jacks.
SURROUND BACK
MONITOR
OUT
SURROUND
L
R
CENTER
SUB
WOOFER
SPEAKERS
SURR BACK
FRONT
L
R
7.1 ch
5.1 ch
SURROUND
DVD
CENTER
SUB
WOOFER
SURR BACK
L
R
DIGITAL IN
COA
XIAL
OPTICAL
1
2
3
REMOTE
CONTROL
IN 3
L
R
COMPONENT
IN 2 IN 1
IN IN
CD TAPE
VIDEO
OUT
ANTENNA
OUT
Y
B
P
PR
L
R
VIDEO 2 VIDEO 1
V
S
IN IN IN
IN IN
L
R
VIDEO 2 VIDEO 1 DVD
FMAM75
DVD
OUT
FRONT
OUT
FRONT
R
LLR
SURROUND
CENTER SUB
WOOFER
DVD player
LR
SURR
BACK
26
Connecting Your Components
Hint!
B
b
—Continued
Connecting a VCR or DVD Recorder for Playback
With this hookup, you can use your VCR’s tuner to listen to your favorite TV programs via the AV
receiver, useful if your TV has no audio outputs.
Step 1: Video Connection
Choose a video connection that matches your VCR or DVD recorder ( , , or
A
You must connect the AV receiver to your TV via the same type of connection.
Step 2: Audio Connection
Choose an audio connection that matches your VCR or DVD recorder ( , , or ), and then make the connection.
a
), and then make the connection.
C
c
•With connection , you can listen to the VCR or DVD recorder even via speaker set B.
•To enjoy Dolby Digital and DTS, use connection or . (To listen via speaker set B, use and , or and
.)
c
a
b c a b a
Connection AV receiver Signal flow VCR or DVD recorder Picture quality
A
B
C
a
b
c
COMPONENT VIDEO IN 2
VIDEO 1 IN S
VIDEO 1 IN V
VIDEO 1 IN L/R
DIGITAL IN COAXIAL
DIGITAL IN OPTICAL 1
b
c
A
DIGITAL IN
COA
XIAL
OPTICAL
1
2
3
REMOTE
CONTROL
IN 3
COMPONENT
L
R
VIDEO
IN 2 IN 1
IN IN
OUT
CD TAPE
⇐
⇐
⇐
⇐
⇐
⇐
OUT
Component video output
S-Video output Better
Composite video output
Analog audio L/R output
Digital coaxial output
Digital optical output
ANTENNA
Y
P
PR
L
R
VIDEO 2 VIDEO 1
B
V
S
IN IN IN
IN IN
L
R
VIDEO 2 VIDEO 1 DVD
OUT
OUT
FMAM75
DVD
FRONT
MONITOR
OUT
SURROUND
SURROUND BACK
SPEAKERS
L
C
C
R
B
B
SURR BACK
CENTER
SUB
WOOFER
a
Best
Standard
OUT
Connect one or the other
Connection must be assigned (see page 35)
b
OPTICAL
OUT
YCOAXIAL
PB
R S VIDEO
COMPONENT VIDEO OUT
P
DVD recorder
LR
AUDIO
OUT
VCR,
OUT
VIDEO
OUT
27
Connecting Your Components
—Continued
Connecting a VCR or DVD Recorder for Recording
Step 1: Choose a video connection that matches your VCR or DVD recorder ( or ), and then make the connec-
A B
tion. The video source to be recorded must be connected to the AV receiver via the same type of connection.
XM
VIDEO
IN 2 IN 1
IN IN
OUT
CD TAPE
⇒
⇒
⇒
SIRIUS
OUT
Y
VIDEO 2 VIDEO 1
P
B
V
PR
S
IN IN IN
L
R
IN IN
L
R
VIDEO 2 VIDEO 1 DVD
S VIDEO IN
Composite video input Standard
Analog audio L/R input —
SURROUND BACK
MONITOR
B
B
OUT
SURROUND
A
L
R
CENTER
SUB
WOOFER
SPEAKERS
SURR BACK
ANTENNA
OUT
OUT
FMAM75
DVD
FRONT
VIDEO IN
S-Video input Better
Step 2: Make the audio connection
a
AUDIO
IN
.
a
IN 3
L
R
COMPONENT
DIGITAL IN
COA
XIAL
OPTICAL
1
2
3
REMOTE
CONTROL
L
R
VCR,
DVD recorder
Connection AV receiver Signal flow VCR or DVD recorder Picture quality
A
B
a
VIDEO 1 OUT S
VIDEO 1 OUT V
VIDEO 1 OUT L/R
Connecting a Camcorder, Games Console, or Other Device
Step 1: Make the video connection .
Step 2: Make the audio connection .
TUNING PRESET
TUNER C D
DIGITAL
TUNING
DIMMER MEMORY
INPUT
MODE
CLEAR
VIDEO 3 INPUT
VIDEO
A
Connection AV receiver Signal flow Camcorder or console
A
a
VIDEO 3 INPUT
VIDEO 3 INPUT L/R
A
a
MASTER VOLUME
ENTER
SETUPRETURN
VIDEO 3 INPUT
VIDEO
AUDIOLR
a
VIDEO 3 INPUT
LR
AUDIO
LR
AUDIO
OUT
VIDEO OUT
Camcorder, games console, etc.
⇐
⇐
Composite video output
Analog audio L/R output
28
Connecting Your Components
Hint!
B
—Continued
Connecting a Satellite, Cable, Set-top box, or Other Video Source
With this hookup, you can use your satellite or cable receiver to listen to your favorite TV programs
via the AV receiver, useful if your TV has no audio outputs.
Step 1: Video Connection
Choose a video connection that matches the video source ( , , or
A
You must connect the AV receiver to your TV via the same type of connection.
Step 2: Audio Connection
Choose an audio connection that matches the video source ( , , or ), and then make the connection.
a b c
), and then make the connection.
C
•With connection , you can listen to and record audio from the video source and listen via speaker set B.
•To enjoy Dolby Digital and DTS, use connection or . (For recording, use and , or and .)
a
b c a b a c
Connection AV receiver Signal flow Video source Picture quality
A
B
C
a
b
c
COMPONENT VIDEO IN 3
VIDEO 2 IN S
VIDEO 2 IN V
VIDEO 2 IN L/R
DIGITAL IN COAXIAL
DIGITAL IN OPTICAL 2
b
COA
XIAL
OPTICAL
c
A
DIGITAL IN
1
2
3
REMOTE
CONTROL
IN 3
COMPONENT
L
R
VIDEO
IN 2 IN 1
IN IN
OUT
CD TAPE
⇐
⇐
⇐
⇐
⇐
⇐
OUT
Component video output Best
S-Video output Better
Composite video output Standard
Analog audio L/R output
Digital coaxial output
Digital optical output
C
BCB
MONITOR
OUT
SURROUND
SURROUND BACK
L
R
CENTER
SUB
WOOFER
a
ANTENNA
FMAM75
Y
P
PR
L
R
VIDEO 2 VIDEO 1
B
V
S
IN IN IN
IN IN
L
R
VIDEO 2 VIDEO 1 DVD
DVD
OUT
FRONT
OUT
SPEAKERS
SURR BACK
OUT
Connect one or the other
Connection must be assigned (see page 35)
b
OPTICAL
OUT
YCOAXIAL
PB
R S VIDEO
COMPONENT VIDEO OUT
P
Satellite, cable, set-top box, etc.
LR
AUDIO
OUT
OUT
VIDEO
OUT
29
Connecting Your Components
c
—Continued
Connecting a CD Player or Turntable
■
CD Player or Turntable (MM) with Built-in Phono Preamp
Step 1:
Choose a connection that matches your CD player ( , , or ). Use connection for a turntable with a built-in
phono preamp.
DIGITAL IN
b
Connect one or
the other
Connection
must be
assigned (see
page 35)
b
c
COAXIAL
OUT
COAXIAL
OPTICAL
3
OPTICAL
OUT
IN
CD
LR
AUDIO
OUT
a b c a
COMPONENT
IN 3
IN 2 IN 1
IN IN
L
R
CD TAPE
VIDEO
OUT
P
PR
OUT
DIGITAL IN
COA
XIAL
OPTICAL
1
2
3
REMOTE
L
CONTROL
R
a
CD player
Y
VIDEO 2 VIDEO 1
B
V
S
IN IN IN
IN IN
LRL
R
VIDEO 2 VIDEO 1 DVD
ANTENNA
OUT
OUT
SURROUND BACK
FMAM75
SPEAKERS
IN
L
L
MONITOR
DVD
OUT
R
R
SURROUND
CD
SURR BACK
CENTER
a
SUB
WOOFER
FRONT
AUDIO
OUTPUT
L
R
Turntable (MM) with
built-in phono preamp
•With connection , you can listen to and record audio from your CD player or turntable and listen via speaker
a
set B.
•To connect the CD player digitally, use connection or . (For recording, use and , or and .)
Connection AV receiver Signal flow CD or turntable
a
b
c
■
Turntable (MM) with no Phono Preamp Built-in
CD IN L/R
DIGITAL IN COAXIAL
DIGITAL IN OPTICAL 3
A phono preamp is necessary to connect a turntable that
doesn’t have a phono preamp built-in.
SURROUND BACK
ANTENNA
COMPONENT
IN 3
IN 2 IN 1
IN IN
L
R
CD TAPE
VIDEO
OUT
Y
P
B
PR
OUT
LRL
AUDIO
OUTPUT
COA
XIAL
OPTICAL
DIGITAL IN
1
2
3
REMOTE
CONTROL
IN
L
R
FMAM75
VIDEO 2 VIDEO 1
V
S
IN IN IN
OUT
IN IN
OUT
R
VIDEO 2 VIDEO 1 DVD
L
R
CD
SPEAKERS
L
MONITOR
DVD
OUT
R
SURROUND
SURR BACK
CENTER
FRONT
SUB
WOOFER
Phono preamp
b
⇐
⇐
⇐
■
Turntable with an MC (Moving Coil) Cartridge
a b a c
Analog audio L/R output
Digital coaxial output
Digital optical output
An MC head amp and phono preamp are necessary to
connect a turntable with an MC (Moving Coil) cartridge.
SURROUND BACK
ANTENNA
COMPONENT
IN 3
IN 2 IN 1
IN IN
L
R
CD TAPE
VIDEO
OUT
OUT
Y
P
B
PR
LRL
AUDIO
OUTPUT
L
R
DIGITAL IN
COA
XIAL
OPTICAL
1
2
3
REMOTE
CONTROL
IN
L
R
CD
FMAM75
VIDEO 2 VIDEO 1
V
S
IN IN IN
OUT
IN IN
OUT
R
VIDEO 2 VIDEO 1 DVD
Phono
preamp
SPEAKERS
L
MONITOR
DVD
OUT
R
FRONT
SURROUND
SURR BACK
CENTER
SUB
WOOFER
AUDIO
INPUT
L
R
AUDIO
OUTPUT
L
R
AUDIO
OUTPUT
L
R
30
AUDIO
INPUT
MC head amp or
MC transformer
L
R
AUDIO
OUTPUT
L
R
AUDIO
INPUT
L
R
Connecting Your Components
D
—Continued
Connecting an HDD-compatible Component
As of this printing, the Onkyo Remote Interactive Dock is the only HDD-compatible component available.
■
■
For HDD-compatible components that
support video
Connect your HDD-compatible component’s analog
audio output jacks and S-Video output jack to the AV
receiver’s VIDEO 2 IN L/R jacks and VIDEO 2 IN S
jack.
AUDIO
OUT
LR
ANTENNA
FMAM75
IN IN IN
OUT
IN IN
OUT
DIGITAL IN
COA
XIAL
OPTICAL
1
2
3
REMOTE
CONTROL
IN 3
L
R
COMPONENT
IN 2 IN 1
IN IN
CD TAPE
VIDEO
OUT
S VIDEO
OUT
OUT
Y
P
PR
L
R
VIDEO 2 VIDEO 1
B
V
S
L
R
VIDEO 2 VIDEO 1 D
FRONT
MONITOR
DVD
OUT
SURROUN
For HDD-compatible components that don’t
support video
Connect your HDD-compatible component’s analog
audio output jacks to the AV receiver’s TAPE IN L/R
jacks.
AUDIO
OUT
LR
IN 3
L
R
COMPONENT
IN 2 IN 1
CD TAPE
DIGITAL IN
COA
XIAL
OPTICAL
1
2
3
REMOTE
CONTROL
VIDEO
IN IN
OUT
OUT
Y
P
B
PR
L
R
Notes:
• Connect the Remote Interactive Dock with an cable (see page 33).
• Set the Remote Interactive Dock’s RI MODE switch to HDD.
• Set the AV receiver’s Input Display to HDD (see page 35).
• Refer to the Remote Interactive Dock’s instruction manual.
31
Connecting Your Components
—Continued
Connecting a Cassette, CDR, MiniDisc, or DAT Recorder
Step 1:
Choose a connection that matches the recorder ( , , or ), and then make the connection.
DIGITAL IN
b
COAXIAL
c
OPTICAL
3
Connect one or the
other
These connections
must be assigned
(see page 35)
COAXIAL
OUT
a b c
DIGITAL IN
IN 3
COA
XIAL
OPTICAL
1
2
3
REMOTE
CONTROL
COMPONENT
IN 2 IN 1
IN IN
L
R
CD TAPE
ANTENNA
VIDEO
OUT
Y
VIDEO 2 VIDEO 1
B
P
V
PR
S
OUT
L
L
R
R
VIDEO 2 VIDEO 1 DVD
FMAM75
IN IN IN
OUT
IN IN
OUT
DVD
FRONT
L
OUT
MONITOR
OUT
SURROUND
TAPE
SURROUND BACK
SPEAKERS
L
R
IN
CENTER
L
SUB
WOOFER
R
L
SURR BACK
a
OPTICAL
OUT
R
IN OUT
REC PLAY
R
Cassette recorder, CDR, etc.
