Operating and Installation Instructions
Ceramic cooktops with induction
To avoid the risk of accidents or damage to the appliance it is
imperative that you read these instructions before
installing the appliance and using it for the first time
.
en-CA
M.-Nr. 10
718 780
Contents
Warnings and safety instructions ........................................................................ 4
Caring for the environment ................................................................................ 13
Overview............................................................................................................... 14
Cooktop................................................................................................................. 14
KM 6092 ........................................................................................................... 14
Control symbols .................................................................................................... 15
Cooktop display symbols...................................................................................... 15
Burner data............................................................................................................ 16
Using for the first time ........................................................................................ 17
Cleaning the cooktop for the first time.................................................................. 17
Turning on the cooktop for the first time ............................................................... 17
Induction .............................................................................................................. 18
How it works.......................................................................................................... 18
Noises.................................................................................................................... 19
Cookware .............................................................................................................. 20
Energy saving tips .............................................................................................. 21
Power setting ranges .......................................................................................... 22
Operation.............................................................................................................. 23
Cooking zone rotary controls ................................................................................ 23
Switching on.......................................................................................................... 23
Switching off.......................................................................................................... 23
Residual heat indicator.......................................................................................... 23
PowerFlex cooking zone ....................................................................................... 24
Auto Heat-up......................................................................................................... 25
Booster.................................................................................................................. 26
Keeping food warm ............................................................................................... 28
Setting the keep warm function .......................................................................28
Safety features..................................................................................................... 29
System lock........................................................................................................... 29
Safety shut-off....................................................................................................... 29
Overheat protection............................................................................................... 30
Cleaning and care ............................................................................................... 31
Problem solving guide .......................................................................................33
Optional accessories ..........................................................................................36
2
Contents
Safety instructions for installation..................................................................... 37
Safety clearances ................................................................................................ 38
Instructions for installation ................................................................................ 41
Installation dimensions....................................................................................... 42
KM 6092 ................................................................................................................ 42
Installation............................................................................................................ 43
Electrical connection ..........................................................................................44
After-sales service, data plate, warranty .......................................................... 46
3
Warnings and safety instructions
This appliance conforms to current safety requirements. However,
improper use can result in personal injury and damage to property.
To prevent accidents and damage to the cooktop, please read
these instructions carefully before using the cooktop for the first
time. They contain important notes on installation, safety, use and
maintenance.
Miele cannot be held liable for damage occurring as a result of
non-compliance with these instructions.
Keep these instructions in a safe place and pass them on to any
future owners.
4
Warnings and safety instructions
Intended use
This cooktop is intended for domestic use and use in other similar
environments.
This cooktop is not intended for outdoor use.
The cooktop is intended to prepare food and keep it warm in
domestic use only. Any other use may be hazardous.
Persons who are unable to safely operate the cooktop due to
limited physical, sensory or mental abilities or because they lack
experience or knowledge may only use the appliance if they are
supervised while doing so. These persons may only use the cooktop
without supervision if they have been shown how to use it in a safe
manner, and if they are able to recognize and understand the
potential risks of improper use.
5
Warnings and safety instructions
Safety with children
Children under 8 years of age must be kept away from the
cooktop unless they are constantly supervised.
Children ages 8 and up may only use the cooktop without
supervision if they have been shown how to use it in a safe manner,
and if they are able to recognize and understand the potential risks
of improper use.
Children must not be allowed to clean the cooktop without
supervision.
Be sure to supervise any children in the vicinity of the cooktop,
and do not let them play with it.
The cooktop gets hot when in use and remains hot for some time
after being switched off. Keep children away from the cooktop until it
has cooled down and is no longer a burn hazard.
Burn hazard.
Keep the spaces above and behind the cooktop clear of any items
that could draw the attention of children. Otherwise, they can be
tempted into climbing onto the appliance.
Risk of burning or scalding.
Turn all handles away from the front of the cooktop so that children
cannot pull pots and pans down and burn themselves.
Risk of suffocation. Children may be able to wrap themselves in
packaging material or pull it over their heads with the risk of
suffocation. Keep children away from all packaging materials.
Activate the system lock to ensure that children cannot turn on the
appliance inadvertently.
6
Warnings and safety instructions
Technical safety
Installation, maintenance and repair work should only be
performed by a Miele authorized service technician. Installation,
maintenance and repair work by unqualified persons can cause
considerable danger to users.
A damaged cooktop can be dangerous. Always check for visible
signs of damage. Never use a damaged appliance.
Reliable and safe operation of the cooktop can only be
guaranteed if it is connected to the public power supply.
The electrical safety of this cooktop can only be guaranteed when
it is properly grounded. Compliance with this essential safety
requirement is absolutely necessary. If in any doubt, please have the
building's electrical system checked by a qualified electrician.
To avoid damaging the cooktop, make sure that the connection
data (voltage and frequency) on the data plate correspond to the
building's power supply before connecting the appliance.
When in doubt, consult a qualified electrician.
