Nokia 16BTSB01A08 User Manual

Nokia 2720

User Guide

Issue 2019-09-05 en-INT

Nokia 2720 User Guide

1 About this user guide

Important: For important information on the safe use of your device and battery,

read “For your safety” and “Product Safety” info in the printed user guide, or at www.nokia.com/support before you take the device into use. To find out how to get started with your new device, read the printed user guide.

Nokia 2720 User Guide

Table of Contents

1 About this user guide 2

2 Get started 4

Keys and parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Set up and switch on your phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Charge your phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

3 Basics 9

Explore your phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Change the volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Write text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Change the text size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Accessibility mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Google Assistant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

4 Connect with your friends and family 12

Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Send messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Send mail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

5 Personalize your phone 15

Change the tones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Change the look of your home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

6 Camera 16

Photos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Videos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

7 Internet and connections 18

Browse the web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Bluetooth® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Nokia 2720 User Guide

8 Music and videos 20

Music player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Listen to radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Video player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Recorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

9 Organize your day 22

Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Calendar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Converter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

10 Copy content and check the memory 25

Copy content . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

File manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

11 Security and privacy 26

Security settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

12 Product and safety information 27

For your safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Network services and costs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Emergency calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Take care of your device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Recycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Crossed-out wheelie bin symbol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Battery and charger information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Small children . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Medical devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Implanted medical devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Nokia 2720 User Guide

Hearing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Protect your device from harmful content . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Vehicles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Potentially explosive environments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Certification information (SAR) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

About Digital Rights Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Copyrights and other notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Nokia 2720 User Guide

2 Get started

KEYS AND PARTS

Explore the keys and parts of your new phone.

Your phone

This user guide applies to the following models: TA-1175, TA-1173, TA-1170, TA-1168.

The keys and parts of your phone are:

1. Call key

2. Messaging key

3. Left selection key

4. Scroll key

5. Earpiece

6. Camera

7. Flash

8. Microphone

Nokia 2720 User Guide

9. Headset connector

10. SOS call/Google Assistant/Google search key. If you have set the accessibility mode on, this key sends an SOS call. Otherwise, the key switches the Google Assistant on. The Google Assistant is available in selected markets and languages. Where not available, the Google Assistant is replaced by Google Search.

11. Back cover opening slot

To unlock the keys, open the fold.

Avoid touching the antenna area while the antenna is in use. Contact with antennas affects the communication quality and may reduce battery life due to higher power level during operation.

Do not connect to products that create an output signal, as this may damage the device. Do not connect any voltage source to the audio connector. If you connect an external device or headset, other than those approved for use with this device, to the audio connector, pay special attention to volume levels. Parts of the device are magnetic. Metallic materials may be attracted to the device. Do not place credit cards or other magnetic storage media near the device, because info stored on them may be erased.

12. USB connector

13. Loudspeaker

14. Volume keys

15. Right selection key

16. Back key

17. Power/End key

18. Microphone

Some of the accessories mentioned in this user guide, such as charger, headset, or data cable, may be sold separately.

SET UP AND SWITCH ON YOUR PHONE

Learn how to insert the SIM card, memory card, and battery, and how to switch on your phone.

Nano-SIM

Important: This device is designed to be used with a nano-SIM card (see figure) only. Use of

incompatible SIM cards may damage the card or the device, and may corrupt data stored on the card.

Nokia 2720 User Guide

MicroSD memory cards

Use only compatible memory cards approved for use with this device. Incompatible cards may damage the card and the device and corrupt data stored on the card.

Note: Switch the device off and disconnect the charger and any other device before removing any covers. Avoid touching electronic components while changing any covers. Always store and use the device with any covers attached.

Set up your phone

1. Remove the back cover.

face down, close down the holder and slide it to the right to lock it in place.

2. If the battery is in, lift it out.

4. If you have a dual-SIM phone, slide the

3. Slide the SIM card holder to the left and SIM2 holder to the left and open it up.

open it up. Place the nano-SIM in the slot

Nokia 2720 User Guide

Place the nano-SIM in the SIM2 slot face down, close down the holder and slide it to the right to lock it in place. Both SIM cards are available at the same time when the device is not being used,but while one SIM

Insert the memory card

card is active, for example, making a call, the other may be unavailable.

