Nespresso PIXIE C60, PIXIE D60 Instruction Manual

Nespresso, an exclusive sys tem creating the perfect Espre sso, time after time. All Nespresso machines are equipped with a patented extrac tion system that guarantees up to 19 bar pressure. Each parameter has been calculated with great precision to ensure that all the aromas from each Grand Cru can be extracted, to give the coee body and create an exceptionally thick and smooth crema.

CONTENT

Please read the instructions and safety precautions before operating the appliance.

安全预防指引/Safety precautions 4–7 概览/Overview 8 首次使用/First use 9 咖啡制备/Coee preparation 10 节能模式以及水位探测/Energy saving concept and water level detection 11 预设杯量/Programming the water volume 11 如在一段时间机器处于不使用状态或维修之前需做系统清空处理，

以免结霜/Emptying the sys tem before a perio d of non-use and for f rost

protec tion, or before a re pair 12

除垢/Reset to factory settings 12

清洁/Cleaning 12 除钙/Descaling 13–14 故障处理/Troubleshooting 15 规格/Specications 15 联系奈斯派索俱乐部/Contact the Nespresso Club 15 废物处理及环境保护/

Disposal and environmental protection 16

Ecolaboration: ecolaboration.com/

Ecolaboration: ecolaboration.com 16

保修/Warranty 17

奈斯派索，一如既往的制作醇美意式浓缩咖啡的专属系统，所有奈斯派索咖啡机都配备有获得专利保证19巴高压的相关系统。每一个参数都经过精确的测算以保证释放出每一颗优选咖啡的香氛，给咖啡带来完整的主体并创造出极其丰厚且顺滑的油沫。

内容

请在操作前仔细阅读安全须知以及说明书。

C60

D60

使用指南

INSTRUCTION MANUAL 2

使用指南

操作手冊 18

사용 설명서 34

注意：安全预防指引是咖啡机的一部分。首次使用咖啡机前请仔细阅读安全预防指引。并将其保存于您可以找到的地方以便于以后的阅读。

注意：此标志表示需要参考安全预防指引以避免任何伤害和损坏的发生。

提示：此标志表示请根据指

示正确、安全的使用咖啡机。

• 请根据本说明书的指引使用咖

啡机。

• 除指定用途以外，切勿用于其

他用途。

• 咖啡机只适合在室内或温差不

大的环境使用。

• 请勿将机器放在阳光直射的地

方，可以被水溅到的地方及潮湿的地方。

• 本咖啡机是为了家庭使用和类

似的应用而设计，如：商店里的员工餐厅，办公室和其他工作环境，乡村酒店，各类酒店房

间，汽车旅馆，私人驿站环境或其他住宅类型的环境供客人使用。

• 本产品不适合由 8岁或以下儿童使用，除非有人已指导他们如何安全使用本产品、监督他们掌握安全使用方法，同时他们已经意识到相关危险。儿童只有在成年人监督下才可清洁和保养本产品。

• 将本产品和电源线放在 8 岁或以下儿童接触不到的地方。

• 本产品不适合由肢体不健全、感觉和精神上有障碍或缺乏经验和知识的人使用，除非有人已指导他们如何安全使用本产品、监督他们掌握安全使用方法，同时他们已经意识到相关危险。

• 切勿让儿童玩耍本产品。

• 由于任何用于商业用途、非适当处理或使用、或因用作其它用途导致损坏、操作错误、由非专业人士进行维修或不遵守使用说明书操作而导致的本产品的任何损坏，生产商不负责提供保修。

