Nokia 3230 User Guide

User’s Guide for Nokia 3230

DECLARATION OF CONFORMITY We, NOKIA CORPORATION declare under our sole responsibility that the product RM-51 is in conformity with the provisions of the following Council Directive:1999/5/EC. A copy of the Declaration of Conformity can be found at http://www.nokia.com/phones/declaration_of_conformity/

0434

Reproduction, transfer, distribution or storage of part or all of the contents in this document in any form without the prior written permission of Nokia is prohibited.

Nokia, Nokia Connecting People and Pop-Port are registered trademarks of Nokia Corporation. Other product and company names mentioned herein may be trademarks or tradenames of their respective owners.

Java™ and all Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc.

Stac ®, LZS ®, ©1996, Stac, Inc., ©1994-1996 Microsoft Corporation. Includes one or more U.S. Patents: No. 4701745, 5016009, 5126739, 5146221, and 5414425. Other patents pending.Hi/fn ®, LZS ®,©1988-98, Hi/fn. Includes one or more U.S. Patents: No. 4701745, 5016009, 5126739, 5146221, and 5414425. Other patents pending.Part of the software in this product is © Copyright ANT Ltd. 1998. All rights reserved.m-Router Connectivity Components © 2000-2002 Intuwave Limited. All rights reserved. (www.intuwave.com).

Bluetooth is a registered trademark of Bluetooth SIG, Inc.

Nokia tune is a sound mark of Nokia Corporation.

Nokia operates a policy of continuous development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice. Under no circumstances shall Nokia be responsible for any loss of data or income or any special, incidental, consequential or indirect damages howsoever caused.

The contents of this document are provided ‘as is’. Except as required by applicable law, no warranties of any kind, either express or implied, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose, are made in relation to the accuracy, reliability or contents of this document. Nokia reserves the right to revise this document or withdraw it at any time without prior notice.

Export Controls This device may contain commodities, technology or software subject to export laws and regulations from the US and other countries. Diversion contrary to law is prohibited.

The availability of particular products may vary by region. Check with the Nokia dealer nearest to you.

