Page 1
Operating and installation instructions
Rangehood
To prevent the risk of accidents or damage to the appliance, it is
essential to read these instructions before it is installed and used for
the first time.
AU, NZ M.-Nr. 09 723 590
Page 2
Contents
Warning and Safety instructions .......................................................................... 4
Caring for the environment................................................................................. 13
Guide to the appliance......................................................................................... 14
Description of the functions ............................................................................... 16
Operation .............................................................................................................. 17
Joystick.................................................................................................................. 17
Switching the fan on .............................................................................................. 17
Selecting a power setting ...................................................................................... 17
Selecting the run-on time....................................................................................... 18
Switching the fan off .............................................................................................. 18
Safety switch-off.................................................................................................... 19
Operating hours counter........................................................................................ 19
Altering the operating hours counter for the grease filters .................................... 19
Activating and altering the operating hours counter for the NoSmell active charcoal
filters ...................................................................................................................... 20
Energy saving tips................................................................................................ 22
Cleaning and care................................................................................................ 23
Housing.................................................................................................................. 23
Grease filters.......................................................................................................... 23
NoSmell active charcoal filters............................................................................... 25
Resetting the operating hours counter for the charcoal filters ......................... 26
Disposing of the charcoal filters ....................................................................... 26
Changing a halogen lamp...................................................................................... 27
After sales service and warranty........................................................................ 28
Position of the data plate....................................................................................... 28
Installation ............................................................................................................ 29
Before installation .................................................................................................. 29
Appliance dimensions............................................................................................ 30
Safety distance (S) ................................................................................................. 31
Installation recommendations................................................................................ 32
Building in .............................................................................................................. 32
Set up for extraction mode .................................................................................... 33
Set up for recirculation mode ................................................................................ 34
Fitting the joystick.................................................................................................. 35
Joystick extension ............................................................................................ 35
Mains connection................................................................................................... 36
2
Page 3
Contents
Electrical connection........................................................................................... 37
Connection for air extraction.............................................................................. 38
Condensate trap .................................................................................................... 39
Silencer .................................................................................................................. 40
Technical data ...................................................................................................... 41
3
Page 4
Warning and Safety instructions
This appliance complies with all relevant local and national safety
requirements. Inappropriate use can, however, lead to personal
injury and damage to property.
To avoid the risk of accidents and damage to the appliance,
please read these instructions carefully before using it for the first
time. They contain important notes on the safety, installation, use
and maintenance of the appliance. Miele cannot be held liable for
non-compliance with these instructions.
Keep these instructions in a safe place and ensure that all users
are familiar with the contents. Pass them on to any future owner of
the appliance.
Correct application
This rangehood is designed for domestic use and for use in
similar environments by guests in hotel or motel rooms, bed &
breakfasts and other typical living quarters. This does not include
common/shared facilities or commercial facilities within hotels,
motels or bed & breakfasts.
The appliance is not suitable for outdoor use.
It must only be used to extract vapours and remove odours from
cooking.
Any other usage is at the owner's risk. Miele cannot be held liable
for damage resulting from incorrect or improper use or operation.
Where a recirculation rangehood is fitted above a gas cooktop,
please ensure that there is an adequate supply of fresh air into the
room in which it is installed. Please seek the advice of a qualified
gas fitter if necessary.
4
Page 5
Warning and Safety instructions
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning its use by a person responsible
for their safety, and are able to recognise the dangers of misuse.
Safety with children
Young children must not be allowed to use this appliance.
Older children may only use the appliance when its operation has
been clearly explained to them and they are able to use it safely,
recognising the dangers of misuse.
Cleaning work may only be carried out by older children under the
supervision of an adult.
Children should be supervised near the appliance. Ensure that
they do not play with the appliance.
Danger of suffocation! Children may be able to wrap themselves
in packing material or pull it over their heads with the risk of
suffocation. Keep children away from any packing material.
5
Page 6
Warning and Safety instructions
Technical safety
Repairs and other work by unqualified persons could be
dangerous. Installation, maintenance work and repairs to electrical
appliances must only be carried out by a Miele approved service
technician.
A damaged appliance can be dangerous. Check it for visible signs
of damage. Do not use a damaged appliance.
The electrical safety of this appliance can only be guaranteed
when continuity is complete between it and an effective earthing
system. It is most important that this basic safety requirement is
present and tested regularly and, where there is any doubt, the
household wiring system should be inspected by a qualified
electrician.
Reliable and safe operation of this rangehood can only be assured
if it has been connected to the mains electricity supply.
Before connecting the appliance to the mains supply, ensure that
the connection data on the data plate (voltage and frequency)
matches the mains electricity supply. This data must correspond in
order to avoid the risk of damage to the appliance. Consult a
qualified electrician if in any doubt.
Do not connect the appliance to the mains electricity supply by a
multi-socket unit or an extension lead. Extension leads are a fire
hazard and do not guarantee the required safety of the appliance.
