Miele KM 6356 Operating instructions

Download
Operating and installation instructions Ceramic hobs with induction
To avoid the risk of accidents or damage to the appliance it is essential to read these instructions before it is installed and used for the first time.
en-GB M.-Nr. 09 743 770
Contents
Warning and Safety instructions.......................................................................... 4
2
Contents
3

Warning and Safety instructions

This hob complies with all relevant safety requirements. Inappro­priate use can, however, lead to personal injury and damage to property.
To avoid the risk of accidents and damage to the hob, please read these instructions carefully before installation and before using it for the first time. They contain important notes on installation, safety, use and maintenance. Miele cannot be held liable for damage caused by non-compliance with these instructions.
Keep these instructions in a safe place and ensure that new users are familiar with the content. Pass them on to any future owner.
4
Warning and Safety instructions

Correct application

This hob is intended for domestic use and use in other similar en-
vironments.
This hob is not intended for outdoor use.It is intended for domestic use only to cook food and keep it
warm. Any other use is not supported by the manufacturer and could be dangerous.
People with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge who are not able to use the hob safely on their own must be supervised whilst using it. They may only use it unsupervised if they have been shown how to use it safely and recognise and understand the consequences of incorrect opera­tion.
5
Warning and Safety instructions

Safety with children

Children under 8 years of age must be kept away from the hob
unless they are constantly supervised.
Children 8 years and older may only use the hob unsupervised if
they have been shown how to use it in a safe way and can recognise and understand the consequences of incorrect operation.
Children must not be allowed to clean the hob unsupervised.Please supervise children in the vicinity of the hob and do not let
them play with it.
The hob gets hot when in use and remains hot for a while after be-
ing switched off. Keep children well away from the hob until it has cooled down and there is no danger of burning.
Danger of burning.
Do not store anything which might arouse a child's interest in stor­age areas above or next to the hob. Otherwise they could be temp­ted into climbing onto the appliance.
Danger of burning or scalding.
Place pots and pans on the cooking zone in such a way that children cannot pull them down and burn themselves.
Danger of suffocation. Packaging, e.g. plastic wrappings, must be
kept out of the reach of babies and children. Whilst playing, children could become entangled in packaging or pull it over their head and suffocate.
Activate the system lock to ensure that children cannot switch on
the hob inadvertently. Use the safety lock when the hob is in use to prevent children from altering the settings selected.
6
Warning and Safety instructions

Technical safety

Unauthorised installation, maintenance and repairs can cause
considerable danger for the user. Installation, maintenance and re­pairs must only be carried out by a Miele authorised technician.
Do not use a damaged appliance. It could be dangerous. Check
the hob for visible signs of damage.
Reliable and safe operation of this hob can only be assured if it
has been connected to the mains electricity supply.
The electrical safety of this hob can only be guaranteed when cor-
rectly earthed. It is essential that this standard safety requirement is met. If in any doubt please have the electrical installation tested by a qualified electrician.
To avoid the risk of damage to the hob, make sure that the con-
nection data on the data plate (voltage and frequency) match the mains electricity supply before connecting it to the mains. Consult a qualified electrician if in doubt.
Do not connect the hob to the mains electrical supply by a multi-
socket adapter or extension lead. These are a fire hazard and do not guarantee the required safety of the appliance.
For safety reasons, this hob may only be used after it has been
built in.
This hob must not be used in a non-stationary location (e.g. on a
ship).
Never open the casing of the hob.
Touching or tampering with electrical connections or components and mechanical parts is highly dangerous to the user and can cause operational faults.
While the hob is under warranty, repairs should only be under-
taken by a Miele authorised service technician. Otherwise the war­ranty is invalidated.
7
Warning and Safety instructions
Miele can only guarantee the safety of the appliance when genu-
ine original Miele replacement parts are used. Faulty components must only be replaced by Miele spare parts.
The hob is not intended for use with an external timer switch or a
remote control system.
The hob must be connected to the electricity supply by a qualified
electrician (see "Electrical connection").
If the connection cable is damaged, it must be replaced with a
special connection cable typeH05V2 V2-F (PVC insulated). See "Electrical connection".
The hob must be disconnected from the mains electricity supply
during installation, maintenance and repair work. Ensure that power is not supplied to the appliance until after it has been installed or un­til any maintenance or repair work has been carried out.
Danger of electric shock.
Do not use the hob if it is faulty, or if the ceramic surface is cracked, chipped or damaged in any way. Switch it off immediately, discon­nect it from the mains electricity supply and contact Miele.
If the hob is installed behind a furniture panel (e.g. a door), ensure
that the door is never closed whilst the hob is in use. Heat and mois­ture can build up behind a closed furniture panel and cause sub­sequent damage to the hob, the housing unit and the floor. Do not close the door until the residual heat indicators have gone out.
8
Warning and Safety instructions

