The Ultimate Cleaning Muscle

Nilfisk CFM’s 08 Industrial Vacuum Series delivers long-lasting cleaning power in an
ergonomic design. These robust vacuums are accessible, adaptable, transportable, and
comfortable to operate. Every detail of the 08 Series is engineered to make your job
easier...your operation, more productive.

• Clean for hours at a time without stopping for maintenance.

• Maneuver the vacuum anywhere it’s needed without straining.

• Customize the unit by effortlessly interchanging your
choice of hoses and accessories.

• Efficiently collect a variety of materials, including toxic,
hazardous, and nuisance dust, debris, and liquids.

The reliable 3308-The 3308
quickly removes dirt, debris
and liquids. Its efficient
operation makes daily
cleaning in production areas
and process manufacturing
fast and hassle-free.

The versatile 3508 W-The
3508 W delivers impressive
power and air-flow rate,
enabling it to swiftly collect and
retain a wide range of materials.
It’s also designed for use in
either central systems, process­integration systems, or for
general plant maintenance.

The powerful 3508-Thanks
to its strong suction power,
the 3508 efficiently collects
heavy materials, oil,
emulsions, swarf, solids and
liquids. A large, 26-gallon
collection container also
makes it ideal for a wide
range of accessories.

The high-capacity 3558-

Cleaning large quantities of
dust and flyaway debris is no
problem for the 3558 with its
high filtering capacity and
air-flow rate. Despite its
power, the 3558 is quiet for
worker safety and comfort.

You asked for new features that would help make your
job easier-and we delivered. Each Nilfisk CFM 08 model
includes features that enhance both performance and
usability.

• Tangential Inlet System: Our innovative inlet system pro­vides a more natural, side entrance into the vacuum, which
allows for a better cyclonic effect. The result is maximum
suction power for longer periods of time.

• Modular Construction: All Nilfisk CFM 08 models are
made of durable, high-alloy steel but are also available in
stainless steel.

• Portable Design: Equipped with extra large wheels and a
wrap-around handle, you can push, pull or maneuver your
08 vacuum anywhere with ease.

• Efficient Filtration: Our exclusive filtration system is #1 in
the industry with HEPA and optional ULPA filters that trap
up to 99.999% of all ultra-fine particles. Graduated filtration
technology with oversized main filters and self-cleaning
filter options also eliminate premature clogging and extend
filter life.

• Protective Shield: A tough protection shield after the inlet
allows you to trap abrasive materials, such as glass or
stones, without damaging the inner surface of the vacuum’s
collection container.

• Low Noise Operation: The Nilfisk CFM 08 vacuums are
quieter than ever, with a sound suppressor that reduces the
speed of the exhaust air and muffles the sound for in­creased worker safety and comfort.

• Ergonomic Filter Shaker: Our manual filter shaker handle
allows you to safely purge filters to prevent clogging and
downtime. Simply move the external handle back and forth
to shake filters clean without opening the vacuum. Reverse
purge and electric filter shakers are also available.

Largest Selection of Accessories, Options &
Filters to Support all your Cleaning Needs!

Whether you are collecting fine paint powders in a powder
coating facility, debris in a food plant, or oil and metal chips
in a metalworking environment, we have the range of
options and expertise to create a cleaning solution for you.

Choose from a range of specialized filters for everything
from static control to toxic material collection. Looking for a
specific brush, nozzle, hose, or other attachment? Nilfisk
CFM offers the largest assortment of accessories in the
industry.

Technical Features 3308 3508 3508W 3558

Voltage @ 60 Hz. volts 200-240/440-480 200-240/440-480 200-240/440-480 200-240/440-480

Type of power no. of phases 3 3 3 3

Power KW 2.55 4.8 6.3 6.3

Current draw amps 11.4/6.0 19.0/9.1 25.5/12.5 25.5/12.5

Waterlift, max. inches H2O 145 200 145 145

Airflow, max. cfm 224 230 353 353

Noise level @ 3’3” (1 meter) dB(A) 69 72 73 73

Filter area, main filter sq. ft. 21 21 21 37.7

Filter area, HEPA (upstream) sq. ft. 53.8 53.8 53.8 53.8

Tank capacity gallons 26 26 26 21

Machine inlet inches 3 3 3 3

Dimensions (L x W x H) inches 25.6 x 49.2 x 61.8 25.6 x 49.2 x 61.8 25.6 x 49.2 x 61.8 25.6 x 49.2 x 62.6

Weight lbs. 437 474 485 525

Cord length feet 30 30 30 30

Filter efficiency, HEPA DOP-tested 99.97% @ 0.3 microns 99.97% @ 0.3 microns 99.97% @ 0.3 microns 99.97% @ 0.3 microns

Innovations Inside the 08 Series Vacuum

ergonomic
manual filter
shaker

Easy to remove, wheeled­collection container

Safety filter
housing

manometer

cable
bracket

Optional
ULPA exhaust
filter

Optional Features

• Stainless Steel Filter Chamber, Collection Container and Chassis - allows for easy cleaning and
improved sanitation.

• Wet Shut-Off Kit - protective kit simply mounts inside the filter chamber to automatically shut down
the vacuum during liquid collection if liquid level rises too high.

• Electric Filter Shaker - enhances vacuum performance by oscillating the filter back and forth to
continuously shake the filter clean during operation.

• ABS Container - used in place of collection container for safe disposal of toxic and hazardous
materials.

• Paper Bag Kit - converts collection container to accept paper dust bags.

• Polyliner Adapter Kit - converts collection container to accept polyliners.