•With connection , you can listen via speaker set B.
•To connect the recorder digitally, use connections and , or and .
a
a b a c
Connection AV receiver Signal flow Cassette/CDR/MD/DAT recorder
a
b
c
TAPE IN L/R
TAPE OUT L/R
DIGITAL IN COAXIAL
DIGITAL IN OPTICAL 3
⇐
⇒
⇐
⇐
Analog audio L/R output
Analog audio L/R input
Digital coaxial output
Digital optical output
Connecting the Power Cord of Another Component
The AV receiver has an AC outlet on its rear panel for
SURROUND
FRONT
connecting the power cord of another AV component.
The other component’s power switch can then be left in
the ON position so that it turns on or off when the AV
receiver is set to On or Standby.
Caution:
• Make sure that the capacity of the component that
you connect to the AC OUTLET does not exceed
the stated capacity (e.g., 100 W).
SPEAKERS
PRE OUT
SUB
WOOFER
SPEAKERS A
L
R
FRONT
SPEAKERS B
CENTER
SPEAKER
L
R
AV RECEIVER
AC OUTLET
AC 120V
SWITCHED
120W 1A MAX.
60Hz
Notes:
• Onkyo components connected via should be
connected directly to a wall outlet, not the AV
receiver’s AC OUTLET.
• The socket type and capacity depends on the
country in which you purchased the AV receiver.
32
AC OUTLET
AC 230-240V
SWITCHED
100W MAX.
50Hz
AC OUTLET
AC 120V
SWITCHED
120W 1A MAX.
60Hz
European model American model
Connecting Your Components
—Continued
Connecting Onkyo Components
Step 1: Make sure that each Onkyo component is connected to the AV receiver with an analog audio cable (con-
nection in the hookup examples) (see pages 24 to 32).
Step 2: Make the connection.
Step 3: If you’re using an MD, CDR, or HDD component, change the Input Display (see page 35).
With (Remote Interactive), you can use the following special functions:
■
Auto Power On/Standby
When you start playback on a component connected via , if the AV receiver is on Standby, it will automatically
turn on and select that component as the input source. Similarly, when the AV receiver is set to Standby, all components connected via will also go on Standby. This function will not work on components connected to an AC
OUTLET on the AV receiver.
■
Direct Change
When playback is started on a component connected via , the AV receiver automatically selects that component
as the input source. If your DVD player is connected to the AV receiver’s multichannel DVD input, you’ll need to
press the [MULTI CH] button to hear all channels (see page 38), as the Direct Change function only selects the
FRONT DVD IN jacks.
a
■
Remote Control
You can use the AV receiver’s remote controller to control your other -capable Onkyo components, pointing the
remote controller at the AV receiver’s remote control sensor instead of the component. You must enter the appropriate remote control code first (page 58).
Notes:
• Use only cables for connections.
cables are supplied with Onkyo players (DVD,
CD, etc.).
• Some components have two jacks. You can
connect either one to the AV receiver. The other
jack is for connecting additional -capable
components.
REMOTE
CONTROL
DIGITAL IN
COA
XIAL
OPTICAL
1
2
3
REMOTE
CONTROL
COMPONENT
VIDEO
OUT
IN 3
IN 2 IN 1
P
PR
IN IN
OUT
LRLRL
CD TAPE
Y
B
ANTENNA
FMAM75
VIDEO 2 VIDEO 1
DVD
V
S
IN IN IN
OUT
IN IN
FRONT
OUT
R
VIDEO 2 VIDEO 1 DVD
SURROUND BACK
SPEAKERS
L
MONITOR
OUT
R
SURROUND
SURR BACK
CENTER
SUB
WOOFER
IN
L
R
CD
FRONT
L
R
DVD
• Connect only Onkyo components to jacks.
Connecting other manufacturer’s components
may cause a malfunction.
• Some components may not support all functions. Refer to the manuals supplied with your
other Onkyo components.
e.g., CD player
e.g., DVD player
ANALOG
AUDIO OUT
ANALOG
AUDIO OUT
LR
LR
Connecting the Power Cord
• Connect the AV receiver’s and subwoofer’s power cord to a suitable wall outlet.
Notes:
•
Before connecting the power cord, connect all of your speakers and AV components.
•Turning on the AV receiver and subwoofer may cause a momentary power surge that might interfere with other
electrical equipment on the same circuit. If this is a problem, plug the AV receiver into a different branch circuit.
33
Turning On the AV Receiver
STANDBY/ON
STANDBY indicator
STANDBY/ON
STANDBY
DVDMULTI CH C
PHONES
SPEAKERS
AB
TONE
3VIDEO 2VIDEO 1
VIDEO
VCR
LISTENING MODE
Turning On and Standby
1
AV receiver
STANDBY/ON
or
Remote
controller
RECEIVER
ON/STANDBY
Press the [STANDBY/ON] button.
Alternatively, press the remote controller’s [RECEIVER] button, followed
by the [ON/STANDBY] button.
The AV receiver comes on, the display lights up, and the STANDBY indicator goes off.
To turn the AV receiver off, press the [STANDBY/ON] button, or press the remote
controller’s [ON/STANDBY] button. The AV receiver will enter Standby mode. To
prevent any loud surprises when you next turn on the AV receiver, always turn down
the volume before you turn it off.
TUNERTAPE
DIGITAL
INPUT
DISPLAYTHX DIMMER MEMORY
ON/STANDBY
ON/STANDBY
RECEIVER
TUNING PRESET
D
TUNING
MODE
CLEAR
MASTER VOLUME
ENTER
SETUPRETURN
VIDEO 3 INPUT
VIDEO
AUDIOLR
123
V1 V2 V3
456
789
+
10
D TUN
--/---
INPUT
GUIDE
TOP MENU
SP A / B
INPUT SELECTOR
MULTI CH
10 11 12
0
ENT
DIMMER
TV
VOL
REMOTE MODE
RECEIVER
TAPE
M
DVD
C DTAPE TUNER
CABLE
CLR
SLEEP
CH
DISC
ALBUM
PREVIOUS
MUTING
MENU
DVD
D/CDR
C D
HDD
TV
VCR
SAT
VOL
To turn on the subwoofer, press its [POWER] switch to the ON position
(not North
American models).
Smooth Operation in a Few Easy Steps
To ensure smooth operation, here’s a few easy steps to help you configure the AV receiver before you use it for the
very first time. These settings only need to be made once.
■ Have you connected a component to a digital audio input?
If you have, see “Assigning Digital Inputs to Input Sources” on
page 35.
■ Have you connected an Onkyo MD recorder, CD recorder,
or next generation HDD-compatible component?
If you have, see “Changing the Input Display” on page 35.
Testing the speakers
To test that all of the speakers are working properly, press the remote controller’s [TEST TONE] button. The
test tone will be output by each speaker in turn and the name of each speaker will appear on the display. To turn off
the test tone, press the [TEST TONE] button again.
• If the test tone is not produced by a speaker, or it’s produced by a speaker other than that shown on the display,
you may have wired the speakers incorrectly and you should check your connections (see page 19).
•Testing cannot be performed while speaker set B is on or a pair of headphones is connected.
COAX
OPT1
OUT IN
TAPE
CD recorder, MD recorder,
RI Dock, etc.
34
First Time Setup
Assigning Digital Inputs to Input
Sources
1 2, 3
MASTER VOLUME
STANDBY/ON
STANDBY
DVDMULTI CH C
PHONES
SPEAKERS
VIDEO
3VIDEO 2VIDEO 1
VCR
TONE
LISTENING MODE
DISPLAYTHX DIMMER MEMORY
To enjoy Dolby Digital and DTS, you must connect your
DVD player to the AV receiver digitally (coaxial or optical).
Here are the default assignments.
Input selector
DVD COA X
VIDEO 1 OPT 1
VIDEO 2 OPT 2
VIDEO 3 - - - -
TAPE - - - -
CD OPT 3
Default assignment
With this function, you can change the digital inputs
assign. If, for example, you connect your DVD player to
the DIGITAL IN OPTICAL 1 input (OPT1), you’ll need
to assign it to the DVD input source, as follows.
1
DVD
VIDEO 3
VIDEO 1
VCR
TAPE
Press the input selector button
for the input source that you want
VIDEO 2
to assign.
(Digital inputs cannot be assigned to
the TUNER input source.)
C D
2
DIGITAL
INPUT
Press the [DIGITAL INPUT]
button.
The current assignment appears.
TUNING PRESET
ENTER
TUNERTAPE
DIGITAL
INPUT
SETUPRETURN
D
VIDEO 3 INPUT
VIDEO
TUNING
MODEAB
CLEAR
AUDIOLR
Changing the Input Display
If you connect an -capable Onkyo MiniDisc
recorder, CD recorder or next generation HDD-compatible component to the TAPE IN/OUT or VIDEO 2 IN
jacks, for to work properly, you must change this
setting.
This setting can only be changed on the AV receiver.
1, 21, 2
MASTER VOLUME
TUNING PRESET
ENTER
TUNERTAPE
DIGITAL
INPUT
SETUPRETURN
D
VIDEO 3 INPUT
VIDEO
TUNING
MODE
CLEAR
AUDIOLR
1
2
STANDBY/ON
PHONES
TAPE
or
VIDEO 2
TAPE
or
VIDEO 2
STANDBY
DVDMULTI CH C
VCR
SPEAKERS
TONE
AB
Press the [TAPE] or [VIDEO 2]
input selector button so that
“TAPE” or “VIDEO2” appears on
the display.
Press and hold down the [TAPE]
or [VIDEO 2] input selector button (about 3 seconds) to change
the setting.
Repeat this step to select MD, CDR, or
HDD.
For the TAPE input selector, the setting
changes in this order:
For the VIDEO 2 input selector, the setting changes in this order:
VIDEO
3VIDEO 2VIDEO 1
DISPLAYTHX DIMMER MEMORY
LISTENING MODE
TAPE
→
MD → CDR → HDD
→
VIDEO 2 ↔ HDD
3
DIGITAL
INPUT
Press the [DIGITAL INPUT] button repeatedly to select COAX,
OPT1, OPT2, OPT3, or “– – – –”
(analog).
Note:
Make sure that components connected digitally are configured to output digital audio. Refer to the relevant manuals.
Note:
HDD can be selected for the TAPE input selector or
VIDEO 2 input selector, but not both at the same time.
35
First Time Setup
—Continued
ENTER
RETURN
ON/STANDBY
123
V1V2V
456
789
+
10
D TUN
--/---
INPUT
GUIDE
TOP MENU
SP A / B
PLAYLIST/CAT PLAYLIST/CAT
STEREO
AUDIO REPEAT
TEST TONE
DISPLAY
INPUT SELECTOR
MULTI CH
10 11 12
0
ENT
DIMMER
TV
VOL
ENTER
LISTENING MODE
SURROUND
RANDOM
SUBTITLE
CH SEL
PLAY MODE
-
650M
RC
REMOTE MODE
RECEIVER
TAPE
M
3
DVD
C DTAPE TUNER
CABLE
CLR
SLEEP
CH
DISC
ALBUM
PREVIOUS
MUTING
SETUPRETURN
-
LEVEL
L NIGHT
DVD
D/CDR
C D
HDD
TV
VCR
SAT
VOL
MENU
LEVEL
Re-EQ
HDDDVDVCR
+
RECEIVER
SETUP
2
3
Use the Up and Down [ ]/[ ]
buttons to select “1. Compo-
nent,” and then press [ENTER].
Use the Up and Down [ ]/[ ]
buttons to select an input selector, and use the Left and Right
[ ]/[ ] buttons to select:
IN1:
Select if the video compo-
nent is connected to COMPONENT VIDEO IN 1.
IN2:
Select if the video compo-
nent is connected to COMPONENT VIDEO IN 2.
IN3:
Select if the video compo-
nent is connected to COMPONENT VIDEO IN 3.
VIDEO:
Select to output composite
video and S-Video sources
from the COMPONENT
VIDEO OUT.
Component Video Setup
If you connect a video component to COMPONENT
VIDEO IN 1, 2, or 3, you must assign that input to an
input selector. For example, if you connect your DVD
player to COMPONENT VIDEO IN 2, you must assign
COMPONENT VIDEO IN 2 to the DVD input selector.
To upconvert and output composite video and S-Video
sources from the COMPONENT VIDEO OUT, select
the VIDEO setting.
Here are the default assignments.
Input selector Default assignment
DVD IN1
VIDEO 1 VIDEO
VIDEO 2 VIDEO
VIDEO 3 VIDEO
1
RECEIVER
Press the [RECEIVER] button,
followed by the [SETUP] button.
4
Press the [SETUP] button.
Setup closes.
SETUP
Note:
• This procedure can also be performed on the AV
receiver by using the [SETUP], [ENTER], and arrow
buttons.
SETUP
36
Playing Your AV Components
Basic AV Receiver Operation
STANDBY/ON
PHONES
1
AV receiver
DVD
VIDEO 3
C D
MULTI CH
STANDBY
VIDEO 1
VIDEO 2
VCR
TAPE TUNER
1
DVDMULTI CH C D
SPEAKERS
AB
VIDEO
3VIDEO 2VIDEO 1
VCR
TONE
LISTENING MODE
2
Remote
controller
RECEIVER
123
V1 V2 V3
789
6
DVD
C DTA PE TUNER
TUNERTAPE
DIGITAL
DISPLAYTHX DIMMER MEMORY
INPUT
DISPLAY
4
TUNING PRESET
TUNING
MODE
CLEAR
MASTER VOLUME
ENTER
SETUPRETURN
VIDEO 3 INPUT
VIDEO
AUDIOLR
1
ON/STANDBY
D TUN
TOP MENU
2
PLAYLIST/CAT PLAYLIST/CAT
REMOTE MODE
RECEIVER
TAPE
INPUT SELECTOR
123
V1V2V
456
MULTI CH
DVD
789
10 11 12
+
0
10
ENT
--/---
DIMMER
SLEEP
TV
VOL
ALBUM
INPUT
GUIDE
SP A / B
ENTER
DVD
D/CDR
M
C D
HDD
3
TV
VCR
C DTAPE TUNER
CABLE
SAT
CLR
CH
DISC
VOL
PREVIOUS
MENU
MUTING
1
Subwoofer’s
rear panel
4
Use the AV receiver’s input selector buttons to select the input source.
