Quick Start Guide
for dishwashers
These short instructions are not a substitute for the operating instructions supplied with the machine.
It is essential to familiarise yourself with the dishwasher before using it for the first time. Take note of the Warning and Safety instructions, as well as the full descriptions on how to use your appliance.
en-AU, NZ
M.-Nr. 11 872 650 / 01
Guide to the appliance
Control panel
a In-operation indicator light
For indicating an ongoing wash programme when the door is closed.
b On/Off sensor
For switching the dishwasher on and off.
c Remote control sensor For activating/deactivating the Remote control option.
d Touch display
For further information, see “Guide to the appliance - Display functions” in the operating instructions.
e Back sensor
For navigating back to the previous menu or deleting values which have been set previously.
f Home sensor
For returning to the Programmes menu.
Brief instructions
a AutoDos (automatic dispensing)
b Detergent compartment
c Rinse aid reservoir
d Salt reservoir
e Filter combination
Opening the door
The dishwasher has a motorised door opener which is activated by knocking on the door front (Knock2open function).
Knock twice in quick succession on the top third of the door front.
The door will open a little.
Filling the salt reservoir
Remove the lower basket from the wash cabinet and unscrew the salt reservoir cap.
Damage to the water softener from detergents.
Dishwasher detergent will damage the water softener.
Do not fill the salt reservoir with powder or liquid detergent.
Risk of corrosion due to saline solution.
Water or saline solution will run out of the reservoir when the cap is opened. Saline solution that runs out can cause corrosion in the wash cabinet and to the dishwasher load. The salt reservoir should therefore only be opened to replenish the salt.
Fill the salt reservoir with approx. 2 l of water (first use only).
Place the funnel provided over the salt reservoir and carefully fill with dishwasher salt until the reservoir is full.
Clean any excess salt from around the reservoir opening and then screw the salt reservoir cap on again firmly.
Immediately after filling the salt container, run the QuickPowerWash
65 °C programme with the
Express option and without any load in the dishwasher to dissolve and remove any traces of salt from the cabinet.
