Netgear AirCard 762S User Guide

Sierra Wireless AirCard 762S Mobile Hotspot
User Guide
4111970
Rev 2
Preface
Important Notice
Safety and Hazards
Due to the nature of wireless communications, transmission and reception of data can never be guaranteed. Data may be delayed, corrupted (i.e., have errors) or be totally lost. Although significant delays or losses of data are rare when wireless devices such as the Sierra Wireless modem are used in a normal manner with a well-constructed network, the Sierra Wireless modem should not be used in situations where failure to transmit or receive data could result in damage of any kind to the user or any other party, including but not limited to personal injury, death, or loss of property. Sierra Wireless accepts no responsibility for damages of any kind resulting from delays or errors in data transmitted or received using the Sierra Wireless modem, or for failure of the Sierra Wireless modem to transmit or receive such data.
Do not operate the Sierra Wireless modem in areas where blasting is in progress, where explosive atmospheres may be present, near medical equipment, near life support equipment, or any equipment which may be susceptible to any form of radio interference. In such areas, the Sierra Wireless modem MUST BE POWERED OFF. The Sierra Wireless modem can transmit signals that could interfere with this equipment.
Do not operate the Sierra Wireless modem in any aircraft, whether the aircraft is on the ground or in flight. In aircraft, the Sierra Wireless modem MUST BE POWERED OFF. When operating, the Sierra Wireless modem can transmit signals that could interfere with various onboard systems.
Limitation of Liability
Note: Some airlines may permit the use of cellular phones while the aircraft is on the ground and the door is open. Sierra Wireless modems may be used at this time.
The driver or operator of any vehicle should not operate the Sierra Wireless modem while in control of a vehicle. Doing so will detract from the driver or operator's control and operation of that vehicle. In some states and provinces, operating such communications devices while in control of a vehicle is an offence.
The information in this manual is subject to change without notice and does not represent a commitment on the part of Sierra Wireless. SIERRA WIRELESS AND ITS AFFILIATES SPECIFICALLY DISCLAIM LIABILITY FOR ANY AND ALL DIRECT, INDIRECT, SPECIAL, GENERAL, INCIDENTAL, CONSEQUENTIAL, PUNITIVE OR EXEMPLARY DAMAGES INCLUDING, BUT NOT LIMITED TO, LOSS OF PROFITS OR REVENUE OR ANTICIPATED PROFITS OR REVENUE ARISING OUT OF THE USE OR INABILITY TO USE ANY SIERRA WIRELESS PRODUCT, EVEN IF SIERRA WIRELESS AND/OR ITS AFFILIATES HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR THEY ARE FORESEEABLE OR FOR CLAIMS BY ANY THIRD PARTY.
Notwithstanding the foregoing, in no event shall Sierra Wireless and/or its affiliates aggregate liability arising under or in connection with the Sierra Wireless product, regardless of the number of events, occurrences, or claims giving rise to liability, be in excess of the price paid by the purchaser for the Sierra Wireless product.
Rev 2 May.12 3
AirCard 762S Mobile Hotspot User Guide
Patents This product may contain technology developed by or for Sierra Wireless Inc. This
product includes technology licensed from QUALCOMM manufactured or sold by Sierra Wireless Inc. or its affiliates under one or more patents licensed from InterDigital Group.
®
. This product is
Copyright © 2012 Sierra Wireless. All rights reserved.
Trademarks AirCard
Watcher and the Sierra Wireless logo are trademarks of Sierra Wireless. Windows Corporation. Macintosh registered in the U.S. and other countries. QUALCOMM trademark of Qualcomm Incorporated. Used under license. Other trademarks are the property of their respective owners.
MiniUPnPd
Copyright (c) 2006-2011, Thomas BERNARD. All rights reserved.
Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:
®
is a registered trademark of Sierra Wireless. Sierra Wireless,
®
and Windows Vista® are registered trademarks of Microsoft
· Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.
· Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution.
· The name of the author may not be used to endorse or promote products derived from this software without specific prior written permission.
®
and Mac OS X® are registered trademarks of Apple Inc.,
®
is a registered
THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS "AS IS" AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT OWNER OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
4 4111970
Contact Information
Sales Desk: Phone: 1-604-232-1488
Hours: 8:00 E-mail: sales@sierrawireless.com
AM to 5:00 PM Pacific Time
Preface
Post: Sierra Wireless
Fax: 1-604-231-1109 Web: www.sierrawireless.com
13811 Wireless Way Richmond, BC Canada V6V 3A4
