Terra® 28B
Walk-Behind Sweeper
Smart cleaning.
A Nilfisk-Advance Brand
Terra® 28B
Superior Pick-up on Hard and Soft Floors.
Walk-Behind Sweeper
Ideal applications include:
Schools and Universities
Hospitals / Healthcare
Commercial Cleaning Facilities
Hotels
Office Buildings
Government Buildings
and Installations
The performance of Advance’s new Terra® 28B walk-behind sweeper leaves
wide-area vacuums in the dust. Its 28 inch wide sweep path handles carpet
with 2.5 times more productivity than a 28 inch wide-area vacuum (ISSA data).
Plus, the Terra 28B’s side broom eliminates the need for edge cleaning after
sweeping. Compact and easy to maneuver for even your smallest operators,
the Terra 28B is rated at just 59 dB A – making it one of the quietest sweepers
in the industry.
The Terra 28B features A.S.A.P. (All Surface All Purpose) sweeping technology.
Sweeping efficiency is maximized as the operator transitions from one floor
type to another without having to change the type of broom. Many times the
transition can also be completed without having to adjust the broom height.
The A.S.A.P. technology is made possible with a unique main broom design
coupled with a well engineered skirting system. The specially designed
main broom contains dual rows of soft and coarse bristles that will pick up
everything from dirt and sand, to paper and plastic pop bottles on carpet and
hard floor. The long-running, maintenance-free gel battery comes standard
on the Terra 28B, while an onboard battery charger allows the operator the
flexibility to plug the sweeper in any place there is an outlet.
The Terra 28B was built with your green cleaning program in mind. The
machine’s extra quiet operation allows daytime cleaning and contributes to
operator safety. The Terra 28B sweeper utilizes a durable polyester panel filter
shaker in the marketplace. Using the filter shaker on a regular basis gives you
the most out of your filter. It minimizes filter changes while maximizing your
indoor air quality. And since the Terra 28B is a bag-less sweeper, there’s no
money spent on bags, or time spent changing them.
One-Touch™ operation, a streamlined design and superior maneuverability
make this sweeper easy for any operator to use. The Terra 28B sweeper
features traction assist for fast and easy sweeping. Tools-free broom removal
and adjustment makes for easy cleaning of the sweeper at the end of an
operator’s shift.
Airports / Train Stations /
Bus Depots
Casinos
Health Clubs
A Nilfisk-Advance Brand
Filter Shaker
Easy, one-hand
operation
Terra® 28B easily cleans both hard and soft floors without having to change brooms.
Adjustable handle folds for easy storage.
Easy to use lever
lowers and raises
Side broom
cleans edges
side broom
Rugged, large capacity
hopper is easy to empty
Adjustable handle for
operator comfort
Broom height is
adjustable
Tools-free removal of brooms and hopper makes for easy maintenance.
Filter shaker easily combs filter for cleaning. A well maintained filter will last for over 100 hours of operation.
Two position, single button operation.
Safety: Operating sound level of 59 dB A meets LEED-EB,
GS-42 and other green-cleaning noise standards.
Sustainability: Machine is standard with maintenance-free
gel battery.
Performance: A.S.A.P. sweeping technology (all surface all
purpose) allows the Terra® 28 to easily transition from hard
to soft floor without having to change brooms.
Air Quality: A durable polyester panel
filter traps dust particles.
FEATURES AND BENEFITS
Technical Specifications
Model Terra® 28B Working Width 28.3 in (72 cm) Main Broom A.S.A.P. (All Surface All Purpose) broom designed for superior performance on all floor types. Length 19.7 in (50 cm) Diameter 7.9 in (20 cm) Speed 335 rpm Side Broom Diameter 12.4 in (31.5 cm) Speed 100 rpm Max Productivity @ 2.5 mph (4 km/hr) 31,200 ft2 (2,900 m2) Hopper Capacity 2.1 ft3 (60 L) Dust Filter Polyester panel filter, 10.8 ft2 (1 m2) Motors Main Broom/Traction 0.3 hp (200 W) Side Broom 0.05 hp (40 W) Vacuum Fan 0.07 hp (50 W) Power Source (1) 12 V, 87 Ah maintenance free gel battery Max Speed 2.5 mph (4 km/hr) Drive System Forward traction system capable of climbing 20% grade Sound Level 59 dB A Machine Weight (with battery) 171 lb (77.5 kg) Battery Charger Standard onboard, 12 V, 6 amp Dimensions Length = 39 in (99 cm) / Width = 31.5 in (80 cm) / Height = 24.4 in (62 cm) Approvals ETL, CSA, CE Part Number 9084702010
Specifications are subject to change without notice.
Terra® 28B
Walk-Behind Sweeper Boosts Productivity with its Ability to Clean Soft and Hard Floors. It Combines All-surface Sweeping and Edge Cleaning.
Standard features:
Maintenance-free Gel Battery
Onboard Charger
Tools-free Removable Broom
Quiet Operation
Mississauga, Ontario, Canada L5T 2L2
Smart cleaning.
Our products are designed using innovative technology that increases productivity and drives down the cost to clean.
Maintain peak performance with Nilfisk Genuine OEM Parts.
©2009 Nilfisk-Advance, Inc. Form L3000A 9-10-09
14600 21st Avenue North
Plymouth, MN 55447-3408
www.advance-us.com
Phone 800-850-5559
Fax 800-989-6566
240 Superior Boulevard
www.nilfisk-advance.com
Phone 800-668-8400
Fax 800-263-5111
