Motorola DROID 2 GLOBAL User Guide

USER GUIDE

Congratulations

DROID2™ Global by Motorola

Make calls from over 200 countries with DROID2 Global by Motorola. Your new phone has international roaming, so you can stay in touch wherever you travel.

• Experience lightning fast access to websites,

documents, and videos, complements of your phone’s 1.2 GHz processor.

• Stream and store multimedia on any DLNA™

Certified device on your home network. No memory cards to swap, no cables to attach.

• Sync your favorite social networking sites—all your

messages, all the latest updates from sources like Facebook®, Twitter, MySpace, Gmail™, and email—so you can stay connected, right from your home screen.

Note: Certain apps and features may not be available

in all countries.

Caution: Before assembling, charging or using your

phone for the first time, please read the important legal and safety information packaged with your product.

•Answers: Touch

You can also flick your home screen left or right to see the Tips & Tricks widget.

•Updates: Phone updates, PC software, user guides,

online help and more at www.motorola.com/mydroid2global

• Accessories: Find accessories for your phone at

www.motorola.com/products

Notes:

• All screen shots in this guide are simulated.

Actual displays may vary.

• Instructions to perform tasks in this guide may

change depending on the software version on your phone.

• Unless specified otherwise, all instructions to

perform tasks in this guide assume that you are starting from the home screen.

Launcher icon

Help Center

1Congratulations

Your phone

1:53 PM

VoicemailMarketText Messa Browser

See all your apps.

Touch the Launcher icon.

1 of

3.5mm

Headset

Micro USB

Connector

Charge or

connect to

PC.

Volume Keys

Power Key

Press = sleep Hold = power

Camera

Back

Home

Microphone

the important keys & connectors

1:53

DEL

LOCK

2 Your phone

LOCK

Text Messa

Alternate

Browser

VoicemailMarket

DEL

SpaceShift

Delete

Return

Navigation Keys

Back

Let’s go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Touchscreen & keys . . . . . . . . . . . . . . . . . . . . . . . . . 5

Home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Apps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Social networking . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Text entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Tips & tricks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Digital living . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Photos & videos . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

YouTube™. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Personalize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Google Maps™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Google Latitude™ . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Apps for all . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Bluetooth® wireless . . . . . . . . . . . . . . . . . . . . . . . . 47

Wi-Fi®. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Memory card & file management. . . . . . . . . . . . . . 50

Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Global Phone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Safety, Regulatory & Legal . . . . . . . . . . . . . . . . . . . . 58

3Contents

Let’s go

let’s get you up and running

Assemble & charge

1 microSD in (may be

already inserted)

3 Batter y in 4 Cover on

5 Charge up

2 SIM in

(already inserted)

Caution: Please read “Battery Use & Safety” on

page 58.

Note: GSM and UMTS-based global services work

only with a SIM card supplied by Verizon Wireless® or by another GSM or UMTS service provider. When you set your phone to use a GSM 900/1800 or UMTS 2100 network (see “Select a network” on page 12), you may be prompted to enter a subsidy code. To get this code, contact Verizon Wireless.

Tip: To save battery life, see “Battery tips” on page 25.

Set up & go

The first time you turn on your phone, a setup wizard guides you through signing in to your Gmail™ account. If you don’t have one, don’t worry, the wizard will help you create one.

After you log into Gmail, you can set up social networking, or you can do it later.

Note: This phone supports data-intensive apps and

services. It is strongly recommended that you purchase a data plan that meets your needs. Contact your service provider for details.

4 Let’s go

1 Press and hold Power on top

of your phone to turn it on.

2 Select a language.

3 Follow the setup wizard to create

or log in to your Gmail account.

Note: If you have an existing Gmail account, your

contacts from that account are synced to your phone. Whenever you choose to select all contacts for the one you want, your phone shows ever y contact, in every group.

Wi-Fi® connect

If you want to use a Wi-Fi network for even faster Internet access, touch Menu >

Wireless & networks >Wi-Fi settings

> search for and connect to wireless networks. There’s more in “Wi-Fi®” on page 48.

Settings

. Touch

Wi-Fi

Cool content & more

Browse and download thousands of the coolest apps on the planet from Android Market™.

Download new apps with “Apps for all” on page 45. Your phone comes with a microSD memory card installed—you can load it up with photos, videos, and music from your computer (see “Memory card” on page 50).

Touchscreen & keys

a few essentials

Touchscreen on/off

Your touchscreen is on when you need it and off when you don’t.

• To make your touchscreen sleep or wake up, just

press Power .

• When you hold the phone to your ear during calls,

your touchscreen sleeps to prevent accidental touches.

• To change how long your phone waits before the

screen goes to sleep automatically, touch Menu

Settings >Display >Screen timeout

• To make the screen lock when it goes to sleep, use

“Screen lock” on page 55. To unlock the screen, press Power or open the phone. Then, drag to the right.

Note: Your touchscreen

might stay dark if the sensor just above it is covered. Don't use covers or screen protectors (even clear ones) that cover this sensor. To find Motorola accessories for your phone, visit www.motorola.com/products

5Touchscreen & keys

Touch tips

VoicemailMarketText Messa Browser

3:00 PM

Contacts: A-Z

Arthur Baudo

Barry Smyth

Cheyenne Medina

Christine Fanning

Jim Somers

Kat Bleser

Kristin Cullen

Contacts: All contacts

Here are some tips on how to navigate around your phone.

Touch

To choose an icon or option, touch it.

Touch & hold

To open special options, touch and hold an icon or other item. Try it: In the home screen, touch

Contacts

and hold a contact to open options.

6 Touchscreen & keys

, then touch

Contacts: A-Z

Contacts: All contacts

Arthur Bando

Barry Smyth

Arthur Bando

Cheyenne Medina

View contact

Christine Fanning

Call contact

Send text message

Jim Somers

Drag

To scroll through a list or move slowly, drag across the touchscreen. Try it: In the home screen, touch

Contacts

, then drag your contact list up or down.

Tip: When you drag or

flick a list, a scroll bar appears on the right. Drag the scroll bar to move the list to a letter A - Z.

Flick

To scroll through a list or move quickly, flick across the touchscreen (drag quickly and release).

Tip: When you flick a long list, touch the screen to stop

it from scrolling.

Zoom

Get a closer look at Google Maps™, web pages, or photos. To zoom in, double-touch (tap twice, quickly) on the screen. To zoom out, double-touch the screen again.

You can also zoom in or out by moving your fingers

Messaging

N Clark St

Wacker Dr

E Ohio S

N Rush St

N Wabash Ave

N Dearborn St

E Grand Av

N Micigan Ave

W Lake St W Lake St

E Wacker Pl

State/Lake

Grand Red

Lake

Randol St Met

Randolph/

Wabash

Washington-Blue

E S WaterSt

E Randolph St

Ontario St

E Ontario St

To zo om in, touch with two fingers,

then move them

apart.

Key

Back

Key

Home

Key

apart or pinching your fingers together on the screen.

rborn St

cker Dr

W Lake St W Lak

andolph St

Messaging

ashington-Blue

State/Lake

Lake

E Wacker Pl

Randolph/

Wabash

N Micigan Ave

Key tips

Menu, home, back, & search

Touch Home to close any menu or app and return to the home screen. In the home screen, touch and hold Home to show the last few apps you used, then touch an app to open it.

E S

Touch Menu to open menu options, or touch Back to go back.

Touch Search for text search, or touch and hold for voice search.

Power key menu

Press and hold Power to open the power key menu, where you can turn off the phone ( or turn

Airplane mode

Silent mode

on or off.

Power off

Adjust volume

Press the volume keys to change the ring volume (in the home screen), or the earpiece volume (during a call).

When playing music or video files, press the volume keys to adjust media volume.

Rotate the screen

When you turn your phone, the touchscreen can rotate to stay right-side up:

Find it: Menu >

screen

Settings >Display >Auto-rotate

7Touchscreen & keys

Quick tips

If you’re not sure what to do next, try one of these:

To .. .

Get the details—Open a

text message, see details for a contact, or open items in other lists.

See screen menu—Open a

menu for the current screen.

See item options—Open

an options menu (if available) for an item on the screen.

Start again—Go back to

the home screen.

Wake up your phone—Turn on a sleeping

touchscreen.

8 Home screen

Touch the message, contact, or item.

Touch Menu .

Touch & hold the item.

Tou ch H o m e .

Press Power or open the phone.

Home screen

quick access to the things you need most

Quick start: Home screen

The home screen gives you all your latest information in one place. It’s what you see when you turn on the phone or touch Home from a menu. It’s basically like this:

1:53

See all your apps.

Touch the Launcher icon.

of 6

VoicemailMarketText Messa Browser

Status Indicators

Notifications

Flick this bar down to see details.

Flick left or right to open more panels.

Shortcuts

Touch to open.

Launcher Icon

Touch to open the app menu.

Note: Your home screen might look a little different.

ONON

l ly

72º

Mostly

My Accoun

Maps

3G Mobile

1:53 PM

Camcorder

GalleryBlockbuste

Work this City

Body Language

Bipartisan meeting to take place this week

TIPS A

How do I set up and u

Widgets content right t Home

1:53 PM

...

Messaging Backup As

1:53 PM

FavoritesContact Se

1:53 PM

VoicemailMarketText Messa Browser

See all your apps.

Touch the Launcher icon.

The home screen extends left and right to give you more room for adding shortcuts, widgets, and more. Flick the home screen left and right to see more panels or to add widgets or shortcuts.

My fantasy b s struggling t

w d

elissa Vurdel

About to sta

0 minutes a

CHICAG

dance party it

of 6

:30pm, Jul 15

ccount Catc

Main Conferenom

und 1:00. Let me know

Use & change your home screen

On your home screen, shortcuts are icons that open your favorite apps, web bookmarks, contacts, mail labels, or music playlists. Widgets show you news, weather, messages, and other updates.

Flick the home screen left or right to open other panels of shortcuts and widgets.

• To open something, touch it. Touch Home to

return to the home screen.

morrow at the countr

Tip: When you open a widget, touch Menu to

show any options or settings (you can choose accounts for

Messages

, or

Social Networking, Social Status

Calendar

widgets).

There’s more about social networking widgets in “Social networking” on page 21.

• To resize

widgets

the widget until you feel a vibration, then drag.

Motorola

, touch and hold

THU

JUL

Kristine Kelley

Not even ready to

3pm

go back to school

Budget Meetin

Budget Meeting

• To add something or

change your wallpaper, touch and hold an empty spot until you see the

to Home screen

Add

menu.

You can add a folder to organize your shortcuts.

• To move or delete something, touch and hold it

until you feel a vibration, then drag it to another spot, another panel, or the trash at the bottom of the screen.

9Home screen

Search

Web

Apps

All

1:53 PM

Touch to search by voice.

Touch here to enter text, then touch to search.

Touch Search on the front of the phone, or touch Search on your phone’s slide-out keypad.

Notifications & phone status

At the top of the screen, icons on the left notify you about new messages or events (notifications). Icons on the right tell you about phone status. Flick the bar down to show notification details.

July 15, 2011

Notifications

Mary Morgan

Copy Revisions

Meeting

New email

10 Hom e screen

3: 00 PM

2:50 PM

2:47 PM

July 15, 2011

Verizon Wireless

Notifications

Mary Morgan

Copy Revisions

Meeting

New email

3: 00 PM

Clear

2:50 PM

2:47 PM

Bluetooth® active network (full signal)

GPS active network (roaming)

Wi-Fi® active GPRS (fast data)

downloading EDGE (faster data)

vibrate 3G (fastest data)

silent airplane mode

mute call sync active

speakerphone

battery (charging)

active

alarm set battery (full charge)

Tip: To see today’s date, touch and hold the status bar

at the top of the screen.

Apps

1:53 PM

ACR3G Mobile

Hotspot

Alarm &

Timer

Amazon

MP3

Backup

Assistant

Blockbuster Browser Calculator

DLNA Files

EMERGENCY

City ID

Dialer

Contacts Dev Tools

DLNA Files

EMERGENCY

Camcorder Camera CarDockCalendar

Touch to return to home screen.

Apps

Touch to open.

get the app you want

Quick start: Apps

You can find all of your apps in one place. From the home screen, just touch app menu.

Launcher icon

to open the

To close the app menu, touch at the bottom of the screen, or touch Home or Back .

Want more? No problem: To download more apps, touch

Launcher icon

Market

Your phone can tell you when there’s an updated app or other phone software. To install the update, just follow the instructions on your screen.

