XV29 Plus
©
MultiSync
MultiSync© XV29 Plus
MultiSync
Multimedia Monitor
User's Manual
©
NEC Technologies
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER. NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
This symbol warns the user that uninsulated voltage within the unit may
have sufficient magnitude to cause electric shock. Therefore, it is dangerous to make any kind of contact with any part inside of this unit.
This symbol alerts the user that important literature concerning the operation and maintenance of this unit has been included. Therefore, it should
be read carefully in order to avoid any problems.
WARNING
TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO
RAIN OR MOISTURE. ALSO DO NOT USE THIS UNIT'S POLARIZED PLUG
WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUTLETS, UNLESS
THE PRONGS CAN BE FULLY INSERTED. REFRAIN FROM OPENING THE
CABINET AS THERE ARE HIGH-VOLTAGE COMPONENTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
DOC compliance Notice
This Class A digital apparatus meets all requirements of the Canadian
Interference-Causing Equipment Regulations.
WARNING
This equipment has been tested and found to comply with the limits for
a Class A digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
Warnings and Safety Precaution
The NEC MultiSync Multimedia monitor XV29 Plus is designed and manufactured to provide long, trouble-free service. No maintenance other
than cleaning is required. Use a soft cloth and if necessary, mild detergent. Do not use commercial spray cleaners which may damage the
surface. In case of damage, arrange for repairs at an authorized NEC
Service Center.
For operating safety and to avoid damage to the unit, read carefully
and observe the following instructions.
To avoid shock and fire hazards:
1. Provide adequate space for ventilation to avoid internal heat buildup. Do not cover rear vents or install in a closed cabinet or shelves.
A cabinet or shelves in which the unit is placed must be maintained
below
40°C.
2. Do not use the power cord polarized plug with extension cords or
outlets unless the prongs can be completely inserted.
3. Do not expose unit to rain or moisture.
4. Avoid damage to the power cord, and do not attempt to modify the
power cord.
5. Unplug unit during electrical storms or if unit will not be used over a
long period.
6. Do not open the cabinet which has potentially dangerous high voltage components inside. If the unit is damaged in this way the warranty will be void. Moreover, there is a serious risk of electric shock.
7. Do not attempt to service or repair the unit. NEC is not liable for any
bodily harm or damage caused if unqualified persons attempt service or open the back cover. Refer all service to authorized NEC Service Centers.
To avoid damage and prolong operating life:
1. Use only with 120V/220-240V 50/60Hz AC power supply. Continued
operation at line voltages other than 120V/220-240 Volts
AC will
shorten the life of the unit, and might even cause a fire hazard.
2. Handle the unit carefully when moving and do not drop.
3. Locate set away from heat, excessive dust, and direct sunlight.
4. Protect the inside of the unit from liquids and small metal objects. In
case of accident, unplug the unit and have it serviced by an authorized NEC Service Center.
5. Unplug unit before cleaning. Use only a soft cloth and mild detergent.
Commercial household sprays and cleaners may damage the CRT
surface and cabinet.
6. Stacking of units, one top of another, may result in damage to the
units. Stacking is not recommended.
ATTENTION
RISQUE D’ELECTROCUTION
NE PAS OUVRIR
MISE EN GARDE: AFIN DE REDUIRE LES RISQUES D’ELECTRO-
AFIN DE REDUIRE LES RISQUES D’INCENDIE OU D’ELECTROCUTION, NE PAS
EXPOSER CET APPAREIL A LA PLUIE OU A L’HUMIDITE. AUSSI, NE PAS
UTILISER LA FICHE POLARISEE AVEC UN PROLONGATEUR OU UNE AUTRE
PRISE DE COURANT SAUF SI CES LAMES PEUVENT ETRE INSEREES A FOND.
NE PAS OUVRIR LE COFFRET, DES COMPOSANTS HAUTE TENSION SE
TROUVENT A L’INTERIEUR. LAISSER A UN PERSONNEL QUALIFIE LE SOIN DE
REPARER CET APPAREIL.