5. Put back the battery.

6. Put back the cover.

1. Remove the back cover.

2. If the battery is in, lift it out.

4. Put back the battery.

5. Put back the cover.

3. Slide the memory card in the memory card

slot.

Switch on your phone

Press and hold the power key until the phone vibrates.

Select which SIM card to use

1. Press the scroll key and select Settings > Network & Connectivity > SIM Manager .

Nokia 2720 User Guide

2. To choose which SIM to use for calls, select Outgoing Calls , and select SIM1 or SIM2 .

3. To choose which SIM to use for messages, select Outgoing Messages , and select SIM1 or

SIM2 .

4. To choose which SIM to use for mobile data, select Data , and select SIM1 or SIM2 .

Tip: To be able to distinguish your SIM cards, give them a descriptive name. In the

SIM Manager settings, select each SIM card, type in the name, and select Save .

CHARGE YOUR PHONE

Your battery has been partially charged at the factory, but you may need to recharge it before you can use your phone.

Charge the battery

1. Plug the charger into a wall outlet.

2. Connect the charger to the phone. When done, unplug the charger from the phone, then

from the wall outlet.

If the battery is completely discharged, it may take several minutes before the charging indicator is displayed.

Tip: You can use USB charging when a wall outlet is not available. Data can be transferred while charging the device. The efficiency of USB charging power varies significantly, and it may take a long time for charging to start and the device to start functioning. Make sure your computer is switched on.

Save power

To save power:

1. Charge wisely: always charge the battery

time.

fully.

5. Lower the screen brightness.

2. Select only the sounds that you need:

mute unnecessary sounds, such as keypad sounds.

6. When applicable, use network connections, such as Bluetooth, selectively: switch the connections on only when you are using

3. Use a wired headset, rather than the

them.

loudspeaker.

7. Turn off Wi-Fi hotspot when internet

4. Change the phone screen settings: set the

sharing is not needed.

phone screen to switch off after a short

Nokia 2720 User Guide

3 Basics

EXPLORE YOUR PHONE

Open the apps list

Press the scroll key.

Open an app or select a feature

Scroll to the app or feature and select SELECT .

Go back to the previous view

Press the back key.

Go back to the home screen

Press the end key.

CHANGE THE VOLUME

Turn the volume up or down

Trouble hearing your phone ringing in noisy environments, or calls too loud? You can change the volume to your liking.

To change the volume during a call, press the volme keys.

To change the volume of your media apps, ringtones, alerts, and alarms, press the scroll key and select Settings . Scroll right to Personalization , and select Sound > Volume .

To change the volume when listening to the radio or music, select Options > Volume .

WRITE TEXT

Writing with the keypad is easy and fun.

Nokia 2720 User Guide

Write using the keypad

Press a key repeatedly until the letter is shown.

To type in a space press 0 .

To type in a special character or punctuation mark, press * .

To switch between character cases, press # repeatedly.

To type in a number, press and hold a number key.

The writing method may vary between applications.

CHANGE THE TEXT SIZE

Make the text bigger

Do you want to read bigger text on the display?

1. Press the scroll key and select Settings .

2. Scroll right to Device , and select Accessibility > Large Text > On .

ACCESSIBILITY MODE

With the accessibility mode, the text on the phone display is bigger, the alerts louder, and the Google Assistant key turns into an SOS call key. If you didn’t switch the accessibility mode on when setting up your phone, press the scroll key to open the apps list, and select Settings >

Device > Accessibility mode > On .

Add your ICE details

To be able to make SOS calls, you need to add your ICE (In Case of Emergency) details. To add your personal details, press the scroll key, and select Settings > Device > ICE information . To define the contacts to whom the SOS call is made, press the scroll key, and select Settings > Device > ICE information > Options > Create ICE contact . Note that you cannot use official emergency call numbers as your ICE contacts.