Browse & install apps

Get all the fun games and cool apps you want! Android Market™ provides access to applications developed by developers worldwide, so you can find the app you want. If you need help or have questions about

Help

Android Market, press Menu >

Find it:

Launcher icon

Market

Scroll to and touch the app you want to install. Then,

Install

touch

(if app is free) or

Buy

Recent apps

In the home screen, touch and hold Home to see the most recent apps you used. Touch an app to open it, or touch Home to return to the home screen.

11Apps

Manage & restore apps

Find it: Menu >

Manage applications

Touch an app in the list, then touch you downloaded),

To reinstall apps from Android Market, touch

icon

installed apps are listed and available for download.

12 C alls

Settings >Applications

Clear cache

Market

My downloads

Uninstall

(for apps

, or other options.

Launcher

. Previously

Calls

it’s good to talk

Select a network

DROID2 Global by Motorola switches effortlessly between CDMA, GSM 900, GSM 1800, and UMTS 2100 networks, so you can make calls in over 200 countries worldwide.

Note: To use your phone on a GSM or UMTS network,

you need to insert a SIM card (see “Assemble & charge” on page 4), supplied by Verizon Wireless® or a compatible GSM or UMTS network service provider.

To set your phone to roam globally:

Find it: Menu >

Mobile networks >Network Mode >Global

To manually switch your phone to a CDMA or GSM/UMTS network, see “Manually switch network mode (outside the U.S.)” on page 54.

Settings >Wireless & networks

Quick start: Calls

From the home screen, touch

1:53

Dialer FavoritesRecent Contacts

123

GHI MNO

465

ABC DEF

JKL

TUVPQRS WXYZ

879

To use a Bluetooth® device during a call, touch

Bluetooth

. For more information, see “Connect new

devices” on page 47.

Phone

Recent Calls List

Touch to open, then touch an entry to call.

Backspace

Touch to delete digits you entered.

Call Voicemail

Add Number To Contacts

Voice Dial

Call

Enter a phone number & touch here to call it.

Note: Using a mobile device or accessory while

driving may cause distraction and may be illegal. Always obey the laws and drive safely.

1:53

Connected 00:12

Kristine Kelley

Mobile (555) 555-7931

Chicago, IL

Going to pottery tonight. Looking forward to it, it’s been forever...

Add call DialpadEnd call

Bluetooth SpeakerMute

Mute

Touch to mute or

unmute the call.

Call Timer

End Call

Touch to hang up.

Dialpad

Touch to enter numbers during a call.

Speakerphone

Touch to turn the speakerphone on or off.

13Calls

Tip: You can touch Home or Back to leave the

Answer

Add call

Bluetooth Mute Speaker

DialpadEnd call

End call

active call display. To reopen it, touch Home

Phone >Return to call in progress

Make & answer calls

To make a call, touch necessary), enter a number, then touch .

Tip: If the screen is locked, drag to the right.

To answer a call while the display is active, touch

. When the display is not active, answer by

dragging to the right.

To ignore a call, touch

Phone

Ignore

, touch the

Dialer

tab (if

End calls

Touch .

Note: When you hold

your phone to your ear, the display goes dark to prevent accidental touches. When you move the phone away from your ear, the display lights up again.

Make calls (outside the U.S.)

Your phone has an assisted dialing feature that makes dialing easy. For local calls, just dial the local number. For international calls, dial the country code, the area code (if applicable), then the phone number.

Recent calls

Find it:

• To call a number, touch it.

• To send a text message, create a contact, view a

• To clear the list, touch Menu >

Phone >Recent

contact, or other options, touch and hold an entry.

Clear list

Frequent calls

Find it:

• To call a number, touch it.

• To send a text message, view a contact, or other

Phone >Favorites

options, touch and hold an entry.

Conference calls

To start a conference call, dial the first number. After the call connects, touch number, or select it from contacts or favorites. When the next number answers, touch

Add Call

. Dial the next

Merge calls

14 C alls

Your phone number

Find it: Menu >

My phone number

Settings >About phone >Status

TTY mode

Your phone can use an optional teletypewriter (TTY) device, for people who are hard of hearing or have a speech impairment.

1 Plug the TTY device into the phone’s headset

connector.

2 Touch Menu >

mode

and choose a TTY setting.

Settings >Call settings >TTY

Emergency calls

Note: Your service provider programs one or more

emergency phone numbers (such as 911 or 112) that you can call under any circumstances, even when your phone is locked. Emergency numbers vary by country. Your pre-programmed emergency number(s) may not work in all locations, and sometimes an emergency call cannot be placed due to network, environmental, or interference issues.

1 Touch

2 Enter the emergency number.

3 Touch to call the emergency number.

Phone

Emergency Call

(if your phone is locked, touch

Note: Your mobile device can use GPS and AGPS

signals to help emergency services find you. See “GPS & AGPS” on page 63.

Cool down

In very limited circumstances, such as where your phone has been exposed to extreme heat, “Cool Down” message screens will appear. To avoid possible damage to your battery and phone, you should follow these instructions until the phone is within its recommended temperature range. When your phone is in “Cool Down” mode, only emergency calls can be made.

15Calls

Contacts

contacts like you’ve never had before

Quick start: Contacts

Find it:

Tip: You can also touch

Contacts: A-Z

Contacts: All contacts

Tip: To search the list, touch and hold Menu to

open a touchscreen keypad, then type a name. When

16 C ontacts

Contacts

Arthur Baudo

Barry Smyth

Cheyenne Medina

Christine Fanning

Jim Somers

Kat Bleser

Kristin Cullen

Launcher icon

Group

Touch Menu to choose which group to show (like All or Favorites).

Create Contacts

Contacts List

Touch to view contact information. Touch & hold to call, send a text message, & more.

you flick or drag the list, drag the scroll bar that appears to move the list faster.

Call or email contacts

Find it:

For

Send email

contact.

Contacts

View contact, Call contact, Send text message

, or other options, touch and hold the

View & use contacts

When you set up a social networking account (see “Social networking” on page 21), you’ll know what everybody’s up to and when. Every time you pick up a call, check a message, or look up a friend’s contact info, you’ll see their name and number, but you can see their social network status and smiling face, too.

Find it:

• To find a contact, just type the name.

Contacts

Touch a contact to open its details. While viewing details, you can start a call or message by touching a phone number or other info. Flick the screen left or right to see

Social Networking

updates or

History

Tip: To change which account provides the pictures

for your contacts, from the home screen touch

Launcher icon

Menu >

My Accounts

Picture source

, then touch

• To change which group of contacts is shown (

1:53 PM

Sara

Walker

555-555-2385

Add contact

Phone

Mobile

Save Discard changes

Touch to add more name details.

Touch to remove this number.

Touch to set the number type.

To see more details, flick up.

Touch to select a picture for the contact.

Touch to add another number.

Facebook, and so on) touch the filter name at the top.

• To change how you view the list of contacts, flick

left or right at the bottom of the screen to select

History

(recently used),

Status

(list with status).

A-Z

(list without status), or

Edit or delete contacts

Find it:

Touch the contact, then touch Menu >

Delete

Contacts

Edit

Link contacts

You might have two contacts for the same person, such as a friend with two email addresses. To combine these two contacts:

Find it:

Touch a contact to open it, then touch Menu

Link contact

> networking account remembers this connection.

Contacts

and touch the second entry. Your social

All

Create contacts

Find it:

Contacts

, then touch Menu >

Add

contact

Slide out the keypad, or touch any entry area to open the touchscreen keypad.

Save

When you’re finished, touch

Where are contacts saved? Your phone saves new

contacts in its memory and to your Google™ account. It also updates your social networking account.

17Contacts

Synchronize contacts

2:50 PM

2:47 PM

2:45 PM

2:41 PM

Mary Morgan

Copy Revisions

Hi Paul, Please take a look at the ...

Arthur Bando

Meeting invitation

Meeting is set for next Thursday at...

Mary Morgan

freelancers Paul, We’re going to need help w...

Universal Inbox (3)

Jim Somers

Meet me outside the theater at 8

and don’t forget your ID. Would yo...

Create Messages

Check for Messages Now

Message Type

Message Status

= unread = urgent = attachments

Message List

Touch to open a message. Touch & hold to move, delete, & more.

When you change one of your contacts, your phone automatically updates your other social networking accounts. Also, your phone updates your contacts and social networking account whenever you change a friend in your social networking accounts.

Groups

Find it:

group

You can put your contacts into groups that you create (like “friends”, “family”, or “work”). Then, you can find contacts faster by showing one group at a time.

Contacts

, then touch Menu >

Display

Messaging

sometimes it’s best to text, or IM, or email . . .

Quick start: Messaging

Find it:

Launcher icon

Inbox

Messaging >Universal

18 M essaging

Tip: To see more messages, flick or drag up.

Read & reply to messages

Find it:

Launcher icon

Universal Inbox

Note:

Universal Inbox

together—text, email, and social networking messages. To show only one type of message, touch a message account type instead of

• To open a text message or social networking

message and all of its replies, touch it.

• To respond to a message, just open it and enter

your response in the text box at the bottom.

To forward a text message, touch and hold a message in the conversation, then touch

message

For email, touch to choose a reply or forward option.

• To open options, touch and

hold a message.

Tip: Try the

Messages

page 40.

Messaging

shows all of your messages

Universal Inbox

Forward

widget in “Widgets” on

Create messages

Find it:

Launcher icon

Messaging

Choose a message type, such as

Text Messaging

Facebook

. Then, enter the recipient

and message. In text messages and emails, touch

Insert...

Menu for options like

Attach Files

Send & receive attachments

To send a file in a message, open a new message and touch Menu >

When you receive a message with an attachment, open the message and touch the file name to download it. Then, touch the name again to open it. Some file formats can be converted to HTML for faster viewing, and your phone will show

While viewing the attachment, touch it to save it, share it, and more.

Tip: To send and receive large attachments faster, use

a Wi-Fi® connection, in “Wi-Fi®” on page 48.

Insert

Get HTML version

19Messaging

Set up messaging

To add email accounts, touch

My Accounts >Add account

Corporate Sync

•

is for Exchange server work email

accounts. Enter details from your IT administrator.

Tip: You might need to enter your domain name

with your user name (like domain/username).

Email

is for most personal email accounts. For

•

account details, contact the account provider.

Note: While you are using a Wi-Fi network, you

cannot access

Yahoo Mail

use your browser to see these accounts at mail.yahoo.com

To change your settings, touch

Messaging

Manage accounts

•

Edit Universal Inbox

•

, touch Menu , then touch:

to add or remove an account.

show messages in the

Messaging Settings

•

account type (along with other preferences, for email).

Tip: For social network accounts, see “Add accounts”

on page 21.

20 M essaging

Launcher icon

accounts. You can still

Launcher icon

to choose which accounts

Universal Inbox

to set the notification for each

The first time you turned on your phone (see page 4), you logged in to your Gmail™ account. You can add any other email account that you set up.

To add other email accounts to your

Universal Inbox

and

Messaging

accounts

screen, touch

: Touch

Launcher icon

, then touch Menu >

Add account

. On the

and enter your email account

Setup accounts

Messages

widget

Manage

information.

Instant messages

To send and receive instant messages, you can use an instant messaging app or your browser. Your phone comes preloaded with Google Talk™. You can also download an instant messaging app from Android Market™:

• To download and use an instant messaging app,

Launcher icon

touch

Communication

> provider. Once you download the app, you’ll see it in “Apps” on page 11.

Market >Apps

, then choose an app for your

• If you don’t see an app for your IM provider, you can

use your web browser. Touch Home

Browser

> your provider’s website. Once you’re there, follow the link to sign in.

Note: Your IM options will depend on your IM provider.

, touch Menu >Go, then enter

Voi c e m ail

When you have a new voicemail, shows at the top of your screen. To hear the voicemail, touch then touch .

If you need to change your voicemail number, in the home screen touch Menu >

settings

Voicemail Settings

Settings >Call

Phone

Social networking

my life, your life

Your social networking account

You can set up a social network account that integrates and syncs all your contacts, emails, and social networking sites, and serves them up just the way you want them. No opening and closing apps and menus. You can interact by using the

Networking

screen. These widgets are your windows into the social networking sites and other accounts you entered into your social status.

and

Social Status

Add accounts

You can add your more accounts to your social networking account. If you don’t have accounts on these sites, visit their websites to set them up.

For email accounts, see “Set up messaging” on page 20.

