DM4000 Series Mobile
Radios Quick Reference
Guide

Important Safety Information

Product Safety and
RF Exposure Compliance

Before using this product, read
the operating instructions for
safe usage contained in the
Product Safety and RF
Exposure booklet enclosed with
your radio.

This radio is restricted to occupational
use only to satisfy FCC/ICNIRP RF
energy exposure requirements. Before

using this product, read the RF energy
awareness information and operating
instructions in the Product Safety and RF
Exposure booklet enclosed with your radio
(Motorola Publication part number
6866537D37) to ensure compliance with RF
energy exposure limits.

For a list of Motorola-approved antennas,
batteries, and other accessories, visit the
following website:

http://www.motorolasolutions.com

ATTENTION!

Computer Software Copyright

The Motorola products described in this manual
may include copyrighted Motorola computer
programmes stored in semiconductor memories
or other media. Laws in the United States of
America and other countries preserve for
Motorola Europe and Motorola Solutions Inc.
certain exclusive rights for copyrighted
computer programmes including, but not limited
to, the exclusive right to copy or reproduce in
any form the copyrighted computer programme.
Accordingly, any copyrighted Motorola
computer programmes contained in the
Motorola products described in this manual may
not be copied, reproduced, modified,
reverse-engineered, or distributed in any
manner without the express written permission
of Motorola. Furthermore, the purchase of
Motorola products shall not be deemed to grant
either directly or by implication, estoppel, or
otherwise, any licence under the copyrights,
patents, or patent applications Motorola, except
for the normal non-exclusive licence to use that
arises by operation of the law in the sale of the
product.

Your Quick Reference Guide

This Quick Reference Guide covers the
basic operation of the DM4000 Series
MOTOTRBO Mobile Radios. For more
operational details, refer to your User Guide.

Check with your dealer or system
administrator because your radio may have
been customized for your specific needs.

Powering Up and Turning Off
the Radio

To turn on the radio, press the On/Off button
briefly.

To turn off the radio, press and hold the
On/Off button.

Adjusting the Volume

To incease the volume, turn the Volume/
Channel Knob clockwise.

To decrease the volume, turn the Volume/
Channel Knob counterclockwise.

1

English

Radio Controls

P1 P2 P3 P 4

OK

MENU

8 7910

1 3 4 5 62

1

23456

7

8910

Record your radio’s programmable button functions in the blanks provided.

SP represents Short Press.
LP represents Long Press.

On/Off Button
Volume/Channel Knob
Display
OK/Menu Button
Scroll Up/Down
Speaker
Return/Home Button

†

†

†

Front Buttons (Programmable)
P1 - SP: ______ LP: _______
P2 - SP: ______ LP: _______
P3 - SP: ______ LP: _______
P4 - SP: ______ LP: _______

Accessory Connector
LED Indicators

†

Not for Numeric Display radio models

LED Indicator

Blinking red – Radio is receiving an

emergency transmission or has failed the
self-test upon powering up, or has moved
out of range if radio is configured with
Auto-Range Transponder System.

Solid green – Radio is powering up, or
transmitting.

Blinking green – Radio is receiving a
non-privacy-enabled call or data, or
detecting activity or retrieving Over-the-Air
Programming transmissions over the air.

Double blinking green – Radio is receiving
a privacy-enabled call or data.

Solid yellow – Radio is monitoring a
conventional channel or in Bluetooth
Discoverable Mode.

Blinking yellow – Radio is scanning for
activity or receiving a Call Alert, or all local
Linked Capacity Plus channels are busy.

Double blinking yellow – Radio is no
longer connected to the repeater while in
Capacity Plus or Linked Capacity Plus, all
Capacity Plus channels or Linked Capacity
Plus channels are currently busy, Auto
Roaming is enabled, radio is actively
searching for a new site. Also indicates
radio has yet to respond to a group call
alert, or radio is locked.

English

2