For appliances with an external motor fitted (...EXT models) the
connection of the two units must be made using the control cable
and the plug connectors.
These models may only be combined with a Miele external motor.
6
Page 7
Warning and Safety instructions
For safety reasons, this appliance may only be used after it has
been built in.
This rangehood must not be installed and operated in mobile
installations (e.g. on a ship).
Tampering with electrical connections or components and
mechanical parts is highly dangerous to the user and can cause
operational faults.
Only open the housing as described in the instructions given in the
installation sheet and in the Cleaning and care section of this
booklet. Under no circumstances should any other parts of the
housing be opened.
The manufacturer's warranty will be invalidated if the appliance is
not repaired by a Miele approved service technician.
Faulty components must only be replaced by genuine Miele spare
parts. The manufacturer can only guarantee the safety of the
appliance when Miele replacement parts are used.
If the mains connection cable is damaged, it must only be
replaced by a Miele authorised service technician in order to avoid a
hazard.
During installation, maintenance and repair work, the appliance
must be disconnected from the mains electricity supply. It is only
completely isolated from the electricity supply when:
– the mains circuit breaker is switched off, or
– it is switched off at the wall socket and the plug is withdrawn
from the socket. Do not pull the mains connection cable but the
mains plug to disconnect your appliance from the mains
electricity supply.
7
Page 8
Warning and Safety instructions
Using at the same time as other heating appliances that depend on the air from the room
Warning - danger of toxic fumes
Great care should be taken when using the rangehood at the
same time and in the same room or area of the house as another
heating appliance which depends on the air in the room.
Such appliances include gas, oil, wood or coal-fired boilers and
heaters, continuous flow or other water heaters, gas cooktops, or
ovens which draw air in from the room and duct exhaust gases
out through a chimney or extraction ducting.
When used in extraction mode, with or without an external motor
fitted, or in recirculation mode with a recirculation box installed
outside the room, the appliance draws air in from the room in
which it is installed and from neighbouring rooms.
If there is insufficient air, an underpressure will occur. The heating
appliance will be starved of oxygen, impairing combustion.
Harmful gases could be drawn out of the chimney or extraction
ducting back into the room, with potentially fatal consequences.
8
Page 9
Warning and Safety instructions
In order to ensure safe operation, and to prevent gases given off
by the heating appliances from being drawn back into the room
when the rangehood and the heater are in operation
simultaneously, an underpressure in the room of 0.04 mbar (4 pa)
is the maximum permissible.
Ventilation can be maintained by air inlets which cannot be
blocked, in windows, doors or outside wall vents, or by other
technical measures, such as ensuring that the rangehood can only
be switched on when the heating appliance is switched off or vice
versa. A ventilation brick alone is not generally sufficient to ensure
safe ventilation.
The overall ventilation condition of the dwelling must be taken into
account. If in any doubt, the advice of a competent builder, or for
gas a qualified gas fitter (registered with an official gas safety
body in accordance with national safety regulations), must be
sought.
If the rangehood is used in recirculation mode, where the air is
directed back into the room in which it is located, operating a
heating appliance which depends on the room air at the same
time is not hazardous.
9
Page 10
Warning and Safety instructions
Correct use
Never use an open flame beneath the rangehood. To avoid the
danger of fire, do not flambé or grill over an open flame.
When switched on, the rangehood could draw flames into the filter.
Fat deposits could ignite, presenting a fire hazard.
The rangehood can become damaged when exposed to
excessive heat.
– When using the rangehood over a gas cooktop, ensure that any
burners in use are always covered by a pan. Switch the cooking
zone off when a pan is removed, even for a short time.
– Select a pan which is suitable for the size of the burner.
– Regulate the flame so that it does not burn up the sides of the
pan.
– Avoid overheating the pan (e.g. when cooking with a wok).
Always switch the rangehood on when a cooking zone is in use,
otherwise condensation may collect in the rangehood, which could
cause corrosion.
When cooking with oil or fat, chip pans and deep fat fryers etc.,
do not leave the pans unattended. Never leave an open grill
unattended when grilling. Overheated oil and fat can ignite and
could set the rangehood on fire.
10
Page 11
Warning and Safety instructions
Do not use the rangehood without the filters in place. This way
you will avoid the risk of grease and dirt getting into the appliance
and hindering its smooth operation.
The rangehood can get very hot during cooking due to heat rising
from the cooktop.
Do not touch the housing or the grease filters until the rangehood
has cooled down.
Correct installation
Refer to the cooktop manufacturer's instructions as to whether a
rangehood may be operated above the cooktop.
Safety regulations prohibit the fitting of a rangehood over solid
fuel stoves.
Insufficient distance between the cooktop and the rangehood can
result in damage to the rangehood.
The minimum safety distances between the top of the cooktop and
the bottom of the rangehood given in the "Installation" section must
be maintained, unless the cooktop manufacturer states that a
greater distance is required.