To select the input source with the remote controller, press the
[RECEIVER] REMOTE MODE button, and then use the INPUT SELECTOR
buttons.
On the remote controller, the [V1], [V2], and [V3] buttons select the VIDEO 1,
VIDEO 2, and VIDEO 3 input sources respectively.
2
AV receiver
3
4
AV receiver
MASTER VOLUME
SPEAKERS
AB
Remote
controller
Remote
controller
VOL
To turn the speakers on or off, use the AV receiver’s SPEAKERS [A] and
[B] buttons, or use the remote controller’s [SP A/B] button.
Pressing the remote controller’s [SP A/B] button cycles through the following settings:
Speaker Set A
Speaker Set A&B → Speaker Set B → Off.
→
Note that while speaker set B is on,
speaker set A is reduced to 5.1-channel
Indicators
playback.
See page 8 for more information about speaker sets A and B.
Start playback on the source component.
To watch a DVD or other video source, on your TV, select the video input that’s connected to the AV receiver’s MONITOR OUT jack.
To adjust the volume, use the MASTER VOLUME control, or the remote
controller’s [VOL] button.
The volume can be set to –∞ dB, –83…0…+16 dB. Since the AV receiver is designed
for home theater enjoyment, it has a wide volume range for precise adjustment.
To set the level of the subwoofer, use the OUTPUT LEVEL control.
Because our ears are less sensitive to very low bass sounds, there’s a temptation to set
the level of the subwoofer too high. As a rule of thumb, set the subwoofer level to what
you think is the optimal level, and then back it off slightly.
5
Select a suitable listening mode and enjoy!
See “Using the Listening Modes” on page 45.
37
Playing Your AV Components
MULTI CH
DISPLAY
ON/STANDBY
123
V1V2V
456
789
+
10
D TUN
--/---
INPUT
STEREO
AUDIO REPEAT
TEST TONE
DISPLAY
INPUT SELECTOR
MULTI CH
10 11 12
0
ENT
DIMMER
TV
VOL
LISTENING MODE
SURROUND
RANDOM
SUBTITLE
CH SEL
PLAY MODE
VCR
-
650M
RC
REMOTE MODE
RECEIVER
TAPE
M
3
DVD
C DTAPE TUNER
CABLE
CLR
SLEEP
CH
DISC
ALBUM
-
LEVEL
L NIGHT
DVD
D/CDR
C D
HDD
TV
VCR
SAT
VOL
LEVEL
Re-EQ
HDDDVD
RECEIVER
+
—Continued
You can display various information about the current
input source as follows.
The following information can typically be displayed:
Displaying Source Information
RECEIVER
DISPLAY
Input source &
volume*
Signal format*
or sampling
frequency
Input source &
listening mode
Press the [RECEIVER] REMOTE
MODE button, and then press the
[DISPLAY] button repeatedly to
cycle through the available information.
1
2
Using the Multichannel DVD Input
The multichannel DVD input is for connecting a component with a 7.1-channel analog audio output, such as a
DVD-Audio or SACD-capable DVD player, or an
MPEG decoder. See page 26 for hookup information.
RECEIVER
MULTI CH
Note:
• While the multichannel DVD input is selected, the
Speaker Configuration settings on page 55 are
ignored, and signals from the multichannel input are
fed to the speakers as they are.
Press the [RECEIVER] REMOTE
MODE button, followed by the
[MULTI CH] button.
The MULTI CH indicator appears on
the display.
MULTI CH indicator
Audio from the multichannel DVD
input will now be used for the DVD
input source.
*1 When AM or FM radio is used, the band, preset num-
ber, and frequency are displayed.
*2 If the input signal is analog, or AM or FM radio is
selected, no format information is displayed. If the
input signal is PCM, the sampling frequency is displayed. If the input signal is digital but not PCM, the
signal format is displayed. Information is displayed
for about 3 seconds, then the previous display reappears.
Note:
• The listening mode is displayed only when speaker set
A is on.
Interpreting Surround Channel Information
ABC
A: The number of front channels (front left, front right,
and center).
B: The number of surround channels (surround left and
surround right). If there’s surround back channel
information, this number will be 3.
C: LFE channel for subwoofer (1 means yes).
38
Listening to the Radio
Listening to AM/FM stations
TUNER
TUNING
MASTER VOLUME
STANDBY/ON
STANDBY
DVDMULTI CH C
VIDEO
3VIDEO 2VIDEO 1
PHONES
VCR
SPEAKERS
TONE
LISTENING MODE
DISPLAYTHX DIMMER MEMORY
With the built-in tuner, you can enjoy AM and FM radio
stations.
1
TUNER
Use the [TUNER] input selector
button to select AM or FM.
In this example, FM has been selected.
TUNING PRESET
TUNERTAPE
DIGITAL
INPUT
SETUPRETURN
D
TUNING
MODEAB
CLEAR
TUNING MODE
ENTER
VIDEO 3 INPUT
VIDEO
AUDIOLR
■
Manual Tuning Mode
1
TUNING
MODE
Press the [TUNING MODE] button
so that the AUTO indicator disappears from the display.
2
TUNING PRESET
Press and hold the TUNING Up or
Down [ ]/[ ] button.
The frequency stops changing when
you release the button.
Press the buttons repeatedly to change
the frequency one step at a time.
The American model changes FM frequency in 0.2 MHz
steps, 10 kHz steps for AM. For other models it’s
0.05 MHz steps for FM and 9 kHz (or 10 kHz) steps for
AM.
When tuned into a station, the TUNED indicator
appears. When tuned into a stereo FM station, the FM
STEREO indicator also appears.
Band Frequency
(Actual display depends on country.)
Tuning into AM/FM Radio Stations
■
Auto Tuning Mode
1
2
TUNING PRESET
TUNING
MODE
Press the [TUNING MODE] button
so that the AUTO indicator
appears on the display.
Press the TUNING Up or Down
[ ]/[ ] button.
Searching stops when a station is
found.
AUTOTUNED
FM STEREO
Tuning into Weak FM Stereo Stations
If the signal from a stereo FM station is weak, it may be
impossible to get good reception. In this case, switch to
Manual Tuning mode and listen to the station in mono.
Note:
•You can also use the remote controller’s Up and Down
[ ]/[ ] buttons to tune the radio.
39
Listening to the Radio
R
■
Tuning into Stations by Frequency
—Continued
You can tune into AM and FM stations directly by entering the appropriate frequency.
2
MEMORY
Press the [MEMORY] button.
The MEMORY indicator appears and
the preset number flashes.
1
2
Number
buttons
RECEIVER
D TUN
D TUN
ON/STANDBY
D TUN
TOP MENU
PLAYLIST/CAT PLAYLIST/CAT
REMOTE MODE
RECEIVER
TAPE
INPUT SELECTOR
123
V1V2V
456
DVD
MULTI CH
789
C DTAPE TUNER
10 11 12
+
CLR
0
10
ENT
--/---
DIMMER
SLEEP
CH
TV
DISC
VOL
ALBUM
INPUT
GUIDE
SP A / B
ENTER
DVD
D/CDR
M
C D
HDD
3
TV
VCR
CABLE
SAT
VOL
PREVIOUS
MENU
MUTING
SETUPRETURN
RECEIVER
CH +/–
Press the [RECEIVER] button,
followed by the [D TUN] button.
(Actual display depends on country.)
The [RECEIVER] button flashes.
Within 8 seconds, use the number buttons to enter the frequency of the radio station.
For example, to tune to 87.5 (FM),
press 8, 7, 5.
Note
: While the [RECEIVER] button is
flashing, the input source cannot be
changed by using the remote controller.
3
TUNING PRESET
ENTER
4
MEMORY
■
Selecting Presets
TUNING PRESET
1
ENTE
CH
DISC
ALBUM
While the MEMORY indicator is
displayed (about 8 seconds), use
the PRESET [ ]/[ ] buttons to
select a preset from 1 through 40.
Press the [MEMORY] button
again to store the station.
The station is stored and the preset
number stops flashing.
Repeat this procedure for all of your
favorite AM/FM radio stations.
To select a preset, use the PRESET [ ]/[ ] buttons, or the
remote controller’s CH [+/–] button.
Presetting Radio Stations
STANDBY/ON
STANDBY
DVDMULTI CH C
PHONES
SPEAKERS
3VIDEO 2VIDEO 1
VIDEO
VCR
TONE
LISTENING MODE
DIGITAL
DISPLAYTHX DIMMER MEMORY
INPUT
MEMORY
You can store a combination of up to 40 of your favorite
AM and FM radio stations as presets.
1
Tune into the station that you
want to store as a preset.
40
PRESET
TUNING PRESET
ENTER
TUNERTAPE
SETUPRETURN
D
TUNING
MODEAB
CLEAR
TUNING MODE
■
Deleting Presets
1
Select the preset that you want to
delete.
See the previous section.
While holding down the [MEMORY] button, press the
MODE
[TUNING MODE] button.
The preset is deleted and its number
MASTER VOLUME
2
MEMORY
TUNING
CLEAR
disappears from the display.
VIDEO 3 INPUT
VIDEO
AUDIOLR
Listening to the Radio
—Continued
Using RDS (European Models Only)
RDS only works with European models and only in areas
where RDS broadcasts are available.
When tuned into an RDS station, the RDS indicator
appears.
RDS indicator
■
What is RDS?
RDS stands for
transmitting data in FM radio signals. It was developed
by the European Broadcasting Union (EBU) and is available in most European countries. Many FM stations use
it these days. In addition to displaying text information,
RDS can also help you find radio stations by type (e.g.,
news, sport, rock, etc.).
The AV receiver supports four types of RDS information:
PS (Program Service)
When tuned to an RDS station that’s broadcasting PS
information, the station’s name will be displayed. Pressing the [DISPLAY] button will display the frequency for
3 seconds.
RT (Radio Text)
When tuned to an RDS station that’s broadcasting text
information, the text will be shown on the display (see
page 42).
PTY (Program Type)
This allows you to search for RDS radio stations by type
(see page 42).
TP (Traffic Program)
This allows you to search for RDS radio stations that
broadcast traffic information (see page 42).
Notes:
• In some cases, the text characters displayed on the AV
receiver may not be identical to those broadcast by the
radio station. Also, unexpected characters may be displayed when unsupported characters are received.
This is not a malfunction.
• If the signal from an RDS station is weak, RDS data
may be displayed intermittently or not at all.
Radio Data System
and is a method of
RDS Program Types (PTY)
Type Display Description
None NONE No program type.
News
reports
Current
affairs
Information INFO General information such as
Sport SPORT Live sports action, sports
Education EDUCATE Formal educational programs.
Drama DRAMA Radio plays and serials.
Culture CULTURE Cultural programs (including
Science and
technology
Var ied VARIED Talk programs not covered by
Pop music POP M Popular commercial music,
Rock music ROCK M Popular music with an alterna-
Middle of
the road
music
Light classics
Serious
classics
Other music OTHER M Music styles not covered by
Alarm ALARM When an RDS station is mak-
NEWS Reports on current events and
happenings.
AFFAIRS Topical reporting of current
affairs, often with a wider
range of topics than news
reports.
weather forecasts, consumer
affairs, medical help, etc.
news, and interviews.
religious affairs).
SCIENCE Programs about the natural
sciences and technology.
the above categories (e.g.,
quizzes, panel games, and
comedy).
usually from past or present
sales charts (e.g., Top 40).
tive appeal, often not appearing on sales charts.
M.O.R.M Easy listening music (as
opposed to Pop, Rock, or
Classical).
LIGHT M Classical music for general
rather than specialist appreciation.
CLASSICS Performances of major
orchestral works, symphonies, chamber music, etc.
(including the Grand Opera).
the above categories (e.g.,
Jazz, Rhythm and Blues, Folk,
Country, and Reggae).
ing an emergency broadcast,
ALARM will flash on the display.
41
Listening to the Radio
—Continued
Displaying Radio Text (RT)
MASTER VOLUME
STANDBY/ON
PURE AUDIO
STANDBY
DVDMULTI CH C
VIDEO
3VIDEO 2VIDEO 1
PHONES
VCR
SPEAKERS
TONE
LISTENING MODE
DISPLAYTHX RT/PTY/TP MEMORY
TUNING PRESET
ENTER
TUNERTAPE
DIGITAL
INPUT
SETUPRETURN
D
VIDEO 3 INPUT
VIDEO
TUNING
MODEAB
CLEAR
AUDIOLR
1
When tuned to an RDS station that’s broadcasting text
information, the text can be displayed.
1
RT/PTY/TP
Notes:
• The message “Waiting” may appear while the AV
receiver waits for the RT information.
• If the message “No Text Data” appears on the display,
no RT information is available.
Press the [RT/PTY/TP] button
once.
The RT information scrolls across the
display.
4
To start the search, press
[ENTER].
The AV receiver searches until it finds a
ENTER
station of the type you specified, at
which point it stops briefly before continuing with the search.
5
When a station you want to listen
to is found, press [ENTER].
If no stations are found, the message
ENTER
“Not Found” appears.
Listening to Traffic News (TP)
1
STANDBY/ON
STANDBY
PURE AUDIO
PHONES
DVDMULTI CH C
SPEAKERS
3VIDEO 2VIDEO 1
VIDEO
VCR
TONE
LISTENING MODE
TUNERTAPE
DIGITAL
DISPLAYTHX RT/PTY/TP MEMORY
INPUT
D
2
3
MASTER VOLUME
TUNING PRESET
ENTER
SETUPRETURN
VIDEO 3 INPUT
VIDEO
TUNING
MODEAB
CLEAR
AUDIOLR
Finding Stations by Type (PTY)
3–5
1
STANDBY/ON
PURE AUDIO
STANDBY
DVDMULTI CH C
PHONES
SPEAKERS
3VIDEO 2VIDEO 1
VIDEO
VCR
TONE
LISTENING MODE
DISPLAYTHX RT/PTY/TP MEMORY
TUNING PRESET
TUNERTAPE
D
DIGITAL
TUNING
INPUT
MODEAB
CLEAR
2
You can search for radio stations by type.
