Installation Plan
Washing Machine
PW 6068 LP
Read all operation and installation instructions prior to
assembly, installation, and initial operation
to prevent injury and machine damage.
en - US
10 441 630/ 00
Legend:
Connection required
Connection optional or required for
a specific model
AV
Drain valve
KW
Cold water connection
AW
Waste water connection
LP
Soap water pump
B
Appliance fastening
PA
Equipotential bonding
BW
Service water connection
SLA
Peak load connection
DOS
Dosing unit connection
UG
Base, closed
EL
Electrical connection
UO
Base, open
F
Adjustable appliance mounts
WTV
Washer/dryer connection
KG
Payment device
WW
Hot water connection
KGA
Payment device connection
XKM
Communication module
Alteration rights reserved 08/14/155
2 10 441 630/ 00
PW 6068 en - US
Appliance Dimensions PW 6068
10 441 630 / 00 3
en - US PW 6068
Installation PW 6068
4 10 441 630/ 00
PW 6068 en - US
Washer/Dryer Stack PW 6068
10 441 630 / 00 5
en - US PW 6068
Assembly
6 10 441 630/ 00
PW 6068 en - US
Assembly
10 441 630 / 00 7
en - US PW 6068
Technical Data
PW 6068 LP
Drum volume
59 l
Filling weight
14.3 lbs (6.5 kg)
Loading door, diameter
11 1/8“ (282 mm)
Max. spin speed
1400 RPM
g-factor
526 Residual moisture (standard load)
49%
Electrical connection (EL)
Standard voltage (US only)
2 AC 208-240 V
Frequency
60 Hz
Total connections
4.0 kW
Fuse protection
2 x 30 A
Connection cable, minimum cross-section
4 x AWG 10 mm²
Connection cable without plug for permanent wiring
Connection cable, length
6‘ 6 ¾“ (2000 mm)
Standard voltage (CDN only)
2 AC 208 V
Frequency
60 Hz
Total connections
4.0 kW
Fuse protection
2 x 20 A
Connection cable, minimum cross-section
4 x AWG10 mm²
Connection cable without plug for permanent wiring
Connection cable, length
6‘ 6 ¾“ (2000 mm)
Cold water (KW)
Permissible water flow pressure
100 – 1000 kPa
Required volume flow (cold water connection only)
11 l/min
Required volume flow (for additional hot water connection)
10 l/min
Average water consumption (60°C standard program)
40 l/h User-supplied connection with external thread as per DIN 44991 (flat sealing)
¾“
Connection hose ½“ with screw fitting ¾“
Connecting hose, length
5‘ 1“ (1550 mm)
Hot water (WW)
Max. inlet temperature
158°F (70°C)
Permissible water flow pressure
100 – 1000 kPa
Required volume flow
11 l/min
Average water consumption (60°C standard program)
13 l/h User-supplied connection with external thread (flat sealing)
¾“
Connection hose ½“ with screw fitting ¾“
Connecting hose, length
5‘ 1“ (1550 mm)
Service water (BW)
Kit with additional inlet valve
Permissible water flow pressure
100 – 1000 kPa
Required volume flow
11 l/min
Average water consumption (60°C standard program)
17 l/h User-supplied connection with external thread as per DIN 44991 (flat sealing)
¾“
Connection hose ½“ with screw fitting ¾“
Connecting hose, length
5‘ 1“ (1550 mm)
Drain valve (AV)
Connecting piece (external diameter)
-
Max. waste water temperature
Max. short-time flow volume
-
Soap pump (LP)
Hose connector (external diameter)
7/8“ (22 mm)
(DN22)
Max. waste water temperature
194°F (90°C)
= standard, = optional, + = only upon enquiry, - not available
8 10 441 630/ 00
PW 6068 en - US
Technical Data
PW 6068 LP
User-supplied hose nozzle (internal diameter x length)
7/8“ x 1 3/16“
(22 x 30 mm)
Max. short-time flow volume
26 l/min
Max. delivery head (from appliance bottom edge)
3‘ 3 3/8“ (1000 mm)
Drain hose DN22 with connector (supplied)
Connecting hose, length
4‘ 11 1/16“
(1500 mm)
Equipotential bonding (PA)
Appliance connection (with separate kit)
Peak load/energy management (SLA)
Appliance connection (with separate kit)
