Netgear GS108E, GS105E Data Sheet [it]

Gigabit Ethernet Plus Switches

Control and Congure Beyond
Plug-and-Play Connectivity

Data Sheet

Today’s growing businesses rely more
on their network to carry out mission­critical business activities. Deployment
of VoIP and IP surveillance needs the
network intelligence to separate the
voice and video trafc from data, and
prioritize them accordingly. However,
companies do not necessarily have
more money or advanced training to
deal with complex managed switches.

Highlights

• Enable network conguration and
management at the price point of
Unmanaged Switches

• Gigabit connection delivers up to
2000 Mbps of dedicated, non­ blocking bandwidth per port

• Simple, yet useful network set-up on
top of plug-and-play connectivity

• Flexible management via easy-to-use
web browser-based management GUI
or using the PC-based Utility application

NETGEAR® Plus Switches meet this
growing need by providing funda­mental network features such as VLANs,
QoS, and IGMP Snooping that will help
optimize the performance of business
networks. Plus Switches come in a
variety of congurations ranging from
5 port desktop to 48 port rack mount.

• Auto “denial-of-service” (DoS) prevention

• Troubleshoot connection issues via
cable test

• Loop detection and broadcast storm
controls

• IGMP snooping v1, v2 and v3 support
for multicast optimization

• Rate limiting for better bandwidth
allocation

• Port mirroring for network monitoring

Some models support Power-over­Ethernet (PoE) and can power devices
such as IP phones, IP surveillance
cameras and wireless access points with
just an Ethernet cable; perfect for low
cost PoE deployments. Plus Switches
are the perfect upgrade from the plug­and-play unmanaged switch, delivering
essential networking features at a very
affordable price.

• Jumbo frame support

• Energy Efcient Ethernet (IEEE 802.3az)
support for maxium power savings

• *Limited Lifetime Hardware Warranty
(excludes external power adapters on
applicable models)

• Lifetime 24/7 Chat Technical Support*

• Next-Business-Day Hardware
Replacement*

• Web Interface with multiple language
option

• VLAN support for trafc segmentation

• Quality of Service (QoS) for trafc
prioritization

1

Option only available on the GS108Ev3, GS108PEv3, GS116Ev2, GS750E, JGS516PE, JGS524Ev2, JGS524PE,

GS105Ev2 and GS105PE English, German, and Japanese are the current supported languages.

1

• Link aggregation/port trunking for
bigger uplink bandwidth (16-por t and
24-port models support static manual
LAGs only; GS750E supports static
manual LAGs and LACP)

PAGE 1 of 8

Hardware at a Glance

Data Sheet

Gigabit Ethernet Plus Switches

FRONT REAR INTERNAL

Model
Name

GS105Ev2 Desktop 5 N/A External Power Adapter N/A

GS105PE Desktop 5 2

GS108Ev3 Desktop 8 N/A External Power Adapter N/A

GS108PEv3 Desktop 8 4 External Power Adapter 53W

GS116Ev2 Desktop 16 N/A External Power Adapter N/A

JGS516PE Rack mount 16 8 Internal 85W

JGS524Ev2 Rack mount 24 N/A Internal N/A

JGS524PE Rack mount 24 12 Internal 100W

GS750E Rack mount 48 Copper and 2 SFP N/A Internal N/A

Form-Factor

10/100/1000 Base-T
RJ45 ports

PoE 802.3af Ports Power Supply PoE budget

NO POWER SUPPLY ­must be powered from
another PoE device

Software at a Glance

PoE pass-thru: 19W
with 802.3at/7.9W with

802.3af input power

Management

PC Utility Tool
Web GUI

2

GS116Ev2, JGS516PE, JGS524Ev2, and JGS524PE support static manual LAGs only. GS750E suppor ts st atic manual LAGs and LACP.

