Operating instructions
Microwave ovens
M 616 EG
M 626 EG, M 636 EG
M 626 EC, M 636 EC
It is essential to read these
operating instructions before
installing or using the machine,
to avoid the risk of accident,
or damage to the machine. M.-Nr. 04 674 691
@Q\ä
Contents
Contents
Description of the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Caring for the environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Warning and Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
How does the microwave oven function? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Calculating power settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Suitable containers for microwave ovens
Material and shape . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Testing dishes for their suitability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Preparation for use
Setting the time of day . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Minute minder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Audible tone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Opening the door. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Closing the door. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Operating modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Operation
Microwave-Solo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Automatic "Keeping warm". . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Switching off the turntable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Interrupting a process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Cancelling a process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Fault indication. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Fan Heat
(only on models M 626 EC and M 636 EC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Fan Grilling
(only on models M 626 EC and M 636 EC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Grilling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Combination mode - Microwave with Grilling . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Combination mode - Microwave with Fan Heat
(only on models M 626 EC and M 636 EC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Contents
Combination mode - Microwave with Fan Grilling
(only with models M 626 EC and M 636 EC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Automatic defrosting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Automatic cooking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Combining Automatic programmes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Short step system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Delaying start
(only on models M 626 EC and M 636 EC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Practical tips. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Reheating. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Cooking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Defrosting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Defrosting and reheating or cooking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Cleaning and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Problem solving guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
After sales service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Installation and electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Technical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Description of the appliance
Description of the appliance
M 616 EG, M 626 EG, M 636 EG
M 626 EC, M 636 EC
Electronic clock with display area
b
c Touchpad to set time m
Touchpad for delayed start )
d
Input touchpads +/-
e
f Microwave power setting
touchpad
Fan heat touchpad D
g
Fan grilling touchpad I
h
Grill touchpad J
i
j
Programme memory store
touchpad 1, 2, 3
ü
k Automatic defrosting touchpad N
Automatic cooking touchpad Q
l
m Cancel touchpad C
Turntable touchpad
n
START touchpad
o
p
Door button a
4
Caring for the environment
Disposal of the packing
material
The transport and protective packing
has been selected from materials
which are environmentally friendly for
disposal and can normally be recycled.
Rather than just throwing these materials away, please ensure they are offered for recycling.
Caring for the environment
Disposal of your old machine /
appliance
Old machines / appliances may contain materials which can be reclaimed
or recycled. Please contact your
dealer, your local waste collection
centre or scrap merchant about potential recycling schemes.
Ensure that the machine / appliance
presents no danger to children
while being stored for disposal
See the appropriate section in the
"Warning and Safety" instructions.
5
Warning and Safety instructions
Warning and Safety instructions
This appliance complies with all relevant legal safety requirements. Improper use of the appliance can,
however, present a risk of both personal injury and material damage.
Before installation and before using
the appliance for the first time, read
the operating instructions carefully.
They contain important notes on
safety, on the operation and care of
the appliance. This way you will
avoid the risk of accidents and damage to the appliance.
Do not let children access the appliance or its controls. Supervise its
use by the elderly or infirm.
Keep these instructions in a safe
place and pass them on to any future user.
Correct usage
The appliance is intended for do-
mestic use only: to cook food, and
in particular to defrost, re-heat, cook,
and to grill. Any other usage is at the
owner’s risk and could be dangerous.
The manufacturer cannot be held responsible for damage caused by improper use of the appliance.
Technical safety
Do not use the microwave if
– the door is warped.
– the door hinges are loose.
– holes or cracks are visible in the casing, the door, the door seal or the oven
interior walls. Switching on with this
type of damage could result in microwaves no longer being contained
within the oven, and presenting a hazard to the user.
Repairs may only be carried out by
suitably competent and qualified service technicians trained by Miele to ensure safety. Repairs and other work by
unqualified persons could be dangerous.
Never open the casing of the ap-
pliance.
Tampering with electrical connections or
components and mechanical parts is
highly dangerous to the user and can
cause operational faults or electric shock.
If the connection cable is dam-
aged the new cable must be fitted
by a Miele service engineer or an authorised agent.
Before connecting the appliance to
the mains supply make sure that the
rating on the data plate corresponds to
the voltage and frequency of the household supply. It is essential that these data
correspond as otherwise damage will
occur to the machine. If in doubt consult
a suitably competent person.
The electrical safety of this ap-
pliance can only be guaranteed
when continuity is complete between
the appliance and an effective earthing
system, which complies with local and
national regulations. It is most important that this basic safety requirement is
tested by a qualified electrician. The
manufacturer cannot be held responsible for the consequences of an inadequate earthing system such as electric
shock.
6
Warning and Safety instructions
Warning and Safety instructions
The appliance is only completely
isolated from the electricity supply
when:
– it is switched off at the wall socket
and the plug removed.
Hold the plug and do not pull on the
cable to remove the plug.
– The house mains fuse is switched off.
– The fuse is screwed out ( in countries
where this is applicable).
Do not connect the appliance to
the mains electricity supply by an
extension lead.
Extension leads do not guarantee the
required safety of the appliance, (for
example danger of overheating).
Use
Always ensure that food has been
thoroughly heated before eating.
Many factors will affect the overall cooking time, including the size and amount
of food, its initial temperature, changes
to the recipe and the shape and size of
cooking container. Some foods may
contain micro organisms which are only
destroyed by thorough cooking, therefore when cooking or reheating foods,
e.g. poultry it is particularly important
that food is fully cooked through (at
more than 70 °C, for more than 10
minutes). If in any doubt as to whether
the selected time or temperature is sufficient, select a slightly longer time or
higher temperature.
It is important that the heat is
allowed to spread evenly throughout the food being cooked.
This can be achieved by stirring and/or
turning the food, and by observing a
sufficiently long standing time, which
should be added to the time needed
for cooking, reheating or defrosting
Always remember that cooking
times in a microwave oven are
usually considerably shorter than with
traditional methods of food preparation.
Excessively long cooking times can
lead to food drying out and eventually
burning, or could even cause it to
catch fire.
There is also a danger of fire if breadcrumbs, flowers, herbs, etc., are dried
in the microwave oven. Always ensure
that this type of procedure is supervised.
Do not use full power if you warm
empty dishes or dry herbs. The
lack or minimum amount of food could
cause damage to the appliance.
Never cook or reheat food or
liquids in sealed containers or
bottles. With babies’ bottles the screw
top and teat must be removed. Otherwise pressure builds up which can
cause the bottle or container to explode posing a severe risk of injury.
Always check the temperature of
the actual food itself after taking it
out of the microwave. Do not be misled
by the temperature of the container. In
particular when preparing food for
babies, children, and the elderly or
infirm, it is essential to check the
temperature of the food or liquid itself, after stirring and before serving
to avoid a burnt mouth. The tempera-
ture of the container does not necessarily give a correct indication of the temperature of the food or liquid it contains.
