Oki C6150n, C6150dn, C6150dtn, C6150hdn Datasheet

C6150 Series

Exceptional performance with professional
High Definition color output for your workgroup

C6150n
C6150dn
C6150dtn
C6150hdn

Ideal for businesses that need the power and control of a
high-end workgroup color printer in a compact package.

Highlights:

• High Definition Color Printing technology for
sharp detail and rich, dramatic color

• Fastest in their class: color output at up to
26 ppm; black & white at up to 32 ppm1

• Time to first page as fast as 9 seconds color,
8 seconds black & white

1

• 1200 x 600 dpi resolution for crisp,
clear output

• Models available with duplex (2-sided)
printing, additional paper capacity, and
40 GB hard disk drive standard

• PCL® 5 and PostScript® 3™ emulations

• 10/100 Base-T Network connectivity standard

• Handles media from 3" x 5" cards, 4" x 6" and
5" x 7" photo paper, to banner -size sheets

• Single Pass Color™ Digital technology for
printing up to 80 lb. cover stock (216 gsm)
and banner sheets up to 8.5" x 48"

• Security features including data encryption,
password protection, and document and hard
disk erasure

• Convenient operator panel enables printer
and network settings changes; LCD displays
toner levels

• 2-piece consumables for low Total Cost of
Ownership in color and mono

2

• 1-Year limited warranty with Overnight
Exchange on printer3; 5-Year limited warranty
on LED printheads

• Live, toll-free technical support 24/7/365

3

High-definition color. Exceptional workgroup performance.

Your workgroups are looking for spectacular
documents; you want a great return on your
printer investment. No problem. C6150 Series

Digital Color printers from OKI Printing Solutions
are the answer. They combine fast, high-quality
color output with standard features such as
automatic duplex (2-sided) printing (C6150dn,

-dtn and -hdn4), extra paper capacity (C6150dtn4),
a 40 GB hard disk drive (C6150hdn4), plus our
legendary reliability.

High Definition (HD) Color Printing technology –

All C6150 Series printers utilize this unique
process for breathtaking output, even on
ordinary office copy paper.

Building on the OKI Printing Solutions heritage
of color printing innovation, HD Color Printing
technology combines multilevel LED printheads
and microfine toner to render deep, saturated
colors, fine detail, and precise toner placement.

Rich color pages at up to 26 per minute1 – The

C6150 Series delivers crisp 1200 x 600 dpi
color output, with the first page printing in
as little as 9 seconds.1 Black & white pages
print at up to 32 ppm, the first in as little as
8 seconds.1 The C6150 Series supports both
PCL® and PostScript® emulations.

Exceptional paper handling – All C6150 Series

models have a paper capacity of at least 400
sheets: a 300-sheet paper tray plus built­in 100 sheet multi-purpose tray for labels,
envelopes, transparencies, and cover stock up

to 80 lb.(216 gsm). Use it to print everything
from 3" x 5" cards, 4" x 6" and 5" x 7" photo
paper, to banner-size sheets up to 8.5" wide
by four feet in length.

Since the more sheets a printer holds means
fewer user interventions, the C6150 Series can
further increase your productivity: the standard
paper capacity of the C6150dtn is 930 sheets
with a 530-sheet 2nd tray—and the 2nd tray is
an option on the other models.

Workgroup connectivity built in – Share the

advantages and efficiencies of any or all of
the C6150 Series models through the internal
OkiLAN® 10/100 Base-T print server. Or make
them personal printers by connecting through
the parallel port or high-speed USB 2.0 port.

Unmatched warranty support – We’re so

confident in the reliable performance of the
C6150 Series that we provide an industry­leading 5-year warranty on its printheads, and
a 1-year limited printer warranty with Overnight
Exchange and optional coverage extensions.3

Of course, if you need technical assistance,
you can speak to a live expert located in North
America—24/7/365—by calling 800.OKI.DATA
(800.654.3282) at any time.

1

Published per formance results ba sed on laborator y test ing.

Individual r esults may vary.

2

Pr inters ship with complete s et of 2,000-page “s tarter”

toner car tridges. 6,000 -page Color and 8,000 -page Black toner
cartr idges are available.