Correct use

The hob gets hot when in use and remains hot for a while after be-
ing switched off. There is a danger of burning until the residual heat indicators go out.
Oil and fat can overheat and catch fire. Do not leave the hob unat-
tended when cooking with oil and fat. If it does ignite do not attempt to put the flames out with water. Disconnect the hob from the mains and use a suitable fire blanket, saucepan lid, damp towel or similar to smother the flames.
Flames could set the grease filters of a cooker hood on fire. Do
not flambé under a cooker hood.
Spray canisters, aerosols and other inflammable substances can
ignite when heated. Therefore do not store such items or substances in a drawer under the hob. Cutlery inserts must be heat-resistant.
Do not heat an empty pan.Do not heat up food in closed containers e.g. tins or sealed jars
on the hob, as pressure can build up in the container, causing it to explode.
Do not cover the hob, e.g. with a hob cover, a cloth or protective
foil. The material could catch fire, shatter or melt if the hob is switched on by mistake or if residual heat is still present.
When the appliance is switched on either deliberately or by mis-
take, or when there is residual heat present, there is the risk of any metal items left on the hob heating up, with the danger of burning. Depending on the material, other items left on the hob could also melt or catch fire. Damp pan lids might adhere to the ceramic sur­face and be difficult to dislodge. Do not use the appliance as a rest­ing place. Switch the cooking zones off after use.
9
Warning and Safety instructions
You could burn yourself on the hot hob. Protect your hands with
heat-resistant pot holders or gloves when handling hot pots and pans. Do not let them get wet or damp, as this causes heat to trans­fer through the material more quickly with the risk of scalding or burning yourself.
When using an electrical appliance, e.g. a hand-held food blender,
near the hob, ensure that the cable of the electrical appliance cannot come into contact with the hot hob. The insulation on the cable could become damaged.
Grains of salt, sugar and sand (e.g. from cleaning vegetables) can
cause scratches if they get under pan bases. Make sure that the ceramic surface is clean before placing pans on it.
Even a light object can cause damage in certain circumstances.
Do not drop anything on the ceramic surface.
Placing hot pans on the sensors and indicators could damage the
electronics underneath. Do not place hot pans on the sensors or in­dicators.
Do not allow solid or liquid sugar, or pieces of plastic or aluminium
foil to get onto the cooking zones when they are hot, as they can damage the ceramic surface when it cools down. If this should oc­cur, switch off the appliance and scrape off all the sugar, plastic or aluminium residues whilst still hot, using a shielded scraper blade. Wear oven gloves. Allow the cooking zones to cool down and clean them with a suitable ceramic hob cleaning agent.
Pans which boil dry can cause damage to the ceramic glass. Do
not leave the hob unattended whilst it is being used.
Only use pots and pans with smooth bases. Rough bases will
scratch the ceramic glass.
Lift pans into position on the hob. Sliding them into place can
cause scuffs and scratches.
10
Warning and Safety instructions
Induction heating works extremely quickly and so the base of the
pan could heat up to the temperature at which oil or fat self-ignites within a very short time. Do not leave the hob unattended whilst it is being used.
Heat oil or fat for a maximum of one minute. Do not use the
Booster function to heat oil or fat.
For people fitted with a heart pacemaker: Please note that the
area immediately surrounding the hob is electromagnetically charged. It is very unlikely to affect a pacemaker. However, if in any doubt, consult the manufacturer of the pacemaker or your doctor.
To prevent damage to items which are susceptible to electromag-
netic fields, e.g. credit cards, digital storage devices, pocket calcu­lators, etc, do not leave them in the immediate vicinity of the hob.
Metal utensils stored in a drawer under the hob can become hot if
the appliance is used intensively for a long time. Do not store any metal items or utensils in a drawer under the hob.
This hob is fitted with a cooling fan. If a drawer is fitted directly
underneath the hob, ensure that there is sufficient space between the drawer and its contents and the underside of the appliance in or­der to ensure sufficient ventilation of the hob. Do not store pointed or small items or paper in the drawer. They could get in through the ventilation slots or be sucked into the housing by the fan and dam­age the fan or impair cooling.
Do not use two pans on a cooking zone, extended zone or Power-
Flex zone at the same time.
If the pan only partially covers the cooking zone, the handle could
become very hot. Ensure that you always place the pan in the middle of the cooking zone.
Only use the wok pan supplied with the appliance. For safety
reasons, other wok pans must not be used. See "Induction - Pans".
11
Warning and Safety instructions

Cleaning and care

Do not use a steam cleaning appliance to clean this hob.
The steam could reach electrical components and cause a short cir­cuit.
If the hob is built in over a pyrolytic oven, the hob should not be
used whilst the pyrolytic process is being carried out, as this could trigger the overheating protection mechanism on the hob (see relev­ant section).
12

Caring for the environment

Disposal of the packing mater­ial
The packaging is designed to protect the appliance from damage during transportation. The packaging materials used are selected from materials which are environmentally friendly for disposal and should be recycled.
Recycling the packaging reduces the use of raw materials in the manufactur­ing process and also reduces the amount of waste in landfill sites.
Disposing of your old appli­ance
Electrical and electronic appliances of­ten contain valuable materials. They also contain specific materials, com­pounds and components, which were essential for their correct function and safety. These could be hazardous to hu­man health and to the environment if disposed of with your domestic waste or if handled incorrectly. Please do not, therefore, dispose of your old appliance with your household waste.
Please dispose of it at your local com­munity waste collection / recycling centre for electrical and electronic ap­pliances, or contact your dealer or Miele for advice. You are also respons­ible (by law, depending on country) for deleting any personal data that may be stored on the appliance being disposed of. Please ensure that your old appli­ance poses no risk to children while be­ing stored prior to disposal.
13

Guide to the appliance

Hob
a
Wok basin with Booster
b
PowerFlex cooking zone with TwinBooster
c
PowerFlex cooking zone with TwinBooster
d
PowerFlex cooking zone with TwinBooster
cd
can be combined to form a PowerFlex cooking area
e
Controls / Indicators
14

Controls / Indicators

Guide to the appliance
Sensor controls
a
On/Off
b
Number sensors
- For setting the power level
- For setting the time
c
For switching the PowerFlex cooking area on and off
d
For activating/deactivating Stop&Go
cd
For activating/deactivating the system lock/safety lock
15
Guide to the appliance
e
Cooking zone selection and display
Cooking zone ready for use Keeping warm setting to Power level TwinBooster level 1 Booster / TwinBooster level 2 PowerFlex cooking area activated No pan on cooking zone or pan unsuitable (see "Induction") Residual heat Auto heat-up
f
Timer selection and displays
 to  Duration in minutes  System lock/safety lock activated
Indicator lights
g
PowerFlex cooking area activated
h
Stop&Go activated
i
For cooking zone selection, e.g. right rear cooking zone
j
Minute minder
16
Guide to the appliance

Cooking zones

Cooking zone Øin cm* Rating in watts for 230 V**
30 Normal
Booster
10–16 Normal
Booster
15–23 Normal
TwinBooster, level 1 TwinBooster, level 2
15–23 Normal
TwinBooster, level 1 TwinBooster, level 2
+ 22–23 /
15x23–23x39
* Pans with a base diameter within the given range may be used. ** The wattage quoted may vary depending on the size and material of the pans used.
Normal TwinBooster, level 1 TwinBooster, level 2
Total: 7300
2300 3200
1400 2200
2100 3000 3650
2100 3000 3650
3400 4800 7300
17
Guide to the appliance

Accessories supplied

The accessories supplied with your ap­pliance as well as a range of optional ones are available to order from Miele (see "Optional accessories").
Wok pan CSWP 1450
18

Before using for the first time

Please stick the extra data plate for
the appliance supplied with this doc­umentation in the space provided in the "After sales service" section of this booklet.
Remove any protective wrapping and
stickers.