CUTION, NE PAS DEPOSER LE COUVERCLE, IL
N’Y A AUCUNE PIECE UTILISABLE A L’INTERIEUR
DE CET APPAREIL. NE CONFIER LES TRAVAUX
D’ENTRETIEN QU’A UN PERSONNEL QUALIFIE.
Ce symbole a pour but de prévenir l’utilisateur de la présence
d’une tension dangereuse, non isolée se trouvant à l’intérieur de
l’appareil. Elle est d’une intensité suffisante pour constituer un
risque d’électrocution. Eviter le contact avec les pièces à
l’intérieur de cet appareil.
Ce symbole a pour but de prévenir l’utilisateur de la présence
d’importantes instructions concernant l’entretien et le
fonctionnement de cet appareil. Par conséquent, elles doivent
être lues attentivement afin d’éviter des problèmes.
AVERTISSEMENT
DOC avis de conformation
Cet appareil numérigue de la classe A respecte toutes les exigences du
Réglement sur le Matériel Brouilleur du Canada.
Mises en garde et précautions de sécurité
Le moniteur MultiSync Multimédia XV29 Plus de NEC est conçu et fabriqué
pour assurer une longue durée de service sans problèmes. Aucun entretien
à l’exception du nettoyage n’est nécessaire. Utiliser un chiffon doux et un
détergent doux, si nécessaire. Ne pas utiliser des aérosols de nettoyage du
commerce qui risquent d’endommager la surface de cet appareil. Si
l’appareil est endommagé, confier les travaux de réparation à un centre
de service agréé NEC.
Pour un fonctionnement sûr et afin d’éviter d’endommager l’appareil, lire
attentivement et respecter les instructions suivantes.
Afin d’éviter tout risque d’électrocution et d’incendie:
1. Réserver un espace libre suffisant pour la ventilation afin d’éviter une
accumulation de chaleur interne. Ne pas couvrir les trous d’aération
arrière ou installer l’appareil dans un coffret fermé ou sur une étagère.
Si l’appareil est posé sur un coffret ou une étagère, la température doit
être maintenue en dessous de 40°C.
2. Ne pas utiliser la fiche polarisée du cordon d’alimentation avec des
prolongateurs ou des prises de courant, sauf si les lames peuvent être
insérées à fond.
3. Ne pas exposer à la pluie ou à l’humidité.
4. Eviter d’endommager le cordon d’alimentation, et ne pas modifier le
cordon d’alimentation.
5. Débrancher l’appareil pendant les tempêtes ou si l’appareil n’est pas
utilisé pendant une longue période.
6. Ne pas ouvrir le coffret. Des composants de haute tension se trouvent à
l’intérieur. Si l’appareil est endommagé de cette manière, la garantie
devient caduque. De plus, il y a risque d’électrocution.
7. Ne pas essayer de réparer ou entretenir l’appareil soi-même. NEC ne saura
être tenu pour responsable pour toute blessure ou dommage causé par
des personnes non qualifiées qui essayent de réparer ou d’ouvrir le
couvercle arrière. Confier toute réparation à un centre de service agréé
NEC.
Pour éviter des dommages et prolonger la durée de service de l’appareil:
1. N’utiliser qu’une source d’alimentation de 120 V/220-240V 50/60 Hz CA. Le
fait d’utiliser l’appareil en continu à des tensions de ligne supérieures à 120/
220-240 Volts CA réduit sa durée de vie et risque de provoquer un
incendie.
2. Manipuler l’appareil avec soin pendant son déplacement et ne pas le
faire tomber.
3.
Eloigner l’appareil des endroits chauds, très poussiéreux et exposés en plein soleil.
4. Eviter que des liquides et des petits objets métalliques pénètrent à
l’intérieur de l’appareil. En cas d’accident, débrancher l’appareil et le
confier à un centre de service agréé NEC.
5. Débrancher l’appareil avant le nettoyage. Utiliser seulement un chiffon
doux et un détergent doux.
Des aérosols et produits de nettoyage disponibles dans le commerce
risquent d’endommager l’écran et le coffret.
6.Ne pas empiler les unités les unes sur les autres, afin
endommager.
d’éviter de les
LIMITED WARRANTY
NEC Multimedia Monitor Products
NEC Technologies, Inc.(hereafter NECTECH)warrants this product to be free from
defects in material and workmanship under the following terms.