Issue 1

Content

For your safety............................ vii

General information ..................... x

Access codes ........................................ x

PIN code ..................................................... x

PIN2 code................................................... x

Lock code.................................................... x

PUK and PUK2 codes............................... x

1. Getting started ........................ 1

Inserting a SIM card and a

MultiMediaCard .................................. 1

Removing the Multimedia card

during phone operation .................... 2

Charging the battery ......................... 3

Switching the phone on and off .... 3

2. Your phone .............................. 5

Keys and parts ..................................... 5

Essential indicators ............................ 6

Keypad lock (Keyguard)..................... 7

Menu ..................................................... 7

Actions common to all

applications.......................................... 8

Volume control.................................... 9

Help ..................................................... 10

3. Call functions ........................ 11

Making a voice call ......................... 11

Speed dialling a phone number........ 11

Making a conference call (network

service)..................................................... 12

Answering or rejecting a call ....... 12

Call waiting (network service) .......... 12

Options during a call ........................... 13

Push to talk........................................ 13

Settings for push to talk..................... 14

Connecting to the push to talk

service ...................................................... 14

Making a push to talk call.................. 15

Callback requests .................................. 16

Using groups........................................... 17

Call register and general log......... 18

Recent calls register............................. 18

Call duration........................................... 19

Viewing the general log...................... 19

GPRS data counter ............................... 20

4. Writing text............................ 21

Using traditional text input........... 21

Using predictive text input............ 21

Tips for writing text......................... 22

Copying text to the clipboard....... 23

5. Personal information............. 24

Contacts.............................................. 24

Managing contacts............................... 24

Adding a ringing tone.......................... 25

Voice dialling.......................................... 25

Assigning speed-dialling keys ........... 26

Presence.............................................. 26

Changing your availability

information............................................. 27

Changing who can view your

Presence information........................... 27

Updating your Presence

information............................................. 30

Presence settings .................................. 30

Positioning.......................................... 30

Calendar.............................................. 31

Creating calendar entries ................... 31

Calendar views....................................... 32

To-do ................................................... 32

Importing data from compatible

phones................................................. 33

6. Media ..................................... 34

Gallery................................................. 34

Opening files .......................................... 34

Other default folders ........................... 35

Downloading files................................. 35

Uploading images to an image

server........................................................ 35

Camera................................................ 36

Taking a picture or recording a video

clip ............................................................ 36

Camera settings .................................... 37

Viewing images ..................................... 38

Visual Radio....................................... 39

Turning on the radio ............................ 40

Tuning and saving a radio channel.. 41

Using the radio...................................... 41

Using the channel list.......................... 41

View Visual Content............................. 43

Visual Radio settings ........................... 43

Channel Directory................................. 44

RealPlayer™ ....................................... 45

Playing media files ............................... 45

Changing the settings ......................... 46

Movie Director.................................. 47

Settings.................................................... 48

7. Messaging ............................. 49

Writing and sending messages.... 50

Settings for multimedia...................... 52

Settings for e-mail ............................... 52

Inbox - receiving messages .......... 52

Viewing multimedia objects .............. 53

Receiving smart messages ................. 53

Receiving service messages ............... 54

My folders.......................................... 54

Mailbox ............................................... 54

Retrieving e-mail messages from

the mailbox............................................. 55

Deleting e-mail messages .................. 56

Outbox................................................. 57

Viewing messages on a SIM

card....................................................... 57

Cell broadcast.................................... 57

Service command editor................. 58

Messaging settings .......................... 58

Text messages ........................................ 58

Multimedia messages .......................... 59

E-mail messages.................................... 60

Service messages .................................. 62

Cell broadcast ........................................ 62

Settings for the Other folder ............. 62

Chat...................................................... 62

Connecting to a chat server............... 63

Modifying your chat settings ............ 63

Joining and leaving a chat group..... 64

Searching for chat groups and

users.......................................................... 64

Chatting in a chat group .................... 65

Starting and viewing individual

conversations ......................................... 66

Chat contacts......................................... 66

Creating a new chat group ................ 67

Chat and Presence servers.................. 68

8. Tools........................................ 69

Applications ....................................... 69

Downloading an application.............. 69

Installing an application..................... 70

Launching an application ................... 71

Memory status for applications........ 72

Removing an application.................... 72

File manager ...................................... 73

Receiving files via Infrared................. 73

Viewing memory consumption ......... 73

Voice commands.............................. 74

Adding a voice command to an

application.............................................. 74

Starting an application using

a voice command.................................. 75

Replaying, erasing, or changing

a voice command.................................. 75

Device manager................................ 75

9. Personalising your phone...... 77

Profiles................................................ 77

Themes................................................ 78

Settings............................................... 79

Changing general settings ................. 79

Phone settings ....................................... 79

Call settings............................................ 81

Connection settings ............................. 82

Date and time ........................................ 85

Security.................................................... 86

Call barring............................................. 88

Network................................................... 89

Enhancement ........................................ 89

Go to.................................................... 89

10. Extras ................................... 91

Notes................................................... 91

Calculator........................................... 91

Converter............................................ 91

Converting units.................................... 91

Setting a base currency and exchange

rates.......................................................... 92

Recorder ............................................. 92

Clock.................................................... 93

Changing clock settings...................... 93

Setting an alarm ................................... 93

Memory card..................................... 94

Formatting the memory card ............ 94

Backing up and restoring

information............................................. 94

Locking the memory card ................... 95

Checking memory consumption ....... 95

Wallet ................................................. 95

Entering the wallet code .................... 96

Storing personal card details............. 96

Creating personal notes...................... 97

Creating a wallet profile..................... 97

Retrieving information from

the wallet to your browser................. 98

Viewing ticket details .......................... 98

Wallet settings....................................... 99

Resetting the wallet and wallet

code .......................................................... 99

11. Services and

Applications............................. 100

Web (Mobile browser).................. 100

Basic steps for accessing .................. 100

Setting up the phone for the

browser service.................................... 100

Making a connection ......................... 101

Viewing bookmarks ............................ 101

Browsing................................................ 102

Downloading ........................................ 104

Ending a connection .......................... 105

Browser settings.................................. 105

Games............................................... 106

12. Connectivity ...................... 107

PC Suite............................................ 107

Bluetooth connection .................. 107

Bluetooth connection settings........ 108

Sending data via Bluetooth

technology ............................................ 108

Paired devices view ............................ 110

Receiving data via Bluetooth

wireless technology............................ 111

Disconnecting Bluetooth

connection............................................ 111

Infrared connection....................... 111

Connection manager .................... 112

Viewing connection details.............. 112

Ending connections............................ 113

Connecting your phone to a

compatible computer ................... 113

Using your phone as a

modem.............................................. 113

Remote synchronisation .............. 113

Creating a new synchronisation

profile..................................................... 114

Synchronising data............................. 115

13. Troubleshooting ................ 116

Q&A ................................................... 117

14. Battery information .......... 120

Charging and Discharging........... 120

Be safe. Be original. ...................... 121

15. Genuine Enhancements .... 124

Power ................................................ 124

Standard Charger (ACP-7)................ 124

Travel Charger (ACP-12) ................... 125

Audio................................................. 125

Boom Headset (HDB-4)..................... 125

16. Care and Maintenance...... 126

17. Additional safety

information .............................. 127

Index ......................................... 132

For your safety

Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information.