Connection voltage of the control contacts
AC 230 V
Payment device connection (KGA)
Connection of payment devices
Communication module (XKM)
RS 232 interface (XKM module retrofit kit)
Liquid dosing system (DOS)
Connection for liquid dosing media (retrofit kit required)
-
Connection for liquid dosing media
Max. number of dosing pumps
Number
6
Installation with device mount (F)
Number of device mounts
Number
4
Device mount, threaded height-adjustment
± 3/16“ (4 mm)
Device mount diameter
1 9/16“ (40 mm)
Mounting (B)
Floor mounting, standard
Mounting kit (for 2 device mounts) with mounting bracket
Wood screw as per DIN 571
¼“ x 2“ (6 x 50 mm)
Dowel (diameter x length)
5/16“ x 1 9/16“
(8 x 40 mm)
Floor mounting, Miele base
Accessories for Miele base (fasteners supplied with product)
Required fastening points
Number
4
Wood screw as per DIN 571
5/16“ x 2 9/16“
(8 x 65 mm)
Dowel (diameter x length)
½“ x 2 3/8“
(12 x 60 mm)
Floor mounting, elevated platform (user-provided)
Floor mounting on user-supplied platform (concrete or masonry)
Min. platform surface (W/D)
23 5/8“ / 25 9/16“
(600 mm / 650mm)
Wood screw as per DIN 571
¼“ x 2“ (6 x 50 mm)
Dowel (diameter x length)
5/16“ x 1 9/16“
(8 x 40 mm)
Appliance data
Overall appliance dimensions (H/W/D)
2‘ 9 7/16“ / 1‘ 11
5/8“ / 2‘ 9 7/16“
(850 mm / 600 mm
/ 722 mm)
Housing dimensions (H/W/D)
2‘ 9 7/16“ /
1‘ 11/7/16“ /
2‘ 3 7/16“
(850 mm / 595 mm
/ 697 mm)
Transport dimensions (H/W)
Min. entry opening (without packaging)
2‘ 11 7/16“ /
1‘ 11 5/8“
(900 mm / 600 mm)
= standard, = optional, + = only upon enquiry, - not available
10 441 630/ 0 9
en - US PW 6068
Technical Data
PW 6068 LP
Installation dimensions
Min. clearance appliance to side
13/16“ (20 mm)
Recommended clearance appliance to side, washer/dryer stack
>11 ¾“ (300 mm)
Min. wall clearance from appliance front
2‘ 11 7/16“
(900 mm)
Recommended min. wall clearance from appliance front
3‘ 7 5/16“
(1100 mm)
Weights and loads
Appliance weight (net weight)
234 lbs (106 kg)
Max. floor load during operation
2820 N
Max. static floor load
1455 N
Max. dynamic floor load
1365 N
Drum max. rotary frequency
22 Hz
Appliance emissions
Emission sound pressure level at a workplace
<70 dB(A)
Heat emission into the installation space
250 W
Options / Accessories
Features
Base, closed (UG)
Base closed, H 11 13/16“ (300 mm) (UG 5005)
Base galvanized, stainless steel side panels
Base closed, H 1‘ 6 ½“ (470 mm) (UG 5005-47)
Base galvanized, "octoblue" heat cure coated side panels
Base closed, H 2‘ 5 ½“ (750 mm) (UG 5005-75)
Base galvanized, "octoblue" heat cure coated side panels
Base, open (UO)
Base open, H 11 13/16“ (300 mm) (UO 5005)
Base galvanized, "octoblue" heat cure coated surface
Base open, H 1‘ 6 ½“ (470 mm) (UO 5005)
Base galvanized, "octoblue" heat cure coated surface
Washer/dryer connection (WTV)
Stainless steel kit (WTV 5062)
Kit for the connection of washer and dryer
"Lotus white" kit (WTV 5061)
Kit for the connection of washer and dryer
Payment devices (KG)
Single-unit operation (C 4060)
Payment device for tokens, program operation only
Single-unit operation (C 4065)
Payment device with coins, time and program operation
Single-unit operation (C 4070)
Payment device for coins and tokens, time and program operation
Multi-unit operation (C 5200 BT)
Basic unit, debit card payment device (for max. 8 terminals)
Remote bundle (ABT 5220)
Terminal monitoring with Bluetooth communication (required for each terminal)
Accessories
Peak load/energy management connection (BSS)
Connection for peak load and energy management functions
Equipotential bonding kit
The assembly kit can be ordered from Customer Service.