1
2
3
TUNER
RT/PTY/TP
TUNING PRESET
Use the [TUNER] input selector
button to select FM.
Press the [RT/PTY/TP] button
twice.
The current program type appears on
the display.
Use the PRESET [ ]/[ ] buttons
to select the type of program you
want.
See the table on page 41.
ENTER
You can search for stations that broadcast traffic news.
TUNER
1
MASTER VOLUME
ENTER
SETUPRETURN
VIDEO 3 INPUT
VIDEO
AUDIOLR
2
RT/PTY/TP
Use the [TUNER] input selector
button to select FM.
Press the [RT/PTY/TP] button
three times.
If the current radio station is broadcasting TP (Traffic Program), “[TP]” will
appear on the display, and traffic news
will be heard as and when it’s broadcast. If “TP” without square brackets
appears, this means that the station is
not broadcasting TP.
3
To locate a station that is broadcasting TP, press [ENTER].
The AV receiver searches until it finds a
ENTER
station that’s broadcasting TP.
If no stations are found, the message
“Not Found” appears.
42
Common Functions
This section explains functions that can be used with any
input source.
DIMMER
CH SEL
ON/STANDBY
123
V1 V2 V3
456
789
+
10
D TUN
--/---
INPUT
GUIDE
TOP MENU
SP A / B
PLAYLIST/CAT PLAYLIST/CAT
STEREO
AUDIO REPEAT
TEST TONE
DISPLAY
INPUT SELECTOR
MULTI CH
10 11 12
0
ENT
DIMMER
TV
VOL
ENTER
LISTENING MODE
SURROUND
RANDOM
SUBTITLE
CH SEL
PLAY MODE
REMOTE MODE
RECEIVER
TAPE
M
DVD
C DTAPE TUNER
CABLE
CLR
SLEEP
CH
DISC
ALBUM
PREVIOUS
MUTING
SETUPRETURN
-
LEVEL
L NIGHT
DVD
D/CDR
C D
HDD
TV
VCR
SAT
VOL
MENU
LEVEL
Re-EQ
HDDDVDVCR
Press
[RECEIVER]
first
SLEEP
MUTING
+
LEVEL – +
Adjusting the Bass and Treble
You can adjust the bass and treble for the front speakers,
except when the Direct, Pure Audio (not North American
models) or THX listening mode is selected.
TONE
1
2
■
Bass
You can boost or cut low-frequency sounds output by the
front speakers from –10 dB to +10 dB in 2 dB steps.
■
Treble
You can boost or cut high-frequency sounds output by
the front speakers from –10 dB to +10 dB in 2 dB steps.
Note:
•To bypass the bass and treble tone circuits, select the
Direct or Pure Audio (not North American model) listening mode.
Press the AV receiver’s [TONE]
button repeatedly to select either
Bass or Treble.
Use the TONE [–]/[+] buttons to
adjust.
-
RC
650M
TONE, –, +
STANDBY/ON
STANDBY
DVDMULTI CH C
PHONES
SPEAKERS
VIDEO
3VIDEO 2VIDEO 1
VCR
TONE
LISTENING MODE
DISPLAYTHX DIMMER MEMORY
TUNING PRESET
ENTER
TUNERTAPE
DIGITAL
INPUT
SETUPRETURN
D
TUNING
MODEAB
CLEAR
PHONES DIMMER
Setting the Display Brightness
You can adjust the brightness of the display.
Press the remote controller’s
[DIMMER] button repeatedly to
DIMMER
select: dim, dimmer, or normal
brightness.
Alternatively, you can use the AV
receiver’s [DIMMER] button (not
European models).
VIDEO
MASTER VOLUME
VIDEO 3 INPUT
AUDIOLR
Muting the AV Receiver
You can temporarily mute the output of the AV receiver.
Press the remote controller’s
[MUTING] button.
MUTING
To unmute the AV receiver,
ler’s [MUTING] button again, or adjust the volume. The
output is unmuted and the MUTING indicator goes off.
Muting is cancelled when the AV receiver is set to
Standby.
The output is muted and the MUTING
indicator flashes on the display.
press the remote control-
43
Common Functions
—Continued
Using the Sleep Timer
With the sleep timer, you can set the AV receiver so that
it turns off automatically after a specified period.
Press the remote controller’s
[SLEEP] button repeatedly to
SLEEP
To cancel the sleep timer,
repeatedly until the SLEEP indicator disappears.
To check the remaining sleep time,
button. Note that if you press the [SLEEP] button while
the sleep time is being displayed, you’ll shorten the sleep
time by 10 minutes.
select the required sleep time.
You can set the sleep time from 90 to 10
minutes in 10 minute steps.
The SLEEP indicator appears on the
display when the sleep timer has been
set, as shown. The specified sleep time
appears on the display for about 5 seconds, then the previous display reappears.
SLEEP indicator
press the [SLEEP] button
press the [SLEEP]
Adjusting Speaker Levels
You can adjust the volume of each speaker in speaker set
A. These temporary adjustments are cancelled when the
AV receiver is set to Standby.
1
CH SEL
-
LEVEL
Notes:
•You cannot use this function while the AV receiver is
muted.
• Speakers that are set to No or None in the Speaker
Configuration cannot be adjusted.
■
Speaker Set B
While speaker set B is on, you can adjust the volume of
the left and right speakers, from –12 dB to +12 dB.
Use the remote controller’s
[CH SEL] button to select each
speaker, and use the [LEVEL–]
and [LEVEL+] buttons to adjust
the volume.
You can adjust the volume of each
+
LEVEL
speaker from –12 dB to +12 dB
(–15 dB to +12 dB for the subwoofer).
Using Headphones
For private listening, you can connect a pair of stereo
headphones (1/4-inch phone plug) to the AV receiver’s
PHONES jack.
STANDBY/ON
STANDBY
PHONES
Notes:
•Always turn down the volume before connecting your
headphones.
• Speaker sets A and B are turned off while the headphones plug is inserted in the PHONES jack.
• When you connect a pair of headphones, the listening
mode is set to Stereo, unless it was set to Pure Audio
(not North American model), Mono, Stereo, or Direct,
in which case it stays the same.
• When the multichannel DVD input is selected, only
the front left and front right channels can be heard in
the headphones.
• These settings are stored when the AV receiver is set
to Standby.
• While speaker set B is on, you cannot adjust the levels
of speaker set A’s surround back speakers.
■
Headphones
While a pair of headphones is connected, you can adjust
the volume of each headphone speaker, from –12 dB to
+12 dB each.
• These settings are stored when the AV receiver is set
to Standby.
44
Using the Listening Modes
Selecting Listening Modes
For a description of each listening mode, see “About the
Listening Modes” on page 47.
• The Dolby Digital and DTS listening modes
can only be selected if your DVD player is
connected to the AV receiver with a digital
audio connection (coaxial or optical).
• Listening mode availability depends on the
format of the current input signal.
• While a pair of headphones is connected,
you can select only the Pure Audio (not
North American model), Mono, Direct, or
Stereo listening mode.
• The listening modes cannot be selected
while speaker set A is off.
Selecting on the AV Receiver
MASTER VOLUME
STANDBY/ON
STANDBY
PURE AUDIO
PHONES
SPEAKERS
PURE AUDIO
DVDMULTI CH C
3VIDEO 2VIDEO 1
VIDEO
VCR
TONE
LISTENING MODE
DISPLAYTHX RT/PTY/TP MEMORY
THX
LISTENING MODE
TUNING PRESET
ENTER
TUNERTAPE
DIGITAL
INPUT
SETUPRETURN
D
VIDEO 3 INPUT
VIDEO
TUNING
MODEAB
CLEAR
AUDIOLR
Selecting with the Remote Controller
CH
TV
DISC
VOL
INPUT
GUIDE
TOP MENU
SP A / B
PLAYLIST/CAT PLAYLIST/CAT
SURROUND
LISTENING MODE
SURROUND
STEREO
■
[STEREO] button
STEREO
SUBTITLE
AUDIO REPEAT
TEST TONE
CH SEL
PLAY MODE
DISPLAY
This button selects the Stereo listening mode.
■
[SURROUND] button
This button selects the Dolby Digital and DTS listening modes and the Neural Surround listening mode
(North American model only).
■
LISTENING MODE [ ]/[ ] buttons
Pressing these buttons repeatedly cycles through all
of the listening modes that can be used with the current input source.
RC
ENTER
-
ALBUM
RANDOM
LEVEL
L NIGHT
650M
-
VOL
PREVIOUS
MENU
MUTING
SETUPRETURN
LEVEL
Re-EQ
HDDDVDVCR
+
,
■
[PURE AUDIO] button (not North American
model)
This button selects the Pure Audio listening mode.
When this mode is selected, the AV receiver outputs
no video signals and its display is turned off.
Pressing this button again will select the previous listening mode.
■
[THX] button
This button selects the THX listening mode.
■
LISTENING MODE [ ]/[ ] buttons
Pressing these buttons repeatedly cycles through all
of the listening modes that can be used with the current input source.
45
Using the Listening Modes
—Continued
The following table shows which listening modes can be used with each input signal format.
Source format
Listening mode
Pure Audio (Not North
American models)
Direct
Stereo
Mono
Multich
PLIIx Movie/Music/Game
Neo:6 Cinema
Neo:6 Music
Neural Surround (North
American models only)
Dolby D
Dolby D + Neo:6
Dolby D EX
Dolby
Dolby D+PLIIx Music
Dolby D+PLIIx Movie
DTS, DTS 96/24
DTS-ES Discrete
DTS-ES Matrix
DTS
DTS+Neo:6
DTS+Dolby EX
DTS+PLIIx Music
DTS+PLIIx Movie
THX Cinema
THX Surround EX
*6
THX Cinema2
THX
THX Music mode
THX Games mode
Mono Movie
Onkyo
Original
DSP
*1. In the Pure Audio and Direct listening modes, 32 kHz, 44.1 kHz, and 48 kHz PCM is processed at 64 kHz, 88.2 kHz, and 96 kHz respectively. In
listening modes other than Pure Audio, Direct, and Stereo, 64 kHz, 88.2 kHz, and 96 kHz PCM is processed at 32 kHz, 44.1 kHz, and 48 kHz
respectively.
*2. In listening modes other than Pure Audio, Direct, Stereo, and DTS 96/24, DTS 96/24 sources are processed as normal DTS.
*3. If the Surr Back parameter is set to None, or speaker set B is on, normal Pro Logic II is used.
*4. Not available for 88.2 kHz and 96 kHz PCM input signals.
*5. If the Surr Back setting is set to None, or speaker set B is on, normal DTS is used.
*6. Available only when surround speakers are connected.
Orchestra
Unplugged
Studio-Mix
TV Logic
All Ch Stereo
Full Mono
*3
*6
Analog,
*1
PCM
CD, TV,
radio,
cassette,
etc.
3/2.1
2/2.1
✔ ✔✔✔✔✔✔ ✔ ✔
✔ ✔✔✔✔✔✔ ✔
✔✔ ✔
*4
✔
✔✔
✔
✔
✔✔✔ ✔✔✔ ✔
✔
✔
✔
✔ ✔ ✔ ✔
✔ ✔✔✔✔✔✔ ✔
Dolby Digital
2/0 1/0, 1+1 Other
DVD, DTV, etc. DVD, CD, etc. DVD
3/2.1
2/2.1
DTS/DTS 96/24
2/0
✔
✔
✔
✔
✔
*2
DTS-ES
Discrete Matrix
*5
✔
✔
✔
Multich
analog
✔
: Only available on 6.1/7.1-channel playback systems. Not available while speaker set B is on.
: Only available on 7.1-channel playback systems. Not available while speaker set B is on.
Tip: To check the format of the digital input signal, see “Displaying Source Information” on page 38.
46
Using the Listening Modes
—Continued
About the Listening Modes
The AV receiver’s listening modes can transform your
listening room into a movie theater or concert hall, with
high fidelity and stunning surround sound.
The illustration shows which speakers are active in
each listening mode with 7.1 channel speaker system.
Front left Center Front right
Subwoofer
Surround left
Pure Audio (not North American models)
back left/ right
In this mode, the display and video circuitry are turned
off, minimizing possible noise sources for the ultimate in
high-fidelity reproduction. (As the video circuitry is
turned off, no video signals are output in this mode.)
Direct
In this mode, audio from the input source is output
directly with minimal processing, providing high-fidelity reproduction. All of the source’s audio channels are
output as they are.
Stereo
Sound is output by the front left and right speakers and
subwoofer.
Mono
Use this mode when watching an old movie with a mono
soundtrack, or use it with the foreign language
soundtracks recorded in the left and right channels of
some movies. It can also be used with DVDs or other
sources containing multiplexed audio, such as karaoke
DVDs.
Dolby Pro Logic IIx
Dolby Pro Logic II
Dolby Pro Logic IIx
7.1-channel playback. It provides a very natural and
seamless surround-sound experience that fully envelops
the listener. As well as music and movies, video games
can also benefit from the dramatic spatial effects and
vivid imaging. If you’re not using any surround back
speakers,
Dolby Pro Logic II
Dolby Pro Logic IIx.
• PLIIx Movie
Use this mode with any stereo or Dolby Surround
(Pro Logic) movie (e.g., TV, DVD, VHS).
• PLIIx Music
Use this mode with any stereo or Dolby Surround
(Pro Logic) music source (e.g., CD, radio, cassette,
TV, VHS, DVD).