SWITCH ON SAFELY

Do not switch the phone on when wireless phone use is prohibited or when it may cause interference or danger.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.

INTERFERENCE

All wireless phones may be susceptible to interference, which could affect performance.

SWITCH OFF IN HOSPITALS

Follow any restrictions. Switch the phone off near medical equipment.

SWITCH OFF IN AIRCRAFT

Follow any restrictions. Wireless devices can cause interference in aircraft.

SWITCH OFF WHEN REFUELLING

Do not use the phone at a refuelling point. Do not use near fuel or chemicals.

SWITCH OFF NEAR BLASTING

Follow any restrictions. Do not use the phone where blasting is in progress.

USE SENSIBLY

Use only in the normal position as explained in the product documentation. Do not touch the antenna unnecessarily.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

ENHANCEMENTS AND BATTERIES

Use only approved enhancements and batteries. Do not connect incompatible products.

WATER-RESISTANCE

Your phone is not water-resistant. Keep it dry.

BACK-UP COPIES

Remember to make back-up copies or keep a written record of all important information stored in your phone.

CONNECTING TO OTHER DEVICES

When connecting to any other device, read its user guide for detailed safety instructions. Do not connect incompatible products.

EMERGENCY CALLS

Ensure the phone is switched on and in service. Press the end key as many times as needed to clear the display and return to the start screen. Enter the emergency number, then press the send key. Give your location. Do not end the call until given permission to do so.

■ About your device

The wireless device described in this guide is approved for use on the EGSM 900, GSM 1800 and GSM 1900 networks. Contact your service provider for more information about networks.

When using the features in this device, obey all laws and respect privacy and legitimate rights of others.

Warning: To use any features in this device, other than the alarm clock, the device must be switched on. Do not switch the device on when wireless device use may cause interference or danger.

■ Network Services

To use the phone you must have service from a wireless service provider. Many of the features in this device depend on features in the wireless network to function. These Network Services may not be available on all networks or you may have to make specific arrangements with your service provider before you can utilize Network Services. Your service provider may need to give you additional instructions for their use and explain what charges will apply. Some networks may have limitations that affect how you can use Network Services. For instance, some networks may not support all language-dependent characters and services.

Your service provider may have requested that certain features be disabled or not activated in your device. If so, they will not appear on your device menu. Contact your service provider for more information.

This device supports WAP 2.0 protocols (HTTP and SSL) that run on TCP/IP protocols. Some features of this device require network support for these technologies.

■ Shared memory

The following features in this device may share memory: contacts, text messages, and multimedia messages, images and ringing tones, video recorder, RealOne

, calendar, to-do notes, visual

Player radio, and downloaded applications. Use of one or more of these features may reduce the memory available for the remaining features sharing memory. For example, saving many images may use all of the available memory. Your device may display a message that the memory is full when you try to use a shared memory feature. In this case, delete some of the information or entries stored in the shared memory features before continuing. Some of the features may have a certain amount of memory specially allotted to them in addition to the memory shared with other features.

■ Enhancements, batteries, and chargers

Check the model number of any charger before use with this phone. This phone is intended for use when supplied with power from ACP-7 and ACP-12.

Warning: Use only batteries, chargers, and enhancements approved by Nokia for use with this particular model. The use of any other types may invalidate any approval or warranty, and may be dangerous.

For availability of approved enhancements, please check with your dealer. When you disconnect the power cord of any enhancement, grasp and pull the plug, not the cord.

Your phone and its enhancements may contain small parts. Keep them out of reach of small children.

General information

■ Access codes

PIN code

The PIN (Personal Identification Number, 4 to 8 digits) code helps to protect your SIM card against unauthorised use. The PIN code is usually supplied with the SIM card.

After three consecutive incorrect PIN code entries, the PIN code is blocked. If the PIN code is blocked, you need to unblock it with the PUK code before you can use the SIM card again.

PIN2 code

The PIN2 code (4 to 8 digits), supplied with some SIM cards, is required to access some functions.

Lock code

The lock code (5 digits) can be used to lock the phone and keypad to avoid unauthorised use.

The factory setting for the lock code is 12345. To avoid unauthorised use of your phone, change the lock code. Keep the new code secret and in a safe place separate from your phone.

PUK and PUK2 codes

The PUK (Personal Unblocking Key, 8 digits) code is required to change a blocked PIN code. The PUK2 code is required to change a blocked PIN2 code. If the codes are not supplied with the SIM card, contact the operator whose SIM card is in your phone for the codes.

xCopyright

1. Getting started

Getting started

Note: Before removing the

cover, always switch off the power and disconnect the charger and any other device. Avoid touching electronic components while changing the covers. Always store and use the device with the covers attached.