Consult our website for up-to-date product descriptions, documentation, application notes, firmware upgrades, troubleshooting tips, and press releases:
www.sierrawireless.com
Rev 2 May.12 5
AirCard 762S Mobile Hotspot User Guide
6 4111970
Contents
Get Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Know Your Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Manage your Device and Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Mobile Hotspot Buttons and Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Lock / Unlock all Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
LCD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Power Sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Set Up and Connect to the Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Insert the SIM Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Connect to the Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
AirCard Watcher App for Smartphones and Tablets . . . . . . . . . . . . . . . .19
Homepage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Security Credentials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Use Your Mobile Hotspot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Set Auto Connect and Network Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
View Data Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Select a Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Enable / Disable Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
View / Block Connected Users. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Add a Wireless Device to your Wi-Fi Network . . . . . . . . . . . . . . . . . . . . . . . 25
View Messages / Alerts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Use the GPS Feature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Battery Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Extend Battery Life . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Set Audio Alerts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Change Device Security Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
View Details About Your Mobile Hotspot . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Rev 2 May.12 7
Use the microSD Card to Share Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Before you Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Share or Access Files over Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Recharge the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Update the Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Advanced Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Show Help for Advanced Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Do not Automatically Install Driver for USB Tethering . . . . . . . . . . . . . . . . . 44
Export / Import Router Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Set Display Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Lock or Unlock Device Keys. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
View WAN Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Contents
Set Connection Preferences. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Enable SIM Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Disable SIM Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
View Wi-Fi Status and List of Connected Devices . . . . . . . . . . . . . . . . . . . . 51
Set Wi-Fi Network Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Set Wi-Fi Security Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Set MAC Filter Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Enable Port Forwarding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Enable Port Filtering. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Enable VPN Passthrough. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Enable DMZ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Enable Universal Plug and Play. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Set Router LAN Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Frequently Asked Questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65
Reset the Mobile Hotspot. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Alerts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Rev 2 May.12 8
Contents
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .71
Mechanical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Environmental Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Regulatory and Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73
Notice. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Safety and Hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Regulatory information for EU countries . . . . . . . . . . . . . . . . . . . . . . . . .74
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Rev 2 May.12 9
AirCard 762S Mobile Hotspot User Guide
10 4111970