避免发生致命触电及火灾。

• 在紧急情况下：请立即拔下电源插头。

• 仅将咖啡机连接到合适的、方便的且有接地保护的插座上。确保电源的电压与指定的电压相同。使用错误的电源导致的损坏不在保修范围内。

咖啡机只有在安装好后才可以连接电源。

• 避免电源线受到尖锐物体的损坏，同时切勿夹紧或悬挂电源线。

• 保持电源线远离热源和潮湿环境。

• 如果电源线受损，必须送回厂家或服务商或者具有类似认可资质的人来维修。以防止任何安全方面的风险。

• 如果电源线已经受损，切勿使用和操作咖啡机。

• 请把咖啡机送到奈斯派索俱乐部或奈斯派索授权方。

• 如果需要延长电源线，只能选用导体截面至少1.5平方毫米或与电源相匹配的带有接地保护

的导线。

• 为避免严重损坏，切勿把机器放置于散热器、火炉，烤箱，明火炉或类似电器表面。

• 将咖啡机放置在平稳和平整的平面上。该平面必须耐热防水，如咖啡、除垢剂或类似物质。

• 长时间不使用咖啡机请拔下电源插头。断开电源连接时，请拔出插头且不要拉电线，否则电线会被损坏。

• 清洁设备前将电源线拔掉并让咖啡机冷却。

• 不要用湿手触摸电源线。

• 不要把机器全部或部分放在水中或其他液体中。

• 不要把机器全部或部分放在洗碗机内。

• 电和水接触非常危险可能导致致命的触电。

• 不要拆开咖啡机，有触电危险。

• 不要往机器开孔内部放置任何物品。这样做可能会引起火灾或电击。

安全预防指引

在操作机器时避免可能的伤害。

• 切勿让咖啡机在无人看守时运作。

• 设备不能正常工作时请停止使用。立即将电源插头拔下。联系奈斯派索用户俱乐部或授权方进行测试，维修或调整。

• 使用已经损坏的设备可能导致触电，灼伤或火灾。

• 在操作过程中始终关闭手柄。避免烫伤。

• 不要把手指放在咖啡出口下方，避免烫伤。

• 不要把手指放在胶囊轴和胶囊仓内。有受伤危险！

• 胶囊如果没有被内部的刀片刺破，水会从胶囊周围溢出可能损坏机器。

• 不要使用损坏的咖啡胶囊。如果胶囊被堵塞在机器内部，将机器电源关掉并拔掉电源。拨打奈斯派索用户俱乐部或授权方进行咨询。

• 在水箱中注入新鲜的饮用水。

• 如果将长时间不使用机器，应将水箱清空。

• 如果超过一个周末或两天未使用机器，请换掉水箱中剩余的水。

• 不要使用没有滴水盘和金属托盘的设备，以避免液体蔓延到机器周围。

• 不要使用强度大的清洗剂和溶剂清洗机器。用蘸有柔和清洗剂的湿布清洁机器表面。

• 只使用干净的清洁工具清洁机器。

• 打开包装后，请取下塑料薄膜。

• Nespresso咖啡机与Nespresso咖啡粉囊为配套设计，Nespresso咖啡粉囊仅可以从Nespresso会员俱乐部或授权方购买。

• 所有的奈斯派索咖啡机均通过了严格的品质控制。生产商曾按随机抽样的形式在实际应用条件下对机器进行了可靠性测试。所以有些机器会有被用过的痕迹。

• 奈斯派索有权更改本说明书并不作任何通知。

除水垢

• 正确的使用奈斯派索除垢剂可以使机器在整个使用寿命过程中一直呈现给您新机器的性能。请参考奈斯派索除垢剂套装内的使用手册正确进行除垢。

请保存此操作说明并将本操作说明提供给。可以从nespresso.com获得本操作说明的PDF版本。

安全预防指引

SAFETY PRECAUTIONS

CAUTION: the safety precautions are part of the appliance. Read them carefully before using your new appliance for the rst time. Keep them in a place where you can nd and refer to them later on.

CAUTION: when you see this sign, please refer to the safety precautions to avoid possible harm and damage.

INFORMATION: when you see this sign, please take note of the advice for the correct and safe usage of your appliance.

• The appliance is intended to prepare

beverages according to these instructions.

• Do not use the appliance for other

than its intended use.

• This appliance has been designed

for indoor and non-extreme temperature conditions use only.

• Protect the appliance from direct sunlight eect, prolonged water splash and humidity.

• This appliance is intended to be used in households and similar applications only such as: sta kitchen areas in shops, oces and other working environments, farm houses; by clients in hotels, motels and other residential environments; bed and breakfast type environments.

• This appliance may be used by children of at least 8 years of age, as long as they are supervised and have been given instructions about using the appliance safely and are fully aware of the dangers involved. Cleaning and user maintenance shall not be made by children unless they are older than 8 and they are supervised by an adult.