Cleaning the hob for the first time

Before using for the first time, clean
the hob with a damp cloth only and then wipe dry.

Switching on the hob for the first time

The metal components have a protect­ive coating which may give off a slight smell when heated up for the first time. The induction coils may also give off a slight smell for the first few hours of op­eration. This smell will be less notice­able with each subsequent use before dissipating completely.
The smell and any vapours given off do not indicate a faulty connection or ap­pliance and they are not hazardous to health.
Please note that the heating up time on induction hobs is very much shorter than on conventional hobs.
19

Induction

How it works

An induction coil is located under each cooking zone. When a cooking zone is switched on, this coil creates a mag­netic field which impacts directly on the base of the pan and heats it up. The cooking zone itself is heated up indir­ectly by the heat given off by the pan.
An induction cooking zone only works when a pan with a magnetic base is placed on it (see "Pans"). Induction automatically recognises the size of the pan.
The symbol flashes alternately with the power setting selected in one of the cooking zone displays
– if the zone has been switched on
without a pan in place, or if the pan is unsuitable (non-magnetic base),
– if the diameter of the base of the pan
is too small,
– if the pan is taken off the cooking
zone when it is switched on.
When the appliance is switched
on either deliberately or by mistake, or when there is residual heat present, there is the risk of any metal items placed on the hob (e.g. cutlery) heating up.
Danger of burning. Do not use the appliance as a resting
place for anything else. Switch the cooking zones off after use with the appropriate sensor control.
If a suitable pan is placed on the cook­ing zone within 3 minutes, the will go out and you can continue as normal.
If no pan or an unsuitable pan is placed on the cooking zone, the cooking zone will switch off automatically after 3minutes.
20

Noises

When using an induction cooking zone, the following noises can occur in the pan, depending on what it is made of and how it has been constructed.
On the higher power settings, it might buzz. This will decrease or cease alto­gether when the power setting is re­duced.
If the pan base is made of layers of dif­ferent materials (e.g. in a sandwiched base), it might emit a cracking sound.
Whistling might occur if linked zones (see "Booster") are being used at the same time, and the pans also have bases made of layers of different mater­ials.
You might hear a clicking sound from the electronic switches, especially on lower power settings.
Induction
You might hear a whirring sound when the cooling fan switches on. It switches on to protect the electronics when the hob is being used intensively. The fan may continue to run after the appliance has been switched off.
21
Induction

Pans

The following pan types are suitable:
– Stainless steel with a base that can
be magnetised,
– enamelled steel,
– cast iron.
The following pan types are not suit- able:
– Stainless steel pans without a mag-
netic base,
– aluminium and copper pans,
– glass, ceramic or earthenware pots
and pans.
To test whether a pot or pan is suitable for use on an induction hob, hold a magnet to the base of the pan. If the magnet sticks, the pan is suitable. If an unsuitable pan is used, the symbol will flash alternately with the power level set.
– Often the maximum diameter quoted
by manufacturers refers to the dia­meter of the top rim of the pot or pan. The diameter of the base (gener­ally smaller) is more important.
– Where possible, use pans with vertic-
ally straight sides. If a pan has angu­lar sides, induction also acts on the sides of the pan. The sides of the pan may discolour or the coating may peel off.
The composition of the pan base can affect the evenness of the cooking res­ults (e.g. when browning pancakes).
– To make optimum use of the cooking
zones, choose a pan with a suitable base diameter (see "Guide to the ap­pliance - Cooking zones"). If the pan is too small, it will not be recognised and the symbol will flash alternately with the power level set.
– Only use pots and pans with smooth
bases. Rough bases will scratch the ceramic glass.
– Lift pans into position on the hob.
Sliding them into place can cause scuffs and scratches.
22
– Use a lid whenever possible to min-
imise heat loss.
– Select a smaller pan when cooking
small quantities. A smaller pan uses less energy than a larger pan with very little in it.
– Cook with as little water as possible.
– Once food has come to the boil or
the oil in the pan is hot enough for frying, reduce the heat to a lower set­ting.
– Use a pressure cooker to reduce
cooking times.

Tips on saving energy

23

Power level range

Cooking zones Setting range
Keeping warm h Melting butter
Dissolving gelatine Melting chocolate
Making milk puddings 2 Warming small quantities of liquid
Cooking rice Defrosting frozen vegetables 3 Making porridge 3 Warming liquid and semi-solid foods
Making omelettes or lightly frying eggs Steaming fruit
Cooking dumplings 4 Steaming vegetables and fish 5 Defrosting and reheating frozen food 5 Gently frying eggs (without overheating the fat) 6 Bringing large quantities of food to the boil, e.g. casseroles. Thickening
custard and sauces, e.g. hollandaise Gently frying meat, fish and sausages (without overheating the fat) 6-7 Frying pancakes, potato fritters etc. 7 Braising meat 8 Boiling large quantities of water
Bringing to the boil
Wok zone
Keeping warm h Heating food up 3–6 Stir-frying, e.g. Chinese food 7–9
1-2
3
4
6-7
9
These settings should only be taken as a guide.The power of the induction coils will vary depending on the size and material of the pan base. For this reason, it is possible that the settings will need to be adjusted slightly to suit your pans. As you use the hob, you will get to know which settings suit your pans best.
24

Operation

How the hob is operated

The glass ceramic hob is equipped with electronic sensor controls which react to finger contact. For safety reasons, in order to switch the hob on, the On/ Off sensor needs to be touched for a little longer than the other sensors. A tone sounds each time a sensor is touched.
When the hob is switched off, only the symbols for the On/Off, Safety lock, Stop&Go and number sensors are visible. When the hob is switched on all the other sensors light up as well.
In order to set or alter a power level or the time, the cooking zones and the timer must be "active". To activate a cooking zone or the timer, touch the sensor for selecting the relevant cook­ing zone or timer. The relevant cooking zone or timer display will begin to flash when touched. Exception: If only one of the cooking zones is in operation, you can alter the power level without activating the cook­ing zone.
Malfunction due to dirty and/or covered sensors
If the sensors are dirty or covered this could cause them to fail to react, to activate a function or even to switch the hob off automatically (see "Safety switch-off"). Placing hot pans on the sensors/indicators can damage the electronic unit under­neath.
Keep the sensors and indicators clean and do not place anything on top of them. Do not place hot pans on them.
25
Operation
Fire hazard.
Do not leave the hob unattended whilst it is being used. Please note that the heating up time on induction hobs is very much shorter than on conventional hobs.