The cooktop may only be combined with the ovens specified by
Miele. The manufacturer cannot guarantee trouble-free operation if
the cooktop is used in combination with any other appliances. Doing
so will void the warranty.
Do not connect the appliance to the electrical supply with a power
bar or extension cord. These are a fire hazard and do not guarantee
the required safety of the appliance.
For safety reasons, the cooktop may only be used when it has
been fully installed.
This cooktop must not be used in non-stationary locations (e.g. on
a ship).
7
Warnings and safety instructions
Any contact with live connections or tampering with the electrical
or mechanical components of the cooktop will endanger your safety
and may lead to cooktop malfunctions.
Do not open the casing of the cooktop under any circumstances.
Any repairs not performed by a Miele authorized service
technician will void the warranty.
Miele can only guarantee the safety of the appliance if genuine
Miele spare parts are used. Defective components must only be
replaced by genuine Miele spare parts.
The cooktop must be connected to the oven by a qualified
electrician (see "Electrical connection").
During installation, maintenance, and repair work, the cooktop
must be completely disconnected from the household electricity
supply. It is only completely isolated from the electricity supply
when:
– The main circuit breaker has been tripped, or
– The plug fuses have been fully unscrewed (where applicable).
Risk of electric shock.
If the ceramic surface of the cooktop is defective or chipped,
cracked or broken in any way, immediately turn the cooktop off and
do not continue to use it. Disconnect the cooktop from the power
supply and contact Miele.
If the cooktop is installed behind a cabinet door, do not close the
door while the cooktop is in operation. Heat and moisture can build
up behind the closed door and cause damage to the cooktop,
cabinetry and flooring. Do not close the door until the cooktop has
completely cooled down.
8
Warnings and safety instructions
Proper use
The cooktop gets hot when in use and remains hot for a while
after being turned off. A burn hazard is present until the residual heat
indicators go out.
Oil and fat can catch fire if overheated. Never leave the cooktop
unattended when cooking with oil and fat. If the oil or fat catches
fire, do not attempt to put the flames out with water.
Turn off the cooktop and smother the flames using a lid or a suitable
fire blanket.
The flames could set the grease filters of a ventilation hood on fire.
Do not flambé under a hood.
Spray canisters, aerosols and other flammable substances can
ignite when heated. Therefore, do not store such items or
substances in a drawer under the cooktop. Any cutlery inserts must
be heat-resistant.
Never heat empty cookware.
Do not heat or can food in closed containers, such as tins or
sealed jars, on the cooktop, as pressure will build up in the container
and cause it to explode.
If the cooktop is covered, there is a risk that the material of the
cover will ignite, explode or melt if the range is still hot or if it is
turned on inadvertently. Never cover the appliance with a cover,
cloth or protective foil.
If the cooktop is on or accidentally turned on, or if it is still hot,
metal objects on the cooktop can heat up. Other items may melt or
catch fire. Damp lids can become attached to the cooktop by
suction. Do not store items on the cooktop. Always turn the burners
off after use.
9
Warnings and safety instructions
You can burn yourself on a hot cooktop. When cooking on the
cooktop, protect your hands by using heat-resistant pot holders or
oven mitts. Only use dry pot holders and oven mitts. Wet or damp
textiles conduct heat more effectively and produce steam, which
poses a burn hazard.
When using an electrical appliance, e.g. a hand mixer, near the
cooktop, make sure that the power cable does not come into
contact with the hot cooktop. The cable's insulation could become
damaged.
Grains of salt, sugar and sand (e.g. from cleaning vegetables) can
cause scratches if they get onto pan bottoms. Make sure that the
ceramic surface and pan bottom are clean before placing any pans
on the cooktop.
Even light objects (such as a salt shaker) can cause damage to
the ceramic cooktop in certain circumstances. Do not drop anything
on the ceramic surface.
Hot pans on the display can cause damage to the electronics
underneath. Do not place hot pans on the display or on the area
around the display.
Do not allow solid or liquid sugar, or pieces of plastic or aluminum
foil, to get on the cooktop when it is hot, as they can damage the
ceramic surface when it cools down. If this should occur, turn off the
appliance immediately and scrape off all the sugar, plastic or
aluminum residues while still hot using a scraper blade. Wear oven
mitts when doing so. Allow the burners to cool down and clean them
with a suitable ceramic cleaning agent.
Pans that boil dry can damage the ceramic surface. Never leave
the cooktop unattended during use.
Pots and pans with rough bottoms can scratch the ceramic
surface. Only use pots and pans that are smooth on the bottom.
10
Warnings and safety instructions
Lift pans into position on the cooktop. Sliding them into place can
cause scuff marks and scratches.
Because induction heating works so quickly, the temperature of
the cookware bottom can quickly reach the ignition point of oils and
fats. Never leave the cooktop unattended when it is on!
Do not heat oils and fats for longer than one minute, and never
use the booster.
For people who have a heart pacemaker: Please note that an
electromagnetic field is created in the area immediately surrounding
the cooktop. It is very unlikely to affect a pacemaker. However, if in
any doubt, consult the manufacturer of the pacemaker or your
doctor.