3

Available in the U.S. and C anada only.

4

Optional on o ther models.

3

The C6150 Series: your best choice for accurate color output,
a high level of security, and a better bottom line.

Digital Color printers from OKI Printing Solutions deliver more than
brilliant output at best-in-class speeds. The C6150 Series also gives you

control—over the quality of your output, the degree of your security, and
the extent of your printing costs.

C6150 Series models offer a long list of features that can improve your
image, peace of mind and profitability. Here are some value-added
examples:

Color Swatch

Easily match custom colors to the color values
on your C6150 Series printer. Select a simple
swatch to print a basic set of colors then match
the values in your application. Select a custom
swatch and set the Hue, Saturation and
Lightness to target your custom color.

Color Correct

Makes it easy to adjust colors
commonly found in applications
such as Microsoft® Word, Excel
and PowerPoint®. It also lets you
adjust the overall color of a print
by controlling the lightness,
darkness and contrast of images,
and the intensity and lightness
of the colors.

C6150 Series models equipped with a 40 GB
hard disk drive (standard on the C6150hdn; optional on the other
models) provide enhanced security features that include Encrypted
Secure Print:

• 256-Bit Encryption

Enables secure passage of sensitive
documents from PC to printer, with
processing and output requiring PIN
identification. (Requires hard
disk drive.)

• Job Timeout

If not retrieved within a certain time (pre-set by the user), the
document is sanitized (cleared) from the hard disk.

• MAC Validation

The Message Authentication Code (MAC) is PC-encrypted into a
document’s printing data to prevent the file from being tampered
with after it is sent to the printer. The printer reads the code and, if
any alterations to the file are detected, issues a warning and cancels
the job.

• Secure Erase

Ordinarily, simply deleting a document leaves
traces of the contents on a printer’s hard drive.
This feature totally removes the document from
the hard disk drive, erasing all vestiges of a
sensitive file or, if desired, sanitizing the entire
disk drive.

Job Accounting

Enables tracking of color and mono printing
costs, easy monitoring of printing activity,
and greater control of printer usage. It
generates reports for administrative, bill­back or cost-accounting purposes. User
permissions can be assigned and are stored
on the printer—not on the network—so the
system is totally secure.

If you’re looking for high speed, high quality, and a high level of
control in printers that will perform to your unique demands, the
C6150 Series from OKI Printing Solutions has exactly what you want.

THE C6150 SERIES AT A GLANCE

Up to 26 ppm color,
32 ppm mono print speeds

LCD screen display

100-sheet
multi-purpose tray

300-sheet paper tray

530-sheet 2nd paper tray
(standard on C6150dtn,
optional on all other models)

1

High capacity toner cartridges:
8K Black, 6K CMY

2

Single Pass Color™ technology
with straight-through paper
path, delivers high speed and
reliability

1200 x 600 dpi resolution
and HD Color Printing technology

Duplex (2-sided) printing
capability (optional on C6150n,
standard on all other models)

High monthly duty cycle:
rated at 60,000 pages

256 MB memory standard;
expandable to 768 MB max.

Shown: C6150dtn Digital Color Printer

Oki Data Americas, Inc.

USA

2000 Bishops Gate Blvd.
Mount Laurel, NJ 08054-4620
Tel: 800.OKI.DATA (800.654.3282)
Fax: [phone]

www.okiprintingsolutions.com

Canada

2735 Matheson Blvd. East
Mississauga, Ontario L4W 4M8
Tel: [phone]
Fax: [phone]

Latin America

2000 Bishops Gate Blvd.
Mount Laurel, NJ 08054-4620
Tel: [phone]
Fax: [phone]

Oki Data de México, S.A. de C.V.

Mariano Escobedo, 748 8º Piso
Col. Nueva Anzures C.P. 11590
México, D.F.
Tel: [phone]
Fax: [phone]

Oki Data do Brasil Informática Ltda.