Switching on

Touch the sensor. will appear in each of the cooking
zone displays and will appear in the timer display. If there is no further input, the hob will switch itself off after a few seconds for safety reasons.

Selecting/changing the power level

Touch the sensor for the cooking
zone you want briefly.
will flash alternately with the selected power level in the cooking zone display.
Touch the appropriate number sensor
for the power level you want.

Residual heat indicator

If the cooking zone is still hot, the resid­ual heat indicator will light up after it has been switched off.
The lines of the residual heat indicator go out one after another as the cooking zone cools down. The last horizontal line only goes out when the cooking zone is safe to touch.
The residual heat indicators will flash in the event of a power cut either dur­ing operation or whilst there is still danger from residual heat.
Danger of burning. Do not touch
the cooking zones whilst the residual heat indicators are lit up.
The power level selected will flash in the display for a few seconds to start with and then light up constantly.

Switching off

To switch a cooking zone off, touch
the sensor for the cooking zone you want twice.
To switch off the hob and all the
cooking zones, touch the sensor.
26

PowerFlex cooking area

The PowerFlex cooking zones can be combined to form a PowerFlex cooking area (see "Guide to the appliance ­Hob"). Settings for the cooking area are controlled by the rear or left PowerFlex cooking zone.

Switching on

Touch the sensor. will flash in the display for the rear or
left cooking zone. will appear in the display for the front or right cooking zone.
Set the power level you want by
touching the appropriate number sensor for the rear or left cooking zone.

Switching off

Touch the  sensor.
Operation
27
Operation

Auto heat-up

When Auto heat-up has been activated, the cooking zone switches on automat­ically at the highest power setting and then switches to the continued cooking setting. The heat-up time depends on which continued cooking setting has been chosen (see chart).

Activating

Touch the sensor for the cooking
zone you want briefly.
Touch the sensor for the continued
cooking setting you want until a tone sounds and lights up in the cooking zone display.
lights up in the cooking zone display during the heat-up time (see chart).
Altering the continued cooking setting while the cooking zone is heating up deactivates Auto heat-up.

Deactivating

Touch the sensor for the cooking
zone you want briefly.
Continued cook-
ing setting
1 approx. 0:15
2 approx. 0:15
3 approx. 0:25
4 approx. 0:50
5 approx. 2:00
6 approx. 5:50
7 approx. 2:50
8 approx. 2:50
9 –
Heat-up time
[min : sec]
Touch the continued cooking setting
you have set until the goes out.
or Select a different power level.
28
Operation

Booster

The cooking zones are equipped with a Booster or TwinBooster (see "Guide to the appliance – Hob"). You can use the booster function for a maximum of two cooking zones at the same time.
When activated, the power is boosted for a maximum of 15 minutes so that large quantities can be heated quickly, e.g. when boiling water for cooking pasta.
The booster function can only be used on two cooking zones at the same time.
If the booster function is switched on when
– no power level has been selected,
the cooking zone will revert automat­ically to level 9 at the end of the booster time or if the booster func­tion is switched off before this.
– a power level has been selected, the
cooking zone will revert automatically to the power level selected at the end of the booster time or if the booster function is switched off before this.
Cooking zones are networked in pairs to supply the power for the booster function. When the booster function is selected, a proportion of energy is taken away from the linked cooking zone and the following happens within the pairs:
– Auto heat-up is deactivated
– the power level is reduced
– the linked cooking zone is switched
off.
29
Operation

To switch on the Booster

Touch the sensor for the cooking
zone you want.
Touch the "9" sensor twice. will appear in the cooking zone dis-
play.

To switch on the TwinBooster, level 1

Touch the sensor for the cooking
zone you want.
Touch the "9" sensor twice. will appear in the cooking zone dis-
play.

To switch on the TwinBooster, level 2

Touch the sensor for the cooking
zone you want.
Touch the "9" sensor three times. will appear in the cooking zone dis-
play.
Switching off the Booster / Twin­Booster
Touch the sensor for the cooking
zone you want.
Select a different power level.
30
Operation

Keeping warm

This function is for keeping food warm which has just been cooked and is still hot. It is not for reheating food that has gone cold.
The maximum duration for keeping food warm is 2 hours.
– Keep food warm in the pan it was
cooked in and cover with a lid.
– You do not have to stir food while it is
being kept warm.
– Nutrients are lost when food is
cooked, and continue to diminish when food is kept warm. The longer food is kept warm for, the greater the loss of nutrients. Try to ensure that food is kept warm for as short a time as possible.

Setting the keeping warm function

Touch the sensor for the cooking
zone you want.
Touch the area between the 0 and 1
sensors.
will appear in the cooking zone dis­play.
To switch off the keeping warm func­tion
Touch the sensor for the cooking
zone you want.
Touch the 0 sensor.
31

Timer

The hob has to be switched on if you wish to use the timer. You can select a time up to a max­imum of 99 minutes.
The timer can be used for the following two different functions:
– For setting the minute minder.
– For automatically switching a cooking
zone off.

Minute minder

Setting

Example: You want to set a time of 15 minutes.
Switch the hob on.Touch the timer display.
The right hand and the indicator light for the minute minder will start to flash.
Enter the tens first and then the units.

Changing

Touch the timer display.Set the time you want, as described
above.