■ Inserting a SIM card and a MultiMediaCard

1. To open the phone slide the phone cover towards the bottom of the phone.

2. Open the memory card holder by pulling it up gently. Insert the SIM card into the lower slot. Make sure that the bevelled corner on the SIM card is facing towards the top of the phone and that the golden contact area on the card is facing downwards.

3. To remove the SIM card, open the memory card holder and use the slider to slide the SIM card out of the card holder.

Getting started

4. Insert the MultiMediaCard (MMC) into the holder’s slot. Make sure that the bevelled corner and golden contact area of the MMC are facing downwards.

5. Close the memory card holder by pressing it downwards until locked.

6. Align the golden contacts of the battery with the corresponding connectors on the phone, and push the opposite end of the battery until it snaps into place.

7. Close the phone cover by sliding it towards the top of the phone.

Keep all SIM cards out of the reach of small children. For availability and information on using SIM card services, contact your SIM card vendor. This may be the service provider, network operator, or other vendor.

Use only compatible Multimedia cards (MMC) with this device. The compatible MMC for your device is Reduced Size Dual Voltage MultiMediaCard. Other memory cards, such as Secure Digital (SD) cards, do not fit in the MMC card slot and are not compatible with this device. Using an incompatible memory card may damage the memory card as well as the device, and data stored on the incompatible card may be corrupted.

■ Removing the Multimedia card during phone operation

You can remove or replace the Multimedia card during phone operation without switching the phone off.

Important: Do not remove the Multimedia card when the phone is switched on in another way as described below. Loss of data may be the result.

2Copyright

Getting started

1. Open the phone cover.

2. Select Menu → Extras →

Memory card. and select Options → Remove mem. card or

press the dip switch right to Multimedia card holder.

The phone displays the message:

Removing memory card will close all open applications. Remove anyway?

3. Press Yes and turn the phone.

4. Open the Multimedia card holder, remove or replace the Multimedia card and close the card holder.

5. Turn the phone and press Ok.

6. Close the phone cover.

■ Charging the battery

2. Connect the other end of the power cord from the charger to the base of the phone.

3. Connect the charger to an AC wall outlet. The battery indicator bar on the display starts scrolling. Note that you can use the phone while charging. When the battery is fully charged, the bar stops scrolling.

Disconnect the charger first from the phone and the from the AC outlet. See ”Battery information”

on page 120.

■ Switching the phone on and off

To switch the phone on and off, press and hold the power button on the top of the phone.

Warning: Do not switch the phone on when wireless phone use is prohibited or when it may cause interference or danger.

Your device has an internal antenna.

1. Connect the power cord to the charger.

Getting started

Note: As with any other

radio-transmitting device, do not touch the antenna unnecessarily when the phone is switched on. Contact with the antenna affects call quality and may cause the phone to operate at a higher power level than otherwise needed. Avoiding contact with the antenna area when operating the phone optimises the antenna performance and the battery life.

NORMAL POSITION: Hold the phone as shown in the picture above.

If the phone requests a PIN code:

The PIN code is usually supplied with the SIM card.

• Enter the code (displayed as ****) and press the left selection key.

If the phone requests a lock code:

• Enter the lock code (displayed as *****) and press the left selection key.

The factory setting for the lock code is 12345.

4Copyright

2. Your phone

Your phone

■ Keys and parts

Front view

1. Earpiece

2. Push to talk (PTT) key

To activate Push to talk. See See

”Push to talk” on page 13.

3. Joystick Enables scrolling through names, phone numbers, menus or settings. The joystick is also used to move the cursor up and down, right and left when writing text, using the calendar, and in some game applications. Pressing the joystick briefly selects the function.

4. Menu key opens the main menu.

5. Call key dials a phone number and answers a call. In standby mode it shows the list of most recently called numbers.

6. – enter numbers and characters.

and are used for various

purposes in different functions.

7. End key ends an active call.

Exits from any function.

8. Edit key opens a list of commands when you are editing a text such as Copy, Cut and

Past e.

9. Clear key clears an entry or deletes an item and exits from different functions.

10. Selection keys The functions of the keys depend on the guiding text shown on the display above the keys. To display the main menu, press .

11 . Power key

Switches the phone on and off. When the keypad is locked, pressing the power key turns the phone’s display lights on for approximately 15 seconds.

Your phone

Back, top and side view

1. Power key and Loudspeaker

2. Eyelet for wrist strap

3. Camera lens

4. Infrared (IR) port

Connectors view

1. Charger connector

2. Pop-Port

connector used, for

example, for headsets and the data cable.

3. Microphone

■ Essential indicators

- The phone is being used in a

GSM network.

- You have received one or several messages to the Inbox folder in Messaging.

- There are messages waiting to be sent in Outbox. See ”Messaging”

on page 49.

and - You have missed calls. See ”Recent calls register” on

page 18.