Launcher icon

Find it:

account

Add an account by touching it. Then enter your user name and password for that account.

When you sign into social networking accounts, you’ll see your friends and contacts in your

Social

widgets on your home

My Accounts >Add

Contacts

list, and

21Social networking

your status and updates can appear in your

Networking

screen.

Twitter and MySpace messages will always appear

as “read” on your phone, but your phone notifies you when you receive a new message. MySpace marks your messages as “read” online.

Tip: To download updates faster, use “Wi-Fi®” on

page 48.

and

Social Status

widgets on your home

Social

Edit & delete accounts

Find it:

Launcher icon

Touch and hold an account, then touch to edit it, or touch with its contacts and messages).

Note: You can’t delete the Google™ account you used

or created when you set up your phone. That account is locked when you set it up.

22 Text entry

Delete account

My Accounts

Open account

to remove it (along

Text entry

think keyboard, now think smaller

Typing tips

To use the full keypad, just open your phone:

To...

Enter alternate characters in the upper corners of keys

Enter symbols chosen from a list

Enter one capital letter Press Shift .

Enter only capital letters Press Shift

Select text Hold Shift and

Cut, Copy, or Paste

selected text

Delete a character (hold to

delete more)

Press Alternate .

Press Alternate , then press .

twice. Press again to revert to lowercase.

press a navigation key.

Touch and hold the text box to open the editing menu.

Press Delete .

To .. .

q w

EN @ # 1 2 3_% ( )

! 7 8 9 0

s d f g h j k

SYM

x cvb n m

‘

e r t y u i o p

8 $ 4 5 6

: ; “

)

q w

EN @ # 1 2 3_% ( )

! 7 8 9 0

s d f g h j k

SYM

x cvb n m

‘

e r t yu i o p

8 $ 4 5 6

: ; “

)

For double letters, circle the letter.

book

day

Jump to the beginning/end

of a line

Press Alternate , then press a navigation key.

Start a new line Press Enter .

Touchscreen keypad

When your phone is closed, you can open a touchscreen keypad by touching a text box, or touching and holding Menu . To close the keypad, touch Back .

Text Box

Touch to open the touchscreen keypad.

Tornado al

we r ty u i op

zxcv bnm

?123

Touch to open a keypad for numbers & symbols.

df gh jk l

1:53 PM

Done

Microphone

DEL

Touch for voice input.

Delete

Return/ Line Feed

Space

Input methods

To select an input method for a touchscreen keypad, touch and hold a text entry area on the screen to open

Edit text

the

menu. Touch the method you want:

Swype™ text entry

Swype lets you enter words with one continuous motion. To enter a word, just drag your finger over the letters in the word.

Input method

, then touch

23Text entry

Tips:

q w

EN @ # 1 2 3_% ( )

! 7 8 9 0

s d f g h j k

SYM

x cvb n m

‘

e r t yu i o p

8 $ 4 5 6

: ; “

)

To capitalize, go above the keypad.

Who

• To enter apostrophes in common words (like “I’ll”),

drag through the

• To enter several symbols, touch

as though it was an apostrophe.

SYM

• To correct a word, double-tap it. Swype shows a

small menu of other word options. Swype might also show a menu if it can’t guess your word.

• If Swype doesn’t know a word, you can still touch

the letter keys to enter it. Swype remembers, so next time you can just drag over the letters.

Multi-touch keyboard

Enter text on a touchscreen keypad one letter at a time. As you type, your phone suggests words from your dictionary and chosen language. Your phone also automatically enters apostrophes in some words, like “dont.” You can also touch two keys at the same time, such as Shift with a letter.

24 Text entry

Text entry settings

When you enter text, your phone automatically corrects or suggests words. To change these settings, press Menu > then:

• To edit your word suggestion dictionar y, touch

dictionary

• To change the language and the style for your

touchscreen keypad, touch

• To change the sounds, corrections, and other

settings for your touchscreen keypad, touch

Multi-touch keyboard

• To change the automatic correction settings for your

full keypad, touch

Settings

Language & keyboard

Select locale

Device keyboard

User

Swype

Tips & tricks

a few handy hints

General tips

• If you can’t to see the screen while wearing

sunglasses, take them off. Screen brightness changes as your phone senses the current lighting conditions.

• To return to home screen, touch Home .

Phone

• To see recently dialed numbers, touch

Recent

• To sleep/wake your phone, press Power/Lock .

• To set screen timeout, touch Menu >

Display >Screen timeout

• To search, touch Search .

• To show last few apps, touch and hold Home .

• To turn sound on/off, press and hold Power/Lock

Silent mode

• To turn airplane mode on/off, press and hold

Power / Lo ck >

Airplane mode

Settings

Battery tips

Want to extend your battery life? Try these:

• To select a battery profile that suits your phone use,

touch Menu >

• To turn off automatic applications sync, touch

Menu >

Delivery

• To turn off Bluetooth® power, touch Menu

Settings >Wireless & networks >Bluetooth

• To turn off Wi-Fi®, touch Menu >

Wireless & networks >Wi-Fi

Settings >Battery Manager

Settings >Data manager >Data

Settings

25Tips & tricks

Digital living

connect and enjoy

Note: Copyright—do you have the right? Always follow

the rules. See “Content Copyright” in your legal and safety information.

BLOCKBUSTER videos

Blockbuster On Demand lets you rent or purchase videos and download them to your phone. To use the service, you need a Blockbuster account and a connection to a Wi-Fi network.

Rented videos can be played on your phone.

Purchased videos can be played on your phone, and on PCs or TVs connected to a TiVo® DVR, Blu-ray player, or 2Wire™ media platform.

To get started, click on the free Blockbuster app:

Launcher icon

Find it:

The app completes an upgrade procedure, which may take a few minutes. When the upgrade is complete, you will be prompted to activate your phone:

• If you don’t have a Blockbuster account, touch

Activate Using Device

you activate your phone, you will be prompted to provide credit card information for your payment option.

26 Di gital living

Blockbuster

Activate Using PC

. When

• If you already have a Blockbuster account, touch

Enter PIN

Once your phone is activated, you can browse or search Blockbuster.com rent or purchase.

, then enter your account information.

to find the videos you want to

Media Share

Media Share gives you an easy way to share your media content—photos, videos, and tunes—with friends and family.

Share your media via DLNA devices: The Media

Share wizard guides you through the easy setup steps.

Share photos & videos: Share any photos or videos

on your phone, even the ones you created.

More tunes: Enjoy favorites from your phone playlist

on your sound system at home. Or get music from your portable music player and add it to your phone’s music library.

Connect

To share media, you need to connect to a Wi-Fi® network or another device:

• Connect to your computer with a USB cable

(see “Memory card & file management” on page 50).

• Connect to a Wi-Fi network or use your own Wi-Fi

hotspot (see “Wi-Fi®” on page 48).

Media Share will lead you the rest of the way.

Your Media Share world

Note: If you’re using a Wi-Fi connection, you need to

allow access to other devices to download media from your phone and to share your files.If you want to access media files on other devices, they need to allow access.

To use Media Share, touch >

Media Share

. Then select the

Launcher icon

Media Share

feature you want to use:

Share media

•

—Allow other devices to access media files on your phone. Without downloading any media from your phone, other people can view your pictures or videos, or play your songs, on their own devices.

Sync media

•

—Sync the media files on your phone

with other devices.

Copy media

•

—Copy a picture from one phone to

another.

Play media

•

—Select media for playback on another

device in a Wi-Fi network.

Share using DLNA

DLNA lets you expand the ways you can enjoy your photos and videos on a DLNA Certified computer, TV, or monitor, using your own Wi-Fi network.

Make sure your phone is connected to an active Wi-Fi

DLNA

11:35 PM

network and has access to a DLNA Certified device.

1 Touch

2 Touch

Launcher icon

DLNA

Play media, Copy

media

to server,

to phone

, or

Share media

Copy media

Play media

Copy media

to server

Then follow the instructions you see on your phone.

Copy media

to phone

Share media

27Digital living

Photos & videos

Chicago, Illinois

573957395739

WSWSWS

Flash

Switch to

Effects

Scenes

See your photos and videos.

Autofocus

Box

Switch to camcorder.

Adjust photo capture settings for greater creative control.

Shots Remaining

see it, capture it, share it!

Photos

Take & share photos

Take that family photo, and post it online for everyone to see.

Find it: Press Camera (on the side of your phone)

Tip: You can also touch

Camera

Launcher icon

Note: Photos are stored on your microSD memory

Picture Resolution

card.

Widescreen

5MP

, unless

you change it.

To take the photo, lightly press Camera halfway until the autofocus box turns green, then press all the way to take the photo.

• To set the photo as a wallpaper, contact photo, or

social network photo, touch Menu >

Set as

• To send the photo in a message or post it online,

touch Menu >

. For more info on sharing your photos, see “Share photos & videos” on page 32.

Delete

• To delete the photo, touch Menu >

• For more options, touch Menu >

28 Photos & videos

Photo options

Touch the viewfinder, then touch a tab on the right side of the screen to set photo options:

options

Scenes

Effects

Set the type of photo you want to

Auto, Portrait, Landscape

take:

Sport

, and more.

Set a photo effect:

Negative, Black and White

Normal

, , and

more.

Flash

Switch to

Set

Flash On, Flash Off

Flash

, or

Switch between camera and

Auto

camcorder modes.

Camera settings

Settings

In the viewfinder, touch Menu >

change camera settings:

options

Picture Resolution

Set photo resolution.

options

Quick Upload Album

Review Time

Face Detection

Video Resolution

ISO equivalent sensitivity

Exposure

Shutter Animation

Automatically upload photos to accounts you select, such as

Facebook, MySpace, Photobucket

and more.

Set how long a new photo is shown before you return to the viewfinder.

Set the camera to detect a face in the viewfinder and adjust image quality.

Set video resolution.

Select an ISO film speed setting.

Select an exposure setting.

Set the camera to play a shutter animation when you take a photo.

29Photos & videos

Picture modes

In the viewfinder, touch Menu >

Picture modes

set picture mode:

options

Single shot

Panorama assist

Take one shot at a time.

Take multiple shots of wide scenes and join them together to make one large image. Use

Capture Direction

to specify how shots will be joined:

Self portrait

Move up, Move right, Move left Move down

Set the camera to detect your face in

the viewfinder and adjust image quality.

Multi-shot

Take several shots in rapid succession when you press and hold Camera .

Tagging photos

You can attach tags to photos to group them in folders. For example, you can create a tag named

Vacation

and apply the tag to your vacation photos. All photos

Vacation

tagged

30 Photos & videos

will be grouped in a

Vacation

folder.

To create and apply a tag:

1 In the viewfinder, touch Menu >

2 If necessary, activate tags by touching

Videos

01:30:00

NTSC

Record & share videos

Launcher icon

Find it:

Note: To get the clearest videos, wipe the lens clean

with a soft, dry cloth before you record a video.

Time Remaining

01:30:00

NTSC

Chicago, Illinois

Tag videos with

your location.

To record the video, press Camera (on the side of your phone). To stop the video recording, press Camera again.

• To send the video in a message or post it online,

touch Menu >

Camcorder

Adjust video capture settings for greater creative control.

. For more info on sharing

Scenes

Effects

Light

Switch to

Switch to camera.

your videos, see “Share photos & videos” on page 32.

• To play the video, touch .

Delete

• To delete the video, touch Menu >

Video options

Touch the viewfinder, then touch a tab on the right side of the screen to set video options:

options

Scenes

Effects

Optimize video recording for different environments:

Night

Set a video effect:

Auto

Normal

Negative, Black and White

, and

more.

Light

Switch to

Turn the camcorder light on or off.

Switch between camera and camcorder modes.

Camcorder settings

Settings

In the viewfinder, press Menu >

to change camcorder settings (see “Camera settings” on page 29.

31Photos & videos

View photos & videos

11:35

Gallery

Folders

2 folders

All photos

1 photos

All videos

3 videos

Find it:

Launcher icon

Touch an option for the photos or videos you want to access:

• Camera roll—All of the captured photos and videos

on your phone.

32 Photos & videos

Gallery

• My Tags—Photos and videos grouped by tag.

• Folde rs—Photos and videos grouped by the folders

where they’re saved.

• All photos—All photos, no groupings.

• All videos—All videos, no groupings.

Note: To see the controls while the video is playing,

touch the display.

View photos & videos

Tip: Turn the phone sideways for a widescreen view.