XKM communication module (XKM RS 232-10)
Retrofit kit XKM module with RS 232 incl. installation kit
= standard, = optional, + = only upon enquiry, - not available
10 10 441 630/ 00
PW 6068 en - US
Installation and planning notes
Installation prerequisites
The appliance must be connected only to a system designed in
accordance with national legislation, regulations and directives, as
well as local codes and standards.
In addition, all regulations by utilities, accident prevention regulations,
insurance guidelines and recognized codes of practice valid at the
installation site must be adhered to.
Transport and placement
The washing machine must not be transported without transport
safety. Do not discard the transport safety, because you will have to
reinstall it prior to transporting the washing machine (during a move,
for example).
General conditions of operation
Ambient temperature of the installation space: +35°F (2°C) to +95°
(35°C).
Depending on the properties of the installation site, noise and/or
vibrations may be transmitted into the building. It is recommended to
have a noise protection expert examine the appliance's installation
site when more stringent demands on sound insulation are made.
Electrical connection
Depending on the design, the appliance may be fitted with a
connection cable with or without a plug.
The appliance must be connected only to an electric supply designed
in accordance with national and local regulations. The installation
must be performed by a qualified electrician.
The appliance data plate indicates the nominal power consumption
and the appropriate fuse capacity. Compare the specifications on the
data plate with those of the electrical power supply.
The appliance can be connected either via a permanent connection or
a plug-in connection. However, we recommend connecting the
appliance via a plug connection so that an electrical safety check can
be carried out, e.g. during repair or maintenance.
If a permanent connection is intended, an all-pole disconnection
device must be provided at the installation side. Disconnect devices
may be switches with a contact gap of more than 3 mm, such as
MCBs, fuses and guards.
The plug-in connection or disconnect device must be accessible at all
times. You must be able to lock the separator or monitor it at all times
in case the appliance has to be disconnected from the power supply.
Only a certified or approved electrician may perform the initial
installation of the connection, change the system or inspect the
ground conductor, including a determination of the correct protection,
because they are familiar with the relevant regulations and the
particular requirements by the electrical utility.
Hot water connection
The connection conditions for the hot water connection to up to 158°F
(70°C) are the same as those for the cold water connection.
A suitable connection hose with screw fitting is supplied with the
appliance.
The appliance may be connected to a hot water system from 158°
(70°C) to 185° (85°C) max., however, you will require a special heatresistant inlet hose.
Purchase this inlet hose from a Miele authorized distributor or Miele
Customer Service. In addition, the appliance must be programmed
correspondingly by Miele Technical Service or an authorized dealer.
For functional reasons, it is not possible to connect the appliance
to a hot water supply only.
If the building does not have a hot water supply, the hot water
connection must be connected to an existing cold water supply.
Alternatively, close the hot water connection with the supplied dummy
cap and convert the appliance controller to colt water inlet.
In this event, you must add the water demand for hot water to the cold
water demand.
Service water connection
The service water connection can be optionally retrofitted using an
additional kit.
The same connection conditions as for the cold water connection
apply.
Soap water pump
The appliance drains through a pump with a 1 m delivery head. For
the water to drain freely, the hose must be free of kinks. The elbow at
the hose end can be rotated and removed, if necessary.
Water drain options:
1. Direct connection to a plastic pipe with rubber sleeve (syphon not
mandatory).
2. Attach to a sink with a plastic fitting
3. Drain into a floor drain (gully).
Comply with the switch-over instructions on the wiring diagram
when switching the appliance to a different voltage. Only
authorized distributors or Miele customer service representatives
may convert the appliance. In this event, it is also necessary to
adjust the heat output.
