Miele KM 6357, KM 6386 Operating instructions
Operating and Installation Instructions
Ceramic cooktops with induction
To avoid the risk of accidents or damage to the appliance it is
imperative that you read these instructions before
installing the appliance and using it for the first time
.
en-CA M.-Nr. 09 330 060
Contents
Warnings and safety instructions ........................................................................ 4
Caring for the environment ................................................................................ 14
Overview............................................................................................................... 15
Cooktop................................................................................................................. 15
KM 6357 / KM 6358 ......................................................................................... 15
KM 6386 / KM 6387 ......................................................................................... 16
Controls/Indicators................................................................................................ 17
Burner data............................................................................................................ 18
Initial commissioning .......................................................................................... 20
Cleaning the cooktop for the first time.................................................................. 20
Turning on the cooktop for the first time ............................................................... 20
Induction .............................................................................................................. 21
How it works.......................................................................................................... 21
Noises.................................................................................................................... 22
Cookware .............................................................................................................. 23
Energy saving tips .............................................................................................. 24
Setting range........................................................................................................ 25
Operation.............................................................................................................. 26
Basic operation ..................................................................................................... 26
Switching on.......................................................................................................... 27
Selecting/Changing the power level...................................................................... 27
Switching off.......................................................................................................... 27
Residual heat indicator.......................................................................................... 27
Setting the power level - expanded setting range ................................................ 28
PowerFlex cooking zone ....................................................................................... 28
Auto Heat-up......................................................................................................... 29
Booster.................................................................................................................. 30
Keeping food warm ............................................................................................... 32
Timer..................................................................................................................... 33
Timer ..................................................................................................................... 33
Turning a cooking zone off automatically.............................................................. 35
Using both timer functions at the same time ........................................................ 36
Additional functions ............................................................................................ 37
Stop & Go.............................................................................................................. 37
Safety features..................................................................................................... 38
System lock/Safety lock........................................................................................ 38
2
Contents
Safety shut-off....................................................................................................... 39
Overheat protection............................................................................................... 40
Cleaning and care ............................................................................................... 41
Programming ....................................................................................................... 43
Frequently Asked Questions .............................................................................. 46
Optional accessories ..........................................................................................49
Miele@home / Con@ctivity ................................................................................ 50
Safety instructions for installation..................................................................... 52
Safety clearances ................................................................................................ 53
Instructions for installation ................................................................................ 57
Installation dimensions....................................................................................... 58
KM 6357 ................................................................................................................ 58
KM 6386 ................................................................................................................ 59
Installation............................................................................................................ 60
Electrical connection ..........................................................................................61
Service..................................................................................................................63
Contact in case of a fault ...................................................................................... 63
Data plate .............................................................................................................. 63
Warranty ................................................................................................................ 63
3
Warnings and safety instructions
This appliance conforms to current safety requirements. However,
improper use can result in personal injury and damage to property.
To prevent accidents and damage to the cooktop, please read
these instructions carefully before using the cooktop for the first
time. They contain important notes on installation, safety, use and
maintenance.
Miele cannot be held liable for damage occurring as a result of
non-compliance with these instructions.
Keep these instructions in a safe place and pass them on to any
future owners.
4
Warnings and safety instructions
Intended use
This cooktop is intended for domestic use and use in other similar
environments.
This cooktop is not intended for outdoor use.
The cooktop is intended to prepare food and keep it warm in
domestic use only. Any other use may be hazardous.
Persons who are unable to safely operate the cooktop due to
limited physical, sensory or mental abilities or because they lack
experience or knowledge may only use the appliance if they are
supervised while doing so. These persons may only use the cooktop
without supervision if they have been shown how to use it in a safe
manner, and if they are able to recognize and understand the
potential risks of improper use.
5
Warnings and safety instructions
Safety with children
Children under 8 years of age must be kept away from the
cooktop unless they are constantly supervised.
Children ages 8 and up may only use the cooktop without
supervision if they have been shown how to use it in a safe manner,
and if they are able to recognize and understand the potential risks
of improper use.
Children must not be allowed to clean the cooktop without
supervision.
Be sure to supervise any children in the vicinity of the cooktop,
and do not let them play with it.
The cooktop gets hot when in use and remains hot for some time
after being switched off. Keep children away from the cooktop until it
has cooled down and is no longer a burn hazard.
Burn hazard.
Keep the spaces above and behind the cooktop clear of any items
that could draw the attention of children. Otherwise, they can be
tempted into climbing onto the appliance.
Risk of burning or scalding.
Turn all handles away from the front of the cooktop so that children
cannot pull pots and pans down and burn themselves.
Risk of suffocation. Children may be able to wrap themselves in
packaging material or pull it over their heads with the risk of
suffocation. Keep children away from all packaging materials.