- Shown if Ringing type is set to

Silent and Message alert tone, Chat alert tone, and E-mail alert tone are

set to Off. See ”Profiles” on page 77.

- The phone keypad is locked.

See ”Keypad lock (Keyguard)” on page 7.

- You have an active alarm. See

”Clock” on page 93.

- All calls to the phone are diverted to another number.

- A memory card is being read or

written to.

- A headset is connected to the

phone.

- A loopset is connected to the

phone.

6Copyright

Your phone

- The connection to a Bluetooth

headset has been lost.

- A data call is active.

- A packet data (GPRS)

connection is active.

- Shown when the packet data connection is on hold. These icons are shown instead of the signal strength indicator (shown in the top left corner in the standby mode). See

”GPRS” on page 84.

- Bluetooth is active.

- An infrared connection is

active.

- Data is being transmitted using Bluetooth. See ”Bluetooth

connection” on page 107.

- USB connection is active.

■ Keypad lock (Keyguard)

Use the keypad lock to prevent the keys from being accidentally pressed.

To lock: In standby mode press the left selection key and then the When the keys are locked, is shown on the display.

To unlock: Press the left selection key and then

key.

When the keypad lock is on, calls still may be possible to the official emergency number programmed into your device.

■ Menu

Press to display the main menu. In the menu you can access all the applications in your phone.

Options in the Menu: Open,

App. downloads, List view/Grid view, Move, Move to folder, New folder, Memory details, Help and Exit.

Grid view or List view of the Menu

• Select Options → List view or

Grid view to change between a

list or an ordered grid of the available applications.

Moving in the Menu

• Move the joystick up, down left and right to navigate in the menu.

Opening applications or folders

• Scroll to an application or a folder and press the joystick to open it.

Closing applications

• Press Back or Exit as many times as needed to return to standby mode or select Options → Exit.

Your phone

Displaying and switching between open applications

• Press and hold to switch from one open application to another. The application switching window opens showing a list of applications that are currently open. Scroll to an application and press the joystick to go to it.

• Numerous open applications may increase the demand on battery power and reduce the battery life. Exit from unused applications.

■ Actions common to all applications

• Opening items for viewing Scroll to an item and press the joystick, or select Options →

Open.

• Editing items - Open the item for viewing and select Options →

Edit. Use the joystick to scroll

through all fields of the item.

• Removing, deleting items Scroll to the item and select

Options → Delete or press the

clear key. To delete many items at a time, you first need to mark them.

• Marking an item - There are several ways to select items when you are in a list.

• To select one item at a time, scroll to the item and select

Options → Mark/Unmark →

Mark or press the edit key and

move the joystick at the same time. A check mark is placed next to the marked item.

• To select all items in the list, select Options →

Mark/Unmark → Mark all.

• To mark multiple items, press and hold the edit key and then move the joystick down or up. As the selection moves, a check mark is placed next to the items. To end the selection, stop the scrolling with the joystick and then release the edit key.

After you have selected all the items that you want, you can move or delete them by selecting Options → Move to

folder or Delete.

• Unmarking an item - Scroll to

the item and select Options →

Mark/Unmark → Unmark or

press the edit key and the joystick at the same time.

• Creating folders - Select Options

→ New folder. You are asked to give a name to the folder (max. 35 letters).

8Copyright

Your phone

• Moving items to a folder -

Select Options → Move to folder (not shown if there are no folders available). When you select Move

to folder, a list of available

folders opens and you can also see the root level of the application (for moving an item out of a folder). Select the location that you want the item to be moved to and press OK.

• Sending items - Scroll to the

item and select Options → Send. Select the method, the choices are Via multimedia, Via

bluetooth, Via e-mail and Via infrared.

• If you choose to send the item in an e-mail or a multimedia message, an editor opens. Press the joystick to select the recipient(s) from the Contacts directory or write the phone number or e-mail address of the recipient in the To field. Add text or sound and select

Options → Send. See

”Writing and sending messages” on page 50.

• Via Bluetooth. See ”Sending

data via Bluetooth technology” on page 108.

Copyright protections may prevent some images, ringing tones, and other content from being copied, modified, transferred or forwarded.

■ Volume control

Voice volume icons:

- for earpiece mode,

- for loudspeaker mode.

When you have an active call or are listening to a sound, press the joystick to the right or to the left to increase or decrease the volume level, respectively.

The loudspeaker allows you to speak and listen to the phone from a short distance without having to hold the phone to your ear, for example, having it on a table nearby. The loudspeaker can be used during a call, with sound and video applications, and when viewing multimedia messages. Sound and video applications use the loudspeaker by default. Using the loudspeaker makes it easier to use other applications during a call.