HOW LONG IS THE WARRANTY
Parts and labor are warranted for (1) One Year and CRT’s for (1) One year from the
date of the first customer purchase.
WHO IS PROTECTED
This warranty may be enforced only by the first purchaser.
WHAT IS COVERED AND WHAT IS NOT COVERED
Except as specified below, this warranty covers all defects in material or
workmanship in this product. The following are not covered by the warranty:
1. Any product which is not distributed in the U.S.A. Canada, and Mexico by
NECTECH or which is not purchased in the U.S.A. Canada, and Mexico from an
authorized NECTECH dealer.
If you are uncertain as to whether a dealer is authorized, please contact NECTECH
at 800-836-0655. Any questions or problems you have with our XP29Plus/
XM29Plus, contact NECTECH at 800-836-0655.
2. Any product on which the serial number has been defaced, modified or removed.
3. Damage, deterioration or malfunction resulting from:
• Accident, misuse, abuse, neglect, fire, water, lightning or other acts of nature,
unauthorized product modification, or failure to follow instructions supplied with
the product.
•Repair or attempted repair by anyone not authorized by NECTECH.
•Any shipment of the product (claims must be presented to the carrier).
•Removal or installation of the product.
•Any other cause which does not relate to a product defect.
•Burns or residual images upon the phosphor of the tubes.
4. Cartons, carrying cases, batteries, external cabinets, magnetic tapes, or any
accessories used in connection with the product.
WHAT WE WILL PAY FOR AND WHAT WE WILL NOT PAY FOR
We will pay labor and material expenses for covered items, but we will not pay for the
following:
1. Removal or installation charges.
2. Costs of initial technical adjustments(set-up), including adjustment of user
controls. These costs are the responsibility of the NECTECH dealer from whom the
product was purchased.
3. Payment of shipping charges.
HOW YOU CAN GET WARRANTY SERVICE
1. To obtain service on your product, consult the dealer from whom you purchased the
product, or ship it prepaid to any authorized NECTECH service center.
2. Whenever warranty service is required, the original dated invoice (or a copy) must
be presented as proof of warranty coverage, and should be included in any shipment
of the product. Please also include in any mailing, your name, address and a
description of the problem(s). Failure to comply with NECTECH Service
Procedures may cause a delay in repairing the unit.
3. For the name of the nearest NECTECH authorized service center, call NECTECH
at 800-836-0655.
LIMITATION OF IMPLIED WARRANTIES
All implied warranties, including warranties of merchantability and fitness for a
particular purpose, are limited in duration to the length of this warranty.
EXCLUSION OF DAMAGES
NECTECH’s liability for any defective product is limited to the repair or replacement
of the product at our option. NECTECH shall not be liable for:
1. Damage to other property caused by any defects in this product, damages based
upon inconvenience, loss of use of the product, loss of time, commercial loss; or
2. Any other damages whether incidental, consequential or otherwise. Some states do
not allow limitation on how long an implied warranty lasts and/or do not allow the
exclusion or limitation of incidental or consequential damages, so the above
limitations and exclusions may not apply to you.
HOW STATE LAW RELATES TO THE WARRANTY
This warranty gives you specific legal rights, and you may also have other rights
which vary from state to state.
FOR MORE INFORMATION, TELEPHONE 800-836-0655
NEC TECHNOLOGIES, INC.
1250 N. Arlington Heights Road, Suite 500
Itasca. Illinois 60143-1248
NOTE: All products returned to NECTECH for service MUST have prior approval.
To get approval, call NEC Technologies at 800-836-0655.
CONTENTS
1. Introduction
Introduction to the MultiSync XV29 Plus ................................................................................. 1
Feature Highlights ...................................................................................................................... 1
2. Part Names and Functions
Front View / Rear View ............................................................................................................. 3
Terminal Board ........................................................................................................................... 5
Remote Control Unit ................................................................................................................. 7
Battery Installation and Replacement / Remote Control Cautions / Operating Range ................