7
Warning and Safety instructions
Warning and Safety instructions
When heating liquids, the boiling
rod provided should be placed
into the container.
ignite.
taining metal, aluminium foil, lead crystal glassware, temperature-sensitive
plastics, wooden utensils or cutlery,
metal clips or wire ties. Do not use
bowls with milled rims or cream pots
with the tinfoil lid only partially
removed. Such items could be damaged, or cause a fire hazard.
Never heat undiluted alcohol in the
microwave oven as this can easily
Do not use any containers, croc-
kery or cutlery made from or con-
When heating, and especially reheating
liquids, milk, sauces etc., in the microwave oven, the boiling point of the liquid may be reached without the production of typical bubbles. The liquid does
not boil evenly throughout. This socalled ’boiling delay’ can cause a sudden build up of bubbles, when the container is removed from the oven or
shaken. This can lead to the liquid boiling over suddenly and explosively.
There is a danger of burning. The formation of bubbles can be so strong
that the pressure forces the oven door
open. The user could be injured and
the appliance damaged.
The boiling rod ensures that the liquid
boils evenly and that bubbles form at
an early stage during the operation.
If smoke occurs in the oven interior
do not open the oven door, to
avoid fuelling any flame. Cancel the
process (press button C twice), switch
off at the wall socket, and where applicable, remove the plug. Do not open the
door until the smoke has dispersed.
The rack supplied with the appliance is
designed to be compatible with microwaves, and can therefore be used for
grilling with and without the microwave
function.
Eggs can only be cooked in their
shells in the microwave oven in a
specially designed egg-boiling device.
Similarly, hard-boiled eggs should not
be reheated in the microwave oven as
this may lead to the eggs bursting,
even once they have been removed
from the oven.
Eggs can be cooked without their
shells in the microwave oven only if
the yolk membrane has been punctured several times first. The pressure
could otherwise cause the egg yolk to
explode.
Food with a thick skin or peel,
such as tomatoes, sausages,
jacket potatoes, aubergines, should be
pierced or cut in several places to
allow steam to escape and prevent the
food from bursting.
8
Warning and Safety instructions
Warning and Safety instructions
Do not reheat food in the oven in
heat-retaining bags intended for
normal ovens.
These heat-retaining bags usually contain a thin layer of aluminium foil which
reflects microwaves. This reflected energy can, in turn, cause the outer
paper covering to become so hot that it
ignites.
Always ensure that food or the
browning dish has been placed in
the microwave, and that the turntable is
in place, before switching on.
Do not leave the oven unattended
when cooking with oils and fats as
these can be a fire hazard if allowed to
overheat.
Ovenproof earthenware can retain
a considerable amount of moisture. Earthenware and porcelain containers with hollow handles and lid
knobs must only be used in this oven if
they have vent holes, which allow the
moisture to escape. Without vent holes
there can be a pressure build-up, causing the container to crack or shatter,
with the danger of injury.
In all operating modes, except
Microwave-Solo, the oven interior,
the grill element, the side runners, the
oven door and the housing get hot.
Do not let small children touch the oven
while it is in operation, there is a
danger of being burnt.
Supervise its use by the elderly or
infirm.
Wear oven gloves when taking dishes
in and out of the oven, or when handling dishes or food in the oven if the
oven is or has just been in operation.
Use the rack only for grilling with or
without microwave mode. Use the
baking tray only for Fan Heat. Take
care not to burn yourself.
During use the grill and baking tray will
get hot. Use oven gloves when handling them.
Do not use the oven to heat up the
room. Due to the high temperatures radiated, objects left near the
oven could catch fire.
To measure the temperature only
use a thermometer only specifically approved for use in a microwave
oven. Never use a thermometer with
mercury or liquid.
In countries which may be subject
to infestation by cockroaches or
other vermin, pay particular attention to
keeping the appliance and its surroundings in a clean condition at all times.
Any damage which might be caused
by cockroaches or other vermin will not
be covered by the appliance guarantee.
Under no circumstances use a
steam cleaner to clean this appliance. Pressurised steam could give
rise to a short circuit, or cause permanent damage to the surface and to
components, for which the manufacturer of the oven cannot accept any responsibility.
9
Warning and Safety instructions
Special accessories
Never place the hot glass tray (or
any other hot cooking containers)
onto a cold surface, such as a tile or
granite worktop. The tray or container
could shatter or break and the worktop
surface could be damaged. Use a heatresistant mat or wire cooling rack.
Only for microwave ovens built in
with a lift-up door:
Do not bring this down into the closed
position when the oven is in operation.
An anti-splash roof liner is avail-
able as an optional extra. You can
slide this in above the grill before using
the oven.
M 636 EG
When using browning dishes:
avoid burns.
Instead use a suitable heat-resistant
mat, grid or board to protect the work
surface or table, which could otherwise
be heat-marked.
Always use oven gloves when
handling the browning dish to
Never place a browning dish directly on to a table or worksurface.
M 616 EG
M 626 EG, M 626 EC, M 636 EC
10
Use browning dishes in a micro-
wave oven only, or as a serving
dish. In a conventional oven the special
glaze would suffer damage.
Disposal of old machines / appliances
Before discarding an old machine
or appliance switch off and disconnect it from the power supply. Cut off
and render any plug useless.
Cut off the cable directly behind the machine to prevent misuse.
The manufacturer cannot be held
liable for damage caused by noncompliance with safety instructions.
How does the microwave oven function?
How does the microwave oven function?
In the microwave oven, food is cooked,
reheated or defrosted more quickly
than by any other method.
How does the microwave oven function?
Microwaves pass through a suitable
container and find their way directly
into the foodstuff. All foodstuffs contain
moisture molecules which, when subjected to microwave energy, start to oscillate 2.5 thousand million times a second. The friction caused by this
vibration creates heat, which first starts
developing around the outside of the
foodstuff and then slowly penetrates towards the centre. The moisture, fat and
sugar content of food will affect the
speed at which it is cooked.
As heat is produced directly in the food,
– food can generally be cooked with-
out adding much liquid or cooking
oil.
In a microwave oven there is a high-frequency tube called a magnetron
This converts electrical energy into
microwaves. These microwaves are distributed evenly throughout the oven interior by a metal fan blade known as a
c -, rebounding off the metal
stirrer
sides of the oven interior and thereby
reaching the food from all sides. Microwave distribution is improved by engaging the turntable.
In order for microwaves to reach the
food, they must be able to penetrate
the cooking utensil being used. Microwaves can penetrate porcelain, glass,
cardboard and plastics but not metal.
Do not, therefore, use utensils made of
metal, or which contain metal, for
example in the form of gold or silver
trim. The metal reflects the microwaves
and this could lead to the creation of
sparks. The microwaves cannot be absorbed.
b.
– cooking, re-heating and defrosting in
a microwave oven is quicker than
using conventional methods.
– nutrients, such as vitamins and mine-
rals, are retained.
– colour, texture and taste of food are
not impaired.
11
Calculating power settings
Calculating power settings
This microwave has 9 power settings.