Objects affected by electromagnetic fields, for instance, credit
cards, CDs and calculators, should be kept away from the cooktop
when it is on.
Do not use two pans on a cooking zone, a casserole cooking zone
or a PowerFlex zone at the same time.
If the cookware only partially covers the cooking or roasting zone,
the handle could become very hot.
Make sure to place the cookware in the middle of the cooking or
casserole cooking zone!
11
Warnings and safety instructions
Cleaning and care
Do not use a steam cleaner to clean the cooktop.
The steam could reach electrical components and cause a short
circuit.
If the cooktop is built in over a self-cleaning oven, the cooktop
should not be used while the self-cleaning process is being carried
out, as this could trigger the overheating protection mechanism on
the cooktop (see relevant section).
12
Caring for the environment
Disposal of the packaging material
The cardboard box and packaging
materials protect the appliance during
shipping. They have been designed to
be biodegradable and recyclable.
Recycling the packaging reduces the
use of raw materials in the
manufacturing process and also
reduces the amount of waste in landfill
sites. You can return the packaging to
your Miele dealer.
Disposing of your old appliance
Old electrical and electronic equipment
often still contain valuable materials.
However, they may also include harmful
substances that were essential for
proper functioning and safe use.
Improperly disposing of these items in
your household waste can be harmful to
your health and the environment.
Therefore, please do not dispose of
your old appliance in your regular
household waste.
Instead, use your local community
waste collection and recycling centre
for electric and electronic appliances.
Contact your dealer for more
information.
Ensure that your old appliance does not
pose a danger to children while being
stored for disposal.
13
Overview
Cooktop
KM 6092
a
Cooking zone with Booster
b
Cooking zone with Booster
c
PowerFlex cooking zone with TwinBooster
d
PowerFlex cooking zone with TwinBooster
cd
can be combined to form PowerFlex cooking zone
e
Display with cooking zone indicators
14
Overview
Control symbols
Symbol Explanation
0 Cooking zone off
Switching on the keep warm function (depending on model)
Switching on the keep warm function or PowerFlex cooking
area (depending on model)
B I Switching on the Booster/TwinBooster
Incremental scale (depending on model)
or Activating Auto heat-up (depending on model)
Cooktop display symbols
Symbol Explanation
Keep warm setting
to Power level
Auto Heat-up
Level 1 TwinBooster/WaterBoost
Booster/Level 2 TwinBooster/WaterBoost
No or unsuitable cookware (see "Induction")
Residual heat
The system lock has been activated
Demonstration mode activated
Demo mode deactivated
15
Overview
Burner data
Cooking zone KM 6092
Øin cm* Power in watts at 230 V**
14–20 normal
Booster
10–16 normal
Booster
15–23 normal
TwinBooster, Level 1
TwinBooster, Level 2
15–23 normal
TwinBooster, Level 1
TwinBooster, Level 2
+ 22–23 /
15x23–23x39
* Within the specified range, pots with any base diameter can be used.
** The specified power can vary depending on the size and the material of the pots and
pans.
normal
TwinBooster, Level 1
TwinBooster, Level 2
Total 7300
1850
3000
1400
2200
2100
3000
3650
2100
3000
3650
3400
4800
7300
16
Using for the first time
Please affix the extra appliance data
plate supplied with this
documentation in the space provided
in the "After-sales service, data plate,
warranty" section of this manual.
Remove any protective foil and
stickers from the cooktop.
Cleaning the cooktop for the first time
Before using it for the first time, wipe
down the cooktop with a damp cloth
and then wipe it dry.
Turning on the cooktop for the first time
Metal components are protected by a
conditioning agent. Smells and vapour
may occur when the appliance is used
for the first time. The heating of the
induction coils also causes odours in
the first few hours of operation. With
each subsequent use, the odour is
reduced until it disappears entirely.
The smell and any vapors that may
occur do not indicate a faulty
connection or defective appliance and
are not harmful to your health.
Please note that the heating-up time
for induction cooktops is very much
shorter than for conventional
cooktops.
17
Induction
How it works
An induction coil is located under each
cooking zone. When a cooking zone is
switched on, this coil creates a
magnetic field which impacts directly
on the base of the pan and heats it up.
The cooking zone itself is heated up
indirectly by the heat given off by the
pan.
An induction cooking zone only works
when a ferromagnetic pan is placed on
it (see "Cookware"). The induction
cooking zone automatically recognizes
the size of the pan.
The symbol is shown in the cooking
zone display and blinks alternately with
the preset power level, if
– the cooking zone has been switched
on without a pan in place, if the pan
is unsuitable (non-magnetic base),
– if the diameter of the base of the pan
is too small,
When the appliance is switched
on either deliberately or by mistake,
or when there is residual heat
present, there is the risk of heating
up any metal items placed on the
cooktop.
Burn hazard!
Do not use the cooktop as a resting
place for items. Switch the cooking
zones off after use by turning the
control to "0".
– or if the pan is taken off the cooking
zone when it is switched on.
