Miele G 6305 SCU, G 6105 SCU, G 4925 U, G 4925 SCU, G 6105 U Specification

Futura Series
Pre-Finished Dishwashers
CLASSIC PLUS G 4925 U, G 4925 SCU CRYSTAL G 6105 U, G 6105 SCU DIMENSION G 6305 SCU
Specication Sheet TRS 04132015
8mieleusa.com
Futura Series
Pre-Finished Dishwashers
SPECIFICATIONS
9
Overall Unit Width 23
Overall Unit Height 33
Overall Unit Depth 22
/16” (598mm)
11
/16” - 361/4” (855 - 920mm)
7
/16” (570mm)
Niche
5
/8” (600mm)
Minimum Cabinet Opening Width
Minimum Cabinet Opening Height 33
Minimum Cabinet Opening Depth 22
23
3
/4” (857mm)
7
/16” (570mm)
Plumbing
May be connected to a cold or hot water
supply up to a maximum of 140°F/60°C.
Must be connected to a shut-off valve with
a male 3/8” NPT. The water shut-off valve
Water Supply Requirements
must be accessible after installation. The
water pressure must be between 4.35 psi (0.3 bar) and may not exceed 145 psi (10 bar). If the pressure is higher than 145 psi (10 bar), a pressure reducing valve must be
installed.
Water Connection Line
4’ 11” (1.5m) flexible water intake hose is supplied with a 3/8 NPT connection.
Drain Hose 4’ 11” (1.5m) flexible drain hose is supplied.
Electrical
Electrical Requirements - Volts/Amps 110V / 120V, 60Hz, 15 Amps
Power Cord - Plug and length
Yes - NEMA 5-15 plug, 5’ 6” (1.7m),
Convertible to Hardwire
Shipping
Shipping Weight 118 lbs (53.5 kg)
Support
Call Miele 800.843.7231
Miele Website
20/20 Link
8www.mieleusa.com
82020technologies.com
Page 2 of 5