• PLIIx Game
Use this mode with video games, especially those that
bear the Dolby Pro Logic II logo.
Surround rightSurround
expands any 2-channel source for
will be used instead of
Dolby Digital
Use this mode with DVDs that bear the
Dolby Digital logo, and Dolby Digital TV
broadcasts. This is the most common digital surroundsound format, and it’ll put you right in the middle of the
action, just like being in a movie theater or concert hall.
Dolby Digital EX
DTS+Dolby EX
These modes expand 5.1-channel Dolby
Digital and DTS sources for 6.1/7.1-channel playback. They’re especially suited to
Dolby Digital EX soundtracks that include
a matrix-encoded surround back channel. The additional
channel adds an extra dimension and provides an enveloping surround sound experience, perfect for rotating
and fly-by sound effects. Use them with DVDs that bear
the Dolby Digital or DTS logo.
Dolby Digital+PLIIx Music
DTS+PLIIx Music
These modes use the Pro Logic IIx Music
mode to expand 5.1-channel Dolby Digital
and DTS sources for 6.1/7.1-channel playback. Use them with Dolby Digital or
DTS 5.1 music sources (e.g., DVD and Dolby Digital TV
broadcasts).
Dolby Digital+PLIIx Movie
DTS+PLIIx Movie
These modes use the Pro Logic IIx Movie
mode to expand 5.1-channel Dolby Digital
and DTS sources for 7.1-channel playback. Use them with Dolby Digital and
DTS 5.1 movies (e.g., DVD and select digital TV broadcasts).
DTS
The DTS digital surround-sound format supports
up to 5.1 discrete channels and uses less compression for high-fidelity reproduction. Use it
with DVDs and CDs that bear the DTS logo.
DTS 96/24
This mode is for use with DTS 96/24
sources. This is high-resolution DTS with a
96 kHz sampling rate and 24-bit resolution, providing
superior fidelity. Use it with DVDs that bear the DTS
96/24 logo.
DTS-ES Discrete
This mode is for use with DTS-ES Discrete
soundtracks, which use a discrete surround
back channel for true 6.1/7.1-channel playback. The
seven totally separate audio channels provide better spatial imaging and 360-degree sound localization, perfect
for sounds that pan across the surround channels. Use it
with DVDs that bear the DTS-ES logo, especially those
with a DTS-ES Discrete soundtrack.
47
Using the Listening Modes
—Continued
DTS-ES Matrix
This mode is for use with DTS-ES Matrix
soundtracks, which use a matrix-encoded
back-channel for 6.1/7.1-channel playback. Use it with
DVDs that bear the DTS-ES logo, especially those with
a DTS-ES Matrix soundtrack.
DTS Neo:6
This mode expands any 2-channel source for 6.1-channel playback. It uses six full-bandwidth channels of
matrix decoding for matrix-encoded material, providing
a very natural and seamless surround sound experience
that fully envelops the listener.
• Neo:6 Cinema
Use this mode with any stereo movie (e.g., TV, DVD,
VHS).
• Neo:6 Music
Use this mode with any stereo music source (e.g.,
CD, radio, cassette, TV, VHS, DVD).
Dolby Digital + Neo:6
DTS+Neo:6
This mode uses Neo:6 to expand 5.1-channel Dolby Digital and DTS sources for
6.1/7.1-channel playback. Use it with
DVDs that bear the Dolby Digital or DTS
logo and feature a 5.1-channel soundtrack.
Neural Surround
(North American models only)
Neural Surround represents the latest advancement in
surround technology developed for music and is adopted
by XM Satellite Radio for digital radio broadcast of surround recordings and live events in surround sound.
Neural Surround employs psychoacoustic frequencydomain processing, which allows delivery of a more
detailed sound stage, with superior channel separation
and localization of audio elements. System playback is
scalable from 5.1 to 7.1 multichannel surround playback.
THX
Founded by George Lucas, THX develops stringent standards that ensure movies are reproduced in movie theaters and home theaters just as the director intended.
• THX Cinema
This mode is for watching movies, which are typically recorded and edited on the assumption that they
will be played in a sizable place like a movie theater.
It carefully optimizes the tonal and spatial characteristics of the soundtrack for reproduction in the
smaller home-theater environment. It can be used
with 2-channel sources processed with other formats, and multichannel sources. Surround back
speaker output depends on the source material and
the selected listening mode.
• THX Cinema2
This mode expands Dolby Digital and DTS 5.1channel sources for 7.1-channel playback. It does
this by analyzing the composition of the surround
source, optimizing the ambient and directional
sounds to produce the surround back channel output.
This is a new and improved mode especially for
home theater use.
• THX Music Mode
This mode is designed for use with music. It expands
Dolby Digital and DTS 5.1-channel sources for 7.1channel playback.
• THX Games Mode
This mode is designed for use with video games.
• THX Surround EX or
This mode expands Dolby Digital and DTS 5.1channel sources for 6.1/7.1-channel playback. It’s
especially suited to Dolby Digital EX sources. THX
Surround EX, also known as Dolby Digital Surround
EX, is a joint development between Dolby Laboratories and THX Ltd.
Onkyo Original DSP Modes
Mono Movie
This mode is suitable for old movies and other mono
sources. The center speaker outputs the sound as it is,
while reverb is applied to the sound output by the other
speakers, giving presence to even mono material.
Orchestra
Suitable for classical or operatic music, this mode
emphasizes the surround channels in order to widen the
stereo image, and simulates the natural reverberation of
a large hall.
Unplugged
Suitable for acoustic instruments, vocals, and jazz, this
mode emphasizes the front stereo image, giving the
impression of being right in front of the stage.
Studio-Mix
Suitable for rock or pop music, listening to music in this
mode creates a lively sound field with a powerful acoustic image, like being at a club or rock concert.
TV Logic
This mode adds realistic acoustics to TV shows produced in a TV studio, surround effects to the entire
sound, and clarity to voices.
All Ch Stereo
Ideal for background music, this mode fills the entire listening area with stereo sound from the front, surround,
and surround back speakers.
Full Mono
In this mode, all speakers output the same sound in
mono, so the sound you hear is the same regardless of
where you are within the listening room.
48
Using the Listening Modes
ENTER
ON/STANDBY
123
V1V2V
456
789
+
10
D TUN
--/---
INPUT
GUIDE
TOP MENU
SP A / B
PLAYLIST/CAT PLAYLIST/CAT
STEREO
AUDIO REPEAT
TEST TONE
DISPLAY
INPUT SELECTOR
MULTI CH
10 11 12
0
ENT
DIMMER
TV
VOL
ENTER
LISTENING MODE
SURROUND
RANDOM
SUBTITLE
CH SEL
PLAY MODE
-
650M
RC
REMOTE MODE
DVD
RECEIVER
TAPE
M
D/CDR
HDD
3
DVD
VCR
C DTAPE TUNER
CABLE
SAT
CLR
SLEEP
CH
DISC
VOL
ALBUM
PREVIOUS
MENU
MUTING
SETUPRETURN
-
LEVEL
LEVEL
Re-EQ
L NIGHT
HDDDVDVCR
C D
TV
+
—Continued
RECEIVER
SETUP
Re-EQ
L NIGHT
Using the Re-EQ
With the Re-EQ, you can soften overly bright movie
soundtracks, which are typically mixed for reproduction
in a movie theater.
Re-EQ can be used with the following listening modes:
Dolby Digital, Dolby Digital EX, PLII/IIx Movie, DTS,
DTS-ES, DTS Neo:6 Cinema, DTS 96/24,
Dolby/DTS+PLIIx Movie, Dolby/DTS+Neo:6,
DTS+Dolby EX, THX Surround EX, THX Cinema2 and
THX Cinema.
1
RECEIVER
Press the [RECEIVER] REMOTE
MODE button, and then press the
[Re-EQ] button repeatedly to
select:
On:
Re-EQ
Off:
Re-EQ on.
Re-EQ off.
Using the Audio Adjust Settings
The Audio Adjust settings only affect speaker set A.
1
RECEIVER
Press the [RECEIVER] button followed by the [SETUP] button.
Using the Late Night Function
(Dolby Digital only)
With the Late Night function, you can reduce the
dynamic range of Dolby Digital material so that you can
still hear quiet parts even when listening at low volume
levels—ideal for watching movies late at night when you
don’t want to disturb anyone.
1
RECEIVER
L NIGHT
Notes:
• The effect of the Late Night function depends on the
Dolby Digital material that you are playing, and with
some material there will be little or no effect.
• The Late Night function is set to Off when the AV
receiver is set to Standby.
Press the [RECEIVER] REMOTE
MODE button, and then press the
[L NIGHT] button repeatedly to
select:
Off:
Late Night function off.
Low:
Small reduction in dynamic
range.
High:
Big reduction in dynamic
range.
2
3
SETUP
Use the Up and Down [ ]/[ ]
buttons to select “5. Audio
Adjust,” and then press [ENTER].
Use the Left and Right [ ]/[ ]
buttons to change the setting.
Press the Down [ ] button to
select the next setting.
Repeat this step for the other settings.
49
Using the Listening Modes
4
SETUP
The Audio Adjust settings are explained below.
Press the [SETUP] button.
Setup closes.
—Continued
Input Channel Settings
■
Multiplex
This setting determines which channel is output from a
stereo multiplex source. Use it to select audio channels
or languages with multiplex sources, multilingual TV
broadcasts, and so on.
Main:
■
This setting determines which channel is output when
the Mono listening mode is used with a stereo source.
The main channel is output (default).
Sub:
The sub channel is output.
M/S:
Both the main and sub channels are output.
Mono (2ch)
L+R:
Both the left and right channels are output
(default).
L:
Only the left channel is output.
R:
Only the right channel is output.
Mono Setting
■
Center Width
With this setting, you can adjust the width of the sound
from the center speaker when using the Pro Logic II
Music or Pro Logic IIx Music listening mode. Normally,
the center channel sound is output by only the center
speaker. (If you’re not using a center speaker, the center
channel sound will be distributed to the front left and
right speakers to create a phantom center). This setting
adjusts the front left, right, and center mix, allowing you
to adjust the weight of the center channel sound. It can
be adjusted from 0 to 7 (default value is 3).
DTS Neo:6 Music Mode Setting
■
Center Image
The DTS Neo:6 Music listening mode creates 6-channel
surround sound from 2-channel (stereo) sources. With
this setting, you can specify by how much the front left
and right channel output is attenuated in order to create
the center channel. It can be adjusted from 0 to 5 (default
value is 2). This setting has no effect if no center speaker
is connected.
When set to 0, the front left and right channel output is
attenuated by half (–6 dB), giving the impression that the
sound is located centrally. This setting works well when
the listening position is considerably off center. When
set to 5, the front left and right channels are not attenuated, maintaining the original stereo balance.
■
Mono Out Sp
This setting determines which speakers output mono
audio when the Mono listening mode is selected.
L/R:
Mono audio is output from the front left and
right speakers.
C:
Mono audio is output from the center speaker
(default).
PLII and PLIIx Music Mode Settings
These settings apply to only 2-channel (stereo) sources.
■
Panorama
With this setting, you can broaden the width of the front
stereo image when using the Pro Logic II Music or Pro
Logic IIx Music listening mode.
On:
Panorama function on.
Off:
Panorama function off (default).
■
Dimension
With this setting, you can move the sound field forward
or backward when using the Pro Logic II Music or Pro
Logic IIx Music listening mode. The default value is 3.
It can be adjusted from 0 to 6. Higher settings move the
sound field forward. Lower settings move it backward.
If the stereo image feels too wide, or there’s too much
surround sound, move the sound field forward to
improve the balance. Conversely, if the stereo image
feels like it’s in mono, or there’s not enough surround
sound, move it backward.
Dolby Digital EX Input Signal Setting
■
Dolby EX
This setting determines how Dolby Digital EX signals
are handled. This setting is unavailable if no surround
back speakers are connected or speaker set B is on.
Auto:
If the source signal contains a Dolby Digital
EX flag, the Dolby Digital EX listening mode
is used, and THX Surround EX can be
selected from among the THX listening
modes (default).
Manual:
You can select Pro Logic IIx Movie, Pro
Logic IIx Music, Dolby Digital, or Dolby
Digital EX.
Multichannel Subwoofer Setting
■
SW Sens
On some DVD players, the signal from the multichannel
subwoofer output is 15 dB higher than normal. You can
change the subwoofer sensitivity to match your DVD
player. Note that this setting only affects signals connected to the SUBWOOFER input jack of the multichannel DVD input.
You can select 0 dB (default), +5 dB, +10 dB, or +15 dB.
If you find that your subwoofer is too loud, try the
+10 dB or +15 dB setting.
50
Using the Listening Modes
—Continued
LFE Level Setting
With this setting, you can set the level of the LFE (Low
Frequency Effects) channel for Dolby Digital and DTS.
The level can be set to –∞, –10 dB, or 0 dB (default).
If you find that the low-frequency effects are too loud
when using one of these sources, set the level to –10 dB
or –∞ dB.
Vol Display
With this preference, you can choose how the volume
level is displayed.
Abs (Absolute):
Rel (Relative):
The absolute value 84 is equivalent to the relative value
0 dB.
Display range is MIN, 1 through 99,
MAX.
Display range is –∞ dB,
–83…0…+16 dB (default).
Using the THX Audio Settings
The THX Audio settings only affect speaker set A.
1
RECEIVER
SETUP
2
Press the [RECEIVER] button followed by the [SETUP] button.
Use the Up and Down [ ]/[ ]
buttons to select “6. THX Audio,”
and then press [ENTER].
4
SETUP
The THX Audio settings are explained below.
Press the [SETUP] button.
Setup closes.
BGC (Boundary Gain Compensation)
Setting
A room’s boundaries (i.e., walls) and their construction
may make bass sounds louder when the listening position or subwoofer is positioned close to such a boundary.
This is called the boundary gain effect. With this setting,
you can compensate for this and achieve a more accurate
and flatter bass response.