• Keep the appliance and its cord out of reach of children under 8 years of age.

• This appliance may be used by

persons with reduced physical, sensory or mental capabilities, or whose experience or knowledge is not sucient, provided they are supervised or have received instruction to use the appliance safely and understand the dangers.

• Children shall not use the device as a toy.

• The manufacturer accepts no responsibility and the guarantee will not apply for any commercial use, inappropriate handling or use of the appliance, any damage resulting from use for other purposes, faulty operation, non-professionals’ repair or failure to comply with the instructions.

Avoid risk of fatal electric shock and re

• In case of an emergency: immediately remove the plug from the power socket.

• Only plug the appliance into suitable, easily accessible, earthed mains connections. Make sure that

the voltage of the power source is the same as that specied on the rating plate. The use of an incorrect connection voids the guarantee.

The appliance must only be connected after installation

• Do not pull the cord over sharp edges, clamp it or allow it to hang down.

• Keep the cord away from heat and damp.

• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualied persons, in order to avoid all risks.

• If the cord is damaged, do not operate the appliance.

• Return the appliance to the Nespresso Club or to a Nespresso authorized representative.

• If an extension cord is required, use only an earthed cord with a conductor cross-section of at least 1.5 mm

or matching input power.

• To avoid hazardous damage, never place the appliance on or beside hot surfaces such as radiators, stoves,

SAFETY PRECAUTIONS

ovens, gas burners, open ame, or similar.

• Always place it on a horizontal, stable and even surface. The surface must be resistant to heat and uids, like water, coee, descaler or similar.

• Disconnect the appliance from the mains when not in use for a long period. Disconnect by pulling out the plug and not by pulling the cord itself or the cord may become damaged.

• Before cleaning and servicing, remove the plug from the mains socket and let the appliance cool down.

• Never touch the cord with wet hands.

• Never immerse the appliance or part of it in water or other liquid.

• Never put the appliance or part of it in a dishwasher.

• Electricity and water together is dangerous and can lead to fatal electrical shocks.

• Do not open the appliance. Hazardous voltage inside!

• Do not put anything into any openings. Doing so may cause re or electrical shock!

Avoid possible harm when operating the appliance

• Never leave the appliance unattended during operation.

• Do not use the appliance if it is damaged or not operating perfectly. Immediately remove the plug from the power socket. Contact the Nespresso Club or Nespresso authorized representative for examination, repair or adjustment.

• A damaged appliance can cause electrical shocks, burns and re.

• Always completely close the lever and never lift it during operation. Scalding may occur.

• Do not put ngers under coee outlet, risk of scalding.

• Do not put ngers into capsule compartment or the capsule shaft. Danger of injury!

• Water could ow around a capsule when not perforated by the blades and damage the appliance.

• Never use a damaged or deformed capsule. If a capsule is blocked in the capsule compartment, turn the

machine o and unplug it before any operation. Call the Nespresso Club or Nespresso authorized representative.

• Always ll the water tank with cold, fresh drinking water.

• Empty water tank if the appliance will not be used for an extended time (holidays, etc.).

• Replace water in water tank when the appliance is not operated for a weekend or a similar period of time.

• Do not use the appliance without the drip tray and drip grid to avoid spilling any liquid on surrounding surfaces.

• Do not use any strong cleaning agent or solvent cleaner. Use a damp cloth and mild cleaning agent to clean the surface of the appliance.

• To clean machine, use only clean cleaning tools.

• When unpacking the machine, remove the plastic lm and dispose.

• This appliance is designed for Nespresso coee capsules available exclusively through the Nespresso Club or your Nespresso authorized representative.

• All Nespresso appliances pass stringent controls. Reliability tests under practical conditions are performed randomly on selected units. This can show traces of any previous use.

• Nespresso reserves the right to change instructions without prior notice.

Descaling

• Nespresso descaling agent, when used correctly, helps ensure the proper functioning of your machine over its lifetime and that your coee experience is as perfect as the rst day. For the correct amount and procedure to follow, consult the user manual included in the Nespresso descaling kit.