Av. Alfredo Egídio de Souza Aranha, 100
Bloco C – 4º andar
04726-170 – São Paulo – SP – Brasil
Tel: [phone]
Fax: [phone]

C6150 Series

Specifications

Performance

Print Speed: Up to 26 ppm Color;

•

up to 32 ppm Mono

Time to First Page: As fast as 9 sec. Color;

•

1

8 sec. Mono 1

Processor: 500 MHz PowerPC CPU

•

HD Color Printing Technology: Combines

•

multilevel LED printheads and microfine toner
for sharp detail and rich color depth

Print Resolution: 1200 x 600 dpi

•

Duty Cycle:

•

Duplex (2-Sided) Printing: Standard on C6150dn,

•

Up to 60,000 pg./mo.

C6150dtn and C6150hdn; optional on C6150n

Productivity Solutions

Web-based Printer Management:

•

PrintSuperVision and OkiLAN® Embedded
Web Server

Direct PDF Printing:

•

Supports PDF v1.5; requires

hard disk drive (standard on C6150hdn)

Security Solutions

Encrypted Secure Printing (requires Hard Disk

•

Drive2): PIN/password-enabled; AES 256-bit

encryption; Secure Erase (DOD5220.22-M
compliant); Message Authentication Code (MAC)

Network Security: IP address filtering, MAC

•

address filtering, SNMP v3, SSL/TLS, IPP over
SSL/TLS, email authentication, Protocol lockouts

Cost Containment Solutions

Job Accounting Software: Tracks color/mono

•

pages by individual or department

Color Access Policy Manager: Allows control over

•

2

color printing access and converts unauthorized
color print jobs to black & white

Compatibility

Emulations: PCL® 5; PostScript® 3™; IBM® PPR;

•

Epson® FX

Operating Systems:

•

Standalone and network –
Windows® Vista®, XP, Server 2003, 2000;
Mac® support – Classic OS 9.x and higher,
OS X 10.2 and higher

Connectivity

Network Interface: OkiLAN® 10/100

•

Base-T Internal Ethernet Print Server

Network Protocols:

•

TCP/IP, NetBeus, NetWave,

Ethertalk

Local Ports: USB v2.0; Parallel

•

Memory

Standard: 256 MB

•

Maximum: 768 MB

•

Memory Storage: 40 GB Hard Disk Drive

•

standard on C6150hdn; optional on
other models

Resident Typefaces

Scalable: 87 PCL fonts and 136 PostScript fonts

•

PCL Bitmap Fonts: OCR-A/B

•

Bar Codes: USPS, UPC-A/E, Code 39/128

•

Paper Handling

Paper Input: 400 sheets standard with 300-sheet

•

Legal/Letter/Universal Tray and 100-sheet Multi­Purpose Tray; 930 sheets max. with 530-sheet
2nd Paper Tray (standard on C6150dtn; optional
on other models)

Multi-Purpose Tray: Standard 100-sheet; handles

•

overhead transparencies, envelopes, mailing
label stock, and banners

Paper Sizes (Min./Max.): Main Tray 4.1" x 5.8"/

•

8.5" x 14"; 2nd Tray 5.8" x 8.3/8.5" x 14";
Multi-Purpose Tray 3" x 5"/8.5" x 48" banner

Paper Weight: Main Tray 20 lb. – 32 lb. bond

•

(75 – 120 gsm); 2nd Tray 20 lb. – 47 lb. bond
(75 – 176 gsm); manual feed 20 lb. bond –
54 lb. bond/80 lb. cover (75 – 216 gsm);
duplex 20 lb. – 28 lb. bond (75 – 105 gsm)

Environmental

Size (WxDxH): 17.1" x 22.1" x 13.4"

•

(43.5 cm x 56.3 cm x 34.0 cm)

Weight: Printer only – 57.3 lb. (26.0 kg)

•

Power Consumption: Idle 100W, Typical 490W,

•

Peak 1200W

Acoustics: Operating – Color 53.8 dB, Mono

•

55.6 dB; Standby – 37 dB

Supplies

Toner Cartridges and Image Drums: Separate

•

Black, Cyan, Magenta and Yellow

Toner Cartridge Life: 6,000 pages CMY,

•

8,000 pages Black – at approx. 5% density

Image Drum Life: Approximately 20,000 pages

•

3

Warranty

Printer: 1-Year limited with Overnight Exchange 5

•

Digital LED Printheads: 5-Year limited warranty

•

For more information on Digital Color Printers

and supplies from OKI Printing Solutions,
including OKIcare® Extended Service Programs 5:
1-800-OKI-DATA (800-654-3282).