If more than one cooking appliance is fitted beneath the rangehood,
and they have different minimum safety distances to the rangehood,
select the greater distance.
The distances given in "Installation" must be observed when
fitting the rangehood.
11
Page 12
Warning and Safety instructions
All ducting, pipework and fittings must be of non-flammable
material. These can be obtained from builders' merchants.
The appliance must not be connected to a chimney or vent flue
which is in use. Neither should it be connected to ducting which
ventilates rooms with fireplaces.
If exhaust air is to be extracted into a chimney or ventilation duct
no longer used for other purposes, seek professional advice.
Cleaning and care
There is a risk of fire if the rangehood is not cleaned as described
in these operating instructions.
Do not use a steam cleaning appliance to clean this appliance.
The steam could reach electrical components and cause a short
circuit.
In areas which may be subject to infestation by cockroaches or
other vermin, pay particular attention to keeping the machine and its
surroundings in a clean condition at all times. Any damage which
may be caused by cockroaches or other vermin will not be covered
by the machine warranty.
Accessories
Use only genuine original Miele spare parts. If spare parts or
accessories from other manufacturers are used, the warranty will be
invalidated, and Miele cannot accept liability.
12
Page 13
Caring for the environment
Disposal of the packing material
The transport and protective packing
has been selected from materials which
are environmentally friendly for
disposal, and can normally be recycled.
Recycling the packaging reduces the
use of raw materials in the
manufacturing process and also
reduces the amount of waste in landfill
sites. Ensure that any plastic
wrappings, bags etc. are disposed of
safely and kept out of the reach of
babies and young children. Danger of
suffocation.
Disposing of your old appliance
Electrical and electronic appliances
often contain materials which, if
handled or disposed of incorrectly,
could be potentially hazardous to
human health and to the environment.
They are, however, essential for the
correct functioning of your appliance.
Therefore, please do not dispose of
your old appliance with your household
waste.
Please dispose of it at your local
community waste collection / recycling
centre.
Ensure that your old appliance presents
no danger to children while being
stored for disposal.
13
Page 14
Guide to the appliance
14
Page 15
a
Touch controls
b
Joystick
c
Cooktop lighting
d
NoSmell active charcoal filters
(only with recirculation mode)
DA 2250, DA 2270: 2 charcoal filters
DA 2210: 4 charcoal filters
e
Grease filters
f
Fan setting indicator lights
g
Touch control for the run-on option
h
Operating hours control for the grease filters
i
Operating hours control for the charcoal filters
Guide to the appliance
15
Page 16
Description of the functions
Depending on the model of the
rangehood, the following options are
available:
Air extraction mode
The air is drawn in and cleaned by the
grease filters and directed outside.
Non-return flap
The non-return flap is designed to
prevent the exchange of room and
outside air taking place.
The flap is closed when the rangehood
is switched off.
When the rangehood is switched on,
the non-return flap opens for the
cooking vapours to be blown directly
outside.
If the on-site ventilation system does
not have a non-return flap, the nonreturn flap supplied must be fitted.
Recirculation mode
(available as an optional extra with a
conversion kit and charcoal filter: see
"Technical Data")
The air is drawn in and cleaned first by
the grease filters and then by a
charcoal filter. The cleaned air is then
recirculated back into the kitchen.
Operation with an external motor
(...EXT model rangehoods.
...EXT models are only available in
selected countries. )
Rangehoods set up for operation with
an external motor have to be connected
to a Miele external motor located in a
suitable position outside the room in
which the rangehood is installed. The
external motor is linked to the
rangehood via a control cable and then
operated using the controls on the
rangehood.
16
Page 17
Operation
Joystick
This is used to operate the fan settings
and the lighting.
Switching the fan on
Press the joystick once to the right.
The fan will come on at power setting 2.
Selecting a power setting
For light to heavy cooking vapours and
odours, select from power settings 1 to
3.
When frying or cooking food with a
strong aroma, select fan power setting
4 (Intensive setting).
Press the joystick repeatedly to the
right to select a higher power setting,
and to the left to select a lower power
setting.
Automatic switch-off of the Intensive setting
You can set the Intensive setting so that
it always only runs for 10 minutes
before reverting automatically to setting
3.
To set this option, both the fan and
the cooktop lighting must be
switched off.
Press the run-on option control
for approx. 10 seconds until the
indicator for power setting 1 lights
up.
Press the joystick
– once to the rear,
– once to the left,
– once to the rear.
The indicator lights for fan power
settings 1 and 4 will flash if automatic
switch-off for the Intensive setting is
not activated.
To activate automatic switch-off,
press the joystick once to the right.
If automatic switch-off is activated, the
1 and 4 indicator lights will light up.
To deactivate automatic switch-off,
press the joystick once to the left.
Press the control for the run-on
option to confirm the setting.
If you do not confirm within 4
minutes, the rangehood will revert to
the old setting.