SAVE THESE INSTRUCTIONS Pass them on to any subsequent user. This instruction manual is also available as a PDF at nespresso.com

OVERVIEW

1 滴水盘

Drip tray

2 滴水网格+杯托

Drip grid + cup support

3 可盛装 9 -11咖啡胶囊的胶

囊回收盒

Capsule container for 9–11 used

capsules

4 咖啡出口 Coee outlet

5 咖啡机把手 Lever

6 意式浓缩按键（小杯） Espresso button (small cup)

7 大杯咖啡按键（大杯） Lungo button (large cup)

开/关按键

ON/OFF button

9 水箱盖

Water tank lid

10 水箱 Water tank

包装细目

Packaging content

咖啡机

Coee machine

16颗咖啡套装

16 capsule set

“欢迎加入奈斯派索”文件夹

“Welcome to Nespresso” folder

用户手册

User manual

保修卡

Warranty card

概览

1 2

3 4

5 6 7

Plug the machine into the mains.

Remove the water tank and capsule container. Adjust the cable length and store the excess under the machine.

Remove the plastic lm from the drip grid.

Insert the remaining cable in the cable guide under the machine and put the machine in the upright position.

FIRST USE

The water tank can be carried by its cover.

Place a container under coee outlet and press the Lungo button to rinse the machine. Repeat three times.

Rinse the water tank before lling with potable water.

Switch the machine on. Blinking light of both coee buttons and the capsule container: heating up for approximately 25 seconds. Steady light: ready.

首先请仔细阅读安全须知以避免致命的电击和起火/

First read the safety precautions to avoid

risks of fatal electrical shock and re

将电源线插入电源插座。

取下水箱以及胶囊盛装盒，调整电源线长度，并将多余的线留在机器下面。

揭开接水盘上面的塑料保护膜。

将电源线从电源线出口拉出，将机器放直立。

首次使用

水箱盖子可以帮助您移动水箱。

在咖啡出水口放置一个容器，点大杯按键冲洗咖啡机。重复 3次。

在加入饮用水前请先灌入清水冲洗。

打开机器电源。机器咖啡按键以及卡胶囊盛装盒的灯光闪烁；大约需25秒时间预热。按键停止闪烁；就绪。

6 7

3 4

For a Latte Macchiato glass fold the cup support into the upright position. It will automatically fall down again when removing the glass to avoid any drips falling on to your kitchen surfaces.

Take the cup. Lift and close the lever to eject the capsule into the used capsule container.

During heat up, you can press the coee button when it’s still blinking. The coee will then ow automatically when the machine is ready.

Press the Espresso (40 ml) or the Lungo (110 ml) button. Preparation will stop automatically. To stop the coee ow or top up your coee, press again.

Switch the machine on. Blinking light: heating up for approximately 2 5 seconds. Steady light: ready.

Close the lever and place a cup under the coee outlet.

COFFEE PREPARATION

Rinse then ll the water tank with potable water. The water tank can be carried by its cover.

Lift the lever completely and insert the capsule.

在咖啡制作过程中请不要将咖啡机把手打开以免造成危

险/Never lift lever during operation and refer to the safety precautions

to avoid possible harm when operating the appliance

如需放置拿铁玛琪朵杯请将机器杯托抬起放置为直立状态。当您将杯子拿走时，杯托会自动落回最初位置以免水滴掉落在您的厨房内。

将咖啡拿走，开关咖啡机把手将咖啡自动掉入咖啡胶囊储藏盒。

在预热闪烁期间按咖啡按键。咖啡将会在机器就绪后自动出水。

按意式浓缩按键(40 ml)或者大杯按键(110 ml)，咖啡制作将自动停止。您可以就此停止咖啡制备或者按按键继续制作。

打开机器。按键闪烁，大约需 25秒时间预热。按键停止闪烁；就绪。

放下把手在咖啡出口下放置咖啡杯。

咖啡制备

将水箱灌入饮用水。水箱盖子可以帮助您移动水箱。

打开咖啡把手放入奈斯派索咖啡胶囊。

1 2 3 4

PROGRAMMING THE WATER VOLUME

Press and hold the Espresso or Lungo button.

Release the but ton once the desired volume is served.

ENERGY SAVING CONCEPT AND WATER LEVEL DETECTION

To save energy, switch the machine o when not in use. Automatic power o: the machine will stop automatically af ter 9 minutes of non use.