Deleting

Touch the time display until ap-
pears.
Touch the number sensor which cor-
responds to the tens position (1 in this case).
The timer display will change and will start flashing on the right hand side.
Touch the number sensor which cor-
responds to the units position (5 in this case).
The timer display will change. The moves to the left and appears on the right.
The minute minder will begin to count down.
32
Timer

Switching a cooking zone off automatically

You can set a time at the end of which a cooking zone will switch off automatic­ally. This function can be used for all the cooking zones at the same time.
If the time programmed is longer than the maximum operational time al­lowed, the cooking zone will switch off after the maximum time allowed (see relevant section).
Select a power level for the cooking
zone you require.
Touch the timer display repeatedly
until the indicator light for this cook­ing zone flashes.
If more than one cooking zone is switched on, the indicator lights will flash in a clockwise direction begin­ning with the front left zone.
Set the time you require.
If you want to set another cooking
zone to switch off automatically, fol­low the same steps as described above.
If more than one switch-off time is programmed, the shortest time re­maining will be displayed, and the cor­responding indicator light will flash. The other indicator lights will light up constantly.
If you want to show the time remain-
ing for another zone which is count­ing down in the background, touch the timer display repeatedly until the indicator light for the zone you require flashes.
33
Timer

Using both timer functions at the same time

The minute minder and automatic switch-off functions can be used at the same time.
If you have programmed in one or more switch-off times, and would like to use the minute minder as well:
Touch the timer display repeatedly
until the indicator lights of the pro­grammed cooking zones light up constantly and the right hand and the indicator light for the minute minder flash in the timer display.
Set the time as described above.
If you have set the minute minder and would like to programme in one or more switch-off times as well:
Touch the timer display repeatedly
until the indicator light for the zone you require flashes.
If you want to show the times remaining which are counting down in the back­ground:
Touch the timer display repeately until
– the indicator light for the cooking
zone you want flashes (automatic switch-off).
– the time display and the indicator
light for the minute minder flash (minute minder).
Starting with the shortest time remain­ing which is shown in the display, all cooking zones which are switched on and the minute minder are selected clockwise.
Set the time as described above.
Shortly after the last entry, the timer display switches to the function with the shortest remaining time.
34

Additional functions

Stop&Go

When Stop&Go is activated, the power of all cooking zones in use is reduced to power level 1. The cooking zone power levels and the timer settings cannot be altered and the hob can only be switched off. A set minute minder time will continue to count down. Booster time, Auto heat­up and automatic switch-off times set will be put on hold.
When Stop&Go is deactivated, the cooking zones will operate at the power level previously selected and the Booster time, Auto heat-up and auto­matic switch-off times will resume run­ning.
If the function is not deactivated, the hob will switch off after an hour.

Activating / Deactivating

Touch the sensor.
Use this function when the sensors need to be cleaned quickly or there is a risk of boiling over.

Recall

If the hob is accidentally switched off during use, you can use this function to restore all the settings. The hob must be switched on again within 6seconds.
Switch the hob on again.Touch the sensor within 6
seconds of switching back on.
35

Safety features

System lock / Safety lock

The system lock and safety lock are deactivated if there is an interruption to the power supply.
Your hob is equipped with a system lock and a safety lock to prevent the hob and the cooking zones being switched on or any settings being altered.
The system lock is set when the hob is switched off. When the system lock ac­tivated, the hob cannot be switched on and the timer cannot be used.
The safety lock is set when the hob is switched on. When the safety lock is activated,
– the cooking zone power levels and
the timer settings cannot be changed.
– the cooking zones, the hob and the
timer can be switched off, but once switched off cannot be switched on again.

Activating

Touch the and sensors until 
appears in the timer display and a tone sounds.
 will go out after a short while..

Deactivating

Touch the and sensors at the
same time until  goes out in the timer display.
If an unavailable sensor is touched whilst the system lock or safety lock is activated  will appear in the timer dis­play for a few seconds and a tone will sound.
36
Safety features

Safety switch-off

Safety switch-off with an overlong cooking time

The safety switch-off mechanism is triggered automatically if one of the cooking zones is heated for an unusu­ally long period of time. This period of time depends on the power level selec­ted. Once exceeded, the cooking zone switches off and the residual heat indic­ators appear. The cooking zone can be operated again after it has been switched off and back on.

Safety switch-off if the sensors are covered

Your hob will switch off automatically if one or several sensors remain covered for more than about 10seconds, for ex­ample by finger contact, food boiling over or an object.  will flash in the cooking zone display and a tone will sound.  will go out once you have re­moved the object or cleaned the hob and the hob will be ready to use again.
37
Safety features

Overheating protection

All the induction coils and cooling ele­ments for the electronics are fitted with an overheating protection mechanism. Before the induction coils or cooling elements get too hot, the overheating protection mechanism cuts in in one of the following ways:
– any booster function in operation will
be switched off.
– the set power level will be reduced.
– the cooking zone will switch off auto-
matically.  will flash in the display.
The overheating protection mechanism can be triggered by:
– heating up an empty pan.
– fat or oil being heated on a high
power level.
– insufficient ventilation to the under-
side of the hob.
– a hot cooking zone being switched
on after an interruption to the power supply.
If, despite removing the cause, the overheating protection mechanism trig­gers again, contact Miele Service.
38

Cleaning and care

Danger of burning.
The cooking zones must be switched off. The hob must have cooled down.
Danger of injury.
The steam from a steam cleaning ap­pliance could reach electrical com­ponents and cause a short circuit.
Do not use a steam cleaner to clean the hob.
The use of unsuitable cleaning agents can cause the surfaces to discolour or alter.
All surfaces are susceptible to scratching.
Remove any cleaning agent residues immediately.
Allow the hob to cool down before cleaning.
Clean the hob after every use.Dry the hob thoroughly after every
cleaning to avoid limescale residue.

Unsuitable cleaning agents

To avoid damaging the surfaces of your appliance, do not use:
– washing-up liquid,
– cleaning agents containing soda, al-
kalines, ammonia, acids or chlorides,
– cleaning agents containing descaling
agents,
– stain or rust removers,
– abrasive cleaning agents, e.g.
powder cleaners and cream cleaners,
– solvent-based cleaning agents,
– dishwasher cleaner,
– grill and oven cleaners,
– glass cleaning agents,
– hard, abrasive brushes or sponges,
e.g. pot scourers, or sponges which have been previously used with ab­rasive cleaning agents,
– melamine eraser blocks.
39
Cleaning and care