Very often, power is expressed in watts
on food packaging or in general
recipes for microwaving.
The following table should help to convert the watts given to a matching
power setting with these ovens.
Microwave oven with max.:
Set-
750 Watt
ting
Example:
A recipe states:
Cook in the microwave at 850 watts
initially for approx. 5 minutes. Then
continue for 20 minutes at 450 watts.
For the microwave with 850 watts maximum power, using the table for guidance this converts to:
[Watt]
1
2
3
4
5
6
7
8
9
80
150
200
300
400
450
550
600
750
850 Watt
[Watt]
80
150
250
350
450
500
600
700
850
900/
1000
Watt
[Watt]
100
200
300
400
500
600
700
800
900/1000
Where the recipe gives a wattage
which does not correspond exactly to
the table, select the nearest power setting available. It may be necessary to
adjust the time very slightly to compensate.
For appliances with a maximum setting
of 1000 watts we recommend using the
top setting (9) to heat clear liquids and
keep them simmering. To prepare
noodles and vegetables setting 8 is
suggested followed by 4 or 5.
See recipes for cooking times. Be prepared to make adjustments where appropriate.
The maximum microwave power output
in watts and the intermediate scale of
settings in watts are given for each
model of oven on the data plate, located at the rear of the oven.
Please make a note of these.
Examples of use given later in this
book refer to oven models with a maximum microwave power output of
900/1000 watts. Adjust according to
the table on this page for ovens with a
different scale of output watts.
Cook in the microwave at setting 9
initially for approx. 5 minutes. Then
continue for 20 minutes at setting 5.
12
Suitable containers for microwave ovens
Suitable containers for microwave ovens
Microwaves
– are reflected by metal.
– pass through glass and china-
ware, . . .
Material and shape
The material and shape of containers
used affect the cooking results and
times. Round and oval shaped ones
provide good results. Heat distribution
is more even than it is in rectangular
containers.
Metal
The following do not belong in an
oven being used in microwave
mode. Metal containers, aluminium
foil and metal cutlery, or china with
metallic decoration, such as gold
rims or cobalt blue.
The metal reflects the microwaves, hindering the cooking process.
Exceptions:
– If recommended by the producer, pre-
cooked meals packed in aluminium foil
containers can be defrosted and reheated in the microwave oven. Important: remove the lid first. The disadvantage is that the food is only heated from
the top. It is better to remove the food
from the aluminium foil container and
transfer it to a dish suitable for a microwave oven. The heat distribution will be
more even.
– and are absorbed by food.
If sparks and arcing occur when using
a metal container, stop and transfer the
food to a microwave safe container.
– Small pieces of aluminium foil. For
even defrosting and to avoid overcooking unevenly shaped cuts of meat,
poultry or fish, small areas of aluminium
foil may be used to mask wingtips or
other thin parts for the last few minutes
13
Suitable containers for microwave ovens
of the process. The aluminium foil must
not touch the interior walls of the oven.
Make sure that the aluminium foil is
at least 2 cm from the oven walls at
all times. It must not touch the walls.
– Metal meat skewers or clamps:
Metal skewers and clamps should only
be used if they are very small in comparison to the size of the cut of meat.
Glassware
Heat-resistant glass or ceramic glass
are ideal for use in the microwave oven.
Glazes and colours
Some glazes and colours contain
metal.
This makes them unsuitable for use in a
microwave oven.
Plastics
Plastic containers must only be
used for microwave mode alone
and not in normal oven mode. Plastics must be heat-resistant to a minimum of 180°C.
Crystal glass contains lead which
could cause the glass to crack.
Glass dishes with a milled rim are
subject to the same risk. Both are
unsuitable for use.
Porcelain (chinaware)
Porcelain (chinaware) is a suitable material.
Do not use porcelain with gold or silver edging or items with hollow
knobs or handles, as insufficient
ventilation may cause pressure.
Earthenware
Decorated earthenware is only suitable if the decoration is beneath an
all-over glaze. Earthenware can get
very hot, and may crack.
Otherwise the plastic may melt and
fuse with the food.
Special plastic utensils, designed for
use in microwave ovens are available
from most department and hardware
stores. Melamine ware is not suitable
as it absorbs energy and heats up.
When purchasing plasticware, make
sure that it is suitable for use in a microwave oven.
Disposable containers, such as trays
made from polystyrene, can only be
used for very short timed warming and
re-heating of food.
Plastic boiling bags can be used for
cooking and re-heating. They
should be pierced beforehand so
that steam can escape.
This prevents a build-up of pressure
and reduces the risk of the bag bursting.
14
Suitable containers for microwave ovens
Suitable containers for microwave ovens
Roasting bags and tubes can be used.
Roasting tubes should be about 40 cm
longer and roasting bags about 20 cm
longer than the food being roasted, and
carefully tied with string. Turn the ends
over and secure them. Holes should be
made according to the manufacturer’s in-
structions.
Do not use metal clips or wire ties,
even if bound by paper.
Testing dishes for their suitability
If in doubt as to whether glass, earthenware or porcelain plates or dishes are
suitable for use in a microwave oven, a
simple test can be performed:
Place the item you wish to test in the
centre of the oven, fill a suitable
glass with water and also place this
in the oven.
There is a danger that they will ignite
when heated.
Wood
Wooden dishes are not suitable
Moisture contained in the wood evaporates when exposed to microwave energy, causing the wood to dry and
crack.
Disposable containers
Only those plastic disposable containers which are specified by the producer as suitable for use in a microwave oven may be used.
Do not leave the oven unattended
when re-heating or cooking food in
disposable containers made of plastic paper or other inflammable material.
Close the door.
Enter a time of 30 seconds with the
time selector
Select power setting P 8 with the ü
touchpad, or for the M 616 EG P 9.
Do not switch off the turntable .
Press the START control.
If a crackling noise is heard accompanied by sparks during the test,
switch off the appliance immediately.
Any crockery which causes this reaction is unsuitable for use in the microwave oven.
The water in the glass should be warm,
but the dish cool. If the dish is very hot
and the water is cold, it would be unwise to use the dish.
m.
Disposable containers are not always
recyclable or degradable.
15
Suitable containers for microwave ovens
Suitable containers for microwave ovens
Note: Although some ovenproof earthenware can be used in a microwave
oven, it may contain a considerable
amount of moisture, causing it to
become hot during use. It is normally
advisable to avoid using it in a microwave oven.
If any doubt exists about the suitability of containers, please contact
the maker.
This test cannot be used to check
whether items with hollow knobs or
handles are suitable for use in a microwave oven.
A cover
– prevents too much steam escaping,
especially when cooking foodstuffs
which need longer to cook, such as
potatoes.
– shortens and evens out the cooking
process.
– keeps the oven interior cleaner.
– prevents food from drying out.
– contains the aroma.
Always use lids or covers made of
microwave-safe glass or plastic, or use
a clingfilm recommended for use in a
microwave oven, (pierce as instructed
by the producer).