On:
Boundary Gain Compensation on.
Off:
Boundary Gain Compensation off (default).
SB Spc (Surround Back Spacing) Setting
This setting is only available if the SurrBack ch setting
in the Speaker Configuration is set to 2ch.
With this setting, you can specify the distance between
your surround back speakers. To get the best from THX’s
ASA (Advanced Speaker Array) technology, these
speakers should be placed as close together as possible.
0–1 ft (0–0.3 m) (Default):
Select this if the speakers are between 0 and
1 foot (0–30 cm) apart.
1–4 ft (0.3–1.2 m):
Select this if the speakers are between 1 and
4 feet (0.3–1.2 m) apart.
>4 ft (>1.2 m):
Select this if the speakers are more than 4 feet
(1.2 m) apart.
3
Use the Left and Right [ ]/[ ]
buttons to change the setting.
Press the Down [ ] button to
select the next setting.
Repeat this step for the other settings.
51
Recording
VIDEO
AUDIOLR
VIDEO 3 INPUT
A
This section explains how to record the selected input
source to a component with recording capability, and
how to record audio and video from different sources.
Recording the Input Source
You can only record to a component that’s connected to
the TAPE OUT or VIDEO 1 OUT jacks.
See pages 22–33 for information on connecting your AV
components.
1
DVD
VIDEO 1
VCR
TAPE TUNER
VIDEO 3
C D
Remote
controller
123
V1 V2 V3
789
2
3
Use the input selector buttons to
select the component that you
VIDEO 2
want to record.
Audio signals from the selected input
source are output by the TAPE OUT
and VIDEO 1 OUT jacks.
You can listen to the source while
recording. The AV receiver’s VOLUME control has no effect on recording.
6
DVD
C DTAPE TUNER
On your recorder, start recording.
Start playback on the source
component.
Recording Audio and Video from
Separate Sources
You can overdub audio onto your video recordings by
simultaneously recording audio and video from two separate sources. This is possible because only the audio
source is switched when an audio-only input source,
such as TAPE, TUNER, or CD, is selected, the video
source remains the same.
In the following example, audio from the CD player connected to the CD IN jacks, and video from the camcorder
connected to the VIDEO 3 INPUT VIDEO jack are
recorded by the VCR connected to the VIDEO 1 OUT
jacks.
Camcorder
video signal
audio signal
SURROUND B
COA
XIAL
OPTICAL
DIGITAL IN
1
2
3
REMOTE
CONTROL
IN 3
COMPONENT
IN 2 IN 1
IN IN
L
R
CD TAPE
ANTENNA
VIDEO
OUT
Y
B
P
V
PR
S
OUT
LRL
R
FMAM75
VIDEO 2 VIDEO 1
IN IN IN
IN IN
VIDEO 2 VIDEO 1 DVD
DVD
OUT
FRONT
OUT
MONITOR
OUT
SURROUND
L
R
CENTER
SUB
WOOFER
SPEAKERS
SURR BACK
Notes:
•You cannot record from a component that’s connected
to a digital input. Only analog inputs can be recorded.
• The surround sound effects provided by the listening
modes cannot be recorded.
•You cannot record from a component that’s connected
to the multichannel DVD input.
• If you select another input source while recording, that
input source will be recorded instead.
• While the Pure Audio listening mode (not North
American model) is selected, the VIDEO 1 OUT V
and S jacks don’t output video signals, so select
another mode when recording.
52
VCRCD player
1.
Prepare the camcorder and CD player
for playback.
2.
Prepare the VCR for recording.
3.
Press the [VIDEO 3] input selector button.
4.
Press the [CD] input selector button.
This selects the CD player as the audio source, but
leaves the camcorder as the video source.
5.
Start recording on the VCR, then start
playback on the camcorder and CD
player.
Video from the camcorder and audio from the CD
player are recorded by the VCR.
Advanced Setup
Advanced Speaker Settings
ENTER
ON/STANDBY
123
V1 V2 V3
456
789
+
10
D TUN
--/---
INPUT
GUIDE
TOP MENU
SP A / B
PLAYLIST/CAT PLAYLIST/CAT
STEREO
AUDIO REPEAT
TEST TONE
DISPLAY
INPUT SELECTOR
MULTI CH
10 11 12
0
ENT
DIMMER
TV
VOL
ENTER
LISTENING MODE
SURROUND
RANDOM
SUBTITLE
CH SEL
PLAY MODE
-
650M
RC
REMOTE MODE
RECEIVER
TAPE
M
DVD
C DTAPE TUNER
CABLE
CLR
SLEEP
CH
DISC
ALBUM
PREVIOUS
MUTING
SETUPRETURN
-
LEVEL
LEVEL
L NIGHT
DVD
D/CDR
C D
HDD
TV
VCR
SAT
VOL
MENU
Re-EQ
HDDDVDVCR
+
RECEIVER
SETUP
3
4
5
Use the Up and Down [ ]/[ ]
buttons to select “3. SP Distance,” and then press the
[ENTER] button.
While “Unit” is displayed, use the
Left and Right [ ]/[ ] buttons to
select “feet” or “meters”.
feet:
Distances in feet. Can be set
from 1 to 30 feet in 1-foot
steps.
meters:
Distances in meters. Can be
set from 0.3 to 9 meters in
0.3-meter steps.
Use the Down [ ] button to
select “Left,” and use the Left and
Right [ ]/[ ] buttons to specify
the distance for the “front left
speaker,” then press the Down
[] button to select the next
speaker.
Speaker Distance
The speaker distance setting cannot be
changed while a pair of headphones is connected, speaker set B is on, or the multichannel input is being used.
To get the best from surround sound, it’s important that
the sound from each speaker reaches the listener at the
same time. To achieve this, you need to specify the distance from each speaker to the listening position.
1
2
RECEIVER
Measure and make a note of the
distance from each speaker to
the listening position.
Press the [RECEIVER] button followed by the [SETUP] button on
the remote controller.
6
7
Repeat step 5 for all speakers.
Note:
Speakers that you set to No or None in
the Speaker Configuration (page 55)
cannot be selected.
Press the [SETUP] button.
Setup closes.
SETUP
SETUP
53
Advanced Setup
—Continued
Speaker Levels
With this function, you can adjust the volume of each
speaker so that all speakers can be heard equally at the
listening position.
• The speaker levels cannot be adjusted while
a pair of headphones is connected, speaker
set B is on, or the AV receiver is muted.
• Because the AV receiver supports THX, the
test tone is output at the standard level of
0 dB (relative volume setting 0). If you normally listen at volume settings below this, be
careful because the test tone will be much
louder.
1
RECEIVER
SETUP
Press the [RECEIVER] button followed by the [SETUP] button on
the remote controller.
4
5
SETUP
Note:
•A quicker way to adjust the speaker levels is to press
the remote controller’s [TEST TONE] button to output
the test tone, use the [LEVEL–] and [LEVEL+] buttons to adjust the levels, and use the [CH SEL] button
to select the speakers.
Repeat step 3 so that the level of
the test tone from each speaker
is the same.
Speakers that you set to No in the
Speaker Configuration (page 55) do not
output the test tone.
If you’re using a handheld sound level
meter, adjust the level of each speaker
so it reads 75 dB SPL at the listening
position, measured with C-weighting
and slow reading.
Press the [SETUP] button.
Setup closes.
Don’t forget to turn down the volume if
you turned it up while setting the levels.
2
3
Use the Up and Down [ ]/[ ]
buttons to select “4. Level Cal,”
and then press the [ENTER] button.
A pink noise test tone is output by the
front left speaker.
Use the Left and Right [ ]/[ ]
buttons to adjust the speaker
level, and use the Down [ ] button to select the next speaker.
The level can be adjusted from –12 to
+12 dB in 1 dB steps (–15 to +12 dB
for the subwoofer).
54
Advanced Setup
—Continued
Speaker Configuration settings only need to
be changed if you’re not using the speakers in
this package.
These settings cannot be changed while headphones are connected, speaker set B is on, or
the multichannel DVD input is being used.
Speaker Configuration
These settings are used to specify which speakers are
connected.
1
RECEIVER
SETUP
2
3
Press the [RECEIVER] button followed by the [SETUP] button.
Use the Up and Down [ ]/[ ]
buttons to select “2. SP Config,”
and then press the [ENTER] but-
ton.
While the Subwoofer setting is
selected, use the Left and Right
[ ]/[ ] buttons to select
No
.
Yes:
Select if a subwoofer is connected.
No:
Select if no subwoofer is connected.
Yes
or
5
6
7
8
SETUP
Use the Down [ ] button to
select “Surround,” and then use
the Left and Right [ ]/[ ] buttons to select
Yes:
No:
Use the Down [ ] button to
select “Surr Back,” and use the
Left and Right [ ]/[ ] buttons to
select
Use the Down [ ] button to
select “SurrBack ch,” and use the
Left and Right [ ]/[ ] buttons to
select
Note:
• If the Surround and Surr Back set-
Press the [SETUP] button.
Setup closes.
Yes
Yes:
Select if the surround back
No:
Select if no surround back
2ch
2ch:
1ch:
tings in steps 5 and 6 are set to No,
this setting does not appear.
Yes
or No.
Select if the surround speakers are connected.
Select if no surround speakers
are connected.
or No.
speakers are connected.
speakers are connected.
or
1ch
.
Select if two (left and right)
surround back speakers are
connected.
Select if one surround back
speaker is connected.
4
Use the Down [ ] button to
select “Center,” and then use the
Left and Right [ ]/[ ] buttons to
select
Yes
or No.
Yes:
Select if the center speaker is
connected.
No:
Select if no center speaker is
connected.
55
Advanced Setup
—Continued
Digital Input Signal Formats
The following table shows the display indicator for each
digital signal format.
Format Display
Dolby Digital
DTS
PCM
Normally, the AV receiver detects the signal format automatically. However, if you experience either of the following issues when playing PCM or DTS material, you
can specify the signal format as either PCM or DTS:
• If the beginnings of tracks from a PCM source are cut
off, try the PCM setting.
• If noise is produced when fast forwarding or reversing
a DTS CD, try the DTS setting.
STANDBY/ON
STANDBY
DVDMULTI CH C
PHONES
SPEAKERS
TONE
PCM
MASTER VOLUME
TUNING PRESET
ENTER
SETUPRETURN
D
VIDEO 3 INPUT
VIDEO
TUNING
MODEAB
CLEAR
AUDIOLR
LISTENING MODE
TUNERTAPE
DIGITAL
DISPLAYTHX DIMMER MEMORY
INPUT
3VIDEO 2VIDEO 1
VIDEO
VCR
Correcting Sound and Picture Sync
When using progressive scanning on your DVD player,
you may find that the picture and sound are out of sync.
With this setting, you can correct this by delaying the
audio signals. You can set it from 0 to 100 milliseconds
(ms) in 20 millisecond steps.
INPUT
SELECTOR
1
RECEIVER
ON/STANDBY
D TUN
TOP MENU
PLAYLIST/CAT PLAYLIST/CAT
Press the [RECEIVER] REMOTE
MODE button.
REMOTE MODE
RECEIVER
TAPE
INPUT SELECTOR
123
V1V2V
456
DVD
MULTI CH
789
10 11 12
+
CLR
0
10
ENT
--/---
DIMMER
SLEEP
TV
DISC
VOL
ALBUM
INPUT
GUIDE
SP A / B
ENTER
DVD
M
D/CDR
C D
HDD
3
TV
VCR
C DTAPE TUNER
CABLE
SAT
CH
VOL
PREVIOUS
MENU
MUTING
SETUPRETURN
RECEIVER
DIGITAL INPUT
Press and hold the AV receiver’s [DIGITAL
1
INPUT] button for about 3 seconds.
While “Auto” is displayed (about 3 sec-
2
onds), press the [DIGITAL INPUT] button
repeatedly to select: PCM, DTS, or Auto.
PCM:
Only PCM format input signals will be
heard. If the input signal is not PCM, the PCM
indicator will flash and there will be no sound.
DTS:
Only DTS format input signals will be
heard. If the input signal is not DTS, the DTS
indicator will flash and there will be no sound.
Auto (default):
The format is detected automatically. If no digital input signal is present, the
corresponding analog input is used instead.
2
123
V1 V2 V3
Press and hold, for more than 4
seconds, the input selector button for the input source that you
want to correct.
6
DVD
This can be the [DVD], [VIDEO 1],
[VIDEO 2], or [VIDEO 3] input
source.
3
Use the Left and Right [ ]/[ ]
buttons to adjust the delay from 0
to 100 milliseconds in 20 millisecond steps.
Note:
• This setting is not available when the Pure Audio listening mode is used, or the Direct listening mode is
used with an analog input signal.
56
Controlling Other Components
You can use the AV receiver’s remote controller
(RC-650M) to control your other AV components,
including those made by other manufacturers. This section explains how to enter the necessary remote control
code for the component that you want to control (e.g.,
DVD player, TV, or VCR).
Entering Remote Control Codes
To control another component, you must first enter the
appropriate remote control code to a REMOTE MODE
button. You’ll need to enter a code for each component
that you want to control.
RECEIVER
Number
buttons
DISPLAY
ON/STANDBY
123
V1V2V
456
789
+
10
D TUN
--/---
INPUT
GUIDE
TOP MENU
SP A / B
PLAYLIST/CAT PLAYLIST/CAT
STEREO
AUDIO REPEAT
TEST TONE
DISPLAY
INPUT SELECTOR
MULTI CH
10 11 12
0
ENT
DIMMER
TV
VOL
ENTER
LISTENING MODE
SURROUND
RANDOM
SUBTITLE
CH SEL
PLAY MODE
L NIGHT
-
650M
RC
REMOTE MODE
RECEIVER
TAPE
M
3
DVD
C DTAPE TUNER
CABLE
CLR
SLEEP
CH
DISC
ALBUM
PREVIOUS
MENU
MUTING
SETUPRETURN
-
LEVEL
LEVEL
Re-EQ
DVD
D/CDR
C D
HDD
TV
VCR
SAT
VOL
HDDDVDVCR
REMOTE
MODE
+
L NIGHT
2
REMOTE MODE
M D/CDR
DISPLAY
3
123
V1 V2 V3
456
MULTI CH
789
0
DIMMER
4
While holding down the REMOTE
MODE button that you want to
set, press the [DISPLAY] button
DVD
for 3 seconds.