If a suitable pan is placed on the
cooking zone within 3minutes, the
will go out and you can continue as
normal.
If no cookware or if unsuitable
cookware is used, the cooking zone will
automatically turn off after 3 minutes.
18
Noises
When you use an induction cooking
zone, the following noises may occur,
depending on the type and shape of the
cookware bottom:
On the higher power settings, it might
buzz. This will decrease or cease
altogether when the power setting is
reduced.
Cookware with bottoms made of
different materials (e.g. sandwich
bottoms) may produce a crackling
noise.
Whistling may occur if connected
cooking zones (see "Booster") are
simultaneously in use and cookware
with bottoms made of different
materials (e.g. in a sandwiched base)
are on them.
The electronics may produce a clicking
sound, especially at lower power
settings.
Induction
You might hear a whirring sound when
the cooling fan turns on. It turns on to
protect the electronics when the
cooktop is being used intensively. The
fan may continue to run after the
appliance has been turned off.
19
Induction
Cookware
Suitable cookware is made of:
– Stainless steel with a magnetic
bottom,
– enamel-coated steel,
– cast iron
Unsuitable cookware is made of:
– Stainless steel pans without a
magnetic bottom,
– Aluminium or copper,
– Glass, ceramics, earthenware,
stoneware.
To test whether a pot or pan is suitable
for use on an induction cooktop, hold a
magnet to the bottom of the pan. If the
magnet sticks, the pan is suitable.
If an unsuitable pan is used, the
symbol will flash alternately with the
power level set.
The composition of the pan bottom can
affect the evenness of the cooking
results (e.g., when making pancakes).
– Lift pans into position on the
cooktop. Sliding them into place can
cause scuff marks and scratches.
– The maximum diameter indicated by
manufacturers will often refer to the
diameter of the top rim of the pot or
pan. The diameter of the base
(generally smaller) is more important.
– To make optimum use of the burners,
choose pans with diameters larger
than the innermost markings but
smaller than the outermost markings
(see "Burner data"). If the diameter of
the pan is smaller than the innermost
marking, the pan will not be
recognized and will flash alternately
with the power level set.
– Pots and pans with rough bottoms
can scratch the ceramic surface.
Only use pots and pans that are
smooth on the bottom.
20
– Use a lid whenever possible to
minimize heat loss.
– For small quantities, select a small
pan. A small pan on a small burner
uses less energy than a large, only
partially filled pan on a large burner.
– Cook with as little water as possible.
– Once food has come to the boil or
the pan is hot for frying, reduce the
heat to a lower power setting.
– Use a pressure cooker to reduce the
cooking time.
Energy saving tips
21
Power setting ranges
Setting range
Keeping food warm h
Melting butter
Dissolving gelatine
Melting chocolate
Making porridge 2
Warming small quantities of liquid
Cooking rice
Thawing frozen vegetables (blocks) 3
Making oatmeal 3
Warming liquid and semi-solid foods
Making omelettes or lightly frying eggs
Steaming fruit
Cooking dumplings 4
Steaming vegetables or fish 5
Thawing and heating frozen food 5
Gently frying eggs (without overheating the fat) 6
Bringing large quantities of food to a boil, e.g.,
casseroles.Thickening custard and sauces, e.g., hollandaise
Gently frying fish, cutlets, sausages, fried eggs, etc. (without
overheating the fat)
Frying pancakes, potato fritters etc. 7
Braising for stews 8
Boiling large quantities of water
Bringing food to a boil
1-2
3
4
6-7
6-7
9
These settings should only be taken as a guide. The power of the induction coils will vary
depending on the size and material of the pan. For this reason, it is possible that the
settings will need to be adjusted slightly to suit your pans. As you use the cooktop, you will
get to know which settings suit your pans best. When using new pans that you are not
familiar with, set the power level below the one specified.
22
Operation
Fire hazard!
Do not leave the cooktop unattended
during operation!
Please note that the heating-up time
for induction cooktops is shorter
than for conventional cooktops.
Cooking zone rotary controls
The cooking zone rotary controls must
not be turned past BI to or or to
0.
Switching on
Turn the cooking zone rotary control
clockwise until the setting you want
appears in the display.
Switching off
Turn the rotary control anti-clockwise
to 0.
The power setting will go out in the
display.
Residual heat indicator
When a cooking zone is hot, the
residual heat indicator will light up after
deactivation.
The lines of the residual heat indicator
go out one after another as the cooking
zone cools down. The last horizontal
line only goes out when the cooking
zone is safe to touch.
23
Operation
PowerFlex cooking zone
(depending on model, see "Overview Cooktop").
The PowerFlex cooking zones can be
combined to form a PowerFlex cooking
area (see "Overview - Cooktop").
Settings for the cooking area are
controlled by the front PowerFlex
cooking zone.
Switching on
Turn the rotary control for the rear
cooking zone clockwise to.
will light up in the display for the rear
cooking zone.
Turn the rotary control for the front
cooking zone clockwise until the
power level you require lights up in
the cooking zone display.