IP Multicast

ltering

IGMP Snoop
ing v1, v2
and v3

IEEE 802.3az
Auto-EEE

­Yes

VLANs QoS Port Trunking

Port-based,
IEEE 802.1Q­based VLANs

Port-based,
IEEE 802.1p­based

16-ports and larger Yes Yes

2

Rate
Limiting

Jumbo
Frame
Support

PAGE 2 of 8

Gigabit Ethernet Plus Switches

Features and Benets

Hardware Features

All Gigabit models

PoE offerings in Plus Switches

Desktop and rack mount

††

Software Features

VLAN

QoS

IGMP Snooping For improved network efciency on delivering multicast trafc

Link Aggregation/Port Trunking

2

Port Mirroring For better and quicker network diagnostics and troubleshooting

Cable Test Easily identify bad Ethernet cables

Multiple Language GUI

Making Plus Switch an ideal upgrade for SMB network combining manage
ment capability with higher speed and better performance

With half of the ports capable of supporting PoE, these PoE Plus models
are the most cost-efcient Gigabit Ethernet solution for converaged net
works where PoE support is needed, but isn’t necessary on all ports

Flexibile deployment for either desktop placement, undertable mount, wall
mount as well as rack mount

Segment network into smaller groups for more secure and efcient use of
network resources

For optimized network performance and better delivery of mission-critical
trafc such as voice and video

Build up bigger bandwidth to support aggregated uplink trafc (16-port
and larger models only)

Product documentation and user interfaces are translated, giving you the
ability to select your preferred language (English, German, and Japanese)

Data Sheet

-

-

1

1

Option only available on the GS108Ev3, GS108PEv3, GS116Ev2, GS750E, JGS516PE, JGS524Ev2, JGS524PE, GS105Ev2 and GS105PE. English, German, and Japanese are the

current supported languages.

2

GS116Ev2, JGS516PE, JGS524Ev2, and JGS524PE suppor t static manual L AGs only. GS750E support s static manual LAGs and LACP.

PAGE 3 of 8

Example Application

SMB Network Application

Data Sheet

Gigabit Ethernet Plus Switches

Why the NETGEAR Gigabit Plus Switch is the ideal upgrade from Unmanaged
Switches for SMB networks:

• Congurable with simple set-up

• Build multiple user groups

• Prioritize voice and video trafc

• Monitor and troubleshoot

PAGE 4 of 8

Data Sheet

Gigabit Ethernet Plus Switches

Technical Specications GS105Ev2 GS105PE GS108Ev3 GS108PEv3 GS116Ev2 JGS516PE JGS524Ev2 JGS524PE GS750E

Gigabit ports 5 5 8 8 16 16 24 24 48

Fiber ports 0 0 0 0 0 0 0 0 2 SFP

# of PoE ports N/A 2 N/A 4 N/A 8 N/A 12 N/A

PoE

pass-thru:
19W with

Total PoE power budget (watts) N/A

Max MAC entries 2K 2K 4K 4K 16K 16K 16K 16K 16K

Buffer size 128KB 128KB 192KB 192KB 768KB 768KB 768KB 768KB 1.5MB

Energy Efcient Ethernet (IEEE

802.3az) compliant

Performance Specication

Forwarding modes Store-and-forward

Bandwidth 10Gbps 10Gbps 16Gbps 16Gbps 32Gbps 32Gbps 48Gbps 48Gbps 100Gbps

Priority queuing

Jumbo frame support

Acoustic noise (dB) (ANSI-S10.12) 0 0 0 0 0 24.5 0 24.4 0

Mean Time Between Failures (MTBF)
(hrs)

L2 Services - VLANs

VLAN (# Supported) 64 64 32 32 100 100 100 100 4000

IEEE 802.1Q VLAN Tagging Yes Yes Ye s Yes Yes Ye s Yes Yes Yes

Port-based VLAN Ye s Yes Yes Ye s Yes Yes Yes Yes Ye s

L2 Services - Availability

Link Aggregation/ Port Trunking2 No No No No

Number of Static Manual LAGs and
# of members

L2 Services - Multicast Filtering

IGMP Snooping (v1, v2 and v3) Yes Yes Yes Ye s Yes Yes Yes Yes Ye s

Block unknown Multicast Yes Yes Ye s Yes Yes Yes Ye s Yes Yes

Supported Mulitcast groups 128 128 128 128 64 64 64 64 128

L3 Services - DHCP

DHCP client Yes Yes Ye s Yes Yes Yes Yes Ye s Yes

Yes Yes Ye s Yes Yes Ye s Yes Yes Yes

Up to 9K

packet size

2,531,294 1,685,972 2,525,259 1,242,394 504,993 840,354 243,476 643,506 1,055,076