1: Get Started

LCD screen
Power key
External antenna connector 1
External antenna connector 2
Navigation key
Micro USB connector
WPS button
Flashes when device is powered on
This chapter provides an overview of AirCard® 762S Mobile Hotspot features, and instructions on how to set up your mobile hotspot and connect to the Internet.

Know Your Device

Your mobile hotspot enables you to create a Wi-Fi access point anywhere there is cellular network coverage. You can use that Wi-Fi access point to connect your laptop and other Wi-Fi capable devices to your service provider’s mobile broadband network and connect to the Internet.
You can also use your mobile hotspot in tethered mode by connecting it to your laptop with the USB cable to access the Internet. See
Tethered mode on page 18.
Additional features include:
GPS
Wi-Fi Protected Setup (WPS)
1
Rev 2 May.12 11

Manage your Device and Settings

You can manage your device and change settings using:
Mobile Hotspot Buttons and Keys (see page 12)
The device LCD (see page 13)
AirCard 762S Mobile Hotspot User Guide
The Homepage (see page 19)
AirCard Watcher App for Smartphones and Tablets (see page 19)

Mobile Hotspot Buttons and Keys

The mobile hotspot has a Power key, Navigation key and a WPS button. Press these buttons or keys alone or in combination to activate various functions. Here’s a summary of how to use them.
Button / Key Action Result / Indicates More details
Power
Navigation
WPS Press and hold for 2 seconds Enter WPS mode (used to add
WPS + Navigation Press and hold for 3 seconds Mute / enable audio on the
Press and hold for 2 seconds Power on / off. Press and release Select or save an option when
prompted on the LCD screen. Flashing blue slowly Mobile hotspot is powered on. Flashing blue quickly Firmware is being updated. Do
not disconnect or power down
the mobile hotspot until the
firmware update is complete. Press and release Enter dashboard mode.
Select an option when
prompted on the LCD screen.
Press and hold for 3 seconds Lock / unlock all keys. Provided this feature is
WPS-enabled Wi-Fi devices to
your Wi-Fi network).
mobile hotspot.
Dashboard mode on page 13
enabled on the homepage (See Lock or Unlock Device
Keys on page 47.) Add a Wireless Device to your
Wi-Fi Network on page 25
Set Audio Alerts on page 30
WPS + Power Press and hold for 5 seconds Reset the mobile hotspot to
factory settings.
Reset the Mobile Hotspot on
page 66

Lock / Unlock all Keys

The mobile hotspot’s keys and buttons can be locked to prevent selection of hotspot features when the hotspot buttons or keys are accidentally pressed (for example, when the device is in a bag or pocket).
If this feature is enabled, you can lock / unlock the device keys by pressing the Navigation key (—) for 3 seconds. For information on enabling this feature, see
Lock or Unlock Device Keys on page 47.
12 4111970
Get Started
Mute or Enable Audio
To mute or enable audio:
1. Do one of the following:
· Press and hold the WPS button + Navigation key for 3 seconds.
· Press the Navigation key repeatedly until you see the Alerts LCD screen.
Press the Power key to mute or enable audio alerts.
2. Optional: On the Web UI, you can select the events for which the mobile hotspot will beep. For more information, see Set Audio Alerts on page 30.
LCD
As well as providing setup information (SSID and Wi-Fi Passphrase) the mobile hotspot LCD displays:
Instructions during setup
Status messages such as “Searching for network”, “Connected”, etc.
Status icons (See Icons on the LCD Screen on page 14 for details.)
Data usage information
Network name
Error messages (See Alerts on page 67 for troubleshooting suggestions.)
Dashboard mode
Press and release the Navigation key to cycle through the Dashboard screens.
The information and instructions available on the Dashboard varies depending on your device and your service provider. Information available may include:
Connect information (SSID and Wi-Fi Passphrase) and homepage URL.
From this screen, you can press the Power key to connect the mobile hotspot to your service provider’s mobile broadband network.
WPS (Wi-Fi Protected Setup) — A fast, easy way to connect WPS-enabled devices to your Wi-Fi network
Messages and Alerts
Billing information
Information about the mobile hotspot such as the Wi-Fi network range,
network preference, firmware version, etc.
Rev 2 May.12 13
AirCard 762S Mobile Hotspot User Guide
DNA
SSID: Mokkula-xxxx Wi-Fi Passphrase: 12345678
To conĮŐƵre your hotspot
ŐŽƚŽŚƩƉĚŶĂŵŽŬŬƵůĂ
LTE
Signal strength
Network indicator
GPS
Wi-Fi
Battery
SSID
Wi-Fi Passphrase
Session data usage
Messages and Alerts View at http://dna.mokkula
Status icons
Wi-Fi on/off Number of connected devices
Device homepage Default Admin login is 12345
Home Screen
To enter Dashboard mode and access additional LCD screens, press the Navigation key.
Roaming indicator
Icons on the LCD Screen
The icons on the LCD screen indicate the status of the mobile hotspot.
14 4111970
Icon Indicates
Signal strength The more bars the stronger the RF signal.
No signal See The No Signal icon appears on the LCD screen. on page 65.
Network type A network icon with a black background indicates that service is
available, but the mobile hotspot is not connected to the network. A network icon with a white background indicates that the mobile
hotspot is connected to the network.
Roaming
Messages / Alerts Y ou have messages (from your service provider) or alerts (device status messages) . To view your messages / alerts, go to the homepage
http://dna.mokkula and click the Messages / Alerts icon.
GPS When the GPS icon flashes, the mobile hotspot is trying to obtain a satellite fix or is tracking a location.
Icon Indicates
Wi-Fi users The number beside the Wi-Fi icon shows the number of users (devices) connected to your Wi-Fi network.
Wi-Fi radio is disabled, or device in standby mode. To adjust the standby timer, see Extend Battery Life on page 29. For information on enabling Wi-Fi, see page 65
The Wi-Fi radio is disabled icon appears on the LCD screen.
Battery status Indicates the charge status of the battery. 4 bars — 80 – 100% 1 bar — 10 – 29%
Battery outline (no bars) — 0 – 9% Recharge immediately.
Battery charging
No battery The mobile hotspot is powered on and connected to the AC charger.
Get Started
The battery is charging through a USB connection.
The mobile hotspot is in the charging cradle.