Cleaning the glass ceramic surface

Risk of damage from pointed ob­jects!
Do not clean the area between the glass ceramic surface and the frame or the frame and the worktop with sharp, pointed objects.
Not all soiling and residues can be removed using a solution of wash­ing-up liquid.
An invisible film can develop that can lead to discolouration of the ceramic glass. This discolouration cannot be removed.
Clean the glass ceramic surface reg­ularly with a suitable ceramic hob cleaning agent.
Remove any coarse soiling with a
damp cloth and more stubborn soil­ing with a glass scraper.
Spots caused by limescale, water
and aluminium residues (spots with a metallic appearance) can be removed using Miele's ceramic and stainless steel hob cleaner.
Danger of burning.
Wear oven gloves when removing residues of sugar, plastic or alu­minium foil from a hot hob with a glass scraper.
Should any sugar, plastic or alu-
minium foil spill or fall onto a hot
cooking zone while it is in use, first switch off the appliance.
Then carefully scrape off these
residues immediately whilst they are still hot, using a shielded scraper blade.
Afterwards, clean the glass ceramic
surface in its cooled state, as de­scribed above.
Then clean the ceramic glass surface
with the Miele ceramic and stainless steel hob cleaner (see "Optional ac­cessories") or with a proprietary ceramic glass cleaner applied with a paper towel or a clean cloth. Do not apply the cleaner while the hob is still hot, as this can result in marking. Please follow the cleaning agent manufacturer's instructions.
Finally wipe the hob with a damp
cloth and polish with a soft, dry cloth.
Residues can burn onto the hob the next time it is used and cause damage to the ceramic surface. Ensure that all cleaning agent residues are removed.
40

Problem solving guide

Many malfunctions and faults that can occur in daily operation can be easily remedied. Time and money will be saved because a service call will not be needed.
The following guide may help you to find the reason for a malfunction or a fault, and to correct it.
Problem Cause and remedy
The hob or cooking zones cannot be switched on.
A smell and vapours are given off when the new appliance is being used.
The symbol flashes al­ternately with the power level selected or in the display for one of the cooking zones.
After the hob has been switched on  appears in the timer display for a few seconds.
There is no power to the hob. Check if the mains fuse has tripped. If it has, con-
tact a qualified electrician or Miele (minimum fuse rating - see data plate).
There may be a technical fault. Disconnect the appliance from the electricity sup-
ply for approx. 1 minute. To do this: – switch off at the isolator, or – disconnect the mains fuse.
If, after resetting the trip switch in the mains fuse
box and switching the appliance back on, the ap­pliance will still not heat up, contact a qualified electrician or Miele.
The metal components have a protective coating. When the appliance is used for the first time, this causes a smell and possibly also vapour. The material from which the induction coils are made also gives off a smell in the first few hours of operation. This smell will be less noticeable with each subsequent use be­fore dissipating completely. The smell and any vapour given off do not indicate a faulty connection or appli­ance and they are not hazardous to health.
There is no pan on the cooking zone, or the pan is un­suitable.
Use a suitable pan (see "Pans").
The system lock or safety lock is activated. Deactivate the system lock or safety lock (see
"System lock / Safety lock").
41
Problem solving guide
Problem Cause and remedy
After the hob has been switched on  appears in the timer display for a few seconds. The cook­ing zones do not heat up.
A cooking zone switches off automatic­ally.
The Booster has deac­tivated early automatic­ally.
The cooking zone is not working in the usual way on the power set­ting selected.
Power level 9 is auto­matically reduced if you select power level 9 on two linked cooking zones at the same time.
The food in the pan does not heat up when the Auto heat-up func­tion is switched on.
An operating noise can be heard after the appli­ance has been switched off.
One or more residual heat indicators are flashing.
The hob is in demonstration mode.
Touch the and sensors at the same time until
 goes out.
It has been operated for too long. You can use the cooking zone again by switching
it back on (see "Safety switch-off").
The overheating protection mechanism has been ac­tivated.
See "Overheating protection".
The overheating protection mechanism has been ac­tivated.
See "Overheating protection".
Operating both zones at power level 9 would exceed the permitted maximum power for the two zones.
Use a different cooking zone.
A large amount of food is being heated up. Start cooking at the highest power level and then
turn down to a lower one manually later on.
The pan is not conducting heat properly. Use a different pot or pan which conducts heat
properly.
The fan will continue running until the appliance has cooled down. It will then switch itself off automatic­ally.
There was an interruption to the power supply during operation or when residual heat was present.
42
Problem Cause and remedy
or  and numbers are flashing in the cooking zone displays.

The overheating protection mechanism has been ac­tivated.
See "Overheating protection". 
One or more of the sensors are covered, e.g. by finger contact, food boiling over or an object.
Remove the obstruction and/or clean the hob. or  and other numbers
There is an electronic unit fault. Interrupt the power supply to the hob for approx. 1
minute.
If the problem persists after power has been re-
stored, please contact Miele.
Problem solving guide
43

Optional accessories

Miele offer a comprehensive range of useful accessories as well as cleaning and conditioning products for your Miele appliances.
These products can be ordered through the Miele Webshop.
These can also be ordered from Miele (see end of this booklet for contact de­tails) or from your Miele dealer.

Pans

Miele offer a wide range of pans which are perfect for Miele hobs. Please refer to the Miele website for more details on individual products.
– Pans in various sizes
– Frying pan with lid
– Anti-stick pans
– Wok
– Gourmet oven dishes

Cleaning and care products

Ceramic and stainless steel hob cleaner 250 ml

Removes heavy soiling, limescale de­posits and aluminium residues

Microfibre cloth

Removes finger marks and light soiling
44

Safety instructions for installation

The appliance must only be installed and connected to the electricity supply
by a suitably qualified and competent person in strict accordance with current national and local safety regulations.
Fit the wall units and cooker hood before fitting the hob to avoid damaging the hob.
The veneer or laminate coatings of worktops (or adjacent kitchen
units) must be treated with 100°C heat-resistant adhesive which will not dissolve or distort. Any backmoulds must be of heat-resistant material.
The hob must not be installed over a fridge, fridge-freezer, freezer,
dishwasher, washing machine, washer-dryer or tumble dryer.
This hob must not be installed above ovens or cookers unless
these have a built-in cooling down fan.
After installation, ensure that nothing can come into contact with
the connection cable and that it is without hindrance.
The electrical cable may not come into contact with any moving
kitchen component (e.g. a drawer) or be subject to mechanical ob­struction which could damage it.
Observe carefully the safety clearances listed on the following
pages.
All dimensions are given in mm.
45