N/A N/A N/A N/A

802.3at/

7.9W with

802.3af
input

power

Up to 9K

packet size

N/A 53 N/A 85 N/A 100 N/A

Weighted Round Robin (WRR)

Up to 9720

bytes

Up to 9720

bytes

Up to 9K

packet size

Static

Manual

LAGs only

8 LAGs
and 2 to 4
members

Up to 9K

packet size

Static

Manual

LAGs only

8 LAGs
and 2 to 4
members

Up to 9K

packet size

Static

Manual

LAGs only

8 LAGs
and 2 to 4
members

Up to 9K

packet size

Static

Manual

LAGs only

8 LAGs
and 2 to 4
members

Up to 9K

packet size

Static and

LACP

8 LAGs

and 2 to 8

members

2

GS116Ev2, JGS516PE, JGS524Ev2, and JGS524PE suppor t static manual L AGs only. GS750E support s static manual LAGs and LACP.

PAGE 5 of 8

Data Sheet

Gigabit Ethernet Plus Switches

Quality of Service (QoS) GS105Ev2 GS105PE GS108Ev3 GS108PEv3 GS116Ev2 JGS516PE JGS524Ev2 JGS524PE GS750E

Rate limiting Yes Yes Ye s Yes Yes Ye s Yes Yes Yes

DSCP Yes Yes Ye s Yes No No No No Ye s

IEEE 802.1p COS Yes Yes Ye s Yes Yes Ye s Yes Yes Yes

Port-based VLAN Ye s Yes Yes Ye s Yes Yes Yes Yes Ye s

TOS Yes Yes Ye s Yes Yes Ye s Yes Yes Yes

WRR (Weighted Round Robin) Yes Yes Ye s Yes Yes Ye s Yes Yes Yes

Strict Priority Queue Technology No No No No No No No No No

IEEE Network Protocols

• IEEE 802.3 Ethernet

• IEEE 802.3i 10BASE-T

• IEEE 802.3u 100BASE-T

Management

System Password Yes Yes Ye s Yes Yes Ye s Yes Yes Yes

Web browser-based management GUI Yes Ye s Yes Yes Yes Yes Ye s Yes Yes

PC Utility Yes Yes Ye s Yes Yes Ye s Yes Yes Yes

Port Mirroring Yes Yes Yes Yes Ye s Yes Yes Yes Ye s

Multiple Language GUI Yes: English, German, Japanese

Max number of source ports allowed
(many to 1)

Many-to-One Port Mirroring Yes Yes Yes Ye s Yes Yes Ye s Yes Yes

Cable Test utility Yes Yes Ye s Yes Yes Ye s Yes Yes Yes

FW upgrade thru Plus Utility (TFTP) Ye s Yes Yes Yes Ye s Yes Yes Ye s Yes

Cong download (to Switch) thru Plus
Utility

Cong upload (to Server) Yes Yes Ye s Yes Yes Ye s Yes Yes Yes

Miscellaneous Features

Loop Detection Yes Yes Ye s Yes Yes Yes Yes Ye s

DoS Prevention Yes Yes Ye s Yes Yes Ye s Yes Yes Yes

Broadcast Storm Control Yes Ye s Ye s Yes Yes Yes Yes Ye s Yes

Energy Efcient Ethernet (EEE) Yes Yes Ye s Yes Yes Ye s Yes Yes Yes

LEDs

Per port Speed, Link, Activity

Per device Power, Fan and PoE Power Status

4 4 7 7 15 15 23 23 47

Yes Yes Ye s Yes Yes Ye s Yes Yes Yes

• IEEE 802.3ab 1000BASE-T

• IEEE 802.1p Class of Service

• IEEE 802.3af (PoE)