17
Page 18
Operation
Selecting the run-on time
It is advisable to run the fan for a few
minutes after cooking has finished to
neutralise any lingering vapours and
odours in the air.
With the run-on function the fan
switches itself off automatically after a
pre-selected time.
After cooking has finished, press the
run-on option control whilst the
fan is still running.
– Press once: The fan will switch off
after 5 minutes (left-hand indicator
lights up).
– Press twice: The fan will switch off
after 15 minutes (right-hand indicator
lights up).
– If you press the run-on control
again, the fan remains on (right-hand
indicator goes out).
Switching the fan off
Press the joystick repeatedly to the
left until the fan switches off.
Alternatively, press the joystick to the
left and hold it until the fan switches
off.
The fan power setting indicator lights
go out.
Switching on the cooktop lighting
Press the joystick once to the rear or
to the front to switch on the lighting.
Dimming the cooktop lighting
With the lighting switched on, press
and hold the joystick to the rear or
the front. The brightness will
gradually dim until you release the
joystick.
Pressing and holding it again will
gradually increase the brightness
until you release it.
Switching off the cooktop lighting
Press the joystick again once to the
rear or to the front to switch it off.
18
Page 19
Operation
Safety switch-off
Should the rangehood be left on, the
fan will switch off automatically after 10
hours. The lighting will remain on.
Pressing the On/Off control will
switch the fan back on again.
Operating hours counter
The number of hours the appliance has
been in operation is stored in memory.
When the grease filter symbol or the
charcoal filter symbol lights up, the
operating hours counters are signalling
that the filters need to be cleaned or
changed. Further information about
cleaning and changing the filters and
resetting the operating hours counter
can be found under "Cleaning and
care".
Altering the operating hours counter for the grease filters
You can set the operating hours
counter for the grease filters to suit the
type of cooking you do.
It is set at the factory for 30 hours.
– Select a shorter time (20 hours) if you
fry a lot.
– If you only cook occasionally, we
recommend that you still select a
short time because grease which has
built up gradually over a long period
of time will harden on the filters and
make cleaning more difficult.
– If you use very little fat for cooking,
select a longer time (40-50 hours).
Switch off the fan using the joystick.
Press the run-on option control
and the grease filter control at the
same time.
The grease filter indicator light and
one of the fan power setting indicator
lights will flash.
19
Page 20
Operation
The indicator lights for the fan power
settings show the operating hours
which have been set:
1st light.................................... 20 hours
2nd light................................... 30 hours
3rd light.................................... 40 hours
4th light.................................... 50 hours
Press to the left for a shorter
operating time, or to the right for a
longer time.
Confirm the selection by touching the
grease filter control .
Activating and altering the operating hours counter for the NoSmell active charcoal filters
Charcoal filters are needed for
recirculation mode.
The operating hours counter for the
charcoal filters needs to be activated
once and the operating hours counter
needs to be set to suit the kind of
cooking you do:
Switch off the fan using the joystick.
Press the run-on option control
and the charcoal filter control at
the same time.
The indicator light for the charcoal filter
control and one of the fan power
setting indicator lights will flash.
The indicator lights for the fan power
settings show the operating hours
which have been set:
1st light.................................. 120 hours
All the indicator lights will go out.
If you don't confirm your selection
within 4 minutes, the rangehood will
automatically revert to the previous
setting.
20
2nd light................................. 180 hours
3rd light.................................. 240 hours
4th light ............................... deactivated
Page 21
Press to the left for a shorter
operating time, or to the right for a
longer time.
Confirm the selection by pressing the
charcoal filter touch control .
All the indicator lights will go out.
If you don't confirm your selection
within 4 minutes, the rangehood will
automatically revert to the previous
setting.
Operation
21
Page 22
Energy saving tips
This rangehood operates very efficiently
and economically. The following will
help you to save even more energy
when using it:
– Ensure that there is sufficient
ventilation in the kitchen when
cooking. In extraction mode, if there
is insufficient air flow the rangehood
cannot operate efficiently and this
causes increased operating noise
levels.
– Always cook with the lowest possible
setting. This produces fewer cooking
vapours, so you can use a lower
rangehood power level and therefore
benefit from reduced energy
consumption.
– Check the power level selected on
the rangehood. A lower power level is
generally sufficient for the majority of
cooking. Only use the intensive
setting when necessary.
– When a large volume of cooking
vapours are being produced, switch
to a high power level in good time.
This is more efficient than operating
the rangehood for longer to try to
capture cooking vapours which have
already been distributed throughout
the kitchen.
– Make sure that you switch the
rangehood off after use.
– Clean or change the filters at regular
intervals. Heavily soiled filters reduce
performance, increase the risk of fire
and are unhygienic.
22
Page 23
Cleaning and care
Housing
General
The surfaces and controls are
susceptible to scratches and
abrasion.
Please observe the following
cleaning instructions.
Switch the rangehood off before any
cleaning or maintenance work is
carried out.