Gallery

The

first displays photos and videos as thumbnails. Scroll through the thumbnails by flicking them up or down. Touch a thumbnail to select it for viewing or playback.

When you select a thumbnail, it is enlarged to normal viewing size. Videos are paused at the beginning. Touch the play and pause buttons on the screen to control video playback.

Note: To see the buttons while the video is playing,

touch the display.

Share photos & videos

Launcher icon

Find it:

To send your photo in a message or post it online:

1 Select an image.

Gallery

2 Touch and hold a photo or video, then touch

3 Choose how you want to share—like

Email, Text Messaging

, and more.

Bluetooth

Manage photos & videos

Find it:

Launcher icon

1 Select an image.

2 Touch and hold a photo or video, then select

upload

Share, Edit, Delete

Gallery

, or

More (Set as, Print

Quick

Tip: To copy photos to/from a computer, go to “USB

connection” on page 51.

Music

when music is what you need...

Quick start: Music

Touch and play—instant music. Just open your music library, then select what you want to play.

Launcher icon

Find it:

Albums Songs Playlists

Artists

Brook Fairfax

1 album

Max Keppler And AnnaLee...

1 album

Running Roughshod

1 song

Miller Heaton/Sprinklesky

1 album

Music

Max Kepler And AnnaLee...

Running Roughshod

Libby Went Trailriding Without Me

1:14 3:45

Touch a category, then

find & select the music

you want.

Music ControlsCategories

Tip: When a song is playing, you can add it to a playlist

by touching Menu >

Add to playlist

33Music

Set up music

What music transfer tools do I need?

To put music on your computer and then load it on your phone, you need:

• Microsoft™ Windows™ PC or Apple™

Macintosh™.

• USB data cable (included with your phone).

• SD memory card (8 GB—included with your phone).

Your music is stored on your memory card. Your phone supports removable microSD memory cards up to 32GB capacity. To make sure your memory card is installed, go to “Assemble & charge” on page 4.

Tip: To see the available memory on your memory

card, touch Menu >

storage

What audio file formats can I play?

Your phone can play many types of files: AAC, AMR, MP3, WAV, WMA, AAC+, and MIDI.

Note: Your phone does not support DRM-protected

files.

34 Music

Settings >SD card & Phone

What headphones can I use?

Your phone has a 3.5mm headset jack for wired stereo listening. You can go wireless with Bluetooth® stereo headphones or speakers (see “Bluetooth® wireless” on page 47).

Get music

You can transfer music from your computer to your phone by using a USB connection.

For more information on transferring music, see “USB connection” on page 51.

Note: Copyright—do you have the right? Always follow

the rules. See “Content Copyright” in your legal and safety information.

Play music

Music library

Open your music library, then select what you want to play.

Find it:

Brook Fairfax

1 album

Albums

Songs Playlists

Max Keppler And AnnaLee...

Miller Heaton/Sprinklesky

1 album

Running Roughshod

1 song

1 album

Artists

Yo u Tu be ™

go and create your own classic

Quick start: YouTube

Find it:

Launcher icon

YouTube

Watch videos

See popular video categories, like

viewed

, and

Top rated

. Touch a category, then touch the video to start playing it. To see more video categories, touch Menu > video in high quality, touch Menu >

High quality video

Featured, Most

Search for videos

Find it:

Launcher icon

Menu >

Enter text, then touch history, touch Menu >

history

YouTube

.To clear your search

Settings >Clear search

, then touch

Share videos

Send someone a link to a video that you are watching.

1 Touch the video to select it.

2 Touch Menu >

3 Address and complete your email, then touch

Send

37YouTube™

Your account

Web Images

Local News

Near me now

Chicago

New window

Refresh

Bookmarks

Forward

Windows

1:53

Google

Press Menu for browser options.

Launcher icon

Find it:

Menu >

1 To create your YouTube™ account, touch the “Don’t

My account

have a YouTube account? Touch here to create one” link.

If you already have a YouTube account, enter your username, password and touch

2 For a new account, enter a username, and complete

the fields, then touch

Upload videos

Find it:

Launcher icon

Upload

Menu >

1 Touch the video you want to upload. You can change

the video title, description, set the access, and add tags.

Upload

2 Touch

I accept

YouTube™

YouTube

, then touch

Web

search, surf, shop

Quick start: Browser

Find it:

Note: If you can’t connect, contact your service

provider.

Browser

38 Web

Connect

Baseball Dayton Team - NJ.com

Dayton Flyers Baseball rosters, game schedules, photos, arcles ...

Get the latest Baseball Dayton high school Baseball news, rankings, schedules, stats, scaores, results & athletes. . .

highschoolsports.nj.com/school/... - Opons

Dayton Flyers Baseball are ranked #2306 on Fanbase. Find arcles, photos, videos, rosters, and results for seasons...

www.fanbase.com/Dayton-Flyers-B... - Opons

Dayton Wings Baseball Team - Ohio History Central - A product of ...

Get the latest Baseball Dayton high school Baseball news, rankings, schedules, stats, scaores, results & athletes. . .

www.ohiohistorycentral.org/entr... - Opons

Searches related to: dayton baseball

Your phone uses the mobile phone network (over the air) or a Wi-Fi® connection to automatically access the web.

Note: Your service provider may charge to surf the

web or download data.

To use a wireless network, touch Menu >

Wireless & networks

Wi-Fi settings

touch

. Touch

Wi-Fi

to turn it on and

to search for nearby wireless

Settings

networks. Touch a network to connect.

Select links

When you touch a link, your phone outlines it and goes to that page. If you touch and hold the link, your phone shows options, like

in new window

Bookmark link

Open

See options

Touch Menu to see browser options:

options

New Window

Bookmarks

Windows

Refresh

Back/Forward

Open a new browser window.

See your bookmarks.

View the browser windows that are currently open.

Reloads the current page.

Navigate to previously viewed pages.

See additional browser options.

39Web

Personalize

add your personal touch

Widgets

Create widgets

1 Find an empty spot on your home screen where you

want to add a widget. You can flick left or right to open other panels on your home screen.

2 Touch and hold the empty spot until you see the

Add to Home screen

Motorola widgets

3 Touch

4 Touch the type of widget. If necessary, enter the

widget settings.

Set up widgets

You can customize some widgets. Touch a widget to open it, then touch Menu .

You may already have several useful widgets on your home screen:

Messages

•

: Change the widget name or choose how long it shows new messages. To add email accounts, “Set up messaging” on page 20.

Music

: Set this widget to an artist, album, song,

•

playlist, or just touch Menu > There’s more about “Music” on page 33.

40 Personalize

menu.

Android™ widgets

Party shuffle

•

News

: Change the widget name, choose how long it shows new stories, or choose a news source. To choose a source, touch , then choose preset

Bundles

URL for a

Weather

•

Channels

Webpage

: Change temperature units or add

, or choose

or an

RSS feed

Custom

to enter a

locations. To add locations, touch , enter a city,

and touch

. When you open the weather

widget, flick left to see other locations you added.

Ringtones

To personalize your ringtones:

Find it: Menu >

ringtone

Settings>Sound >Phone

Notification ringtone

To set your vibrate options:

Find it: Menu >

vibrate

Settings >Sound >Phone

Wallpaper

To apply a new wallpaper:

1 Touch and hold an empty spot on your home screen.

2 Touch

3 Touch

Wallpapers

Live Wallpapers, Media gallery

, or

, and choose a wallpaper.

Sounds

• To set volume for media and videos, touch

Menu >

• To play tones when using dial pad, touch Menu

Settings >Sound >Audible touch tones

• To play sound on a screen selection, touch

Menu > then adjust

Settings >Sound >Volume

Settings >Sound >Audible selection

Media volume

Display settings

• To set display brightness, touch Menu

Settings >Display >Brightness

• To set orientation, touch Menu >

Display >Auto-rotate screen

• To set animation, touch Menu >

Display >Animation

Note: Some apps are designed so that your phone

can “animate” them by rotating, fading, moving, and stretching one or more images.

Settings

Quick launch shortcuts

You can add shortcuts directly to the home screen by touching and holding an empty spot on the home screen, touching

Shortcuts

, and selecting a shortcut.

Date & time

Set date, time, time zone, and formats:

Find it: Menu >

Settings >Date & time

Language & region

Set your menu language and region:

Find it: Menu >

Select language

Settings >Language & keyboard

41Personalize

Google Maps™

200

Oak

3:00 PM

where you are, where you’re going

Quick start: Maps

Where am I? What’s around here? Don’t worry—let Google Maps help you explore your surroundings and find what you’re looking for.

Launcher icon

Find it:

Note: The map image you see may be a little different.

42 Google Maps™

Maps

Set your location sources

Set your phone to determine your location using GPS satellite signals (highly accurate, but uses battery power) or using the mobile network (less accurate, but conserves battery power).

Settings

To set your location, touch Menu >

Location & security >Use GPS satellites

wireless networks

and/or

Use

Find your location

Note: Don’t forget to set your location sources.

From the main Google Maps screen, touch Menu

My Location

. The bigger the circle, the less accurate the

location.

Find any location

1 Touch Menu >

2 Enter text in the search box, like an address,

business, or city, then touch Search .

Tip: If it’s an address you have visited before, select

from the list shown.

3 Touch the search box to view all the results, then

touch the one you want.

. Your location is shown on the map as

Get directions

Find your way with turn-by-turn navigation. You can even have directions spoken so you can keep your eye on the road.

1 Touch Menu >

Directions

2 Enter a starting point address or touch and select

My current location, Contacts

, or

Points on map

3 Enter an end point address or touch and select

Contacts

Points on map

4 Select your mode of transport (car, public transport

or walk), then touch

. Your directions are shown

as a list. To view your directions on a map, touch

Show on map

5 When you have finished, touch Menu >

Clear map

Select map mode

Touch Menu >

Satellite, Latitude

positions or directions.

Touch Menu >

My Maps, Wikipedia

from

Clear Map

Touch

Layers

to select from

Traffic

or recent searches, viewed

Layers >More layers

, or

Transit Lines

to select

to clear your selections.

Map view

Shows a map, complete with names of streets, rivers, lakes, mountains, and borders. This is the default view.

Satellite view

Shows map on top of aerial photo.

Traffic view

If available in your area, real-time traffic conditions are shown on the roads as color-coded lines.

43Google Maps™

Google Latitude™

where are your friends & family?

Join Google Latitude

Keep track of where your friends and family are on Google Maps™. Plan to meet up, check that your parents got home safely, or just stay in touch.

Don’t worry, your location is not shared unless you agree to it. You need to join Google Latitude, and then invite your friends to view your location or accept their invitations. When using Google Maps (in any mode except street view), touch Menu > Read the privacy policy and if you agree with it, touch

Agree & Share

Add & remove friends

Find it:

Launcher icon

touch Menu >

To add friends:

1 Touch Menu >

Select from Contacts

2 Touch

Or, touch

Add via email address

email address.

Add friends

3 Touch

If your friends already use Google Latitude, they’ll receive an email request and a notification. If they have

44 Google Latitude™

Latitude

Add friends

, then touch a contact.

Join Latitude

Maps

, then

, then enter an

not yet joined Google Latitude, they’ll receive an email request that invites them to sign in to Google Latitude with their Google™ account.

To remove friends:

1 Touch Menu >

Latitude

to show your friend’s

list, then touch a friend in your list.

2 Touch

Remove this friend

Share location

When you receive a request to share location details

you can choose to:

Accept and share back

•

—See your friend’s location,

and your friend can see yours.

Accept, but hide my location

•

—See your friend's

location, but they can't see yours.

Don't accept

•

—Location information is not shared

between you and your friend.

Hide your location

To hide your location from a friend, touch Menu

Latitude

> contact name, then touch Menu >

settings

to show your friend’s list. Touch your

Hide your location

Edit privacy

Turn off Google Latitude

Touch Menu > Touch Menu >

Latitude

to show a friend’s list.

Edit privacy settings >Turn off

Apps for all

get the app you want

Android Market™

Note: You need to set up a Gmail™ account (see “Set

up & go” on page 4) in order to buy and download apps from Android Market™.

Launcher icon

Find it:

Get all the fun games and cool apps you want! Android Market provides access to applications from developers worldwide, so you can find the app you want. If you need help or have questions about Android Market, touch Menu >

Browse & install apps

Scroll to and touch the app you want to install. Then,

Install

touch

Warning: If an app you are downloading requires

access to your data or control of functions on your phone, you’ll be asked to give your permission. After selecting selecting additional Google™ account. Sign in and select

Purchase now

instructions. To see the download progress, open the notifications window.