Activate the system lock to ensure that children cannot turn on the
appliance inadvertently. Use the safety lock when the cooktop is in
use to prevent children from altering the settings selected.
6
Warnings and safety instructions
Technical safety
Installation, maintenance and repair work should only be
performed by a Miele authorized service technician. Installation,
maintenance and repair work by unqualified persons can cause
considerable danger to users.
A damaged cooktop can be dangerous. Always check for visible
signs of damage. Never use a damaged appliance.
Reliable and safe operation of the cooktop can only be
guaranteed if it is connected to the public power supply.
The electrical safety of this cooktop can only be guaranteed when
it is properly grounded. Compliance with this essential safety
requirement is absolutely necessary. If in any doubt, please have the
building's electrical system checked by a qualified electrician.
To avoid damaging the cooktop, make sure that the connection
data (voltage and frequency) on the data plate correspond to the
building's power supply before connecting the appliance.
When in doubt, consult a qualified electrician.
Do not connect the appliance to the electrical supply with a power
bar or extension cord. These are a fire hazard and do not guarantee
the required safety of the appliance.
For safety reasons, the cooktop may only be used when it has
been fully installed.
This cooktop must not be used in non-stationary locations (e.g. on
a ship).
Any contact with live connections or tampering with the electrical
or mechanical components of the cooktop will endanger your safety
and may lead to cooktop malfunctions.
Do not open the casing of the cooktop under any circumstances.
Any repairs not performed by a Miele authorized service
technician will void the warranty.
7
Warnings and safety instructions
Miele can only guarantee the safety of the appliance if genuine
Miele spare parts are used. Defective components must only be
replaced by genuine Miele spare parts.
The appliance is not intended for use with an external timer switch
or a remote control system.
Connection of the cooktop to the electrical power supply must
only be performed by a qualified electrician (see "Electrical
connection").
If the power cord is damaged, it must be replaced with a special
connection cable typeH05VV-F (PVC insulated). See "Electrical
connection".
During installation, maintenance, and repair work, the cooktop
must be completely disconnected from the household electricity
supply. It is only completely isolated from the electricity supply
when:
– the main circuit breaker has been tripped, or
– the plug fuses have been fully unscrewed or
– the power plug (if present) is removed from the outlet. To do this,
pull the plug not the cord.
If the cooktop is fitted with a communication module, in addition
to disconnecting the cooktop, this module must also be
disconnected from the electrical supply during installation and
maintenance of the cooktop as well as while any repair work is being
carried out
Risk of electric shock.
If the ceramic surface of the cooktop is defective or chipped,
cracked or broken in any way, immediately turn the cooktop off and
do not continue to use it. Disconnect the cooktop from the power
supply and contact Miele.
8
Warnings and safety instructions
If the cooktop is installed behind a cabinet door, do not close the
door while the cooktop is in operation. Heat and moisture can build
up behind the closed door and cause damage to the cooktop,
cabinetry and flooring. Do not close the door until the cooktop has
completely cooled down.
9
Warnings and safety instructions
Proper use
The cooktop gets hot when in use and remains hot for a while
after being turned off. A burn hazard is present until the residual heat
indicators go out.
Oil and fat can catch fire if overheated. Never leave the cooktop
unattended when cooking with oil and fat. If the oil or fat catches
fire, do not attempt to put the flames out with water.
Turn off the cooktop and smother the flames using a lid or a suitable
fire blanket.
The flames could set the grease filters of a ventilation hood on fire.
Do not flambé under a hood.
Spray canisters, aerosols and other flammable substances can
ignite when heated. Therefore, do not store such items or
substances in a drawer under the cooktop. Any cutlery inserts must
be heat-resistant.
Never heat empty cookware.
Do not heat or can food in closed containers, such as tins or
sealed jars, on the cooktop, as pressure will build up in the container
and cause it to explode.
If the cooktop is covered, there is a risk that the material of the
cover will ignite, explode or melt if the range is still hot or if it is
turned on inadvertently. Never cover the appliance with a cover,
cloth or protective foil.
If the cooktop is on or accidentally turned on, or if it is still hot,
metal objects on the cooktop can heat up. Other items may melt or
catch fire. Damp lids can become attached to the cooktop by
suction. Do not store items on the cooktop. Always turn the burners
off after use.
10
Warnings and safety instructions
You can burn yourself on a hot cooktop. When cooking on the
cooktop, protect your hands by using heat-resistant pot holders or
oven mitts. Only use dry pot holders and oven mitts. Wet or damp
textiles conduct heat more effectively and produce steam, which
poses a burn hazard.