Functions of DIP SW ................................................................................................................. 13
3. Installation
Wiring Diagram ........................................................................................................................ 15
Connecting Your PC or Macintosh Computer .................................................................... 17
Connecting Your VCR or Laser Disc Player .......................................................................... 18
Connecting Your Document Camera.................................................................................. 18
D-Sub 15 Pin RGB Signal Composition .................................................................................. 19
4. Operation
Power/General Controls/Degaussing ................................................................................... 21
Using OSM Controls ................................................................................................................. 22
Direct Control Screen ............................................................................................................. 23
Accessing OSM........................................................................................................................ 26
OSM Menus .............................................................................................................................. 26
11
Visual Controls Group ............................................................................................................. 26
H-position/H-width/Pin-cushion Controls Group .................................................................. 27
V-position/V-height/V-linearity Controls Group ................................................................... 27
Keystone/Tilt/Rotation/Scan Select Controls Group ........................................................... 28
RGB Controls Group ................................................................................................................29
OSM Location/OSM Turn Off Time Control ........................................................................... 29
Source Information .................................................................................................................. 30
Volume Control ....................................................................................................................... 31
Reset Control ........................................................................................................................... 31
OSM System Control Menu .................................................................................................... 33
5. Troubleshooting ............................................................................................................. 37
6. Specifications ................................................................................................................ 39
7. Timing Charts
Input Signal Reference Chart ................................................................................................ 45
Typical Input Signal Timing ..................................................................................................... 49
Signal Identification for Raster Preset .................................................................................... 53
8. Service and Support ..................................................................................................... 55
OSM and IPM are trademarks of NEC Technologies, Inc.
IBM PC/AT, PS/2, VGA, S-VGA, 8514/A and XGA are registered
trademarks of International Business Machines Corporation.
Apple and Macintosh are registered trademarks of Apple Computer,
Inc.
Microsoft is a registered trademark of Microsoft Corporation. Windows is
a trademark of Microsoft Corporation.
Introduction
Introduction to the MultiSync XV29 Plus Monitor
This section introduces you to your new MultiSync XV29 Plus monitor,
provides a list of materials that comes with your monitor and describes
the features and controls.
The features you’ll enjoy include:
•Simple controls
Let you make all necessary adjustments and selections with one
button simplicity from the remote control.
•29” CRT(27” viewable image size)
• True displayable 8002600 resolution
• On-screen menus
Plain English and clear instructions with graphic icons show you
1
exactly how to adjust your screen image.
• Flexible inputs
Connect up to four different inputs at once and switch among them
with a touch of a button to seamlessly integrate information from a
computer and VCR into one presentation.
• Attractive cabinets
A sleek, sophisticated cabinet design complements your
presentation environment and enhances the professionalism of your
presentations.
• Microsoft Plug and Play compatibility
The only monitors in their class to include this standard that
automatically optimizes display settings.
• Supports most IBM VGA, S-VGA, XGA, Macintosh or any other RGB
signals within a horizontal frequency range or 15.5 to 50 kHz and a
vertical frequency range of 55 to 90 Hz. This includes NTSC, PAL,
SECAM, and M-NTSC standard video signals.
• The supplied RGB cable allows hookup to IBM-PC compatible directly.
• Front bezel controls
• Power supply at 120/22-240 Vac
Contents of the Package
The following lists all of the items included in your MultiSync multimedia
monitor package. Please save the original box and packing materials
for future transportation or shipment of this monitor.
1. MultiSync XV29 Plus (XV-2940) multimedia monitor
2. Power cord
3. Wireless remote control unit and two AA batteries
4. RGB (15-Pin Mini D-Sub To 15-pin Mini D-Sub Connector)
5. User' s manual
6. Quick set up card
7. Registration card : Please fill out and return the registration card as
soon as possible.