All external surfaces and controls can
be cleaned using warm water with a
small amount of washing-up liquid
applied with a well wrung-out soft
sponge or cloth.
Do not use too much water when
cleaning the controls.
Water could penetrate into the
electronics and cause damage.
After cleaning, wipe the surfaces dry
using a soft cloth.
Do not use:
– cleaning agents containing soda,
acids, chlorides or solvents,
– abrasive cleaning agents, e.g.
powder cleaners or cream cleaners
and abrasive sponges, as well as pot
scourers or sponges which have
been used previously with abrasive
cleaning agents. These will damage
the surface material.
Grease filters
The re-usable metal grease filters in the
appliance remove solid particles
(grease, dust, etc.) from the kitchen
vapours, preventing soiling of the
rangehood.
An oversaturated filter is a fire
hazard.
When to clean the grease filters
The grease filters should be cleaned
regularly (at least every 3-4 weeks) to
avoid a build-up of grease.
The operating hours counter regularly
reminds you to clean the grease filters
by illuminating the grease filter touch
control indicator light .
You can set the operating hours
counter to suit the type of cooking
you do (see "Operation").
Removing a grease filter
The grease filter can fall out when
you are handling it.
This can result in damage to the filter
and the cooktop below.
Make sure you hold the filter
securely at all times when handling
it.
23
Page 24
Cleaning and care
To take out a grease filter, release the
locking clip on the filter, lower the
filter approx. 45°, unhook it at the
back and remove it.
Cleaning the grease filters by hand
Clean the filters with a soft nylon
brush in a mild solution of hot water
and a small amount of washing-up
liquid. Do not use undiluted washing
up liquid.
Unsuitable cleaning agents
Unsuitable cleaning agents can cause
damage to the surface of the filters if
used regularly.
Do not use:
– cleaning agents containing descaling
agents,
– powder cleaners or cream cleaners,
– aggressive all-purpose cleaning
agents or spray cleaners for grease,
Cleaning the grease filters in a dishwasher
Place the filters as upright as
possible in the lower basket, with the
short sides upright, ensuring the
spray arm is not obstructed.
Use a proprietary household
dishwasher detergent.
Select a dishwasher programme with
a wash temperature between 50 °C
and 65 °C.
Depending on the cleaning agent
used, cleaning the filters in a
dishwasher can cause permanent
discolouration to the surface.
However, this will not affect the
functioning of the filters in any way.
After cleaning
After cleaning, leave the filters to dry
on an absorbent surface before
refitting them.
When removing the filters for
cleaning, also clean off any residues
of oil or fat from the now accessible
housing to prevent the risk of these
catching fire.
Replace the grease filters, making
sure that the locking clips are facing
down towards the cooktop.
– oven sprays.
24
Page 25
Cleaning and care
If a grease filter is inadvertently
refitted upside down, insert a small
screwdriver blade into the slit to
disengage the clip.
Resetting the operating hours counter for the grease filters
After cleaning, the operating hours
counter needs to be reset.
Whilst the fan is switched on, press
the grease filter control for approx.
3 seconds until only the first fan
power setting indicator light flashes.
The indicator light for the grease filter
touch control will go out.
If the grease filters are cleaned before
the operating hours counter has
reached its maximum:
Press the grease filter control for
approx. 6 seconds until only the first
fan power setting indicator light
flashes.
NoSmell active charcoal filters
If the rangehood is connected for
recirculation, either two (DA 2250,
DA 2270) or four (DA 2210) charcoal
filters must be inserted in addition to
the grease filters. They are designed to
absorb cooking odours and are fitted in
the canopy above the grease filters.
Replacement charcoal filters can be
obtained from Miele or via the internet
at www.miele-shop.com (depending on
country). See the back of these
instructions for contact details, and
"Technical data" for type and reference
number.
Fitting and replacing the charcoal filters
Before fitting or replacing the
charcoal filters, the grease filters
must first be taken out (see previous
section for instructions on how to do
this).
Unwrap the charcoal filters.
Press the charcoal filters into the
frame.
Refit the grease filters.
When fitting for the first time, activate
the operating hours counter (see
"Operation").
25
Page 26
Cleaning and care
When to change the NoSmell active charcoal filters
Always replace the charcoal filters
when they no longer absorb kitchen
odours effectively.
They should, however, be replaced at
least every 6 months.
The operating hours counter regularly
reminds you to replace the charcoal
filters by illuminating the charcoal filter
touch control indicator light .
The charcoal filter operating hours
counter needs to be activated before
using for the first time (see
"Operation").
Resetting the operating hours counter for the charcoal filters
After changing the charcoal filters, the
operating hours counter needs to be
reset.
Whilst the fan is switched on, press
the charcoal filter control for
approx. 3 seconds until only the first
fan power setting indicator light
flashes.
Disposing of the charcoal filters
The used charcoal filters can be
disposed of with the normal
household waste.