• IEEE 802.1Q VLAN Tagging

• IEEE 802.3x Full-duplex Flow Control

Loop
Prevention

PAGE 6 of 8

Data Sheet

Gigabit Ethernet Plus Switches

Physical Specications GS105Ev2 GS105PE GS108Ev3 GS108PEv3 GS116Ev2 JGS516PE JGS524Ev2 JGS524PE GS750E

Dimensions (mm) 94x100x27 158x100x27 158x101x29 158x101x29 286x101x26 328x170x43 328x170x43 328x170x43 440x204x43

Weight (kg) 0.25 0.47 0.50 0.54 0.84 1.67 1.40 1.84 3.25

Fan 0 0 0 0 0 1 0 1 0

Power Consumption (when all ports used, line-rate trafc and max PoE)

Worst case, all ports used, line-rate
trafc, max PoE (W)

Heat Dissipation Max/Standby
(BTU/hr)

Environmental Specications

Operating

Operating temperature- Switch

Operating temperature- Adapter 32° to 104°F (0° to 40°C)

Humidity 90% maximum relative humidity, non-condensing

Altitude 10,000 ft (3,000 m) maximum

Storage

Storage temperature – 4° to 158°F (–20° to 70°C)

Humidity 95% maximum relative humidity, non-condensing

Altitude 10,000 ft (3,000 m) maximum

Electromagnetic Emissions and Immunity

Certications Class (including but not
limited to CE, FCC Part 15, VCCI, RCM,
KCC, EAC and CCC)

Safety

Certications

Warranty and Support

Switch Warranty

Power Adapter Warranty 2 years 2 years 2 years 2 years

Technical support Lifetime Tech Support* via chat, 90 day tech support via email

Next-Business-Day (NBD)
Replacement

ProSUPPORT OnCall 24x7,
Service Packs

2

2.6 22.0 4.5 60.0 10.0 110.0 13.8 123.0 30

Max: 8.9

Min: 2.2

32° to 122°F

(0° to 50°C)

B B B A A A A A A

CB, CE

LVD, CCC,

EAC

Limited
lifetime

warranty*

Category S01

PMB0S11

(1 yr)

PMB0S31

(3 yr)

PMB0S51

(5 yr)

Max: 6.7
Min: 1.2

32° to 122°F

(0° to 50°C)

CE LVD,

EAC

Limited
lifetime

warranty*

Category S01

PMB0S11

(1 yr)

PMB0S31

(3 yr)

PMB0S51

(5 yr)

Category S01

Max: 15.2

Min: 4.9

32° to 104°F

(0° to 40°C)

CB, CE

LVD, CCC,

EAC

Limited
lifetime

warranty*

PMB0S11

(1 yr)

PMB0S31

(3 yr)

PMB0S51

(5 yr)

Max: 205.2

Min: 3.7

32° to 104°F

(0° to 40°C)

CB, CE

LVD, CCC,

EAC

Limited
lifetime

warranty*

Category S01

PMB0S11

(1 yr)

PMB0S31

(3 yr)

PMB0S51

(5 yr)

Max: 34.2

Min: 13.3

32° to 104°F

(0° to 40°C)

CB, CE
LVD, CCC,

EAC

Limited
lifetime

warranty*

Limited lifetime*

Category S02

PMB0S12

(1 yr)

PMB0S32

(3 yr)

PMB0S52

(5 yr)

Max: 34.2

Min: 14.4

32° to 122°F

(0° to 50°C)

CB, CE

LVD, CCC,

EAC, UL

60950-1

Limited
lifetime

warranty*

Category S02

PMB0S12

(1 yr)

PMB0S32

(3 yr)

PMB0S52

(5 yr)

Max: 47.2

Min: 19.6

32° to 122°F

(0° to 50°C)

CB, CE

LVD, CCC,

EAC, UL

60950-1

Limited
lifetime

warranty*

Category S02

PMB0S12

(1 yr)