To increase automatic power o from 9 to 30 minutes: switch the machine o, press the Espresso and Lungo buttons simultaneously then press the ON/OFF button.

Water volume level is now store d.

Red backlight lights up: water tank is empt y. Rell the water tank with potable water. Empty and rinse the used capsule container and the drip tray.

Fill the water tank and insert the capsule.

预设杯量

持续按住小杯或大杯键。

当到达适合后松手设置被保存。

节能模式以及水位探测

为了节省能源，请在不使用的状态下关闭机器。自动关机；机器将在9 分钟不使用后自动关机。

可以将自动关机时间从 9分钟更改至30分钟，请将机器关闭，同时按住意式浓缩咖啡或大杯键然后按开/关机按键。

水量已经被保存。

加水并放入咖啡胶囊。

红色后灯亮起：水箱空，请加入饮用水，排空并冲洗咖啡胶囊盒以及滴水盘。

1 2 3 4

1 2 1

EMPTYING THE SYSTEM BEFORE A PERIOD OF NONUSE, FOR FROST PROTECTION OR BEFORE A REPAIR

Switch the machine o.

Machine switches o automatically.

CLEANINGRESET TO FACTORY SETTINGS

Switch the machine o.

Press and hold the Lungo button and switch the machine on.

Press and hold the Espresso button and s witch the machine on. Wait until no more water comes out.

Remove the water tank. Close the Lever. Place a container under the coee outlet.

To assemble the cup support and the drip tray: take o the grid, place them side by side and clip the drip tray to the cup suppor t.

Clean the coee outlet regularly with a damp cloth.

Espresso cup: 40 ml; Lungo cup: 110 ml.

Do not use any strong cleaning agent or

solvent cleaner. Do not put in a dishwasher.

请勿把机器部件其侵入水

中/

Never immerse the appliance or

part of it in water.

如在一段时间机器处于不使用状态货维修之前需做系统清空处理，以免结霜

关机。

机器自动关机。

清洗除垢

关机。

按住大杯键并同时开机。

按住小杯键并同时开机。等待没有水再流出。

移开水箱，关闭机器把手。将一个容器置放在咖啡出口。

组装（分拆）杯架子和滴水盘，把他们边对边垂直对齐把滴水盘查入锁扣内。

咖啡出口经常用湿布擦拭。

小意式浓缩咖啡 40 ml。大杯咖

啡110 m l。

请不要使用任何强烈的清洗剂或溶剂清洗。请勿放入清洗剂。

1 2 3 4

5 6 7 8

DESCALING

Empty the drip tray and the used capsule con taine r.

Fill the water tank with 0.5 L of water and add the Nespresso descaling liquid.

Place a container (minimum volume: 0.6 L) under the coee outlet.

Remove the capsule and close the lever.

Switch the machine on.

Press both coee buttons simultaneously for three seconds. They will start blinking.

Blinking light: heating up. Steady light: ready.

Press the Lungo button and wait until the water tank is empty.

大约需要15分钟的时间/Duration approximately 15 minutes

请在做咖啡除钙之前阅读安全须知并参照使用频率说明（请见14页）/ Read the safety

precautions on the descaling package and refer to the table for the frequency of use (see page 14)

除碱

到空接水盒将胶囊储藏盒放回原位。

将咖啡机水箱加水至0. 5L并加入奈斯派索清洗剂液体。

在咖啡出水口置放一个容器（最小容量0.6 L)。

让胶囊落入垃圾筐并关闭咖啡机把手。

打开咖啡机。

同时按住两个咖啡按键3秒。两个按键会开始闪烁。

按键闪烁；开始预热。按键不闪；准备就绪。

按下大杯按键并等待水箱排空。

1000

2000

4000

CaCO

360 mg/l

180 m g/l

0 mg/l

CaCO

9 10 11 12

Water hardness: Descale af ter:

French grade

German grade

calcium carbonate

Nespresso descaling kit: Ref. 3035/CBU-2

CAUTION

The descaling solution can be harmful. Avoid contact with eyes, skin and surfaces. We recommend the Nespresso descaling kit available from the Nespresso Club as it is specically adapted to your machine. Do not use other products (such as vinegar) that would aect the taste of the coee.