The indicator light for the charcoal filter
touch control will go out.
If you replace the charcoal filter before
the operating hours counter has
reached its maximum:
Press the charcoal filter control for
approx. 6 seconds until only the first
fan power setting indicator light
flashes.
26
Page 27
Changing a halogen lamp
The halogen lamps should be replaced
with the following:
Manufacturer............................... Osram
Lamp type .................................... GU10
Model........................................ Halopar
Voltage...........................................230 V
Wattage......................................... 50 W
These halogen lamps are available from
Miele or from specialist retailers.
Disconnect the rangehood from the
mains electrical supply before
replacing the lamps (see "Warning
and Safety instructions").
Cleaning and care
Remove the grease filters.
Remove the charcoal filters if the
rangehood is being used in
recirculation mode.
Note that halogen lamps become
very hot when in use.
They can cause burns even after
being switched off for some time.
Allow the lamps to cool down for a
few minutes before changing them.
Push down the lighting unit slightly
via the opening in the safety panel.
Turn the halogen lamp anti-clockwise
and pull it out.
Screw the new halogen lamp into the
socket and push it upwards. Please
follow the manufacturer's safety
instructions.
Replace the grease filters and, if
being used in recirculation mode, the
charcoal filters.
27
Page 28
After sales service and warranty
In the event of a fault which you cannot
remedy yourself, please contact Miele.
The contact details for Miele are given
at the back of these instructions.
When contacting Miele, please quote
the model and serial number of your
appliance.
These can be found on the data plate.
Position of the data plate
The data plate is visible after removing
the grease filters.
Warranty
The manufacturer's warranty for this
appliance is 2 years.
For further information, please refer to
your warranty booklet.
28
Page 29
Before installation
Before installation, it is important
to read the information given on the
following pages as well as the
"Warning and Safety instructions" at
the beginning of this booklet.
Installation
29
Page 30
Installation
Appliance dimensions
*Cut-out dimensions
A depth T of at least 25 mm must be provided at the back of the building-in
niche.
30
Page 31
Installation
Safety distance (S)
The minimum distances between the top of a cooktop (excluding trivets, dials depending on model) and the bottom of the rangehood are as follows, unless a
greater distance is specified by the manufacturer of your cooking appliance.
See also "Warning and Safety instructions".
Cooking appliance Minimum distance S
Electric cooktop 600 mm
Electric grill, deep fat fryer (electric) 650 mm
Multi-burner gas cooktop with maximum 45.4 MJ/h
total output, with no burner having a greater output than
16.2 MJ/h.
Multi-burner gas cooktop with total output greater than
45.4 MJ/h, but with a maximum of 77.8 MJ/h, with no
burner having a greater output than 17.3 MJ/h.
Multi-burner gas cooktop with total output greater than
77.8 MJ/h, with a single burner having a greater output
than 17.3 MJ/h.
Single burner gas cooktop with a maximum output of
21.6 MJ/h.
Single burner gas cooktop with an output greater than
21.6 MJ/h, but with a maximum of 29.2 MJ/h.
Single burner gas cooktop with an output greater than
29.2 MJ/h.
650 mm
760 mm
Not possible
650 mm
760 mm
Not possible
31
Page 32
Installation
Installation recommendations
– To achieve optimum vapour
extraction, the rangehood must cover
the cooktop. It should be positioned
centrally over the cooktop, not to the
side.
– The cooktop should be no wider than
the rangehood and, if possible, it
should be narrower, especially for
safety distances greater than 750
mm.
– The installation area must be easily
accessible. The rangehood should be
easily accessible and easy to
dismantle in the event that service is
required. This should be taken into
consideration when planning the
position of cupboards, shelves,
ceilings or features in the vicinity of
the rangehood.
Building in
The rangehood is intended to be built
into wall units, rangehood housing
units, and above breakfast bars or
island areas.
Check prior to installation that the top
of the appliance will be accessible
after installation.
If this is not the case, install the exhaust
ducting and prepare the mains
connection before installation.
32
Place the appliance in the cut-out
from below and align it and secure it
to the frame.
The screws are suitable for a solid
installation surface made from wood.
For installation in other materials,
ensure you use appropriate means of
fixing. Make sure the structure is
able to take the weight of the
rangehood.
Page 33
Set up for extraction mode
dai2699
If required, install the non-return flap.
Check that the flap opens easily and
closes by itself.
A non-return flap is used in each of
the two exhaust sockets on the
DA 2210.
Installation
Place the exhaust ducting on the
exhaust collar for the rangehood.
See "Connection for air extraction"
for further instructions on fitting the
ducting.
DA 2210: The rangehood has two
exhaust sockets for use with two
150 mm diameter exhaust hoses. A
"Y" adapter is supplied with the
rangehood. It may be used to feed
the exhaust from both sockets to a
200 mm common duct.
However, for optimum performance
and minimum operating sound,
exhaust ducting via two separate
ducts is strongly recommended.