Sealed glass containers, such as
jars of food, must be opened before
they are placed in the oven.
Do not use a lid or cover if:
– food coated with breadcrumbs is
being cooked.
– cooking meals which are to be given
a crisp finish.
16
– using the grill.
Preparation for use
Preparation for use
Setting the time of day
Connect the appliance to the electricity supply.
0:00 flashes in the display area.
Use the +/- touchpads to set the
hours (0 to 23).
Press the m touchpad and use the
+/- touchpads to set the minutes.
Press the m touchpad again to confirm the time now showing in the display area.
The appliance is now ready for use.
Altering the time of day
Press the m touchpad twice.
0:00 flashes in the display area.
Alter the time of day as described
above.
Minute minder
Press the m touchpad and then use
the +/- touchpads to set the minute
minder time you require (5 seconds
up to 99 minutes).
Press the ü touch pad.
The symbol
flashes in the display and P 9 appears.
Hold the - touchpad pressed in until
P 0 appears.
h symbol disappears and the
The
for microwave mode
h
l symbol for the minute minder
flashes.
Press the START touchpad.
The time which has been entered appears in the display area and begins
to count down in one second steps.
An audible tone sounds when the
minute minder time has elapsed.
Audible tone
An audible tone sounds when the set
time has elapsed. This is repeated after
a few seconds.
Press touchpad C to turn off the tone
early.
The time of day reappears in the display area.
Opening the door
Press the "a" button to open the
door.
The light comes on.
If the microwave is being used, opening the door will interrupt the cooking
process. The relevant operating mode
indicator will flash in the display area.
Closing the door
Push the door shut.
Press the START touchpad to continue
an interrupted cooking process.
17
Operating modes
Operating modes
M 626 EC, M 636 EC
The 7 operating modes detailed below
are available.
M 616 EG, M 626 EG, M 636 EG
Here you can choose between 3 operating modes, Microwave Solo, Grill and
a combination of these two, see 1, 4,
and 7 below; (Fan Heat and Fan Grilling (with or without microwave mode)
are not available).
– 1. Microwave-Solo mode ü
Suitable for defrosting, reheating or
cooking.
– 2. Fan Heat
Ideal for baking.
– 3. Fan Grilling
Use to grill or roast thicker cuts of
meat and pieces of poultry. The fan
and the grill heating element operate
at the same time.
– 4. Grilling
Ideal for grilling thinner items e.g.
steaks or sausages.
– 5. Combination mode - Microwave
D *
I *
J
ü with Fan Heat D *
You can use this combination mode
to prepare puddings very quickly.
– 6. Combination mode - Microwave
ü with Fan Grilling I *
This combination is particularly suitable for roasting and grilling.
– 7. Combination mode - Microwave
ü with Grilling J
Ideal for crisping and browning. The
microwave cooks the food, the grill
browns and crisps the surface.
* only with models M 626 EC and
M 636 EC
Automatic programmes
The Automatic Defrosting programme
N offers 4 programmes (d1 – d4).
The Automatic Cooking programme
Q offers 8 programmes (C1 – C8).
All the automatic programmes are
weight dependent, which means that
the weight of the food must be entered.
The automatic programmes for defrosting and cooking can also be set to run
one after the other.
Short step system
Touchpads 1, 2, 3 allow you to store in
the memory programmes you use frequently. Each memory store can be
used again with a different programme.
Delaying start
(only on models M 626 EC and
M 636 EC)
The length of cooking time and the end
of a process can be pre-programmed
up to 24 hours beforehand.
Automatic "Keeping warm"
The automatic "keeping warm" function
will switch on for a maximum of 15
minutes after a cooking process using
a power setting of 5 or higher has finished.
18
Operation
Operation
Microwave-Solo
There is a choice of 9 power settings.
The higher the power setting, the more
microwaves reach the food.
When heating up food of differing composition, or which cannot be stirred or
turned during cooking, as with a plated
meal, it is preferable to heat these on a
lower power setting. This ensures that
the heat is distributed evenly. Heat for
long enough to reach the temperature
required.
Times for defrosting, reheating and
cooking
The necessary time depends on:
– the initial temperature of the food.
Food taken from the refrigerator will
need longer to be reheated or
cooked than food already at room
temperature.
– the type and texture of the food.
Fresh vegetables probably contain
more water and cook more quickly
than stored vegetables.
– the shape and material of the con-
tainer.
– the amount of food.
In general:
Double the amount of food - at least
one third extra cooking time.
For smaller amounts of food reduce
the time accordingly.
Ideally the container should be
placed in the middle of the oven.
Press the m touchpad and use the
+/- touchpads to enter the cooking
time you require (5 seconds up to 99
minutes).
Press the ü touchpad.
h symbol for microwave mode
The
flashes in the display area and P 9
appears.
Use the +/ - touchpads to select the
power setting you require.
h symbol flashes and the se-
The
lected power setting appears.
Press the START touchpad.
The set time appears in the display
area and begins to count down in
one second steps.
An audible tone sounds when the
cooking time has elapsed.
Press touchpad C to turn off the tone
early.
Press the
call up the power setting while the appliance is in operation.
ü touchpad if you want to
Automatic "Keeping warm"
The automatic "keeping warm" function
will switch on for a maximum of 15
minutes after a cooking process using
a power setting of 5 or higher has finished.
H:H and the symbol
display area. The turntable continues to
operate.
The process is cut short if the door is
opened during this time.
The "keeping warm" stage cannot be
set separately.
h appear in the
19
Operation
Operation
Switching off the turntable
The turntable is always switched on
and should only be switched off if there
is a danger of something blocking it,
e.g. a large dish which is wider than
the turntable.
Press the touchpad before you
start the cooking process to switch
off the turntable.
The symbol for the switched off
turntable appears in the display area.
If you want to switch off the turntable
while the microwave is being used, you
must interrupt the cooking process by
twice pressing the C touchpad and
then re-enter the settings.
Interrupting a process
Press the C touchpad once to stop
an operating function.
The symbol for the operating function flashes in the display area and
the time remaining appears.
Press the START touchpad to continue the process.
Fault indication
Press the C touchpad once if you
make an unintentional entry and the
letter E appears in the display area.
You can then re-enter the settings.
If E15 appears in the display this indicates overheating in the oven interior. Let the appliance cool down with
the door open for 15 – 20 minutes.
Afterwards, press the C touchpad
and enter the settings again.
Cancelling a process
Press the C touchpad twice to cancel the operating function which is in
progress.
The time of day appears.
20
Congratulations on the purchase of your new Miele microwave oven.
We trust you will be delighted with the wide range of programmes
and applications it has to offer.
To help you make the most of your oven, we would be pleased to send you,
free of charge, a copy of the
This prestigious book contains over a hundred delicious recipes, all tested on
Miele 850 W microwave ovens. Furthermore, it offers comprehensive advice on
the basics of microwave cooking, how to use the different cooking techniques to
best advantage and timing charts for thawing and cooking many types of food.