RGB2 VIDEO2SL (MONO) R
POWER
ON
OFFDEGAUSS
RGB 2RGB 1VIDEO 2VIDEO 1
POSITION/CONTROL PROCEED
EXIT
SCAN
NORMALSIDE PINHEIGHTWIDTH
NORMAL
BRIGHT
CONTRAST
MUTE
VOLUME
MULTIMEDIA MONITOR
RD-346E
79645721
POWER
POWER
/STANDBY
SOURCE SELECTVOLUME
PROCEED EXIT
AUDIO
2
Part Names and Functions
3
RGB2 VIDEO2SL (MONO) R
AUDIO
PROCEED EXIT
RGB2 VIDEO2SL (MONO) R
Rear ViewFront View
11
12345678910
POWER
POWER
/STANDBY
SOURCE SELECTVOLUME
AC-IN
VIDEO1
L
AUDIO1
R
(
)
MONO
IN
L
RGB
R
(
)
MONO
AUDIO IN
RGB1
MONITOR
R
L
OUT
DIP SW
ON
1
2
POWER
POWER
/STANDBY
SOURCE SELECTVOLUME
PROCEED EXIT
AUDIO
3
456
Terminal Board
1 POWER
Press to turn the main power on and off when the AC power is supplied.
2 POWER/STANDBY
When this indicator is green, the monitor is on; when the indicator is amber,
it is in standing by.
3 Remote Sensor Window
Receives infrared signal from the handheld remote control.
4 SOURCE SELECT ( )
Press to select VIDEO 1, VIDEO 2, RGB 1 or RGB 2 video source. When
you are in the OSM mode, this button works as the down button.
NOTE: S-VIDEO IN terminals will take preference over VIDEO IN terminals
when the video source is connected to each terminal and VIDEO 1 or 2 selected.
5 VOLUME ( / +)
Used to increase the volume. When you are in the OSM mode, this button
works as the plus button.
6 VOLUME ( / –)
Used to decrease the volume. When you are in the OSM mode, this button
works as the minus button.
7 EXIT
Press to exit the OSM mode. The OSM screen disappears.
8 PROCEED
Press to access OSM. The OSM screen is displayed.
9 VIDEO 2
VIDEO 2 IN (RCA type)........ Connect a VCR or laser disk player here to
display the video.
S-VIDEO 2 IN........................ Here is where you connect S-Video input
from an external source like a VCR.
AUDIO R IN .......................... This is your right channel audio input for
stereo sound coming from video 2 or RGB 2
input, or audio system.
AUDIO L IN (MONO)........... This is your left channel audio input for
stereo sound coming from video 2 or RGB 2
input, or audio system. It also serves as the
mono audio input.
10 RGB 2 Input(D-Sub mini 15 pin)
Connect your PC or other RGB equipment such as IBM or compatible
computers.
11 Remote Control Holder
Place remote control unit here when not in use.
4
Terminal Board
5
12 13
AC-IN
VIDEO1
AUDIO1
R
IN
RGB
OUT
R
R
DIP SW
AUDIO IN
MONITOR
14 16 15 17
12 AC Input
Connect the supplied power cord' s three-pin plug here.
13 VIDEO 1
VIDEO 1 IN (RCA type)........ Connect a VCR or laser disk player here to
display the video.
S-VIDEO 1 IN ........................ Here is where you connect S-Video input
from an external source like a VCR.
AUDIO R IN .......................... This is your right channel audio input for
stereo sound.
L
(
)
MONO
L
(
)
MONO
RGB 1
L
ON
1
2
3
4 56
15 MONITOR OUT (R/L)
Connect additional external speakers here to listen to audio coming from
your computer, Video or S-Video audio inputs (R/L).
16 DIP SWITCH
This switch sets Sync. Control, Power Management, Remote Control ON/
OFF and OSM system Control ON/OFF. See page xx for more details.
17 RGB 1 Input(D-Sub mini 15 pin)
Connect your PC or other RGB equipment such as IBM or compatible
computers.
AUDIO L IN (MONO)........... This is your left channel audio input for
stereo sound coming from video equipment
or audio system. It also serves as the mono
audio input.
14 RGB AUDIO
AUDIO R IN .......................... This is where you connect RGB right audio
output from a computer or another RGB
source.
AUDIO L IN(MONO)............ This is where you connect RGB left audio
output from a computer or another RGB
source.