(if app is free) or

Install

, the app will download. After

Buy

, you may be asked to sign in to an

to proceed. Follow the on-screen

Market

Buy

Help

45Apps for all

After you download an app, the icon for that app appears in the app menu (see “Apps” on page 11).

Manage & restore apps

Find it: Menu >

Manage applications

Touch an app in the list, then touch you downloaded),

To reinstall any downloaded items, touch

icon

Settings >Applications

Clear cache

Market

Uninstall

(for apps

, or other options.

Launcher

Important customer information

Please be advised that many services and applications offered through this unique device are provided by Google and various application developers. If you use, link to or download a Google service, or an application such as a non-Verizon Wireless location based GPS-type service, chat room, marketplace or social network from this device, you should carefully review the terms of such service or application. If you use any of these non-Verizon Wireless services or applications, personal information you submit may be read, collected, or used by the service or application provider and/or other users of those forums.

Motorola Mobility, Inc. and Verizon Wireless are not responsible for your use of those applications or information you choose to submit or share with others.

46 Apps for all

Specific terms and conditions, terms of use, and privacy polices apply to those applications and services. Please review carefully any and all terms and conditions applicable to those applications and services including those related to any location-based services for any particular privacy policies, risks or waivers.

Your Verizon Wireless customer agreement terms and conditions and certain other specifically identified terms govern your use of any Verizon Wireless products and services.

Bluetooth® wireless

lose the wires and go wireless

Quick start: Bluetooth wireless

Find it: Menu >

Bluetooth settings

Bluetooth

Device name

DROID2

Discoverable

Make device discoverable

Enhanced Stereo

Improved battery life and MP3 audio quality for supporting devices

Scan for devices

Bluetooth devices

DROID2

Pair with this device

Turn Bluetooth power on or off

Find it: Menu >

Bluetooth

Note: To extend battery life, turn Bluetooth power

off when not in use.

Settings >Wireless & networks

Touch to turn on/off & to scan.

Touch to re-scan.

Touch to connect.

Settings >Wireless & networks

Connect new devices

Note: This feature requires an optional accessory.

To connect with a new device, you need to pair with it. You only need to do this once for each device—to connect again, just turn on the device.

1 Make sure the device you are pairing with is in

discoverable mode.

Note: Refer to the guide that came with the device

for details.

2 Touch Menu >

Bluetooth settings

3 Touch

Bluetooth

power is already on, touch

Settings >Wireless & networks

to turn on and scan. If Bluetooth

Scan for devices

4 Touch a device to connect.

5 If necessary, touch

0000

(like

) to connect to the device. When the

, or enter the device passkey

device is connected, the Bluetooth indicator appears in the status bar.

Note: Using a mobile device or accessory while

driving may cause distraction and may be illegal. Always obey the laws and drive safely.

Note: The Bluetooth Enhanced Audio setting is not

recommended for older Bluetooth headsets, as it may not deliver acceptable sound quality.

47Bluetooth® wireless

Reconnect devices

Wi-Fi networks

Wi-Fi settings

Notify me when an open network is available

Network notification

Your network

Add Wi-Fi network

Wi-Fi

Touch to turn on/off & to scan.

Touch to connect.

To automatically reconnect your phone with a paired device, simply turn on the device.

To manually reconnect your phone with a paired device, touch the device name in the

devices

list.

Bluetooth

Disconnect devices

To automatically disconnect your phone from a paired device, simply turn off the device.

To manually disconnect your phone from a paired device, touch the device name in the devices list, then touch Menu >

Disconnect

Edit properties

Touch Menu >

Bluetooth settings >Device name

> and touch

48 Wi-Fi®

Settings >Wireless & networks

. Enter a name

Wi-Fi®

home, office, or hotspot

Quick start: Wi-Fi

Find it: Menu >

Wi-Fi settings

Note: Your phone's Wi-Fi features and power levels

are not allowed for outdoor operation in France. To avoid unlawful interference with radio signals, do not use the Wi-Fi features in France unless you are indoors.

Use a wireless network for fast Internet access and to download data.

Settings >Wireless & networks

Turn Wi-Fi on or off

Find it: Touch Menu >

networks

Wi-Fi

Note: To extend battery life, turn off Wi-Fi power when

not in use.

Settings >Wireless &

Wi-Fi search & connect

To find networks in your range:

1 Touch Menu >

Wi-Fi settings

Wi-Fi

2 Touch

on, touch Menu > networks it finds within range.

Tip: To see your phone’s MAC address or other

Wi-Fi details, touch Menu >

3 Touch a network to connect.

4 If necessary, enter

Wireless password

phone is connected to the network, the wireless indicator appears in the status bar.

Tip: When you are in range and Wi-Fi is on, you will

automatically reconnect to available networks you’ve connected to before.

Settings >Wireless & networks

to turn on and scan. If Wi-Fi is already

Scan

. Your phone lists the

Advanced

Network SSID, Security

, and touch

Connect

, and

. When your

Wi-Fi hotspot

Note: You need to subscribe to Wi-Fi hotspot service

to use this feature. Contact your service provider.

You can set up your phone as a Wi-Fi hotspot to provide portable, convenient internet access to other Wi-Fi enabled devices.

Setup

Note: Risks can be associated with connecting to the

public internet. Your phone allows you to create a 3G Mobile Hotspot, which may be accessible by unauthorized users. It is highly recommended that you use a password and other possible steps to protect your computer from unauthorized access. To add security to your Wi-Fi hotspot:

Launcher icon

Find it:

Advanced >WiFi AP mode Settings

> >

3G Mobile Hotspot

Touch a setting to modify it:

• SSID—Enter a unique name for your hotspot and

touch

• Security—Select the type of security you want, and

Save: WEP, WPA

touch

, or

WPA2

. Enter a unique password. Other users can access your Wi-Fi hotspot only if they enter the correct password.

49Wi-Fi®

Note:

WEP

highly vulnerable to hacking.

is the weakest option because it is

WPA2

is recommended

by IEEE.

• Channel—Select a channel that minimizes potential

interference. You may need to try different channels after your hotspot is active for a time.

Save

Touch

when the settings are complete.

Activate hotspot

Find it:

Launcher icon

Tap to start Mobile Hotspot service

3G Mobile Hotspot

When your Wi-Fi hotspot is active, other Wi-Fi enabled

SSID

devices can connect by entering your hotspot’s

Security

selecting a

Wireless password

50 M emory card & file management

type, and entering the correct

Memory card & file management

copy photos, music, and more to your phone

Memory card

Note: You need the memory card installed for some

features on your phone, like

To insert a memory card, see “Assemble & charge” on page 4.

To see the files on your phone and memory card, touch

Launcher icon

open it. Touch and hold a file to

Delete

it.

Note: Do not remove your memory card while your

phone is using it or writing files on it.

Warning: When you format a memory card, all data on

the card is deleted.

To remove or format your memory card, you need to unmount it. Touch Menu >

phone storage

Unmount SD card

your memory card, touch

Camera

Files

. Touch a file or folder to

Share, Rename

Settings >SD card &

. Then, to format

Format SD card

, or

USB connection

You can connect your phone to a computer with a USB cable.

Note: The first time you use a USB connection, your

computer may indicate that drivers are being installed. Follow any prompts you see to complete the installation. This may take a few minutes.

1 With a memory card inserted, and your phone

showing the home screen, connect a Motorola micro USB data cable from your phone’s micro USB port to a USB port on your computer. Your phone should show in the status bar.

Note: Make sure to connect the phone to a high

power USB port. Typically, these are located directly on your computer.

2 On your phone, flick down the status bar to see the

USB connection options.

3 Touch an option:

PC Mode

•

Windows Media Sync

—Use Windows Media Player to sync media files on your computer and phone.

•

USB mass storage

—Drag and drop files between your computer and memory card folders. When you’re done, use “Safely Remove Hardware” before disconnecting the USB cable.

Note: You can’t use the files on your

memory card while it is connected.

•

Charge Only

—Use the connection to charge

your phone’s battery.

51Memory card & file management

Too ls

2:17

Alarm Name

7:00

Alarm Name

8:30

Alarm Name

9:00

Alarm Timer

Tuesday

Tue. Fri

January 2010

Sun Mon Tue Wed Thu Fri Sat

272829

30 31

stay on top of things

Alarm clock

Find it:

Launcher icon

To turn on an alarm, touch the check b ox.

When an alarm sounds, slide to

Dismiss

to turn it off or

to delay for five minutes.

To add an alarm, touch Menu > enter alarm details.

To enable or disable an alarm, touch the check box.

Note: Your phone’s clock

automatically adjusts to the local time when you travel internationally.

52 Tools

Add alarm

Snooze

, then

Alarm & Timer

Calendar

Find it:

Launcher icon

Your calendar events can be viewed in different ways: Touch Menu >

Week

Day, or

. When you highlight an event, more details appear.

Add calendar events

From any view, touch Menu > Enter the event start time and other details. You can even set a reminder so you don’t forget about the event. (When you set the reminder time to it plays at the event start time.)

Tip: Reminders will play only if you’ve selected a

notification ringtone (see “Ringtones” on page 40).

When you finish entering event details, touch

Manage calendar events

To edit an event, touch and hold it, then touch

event

. When you’re done, touch

To delete an event, touch and hold it, then

Delete event

touch

To go to today, touch Menu >

Agenda

Calendar

Save

More >New event

0minutes

Save

Edit

Today

Calculator

Find it:

Launcher icon

Your calculator has basic and advanced views. To change views, touch Menu >

Basic panel history

. To clear history, touch Menu >

Calculator

Advanced panel

Clear

Management

stay in control

Wireless manager

Find it: Menu >

Manage all your wireless connections: Wi-Fi®, Bluetooth®, airplane mode, & mobile networks (“Manually switch network mode (outside the U.S.)” on page 54).

Airplane mode

Use airplane mode to turn all your wireless connections off—useful when flying. Press Power/ Lock >

Note: When you select airplane mode, all wireless

services are disabled. You can then turn Wi-Fi and/or Bluetooth back on, if permitted by your airline. Other wireless voice and data services (such as calls and text messages) remain off in airplane mode. Emergency calls to your region's emergency number (e.g., 911) can still be made.

Settings >Wireless & networks

Airplane mode

53Management

Manually switch network mode (outside the U.S.)

In a few countries where both CDMA and GSM networks are present or where multiple GSM networks are available, you may have to manually switch to the appropriate network to get global data. For more information, go to verizonwireless.com/global

To manually switch the network mode on your phone, touch Menu >

Network mode >CDMA

Depending on your network, your phone shows additional options for network roaming, network selection, operator selection, and access point names.

Settings >Wireless & networks

GSM/UMTS

Data roaming (outside the U.S.)

Data roaming is turned off for your phone. You can turn it on to connect to data services when roaming globally:

Find it: Menu >

delivery

Data roaming

Note: You may incur significant roaming charges when

this feature is turned on. Go to verizonwireless.com/global coverage limitations and features.

54 M anagement

Settings >Data manager >Data

for rates, countries,

Update my phone

Stay up to date with the latest software for your phone. You can check, download, and install updates using your phone or your computer:

• Using your phone:

You may get an automatic notification of an available update on your phone. Follow the instructions to download and install.

To manually check for updates, touch Menu

Settings

Your phone downloads any updates over your mobile network. Remember, these updates can be quite large (25MB or more) and may not be available in all countries. If you don’t have an unlimited data plan, or mobile network updates are not available in your country, you can update using a computer.

• Using your computer:

On your computer, go to www.motorola.com/mydroid2global “Software” links. If an update is available, simply follow the installation instructions.

About phone

System updates

and check the

Security

help keep your phone safe

Quick start: Security

Find it: Menu >

Location & security settings

Security

Set up screen lock

Lock screen with a pattern, PIN, or password

Security lock timer

20 minutes

Manage restriction lock

Set up restriction lock

SIM card lock

SIM network lock settings

Passwords

Visible passwords

Show password as you type

Device administration

Select device administrators

You can set a pattern, PIN, or password to prevent unauthorized access to your device.

Settings >Location & security

1:53 PM

Select & set up a screen lock method.

Lock your GSM SIM card & change SIM PIN.

Touch to see the passwords you enter.

Screen lock

Note: You can make emergency calls on a locked

phone (see “Emergency calls” on page 15). A locked phone still rings, but you need to unlock it to

answer.

Lock the screen in the following ways:

• Press Power/Lock .

