Miele CSDA1020 Installation and Operation Guide
Operating and installation instructions
Stainless steel TepanYaki
To prevent the risk of accidents or damage to the appliance, it is
essential to read these instructions before it is installed and used for
the first time.
en-AU, NZ M.-Nr. 09 054 600
Contents
Warning and Safety instructions.......................................................................... 3
Caring for the environment ................................................................................ 12
Overview............................................................................................................... 13
TepanYaki .............................................................................................................. 13
Indicators............................................................................................................... 13
Using for the first time ........................................................................................ 14
Cleaning the CombiSet for the first time ............................................................... 14
Switching on the CombiSet for the first time ........................................................ 14
Power level range................................................................................................ 15
Operation.............................................................................................................. 16
Operating controls................................................................................................. 16
Switching on.......................................................................................................... 16
Switching off.......................................................................................................... 16
Residual heat indicator.......................................................................................... 16
Useful tips ............................................................................................................. 17
Cleaning and care ............................................................................................... 18
Frying surface........................................................................................................ 19
Stainless steel frame/control panel ....................................................................... 19
Operating controls................................................................................................. 19
Problem solving guide ........................................................................................20
Optional accessories ..........................................................................................21
Safety instructions for installation..................................................................... 22
Safety distances .................................................................................................. 23
Installation notes ................................................................................................. 24
Building-in dimensions .......................................................................................25
Building-in several CombiSets........................................................................... 26
Installation............................................................................................................ 28
Electrical connection ..........................................................................................32
After sales service, data plate, warranty........................................................... 34
2
Warning and Safety instructions
This appliance complies with all relevant safety requirements.
Inappropriate use can, however, lead to personal injury and
damage to property.
To avoid the risk of accidents or damage to the appliance, please
read these instructions carefully before installation and before
using it for the first time. They contain important notes on
installation, safety, use and maintenance.
Miele cannot be held liable for damage caused by non-compliance
with these Warning and Safety instructions.
Keep these instructions in a safe place and ensure that new users
are familiar with the content. Pass them on to any future owner.
3
Warning and Safety instructions
Correct application
This Tepan plate is designed for domestic use and for use in
similar environments by guests in hotel or motel rooms, bed &
breakfasts and other typical living quarters. This does not include
common/shared facilities or commercial facilities within hotels,
motels or bed & breakfasts.
This appliance is not suitable for outdoor use.
It is intended to cook food and keep it warm. Any other use is not
supported by the manufacturer and could be dangerous.
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning its use by a person responsible
for their safety, and are able to recognise the dangers of misuse.
4
Warning and Safety instructions
Safety with children
Young children must not be allowed to use this appliance.
Older children may use the appliance only when its operation has
been clearly explained to them and they are able to use it safely.
They must be aware of the potential dangers caused by incorrect
operation.
Children must not be allowed to clean the appliance
unsupervised.
Please supervise children in the vicinity of the appliance, and do
not let them play with it.
The appliance gets hot when in use and remains hot for a while
after being switched off. Keep children well away from the appliance
until it has cooled down and there is no danger of burning.
Danger of burning!
Do not store anything which might arouse a child's interest in
storage areas above or next to the appliance. Otherwise they could
be tempted into climbing onto the appliance.
Danger of suffocation! Children may be able to wrap themselves in
packing material or pull it over their heads with the risk of
suffocation. Keep children away from any packing material.
5
Warning and Safety instructions
Technical safety
Repairs and other work by unqualified persons could be
dangerous. Installation, maintenance work and repairs to electrical
appliances must only be carried out by a Miele approved service
technician.
A damaged appliance can be dangerous. Always check for visible
signs of damage. Never use a damaged appliance.
Reliable and safe operation of this appliance can only be assured
if it has been connected to the mains electricity supply.
The electrical safety of this appliance can only be guaranteed
when continuity is complete between it and an effective earthing
system. It is most important that this basic safety requirement is
present and tested regularly and, where there is any doubt, the
household wiring system should be inspected by a qualified
electrician.
Before connecting the appliance to the mains supply, ensure that
the connection data on the data plate (voltage and frequency) match
the mains electricity supply.
This data must correspond in order to avoid the risk of damage to
the appliance. Consult a qualified electrician if in any doubt.