Safety distances

Safety distance above the hob

A minimum safety distance must be maintained between the appliance and the cooker hood above it. See the cooker hood manufacturer's operating and installation instructions for details. If the manufacturer's instructions are not available for the cooker hood or if any flammable objects (e.g. utensil rails, wall units etc) are installed above the hob a minimum safety distance of at least 760mm must be maintained between them and the appliance below.
When two or more appliances which have different safety distances are installed together below a cooker hood, you should observe the greatest safety distance.
46

Safety distances to the sides and back of the hob

Ideally the hob should be installed with plenty of space on either side. There may be a wall at the rear or a tall unit or wall on one side (right or left) (see illus­trations).
Safety distances
Minimum distance between the back of the worktop cut-out and the rear edge of the worktop: 50mm
Minimum distance between the worktop cut-out and a wall or tall unit to the right of it: 50mm.
Minimum distance between the worktop cut-out and a wall or tall unit to the left of it: 50mm.
Not allowed
Recommended
Not recommended
Not recommended
47
Safety distances
Minimum safety distances un­derneath the hob
To ensure sufficient ventilation to the hob, a certain gap must be left between the underside of the hob and any oven, interim shelf or drawer.
The minimum gap between the under­side of the hob and
– the top of an oven is 15mm.
– the top of an interim shelf is 15mm.
– the base of a drawer is 75mm.

Interim shelf

It is not necessary to fit an interim shelf underneath the hob but one may be fit­ted if you wish.
Leave a gap of 10mm at the back of the shelf to accommodate the cable. We recommend a gap at the front of the shelf of 20mm to ensure good ventila­tion.
48
Safety distances

Safety distance when installing the appliance near a wall with additional niche cladding

A minimum safety distance must be maintained between the worktop cut-out and any niche cladding to protect it from heat damage.
If the niche cladding is made from a combustible material (e.g. wood) a minimum safety distance of 50 mm must be maintained between the cut-out and the cladding.
If the niche cladding is made from a non-combustible material (e.g. metal, natural stone, ceramic tiles) the minimum safety distance between the cut-out and the cladding will be 50 mm less the thickness of the cladding. Example: 15 mm niche cladding 50mm - 15mm = minimum safety distance of 35mm
Flush-fitted hobs Hob with frame or bevelled edge
a
Masonry
b
Niche cladding dimension x = thickness of the niche cladding material
c
Worktop
d
Worktop cut-out
e
Minimum distance to
combustible materials 50mm non-combustible materials 50mm - dimension x
49

Installation notes

Flush fit hobs are only suitable for in­stallation in natural stone (granite, marble), tiled or solid wood worktops. Certain models are suitable for build­ing into glass worktops - please see advice under "Building-in dimen­sions". When using a worktop made from any other material, please check first with the worktop manufacturer that it is suitable for installing a flush fit hob.
The internal width of the base unit must be at least as wide as the in­ternal cut-out width for the hob (see "Building-in dimensions"). This is to ensure that the casing can be easily removed for maintenance. If the un­derside of the hob is not freely ac­cessible after installation, any sealant used to plug the gaps around the ap­pliance must be removed to enable the hob to be lifted out of the cut-out should this be necessary.
The hob can be installed
– in a suitable cut-out in a natural stone
worktop.
– in a suitable cut-out in a tiled or solid
wood worktop or a glass worktop with a wooden support frame. The frame must be provided on site, and is not supplied with the appliance.
50

Building-in dimensions

a
Front
b
Casing depth
c
Clearance for ventilation
The mains connection cable (1440 mm long) is supplied separately with the hob.
Please observe the detailed diagrams for cut-out dimensions in natural stone worktops.
d
Stepped cut-out for natural stone worktops
e
Mains connection box
51

Installation

Natural stone worktops

a
Worktop
b
Hob
c
Gap
As the ceramic glass and the worktop cut-out have a certain dimensional tol­erance, the size of gap can vary (min. 1 mm).

Solid wood, tiled and glass worktops

a
Worktop
b
Hob
c
Gap
d
Wooden frame 10 mm (to be provided on site)
As the ceramic glass and the worktop cut-out have a certain dimensional tol­erance, the size of gap can vary (min. 1 mm).
a
Stepped cut-out
52

Prepare the worktop

Create the worktop cut-out as shown
in the hob and inset diagrams. Re­member to maintain the minimum safety distances (see "Safety dis­tances").
Solid wood, tiled and glass worktops:
Fix a wooden frame 7mm below the top edge of the worktop (see dia­gram).

Connect the mains connection cable to the appliance

The mains connection cable must only be connected by a suitably qualified and competent person.
Follow the instructions in the wiring
diagram (see "Electrical connection ­Wiring diagram").
Installation

Install the hob

Feed the mains connection cable
down through the cut-out.
Centre the hob in the cut-out.Connect the hob to the mains.Check that the hob works.Seal the remaining gap with a silic-
one sealant that is heat-resistant to at least 160°C.
Unsuitable sealant can damage nat­ural stone.
For natural stone worktops and nat­ural stone tiles, only use silicone sealant that is specially formulated for natural stone.
Please follow the manufacturer's in­structions.
53

Electrical connection

Danger of injury.
Miele cannot be held liable for unau­thorised installation, maintenance and repair work as this can be dan­gerous to users. Miele cannot be held liable for dam­age or injury caused by incorrect in­stallation, maintenance or repair work, or by an inadequate or faulty earthing system (e.g. electric shock).
This hob must be connected to the mains electrical supply by a suitably qualified and competent person, in accordance with current local and national safety regulations (BS 7671 in the UK).
After installation ensure that all elec­trical components are shielded and cannot be accessed by users.

Connection

AC 230 V, 50 Hz
The connection data is quoted on the dataplate. It must match the household supply.
Please see wiring diagram for connec­tion. (N.B. This appliance is supplied single phase only in the UK / AUS / NZ).

Residual current device

For extra safety, it is advisable to pro­tect the appliance with a suitable resid­ual current device (RCD) with a trip range of 30mA.
WARNING THIS APPLIANCE MUST BE EARTHED

Separators

The appliance must be able to be dis­connected from the mains on all poles by disconnecting devices. When switched off there must be an all-pole contact gap of at least 3 mm in the isol­ator switch. Disconnecting devices in­clude overcurrent protection and circuit breakers.
54
Electrical connection

Disconnecting from the mains

Danger of electric shock.
After disconnection, ensure the ap­pliance cannot be switched back on by mistake.
To disconnect the appliance from the mains power supply, do one of the fol­lowing depending on installation:

Safety fuses

Completely remove fuses

Automatic circuit breakers

Press the (red) button until the middle
(black) button springs out.