Please fill in the slip below and send it to:
Miele Company Limited, Fairacres, Marcham Road, Abingdon, Oxon OX14 1TW
Please note, this offer applies only to new microwave ovens purchased in the UK.
.............................................................................................................................
..
A
I have purchased a Miele microwave oven, model ................
Dear Customer,
Good Housekeeping Essential Microwave Handbook.
from (name of retailer)................................................................town..........................
Please send me the Good Housekeeping Essential Microwave Handbook.
Name:..........................................................................................................................
Address:......................................................................................................................
.....................................................................................................................................
........................................................................................................................
........................................................................................................................
Signed:................................................................................Date:...............................
Operation
Fan Heat
(only on models M 626 EC and
M 636 EC)
Press the m touchpad and use the
+/- touchpads to set the cooking time
you require (5 seconds to 99 minutes).
Operation
Fan Grilling
(only on models M 626 EC and
M 636 EC)
Press the m touchpad and use the
+/- touchpads to set the cooking time
you require (5 seconds to 99 minutes).
Press the D touchpad.
The set time as well as the pre-set
temperature appear in the display
area. The
Heat mode flashes.
Use the +/ - touchpads to select the
temperature you require
(50 °C – 250 °C).
Press the START touchpad.
The set time appears in the display
area and begins to count down in
one second steps.
A red dot also lights up in the display area (heat warning indicator).
An audible tone sounds when the
cooking time has elapsed.
Recommendations
The turntable should always be
switched on when using the Fan Heat
mode if placing the dish on the turntable.
You can take out the side runners
(where fitted) when using larger dishes.
Make use of the residual heat by leaving the food in the appliance for
5 minutes after the cooking time has
finished.
D symbol for the Fan
Press the I touchpad.
The set time as well as the pre-set
temperature appear in the display
area and the
Grilling mode flashes.
Use the +/ - touchpads to select the
temperature you require
(50 °C – 200 °C).
Press the START touchpad.
The set time appears in the display
area and begins to count down in
one second steps.
A red dot also lights up in the display area (heat warning indicator).
An audible tone sounds after the
cooking time has elapsed.
I symbol for the Fan
21
Operation
Operation
Grilling
Press the m touchpad and use the
+/- to set the cooking time you require
(5 seconds to 99 minutes).
Press the J touchpad.
The set time as well as the pre-set
temperature appear in the display
area. The
flashes.
Use the +/ - touchpads to select the
temperature you require.
(50 °C – 200 °C).
Press the START touchpad.
The set time appears in the display
area and begins to count down in
one second steps.
A red dot also lights up in the display area (heat warning indicator).
An audible tone sounds once the
cooking time has elapsed.
Recommendations
Turn over meat and fish half-way
through the cooking time so that both
sides are cooked and browned evenly.
Thin slices and pieces only require to
be turned over once, whereas larger,
thicker pieces should be turned several
times.
If the total grilling time is less than
15 minutes, pre-heat the grill for about
5 minutes.
J for the Grilling mode
Combination mode - Microwave with Grilling
Press the m touchpad and use the
+/- touchpads to set the cooking time
you require (5 seconds to 99 minutes).
Press the ü touchpad.
The symbol
mode and P 9 appears.
Use the +/ - to select the power setting you require.
h symbol flashes and the se-
The
lected power setting appears.
Now press the J touchpad.
The set time as well as the pre-set
temperature appear in the display
area. The
Use the +/ - touchpads to select the
temperature you require
(50 °C – 200 °C).
Press the START touchpad.
The set time appears in the display
area and begins to count down in
one second steps.
A red dot also lights up in the display area (heat warning indicator).
An audible tone sounds after the
cooking time has elapsed.
Press the
call up the power setting while the appliance is in operation.
h for the Microwave
J and h symbols flash.
ü touchpad if you wish to
22
Operation
Combination mode - Microwave with Fan Heat
(only on models M 626 EC and
M 636 EC)
Press the m touchpad and use the
+/- touchpads to set the cooking time
you require (5 seconds to 99 minutes).
Press the ü touchpad.
The symbol
mode flashes in the display and P 9
appears.
Use the +/ - touchpads to select the
power setting you require.
h symbol flashes and the se-
The
lected power setting appears.
Now press the D touchpad.
The set time as well as the pre-set
temperature appear in the display
area. The
Use the +/ - to select the temperature you require
(50 °C – 250 °C).
Press the START touchpad.
The set time appears in the display
area and begins to count down in
one second steps.
A red dot also appears in the display
area (heat warning indicator).
An audible tone sounds after the
cooking time has elapsed.
Press the
call up the power setting while the appliance is in operation.
h for the Microwave
D and h symbols flash.
ü touchpad if you wish to
Operation
Combination mode - Microwave with Fan Grilling
(only with models M 626 EC and
M 636 EC)
Press the m touchpad and use the
+/- touchpads to set the cooking time
you require (5 seconds to 99 minutes).
Press the ü touchpad.
h symbol for the Microwave
The
mode flashes in the display area and
P 9 appears.
Use the +/ - to select the power setting you require.
h flashes and the selected
The
power setting appears.
Now press the I touchpad.
The set tiime as well as the pre-set
temperature appear in the dipslay
area. The
Use the +/ - touchpads to select the
temperature you require
(50 °C – 200 °C).
Press the START touchpad.
The set time appears in the display
area and begins to count down in
one second steps.
A red dot also lights up in the display area (heat warning indicator).
An audible tone sounds after the
cooking time has elapsed.
Press the
call up the power setting while the appliance is in operation.
I and h symbols flash.
touchpad if you wish to
ü
Recommendation
The turntable should always be
switched on when the Microwave with
Fan Heat mode is in use.
23
Operation
Operation
Automatic defrosting
There is a choice of 4 Automatic defrosting programmes.
Automatic cooking
There is a choice of 8 Automatic cooking programmes.
Programme Food type
d 1
d 2
d 3
d 4
Press the N touchpad.
The symbol
area and d 1 appears.
Press the N touchpad enough times
to select the programme you require.
With the +/ - touchpads enter the
weight of the food
(50 g – 4000 g).
The symbol
area, and the food weight entered
appears.
The defrosting time is calculated automatically by the appliance.
Press the START button.
The defrosting time which has been
calculated appears in the display
area and begins to count down in
one second steps. The symbols
and N also appear.
An audible tone sounds at the end of
the defrosting time.
The fault message "E 15" appears in
the display if the oven interior is still
warm from previous use. Wait until it
has cooled down.
Poultry
Meat
Fish
Light textured bakes,
e.g cream gateaux
N flashes in the display
N flashes in the display
h
Programme Food type
C 1
C 2
C 3
C 4
C 5
C 6
C 7
C 8
Press the Q touchpad.
The weight symbol flashes in the display area, and C 1 appears.
Press the Q touchpad enough
times to select the programme you
require.
With the +/ - touchpads enter the
weight of the food.
The weight symbol flashes in the display area, and the food weight entered appears.