Attach the exhaust ducting, e.g.
flexible hose, to the exhaust collar
using a hose clip (available as an
optional accessory). When using
125 mm ducting, fit the reducing
collar supplied into the exhaust
socket (see "Connection for air
extraction").
33
Page 34
Installation
Set up for recirculation mode
If site conditions are not suitable for the
rangehood to be used with air
extraction, the appliance must be set
up for recirculation. The DUU 151
conversion kit, available from Miele, is
required for operating the rangehood in
recirculation mode. You will also need a
charcoal filter set DKF 15-1 (2 charcoal
filters).
The DA 2210 requires two conversion
kits and two charcoal filter sets (4
charcoal filters).
34
Fit the conversion kit as described in
the installation instructions supplied
with the kit. Make sure that the slats
in the exhaust grille point towards the
centre of the room and not towards a
wall or the ceiling.
A non-return flap is not used in
recirculation mode.
Fit the charcoal filters (see "Cleaning
and care").
Page 35
Installation
Fitting the joystick
Screw the spring into the joystick
holder and tighten by hand. Whilst
doing so, counterhold the joystick
holder with an SW 9 spanner. Do not
turn the spanner.
Then fit the middle section onto the
spring and tighten by hand whilst
continuing to counterhold the joystick
holder. Do not turn the spanner.
Fit the lower section of the joystick
and lightly secure in position with the
screw supplied and a spring washer.
Do not tighten the screw yet.
Turn the lower section around, until
the symbol is facing the front.
Then tighten the screw with a 3 mm
Allen key. Continue to counterhold
the joystick holder with an SW 9
spanner. Do not turn the spanner.
Joystick extension
The joystick can be extended if required
(special accessory - Miele DBV 100).
Assemble the spring and top section
as described above.
Whilst counterholding the base of the
joystick with an SW 9 spanner (do
not turn), secure the joystick
extension to the socket using a
spring washer in between them, as
shown above.
Then attach the lower section of the
joystick to the extension piece as
previously described, turn the
symbol to the front and then tighten
the screw.
35
Page 36
Installation
Mains connection
Refer to the notes in “Electrical
connection” and “Warning and
Safety instructions” before
connecting to the electricity supply.
For appliances connected to an
external motor (...EXT models):
Connect the rangehood and the
external motor using the control
cable and the six-pole plug
connector.
Plug the mains connection cable into
an electrical socket.
36
Page 37
All electrical work should be
undertaken by a suitably qualified
and competent person in strict
accordance with current national and
local safety and building code
regulations. Installation, repairs and
other work by unqualified persons
could be dangerous, for which the
manufacturer cannot be held liable.
Ensure power is not supplied to the
appliance until after installation or
repair work has been carried out.
The rangehood must be connected to a
suitably earthed socket (AC 230 V,
50 Hz).
For extra safety it is advisable to install
a residual current device (RCD) with a
trip current of 30 mA.
Connection of this appliance should be
made via a suitable isolator which
complies with national and local safety
regulations and the On-Off switch
should be easily accessible after the
appliance has been built in.
Electrical connection
If the mains socket is not accessible
after installation, an additional means of
disconnection must be provided for all
poles. There must be an all-pole
contact gap of 3 mm in the switch
(including switch, fuses and relays
according to EN 60335).
The connection data is given on the
data plate (See "After sales service").
Ensure that this data matches the
household mains supply.
37
Page 38
Connection for air extraction
Before installation, it is important
to read the information given on the
following pages as well as the
"Appliance dimensions" and the
"Warning and Safety instructions" at
the beginning of this booklet. This is
particularly crucial when using the
rangehood at the same time as a
heating appliance that relies on
oxygen from the same room, which
could result in the build-up of toxic
fumes.
The rangehood should be installed
according to local and national
building regulations. Seek approval
from the building inspector where
necessary.
Only use smooth pipes or flexible
hoses made from non-flammable
materials for the extraction ducting.
Highly flexible, concertina type
ducting material will greatly reduce
the performance of the rangehood.
– A reduction in diameter will
compromise the extraction
performance of the rangehood.
– If flat ducting is being used, the
cross-sectional area must not be
smaller than the cross-sectional area
of the exhaust connection.
– The exhaust ducting should be as
short and straight as possible.
– Only use wide radius bends.
– The exhaust ducting should not be
kinked or compressed.
– Ensure that all connections are
strong and airtight.
Remember that any constriction of
the airflow will reduce extraction
performance and increase operating
noise.
If the exhaust is ducted through an
outside wall, a telescopic wall vent or
a roof vent (available as an optional
accessory) is recommended.
When using an external motor, make
sure that the exhaust ducting is
sufficiently rigid. The external motor
can cause an underpressure which
can result in the exhaust ducting
distorting.
To achieve the greatest possible air
extraction with the lowest noise level,
please note the following:
To ensure efficient air extraction, the
diameter of the exhaust ducting
should not be less than 150 mm.