PMB0S32

(3 yr)

PMB0S52

(5 yr)

Max: 78.7

Min: 19.8

32° to 122°F

(0° to 50°C)

CB, CE

LVD, CCC,

EAC, UL

60950-1

Limited

lifetime

warranty*

Category S02

PMB0S12

(1 yr)

PMB0S32

(3 yr)

PMB0S52

(5 yr)

Max: 102.7

Min: 38.9

32° to 122°F

(0° to 50°C)

CB, CE

LVD, CCC,

EAC, UL

60950-1

Limited
lifetime

warranty*

Category 1

PMB0311

(1 yr)

PMB0331

(3 yr)

PMB0351

(5 yr)

2

Do not use the se devices outdoors . If you connect cables or devices tha t are outdoors to this devic e, see htt ps: //kb.netgear.com/0 00 057103 for safet y and warrant y inform ation

PAGE 7 of 8

Data Sheet

Gigabit Ethernet Plus Switches

Package Contents

All models

Ordering Information

GS105E JGS516PE

GS105E-200NAS North America and Latin America JGS516PE-100NAS North America and Latin America

GS105E-200PES Europe JGS516PE-100EUS Europe

GS105E-200AUS Australia JGS516PE-100AJS Asia Pacic/Japan

GS105E-200UKS United Kingdom JGS516PE-100PRS China

GS105E-200JPS Japan JGS516PE-100INS India

GS105PE JGS524E

GS105PE-10000S Worldwide JGS524E-200NAS North America and Latin America

GS108E

GS108E-300NAS North America and Latin America JGS524E-200AJS Asia Pacic/Japan

GS108E-300PES Europe JGS524E-200PRS China

GS108E-300AUS Australia

GS108E-300UKS United Kingdom JGS524PE-100NAS North America and Latin America

GS108E-300PRS China JGS524PE-100EUS Europe

GS108E-300INS India JGS524PE-100AJS Asia Pacic/Japan

GS108E-300JPS Japan JGS524PE-100PRS China

GS108PE

GS108PE-300NAS North America and Latin America

GS108PE-300EUS Europe GS750E-100NAS North America and Latin America

GS108PE-300AJS Asia Pacic/Japan GS750E-100EUS Europe

GS108PE-300PRS China GS750E-100AJS Asia Pacic/Japan

GS108PE-300INS India

GS116E

GS116E-200NAS North America and Latin America

GS116E-200PES Europe

GS116E-200AUS Australia

GS116E-200UKS United Kingdom

GS116E-200JPS Japan

GS116E-200PRS China

Plus Switch
Power cordor power adapter (depending on model; GS105PE has no power supply or power cord)
Installation guide
Rack mount kit (JGS516PE, JGS524Ev2, JGS524PE and GS750E only)

JGS524E-200EUS Europe

JGS524PE

JGS524PE-100INS India

GS750E

*

This product comes with a limited warranty that is valid only if purchased from a NETGEAR authorized reseller, and covers unmodied hardware, fans and internal power
supplies – not soft ware or external power supplies, and requires produc t registration at https://www.netgear.com/business/registration within 90 days of purchase; see
https://ww w.netgear.com/about/warranty for det ails. Intended for indoor use only.

**

The NETGEAR OnCall 24x7 contract provides unlimited phone, chat and email technical support for your networking product.

††

Only JGS516PE, JGS524Ev2, JGS524PE, and GS750E are rack mountable.

NETGE AR and the NETGEAR Logo are trademarks of NETGEAR, Inc. in the United States and/or other countries. Other brand names mentioned herein are for identication

purposes only and may be trademarks of their respective holder(s). Information is subject to change without notice. ©NETGEAR, Inc. All Rights reserved.

NETGE AR, Inc. 350 E. Plumeria Drive, San Jose, CA 95134-1911 USA, 1-888- NETGEAR (638- 4327), E-mail: [e-mail], www.NETGEAR.com

DS-PlusSwitches-24Dec20

PAGE 8 of 8