To start using the loudspeaker during an already active call, select

Options → Activate loudsp.. A tone

is played, is shown in the navigation bar, and the volume indicator changes.

* Display dependent on theme selected.

Your phone

The loudspeaker cannot be activated during a call when you have connected a headset to the phone.

Warning: Do not hold the device near your ear when the loudspeaker is in use, because the volume may be extremely loud.

To turn off the loudspeaker when you have an active call, select

Options → Activate handset.

■ Help

Select Menu → Help.

Help provides usage information for

many applications on the phone. Move the joystick to the left or to the right to toggle between the help category list or a list of keywords . Select a category or a keyword by scrolling or use the text input field, to jump to the desired category or keyword. Press the joystick to display the related helptext.

3. Call functions

Call functions

■ Making a voice call

1. In the standby mode, enter the phone number, including the area code. To remove a number press the clear key.

For international calls, press the

key twice for the + character

(replaces the international access code), and enter the country code, area code (omit the leading zero if necessary), and phone number.

2. Press the call key to call the number.

3. Press the end key to end the call (or to cancel the call attempt).

Pressing the end key will always end a call, even if another application is active.

Tip: To increase or decrease the volume during a call, move the joystick to the right or to the left.

Making a call from the Contacts application - Press and select

Contacts. Scroll to the desired

name; or enter the first letters of the name to the Search field. Matching contacts are listed. Press the call key to call.

Calling your voice mailbox (network service) - To call your

voice mailbox, press and hold key 1 in the standby mode.

Tip: To change the phone number of your voice mailbox, press and select

Tools → Voice mailbox and

select Options → Change

number. Enter the number

(obtained from your service provider) and press OK.

Calling a recently dialled number In the standby mode, press the call key to access a list of the 20 last numbers you called or attempted to call. Scroll to the number you want, and press the call key to call the number.

Speed dialling a phone number

To assign a phone number to one of the speed dialling keys (2 - 9), press

and select Tools → Speed dial.

Key 1 is reserved for the voice mailbox.

To call: In standby mode, press the related key and then the call key or press and hold the related key.

Call functions

Making a conference call (network service)

1. Make a call to the first participant.

2. To make a call to another participant, select Options →

New call. The first call is

automatically put on hold.

3. When the new call is answered, join the first participant in the conference call. Select Options → Conference.

• To add a new person to the

call, repeat step 2, and select

Options → Conference →

Add to conference. The phone

supports conference calls between a maximum of six participants, including yourself.

• To have a private conversation

with one of the participants, select Options → Conference → Private. Select a participant and press Private. The conference call is put on hold on your phone. The other participants can still continue the conference call. Once you have finished the private conversation, select Options → Add to conference to return to the conference call.

• To drop a participant, select

Options → Conference →

Drop participant, scroll to the

participant, and press Drop.

4. To end the active conference call, press the end key.

■ Answering or rejecting a call

• To answer the call, press the call key.

• To mute the ringing tone when a call comes in, press Silence.

Tip: If a compatible headset is connected to the phone, press the headset key to answer and end a call.

• If you do not want to answer a call, press the end key to reject it. The caller will hear a line busy tone. If you have activated the

Call divert → If busy function to

divert calls, rejecting an incoming call will also divert the call.

Call waiting (network

service)

You can answer a call while you have another call in progress if you have activated the Call waiting function in Settings → Call settings → Call

waiting.

Call functions

• To answer the waiting call, press the call key. The first call is put on hold.

• To switch between the two calls, press Swap. Select Options →

Transfer to connect an incoming

call or a call on hold with an active call and to disconnect yourself from the calls. To end the active call, press the end key. To end both calls, select Options →

End all calls.

Options during a call

Many of the options that you can use during a call are network services. Select Options during a call for some of the following options:

Mute or Unmute, Answer, Reject, Swap, Hold or Unhold, Activate handset, Activate loudsp., or Activate handsfree (if a compatible

Bluetooth headset is attached), End

active call or End all calls, New call, Conference, and Transfer. Select:

• Swap - to switch between the active call an the call in hold.

• Transfer - to connect an incoming call or a call on hold with an active call and to disconnect yourself from both calls.

• Replace - to end an active call and replace it by answering the waiting call.

• Send DTMF - to send DTMF tone strings, for example, a password. Enter the DTMF string or search for it in Contacts. To enter a wait character (w) or a pause character (p), press

repeatedly.

Press OK to send the tone.

Tip: You can add DTMF tones to the Phone number or

DTMF fields in a contact

card.

■ Push to talk

Select Menu → Push to talk.

Push to talk over cellular is a two-way radio service (network service) available over a GSM/GPRS cellular network. Push to talk provides direct voice communication connected with pressing the Push to talk key.