38
If the exhaust air is to be ducted into
a vent flue, the ducting must be
directed in the flow direction of the
flue.
Page 39
Connection for air extraction
When ducting is horizontal it must be
laid to slope away at at least 1 cm
per metre. This is to ensure that
condensate cannot drain back into
the rangehood.
If the exhaust ducting is to run
through rooms, ceiling space etc.
where there may be great variations
in temperature between the different
areas, the problem of condensation
will need to be addressed. The
exhaust ducting will need to be
suitably insulated.
Condensate trap
exhaust socket.
The arrow on the housing indicates
the direction of airflow.
The condensate trap will be integrated
in rangehoods which are designed to
be connected to an external fan
(model......EXT).
In addition to insulating the exhaust
ducting, we recommend that a suitable
condensate trap is also installed to
collect and evaporate any condensate
which may occur.
Condensate traps are available for
125 mm or 150 mm ducting.
When installing a condensate trap,
ensure that it is positioned vertically
and, if possible, directly above the
39
Page 40
Connection for air extraction
Silencer
To achieve even further reductions in
noise levels, a special silencer (optional
accessory) can be fitted in the ducting
system.
Air extraction mode
Recirculation mode
The silencer needs to be positioned
between the exhaust connection and
the exhaust grille . Ensure there is
adequate space for fitting it.
Air extraction with external motor
The silencer not only reduces noise
from the motor outside the house, but
also sounds from outside (e.g. traffic
noise). For this reason, the silencer
must be positioned as close as
possible to the ducting exit .
40
To minimise noise from the motor in the
kitchen, the silencer should be
positioned in front of the external motor
if possible, or, if the ducting is long,
above the exhaust connection inside
the rangehood . In the case of an
external motor located inside the
house, fitting a silencer behind the
external motor reduces the noise of
the motor outside the house.
Page 41
Technical data
Fan motor*
DA 2250, DA 2270 200 W
DA 2210 2 x 290 W
Cooktop lighting
DA 2250, DA 2270 2 x 50 W
DA 2210 4 x 50 W
Total rated load*
DA 2250, DA 2270 300 W
DA 2210 780 W
Voltage, frequency AC 230 V, 50 Hz
Fuse rating 10 A
Mains connection cable length 1.5 m
Weight
DA 2250 8 kg
DA 2250 EXT 5.5 kg
DA 2270 9.5 kg
DA 2270 EXT 7 kg
DA 2210 16 kg
41
Page 42
Technical data
Extraction power* according to EN 61591
DA 2250, DA 2270, extraction ducting 150 mm
Setting 1 200 m³/h
Setting 2 300 m³/h
Setting 3 400 m³/h
Intensive setting 640 m³/h
Recirculation power**
Setting 1 140 m³/h
Setting 2 240 m³/h
Setting 3 360 m³/h
Intensive setting 550 m³/h
DA 2210, extraction ducting 2 x 150 mm
Setting 1 650 m³/h
Setting 2 950 m³/h
Setting 3 1250 m³/h
Intensive setting 1850 m³/h
Recirculation power**
Setting 1 600 m³/h
Setting 2 900 m³/h
Setting 3 1200 m³/h
Intensive setting 1550 m³/h
* For EXT models, the rated load will depend on the type of external motor fitted.
Length of control cable to external motor: 1.9 m
**Special accessories for recirculation mode:
DUU 151 conversion kit and DKF 15-1 charcoal filter set (contains 2 charcoal filters).
The DA 2210 requires two conversion kits and two charcoal filter sets.
42
Page 43
www.miele.com.au
Miele Center and Head Office Melbourne:
1 Gilbert Park Drive
Knoxfield, VIC 3180
Miele Center and Office Melbourne:
206-210 Coventry Street
South Melbourne, VIC 3205
Miele Center and Office Sydney:
3 Skyline Place
Frenchs Forest, NSW 2086
Miele Center and Office Brisbane:
39 Harvey Street North
Eagle Farm, QLD 4009
Miele Center and Office Adelaide:
83-85 Sir Donald Bradman Drive
Hilton, SA 5033
205-207 Stirling Highway
Claremont, WA 6010
Miele Center and Office Perth:
Miele Australia Pty. Ltd.
Miele New Zealand Limited
Level 2, 10 College Hill
Freemans Bay, Auckland 1011
Miele Center Auckland:
8 College Hill
Freemans Bay, Auckland 1011
Telephone:
0800 4 MIELE (0800 464 353)
www.miele.co.nz
Miele Global Headquarters
Germany
Miele & Cie. KG
Carl-Miele-Straße 29
33332 Gütersloh
Federal Republic of Germany
Head Office:
IRD 98 463 631
ACN 005 635 398
ABN 96 005 635 398
43
Page 44
DA 2250
DA 2270
DA 2210
DA 2250 EXT
DA 2270 EXT
M.-Nr. 09 723 590 / 04AU, NZ
Loading...