Accessories

Depending on your service provider, the following accessories may be included:
Micro USB cable — Used mainly for recharging the battery, although you can also use it to tether the mobile hotspot to your computer
AC adapter — Used with the USB cable to recharge the battery or to power the mobile hotspot from a wall socket
Charging cradle
Extended battery
Additional accessories are available from
www.sierrawireless.com/wheretobuy/onlinestore/default.aspx.

Power Sources

You can power your mobile hotspot from:
Rechargable battery included with the mobile hotspot
USB port on your computer
Wall socket using the AC adapter and USB cable
Rev 2 May.12 15
AirCard 762S Mobile Hotspot User Guide
Battery
Gold contacts
Default security credentials

Set Up and Connect to the Internet

Insert the SIM Card

Depending on your service provider, the SIM card may already be inserted. If you need to insert it:
1. Slide the SIM card under the cover.
Install the Battery
1. Insert the battery as shown in the illustration. Ensure that the gold contacts on the battery are lined up with the gold contacts on the device.
2. Replace the back cover.
16 4111970
Get Started
Note: Depending on your service provider, the battery may come partially-charged and ready to go. When the battery needs recharging, follow the instructions in Recharge the
Battery on page 37.

Connect to the Internet

Note: Your mobile hotspot does not need to be connected to the computer with the USB cable to connect to the Internet. The USB cable is used mainly for recharging the battery. (If you want to connect to the Internet with the mobile hotspot tethered to the laptop with the USB cable, see Tethered mode on page 18 before connecting for the first time.)
To connect to the Internet:
1. Press and hold the Power key for a few seconds to turn on the mobile hotspot.
The first time you turn on the mobile hotspot, you’ll be asked to select a lan­guage on the LCD. After that, you can change the language on the home­page. (See Select a Language on page 23.)
The mobile hotspot automatically searches for and connects to your service provider’s mobile broadband network. You can also connect to your service provider’s network from the dashboard. See Dashboard mode on page 13.
Note: The LCD screen may go into sleep mode to save power. To wake up the LCD screen, press any button or key.
2. Connect your computer or other device to your Wi-Fi network.
a. On your computer, view the list of available Wi-Fi networks.
b. Select the SSID displayed on the mobile hotspot LCD screen, and
connect to it.
c. When prompted, enter your Wi-Fi Passphrase, as it appears on the
mobile hotspot LCD screen.
3. Launch your browser and go to the homepage http://dna.mokkula.
If SIM security is enabled:
a. SIM security is enabled by default for DNA SIM cards (and may be
enabled for other SIM cards). If SIM security is enabled, enter the Admin Password (default password is 12345) in the pop-up window.
Rev 2 May.12 17
AirCard 762S Mobile Hotspot User Guide
b. Click Submit.
c. Enter your SIM PIN in the next pop-up window.
If you are using a DNA SIM card, the default PIN is 1234.
If you have changed the PIN on your DNA SIM card, or are using a SIM card from another service provider, enter the appropriate PIN.
If you do not know the PIN, contact DNA (if you have changed the PIN on a DNA SIM card and subsequently forgot it) or the company that issued the SIM card (if the SIM card is from another service provider).
By default, SIM security is enabled for DNA SIMs the first time you use your mobile hotspot. It is not required for subsequent use, provided you have pow­ered off the mobile hotspot.
If you want the extra security of having to enter the SIM PIN each time you use your mobile hotspot to access the Internet (after having powered it off), clear the check box beside Disable SIM Security.
d. Click Submit.
4. Optional: Use the menu options on the homepage to customize your SSID,
Admin Password, and other settings.
Tethered mode
The first time you use your mobile hotspot in tethered mode (connected to a computer using the USB cable):
1. Ensure that the mobile hotspot is powered off.
2. Use the USB cable to connect the mobile hotspot to your computer.
The mobile hotspot automatically powers on and installs the necessary driver.
3. Once the driver is installed, you can surf the net or go to the homepage
http://dna.mokkula to customize your mobile hotspot.
18 4111970
Get Started
Status and settings Virtual image of the device Connect / DisconnectPower off
Admin Login
Change Web UI language*
* Changes the homepage language used for the current session. To change the language used for subsequent session as well, and to change the language used on the device LCD, see Select a Language on page 23.