The REMOTE MODE button lights up.
D
C
HDD
TV
VCR
CABLE
SAT
Within 30 seconds, use the number buttons to enter the 4-digit
remote control code.
The REMOTE MODE button flashes
twice.
DVD
C DTAPE TUNER
11
ENT
Press the REMOTE MODE button
again to select the remote controller mode, point the remote
controller at the component, and
check the operation.
If the remote controller doesn’t work as
expected, and several remote codes are
listed, try each one in turn and use the
one that works best.
Notes:
•A remote control code cannot be entered for the
[RECEIVER] REMOTE MODE button.
• The remote control codes provided are correct at the
time of printing, but are subject to change.
1
Look up the appropriate remote
control code in the separate
Remote Control Codes list.
The codes are organized by category
(e.g., DVD player, TV, etc.).
57
Controlling Other Components
—Continued
Remote Control Codes for Onkyo
Components Connected via
Onkyo components that are connected via are controlled by pointing the remote controller at the AV
receiver, not the component. This allows you to control
components that are out of view, in a rack, for example.
Make sure the Onkyo component is con-
1
nected with an cable and an analog
audio cable (RCA).
See page 33 for details.
Enter the appropriate remote control code
2
for the [DVD] or [CD] REMOTE MODE button.
[DVD] REMOTE MODE button
1612:
Onkyo DVD player with
[CD/MD/CDR/HDD] REMOTE MODE button
1327:
Onkyo CD player with
1808:
Onkyo MD recorder with
1322:
Onkyo CD recorder with
1993:
HDD-compatible component with
See the previous page for how to enter remote
control codes.
Press the [DVD] or [CD] REMOTE MODE
3
button, point the remote controller at the
AV receiver, and operate the component.
If you want to control an Onkyo component by pointing
the remote controller directly at it, or you want to control
an Onkyo component that’s not connected via , use
the following remote control codes:
[DVD] REMOTE MODE button
0627:
Onkyo DVD player without (default)
[CD/MD/CDR/HDD] REMOTE MODE button
1817:
Onkyo CD player without (default)
0868:
Onkyo MD recorder without
1323:
Onkyo CD recorder without
1990:
HDD-compatible component without
Note:
If you connect an -capable Onkyo MD recorder, CD
recorder, or HDD-compatible component to the TAPE
IN/OUT or VIDEO 2 jacks, for remote operation to work
properly, you must set the Input Display to MD, CDR, or
HDD (see page 35).
Resetting REMOTE MODE Buttons
You can reset a REMOTE MODE button to its default
remote control code.
1
REMOTE MODE
M D/CDR
L NIGHT
2
REMOTE MODE
M D/CDR
While holding down the REMOTE
MODE button that you want to
reset, press the [L NIGHT] button
DVD
for 3 seconds.
D
C
The REMOTE MODE button lights up.
HDD
TV
VCR
CABLE
SAT
Press the REMOTE MODE button
again.
The REMOTE MODE button flashes
DVD
twice, indicating that it’s been reset.
D
C
HDD
TV
The [DVD] and [CD] REMOTE
MODE buttons are preprogrammed
VCR
with remote control codes for control-
CABLE
ling Onkyo DVD players and CD play-
SAT
ers respectively. When these buttons
are reset, the preprogrammed code is
restored.
Resetting the Remote Controller
You can reset the remote controller to its default settings.
1
2
RECEIVER
L NIGHT
RECEIVER
While holding down the
[RECEIVER] REMOTE MODE button, press the [L NIGHT] button
for 3 seconds.
The [RECEIVER] button lights up.
Press the [RECEIVER] REMOTE
MODE button again.
The [RECEIVER] button flashes twice,
indicating that it’s been reset.
58
Controlling Other Components
—Continued
To control another component, point the remote controller at it and use the buttons explained below. (You must
select the appropriate remote control mode first.) With some AV components, certain buttons may not work as
expected, and some may not work at all.
■
Controlling a TV
■
Controlling a VCR
■
Controlling a Satellite or
Cable Receiver
ON/STANDBY
D TUN
TOP MENU
PLAYLIST/CAT PLAYLIST/CAT
REMOTE MODE
RECEIVER
TAPE
INPUT SELECTOR
123
V1V2V
456
MULTI CH
DVD
789
10 11 12
+
10
0
ENT
--/---
DIMMER
SLEEP
TV
VOL
ALBUM
INPUT
GUIDE
SP A / B
ENTER
M
3
C DTAPE TUNER
CABLE
CLR
CH
DISC
PREVIOUS
MENU
MUTING
SETUPRETURN
DVD
D/CDR
C D
HDD
TV
VCR
SAT
VOL
A
Press [TV]
first
2
3
4
5
6
7
LISTENING MODE
SURROUND
STEREO
RANDOM
SUBTITLE
AUDIO REPEAT
TEST TONE
CH SEL
PLAY MODE
DISPLAY
A
[ON/STANDBY], TV [ ]*
Sets the TV to On or Standby.
Number buttons
B
Enter numbers.
C
TV VOL [ ]/[ ]*
Adjusts the TV’s volume.
[CH +/–]
D
Selects channels on the TV.
[PREVIOUS]
E
Selects the previous channel.
[TV INPUT]*
F
Selects the TV’s VCR input.
[], [ ], [ ], [ ], [ ]
G
Operates the VCR.
* Buttons marked with an asterisk
(*) are exclusively for controlling a TV and can be used at anytime regardless of the current
remote controller mode.
LEVEL
L NIGHT
+
-
LEVEL
Re-EQ
HDDDVDVCR
ON/STANDBY
D TUN
TOP MENU
SP A / B
PLAYLIST/CAT PLAYLIST/CAT
REMOTE MODE
RECEIVER
TAPE
INPUT SELECTOR
123
V1V2V
456
MULTI CH
DVD
789
C DTAPE TUNER
10 11 12
+
CLR
0
10
ENT
--/---
DIMMER
SLEEP
CH
TV
DISC
VOL
ALBUM
INPUT
GUIDE
ENTER
M
3
CABLE
PREVIOUS
MENU
MUTING
SETUPRETURN
DVD
D/CDR
C D
HDD
TV
VCR
SAT
VOL
A
2
Press [VCR]
first
3
4
5
LISTENING MODE
SURROUND
STEREO
RANDOM
SUBTITLE
AUDIO REPEAT
TEST TONE
DISPLAY
A
[ON/STANDBY]
CH SEL
PLAY MODE
LEVEL
L NIGHT
-
LEVEL
Re-EQ
Sets the VCR to On or Standby.
Number buttons
B
Select channels.
[CLR]
C
Cancels functions.
[CH +/–]
D
Selects channels on the VCR.
[], [ ], [ ]
E
Pause, Play, Stop.
[], []
F
Rewind and Fast forward.
6
+
HDDDVDVCR
ON/STANDBY
D TUN
TOP MENU
PLAYLIST/CAT PLAYLIST/CAT
REMOTE MODE
RECEIVER
TAPE
INPUT SELECTOR
123
V1V2V
456
MULTI CH
789
10 11 12
+
0
10
ENT
--/---
DIMMER
SLEEP
TV
VOL
ALBUM
INPUT
GUIDE
SP A / B
ENTER
M
3
DVD
C DTAPE TUNER
CABLE
CLR
CH
DISC
PREVIOUS
MUTING
DVD
D/CDR
C D
HDD
TV
VCR
SAT
VOL
MENU
SETUPRETURN
A
2
Press [SAT]
first
3
4
5
6
7
8
9
LISTENING MODE
SURROUND
STEREO
RANDOM
SUBTITLE
AUDIO REPEAT
TEST TONE
CH SEL
PLAY MODE
DISPLAY
A
[ON/STANDBY]
Sets the satellite/cable receiver
to On or Standby.
B
Number buttons
Enter numbers.
[CLR]
C
Cancels functions.
[CH +/–]
D
Selects satellite/cable channels.
[PREVIOUS]
E
Selects the previous channel.
[GUIDE]
F
Displays the program guide.
G
[ENTER]
Confirms the selection.
[ ]/[ ]/[ ]/[ ]
H
Selects menu items.
[], [ ], [ ], [ ], [ ]
I
Operates the VCR.
LEVEL
L NIGHT
+
-
LEVEL
Re-EQ
HDDDVDVCR
59
Troubleshooting
If you have any trouble using the 7.1ch THX Certified
Digital Surround Receiver and Speaker Package, look
for a solution in this section.
If you can’t resolve the issue yourself, try resetting
the AV receiver before contacting your Onkyo dealer.
To reset the AV receiver to its factory defaults,
turn it on and, while holding down the [VIDEO 1]
button, press the [STANDBY/ON] button. “Clear”
will appear on the display and the AV receiver will
enter Standby mode.
VIDEO 1
VCR
Note that resetting the AV receiver will delete your
radio presets and custom settings.
Power
Can’t turn on the AV receiver
• Make sure that the power cord is plugged into the wall
outlet properly.
• Unplug the power cord from the wall outlet, wait 5
seconds or more, then plug it in again.
The AV receiver turns off as soon as it’s turned
on
• The amp protection circuit has been activated.
Remove the power cord from the wall outlet immediately. Disconnect all speaker cables and input sources,
and leave the AV receiver with its power cord disconnected for 1 hour. After that, reconnect the power cord
and set the volume to maximum. If the AV receiver
stays on, set the volume to minimum, disconnect the
power cord, and reconnect your speakers and input
sources. If the AV receiver turns off when you set the
volume to maximum, disconnect the power cord, and
contact your Onkyo dealer.
Audio
There’s no sound or it’s very quiet
• Make sure that the digital input source is selected
properly (page 35). Press the [DIGITAL INPUT] button repeatedly.
• Make sure the speker set A or B is on (page 8).
• Make sure that all audio connecting plugs are pushed
in all the way (page 22).
• Make sure that the polarity of the speaker cables is
correct, and that the bare wire is in contact with metal
part of each speaker terminal (page 19)
• Make sure that the speaker cables are not shorting.
• Check the volume. It can be set to –∞, –83 throught
+16 dB (page 37). The AV receiver is designed for
60
STANDBY/ON
home theater enjoyment and has a wide volume range
for precise adjustment.
• If the MUTING indicator is shown on the display,
press the remote controller’s [MUTING] button to
unmute the AV receiver (page 43).
• While a pair of headphones is connected to the
PHONES jack, no sound is output by the speakers
(page 44).
• Check the digital audio output settings on the connected device. On some games consoles, such as those
that can play DVDs, the default setting is off.
•With some DVD-Video discs, you need to select an
audio format from a menu.
• If your turntable doesn’t have a phono preamp built-in,
you must connect one between it and the AV receiver.
If your turntable uses an MC cartridge, you must connect an MC head amp, or an MC transformer and a
phono preamp.
• Specify the speaker distances and adjust the individual
speaker levels (pages 53, 54).
• The input signal format is set to PCM or DTS. Set it to
Auto (page 56).
Only the front speakers produce sound
• When the Stereo or Mono listening mode is selected,
only the front speakers and subwoofer produce sound.
• Make sure the speakers are configured correctly
(page 55).
Only the center speaker produces sound
• If you use the Pro Logic IIx Movie, Pro Logic IIx
Music, or Pro Logic IIx Game listening mode with a
mono source, such as an AM radio station or mono TV
program, the sound is concentrated in the center
speaker.
• Make sure the speakers are configured correctly
(page 55).
The surround speakers produce no sound
• When the Stereo or Mono listening mode is selected,
the surround speakers produce no sound (page 47).
• Depending on the source and current listening mode,
not much sound may be produced by the surround
speakers. Try selecting another listening mode.
• Make sure the speakers are configured correctly
(page 55).
The center speaker produces no sound
• When the Stereo or Mono listening mode is selected,
the center speaker produces no sound (page 47).
• Make sure the speakers are configured correctly
(page 55).
The surround back speakers produce no sound
• While speaker set B is on, speaker set A is reduced to
5.1-channel playback and the surround back speakers
produce no sound.
Troubleshooting
—Continued
• The surround back speakers are not used with all listening modes. Select another listening mode
(page 47).
• Not much sound may be produced by the surround
back speakers with some sources.
• Make sure the speakers are configured correctly
(page 55).
The subwoofer produces no sound
• The level of the input signal was too low so the subwoofer entered Standby mode. Increase the subwoofer
level slightly on the HT-R940.
• Make sure that the subwoofer’s [POWER] switch is
set to ON (not North American models).
• The subwoofer’s OUTPUT LEVEL control is set at
minimum. Turn it up.
• The subwoofer outputs no sound while only speaker
set B is on. Turn on speaker set A.
• When you play source material that contains no information in the LFE channel, the subwoofer produces
no sound.
• Make sure the speakers are configured correctly
(page 55).
Speaker set B produces no sound
• Speaker set B only outputs sources that are connected
to an analog input. Make sure that the analog audio
cables are connected properly.
There’s no sound with a certain signal format
• Check the digital audio output setting on the connected device. On some games consoles, such as those
that can play DVDs, the default setting is off.
•With some DVD-Video discs, you need to select an
audio output format from a menu.
Can’t get 6.1- or 7.1-channel playback
• While speaker set B is on, speaker set A is reduced to
5.1-channel playback.
The volume cannot be set to +16 dB
• When the volume level of each speaker has been
adjusted (pages 44, 54), the maximum possible volume may be reduced.
Noise can be heard
• Using cable ties to bundle audio cables with power
cords, speaker cables, and so on may degrade the
audio performance, so don’t do it.
• An audio cable may be picking up interference. Try
repositioning your cables.