The following table will indicate the descaling frequency required for the optimum performance of your machine, based on water hardness. For any additional questions you may have regarding descaling, please contact your Nespresso Club.

Rell the water tank with the used descaling solution collec ted in the container and repeat step 8.

To exit the descaling mode, press both buttons simultaneously f or one second. The machine is now ready for use.

Empty and rinse the water tank. Fill it with potable water. When ready, press the Lungo button to rinse

machine.

水硬度除碱之后

法国度

德国度

碳酸钙

奈斯派索除钙剂：3035/CBU-2

注意除碱剂可能会有带来伤害，请避免与眼睛，皮肤等表面接触。我们建议您可以在奈斯派索俱乐部找到适合您机器的专用清洗剂。请不要使用其它溶剂（例如醋）那样会影响咖啡的口味。下表向您提供了咖啡机除碱频率的建议，除碱情况将视水的硬度而定。如关于除碱方面有任何问题，请联系奈斯派索俱乐部。

用使用过的除钙剂再次灌满水箱并重复步骤 8。

退出除碱模式，同时按下两个按键并按住几秒，机器将可以正常使用。

排空并冲洗水箱，加入饮用水。当准备就绪，按下大杯按键冲洗

机器。

杯子, Cups (40 ml)

TROUBLESHOOTING

SPECIFICATIONS

No light.

➔ The machine has switched o automatically; press ON/OFF button. ➔ Check the mains: plug, voltage, fuse.

No coee, no water.

➔ Check the water tank, if empty, ll with potable water. Descale it if necessar y. ➔ Lift the lever. Press one coee button and wait until water comes out.

Coee is not hot enough.

➔ Preheat cup. Descale the machine if necessar y.

The lever cannot be closed completely.

➔ Empty the capsule container/Check that there is not a capsule blocked inside the machine.

Leakage or unusual coee ow.

➔ Check that the water tank is in position.

Lights ash irregularly.

➔ Call the Nespresso Club. ➔ Exit descaling procedure (see paragraph on descaling).

No coee, water just comes out (despite inserted capsule).

➔ In case of diculties, call the Nespresso Club.

Machine switches itself o.

➔ To save energy the machine will turn itself o after 9 minutes of non use. See paragraph on «Energy

saving concept».

Front light is red.

➔ Water tank is empty or ne eds to be cleaned.

CONTACT THE NESPRESSO CLUB

For any additional information, in case of problems or simply to seek advise, call the Nespresso Club. Contac t details of the Nespresso Club can be found in the «Welcome to Nespresso» folder in your machine box or at nespresso.com

220 V, 50 Hz, < 1150 W

220-240 V, 50-60 Hz, < 1260 W

max

最高. 19 巴/19 bar

~ 3 千克/~ 3 kg

0.7 升/0.7 L

11.1 厘米/cm 23.5 厘米/cm

32.6 厘米/cm

故障处理/

规格/

联系奈斯派索俱乐部/

如有任何问题，或者想寻求建议，请致电奈斯派索俱乐部。具体联系方式请参见机器包装内的“ 奈斯派索欢迎 ”文件夹或者登陆 www.nespresso.com

没有亮灯。

➔ 咖啡机自动关闭。请按开/关机按键。 ➔ 主要检查：电源，电压，保险。

不出咖啡，不出水。

➔ 检查水箱，如果已经空了，请加入饮用水。如需要请做清洁除钙，打开机

器把手。

➔ 按下任意咖啡按键直到出水。

咖啡不够热。

➔ 预热咖啡杯。在需要的时候为机器除钙。咖啡机把手不能完全关闭。

➔ 排空咖啡/检查是否有咖啡胶囊。

漏水或正常咖啡流出。

➔ 检查水箱是否置放到位。灯不规则闪烁。

➔ 致电奈斯派索俱乐部。

➔ 退出除碱流程（参阅除碱说明）。

没有咖啡，只有水流出（尽管已放置胶囊）。

➔ 如有任何困难，请致电奈斯派索俱乐部。

机器自动关机。

➔ 为了节省能源机器将会在没有使用9分钟之后自动关机。请参阅“节能

信息”。

前灯变红。

➔ 水箱空或需要清洗。

+ 33 hidden pages

Nespresso PIXIE C60, PIXIE D60 Instruction Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