If the front cooking zone already has a
power level set when the cooking area
is activated, you need to turn the
rotary control to "0" before you can
set the power level for the PowerFlex
cooking area.
Switching off
Turn both rotary controls anti-
clockwise to 0.
24
Operation
Auto Heat-up
When Auto Heat-up has been activated,
the cooking zone turns on automatically
at the highest level and then switches
to the previously selected continued
cooking level. The heat-up time
depends on which continued cooking
level has been chosen (see chart).
Activating
Turn the rotary control anti-clockwise
to or (depending on model) and
hold until flashes once in the
cooking zone display.
Now turn the rotary control clockwise
until the continued cooking setting
lights up in the cooking zone display.
The continued cooking setting selected
will flash alternating with during the
heat-up time (see chart).
When you change the continued
cooking level, you deactivate Auto
Heat-up.
Continued
cooking level
1 approx. 0 : 15
2 approx. 0 : 15
3 approx. 0 : 25
4 approx. 0 : 50
5 approx. 2 : 00
6 approx. 5 : 50
7 approx. 2 : 50
8 approx. 2 : 50
9 –
Auto Heat-up
time
[min : sec]
Deactivating
Select a different power level.
25
Operation
Booster
The cooking zones are equipped with a
one stage Booster, two stage
WaterBoost or TwinBooster (see
"Overview - Cooktop").
When activated, the power is boosted
for a maximum of 15 minutes so that
large quantities can be heated quickly,
e.g., water for cooking pasta.
The Booster function can only be used
on two cooking zones at the same time.
The cooking zone will automatically
revert to power level 9 at the end of the
Booster duration.
The cooking zones are connected in
pairs in order to provide sufficient
power for the Booster.
When the booster function is selected,
a proportion of energy is taken away
from the linked cooking zone and the
following happens within the pairs:
– auto heat-up is deactivated,
– the power level that is set will be
reduced,
– the connected cooking zone will be
turned off.
26
Operation
Activating the booster
Turn the rotary control clockwise
gently past the point of resistance to
BI and back to the point of
resistance.
will appear in the cooking zone
display.
TwinBooster level 1 activation
Turn the rotary control clockwise
gently past the point of resistance to
BI and back to the point of
resistance.
will appear in the cooking zone
display.
TwinBooster level 2 activation
Turn the rotary control clockwise
gently past the point of resistance to
BI and back to the point of
resistance.
Turn the rotary control again gently
past the point of resistance to BI and
back to the point of resistance.
Turning the Booster/TwinBooster off
Select a different power level.
The Booster symbol will go out.
will appear in the cooking zone
display.
27
Operation
Keeping food warm
The keep warm function is for keeping
food warm that has just been cooked,
i.e., food that is still hot. It is not for
reheating cold food.
The maximum holding time is 2 hours.
– Only use pans for keeping food
warm. Cover the pan with a lid.
– It is not necessary to stir the food
while it is being kept warm.
– Nutrients are lost when food is
cooked, and continue to diminish
when food is kept warm. The longer
the food is kept warm, the greater the
loss of nutrients. Try to ensure that
food is kept warm for as short a time
as possible.
Setting the keep warm function
Turn the rotary control clockwise to
or (depending on model).
will appear in the cooking zone
display.
28
Safety features
System lock
The system lock is deactivated if
there is a power outage.
The system lock can only be activated
if all the cooking zones are switched
off.
Your cooktop is equipped with a system
lock to prevent the cooking zones being
switched on inadvertently.
If a power level is selected when the
system lock is activated, appears in
the display for approx. 3 seconds.
Activating
Turn the rotary controls for both front
cooking zones anti-clockwise to the
point of resistance at the same time
and hold until appears.
Deactivating
Turn the rotary controls for both front
cooking zones anti-clockwise to the
point of resistance at the same time
and hold until goes out.
Safety shut-off
Safety shut-off with an overlong cooking time
The safety shut-off is triggered
automatically if a cooking zone is
heated for an unusually long period of
time. This time depends on the power
level selected. If it has been exceeded,
the cooking zone turns off and the
residual heat indicator appears. If you
turn the cooking zone on and off again,
it is ready for operation again.
29
Safety features
Overheat protection
All induction coils and the cooling
elements for the electronics are
equipped with an overheating
protection mechanism. To prevent the
induction coils and cooling elements
from overheating, the overheating
protection mechanism works on the
affected cooking zone or on the entire
cooktop in the following ways:
– any booster function in operation will
be turned off,
– the set power level will be reduced,
– one or more cooking zones will
switch off automatically.
Turn the rotary controls for all the
affected cooking zones to "0". The
affected cooking zones can only be
used again as usual once the induction
coils or cooling elements have cooled
down to a safe level.
Any of the following can trigger the
overheat protection:
– Heating empty cookware
– Fat or oil being heated on a high
power level.
– Insufficient ventilation of the
underside of the cooktop.
– A hot cooking zone being switched
on after an interruption to the power
supply.
