XT·60
DUAL BAND (PMR446/LPD) WALKIE-TALKIE
› Instruction Guide
<![endif]>* Depending on terrain
up to
10Km*
Content of the package
•2 transceivers with belt clip
•1 USB cable
•1 double fast desktop charger
•2 rechargeable battery packs 700mAh
Coverage (referred to PMR frequency band)
The maximum range depends on terrain condition and is obtained during use in an open space.
The only limitation to maximum possible range are environmental factors such as blockage caused by trees, buildings, or other obstructions. Inside a car or a metallic constructions, the range can be reduced. Normally the coverage in the city, with buidings or other obstructions is about 1 or 2 Km. In open space but with obstructions like trees, leafs or houses the maximum possible range is about 4-6 Km. In open space, without obstructions and in sight, like for example in mountain, the coverage can be 10 Km.
XT60 user’s manual |
| 1 |
Main functions
•Dual Band LPD/PMR transceiver
Channels: 24 PMR446 (8+16 pre-programmed) + 69 LPD
•Side Tone: end transmission noise mufer
•LCD display with backlight
•Low battery indicator
•Auto power save: automatic current economy circuit
•38 CTCSS and 83 DCS tones in TX and RX
•CALL button with 5 tones selectable
•Battery life up to 12 hours
•Automatic squelch adjustment
•Buttons for the channel selection
•SCAN function
•Keypad lock
•Hi/low power selection (PMR band)
•Roger Beep on/of
•VOX for hands-free communications with 9 selectable levels
•2 Pin jack for ext. mike / ext. speaker
•USB port to recharge the radio
The manufacturer, with its efort to constantly improve product quality, reserves the right to change characteristics and features without prior notice.
2 | |
XT60 user’s manual |
Above all….Safety!
Warnings
!Do not open the radio for any reason! The radio’s precision mechanics and electronics require experience and specialized equipment; for the same reason, the radio should under no circumstances be realigned as it has already been calibrated for maximum performance. Unauthorized opening of the transceiver will void the warranty.
!Do not use detergents, alcohol, solvents, or abrasives to clean the equipment. Just use a soft, clean cloth. If the radio is very dirty, slightly dampen the cloth with a mixture of water and a neutral soap.
Batteries
!Do not try to charge alkaline batteries or non rechargeable batteries. Make sure that when you charge the radio, only rechargeable NI-MH batteries should be contained in the battery compartment! It is very dangerous attempting to recharge other types of batteries (for example alkaline or manganese batteries). Batteries which are not suitable to be recharged may leak, explode or even burn and cause damage!
!Using a diferent battery charger other than the one specified can cause damage to your device or may even cause explosions and personal injuries.
!Do not throw batteries into fire or place them near heat as this may cause explosions or personal injuries. Dispose of the batteries according to procedures set out by local regulations.
!Do not mix old and new batteries or batteries of diferent types or batteries which have been used in diferent manners.
XT60 user’s manual |
| 3 |
Identifying the parts
3 |
4 |
6 |
2 |
|
|
|
|
|
|
7 |
|
|
|
H L |
||||
|
|
|
5 |
||||
|
|
|
|
||||
|
|
|
|
||||
|
|
|
|
DCSCTCSS |
|||
|
|
|
|
|
|
|
8 |
1 9
10
11
|
<![if ! IE]> <![endif]>XT60 |
|
12 |
17 |
|
MON |
18 |
|
CALL MENU |
||
13 |
SCAN |
|
|
|
|
|
|
16 |
|
|
16 |
14 |
|
|
20 |
|
|
|
|
15 |
|
|
|
19
21
4 | |
XT60 user’s manual |
LCD Display
1.Selected channel (P1-P8/9P-24P: PMR446 /1-69:LPD)
2.VOX - Function activated
3.
- Keypad lock activated
4.
- Battery status indicator
5.H/L - Indicates the high / low power selection in transmission (only in PMR band)
6.RX - Radio in rx mode (busy channel)
7.TX - Radio in transmission (PTT pressed)
8.DCS/CTCSS - Type of sub-audio tone selected
9.Code of the selected CTCSS or DCS tone
(CTCSS: 1-38; DCS: 1-83)
Transceiver
10.Antenna
11.OFF/VOLUME knob - To switch on/of the radio and to adjust the volume.
12.PTT - Press to transmit.
13.CALL/
– to send a call to the selected channel. If you keep it pressed for about 3 seconds, the keypad lock is activated.
14.MIC - Built-in microphone
15.Built-in Speaker.
16.▲▼ controls - To change the settings in the MENU.
17.MENU - Press this control to enter the radios MENU
18.MON/SCAN - Press this button once to activate SCAN. Keep it pressed for about 2 seconds to activate the Monitor function, that temporarily cuts of the squelch (for weak signals)
19.SPK | MIC (under the protective cover) - To connect to external audio devices such as microphones, headphones, etc
20.USB port for the recharge of the radio
21.Battery compartment: insert the rechargeable battery pack supplied in the package or 3 x AAA batteries (alkaline or rechargeable).