6
Remote Control Unit
2
POSITION/ CONTROL PROCEED
4
BRIGHT
NORMAL
CONTRAST
MULTIMEDIA MONITOR
RD-346E
OFFDEGAUSS
MUTE
POWER
NORMALSIDE PINHEIGHTWIDTH
VOLUME
ON
RGB 2RGB 1VIDEO 2VIDEO 1
EXIT
SCAN
79645721
7
NOTE: When not in use the remote control unit is conveniently stowed in the
holder on the rear panel.
1 POWER ON/OFF
Press POWER ON to turn the monitor on when the POWER/STANDBY
indicator is lit red.
Press POWER OFF to turn the monitor off and the monitor will go into the
standby condition.
2 DEGAUSS
Press to demagnetize the picture tube in the manual operation. See also page 21.
1
3
5
6
3 Input Select
VIDEO 1........ Press to select an NTSC, PAL, SECAM or M-NTSC
compatible video source from a VCR, laser disc player,
document camera, or an S-Video source from a VCR
connected to the VIDEO 1 IN terminal.
VIDEO 2........ Press to select an NTSC, PAL, SECAM or M-NTSC
compatible video source from a VCR, laser disc player,
document camera, or an S-Video source from a VCR
connected to the VIDEO 2 IN terminal.
RGB 1 ............ Press to select an RGB video source from a computer
connected to the RGB 1 IN terminal.
RGB 2 ............ Press to select an RGB video source from a computer, NEC
scan converter or document camera connected to the RGB 2
IN terminal.
OSM Control
4 POSITION/CONTROL
POSITION
(▲▼
§ ©
).. Adjusts the vertical position of the image up and
down, and the horizontal position of the image from
left to right.
CONTROL ( + / – ) .... Moves the bar in the + or - direction to increase or
decrease the adjustment in an OSM menu.
CONTROL (▲/▼) ..... Select one of the controls in an OSM menu. Press s
to select a higher item in the menu; press t to select a
lower item in the menu.
5 PROCEED
Press to access OSM. When an adjustment item is selected, a press of this
button returns to its icon selection screen.
6 EXIT
Press to exit the OSM mode.
NOTE: The direct keys such as BRIGHT, CONTRAST, WIDTH, HEIGHT, SIDE
PIN can access each control while in the OSM mode.
8
12
13
9
Raster Control
7 WIDTH (+ / –)
Adjusts the horizontal size of the image.
8 HEIGHT (+ / –)
Adjusts the vertical size of the image.
9 SIDE PIN (+ / –)
Adjusts the curvature of the edges of the left and right side of the display
image either inward or outward. The image should be adjusted to attain a
straight line on the left and right sides.
POWER
OFFDEGAUSS
ON
RGB 2RGB 1VIDEO 2VIDEO 1
POSITION/ CONTROL PROCEED
EXIT
SCAN
7
8
CONTRAST
BRIGHT
MULTIMEDIA MONITOR
RD-346E
NORMAL
MUTE
NORMALSIDE PINHEIGHTWIDTH
VOLUME
79645721
9
10
11
14
16
15
10 SCAN SELECT
Each time this key is pressed, the picture size switches from OVER SCAN
for large size to UNDER SCAN for small size and vice versa. Normally
select OVER SCAN for video display and UNDER SCAN for RGB display.
11 NORMAL
This key resets the raster adjustment settings of user changeable memory and
recalls the factory preset data.
Visual Control
12 BRIGHT (▲/▼)
Adjusts the overall image and screen brightness.
Press and hold s for a brighter picture.
Press and hold t for a darker picture.
13 CONTRAST (▲/▼)
Adjusts the image brightness in relation to the background.
Press and hold ▲ for higher contrast.
Press and hold ▼ for lower contrast.
NOTE: The VISUAL CONTROL storing operation is effective only for one input
(VIDEO1, VIDEO 2, RGB 1 or RGB 2).
14 NORMAL
This key resets the visual control settings and recalls the factory preset data.
NOTE: The brightness and contrast adjustment level are factory preset at the
optimum position.
15 MUTE
Press to cancel sound ; press again to restore sound.
NOTE: The other ways to restore sound are to press POWER OFF, then ON or to
press VOLUME keys on the remote control unit.
16 VOLUME (▲/▼)
Adjusts the volume.
Press and hold ▲ to increase sound.
Press and hold ▼ to decrease sound.
10
Loading...