When using an electrical appliance, e.g. a hand mixer, near the
cooktop, make sure that the power cable does not come into
contact with the hot cooktop. The cable's insulation could become
damaged.
Grains of salt, sugar and sand (e.g. from cleaning vegetables) can
cause scratches if they get onto pan bottoms. Make sure that the
ceramic surface and pan bottom are clean before placing any pans
on the cooktop.
Even light objects (such as a salt shaker) can cause damage to
the ceramic cooktop in certain circumstances. Do not drop anything
on the ceramic surface.
Do not place hot pans on the sensor buttons and display as this
could cause damage to the electronics underneath. Do not place hot
pans on the area around the display.
Do not allow solid or liquid sugar, or pieces of plastic or aluminum
foil, to get on the cooktop when it is hot, as they can damage the
ceramic surface when it cools down. If this should occur, turn off the
appliance immediately and scrape off all the sugar, plastic or
aluminum residues while still hot using a scraper blade. Wear oven
mitts when doing so. Allow the burners to cool down and clean them
with a suitable ceramic cleaning agent.
Pans that boil dry can damage the ceramic surface. Never leave
the cooktop unattended during use.
Pots and pans with rough bottoms can scratch the ceramic
surface. Only use pots and pans that are smooth on the bottom.
11
Warnings and safety instructions
Lift pans into position on the cooktop. Sliding them into place can
cause scuff marks and scratches.
Because induction heating works so quickly, the temperature of
the cookware bottom can quickly reach the ignition point of oils and
fats. Never leave the cooktop unattended when it is on!
Do not heat oils and fats for longer than one minute, and never
use the booster.
For people who have a heart pacemaker: Please note that an
electromagnetic field is created in the area immediately surrounding
the cooktop. It is very unlikely to affect a pacemaker. However, if in
any doubt, consult the manufacturer of the pacemaker or your
doctor.
Objects affected by electromagnetic fields, for instance, credit
cards, CDs and calculators, should be kept away from the cooktop
when it is on.
Metal utensils stored in a drawer under the cooktop can become
hot if the appliance is used intensively for a long time. Do not store
any metal items or utensils in a drawer under the cooktop.
This cooktop is equipped with a cooling fan. If a drawer is fitted
directly underneath the cooktop, ensure that there is sufficient space
between the drawer and its contents and the underside of the
appliance in order to ensure sufficient ventilation of the cooktop. Do
not store pointed or small items or paper in the drawer. They could
get in through the ventilation slots or be sucked into the housing by
the fan and damage the fan or impair cooling.
Do not use two pans on a cooking zone, a casserole cooking zone
or a PowerFlex zone at the same time.
If the cookware only partially covers the cooking or roasting zone,
the handle could become very hot.
Make sure to place the cookware in the middle of the cooking or
casserole cooking zone!
12
Warnings and safety instructions
Cleaning and care
Do not use a steam cleaner to clean the cooktop.
The steam could reach electrical components and cause a short
circuit.
If the cooktop is built in over a self-cleaning oven, the cooktop
should not be used while the self-cleaning process is being carried
out, as this could trigger the overheating protection mechanism on
the cooktop (see relevant section).
13
Caring for the environment
Disposal of the transport packaging material
The packaging material protects the
appliance from transport damage. The
packaging materials used are selected
from materials which are
environmentally friendly for disposal
and should be recycled.
Recycling the packaging reduces the
use of raw materials in the
manufacturing process and also the
amount of waste. You can return the
packaging to your Miele dealer.
Disposal of your old appliance
Electronic and electrical appliances
contain many valuable materials. They
also contain certain materials,
compounds and components which
were essential for their correct
functioning and safety. These could be
hazardous to your health and to the
environment if disposed of with general
waste or if handled incorrectly. Please
do not, therefore, dispose of your old
appliance with general waste.
Instead, please make use of officially
designated collection and disposal
points to dispose of and recycle
electrical and electronic appliances in
your local community, dealer, or with
Miele. By law, you are solely
responsible for deleting any personal
data from the appliance prior to
disposal. Ensure that it presents no
danger to children while being stored
for disposal.