The Late Night function doesn’t work
• Make sure the source material is Dolby Digital
(page 49).
The multichannel DVD input doesn’t work
• Check the multichannel DVD input connections
(page 26).
•To select the multichannel DVD input, press the
[MULTI CH] input selector button.
• Check the audio output settings on your DVD player.
About DTS signals
• When playing DTS program material, using the pause,
fast forward, or fast reverse function on your player
may produce a short audible noise. This is not a malfunction.
• When DTS program material ends and the DTS bitstream stops, the AV receiver remains in DTS listening mode and the DTS indicator remains on. This is to
prevent noise when you use the pause, fast forward, or
fast reverse function on your player. If you switch your
player from DTS to PCM, because the AV receiver
does not switch formats immediately, you may not
hear any sound, in which case you should stop your
player for about 3 seconds, and then resume playback.
•With some CD players, you won’t be able to playback
DTS material properly even though your player is connected to a digital input on the AV receiver. This is
usually because the DTS bitstream has been processed
(e.g., output level, sampling rate, or frequency
response changed) and the AV receiver doesn’t recognize it as a genuine DTS signal. In such cases, you
may hear noise.
Video
There’s no picture
• Make sure that all video connecting plugs are pushed
in all the way (page 22).
• Make sure that each video component is properly connected.
• The AV receiver does not convert component video
input signals to other formats, so if a video source
component is connected to a component video input,
your TV must be connected to the component video
output (page 23).
• On your TV, make sure that the video input to which
the AV receiver is connected is selected.
• While the Pure Audio listening mode (not North
American model) is selected, the video circuits are
turned off and the AV receiver outputs no video signals.
61
Troubleshooting
—Continued
Tuner
Reception is noisy, stereo FM reception suffers
from hiss, or the FM STEREO indicator doesn’t
appear
• Relocate your antenna.
•Move the AV receiver away from your TV or computer.
• Listen to the station in mono (page 39).
• When listening to an AM station, operating the remote
controller may cause noise.
•Passing cars and airplanes can cause interference.
• Concrete walls weaken radio signals.
• If nothing improves the reception, install an outdoor
antenna.
Remote Controller
The remote controller doesn’t work
• Make sure that the batteries are installed with the correct polarity (page 13).
• Make sure that the remote controller is not too far
away from the AV receiver, and that there’s no
obstruction between the remote controller and the AV
receiver’s remote control sensor (page 13).
• Make sure you’ve selected the correct remote controller mode (page 14).
• Make sure you’ve entered the correct remote control
code (page 57).
Can’t control other components
• Make sure you’ve selected the correct remote controller mode (page 14).
• If you’ve connected an -capable Onkyo MD
recorder, CD recorder, or next generation HDD-compatible component to the TAPE IN/OUT jacks, or a
DS-A1 Remote Interactive Dock to the VIDEO 2 IN
jacks, for the remote controller to work properly, you
must set the Input Display to MD, CDR, or HDD (see
page 35).
• The entered remote control code may not be correct. If
more than one code is listed, try each one.
•With some AV components, certain buttons may not
work as expected, and some may not work at all.
•To control an Onkyo component that’s connected via
, point the remote controller at the AV receiver. Be
sure to enter the appropriate remote control code first
(see page 58).
•To control an Onkyo component that’s not connected
via , or another manufacturer’s component, point
the remote controller at the component. Be sure to
enter the appropriate remote control code first (see
page 57).
Recording
Can’t record
• On your recorder, make sure the correct input is
selected.
•To prevent signal loops and damage to the AV
receiver, input signals are not fed through to outputs
with the same name (e.g., TAPE IN to TAPE OUT, or
VIDEO 1 IN to VIDEO 1 OUT).
• When the Pure Audio listening mode (not North
American model) is selected, recording is not possible
because no video signals are output. Select another listening mode.
Others
The sound changes when I connect my headphones
• When a pair of headphones is connected, the listening
mode is set to Stereo, unless it’s already set to Stereo,
Mono, Direct, or Pure Audio (not North American
model).
The display doesn’t work
• The display is turned off when the Pure Audio listening mode (not North American model) is selected.
How do I change the language of a multiplex
source
• Use the “Multiplex” setting on the “Audio Adjust”
menu to select Main or Sub (page 50).
The functions don’t work
•To use , you must make an connection and an
analog audio connection (RCA) between the component and AV receiver, even if they are connected digitally (page 33).
62
Troubleshooting
—Continued
The AV receiver contains a microcomputer for signal
processing and control functions. In very rare situations, severe interference, noise from an external
source, or static electricity may cause it to lockup. In the
unlikely event that this happens, unplug the power cord
from the wall outlet, wait at least five seconds, and then
plug it back in again.
Onkyo is not responsible for damages (such as CD
rental fees) due to unsuccessful recordings caused by
the unit’s malfunction. Before you record important
data, make sure that the material will be recorded correctly.
Before disconnecting the power cord from the wall outlet, set the AV receiver to Standby.
Memory Backup
The AV receiver uses a battery-less memory backup
system in order to retain radio presets and other settings when it’s unplugged or in the case of a power failure. Although no batteries are required, the AV receiver
must be plugged into an AC outlet in order to charge the
backup system. Once it has been charged, the AV
receiver will retain the settings for several weeks,
although this depends on the environment and will be
shorter in humid climates.
The following settings can be made for the
S-Video and composite video inputs
You must use the buttons on the unit to make these settings.
1. While holding down the input selector button for the
input source that you want to set, press the [SETUP]
button.
2. Use the Left and Right [ ]/[ ] buttons to change
the setting.
3. Press the [SETUP] button when you’ve finished.
•
Video Attenuation
This setting can be made for the DVD, VIDEO 1,
VIDEO 2, or VIDEO 3 input.
If you have a games console connected to an S-Video
or composite video input, and the picture isn’t very
clear, you can attenuate the gain.
Video ATT:0:
Video ATT:2:
(default).
Gain is reduced by 2 dB.
63
Specifications
Amplifier Section
Rated Output Power (FTC)
All channels: 110 watts minimum continuous power
Rated Output Power (IEC)
Dynamic Power 230 W + 230 W (3
THD (Total Harmonic
Distortion) 0.08% (Power Rated)
Damping Factor 60 (Front, 1kHz, 8
Input Sensitivity and
Impedance 200 mV/ 47 k
Output Level and
Impedance 200 mV/ 470
Frequency Response 5 Hz–100 kHz/ +1 dB–3 dB
Tone Control ±10 dB, 80 Hz (BASS)
Signal to Noise Ratio 100 dB (CD, IHF-A)
Speaker Impedance 8
per channel, 8 ohm loads, 2 channels
driven at 1 kHz, with a maximum total
harmonic distortion of 0.9%
7 ch
×
130 W at 8 ohms, 1 kHz, 1 ch
driven
170 W + 170 W (4
120 W + 120 W (8
(Direct mode)
±10 dB, 20 kHz (TREBLE)
Ω
–16
Ω
Ω
, Front)
Ω
, Front)
Ω
, Front)
Ω
)
Ω
(LINE)
Ω
(REC OUT)
Video Section
Input Sensitivity/Output
Level and Impedance 1 Vp-p /75
0.7 Vp-p /75
0.28 Vp-p /75
1 Vp-p /75
Component Video
Frequency Response 5 Hz – 50 MHz
Ω
(Component and S-Video Y)
Ω
(Component PB/CB, PR/CR)
Ω
(S-Video C)
Ω
(Composite)
Tuner Section
■
FM
General
Power Supply North American: AC 120 V, 60 Hz
Power Consumption North American: 5.9 A
Standby Power
Consumption North American: 0.2 W
Dimensions
(W
×
H × D)
Weight North American: 9.6 kg
■
Video Inputs
Component IN1, IN2, IN3
S-Video DVD, VIDEO1, VIDEO2
Composite DVD, VIDEO1, VIDEO2, VIDEO3
■
Video Outputs
Component MONITOR
S-Video MONITOR, VIDEO1
Composite MONITOR, VIDEO1
■
Audio Inputs
Digital Inputs Optical: 3
Analog Inputs DVD (MULTICHANNEL), VIDEO1,
Multichannel Inputs 7.1
■
Audio Outputs
Analog Outputs TAPE, VIDEO1
Subwoofer Pre Outputs 1
Speaker Outputs SP A (L, R, C, SL, SR, SBL, SBR)
Phones 1
European: AC 230-240 V, 50Hz
European: 670 W
European: 0.4 W
435 × 151 × 377 mm
17-1/8" × 5-15/16" × 14-13/16"
21.2 lbs.
European: 10.2 kg
22.5 lbs.
Coaxial: 1
VIDEO2, VIDEO3, TAPE, CD
SP B (L, R)
Tuning Frequency
Range North American: 87.5 MHz– 107.9 MHz
Usable Sensitivity Stereo: 22.2 dBf (75
Signal to Noise Ratio Stereo: 67 dB (IHF-A)
THD Stereo: 0.5% (1 kHz)
Frequency Response 30 Hz–15 kHz / ±1 dB
Stereo Separation 40 dB (1 kHz)
■
AM
Tuning Frequency
Range North American: 530 kHz–1710 kHz
Usable Sensitivity 300 µV/m
Signal to Noise Ratio 40 dB
THD 0.7%
European: 87.5 MHz– 108.0 MHz
Mono: 15.2 dBf (75
Mono: 73 dB (IHF-A)
Mono: 0.3% (1 kHz)
European: 522 kHz–1611 kHz
Ω
Ω
IHF)
IHF)
Specifications and features are subject to change without
notice.
64
Specifications
■
Speaker
■
Powered Subwoofer (SKW-940)
Type: Acoustic Suspension
Input
sensitivity/impedance: 330 mV / 100 k
Maximum output power:230 W (Dynamic Power)
Frequency response: 20 Hz–100 Hz
Cabinet capacity: 1.73 cubic feet (49 L)
Dimensions
(W
×
H × D):
Weight: 34.2 lbs. (15.5 kg)
Drivers unit: 12 inch (30 cm) Cone Woofer
Power supply: North American: AC 120 V, 60 Hz
Power consumption: North American: 140 W
Other: Auto Standby function
■
Front Speaker (SKF-940F)
Type: 2 Way Acoustic Suspension
Impedance: 8
Maximum input power: 130 W
Output sound pressure
level:
Frequency response: 50 Hz–45 kHz
Crossover frequency: 2 kHz
Cabinet capacity: 0.27 cubic feet (7.5 L)
Dimensions
(W
×
H × D):
Weight: 11.7 lbs. (5.3 kg)
Drivers unit:
Terminal: Banana-plug compatible speaker posts
Other: Magnetic shielding
—Continued
Ω
14-15/16" × 17-1/16" × 16-7/8"
(380 × 444 × 429 mm)
European: AC 230-240 V, 50 Hz
European: 137 W
Ω
83 dB/W/m
6-1/4" × 17-1/16" × 7-13/16"
×
433 × 199 mm)
(158
5 inch (12 cm) A-OMF Cone Woofer
1 inch (2.5 cm) Soft Dome Tweeter
■
Center Speaker (SKC-940C)
Type: 2 Way Acoustic Suspension
Impedance: 8
Maximum input power: 130 W
Output sound pressure
level:
Frequency response: 50 Hz–45 kHz
Crossover frequency: 2 kHz
Cabinet capacity: 0.27 cubic feet (7.5 L)
Dimensions
(W
×
H × D):
Weight: 11.7 lbs. (5.3 kg)
Speaker:
Terminal: Banana-plug compatible speaker posts
Other: Magnetic shielding
■
Surround Speaker (SKM-940S/SKB-940)
Type: 2 Way Acoustic Suspension
Impedance: 8
Maximum input power: 130 W
Output sound pressure
level:
Frequency response: 50 Hz–45 kHz
Crossover frequency: 2 kHz
Cabinet capacity: 0.16 cubic feet (4.6 L)
Dimensions
(W
×
H × D): 7-7/8" × 10-13/16" × 6-5/8"
×
2
Weight: 7.7 lbs. (3.5 kg)
Speaker: 5-1/8 inch (13 cm) A-OMF Cone Woofer
Terminal: Banana-plug compatible speaker posts
Ω
83 dB/W/m
17-1/16" × 6-1/4" × 7-13/16"
(433 × 158 × 199 mm)
5 inch (12 cm) A-OMF Cone Woofer
1 inch (2.5 cm) Soft Dome Tweeter
Ω
81 dB/W/m
×
275 × 169 mm)
(200
1 inch (2.5 cm) Soft Dome Tweeter
×
2
Specifications and appearance are subject to change
without prior notice.
65
Memo
66
Memo
67
Sales & Product Planning Div. : 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN
Tel: 072-831-8023 Fax: 072-831-8124
ONKYO U.S.A. CORPORATION
18 Park Way, Upper Saddle River, N.J. 07458, U.S.A.
Tel: 201-785-2600 Fax: 201-785-2650 http://www.us.onkyo.com/
ONKYO EUROPE ELECTRONICS GmbH
Liegnitzerstrasse 6, 82194 Groebenzell, GERMANY
Tel: +49-8142-4401-0 Fax: +49-8142-4401-555 http://www.eu.onkyo.com/
ONKYO EUROPE UK Office
Suite 1, Gregories Court, Gregories Road, Beaconsfield, Buckinghamshire, HP9 1HQ
UNITED KINGDOM Tel: +44-(0)1494-681515 Fax: +44(0)-1494-680452
ONKYO CHINA LIMITED
Units 2102-2107, Metroplaza Tower I, 223 Hing Fong Road, Kwai Chung,
N.T., HONG KONG Tel: 852-2429-3118 Fax: 852-2428-9039
http://www.ch.onkyo.com/
SN 29344197
(C) Copyright 2006 ONKYO CORPORATION Japan. All rights reserved.
68
HOMEPAGE
http://www.onkyo.com/
I0604-1
* 2 9 3 4 4 1 9 7 *
Loading...