If, despite elimination of the cause, the
overheat protection is triggered again,
contact Miele Service.
30
Cleaning and care
Burn hazard.
The burners must be turned off and
allowed to cool completely.
Risk of injury.
The steam from a steam cleaner can
reach electrical components and
cause a short circuit.
Do not use a steam cleaner to clean
the cooktop.
The use of unsuitable cleaning
agents can discolour or alter the
external surfaces of the cooktop.
The external surfaces of the cooktop
are susceptible to scratching.
Immediately remove any residues left
by cleaning agents.
Allow the CombiSet to cool down
before cleaning.
The cooktop should be cleaned after
each use.
Dry the cooktop after using water to
clean it. This helps prevent lime
deposits.
Unsuitable cleaning agents
To avoid damaging the surfaces of the
cooktop, do not use any of the
following when cleaning:
– Dishwashing liquid
– Cleaners containing soda, ammonia,
acids or chlorides
– Lime removers
– Stain or rust removers
– Abrasive cleaning agents, such as
powder or cream cleansers, pumice
stones
– Solvent-based cleaners
– Dishwasher cleaner
– Grill and oven sprays
– Glass cleaners
– Hard, abrasive brushes or sponges,
e.g. pot scourers, brushes or
sponges which have been previously
used with abrasive cleaning agents
– Magic erasers
31
Cleaning and care
Risk of damage from pointed
objects!
Do not use sharp, pointed objects to
clean the area between the glass
ceramic and the trim or between the
trim and the countertop.
Using dishwashing liquid to clean the
cooktop will not remove all soiling
and residues.
It forms an invisible coating which
will cause permanent discolouration
of the ceramic surface.
Clean the glass ceramic surface
regularly with a suitable ceramic
cooktop cleaning agent.
First, wipe away all coarse soiling
from the surface using a damp cloth.
Stubborn soiling may need to be
removed with a scraper blade.
Then, clean the glass ceramic surface
with the Miele ceramic and stainless
steel cleaner (see "Optional
accessories") or commercial glass
ceramic cleaner using a paper towel
or clean cloth. Do not put the cleaner
on a hot surface, as this may cause
spotting. Please follow the
manufacturer's instructions.
Spots from lime deposits, water, and
aluminum deposits (shiny metallic
spots) can be removed with a
ceramic and stainless steel cleaner.
Burn hazard!
Wear oven mitts when using a
scraper blade to remove sugar,
plastic or aluminum residues from a
hot cooktop.
Should any sugar, plastic or
aluminium foil spill or fall on to a hot
cooking zone while it is in use, first
switch off the appliance.
Then carefully scrape off all the sugar,
plastic or aluminium residues from
the hob whilst they are still hot using
a shielded scraper blade. Take good
care.
Afterwards, clean the glass ceramic
surface in its cooled state, as
described above.
Remove any cleaner residue with a
damp cloth and then dry the glass
ceramic surface.
Residues can burn onto the appliance
the next time it is used and cause
damage to the ceramic surface.
Ensure that all cleaning agent residues
are removed.
32
Problem solving guide
The following guide is intended to help you resolve problems that occur during
normal operation of the appliance.
If you are unable to identify or remedy the cause of the problem on your own,
please contact Miele Service (see back cover for details).
Risk of injury. Improperly performed installation, maintenance or repair work
can pose a serious danger to users of the appliance, for which Miele is not
responsible.
Installation, maintenance and repairs may only be carried out by Miele
authorized technicians.
Do not attempt to open the cooktop casing yourself.
Problem Possible cause and remedy
The burners do not heat
up.
There is a strange smell
or vapours when the
cooktop is being used
for the first time.
There is no power to the cooktop.
Check if the circuit breaker has tripped. Contact
an electrician or Miele Service (for the minimum
fuse rating, see data plate).
There may be a technical fault.
Turn the burner knob to 0.
Disconnect the appliance from the electric power
supply for approx. 1minute by:
– tripping the relevant circuit breaker or screwing
the fuse out completely, or
– tripping the ground fault circuit interrupter
(GFCI).
If, after resetting/replacing the fuse or the GFCI,
the appliance still will not turn on, contact a
qualified electrician or Miele Service.
Metal components are protected by a conditioning
agent. Smells and vapour may occur when the
appliance is used for the first time. The smell and any
vapours do not indicate a faulty connection or a
defective appliance and are not harmful to your
health. With each subsequent use, the odour is
reduced until it disappears completely. The smell and
any vapours do not indicate a faulty connection or a
defective appliance and are not harmful to your
health.
33
Problem solving guide
Problem Possible cause and remedy
In the burner display,
the symbol will flash
alternately with the
selected power setting
or .
After switching on a
cooking zone, appears
in the front left cooking
zone display and
appears in the front
right cooking zone
display for a few
seconds.
After switching on a
cooking zone,
appears in the front left
cooking zone display
and appears in the
front right cooking zone
display for a few
seconds.
The cooking zones do
not heat up.
A burner turns itself off
automatically.
The booster has
automatically turned off
early.