AirCard Watcher App for Smartphones and Tablets

Download the complimentary AirCard Watcher™ app from
www.sierrawireless.com/AirCardApps. Use this app to view
your connection, settings, and data usage from your smartphone or tablet. To manage all hotspot settings, go to the homepage http://dna.mokkula.

Homepage

Your mobile hotspot comes configured, perfectly secure, and ready to use, but if you want to change the security settings, the SSID, and other settings, go to your mobile hotspot’s homepage.
The homepage URL (http://dna.mokkula) is shown on the LCD during setup. You can also find it in the Quick Start Guide that came with your mobile hotspot.
To make changes to the settings on the homepage, you must be logged in as
Administrator (default Admin login is 12345).
Rev 2 May.12 19
AirCard 762S Mobile Hotspot User Guide
You can view some information about the device without being logged in as Administrator, but to view detailed information and to change any settings and use some features, you must be logged in as Administrator.
To log in as Administrator:
1. Place your cursor in the Admin Login field and type 12345 (the default Admin
login).
2. Click Login.
The first time you log in, you will be asked to accept the terms and conditions. Click Agree to accept.
Once you are logged in with the default Admin login, you can view detailed information and change mobile hotspot settings, such as:
Change the SSID, Wi-Fi Passphrase, Admin login, and Wi-Fi encryption
Set autoconnect options
Set GPS options
Use GPS to track or map your location and find nearby amenities
Set battery options
View data usage
Set audio alerts
Change advanced settings such as security settings and router options

Security Credentials

Two passwords are associated with the mobile hotspot:
Wi-Fi Passphrase — Used to connect your computer or other Wi-Fi device to your mobile hotspot network. This character string is unique to your device. It is displayed on the main mobile hotspot LCD screen. If the screen is blank (a power-saving feature), press and release any button or key to wake up the LCD screen. The default Wi-Fi Passphrase is also printed on a label under the battery.
Admin login — Used to log into the homepage as Administrator. You must be logged in as Administrator to use certain features and to make changes to
your mobile hotspot settings. The default Admin login, 12345, is printed on a
label under the battery. The Admin login can be 5–31 characters.
You can change both of these passwords on the homepage, http://dna.mokkula. For more information, see Change Device Security Settings on page 31.
20 4111970

2: Use Your Mobile Hotspot

This chapter provides information on how to use your mobile hotspot.
Note: To change settings you need to be logged in as Administrator. See Set
Up and Connect to the Internet on page 16.