14
Cooktop
a
c
b
d
e
KM 6357 / KM 6358
Overview
a
Cooking zone with Booster
b
Cooking zone with Booster
c
PowerFlex cooking zone with TwinBooster
d
PowerFlex cooking zone with TwinBooster
cd
can be combined to form PowerFlex cooking zone
e
Controls/Indicators
15
Overview
a
b
c
d
f
e
KM 6386 / KM 6387
a
Cooking zone with Booster
b
Cooking zone with Booster
c
Cooking zone with Booster
d
PowerFlex cooking zone with TwinBooster
e
PowerFlex cooking zone with TwinBooster
de
f
Controls/Indicators
can be combined to form PowerFlex cooking zone
16
Controls/Indicators
0123456789 0123456789 0123456789
0123456789 0123456789
h
f
o
88
m
e
c
l
n
p
k
i
abd
g
j
h
Sensor buttons
a
For switching the cooktop on and off
b
For activating/deactivating the system lock/safety lock
c
For switching the timer to hours
d
Timer
- For turning on and off
- For switching between timer functions
- For selecting a cooking zone (see "Turning a cooking zone off automatically")
e
For activating/deactivating Stop&Go
f
For selecting the power setting
g
For switching the Booster/TwinBooster/WaterBoost on/off
h
Turning the PowerFlex cooking zone on/off
i
Control scale
- For setting a timer/turn-off time
- For setting the power level for middle rear cooking zone (depending on model)
j
Turning the keep warm function on/off
Indicator lamps
k
Residual heat
l
In half hours if the minute minder setting exceeds 99 minutes
m
System lock/Safety lock activated
n
Shows cooking zone selection, e.g. rear right cooking zone
Overview
17
Overview
o
TwinBooster/WaterBoost (depending on model) switched on
Level 1
Level 2
p
Timer display
to Time in minutes
. to . Time in hours
System lock/Safety lock activated
Demonstration mode activated
Burner data
Burner KM 6357 / KM 6358
Øin cm* Power in watts at 230 V**
18–28 normal
TwinBooster, Level 1
TwinBooster, Level 2
10–16 normal
Booster
15–23 normal
TwinBooster, Level 1
TwinBooster, Level 2
15–23 normal
TwinBooster, Level 1
TwinBooster, Level 2
+ 22–23 /
15x23–23x39
* Within the specified range, pots with any base diameter can be used.
** The specified power can vary depending on the size and the material of the pots and
pans.
normal
TwinBooster, Level 1
TwinBooster, Level 2
Total 7400
2600
3000
3700
1400
2200
2100
3000
3700
2100
3000
3700
3400
4800
7400
18
Burner KM 6386 / KM 6387
Øin cm* Power in watts at 230 V**
Overview
14–20 normal
Booster
10–16 normal
Booster
18–28 normal
WaterBoost, level 1
WaterBoost, level 2
15–23 normal
TwinBooster, Level 1
TwinBooster, Level 2
15–23 normal
TwinBooster, Level 1
TwinBooster, Level 2
+ 22–23 /
15x23–23x39
normal
TwinBooster, Level 1
TwinBooster, Level 2
Total 7400
* Within the specified range, pots with any base diameter can be used.
** The specified power can vary depending on the size and the material of the pots and
pans.
1850
3000
1400
2200
2600
3000
3700
2100
3000
3700
2100
3000
3700
3400
4800
7400
19
Initial commissioning
Please affix the extra appliance data
plate supplied with this
documentation in the space provided
in the "Service" section of this
manual.
Remove any protective foil and
stickers from the cooktop.
Cleaning the cooktop for the first time
Before using it for the first time, wipe
down the cooktop with a damp cloth
and then wipe it dry.
Turning on the cooktop for the first time
Metal components are protected by a
conditioning agent. Smells and vapour
may occur when the appliance is used
for the first time. The heating of the
induction coils also causes odours in
the first few hours of operation. With
each subsequent use, the odour is
reduced until it disappears entirely.
The smell and any vapors that may
occur do not indicate a faulty
connection or defective appliance and
are not harmful to your health.
Please note that the heating-up time
for induction cooktops is very much
shorter than for conventional
cooktops.
20
Induction
How it works
An induction coil is located under each
burner. When a zone is turned on, this
coil creates a magnetic field that
interacts directly with the base of the
pan and heats it up. The burner itself is
heated up indirectly by the heat given
off by the pan.
An induction burner only works when a
ferromagnetic pan is placed on it (see
"Cookware"). The induction burner
automatically recognizes the size of the
pan.
On the control scale of the cooking
zone, power levels 1 to 9 flash if:
– the cooking zone has been switched
on without a pan in place, if the pan
is unsuitable (non-magnetic base),
– if the diameter of the base of the pan
is too small,
– or if the pan is taken off the cooking
zone when it is switched on.
When the appliance is switched
on either deliberately or by mistake,
or when there is residual heat
present, there is the risk of heating
up any metal items placed on the
cooktop.
Burn hazard!
Do not store items on top of the
cooking area. Switch the cooking
zones off after use by turning the
relevant sensor button.
If suitable cookware is placed on the
cooking zone within 3 minutes, you can
continue as usual.
If no cookware or if unsuitable
cookware is used, the cooking zone will
automatically turn off after 3 minutes.
21
Loading...