You can use push to talk to have a conversation with one person or with a group of people having compatible devices. When your call is connected, the person or group you are calling does not have to answer the phone. Besides the GPRS counters, the phone registers only one-to-one calls in the recent calls lists in Log. The participants should confirm the reception of any communications where appropriate as there is no other confirmation of

Call functions

whether the recipient(s) has(have) heard the call.

To check availability and costs, and to subscribe to the service, contact your network operator or service provider. Note that roaming services may be more limited than for normal calls.

Before you can use the push to talk service, you must define the required push to talk service settings.

While connected to the push to talk service, you can use the other functions of the phone. The push to talk service is not connected to traditional voice communication, and therefore many of the services available for traditional voice calls (for example, voice mailbox) are not available for push to talk communications.

Settings for push to talk

Select Options → Settings.

For push to talk service settings, contact your network operator or service provider. You may receive the settings over the air.

• Notification tone - A tone for incoming push to talk calls.

• Default nickname - Your nickname shown to other users.

• Show my PTT address - Select No if you want to hide your push to talk address from the receivers of your push to talk group or one-to-one calls.

• Domain - The default domain name.

• Access point name - The access point name for the push to talk service.

• Server address - The push to talk server address.

• User name - Your user name used to enter the push to talk service.

• PTT password - Your password used to enter the push to talk service.

• Realm - The name of the domain used for group user authentication.

After modifying the settings, restart the push to talk application.

Connecting to the push to talk service

Select Menu → Push to talk.

Alternatively, press and hold the Push to talk key for a few seconds to connect to the service.

The push to talk application automatically attempts to connect to the push to talk service. If the login is successful, the push to talk sessions view opens.

Call functions

indicates the push to talk connection. If you have added group(s) to the phone, you are automatically joined to the active groups, and the name of the default group is displayed in standby mode.

indicates that the service is temporarily unavailable. The phone automatically tries to reconnect to the service until you disconnect from the push to talk service.

If the login fails, you get an error note such as Unable to switch Push

to talk on. Select Options → Switch PTT on to try to log in again, Settings

to open the settings view, or Exit to close the error note.

To disconnect from the push to talk service, select Options →

Deactivate.

Options in the sessions view

are: Deactivate loudsp./Activate

loudsp., Active members, PTT contacts, PTT log, Settings, Help, Deactivate, and Exit.

Making a push to talk call

Select Options → Deactivate

loudsp./Activate loudsp. to use either

loudspeaker or earpiece for push to talk communication. When the earpiece is selected, you can use the phone normally to your ear.

Warning: Do not hold the device near your ear when the loudspeaker is in use, because the volume may be extremely loud.

To make a push to talk call

1. Select Options → PTT contacts

and search for a contact person or a group.

To open the Push to talk groups view, press the joystick to the right.

2. Press the Push to talk key or the call key. This starts a push to talk call.

Select Options → Send callback

req.. This sends a callback request

to the selected push to talk contact or group.

A tone sounds indicating that the access is granted, and the phone displays your nickname and group name.

3. To request a speech turn, press the Push to talk key. The phone sends your request. Wait until your phone receives a speech turn signal. When the phone displays Talk, you have 30 seconds to talk on your speech turn.

Call functions

Press and hold the Push to talk key the entire time you are

talking, and hold the phone in front of you so that you can see the display. When you have finished, release the key. Talking is allowed on a first-come, first-served basis. When someone stops talking, the first person to press the Push to talk key can talk next.

4. To switch between several active

sessions, select Swap.

5. To end the active session, select

Deactiv..

If you have other active sessions, the phone moves to the next session.

If there are no other sessions, the phone displays a note stating that there are no active sessions.

6. To exit the push to talk

application, select Options →

Exit.

Receiving a push to talk call

A short tone notifies you of an incoming group or a one-to-one call. Press Accept to receive the call or

Silence to reject it.

When receiving a group call, the group name and the nickname of the caller are displayed. When receiving a one-to-one call from a person whose information you have saved

in Contacts, the saved name is displayed if identified; otherwise, only the nickname of the caller is displayed.

Callback requests

Select Options → PTT contacts

or PTT log.

Sending a callback request

If you make a one-to-one call and do not get a response, you can send a request for the person to call you back. You can send a callback request in different ways:

• To send a callback request from the contacts list in the Push to

talk menu, select Options → PTT

contacts. Scroll to a contact and

select Options → Send callback

req..

• To send a callback request from the Contacts, move the joystick down in standby mode, and scroll to the desired contact. Press

Details, scroll to the push to talk

address and select Options →

Send callback req..

• To send a callback request from the group list in the Push to talk menu, select Options → PTT

contacts and move the joystick to

the right. Scroll to the desired group and select Options →

Send callback req..