The burner is not
working in the usual
way with the set power
level.
Power setting 9 is
automatically reduced if
you select power
setting 9 on two linked
burners or extended
zones at the same time.
There is no or unsuitable cookware on the cooking
zone.
Use a suitable pan (see "Cookware").
The system lock has been activated.
You need to deactivate the system lock (see
"System lock").
Demonstration mode is activated.
Turn the rotary control for the front left cooking
zone anti-clockwise and hold.
Turn the rotary control for the front right cooking
zone twice briefly anti-clockwise and then turn
anti-clockwise and hold until appears in the
display.
A burner might have been operated for too long.
You can use the burner again by turning it back on
(see "Safety shut-off").
The overheat protection was triggered.
See "Overheat protection".
The overheat protection was triggered.
See "Overheat protection".
Operating both zones at power level 9 would exceed
the permitted maximum power for the cooktop.
Use another burner that is not linked.
34
Problem solving guide
Problem Possible cause and remedy
Auto Heat-up is turned
on, but the food does
not start cooking.
A noise can be heard
after the appliance is
turned off.
is flashing in the
display of one or
more cooking
zones.
The rotary control is not
at "0", a power level has
been set for the
cooking zone. The
cooking zone is not
heating up.
appears in the display
or flashes alternately
with .
flashes in the
display
alternating with
numbers.
Large amounts of food are being heated.
Start cooking at the highest power level, then
reduce the power level manually.
Pan is not conducting heat properly.
Use a different pan that is able to better conduct
heat on an induction cooktop.
The fan will continue running until the appliance has
cooled down. It will then turn itself off automatically.
The rotary control for the cooking zone has been
turned to the point of resistance clockwise or anticlockwise for longer than 30 seconds.
Turn the rotary control to 0. If the fault message
does not go out, there could be a technical fault.
Contact Miele Technical Service.
There was an interruption to the power supply during
operation.
The cooking zone was switched on more than 3
minutes ago without a suitable pan being placed on it.
The maximum operating time for the cooking zone
has been exceeded.
Turn the rotary control to 0.
The cooking zone can now be used again.
There is a fault with the electronics.
Interrupt the power supply to the cooktop for
approx.1minute. If the problem persists after
power is restored, please contact Miele Service.
35
Optional accessories
Miele offers a wide range of useful
accessories as well as cleaning and
conditioning products for your Miele
appliances.
These accessories can be ordered from
the Miele website.
These can be ordered online or from
your Miele dealer (see end of this
booklet for contact details).
Cookware/bakeware
Miele offers a wide range of pans that
are perfect for Miele cooktops. Please
refer to the Miele website for more
details on individual products.
– Pots in a range of sizes
– Saucepan with cover
– Non-stick coated pan
– Wok
– Fry pan
Cleaning and care products
Ceramic and stainless steel cleaner
250mL
Removes heavy soiling, lime scale, and
aluminum residues.
Microfibre cloth
Removes fingerprints and light soiling
36
Safety instructions for installation
Installation of the cooktop may only be performed by a qualified technician.
The cooktop may only be connected to the oven by a qualified electrician.
Install the upper cabinets and ventilation hood before installing the cooktop to
avoid damaging the appliance.
The veneer or laminate coatings of countertops must be treated
with 100°C heat-resistant adhesive which will not dissolve or
become deformed. Wall strips must also be heat-resistant.
The cooktop is fitted with a cooling fan. To guarantee sufficient
ventilation of the cooling fan, the worktop must be at least 29mm
thick.
Once the cooktop has been installed, the electrical cord must not
be subject to mechanical stress.
Observe carefully the safety clearances listed on the following
pages.
All dimensions are indicated in mm.
37
Safety clearances
Safety clearance above the cooktop
For a ventilation hood positioned above
the cooktop, always use the clearance
specified by the hood manufacturer. If
no specifications are available from the
hood manufacturer, or if flammable
materials (e.g. wall shelf) are installed
above the cooktop, the clearance must
be at least 760mm.
If there is more than one appliance
installed below the ventilation hood,
each with a different safety
clearance, the largest clearance must
be used.
38
Safety clearances to the sides and back of the cooktop
Ideally, the cooktop should be installed
with plenty of space on either side.
There may be a wall at the rear or a tall
cabinet or wall on one side (right or left)
(see illustrations).
Safety clearances
Minimum distance between the back
of the countertop cut-out and the rear
edge of the countertop:
50mm
Minimum distance on the right side
between the countertop cut-out and the
closest adjacent piece of furniture (e.g.
tall cabinet) or a room wall:
50mm
Minimum distance on the left side
between the countertop cut-out and the
closest adjacent piece of furniture (e.g.
tall cabinet) or a room wall:
50mm
Not permitted!
Highly recommended!
Not recommended!
Not recommended!
39
Safety clearances
Safety distance from the wall covering
If a wall covering is installed, a minimum safety distance must be maintained
between the countertop cut-out and the covering, since high temperatures can
damage these materials.
If the covering is made of a flammable material (such as wood), the minimum
distance between the countertop cut-out and the wall covering must be 50mm.