Built-in circuit breakers

Circuit breakers, type B or C: switch
the on-off switch from 1 (on) to 0 (off).

Residual current device (RCD)

Switch the main switch from 1 (on) to
0 (off) or press the test button.

Mains connection cable

The hob must be connected to the elec­trical supply with a special connection cable, type H 05 V2 V2-F (cross section 3 core cable 2.5mm² / 5 core cable
1.5mm², PVC insulated) in accordance with the wiring diagram.
Please see wiring diagram for connec­tion. (N.B. This appliance is supplied single phase only in the UK / AUS / NZ).
See the data plate on the hob for the correct voltage and frequency.

Replacing the mains cable

Danger of electric shock.
The mains connection cable must be replaced by a suitably qualified and competent person in accordance with current local and national safety regulations. (e.g. BS 7671 in the UK).
The earth lead must be connected to the point marked .
If the mains cable needs to be replaced it must be replaced with a special con­nection cable, type H05V2 V2-F (cross section 3 core cable2.5mm² / 5 core cable1.5mm², PVC insulated), avail­able from Miele.
The connection data is quoted on the data plate.
55
Electrical connection

Wiring diagram

56

After sales service

Contact in case of malfunction

In the event of any faults which you cannot remedy yourself, please contact your Miele Dealer or Miele Service.
Contact information for Miele Service can be found at the end of this document.
Please note that telephone calls may be monitored and recorded for training pur­poses and that a call-out charge will be applied to service visits where the problem could have been resolved as described in this booklet.
Please quote the model and serial number of your appliance when contacting Miele. This information can be found on the data plate.

Data plate

Stick the extra data plate supplied with the appliance here. Make sure that the model number matches the one specified on the back cover of this document.

Warranty

The appliance warranty is valid for 2 years from date of purchase. In the UK, you must activate your cover by calling 0330 160 6640 or registering online at www.miele.co.uk.
For further information on country specific warranty terms and conditions, please refer to your warranty booklet or contact Miele Customer Service.
57

Product data sheets

The following data sheets apply to the models described in this operating instruc­tion manual.

Information about domestic electric hobs

In acc. with regulation (EU) No. 66/2014
MIELE Model name / identifier KM 6356 FL.BDG.
Number of cooking zones and/or areas 4 For circular cooking zones: diameter of useful sur-
face area/cooking zone For non-circular electric cooking zones or areas: length and width of useful surface area per electric cooking zone or area L/W
Energy consumption per cooking zone or area cal­culated per kg (EC
electric cooking
)
1. = Ø 300 mm
2. = Ø 100-160 mm
3. = 230x390 mm
4. =
5. =
6. =
2. = 175,4 Wh/kg
3. = 190,6 Wh/kg
Energy consumption for the hob calculated per kg (EC
electric hob
)
183,0 Wh/kg
58
United Kingdom
Miele Co. Ltd. Fairacres, Marcham Road Abingdon, Oxon, OX14 1TW Customer Contact Centre Tel: 0330 160 6600 E-mail: mielecare@miele.co.uk Internet: www.miele.co.uk
Australia
Miele Australia Pty. Ltd. ACN 005 635 398 ABN 96 005 635 398 1 Gilbert Park Drive, Knoxfield, VIC 3180 Tel: 1300 464 353 Internet: www.miele.com.au
Miele (Shanghai) Trading Ltd. 1-3 Floor, No. 82 Shi Men Yi Road Jing' an District 200040 Shanghai, PRC Tel: +86 21 6157 3500, Fax: +86 21 6157 3511 E-mail: info@miele.cn, Internet: www.miele.cn
China
41/F - 4101, Manhattan Place 23 Wang Tai Road Kowloon Bay, Hong Kong Tel: (852) 2610 1025, Fax: (852) 3579 1404 Email: customerservices@miele.com.hk Website: www.miele.hk
Miele (Hong Kong) Limited
Miele India Pvt. Ltd. Ground Floor, Copia Corporate Suites Plot No. 9, Jasola, New Delhi - 110025 Tel: 011-46 900 000, Fax: 011-46 900 001 E-mail: customercare@miele.in, Internet: www.miele.in
India
Miele Ireland Ltd. 2024 Bianconi Avenue Citywest Business Campus, Dublin 24 Tel: (01) 461 07 10, Fax: (01) 461 07 97 E-Mail: info@miele.ie, Internet: www.miele.ie
Ireland
Malaysia
Miele Sdn Bhd Suite 12-2, Level 12 Menara Sapura Kencana Petroleum Solaris Dutamas No. 1, Jalan Dutamas 1 50480 Kuala Lumpur, Malaysia Phone: +603-6209-0288 Fax: +603-6205-3768
Miele New Zealand Limited IRD 98 463 631 Level 2, 10 College Hill Freemans Bay, Auckland 1011, NZ Tel: 0800 464 353 Internet: www.miele.co.nz
New Zealand
Miele Pte. Ltd. 163 Penang Road # 04 - 03 Winsland House II Singapore 238463 Tel: +65 6735 1191, Fax: +65 6735 1161 E-Mail: info@miele.com.sg Internet: www.miele.sg
Singapore
Miele (Pty) Ltd 63 Peter Place, Bryanston 2194 P.O. Box 69434, Bryanston 2021 Tel: (011) 875 9000, Fax: (011) 875 9035 E-mail: info@miele.co.za Internet: www.miele.co.za
South Africa
Miele Appliances Ltd. Gold & Diamond Park Office No. 6-217, Sheikh Zayed Road P.O. Box 11 47 82 - Dubai Tel. +971 4 3044 999 Fax. +971 4 3418 852 800-MIELE (64353) E-Mail: info@miele.ae Website: www.miele.ae
United Arab Emirates
Carl-Miele-Straße 29, 33332 Gütersloh, Germany
Manufacturer:
Miele & Cie. KG
KM 6356
M.-Nr. 09 743 770 / 05en-GB
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