The cooking time is calculated automatically by the appliance.
Press the START button.
The cooking time which has been
calculated appears in the display
area and begins to count down in
one second steps. The symbols
and the weight symbol also appear.
An audible tone sounds at the end of
the cooking time.
boiling potatoes
Boiling vegetables
Poaching fish
Frozen vegetables
Heating liquids
Reheating conserves
Chilled plated meals
Frozen plated meals
h
24
Operation
Operation
Combining Automatic programmes
The two Automatic Programmes can be
set to run so that defrosting runs followed by cooking.
Press the N touchpad.
The symbol
area and d 1 appears.
Press the N touchpad enough times
to select the programme you require.
With the +/ - touchpads enter the
weight of the food
(50 g – 4000 g).
The symbol
area, and the food weight entered
appears.
Now press touchpad Q.
The weight symbol flashes in the display area, and C 1 appears.
Press the Q touchpad enough
times to select the programme you
require.
N flashes in the display
N flashes in the display
The automatic cooking programme will
switch on automatically once the defrosting time has elapsed.
The cooking time which has been calculated appears in the display area
and begins to count down in one second steps.
h and the weight symbol also appear.
An audible tone sounds once the cooking time has elapsed.
With the +/ - touchpads enter the
weight of the food.
The weight symbol flashes in the display area, and the food weight entered appears.
The defrosting time and cooking time
are calculated automatically by the appliance.
Press the START button.
The defrosting time which has been
calculated appears in the display
area and begins to count down in
one second steps. The symbols
and N also appear.
h
25
Operation
Operation
Short step system
Touchpads 1, 2, and 3 allow you to
store in memory programmes which
you frequently use.
There are three memory stores where
frequently used programmes can be recorded.
You can store all the operating functions, e.g. grilling, combination functions,
and automatic programmes.
You can also store the command to
switch the turntable function on or off.
Each memory store can be used again
with a different programme.
Proceed as for setting the operating
mode.
Do not however press the START button at the end, instead select one of
the three programmes 1, 2, or 3 and
store the setting.
The code number of the stored programme will appear in the display.
Press the START button.
In the display area the codes for the
operating functions appear and the
time counts down in one second
steps. An audible tone sounds at the
end.
If you press the START button immediately after selecting the programme 1,
2, or 3, this will avoid the whole sequence showing in the display area.
Storing a new programme will automatically delete any previously
stored programme.
In the event of a power cut the
stored programmes will be deleted,
and will need to be re-entered.
Make a note of the programme sequences, so that they are available
for use when you need them.
Finally press touchpad C to confirm
the setting.
The time of day appears in the display area.
Calling up the "Short step system"
Press the relevant storage touchpad,
1,2 or 3.
The stored settings for the operating
function appear in the display area.
The symbol for the function flashes
and the number of the programme
store appears.
26
Operation
Delaying start
(only on models M 626 EC and
M 636 EC)
The length of time and also the end of
a process can be pre-programmed up
to 24 hours beforehand.
Proceed as before to set the operating mode.
After setting the mode do not however press the START touchpad but
instead press the
0:00 and
ying start flash in the display area.
Now enter the time at which you wish
the process to end. Use the +/touchpads to enter the hours. Press
the
the +/- to set the minutes.
Press the START touchpad.
The current time of day and the
symbol appear in the display area.
)
m touchpad and then finally use
) touchpad.
the symbol for dela-
)
Operation
The appliance will then switch on and
off at the required time.
If you are using the delaying start
function with the microwave mode,
the food must have already been
placed in the cooking compartment.
27
Practical tips
Practical tips
Reheating
Select the following microwave power
settings to reheat food:
Drinks. . . . . . . . . . . . . . . . . . . . . . . . . 8
Food. . . . . . . . . . . . . . . . . . . . . . . . . . 6
Food for babies * . . . . . . . . . . . . . . . . 4
(See table on page 12 for ovens with
maximum microwave output of less
than 900/1000 watts.)
* We do not recommend heating or
re-heating foods or drinks for
babies or young children in the
microwave oven. Any decision to do
this is the responsibility of the user,
and should only be done with the utmost care. Pasteurised or sterilised
cooked food should be gently
heated on level 4, (5 or 6) according to model, see table on page 12,
and tasted so that it is not too hot
for a baby’s palate before serving.
Other food or drink when reheated
should be heated to a high temperature and allowed to cool to a suitable heat for eating. For made-up
milk follow the maker’s instructions.
Always use a lid or cover for re-heating
food, except when a drier finish is
needed, e.g. breaded poultry/meat.
Always remove the lid from jars, especially jars of baby food.
Remove the rubber teat and seal
top before warming baby bottles.
When re-heating liquids place the
boiling rod supplied with the machine into the cup or glass.
Never reheat hard boiled eggs in a
microwave oven, even without the
shell. The eggs can burst.
The time required depends largely on
the nature and initial temperature of the
food and the amount to be cooked.
Food taken straight from the fridge or
freezer requires for example longer to
reheat than food stored at room temperature.
Always ensure that the food is thoroughly heated.
If in any doubt that a sufficiently high
temperature has been reached, continue re-heating for a little longer.
28
Stir or turn food from time to time during cooking. Stir the food from the outside towards the middle, as food heats
more quickly from the outside.
Practical tips
After re-heating
Be careful when removing a dish
from the oven. It may be hot.
Practical tips
Ensure that perishable types of
food, such as meat and fish, are
cooked for an appropriate length of
time.
Although heat is not normally produced
in the container itself by the microwaves, (apart from stoneware and similar dishes), heat transfer from the food
to the container may be considerable,
making the container itself hot.
Allow food to stand for a few minutes
once a programme has ended to allow
heat to be distributed evenly.
After re-heating food, especially
food for babies and small children,
stir the food or shake the container
and check that the temperature
does not pose any danger. Double
check after it has been left to stand.
Cooking
Place the food in a covered microwavesafe dish.
When cooking fresh vegetables, fish,
meat, poultry first select power setting
8 or for M 616 EG setting 9, and then
select power setting 5 or for M 616 EG
setting 6 to continue cooking.
For dishes such as rice or semolina
pudding first select power setting 8 or
for M 616 EG setting 9 and then turn
down to power setting 2 to complete
cooking.
For food with skin or peel, such as tomatoes, some types of sausage, jacket
potatoes and aubergines, should be
pricked or the skin cut several times before cooking to prevent food from bursting.
Boiling eggs in the microwave oven
is not possible without a special
egg-boiling device, available from
specialist shops.
Otherwise the eggs will burst. Eggs
can only be cooked in a microwave
oven out of their shells in a glass dish.
The yolk must be pricked several times
first with a sharp object.
Add a little water to vegetables which
have been kept stored. Vegetable cooking times depend on the texture of the
vegetable. Fresh vegetables contain
water and usually cook more quickly.
Stir and turn food at least once during
cooking.
29
Practical tips
Practical tips
Defrosting
Remove the frozen food from its packaging and place in a covered microwave-safe container, to defrost without
a lid. Turn, stir or separate the food
about half-way through the programme.