For coverings made of non-flammable materials (such as metal, natural stone,
ceramic tiles) the minimum safety distance between the countertop cut-out and
the wall covering is equal to 50mm minus the thickness of the covering.
For example: thickness of wall covering 15mm
50mm - 15mm = minimum distance of 35mm
Flush-mounted cooktops Cooktops with trim or bevelled
edges
a
Masonry
b
Wall covering dimension x = thickness of wall covering
c
Countertop
d
Countertop cut-out
e
Minimum distance to
flammable materials: 50mm
non-flammable materials: 50mm - dimension x
40
Instructions for installation
Seal between the cooktop and countertop
Do not use sealant between the
cooktop and the countertop. Doing
so could result in damage to the
cooktop or countertop if the cooktop
ever needs to be removed for
servicing.
The sealing strip under the top edge
of the appliance provides an
adequate seal with the countertop.
Tiled countertop
The grouting and the shaded area
under the cooktop frame must be
smooth and flat so that the frame will sit
evenly on the countertop and so that
the sealing strip under the top edge of
the appliance can provide an adequate
seal with the countertop.
41
Installation dimensions
KM 6092
a
Front
b
Installation height
42
Installation
Preparing the countertop
Create the countertop cut-out as
shown in the cooktop diagram.
Remember to maintain the minimum
safety distances (see "Safety
clearances").
Wooden countertop
Seal any cut surfaces on the wooden
countertop with a special varnish,
silicone rubber, or resin to prevent the
wood from swelling as a result of
moisture. The sealant must be
temperature-resistant.
Make sure that the sealant does not
get on countertop surface.
The sealing strip ensures that the
cooktop will sit securely in the cut-out
without slipping. Any gap between the
trim and countertop will become
smaller over time.
Installing the cooktop
Feed the cooktop power cord down
through the countertop cut-out.
Connecting the cooktop
Insert the plug housing at the end of
the connection cable into the socket
on the oven.
The plug housing and plug connector
are designed so that only one
connection alignment is possible. Do
not use force to insert the plug. The
protective earth wire is integrated in
the plug housing.
Check that the cooktop works.
Centre the cooktop in the cut-out.
Make sure that the seal under the
cooktop sits flush with the counter on
all sides. This is important to ensure
an effective seal.
If the seal does not sit flush with the
countertop in the corners, the corner
radius (≤R4) can be carefully cut to fit
using a jigsaw.
Never seal the cooktop using
additional sealant (e.g. silicone).
43
Electrical connection
Risk of injury.
Installation, maintenance and repair
work by unqualified persons can
cause considerable danger to users,
for which Miele is not responsible.
Miele cannot be held liable for
damage or injury caused by
improper installation, maintenance or
repair work or by inadequate or
faulty grounding in the building's
wiring system (e.g. electric shock).
The cooktop may only be connected
to the oven by a qualified and
competent electrician in accordance
with current local and national safety
regulations.
Make sure that all electrical
components are shielded and cannot
be accessed by users after
installation.
Connection
The voltage, rated load and fuse rating
can be found on the oven data plate.
Please ensure that these match the
building's electrical supply.
Ground fault circuit interrupter
For added safety, it is advisable to
protect the appliance with a suitable
ground fault circuit interrupter (GFCI)
with a trip current of 30mA.
Disconnecting devices
It must be possible to disconnect the
appliance from the power supply on all
poles using disconnecting devices.
When switched off, a contact distance
of at least 3mm must be present.
Disconnecting devices include
overcurrent protection elements and
protective circuit breakers.
44
Disconnecting from the power supply
Danger of electrical shock!
After disconnection, ensure the
appliance cannot be switched back
on by mistake.
To disconnect the appliance from the
power supply, do one of the following
depending on installation:
Safety fuses
Completely remove fuses
Automatic circuit breakers
Press the (red) button until the middle
(black) button springs out.
Built-in circuit breakers
Circuit breakers, type B or C: switch
the on-off switch from 1(on) to 0(off).
Electrical connection
Residual current device (RCD)
Switch the main switch from 1(on) to
0(off) or press the test button.
45
After-sales service, data plate, warranty
After-sales service
For problems that you cannot resolve on your own, please contact:
– Your Miele dealer or
– Miele Service
The telephone number for Miele Service can be found at the back of this booklet.
When contacting Miele, please have the model and serial number of your cooktop
ready.
Data plate
Affix the extra data plate supplied with the appliance in the box below. Make sure
that the model number matches the information on the back of these operating
instructions.
Warranty
For further information, please refer to your warranty booklet.
46
Importer
Miele Limited
Headquarters and Miele Centre
161 Four Valley Drive
Vaughan, ON L4K 4V8
www.miele.ca
Customer Care Centre
Phone: 800-565-6435
customercare@miele.ca
Miele & Cie. KG
Carl-Miele-Straße 29
33332 Gütersloh
Germany
Manufacturer
Canada
KM 6092
M.-Nr. 10 718
780 / 00en-CA