Call functions

• To send a callback request from the callback request list in the

Push to talk menu, select Options → PTT log. Select

Received callback reqs. and select

Options → Open. Scroll to a

contact and select Options →

Send callback req..

Saving the callback request sender

When you receive a callback request from someone who is not in your contacts list, you can save the name to your contacts.

1. To open the request, select

Options → PTT log → Received

callback reqs..

2. Scroll to the a contact and select

Options → Add to Contacts.

Using groups

Select Options → PTT contacts.

When you call a group, all members joined to the group hear the call simultaneously.

Each member in the groups is identified by a user name given by the service provider. Group members can choose a nickname for within each group, which is shown as a caller identification.

Groups are registered with a URL address. One user registers the group URL in the network by joining the group session the first time.

Adding a group

1. Select Options → PTT contacts

and then move the joystick to the right. This opens the Push to talk

groups view.

2. Select Options → Add group →

Create new.

3. Enter a Group name, and press

OK.

4. Select a Group privacy level.

5. Enter your own nickname in

Nickname in group.

6. To add a thumbnail image to the

group, select Options → Add

thumbnail.

7. Press Done. To add members and

to send an invitation to the group, press Yes when the phone requests for Send group

invitation to all members now?.

This opens a view where you can select members for the group.

The members you invite to the open groups can also invite more members to the group.

Call functions

Joining an existing group

For group detail information, contact your network operator or service provider. You may receive the details over the air.

1. Press Menu → Push to talk →

PTT contacts and then move the

joystick to the right. This opens the Push to talk groups view.

2. Select Options → Add group →

Join existing.

3. Enter the Group address, Group

name, and Nickname in group.

You can also add a Group

thumbnail.

4. Press Done.

Receiving an invitation

When you receive a text message invitation to a group, you get following information:

• From - View the contact information of the person who sent the invitation.

• Nickname - View the nickname of the person who sent the invitation.

• Group name - View the name of the group if the group is not a secured group.

• Group address - View the group address if the group is not a secured group.

Select Options → Save group to ad d the group to your phone. After the group is saved, the phone asks whether you want to connect to the saved group.

To reject the invitation, press Back and Yes.

■ Call register and general log

Select Menu → Log.

In the log, you can monitor information about phone calls, text messages, packet data connections, and data calls registered by the phone. You can filter the log to view just one type of event and create new contact cards based on the log information.

Connections to your remote mailbox, multimedia messaging centre, or browser pages are shown as data calls or packet data connections in the general communications log.

Recent calls register

Select Menu → Log → Recent

calls.

Call functions

The phone registers the phone numbers of missed, received, and dialled calls, and the approximate duration of your calls. The phone registers missed and received calls only if the network supports these functions, and the phone is switched on and is within the network’s service area.

Options in the Missed,

Received, and Dialled views: Call,

Create message, Use number, Delete, Clear list, Add to Contacts, Help, and Exit.

Missed calls and received calls

To view a list of the last 20 phone numbers from which somebody has tried to call you without success (network service), go to Log →

Recent calls → Missed calls.

To view a list of the 20 numbers or names from which you have most recently accepted calls (network service), go to Log → Recent calls →

Received calls.

Dialled numbers

To view the 20 phone numbers that you have most recently called or attempted to call, go to Log →

Recent calls → Dialled nos..

Erasing recent call lists

• To clear all recent call lists, select

Options → Clear recent calls in

the Recent calls main view.

• To clear one of the call registers, open the register you want to erase and select Options → Clear

list.

• To clear an individual event, open a register, scroll to the event, and press the clear key.

Call duration

Select Menu → Log → Call

duration.

Allows you to view the approximate duration of your incoming and outgoing calls.

Note: The actual time invoiced for calls by your service provider may vary, depending on network features, rounding off for billing, and so forth.

Erasing call duration timers - Select

Options → Clear timers. For this,

you need the lock code. See

”Security” on page 86.

Viewing the general log

Select Menu → Log and move

the joystick to the right.

+ 116 hidden pages

Nokia 3230 User Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Content

For your safety

General information

■ Access codes

PIN code

PIN2 code

Lock code

PUK and PUK2 codes

1. Getting started

■ Inserting a SIM card and a MultiMediaCard

■ Removing the Multimedia card during phone operation

■ Charging the battery

■ Switching the phone on and off

2. Your phone

■ Keys and parts

■ Essential indicators

■ Keypad lock (Keyguard)

■ Menu

■ Actions common to all applications

■ Volume control

■ Help

3. Call functions

■ Making a voice call

Speed dialling a phone number

Making a conference call (network service)

■ Answering or rejecting a call

Options during a call

■ Push to talk

Settings for push to talk

Connecting to the push to talk service

Making a push to talk call

Callback requests

Using groups

■ Call register and general log

Recent calls register

Call duration

Viewing the general log