• Let the screen time out (don’t press anything).

• Switch the power off.

To unlock the screen, press Power/Lock . Then, drag to the right.

Lock pattern

Settings

To set the lock pattern, touch Menu >

Location & security >Set up screen lock >Pattern

Follow the instructions to draw your lock pattern.

When prompted, draw the pattern to unlock the phone.

Passcode lock

To set the passcode, touch Menu >

Location & security >Set up screen lock

Password

Settings

Enter the password, then confirm it.

55Security

When prompted, enter the password to unlock the phone.

Forgot your pattern or passcode?

If you forget your pattern or passcode, contact your service provider.

Reset

To reset your phone to factory settings and erase all

Settings

the data on your phone, touch Menu >

Privacy >Factory data reset >Reset phone

Warning: All data on your phone will be deleted.

(Nothing on your memory card is deleted.)

Remote wipe a lost or stolen phone

Don't you just hate it when your life is on your phone and it all goes wrong? Lost, or even worse—stolen! If necessary, you can use your email account on a Microsoft™ Exchange ActiveSync 2007 server to clear the personal data from your phone and memory card.

You need to be assigned permissions before you can remote wipe data from your phone and memory card.

Contact your IT system administrator for the information and permissions you need to perform the remote wipe procedure.

Warning: All downloaded apps and user data on your

phone and memory card will be deleted.

56 Gl obal Phone

Global Phone

Global Phone offers you reliable, consistent voice service at home and abroad. Use one phone and one number for voice coverage in more than 220 countries. Get one bill for both domestic and international calls. In order to get the full benefits of Global Phone service you must subscribe to a Global Phone calling plan and ensure that you have a SIM card installed. Go to verizonwireless.com/global coverage limitations and features.

Your phone comes with an installed SIM card that enables you to make and receive calls and text messages while traveling outside of the U.S. in supported destinations. Should your SIM card be lost or damaged, please follow these instructions to install a new SIM card:

1 Remove the battery cover and remove the battery.

2 Remove the SIM card from its packaging.

3 Hold the SIM card so that

the metal contacts on the SIM card face down and the cutoff corner of the SIM card points toward the top-left corner of your phone.

for rates, countries,

4 Slide the SIM card into the SIM card holder until it

stops.

5 Insert the battery so that

the metal contacts on the battery align with the metal contacts on your phone.

6 Place the battery cover

into the slots and push up, so that the cover clicks into place.

Yo u r SI M ( Subscriber Identity Module) card is a small rectangular plastic card that stores your phone number and other important information. Do not bend or scratch your SIM card. Avoid exposing your SIM card to static electricity, water or dirt. If your SIM card is lost or damaged while in the U.S., please dial from your Verizon Wireless device or 1-800-922-0204 from any phone to speak with a Customer Service Representative. From outside of the U.S., please refer to the Verizon Wireless Global Support Guide, welcome letter and calling card that came with your device. This will enable you to make calls toll free from landlines in most countries where we offer Global Phone service.

*611

Troubleshooting

Crash recovery

In the unlikely event that your phone stops responding to touches and key presses, try a quick reset. Remove the back cover and battery (“Assemble & charge” on page 4), then replace and switch your phone on as usual.

Service & Repairs

If you have questions or need assistance, we're here to help.

Go to www.motorola.com/repair www.motorola.com/support select from a number of customer care options. You can also contact the Motorola Customer Support Center at 1-800-734-5870 (United States), 1-888-390-6456 (TTY/TDD United States for hearing impaired), or 1-800-461-4575 (Canada).

(United States) or

(Canada), where you can

57Troubleshooting

Safety, Regulatory & Legal

032375o

Battery Use & Safety

Important: Handle and store batteries properly to avoid injury or damage.

Most battery issues arise from improper handling of batteries, and particularly from the continued use of damaged batteries.

DON’Ts

• Don’t disassemble, crush, puncture, shred, or otherwise attempt to change the form of your battery.

• Don’t let the mobile device or battery come in contact with water.*

can get into the mobile device’s circuits, leading to corr osion. If the mobile device and/or battery get wet, have them checked by your service provider or contact Motorola, even if they appear to be working properly.*

• Don’t allow the battery to touch metal objects.

jewelry, stay in prolonged contact with the battery contact points, the battery could become very hot.

• Don’t place your mobile device or battery near a heat source.*

heat can damage the mobile device or the battery. High temperatures can cause the battery to swell, leak, or malfunction. Therefore:

• Don’t dry a wet or damp battery with an appliance or heat source

a hair dryer or microwave oven.

DOs

• Do avoid leaving your mobile device in your car in high temperatures.*

• Do avoid dropping the battery or mobile device.*

especially on a hard surface, can potentially cause damage.*

• Do contact your service provider or Motorola if your mobile device or battery has been damaged from dropping or high temperatures.

* Note:

Always make sure that the battery compartment is closed and secure to

avoid direct exposure of the battery to any of these conditions.

If metal objects, such as

Excessive

Dropping these items,

Water

, such as

Important: Use Motorola Original products for quality assurance and safeguards.

To aid consumers in identifying authentic Motorola batteries from non-original or counterfeit batteries (tha t may not have adequate safety protection), Motorola provides holograms on its batteries. Consumers should confirm that any battery they purchase has a “Motorola Original” hologram.

Motorola recommends you always use Motorola-branded batteries and chargers.

Motorola mobile devices are designed to work with Motorola batteries.

If you see a message on your display such as

Unable to Charge

•

Remove the battery and inspect it to confirm that it has a “Motorola Original” hologram;

•

If there is no hologram, the battery is not a Motorola battery;

•

If there is a hologram, replace the battery and try charging it again;

•

If the message remains, contact a Motorola authorized service center.

Important:

Motorola’s warranty does not cover damage to the mobile device caused

by non-Motorola batteries and/or chargers.

Warning:

Use of a non-Motorola battery or charger may present a risk of fire,

explosion, leakage, or other hazard.

Proper and safe battery disposal and recycling:

only important for safety, it benefits the environment. Consumers may recycle their used batteries in many retail or service provider locations. Additional information on proper disposal and recycling may be found on the web:

•

www.motorola.com/recycling

•

www.rbrc.org/call2recycle/

Disposal:

Promptly dispose of used batteries in accordance with local regulations. Contact your local recycling center or national recycling organizations for more information on how to dispose of batteries.

Warning:

Never dispose of batteries in a fire because they may explode.

, take the following steps:

Invalid Battery

(in English only)

Proper battery disposal is not

Battery Charging

Battery Chargi ng

Notes for charging your product’s battery:

•

When charging your battery, keep it near room temperature. Never expose batteries to temperatures below 0°C (32°F) or above 45°C (113°F) when charging.

•

New batteries are not fully charged.

•

New batteries or batteries stored for a long time may take more time to charge.

•

Motorola batteries and charging systems have circuitry that protects the battery from damage from overcharging.

Driving Precautions

Responsible and safe driving is your primary responsibility when behind the wheel of a vehicle. Using a mobile device or accessory for a call or other application while driving may cause distraction. Using a mobile device or accessory may be prohibited or restricted in certain areas, al ways obey the laws and regulations on the use of these products.

While driving, NEVER:

•

Type or read texts.

•

Enter or review written data.

•

Surf the web.

•

Input navigation information.

•

Perform any other functions that divert your attention from driving.

While driving, ALWAYS:

•

Keep your eyes on the road.

•

Use a handsfree device if available or required by law in your area.

•

Enter destination information into a navigation device

•

Use voice activated features (such as voice dial) and speaking features (such as audible directions), if available.

•

Obey all local laws and regulations for the use of mobile devices and accessories in the vehicle.

•

End your call or other task if you cannot concentrate on driving. Remember to follow the “Smart Practices While Driving” in this guide and at www.motorola.com/callsmart

(in English only).

before

driving.

Seizures/Blackouts

Some people may be susceptible to epileptic seizures or blackouts when exposed to flashing lights, such as when playing videos or games. These may occur even if a person has never had a previous seizure or blackout. If you have experienced seizures or blackouts, or if you have a family history of s uch occurrences, please consult with your physician before playing videos or games or enabling a flashing-lights feature (if available) on your mobile device. Discontinue use and consult a physician if any of the following symptoms occur: convulsion, eye or muscle twitching, loss of awareness, involuntary movements, or disorientation. It is always a good idea to hold the screen away from your eyes, leave the lights on in the room, take a 15-minute break every hour, and stop use if you are tired.

Caution About High Volume Usage

Warning:

Exposure to loud noise from any source for extended periods of time may affect your hearing. The louder the volume sound level, the less time is required before your hearing could be affected. To protect your hearing:

•

Limit the amount of time you use headsets or headphones at high volume.

•

Avoid turning up the volume to block out noisy surroundings.

•

Turn the volume down if you can’t hear people speaking near you. If you experience hearing discomfort, including the sensation of pressure or fullness in your ears, ringing in your ears, or muffled speech, you s hould stop listening to the device through your headset or headphones and have your hearing checked. For more information about hearing, see our website at direct.motorola.com/hellomoto/nss/AcousticSafety.asp only).

(in English

Repetitive Motion

When you repetitively perform actions such as pressing keys or entering finger-written characters, you may experience occasional discomfort in your hands, arms, shoulders, neck, or other parts of your body. If you continue to have discomfort during or after such use, stop use and see a physician.

Small Children

032374o

032376o

032375o

Keep your mobile device and its accessories away from small children.

These products are not toys and may be hazardous to small children. For example:

•

A choking hazard may exist for small, detachable parts.

•

Improper use could result in loud sounds, possibly causing hearing injury.

•

Improperly handled batteries could overheat and cause a burn.

Glass Parts

Some parts of your mobile device may be made of glass. This glass could break if the product is dropped on a hard surface or receives a substantial impact. If glass breaks, do not touch or attempt to remove. Stop using your mobile device until the glass is replaced by a qualified service center.

Operational Warnings

Obey all posted signs when using mobile devices in public areas.

Potentially Explosive Atmospheres

Areas with potentially explosive atmospheres are often, but not always, posted and can include fueling areas, such as below decks on boats, fuel or chemical transfer or storage facilities, or areas where the air contains chemicals or particles, such as grain dust, or metal powders. When you are in such an area, turn off your mobile device, and do not remove, install, or charge batteries. In such areas, sparks can occur and cause an explosion or fire.

Symbol Key

Your battery, charger, or mobile device may contain symbols, defined as follows:

Symbol Definition

Important safety information follows.

Do not dispose of your battery or mobile device in a fire.

Your battery or mobile device may require recycling in accordance with local laws. Contact your local regulatory authorities for more information.

Do not dispose of your battery or mobile device with your household waste. See “Recycling” for more information.

For indoor use only.

Listening at full volume to music or voice through a headset may damage your hearing.

Radio Frequency (RF) Energy

Exposure to RF Energy

Your mobile device contains a transmitter and receiver. When it is ON, it receives and transmits RF energy. When you communicate with your mobile device, the system handling your call controls the power level at which your mobile device transmits. Your mobile device is designed to comply with local regulatory requirements in your country concerning exposure of human beings to RF energy.

RF Energy Operational Precautions

For optimal mobile device performance, and to be sure that human exposure to RF energy does not exceed the guidelines set forth in the relevant standards, always follow these instructions and precautions:

•

When placing or receiving a phone call, hold your mobile device just like you would a landline phone.

•

If you wear the mobile device on your body, always place the mobile device in a Motorola-supplied or approved clip, holder, holster, case, or body harness. If you do not use a body-worn accessory supplied or approved by Motorola, keep the mobile device and its antenna at least 2.5 centimeters (1 inch) from your body when transmitting.

•

Using accessories not supplied or approved by Motorola may cause your mobile device to exceed RF energy exposure guidelines. For a list of Motorola-supplied or approved accessories, visit our website at:

www.motorola.com

RF Energy Interference/Compatibility

Nearly every electronic device is subject to RF energy interference from external sources if inadequately shielded, designed, or otherwise configured for RF energy compatibility. In some circumstances, your mobile device may cause interference with other devices.

Follow Instructions to Avoid Interference Problems

Turn off your mobile device in any location where posted notices instruct you to do so. In an aircraft, turn off your mobile device whenever instructed to do so by airline staff. If your mobile device offers an airplane mode or similar feature, consult airline staff about using it in flight.

