Murata EN-EL15c, LIP2228 DATA SHEET

No: MDW-TR-21334

品保-报告-098（2） 1 / 4

品保－作標－S031, 様式-8, 改訂 2016/12/01

Murata Energy Device Wuxi Co., Ltd.

No.27, Changjiang Road, Xinwu District, Wuxi, Jiangsu Province , 214028 P.R.C

Phone:[phone] / E-mail: [e-mail]

SAFETY DATA SHEET

1. Product and Company Identification

Product Information

Customer Name : Nikon Corporation
Product Category : Lithium Ion Rechargeable Battery Pack
Model Name : EN-EL15c/LIP2228
Rated Capacity : 2280 mAh ( 16 Wh)
Average Operating Voltage : 7.0 V

Company Identification

Manufacturer’s Name : Murata Energy Device Wuxi Co., Ltd.
Address : No.27, Changjiang Road, Xinwu District, Wuxi, Jiangsu Province , 214028 P.R.C
Information Telephone : [phone]
E-mail Address : [e-mail]
Date Prepared : Jan. 01, 2021
Person in charge : Weiwei Tang

2. Hazard Identification

Class Name : Not applicable for regulated class
Hazard : It may cause heat generation or electrolyte leakage if battery terminals contact with other

metals. Electrolyte is flammable. In case of electrolyte leakage, move the battery from fire
immediately.

Toxicity : Vapor generated from burning batteries, may make eyes, skin and throat irritate.

3. Composition / Information on Ingredients

IMPORTANT NOTE:
The battery pack uses two US18500VC7 lithium ion rechargeable cell and control circuit on the PWB.
The battery should not be opened or burned since the following ingredients contained within the battery that
could be harmful under some circumstance if exposed or misused.
The cell contains neither metallic lithium nor lithium alloy.

Cathode : Lithium Nickel Cobalt Oxides (active material)
Polyvinylidene Fluoride (binder)
Anode : Graphite (active material)
Styrene-butadiene rubber / Carboxymethyl cellulose sodium salt (binder)
Electrolyte : Organic Solvent (non-aqueous liquid)
Lithium Salt
Others : Heavy metals such as Mercury, Cadmium, Lead, and Chromium are not used in the

battery.
Enclosure : Plastic (PC)
UN number : UN3480
Watt-hour rating : 16 Wh for battery pack

No: MDW-TR-21334

品保-报告-098（2） 1 / 4

品保－作標－S031, 様式-8, 改訂 2016/12/01

4. First Aid Measures

The product contains organic electrolyte. In case of electrolyte leakage from the battery, actions described below
are required.

Eye contact : Flush the eyes with plenty of clean water for at least 15 minutes immediately, without

rubbing, and call a doctor. If appropriate procedures are not taken, this may cause an eye

irritation.
Skin contact : Wash the contact areas off immediately with plenty of water and soap.
If appropriate procedures are not taken, this may cause sores on the skin.
Inhalation : Remove to fresh air immediately, and call a doctor.

5. Fire Fighting Measures

・Use specified extinguishers (gas, foam, powder) and extinguishing system under the Fire Defense Law.
・Since corrosive gas may be produced at the time of fire extinguishing, use an air inhalator when danger is

predicted.

・Use a large amount of water as a supportive measure in order to get cooling effect if needed.

(Indoor/outdoor fire hydrant)

・Carry away flammable materials immediately in case of fire.
・Move batteries to a safer place immediately in case of fire.

6. Accidental Release Measures

・Wipe off with dry cloth
・Keep away from fire
・Wear safety goggles, safety gloves as needed

7. Precautions for Safe Handling and Use

Storage : Store within the recommended limit of -20°C to 40°C (-4°F to 104°F), well-ventilated area.
Do not expose to high temperature (65°C/149°F ). Since short circuit can cause burn hazard or

safety vent to open, do not store with metal jewelry, metal covered tables, or metal belt.
Handling : Do not disassemble, remodel, or solder. Do not short + and - terminals with a metal.
Do not open the battery.
Charging : Charge within the limits of 0°C to 60°C (32°F to 140°F) temperature.
Charge with specified charger designed for this battery.
Discharging : Discharge within the limits of -10°C to 65°C (14°F to 149°F) temperature.
Disposal : Dispose in accordance with applicable federal, state and local regulations.

DO NOT EXPOSE TO HIGH TEMPERATURES (140°F/60°C).

DO NOT INCINERATE. DO NOT DISASSEMBLE.

DO NOT INCINERATE. DO NOT DISASSEMBLE.

8. Exposure Controls/Personal protection (In case electrolyte is leaked from battery）

Acceptable concentration : Not specified in ACGIH.
Facilities : Provide appropriate ventilation such as local ventilation system in the storage.
Protective clothing : Gas mask for organic gases, safety goggle, safety glove.

9. Physical and chemical Properties

Appearance : Lithium ion rechargeable cells are set in a resin case.
Average Operating Voltage : 7.0 V

Caution :