Devices for an automatic shut-down of the appliance (such as timers)
must not be installed.
The conductor cross-section information in the technical data refers
only to the required connecting cable. Refer to the applicable national
and local regulations for calculating the other dimensions.
Cold water connection
You may connect the washing machine to a drinking water system
without a backflow preventer because it has been designed according
to the applicable standards for drinking water protection.
For the connection, you require a water shut-off valve or a tap with
connecting thread. If such is missing, only an authorized plumber may
connect the appliance to the drinking water pipe.
A suitable connection hose with screw fitting is supplied with the
appliance.
Authorized Miele distributors and Miele Customer Service
representatives can provide you with hoses of 8‘ 2 ½“ or 13‘ 1 ½“ (2.5
or 4 m) length to extend the hose.
10 441 630/ 00 11
en - US PW 6068
Permanent connection of the drain hose to a sink syphon
You may permanently connect the drain hose to a special sink
syphon.
If necessary, the hose may be extended to a maximum length of 5 m.
Accessories are available from an authorized Miele dealer or Miele
Technical Service.
For delivery heads over 3‘ 3 3/8“ (1 m) (up to a max. of 5‘ 10 7/8“ /
1.8 m), contact your Miele dealer or Miele Customer Service for a
drain pump.
Equipotential bonding
Depending on the local and national installation regulations, you may
have to create equipotential bonding with proper contact connection.
The connection material for a necessary equipotential bonding can be
ordered as an assembly kit from Miele Service or supplied by the user.
Alternatively, you can use a wireless multi-station system for
maximum 8 terminals with a debit card payment device and additional
controllers for terminal monitoring.
Serial interface
The serial interface is provided with an additional integrated XKM
RS323 module.
The data interface leading from the XKM RS232 module is compliant
with SELV (safety extra-low voltage). Any connected external devices
must also comply with SELV.
The pluggable module is supplied with a connecting cable and a Dsub plug for further connection.
Installation and fastening
The machine must be installed on a level, horizontal, and solid surface
which is capable of withstanding the specified stresses.
The floor load caused by the appliance affects the installation surface
as point load in the area of the device mounts.
Positional stability of the appliance is mandatory.
Use the adjustable mounts to horizontally align the appliance lengthand crosswise.
Peak load/energy management
Using an optional kit, you may connect the appliance to a peak load or
energy management system.
The appliance provides 3 signal contacts with mains potential and a
neutral conductor on terminal strip, which is identified with a, b, c, and
d.
a - Output signal: machine operation starts
b - Output signal: machine requests heating
c - Input signal peak load: machine switches heater
d – Neutral conductor
When the peak load function is activated, the heating is switched off
and the program is stopped. The display returns a corresponding
message.
Upon the end of the peak load function, the program automatically
resumes.
Liquid dosing connection
You can use external liquid dosing pumps with low-level sensor for the
dosing of liquid detergents.
You can only use dosing pumps with internal controller and/or
programming option for liquid dosing.
Always note the manufacturers' instructions when using and
combining detergents and special products.
Payment device
The washing machine can be fitted with a single payment device as
an optional accessory. Only an authorized Miele dealer or the Miele
Service may program the appliance for this function.
Use the supplied mounting bracket to attach the two front mounts of
the appliance to the floor. The fixing material is designed for a dowel
attachment to concrete flooring.
The user must provide fixing material for any different flooring design.
Platform installation
The washing machine may be installed on a base (open or closed
compartment) which may be optionally purchased from Miele. It may
also be installed on a user-supplied concrete platform.
The quality of the concrete and its strength must be assessed
according to the machine load. Ensure that the on-site concrete
platform has an adequate grip on the substrate.
If the washing machine is installed on a user-supplied platform
(concrete or masonry), you must secure the machine with the
mounting bracket to prevent the possibility of the washing machine
toppling off the platform during the spin cycles.
Washer/dryer stack
The Miele washing machine can be installed in combination with a
Miele dryer as part of a washer-dryer stack. For this purpose, you
require a connection kit
(WTV) which can be optionally purchased.
Only an authorized specialist or Miele Service representative may
install the connection kit.
12 10 441 630/ 00
Loading...