1

Published per formance results ba sed on laborator y test ing.

Individual r esults may vary.

2

Req uires hard disk drive for opt imal functionalit y. Standard on

C6150hdn; optional on other models .

3

Toner cartri dges have an estimated lif e bas ed on 5% coverage

of letter-si ze pages. Printer s ship with a complete set of
2,000- page “starter” t oner cartridges .

4

Estimated life, based o n 3 page s per job.

5

Available in the U.S. and C anada only.

Ordering Information

Description Part Numbers

Printer

C6150n 120V (Multilingual) 62430401
C6150n 230V (Multilingual) 62430402
C6150dn 120V (Multilingual) 62430403
C6150dn 230V (Multilingual) 62430404
C6150dtn 120V (Multilingual) 62430405
C6150dtn 230V (Multilingual) 62430406
C6150hdn 120V (Multilingual) 62430407
C6150hdn 230V (Multilingual) 62430408

Options

Duplex (2-Sided Printing) Unit 43830001
530-sheet 2nd Paper Tray 43347601
Memory Expansion:
256 MB DIMM 70051601
512 MB DIMM 70051701
40 GB Hard Disk Drive 70043502

Supplies

Toner Cartridges:

Cyan Toner Cartridge 6,000 pg.
Magenta Toner Cartridge 6,000 pg.
Yellow Toner Cartridge 6,000 pg.
Black Toner Cartridge 8,000 pg.

Image Drum Kits:

Cyan Image Drum Kit 20,000 pg.
Magenta Image Drum Kit 20,000 pg.
Yellow Image Drum Kit 20,000 pg.
Black Image Drum Kit 20,000 pg.

OKIcare® Overnight Exchange Warranty Extensions

U.S. Canada

C6150 Srs. 1-Yr Warranty Ext. 58265801 58265811
C6150 Srs. 2-Yr Warranty Ext. 58265802 58265812
C6150 Srs. Upgrade to On-Site 58265602 58265612

4

OKIcare® On-Site Warranty Extensions

U.S. Canada

C6150 Srs. 1-Yr Warranty Ext. 58263501 58263511
C6150 Srs. 2-Yr Warranty Ext. 58263502 58263512

Print Media Sheets Per Box

Bright White Proofing Sheets (32 lb.):

8.5" x 11" 500 52206101
Premium Color Transparency Film 50 52205701
Premium Card Stock (8.5" x 11"):
60 lb. Cover 250 52205601
90 lb. Index 250 52205602
110 lb. Index 250 52205603
SynFlex™ Paper (8.5" x 11" –
Waterproof and Tear-resistant) 100 52205901
Premium Envelopes (size #10): 100 52206301
500 52206302
Banner Paper (8.5" x 35.4") 100 52206002

3

43865719

3

43865718

3

43865717

3

43865720

4

43381719

4

43381718

4

43381717

4

43381720

5

5

Specifications are subject to change without notice.

© 2007 Oki Data Americas, Inc. OKI Reg. T.M., M.D. M.R., OKIcare, OkiLAN Reg. T.M., Oki Electric Industry Co., Ltd. High Definition Color log o T.M.,
Single Pass Color T.M. and design Reg. T.M., Oki Data Corp. SynFlex, Overnight Exchange logo T.M., Oki Data Americas, Inc. PCL Reg. T.M., Hewlett
Packard Co. Microsoft, PowerPoint, Windows, Windows NT Reg. T.M., Microsoft Corp. PostScript Reg. T.M., PostScript 3 T.M., Adobe Systems,
Inc. Mac Reg. T.M., Apple Computer Inc. USB-IF logo T.M., Universal Serial Bus Implementers Forum, Inc. ENERGY STAR Reg. T.M., U.S. EPA.

Printed in the USA

MS15922-0508