To defros t delicate foods, e.g. cream,
butter, gateaux and cheese, select the
microwave setting 1. However to
achieve an even result remove from the
oven and allow to finish defrosting at
room temperature.
To defrost meat unpack the frozen
meat and lay it on an upturned plate in
a glass or china container so that the
meat juice can run out, but be collected. Turn half way through defrosting.
For defrosting basic food stuffs such
as bread, cakes or fruit microwave
power setting 2 is recommended.
Defrosting and reheating or
cooking
Deep-frozen pre-cooked food can be
defrosted and immediately reheated or
cooked, using the combination of the
two automatic programmes, Auto defrost and Auto cook.
Remove the food from its packaging
and place in a covered microwave-safe
dish for defrosting and re-heating or
cooking. Exception: Minced meat
should be left uncovered while cooking. Soups, stew and vegetables
should be stirred several times during
the process. Separate slices of meat
half-way through the programme. Turn
pieces of meat and fish at the half-way
stage.
Deep-frozen pre-cooked meals in cardboard trays which, according to manufacturer’s instructions are suitable for
use in a conventional oven, are microwave-safe.
After defrosting
Allow the food to stand at room temperature for approximately the same
amount of time spent for defrosting to
enable the heat to spread evenly
throughout the food.
30
After defrosting followed by re-heating or cooking.
Allow the food to stand at room temperature long enough to enable the
heat to spread evenly throughout the
food.
Practical tips
Practical tips
Examples
Melting margarine, butter
Melt 100 g at setting 5 uncovered, for
approx 1-1
Melting chocolate
Break 100 g into pieces, melt at setting
5 uncovered, for approx. 2 minutes.
Dissolving gelatine
Melt at setting 5 uncovered, for approx.
ally, (N.B. follow the instructions on the
packet if these differ and for the
amount of water).
Preparing flan topping/jelly glaze
Gently heat 1 sachet +
setting 5 uncovered, for approx. 4-5
minutes, stirring occasionally.
1
/2 minutes.
1
/2-1 minutes, stirring occasion-
1
/4 l liquid at
The examples below are for an oven
with a maximum microwave power output of 900/1000 watts.
For models with a different power output scale, adjust according to the table
on page 12. E.g. for a 750 watt model
use setting 6 instead of setting 5.
Bottling
Bottling should only be undertaken by
an experienced cook who has received
proper training in this method of
preserving fruit and vegetables in an
oven or microwave oven, and understands the implications of the chemical
reactions involved.
Proving dough
(500 g flour) leave covered to rise for
approx. 8-10 minutes at setting 1.
Skinning tomatoes
Score 3 tomatoes crosswise at the bottom, drop into water and heat at setting
5 for approx. 2 minutes. The skin can
now be peeled away easily. Take care,
the tomatoes may be very hot.
31
Cleaning and care
Cleaning and care
Microwave oven
Disconnect the microwave oven
from the power supply before cleaning.
Oven housing and interior
The housing and interior can be
cleaned using a damp cloth with a solution of washing up liquid or a mild detergent and water. Wipe dry with a soft
cloth.
Avoid too much water as this could
penetrate the openings of the oven interior.
Do not use a scouring agent which
could scratch.
The stainless steel surfaces can be
cleaned with a non-abrasive cleaner for
stainless steel.
To neutralise odours in the microwave
put a cup of water with some lemon
juice in the oven and simmer for a few
minutes.
Always keep the roller ring underneath it clean as well as the oven
floor. Otherwise the ring might not
run smoothly.
Do not turn the carrier manually, as
this could damage the drive motor.
Door interior
Always keep the door interior clean. Do
not use any scouring agent. Check the
door and door seal at regular intervals
for any sign of damage. If any damage
is noticed, the oven should not be used
again in microwave mode until the fault
has been rectified by a service engineer trained by Miele.
Air vents
Do not let water or any other object find
its way into the ventilation outlets.
The turntable can be removed for
cleaning.
32
Cleaning and care
Accessories (depending on model)
Boiling rod
The boiling rod can be washed in a dishwasher.
Cleaning and care
Rack, baking tray and runners
Wash and dry after each use. Remove
stubborn soils
– from stainless steel:
with a stainless steel cleaner.
Side runners
The side runners can be removed to
clean the oven interior walls.
Take the runners out at the bottom
from the side wall, pull upwards and
un-hook.
Reassemble in reverse order.
– from enamel:
Soak to loosen the soil and then
clean with a soft brush or a sponge.
Glass tray
The glass tray can be washed in a solution of hot water and washing up liquid
or in the dishwasher.
Do not use scouring agents, as these
would scratch the surface.
Ceramic anti-splash roof liner
Take out and clean with washing up liquid and water after each use.
33
Problem solving guide
Problem solving guide
Repairs to electrical appliances
should only be carried out by suitably qualified and competent service technicians trained by Miele.
Improper repairs may pose a
serious risk to the user.
. . . the turntable does not turn
smoothly.
Check whether the path described
by the ring on the base of the oven
interior under the turntable is clean,
and if not remove any soiling.
The following minor malfunctions however can usually be resolved without
calling the Service Department:
What to do if . . .
. . . a process cannot be started.
Check whether,
the appliance door is closed
properly.
a time has been entered.
the appliance is plugged in to the
mains supply.
the mains fuse has blown (call a
qualified electrician or the Service
department, see "After Sales Service").
. . . food is not adequately defrosted,
heated or cooked at the end of the
selected process time.
check whether the correct power setting was selected for the time set.
The lower the power setting the longer
the time required.
. . . strange noises are heard when
the microwave oven is being used.
Check whether,
the food is covered with aluminium
foil.
If it is remove it.
Sparks are being created by the use
of crockery with a metallic finish. See
notes on types of containers.
. . . food cools down too quickly.
In the microwave oven, food begins to
cook from the outside first, the inside of
the food relying on the slower conduction of heat.
If food is cooked at a high power level
it is possible that the heat may not have
reached the centre of the food. During
standing time heat is transferred to the
centre of the food. Food may be warm
in the middle but cool on the edge.
When reheating food with different densities, such as plated meals it is sensible to start with a low power level and
lengthen the time required.
check whether the process has been
interrupted and not restarted.
34
Problem solving guide
. . . the microwave switches itself off
during a cooking, reheating or defrosting process.
There may be insufficient air circulation.
Check whether:
the air inlet is blocked.
Any object is blocking the ventilation
outlets.
whether anything is blocking the gap
between the base of the unit and the
worktop surface.
Remove any objects if necessary. The
appliance switches off automatically in
the case of overheating. Cooking can
be recontinued after a cooling-down
period.
If the microwave oven switches itself off
repeatedly, please call the Service Department.
Problem solving guide
If it is not possible to remedy a fault
by following the instructions given
above, on no account open the appliance casing.
These microwave ovens should only
be repaired by suitably qualified
technicians trained by Miele.