Implantable Medical Devices

If you have an implantable medical device, such as a pacemaker or defibrillator, consult your physician before using this mobile device. Persons with implantable medical devices should observe the following precautions:

•

ALWAYS keep the mobile device more than 20 centimeters (8 inches) from the implantable medical device when the mobile device is turned ON.

•

DO NOT carry the mobile device in the breast pocket.

•

Use the ear opposite the implantable medical device to minimize the potential

for interference.

•

Turn OFF the mobile device immediately if you have any reason to suspect that

interference is taking place. Read and follow the directions from the manufacturer of your implantable medical device. If you have any questions about using your mobile device with your implantable medical device, consult your healthcare provider.

Specific Absorption Rate (IEEE)

SAR (IEEE)

Your model wireless phone meets the governmental requirements for exposure to radio waves.

Your mobile device is a radio transmitter and receiver. It is designed and manufactured to not exceed limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission (FCC) of the U.S. Government and by the Canadian regulatory authorities. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed for the safety of all persons , regardless of age or health, and to account for any variations in measurements. The exposure standard for mobile devices employs a unit of measurement known as the Specific Absorption Rate (SAR). The IEEE SAR limit set by the FCC and by the Canadian regulatory authorities is 1.6 watts per kilogram (W/kg), averaged over one gram of tissue. Tests for SAR are conducted using procedures accepted by the FCC and by Industry Canada with the mobile device transmitting at its highest certified power level in all tested frequencies. Although the SAR is determined at the highest certified power level, the actual SAR level of the mobile device while operating can be below the maximum value. This is because the mobile device is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station, the lower the power output. Before a mobile device is available for sale to the public in the U.S. and Canada, it must be tested and certified to the FCC and Industry Canada that it does not exceed

the limit established by each government for safe exposure. The tests are performed in positions and locations (e.g., at the ear and worn on the body) submitted to the FCC and available for review by Industry Canada. The highest SAR value for this mobile device when tested for use at the ear is 1.58 W/kg, and when worn on the body, as described in this guide, is 0.89 W/kg. Body-worn measurements can differ, depending upon available accessories and regulatory requirements. The SAR information includes the Motorola testing protocol, assessment procedure, and measurement uncertainty range for this product. While there may be differences between the SAR levels of various mobile devices and at various positions, they meet the governmental requirements for safe exposure. Please note that improvements to this product model could cause differences in the SAR value for later products; in all cases, products are designed to be within the guidelines. Additional information on SAR can be found on the Cellular Telecommunications & Internet Association (CTIA) website: http://www.phonefacts.net or the Canadian Wireless Telecommunications Association (CWTA) website: http://www.cwta.ca

Information from the World Health Organization

WHO Information

“Present scientific information does not indicate the need for any special precautions for the use of mobile phones. If you are concerned, you may want to limit your own or your children’s RF exposure by limiting the length of calls or by using handsfree devices to keep mobile phones away from your head and body.” Source: WHO Fact Sheet 193 Further information:

http://www.who.int/peh-emf

European Union Directives Conformance Statement

EU Conformance

0168

Hereby, Motorola declares that this product is in compliance with:

•

The essential requirements and other relevant provisions of Directive 1999/5/EC

•

All other relevant EU Directives

0168

The above gives an example of a typical Product Approval Number. You can view your product’s Declaration of Conformity (DoC) to Directive 1999/5/EC (to R&TTE Directive) at Product Approval Number from your product’s label in the “Search” bar on the website.

FCC Notice to Users

FCC Notice

The following statement applies to all products that have received FCC approval. Applicable products bear the FCC logo, and/or an FCC ID in the format FCC ID:xxxxxx on the product label.

Motorola has not approved any changes or modifications to this device by the user. Any changes or modifications could void the user’s authority to operate the equipment. See 47 CFR Sec. 15.21. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. See 47 CFR Sec. 15.19(3).

www.motorola.com/rtte

[Only Indoor Use Allowed In France for Bluetooth and/or Wi-Fi]

Product Approval Number

. To find your DoC, enter the

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

•

Reorient or relocate the receiving antenna.

•

Increase the separation between the equipment and the receiver.

•

Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.

•

Consult the dealer or an experienced radio/TV technician for help.

Industry Canada Notice to Users

Industry Canada Notice

Operation is subject to the following two conditions: (1) This device may not cause interference and (2) This device must accept any interference, including interference that may cause undesired operation of the device. See RSS-GEN 7.1.5. This Class B digital apparatus complies with Canadian ICES-003.

GPS & AGPS

Your mobile device can use Global Positioning System (GPS) signals for location-based applications. GPS uses satellites controlled by the U.S. government that are subject to changes implemented in accordance with the Department of Defense policy and the Federal Radio Navigation Plan. These changes may affect the performance of location technology on your mobile device. Your mobile device can also use Assisted Global Positioning System (AGPS), which obtains information from the cellular network to improve GPS performance. AGPS uses your wireless service provider's network and therefore airtime, data charges, and/or additional charges may apply in accordance with your service plan. Contact your wireless service provider for details.

Your Location

Location-based information includes information that can be used to determine the approximate location of a mobile device. Mobile devices which are connected to a wireless network tran smit location-based information. Devices enabled with GPS or AGPS technology also transmit location-based information. Additionally, if you use applications that require location-based information (e.g. driving directions), such applications transmit location-based information. This location-based information may be shared with third parties, including your wireless service provider, applications providers, Motorola, and other third parties providing services.

Emergency Calls

When you make an emergency call, the cellular network may activate the AGPS technology in your mobile device to tell the emergency responders your approximate location. AGPS has limitations and

•

Always tell the emergency responder your location to the bes t of your ability; and

•

Remain on the phone for as long as the emergency responder instructs you.

might not work in your area

. Therefore:

Performance Tips

•

Go outside and away from underground locations, covered vehicles, structures

with metal or concrete roofs, tall buildings, and foliage. Indoor performance

might improve if you move closer to windows, but some window sun shielding

films can block satellite signals.

•

Move away from radios, entertainment equipment, and other electronic devices.

Navigation

When using navigation features, note that mapping information, directions and other navigational data may contain inaccurate or incomplete data. In some countries, complete information may not be available. Therefore, you should visually confirm that the navigational instructions are consistent with what you see. All drivers should pay attention to road conditions , closures, traffic, and all other factors that may impact driving. Always obey posted road signs.

Smart Practices While Driving

Driving Safety

Check the laws and regulations on the use of mobile devices and their accessories in the areas where you drive. Always obey them. The use of these devices may be prohibited or restricted in certain areas—for example, handsfree use only may be required. Go to

www.motorola.com/callsmart Your mobile device lets you communicate by voice and data—almost anywhere, anytime, wherever wireless service is available and safe conditions allow. When driving a car, driving is your first responsibility. If you choose to use your mobile device while driving, remember the following tips:

• Get to know your Motorola mobile device and its features such as speed dial, redial and voice dial.

call without taking your attention off the road.

• When available, use a handsfree device.

of convenience to your mobile device with one of the many Motorola Original handsfree accessories available today.

• Position your mobile device within easy reach.

mobile device without removing your eyes from the road. If you receive an incoming call at an inconvenient time, if possible, let your voicemail ans wer it for you.

• Let the person you are speaking with know you are driving; if necessary, suspend the call in heavy traffic or hazardous weather conditions.

sleet, snow, ice, and even heavy traffic can be hazardous.

• Do not take notes or look up phone numbers while driving.

“to do” list or going through your address book takes attention away from your primary responsibility—driving safely.

• Dial sensibly and assess the traffic; if possible, place calls when your car is not moving or before pulling into traffic.

moving, dial only a few numbers, check the road and your mirrors, then continue.

• Do not engage in stressful or emotional conversations that may be distracting.

Make people you are talking with aware you are driving and

suspend conversations that can divert your attention away from the road.

(in English only) for more information.

If available, these features help you to place your

If possible, add an additional layer

Be able to access your

Rain,

Jotting down a

If you must make a call while

• Use your mobile device to call for help.

number in the case of fire, traffic accident, or medical emergencies (wherever wireless phone service is available).

• Use your mobile device to help others in emergencies.

accident, crime in progress, or other serious emergency where lives are in danger, call 911 or other local emergency number (wherever wireless phone service is available), as you would want others to do for you.

• Call roadside assistance or a special non-emergency wireless assistance number when necessary.

posing no serious hazard, a broken traffic signal, a minor traffic accident where no one appears injured, or a vehicle you know to be stolen, call roadside assistance or other special non-emergency wireless number (wherever wireless phone service is available).

Privacy & Data Security

Privacy & Data Securit y

Motorola understands that privacy and data security are important to everyone. Because some features of your mobile device may affect your privacy or data security, please follow these recommendations to enhance protection of your information:

• Monitor access

others may have unmonitored access. Lock your device’s keypad where this feature is available.

• Keep software up to date

releases a patch or software fix for your mobile device that updates the device’s security, install it as soon as possible.

• Secure Personal Information

information in various locations including your SIM card, memory card, and phone memory. Be sure to remove or clear all personal information before you recycle, return, or give away your device. You can also backup your personal data to transfer to a new device.

Note:

go to

—Keep your mobile device with you and do not leave it where

—If Motorola or a software/application vendor

For information on how to backup or wipe data from your mobile device,

www.motorola.com/support

Dial 911 or other local emergency

If you see an auto

If you see a broken-down vehicle

—Your mobile device can store personal

• Online accounts

(such as MOTOBLUR). Go to your account for information on how to manage the account, and how to use security features such as remote wipe and device location (where available).

• Applications

Applications can have access to private information such as call data, location details and network resources.

• Location-based information

information that can be used to determine the approximate location of a mobile device. Mobile phones which are connected to a wireless network transmit location-based information. Devices enabled with GPS or AGPS technology also transmit location-based information. Additionally, if you use applications that require location-based information (e.g. driving directions), such applications transmit location-based information. This location-based information may be shared with third parties, including your wireless service provider, applications providers, Motorola, and other third parties providing services.

• Other information your device may transmit

testing and other diagnostic (including location-based) information, and other non-personal information to Motorola or other third-party servers. This

information is used to help improve products and services offered by Motorola. If you have further questions regarding how the use of your mobile device may impact your privacy or data security, please contact Motorola at privacy@motorola.com

—Some mobile devices provide a Motorola online account

—Install third party applications from trusted sources only.

—Location-based information includes

—Your device may also transmit

, or contact your service provider.

Use & Care

To care for your Motorola mobile device, please observe the following:

liquids

Don’t expose your mobile device to water, rain, extreme humidity, sweat, or other liquids. If it does get wet, don’t try to accelerate drying with the use of an oven or dryer, as this may damage the mobile device.

extreme heat or cold

Avoid temperatures below 0°C/32°F or above 45°C/113°F.

microwaves

Don’t try to dry your mobile device in a microwave oven.

dust and dirt

Don’t expose your mobile device to dust, dirt, sand, food, or other inappropriate materials.

cleaning solutions

To clean your mobile device, use only a dry soft cloth. Don’t use alcohol or other cleaning solutions.

shock and vibration

Don’t drop your mobile device.

protection

To help protect your mobile device, always make sure that the battery compartment and any connector covers are closed and secure.

Recycling

Mobile Devices & Accessories

Please do not dispose of mobile devices or electrical accessories (such as chargers, headsets, or batteries) with your household waste, or in a fire. These items should be disposed of in accordance with the national collection and recycling schemes operated by your local or regional authority. Alternatively, you may return unwanted mobile devices and electrical accessories to any Motorola Approved Service Center in your region. Details of Motorola approved national recycling schemes, and further information on Motorola recycling activities can be found at: www.motorola.com/recycling

Packaging & Product Guides

Product packaging and pr oduct guides should only be disp osed of in accordance with national collection and recycling requirements. Please contact your regional authorities for more details.

California Perchlorate Label

Perchlorate Label

Some mobile phones use an internal, permanent backup battery on the printed circuit board that may contain very small amounts of perchlorate. In such cases, California law requires the following label: Perchlorate Material – special handling may apply when the battery is recycled or disposed of. See There is no special handling required by consumers.

www.dtsc.ca.gov/hazardouswaste/perchlorate

Hearing Aid Compatibility with Mobile Phones

Hearing Aid Compat ibili ty

Some Motorola phones are measured for compatibility with hearing aids. If the box for your particular model has “Rated for Hearing Aids” printed on it, the following explanation applies. When some mobile phones are used near some hearing devices (hearing aids and cochlear implants), users may detect a buzzing, humming, or whining noise. Some hearing devices are more immune than others to this interference noise, and phones also vary in the amount of interference they generate. The wireless telephone industry has developed ratings for some of their mobile phones, to assist hearing device users in finding phones that may be compatible with their hearing devices. Not all phones have been rated. Phones that are rated have the rating on their box or a label on the box. To maintain the published Hearing Aid Compatibility (HAC) rating for this mobile phone, use only the original equipment battery model. The ratings are not guarantees. Results will vary depending on the user’s hearing device and hearing loss. If your hearing device happens to be vulnerable to interference, you may not be able to use a rated phone successfully. Trying out the phone with your hearing device is the best way to evaluate it for your personal needs.