Set Auto Connect and Network Options

By default, the mobile hotspot automatically connects to your service provider’s mobile broadband network. You can change this feature so that the mobile hotspot automatically connects to another network when you are roaming, or never auto connects.
To select the auto connect and network technology options:
1. On the Mobile Hotspot Homepage, log in as Administrator.
2. Click the Signal Strength icon ( ).
2
3. Under Network Technology, select the desired option from the drop-down menu.
Note: For most users, it is best to leave the default setting (All bands). If you choose a network technology that is not available, you will be unable to connect to a mobile broadband network.
4. Under Auto Connect & Roaming, select the desired option:
· Always auto connect — The mobile hotspot automatically
attempts to connect to the mobile broadband network when powered on. You may incur additional roaming charges if you are outside of your service provider’s coverage area.
Rev 2 May.12 21
AirCard 762S Mobile Hotspot User Guide
Data usage
DNA
SSID: Mokkula-xxxx Wi-Fi Passphrase: 12345678
To c onĮŐƵre your hotspot
ŐŽƚŽŚƩƉĚŶĂŵŽŬŬƵůĂ
LTE
Billing Info
Data used from: 2011/06/18 Data transferred: 4.23 MB* Cycle restarts: 2011/07/01
ĂLJƐůĞŌϭϮĚĂLJƐ
(4/5)
* approximate
On the
On the Dashboard:
Press the Navigation key until the Billing Info screen appears.
main screen
(current session)
· Always auto connect except when roaming — The mobile hotspot automati­cally attempts to connect only to your service provider’s mobile broadband network when powered on (default).
· Never auto connect — The mobile hotspot will not attempt to automatically connect to the mobile broadband network when powered on.
If you choose this option, press the Power key and follow the instructions on the LCD screen to connect, or go to the homepage (http://dna.mokkula) and click Connect. See page 16 for more infor­mation.
5. Click Save. (Save button appears once you make a selection.)

View Data Usage

You can view an estimate of your data usage (not accurate for billing purposes) on the homepage and on the LCD screen.
On the LCD screen:
On the homepage:
1. On the Mobile Hotspot Homepage, log in as Administrator.
2. Click the Data icon ( ).
3. From the drop-down list, select the day of the month your billing cycle starts
(typically the first of the month). This information is available on your service provider’s bill.
22 4111970
To reset the data counter manually, click Reset.
Use Your Mobile Hotspot

Select a Language

The first time you power on the mobile hotspot, you can choose the desired language. Press the Navigation key to cycle through the available languages and press the Power key to select a language. The selected language is used for the homepage and the LCD.
To change the language used in the current session only, select the desired language from the drop-down menu in the upper right corner of the homepage.
To change the language used in the current and subsequent sessions:
1. Click the Advanced Setting icon ( ).
2. On the Device Basic page, select the desired language from the drop-down
menu.
3. Click Save. (Save button appears once you make a selection.)

Enable / Disable Wi-Fi

By default, Wi-Fi is enabled, but if your place of business does not allow Wi-Fi or for any reason you want to disable Wi-Fi and use the mobile hotspot only in tethered mode, the mobile hotspot gives you that option.
To enable / disable your Wi-Fi network:
1. On the Mobile Hotspot Homepage, log in as Administrator.
2. Click the Wi-Fi icon ( ).
Rev 2 May.12 23
AirCard 762S Mobile Hotspot User Guide
3. To disable the Wi-Fi radio, beside Enable Wi-Fi, select Off.
4. Click Ok to confirm.

View / Block Connected Users

To view a list of devices connected to your mobile hotspot and block undesired users:
1. On the Mobile Hotspot Homepage, log in as Administrator.
2. Click the Wi-Fi icon( ).
If you notice a user or Wi-Fi device that you do not recognize, you can block that device from connecting to your Wi-Fi network.
To block a user (or device):
1. Select the box beside the device in the Block column.
2. Click Save. (Save button appears once you make a selection.)
24 4111970
Loading...
+ 54 hidden pages