. . . an E appears in the display
This appears with an incorrect entry.
Press the C touchpad once. Afterwards, it is possible to enter the settings again.
. . . an E 15 appears in the display
The oven interior is too hot.
Let the appliance cool down with the
door open for 15 – 20 minutes. Afterwards, press the C touchpad and
enter the settings again.
35
After sales service
After sales service
In the event of any faults which you cannot easily remedy, please contact
– your Miele dealer
– the nearest Miele Service Depart-
ment.
See address on the back page.
When contacting the service depart-
ment please quote the Model and Serial number of your appliance, given on
the data plate which is located externally, on the rear wall of the appliance.
36
Installation and electrical connection
Installation and electrical connection
All electrical work should be carried out
by a competent person, in accordance
with national and local safety regulations.
The microwave oven is supplied with a
mains cable and plug for connection to
a single phase 230-240 V, 50 Hz a. c.
supply. The voltage, rated load and
fuse rating are given on the data plate.
Please ensure that these match the
household mains supply.
If the cable is damaged it must be
replaced by a special cable which
must be fitted by a competent person trained by the manufacturer.
Please consult the Customer Service dept.
For extra safety it is advisable to install
a residual current device (RCD) with a
trip current of 30 mA.
GB / IRL
Connection should be made via a
fused connection unit or a fused plug
and a suitable switched socket, (rated
load under 3000 W), or via suitable isolator (rated load over 3000 W), which is
easily accessible.
AUS / NZ
The plug rating is 10 A.
Important
The wires in the mains lead are coloured in accordance with the following
code:
Green/yellow = earth
Blue = neutral
Brown = live
As the colours of the wires in the mains
lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows:
The wire which is coloured green and
yellow must be connected to the terminal in the plug which is marked with the
letter E or by the earth symbol
coloured green or green and yellow.
The wire which is coloured blue must
be connected to the terminal which is
marked with the letter N or coloured
black.
The wire which is coloured brown must
be connected to the terminal which is
marked with the letter L (GB / IRL) or
A (AUS / NZ) or coloured red.
WARNING
THIS APPLIANCE MUST
BE EARTHED
z or
This appliance is elecrically suppressed according to
AS / NZS 4052 : 1992
37
Installation and electrical connection
Non rewireable plugs BS 1363
(GB / IRL)
If this machine or appliance is fitted
with a non-rewireable plug, the following information applies:
If the socket outlets are not suitable for
the plug supplied with this product, it
must be cut off and an appropriate
plug fitted.
The plug cut from the flexible cord
should be disposed of and on no account be inserted into a socket elsewhere in the house (electric shock hazard).
The fuse cover must be refitted when
changing the fuse, and if the fuse
cover is lost, the plug must not be used
until a suitable replacement is obtained. The colour of the correct replacement cover is that of the coloured
insert in the base of the plug, or the colour that is embossed in words in the
base of the plug (as applicable to the
design of plug fitted).
The correct fuse rating of the replacement fuses that are ASTA approved to
BS 1362 should be fitted. Replacement fuse covers may be purchased
from your local electrical suppliers, or
Miele Service Agent.
Do not position the appliance too
close to adjacent furniture.
A space of 5 cm (M 636 EG: 10 cm)
is required all round the appliance
for ventilation.
The microwave oven should be positioned or built-in at least 85 cm
above the ground (EN 60335) except for M 636 EC.
When installing a microwave oven
care should also be taken that the
air can be freely discharged from
under and behind the appliance.
Do not place any objects on the ventilation outlets or block the space
between the appliance floor and the
surface upon which it is placed.
The microwave oven can be:
– placed on a worktop
– built under a wall unit in conjunction
with a building under frame
(M 616 EG) only.
– built into a wall unit (M 616 EG only)
or into a tall unit.
M 636 EC on the other hand can be
built under a worktop, with the exception of the stainless steel version.
Use the appropriate building frame and
follow the fitting instructions.
38
The special fitting kit with instructions is
available from the Miele specialist
dealer or the Domestic Sales Department.
Technical data
M 616 EG
Voltage . . . . . . . . . . . . 230-240 V, 50 Hz
Technical data
M 636 EG
Voltage . . . . . . . . . . . 230-240 V, 50 Hz
Rated load . . . . . . . . . . . see data plate
Power settings . . . . 9 (80/150/200/300/
. . . . . . . . . . . . 400/450/550/600/750 W)
Fuse/plug rating . . . . . . . see data plate
Timer switch . . . . . . . . up to 99 minutes
Freestanding appliance:
Dimensions (H x W x D) in mm:
Housing . . . . . . . . . . . . 296 x 440 x 316
Net weight . . . . . . . . . . . . . . . . . . 15 kg
M 626 EG
Voltage . . . . . . . . . . . . 230-240 V, 50 Hz
Rated load . . . . . . . . . . . see data plate
Power settings . . . . 9 (80/150/250/350/
. . . . . . . . . . . . 450/500/600/700/850 W)
Fuse/plug rating . . . . . . . see data plate
Timer switch . . . . . . . . up to 99 minutes
Freestanding appliance:
Dimensions (H x W x D) in mm:
Housing . . . . . . . . . . . . 296 x 496 x 384
Net weight . . . . . . . . . . . . . . . . . . 17 kg
Rated load. . . . . . . . . . . see data plate
Power settings. . . . 9 (100/200/300/400/
. . . . . . . . . . . 500/600/700/800/900 W)
Fuse/plug rating . . . . . . see data plate
Timer switch . . . . . . . up to 99 minutes
Freestanding appliance:
Dimensions (H x W x D) in mm:
Housing. . . . . . . . . . . . 348 x 555 x 429
Net weight . . . . . . . . . . . . . . . . . . . 22kg
M 636 EC
Voltage . . . . . . . . . . . 230-240 V, 50 Hz
Rated load. . . . . . . . . . . see data plate
Power settings. . . . . 9 (80/150/250/350/
. . . . . . . . . . . 450/500/600/700/850 W)
Fuse/plug rating . . . . . . see data plate
Timer switch . . . . . . . up to 99 minutes
Freestanding appliance:
Dimensions (H x W x D) in mm:
Housing. . . . . . . . . . . . 348 x 555 x 484
Net weight . . . . . . . . . . . . . . . . . . . 26kg
M 626 EC
Voltage . . . . . . . . . . . . 230-240 V, 50 Hz
Rated load . . . . . . . . . . . see data plate
Power settings . . . . 9 (80/150/250/350/
. . . . . . . . . . . . 450/500/600/700/850 W)
Fuse/plug rating . . . . . . . see data plate
Timer switch . . . . . . . . up to 99 minutes
Freestanding appliance:
Dimensions (H x W x D) in mm:
Housing . . . . . . . . . . . . 296 x 496 x 460
Net weight . . . . . . . . . . . . . . . . . . 25 kg
39
Alteration rights reserved / 22 / 004 AUS, GB - 3498
This paper consists of cellulose which has been bleached without the use of chlorine.
Loading...