Do not connect the appliance to the mains electrical supply by a
multi-socket adapter or extension lead. These are a fire hazard and
do not guarantee the required safety of the appliance.
For safety reasons, this appliance may only be used when it has
been built in.
This appliance must not be installed and operated in mobile
installations (e.g. on a ship).
Never open the casing of the appliance.
Touching or tampering with electrical connections or components
and mechanical parts is highly dangerous to the user and can cause
operational faults.
6
Warning and Safety instructions
The manufacturer's warranty will be invalidated if the appliance is
not repaired by a Miele approved service technician.
Faulty components must only be replaced by genuine Miele spare
parts. The manufacturer can only guarantee the safety of the
appliance when Miele replacement parts are used.
The appliance is not intended for use with an external timer switch
or a remote control system.
If the plug has been removed or the connection cable is not
supplied with a plug, the appliance must be connected to the mains
supply by a suitably qualified electrician.
If the mains connection cable is damaged, it must be replaced
with a special connection cable typeH05VV-F (PVC insulated),
available from Miele, by a Miele approved service technician or
suitably qualified electrician in order to avoid a hazard. See
"Electrical connection".
During installation, maintenance and repair work, the appliance
must be disconnected from the mains electricity supply. It is only
completely isolated from the electricity supply when:
– the mains circuit breaker is switched off, or
– it is switched off at the wall socket and the plug is withdrawn from
the socket. Do not pull the mains connection cable but the mains
plug to disconnect your appliance from the mains electricity
supply.
Danger of electric shock!
Do not use the appliance if it is faulty. Switch it off immediately,
disconnect it from the mains electricity supply and contact Miele.
7
Warning and Safety instructions
If the appliance is installed behind a furniture panel (e.g. a door),
ensure that the door is never closed whilst the appliance is in use.
Heat and moisture can build up behind a closed furniture panel and
cause subsequent damage to the appliance, the housing unit and
the floor. Do not close the door until the residual heat indicators have
gone out.
8
Warning and Safety instructions
Correct use
The appliance gets hot when in use and remains hot for a while
after being switched off. There is a danger of burning until the
residual heat indicators go out.
Due to the high temperatures radiated, objects left near the
appliance when it is in use could catch fire.
Do not use the appliance to heat up the room.
Oil and fat can overheat and catch fire. Do not leave the appliance
unattended when cooking with oil and fat. If it does ignite, do not
attempt to put the flames out with water.
Disconnect the appliance from the mains and use a suitable fire
blanket, saucepan lid, damp towel or similar to smother the flames.
Flames could set the grease filters of a rangehood on fire. Do not
flambé under a rangehood.
Spray canisters, aerosols and other inflammable substances can
ignite when heated. Therefore do not store such items or substances
in a drawer under the TepanYaki. Cutlery inserts must be heatresistant.
Do not heat up food in closed containers, e.g. tins or sealed jars,
on the appliance, as pressure can build up in the containers, causing
them to explode.
Do not cover the appliance, e.g. with a cover, a cloth or protective
foil. The material could catch fire, shatter or melt if the appliance is
switched on by mistake or if residual heat is still present.
When the appliance is switched on either deliberately or by
mistake, or when there is residual heat present, there is the risk of
any metal items left on the appliance heating up, with the danger of
burning. Depending on the material, other items left on the appliance
could also melt or catch fire. Do not use the appliance as a resting
place. Switch the appliance off after use.
9
Warning and Safety instructions
You could burn yourself on the hot Tepan plate. Protect your
hands with heat-resistant pot holders or gloves when handling hot
pots and pans. Do not let them get wet or damp, as this causes heat
to transfer through the material more quickly with the risk of scalding
or burning yourself.
When using an electrical appliance, e.g. a hand-held mixer, near
the TepanYaki, ensure that the cable of the electrical appliance
cannot come into contact with the hot Tepan plate. The insulation on
the cable could become damaged.
The appliance becomes very hot. Do not use plastic utensils. Even
heat-resistant plastic utensils are unsuitable.
Where several CombiSets are installed side by side:
Hot objects can damage the seal of the cover strip between the
appliances. Do not place hot pans near or on the cover strip.
10
Warning and Safety instructions
Cleaning and care
Do not use a steam cleaning appliance to clean the Tepan plate.
The steam could reach electrical components and cause a short
circuit.
11