M-Ratings:

Phones rated M3 or M4 meet FCC requirements and are likely to generate less interference to hearing devices than phones that are not labeled. M4 is the better/higher of the two ratings.

T-Ratings:

Phones rated T3 or T4 meet FCC requirements and are likely to be more usable with a hearing device’s telecoil (“T Switch” or “Telephone Switch”) than unrated phones. T4 is the better/higher o f the two ratings. (Note that not all hearing devices have telecoils in them.) Hearing devices may also be measured for immunity to this type of interference. Your hearing device manufacturer or hearing health professional may help you find results for your hearing device. The more immune your hearing aid is, the less likely you are to experience interference noise from mobile phones.

Software Copyright Notice

Motorola products may include copyrighted Motorola and third-party software stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola and third-party software providers certain exclusive rights for copyrighted software, such as the exclusive rights to distribute or reproduce the copyrighted software. Accordingly, any copyrighted software contained in Motorola products may not be modified, reverse-engineered, distributed, or reproduced in any manner to the extent allowed by law. Furthermore, the purchase of Motorola products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents, or patent applications of Motorola or any third-party software provider, except for the normal, non-exclusive, royalty-free license to use that arises by operation of law in the sale of a product.

Content Copyright

The unauthorized copying of copyrighted materials is contrary to the provisions of the Copyright Laws of the United States and other countries. This device is intended solely for copying non-copyrighted materials, materials in which you own the copyright, or materials which you are authorized or legally permitted to copy. If you are uncertain about your right to copy any material, please contact your legal advisor.

Open Source Software Information

OSS Information

For instructions on how to obtain a copy of any source code being made publicly available by Motorola related to software used in this Motorola mobile device, you may send your request in writing to the address below. Please make sure that the request includes the model number and the software version number. MOTOROLA MOBILITY, INC. OSS Management 600 North US Hwy 45 Libertyville, IL 60048 USA

The Motorola website regarding Motorola's use of open source. Motorola has created the portal for interaction with the software community-at-large. To view additional information regarding licenses, acknowledgments and required copyright notices for open source packages used in this Motorola mobile device, please press Menu Key > >

Legal information >Open source licenses

Motorola device may include self-contained applications that present supplemental notices for open source packages used in those applications.

Export Law Assurances

Export Law

This product is controlled under the export regulations of the United States of America and Canada. The Governments of the United States of America and Canada may restrict the exportation or re-exportation of this product to certain destinations. For further information contact the U.S. Department of Commerce or the Canadian Department of Foreign Affairs and International Trade.

Product Registration

Registration

Online Product Registration: www.motorola.com/us/productregistration Product registration is an important step toward enjoying your new Motorola product. Registering permits us to contact you for product or software updates and allows you to subscribe to updates on new products or special promotions. Registration is not required for warranty coverage. Please retain your original dated sales receipt for your records. For warranty service of your Motorola Personal Communications Product you will need to provide a copy of your dated sales receipt to confirm warranty status. Thank you for choosing a Motorola product.

opensource.motorola.com

Settings >About Phone

also contains information

website to serve as a

. In addition, this

Motorola Limited Warranty for the United States and Canada

Warra nty

What Does this Warranty Cover?

Subject to the exclusions contained below, Motorola Mobility, Inc. warrants its mobile telephones (“Products”), Motorola-branded or certified accessories sold for use with these Products (“Accessories”), and Motorola software contained on CD-ROMs or other tangible media and sold for use with these Products (“Software”) to be free fr om defects in materials and wor kmanship unde r normal consumer usage for the period(s) outlined below. This limited warranty is a consumer's exclusive remedy, and applies as follows to new Motorola Products, Accessories, and Software purchased by consumers in the United States or Canada, which are accompanied by this written warranty:

Products and Accessories

Products Covered Length of Coverage

Products and Accessories

defined above, unless otherwise provided for below.

Decorative Accessories and Cases.

Decorative covers, bezels, PhoneWrap™ covers and cases.

Monaural Headsets.

and boom headsets that transmit mono sound through a wired connection.

Products and Accessories that are Repaired or Replaced.

Ear buds

One (1) year

the first consumer purchaser of the product unless otherwise provided for below.

Limited lifetime warranty

lifetime of ownership by the first consumer purchaser of the product.

Limited lifetime warranty

lifetime of ownership by the first consumer purchaser of the product.

The balance of the original warranty or for ninety (90) days

returned to the consumer, whichever is longer.

from the date of purchase by

for the

from the date

Exclusions (Products and Accessories)

Normal Wear and Tear.

due to normal wear and tear are excluded from coverage.

Batteries.

Only batteries whose fully charged capacity falls below 80% of their

rated capacity and batteries that leak are covered by this limited warranty.

Abuse & Misuse.

storage, misuse or abuse, accident or neglect, such as physical damage (cracks, scratches, etc.) to the surface of the product resulting from misuse; (b) contact with liquid, water, rain, extreme humidity or heavy perspiration, sand, dirt or the like, extreme heat, or food; (c) use of the Products or Accessories for commercial purposes or subjecting the Product or Accessory to abnormal usage or conditions; or (d) other acts which are not the fault of Motorola, are excluded from coverage.

Use of Non-Motorola Products and Accessories.

from the use of non-Motorola branded or certified Products, Accessories, Software or other peripheral equipment are excluded from coverage.

Unauthorized Service or Modification.

service, testing, adjustment, instal lation, maintenance, alteration, or modification in any way by someone other than Motorola, or its authorized service centers, are excluded from coverage.

Altered Products.

that have been removed, altered or obliterated; (b) broken seals or that show evidence of tampering; (c) mismatched board serial numbers; or (d) nonconforming or non-Motorola housings, or parts, are excluded from coverage.

Communication Services.

Accessories or Software due to any communication service or signal you may subscribe to or use with the Products Accessories or Software is excluded from coverage.

Periodic maintenance, repair and replacement of parts

Defects or damage that result from: (a) improper operation,

Defects or damage that res ult

Defects or damages resulting from

Products or Accessories with (a) serial numbers or date tags

Defects, damages, or the failure of Products,

Software

Products Covered Length of Coverage

Applies only to physical defects in the

Software.

media that embodies the copy of the software (e.g. CD-ROM, or floppy disk).

Ninety (90) days

the date of purchase.

from

Exclusions (Software)

Software Embodied in Physical Media.

will meet your requirements or will work in combination with any hardware or software applications provided by third parties, that the operation of the software products will be uninterrupted or error free, or that all defects in the software products will be corrected.

Software NOT Embodied in Physical Media.

physical media (e.g. software that is downloaded from the Internet), is provided “as is” and without warranty.

Who is Covered?

This warranty extends only to the first consumer purchaser, and is not transferable.

No warranty is made that the software

Software that is not embodied in

What Will Motorola Do?

Motorola, at its option, will at no charge repair, replace or refund the purchase price of any Products, Accessories or Software that does no t conform to this warranty. We may use functionally equivalent reconditioned/refurbished/pre-owned or new Products, Accessories or parts. No data, software or applications added to your Product, Accessory or Software, including but not limited to personal contacts, games and ringer tones, wi ll be reinstalled. To avoid losing such data, software, and applications, please create a back up prior to requesting service.

How to Obtain Warranty Service or Other Information

USA

Canada

TTY

You will receive instructions on how to ship the Products, Accessories or Software, at your expense, t o a Motorola Authorized Repair Center. To obtain service, you must include: (a) a c opy of your receipt, bill of sale or other comparable proof of purchase; (b) a written description of the problem; (c) the name of your service provider, if

1-800-734-5870

1-800-461-4575

1-888-390-6456

applicable; (d) the name and location of the installation facility (if applicable) and, most importantly; (e) your address and telephone number.

What Other Limitations are There?

ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED TO THE DURATION OF THIS LIMITED WARRANTY, OTHERWISE THE REPAIR, REPLACEMENT, OR REFUND AS PROVIDED UNDER THIS EXPRESS LIMITED WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER, AND IS PROVIDED IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED. IN NO EVENT SHALL MOTOROLA BE LIABLE, WHETHER IN CONTRACT OR TORT (INCLUDING NEGLIGENCE) FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF THE PRODUCT, ACCESSORY OR SOFTWARE, OR FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES OF ANY KIND, OR LOSS OF REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF INFORMATION OR DATA, SOFTWARE OR APPLICATIONS OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION WITH THE ABILITY OR INABILITY TO USE THE PRODUCTS, ACCESSORIES OR SOFTWARE TO THE FULL EXTENT THESE DAMAGES MAY BE DISCLAIMED BY LAW.

Some states and jurisdictions do not allow the limitation or exclusion of incidental or consequential damages, or limitation on the length of an implied warranty, so the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights, and you may also have other rights that vary from state to state or from one jurisdiction to another.

Motorola Mobility, Inc. Consumer Advocacy Office 600 N US Hwy 45 Libertyville, IL 60048 www.hellomoto.com

Note:

Do not ship your product to the above address. If you need to return your product for repairs, replacement, or warranty service, please contact the Motorola Customer Support Center at: 1-800-734-5870 (United States) 1-888-390-6456 (TTY/TDD United States for hearing impaired) 1-800-461-4575 (Canada) Certain features, services and applications are network dependent and may not be available in all areas; additional terms, conditions and/or charges may apply. Contact your service provider for details. All features, functionality, and other product specifications, as well as the information contained in this guide, are based upon the latest available information and believed to be accurate at the time of printing. Motorola reserves the right to change or modify any information or specifications without notice or obligation. MOTOROLA, the Stylized M Logo, MOTOBLUR and the MOTOBLUR logo are trademarks or registered trademarks of Motorola Trademark Holdings, LLC. DROID is a trademark of Lucasfilm Ltd. and its related companies. Used under license. The Bluetooth trademarks are owned by their proprietor and used by Motorola Mobility, Inc. under license. is a Certification Mark of the Wireless Fidelity Alliance, Inc. Google, the Google logo, Google Maps, Gmail, YouTube, Picasa, Android and Android Market are trademarks of Google, Inc. Facebook is a registered trademark of Facebook, Inc. Microsoft, Windows, Windows Me, and Windows Vista are registered trademarks of Microsoft Corporation in the United States and other countries. Apple, Macintosh, Quicktime and Quicktime logo are registered trademarks of Apple Computer, Inc. All other product or service names are the property of their respective owners. © 2011 Motorola Mobility, Inc. All rights reserved.

Caution:

Changes or modificat ions made in the radio phone, no t expressly approved by Motorola, will void the user’s authority to operate the equipment. Product ID: Motorola A956 Manual Number: 68014291001-B

Motorola DROID 2 GLOBAL User Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Congratulations

Your phone

Contents

Let’s go

Assemble & charge

Set up & go

Wi-Fi® connect

Cool content & more

Touchscreen & keys

Touchscreen on/off

Touch tips

Key tips

Rotate the screen

Quick tips

Home screen

Quick start: Home screen

Use & change your home screen

Search

Notifications & phone status

Apps

Quick start: Apps

Browse & install apps

Recent apps

Manage & restore apps

Calls

Select a network

Quick start: Calls

Make & answer calls

End calls

Make calls (outside the U.S.)

Recent calls

Frequent calls

Conference calls

Your phone number

TTY mode

Emergency calls

Cool down

Contacts

Quick start: Contacts

Call or email contacts

View & use contacts

Edit or delete contacts

Link contacts

Create contacts

Synchronize contacts

Groups

Messaging

Quick start: Messaging

Read & reply to messages

Create messages

Send & receive attachments

Set up messaging

Email

Instant messages

Voi c e m ail

Social networking

Your social networking account

Add accounts

Edit & delete accounts

Text entry

Typing tips

Touchscreen keypad

Input methods

Text entry settings

Tips & tricks

General tips

Battery tips

Digital living

BLOCKBUSTER videos

Media Share

Photos & videos

Photos

Videos

View photos & videos

Music

Quick start: Music
