PD4298HD

Marantz’s PD4298HD Widescreen High
Definition Plasma Monitor sets a new
standard in plasma TV display image quality,
incorporating leading-edge digital video
technologies that enable it to display images
with true HDTV resolution. The PD4298HD
delivers images of unprecedented clarity,
brightness, contrast and color resolution
from a 42-inch widescreen (16:9) display,

and accepts the input from virtually any
digital and analog video source including the
output from a computer up to SXGA
resolution. With a super-slim chassis less
than 3-1/2 inches deep, the Marantz
PD4298HD offers unmatched installation
flexibility, with far more placement options
than conventional TVs including wall-or
ceiling mounting.

Feature

♦ 42-inch widescreen 16:9 plasma screen

♦ Highest-resolution 1024 x 1024 pixel array

♦ Exclusive image-enhancement technologies

including built-in line doubler for NTSC
sources

♦ Accepts input from virtually all video sources

including computers

♦ Slim-profile chassis design

♦ 160-degree viewing angle

♦ Variety of aspect ratio and picture preference

modes

♦ Multi-language on-screen menu and full-

function remote

Benefit

➣ HDTV programs and widescreen DVD

movies can be viewed in their original
widescreen aspect ratio with powerful
big-screen impact

➣ Best-possible image quality with true 480p,

720p and 1080i HDTV resolution

➣ Displays exceptionally lifelike and detailed

picture quality

➣ Displays NTSC, PAL and SECAM formats as

well as computer images

➣ Allows space-saving installation options

including wall mounting

➣ Provides a bright, high-quality picture from

virtually any viewing location

➣ Allows optimum display of any video source

to the user’s preference

➣ Easy, intuitive operation of all functions

Widescreen High Definition Plasma Monitor

We'll Open

Your Eyes.

Specifications

42" High Defintion Plasma Monitor PD4298HD

Screen size: 36.3"H x 20.4"V

921mm x 518.4mm

diagonal 42"
Aspect ratio 16:9
Resolution 1024(H) x 1024(V) pixels
Pixel pitch 0.04"H x 0.02"V

0.9mm x 0.51mm

Brightness 250 cd/m

2

Contrast 350:1
Color reproduction 256 levels, 16,777,216 colors
Signals:
Synchronization Horizontal: 15.5 to 80.5kHz
Range (automatic: step scan)

Vertical: 50.0 to 75Hz

(automatic: step scan)

Input signals RGB, NTSC (3.58/4.43),

PAL (B,G,M,N),
PAL60, SECAM,

HD*1, DVD*1, DTV*

1

Input terminals:

Component video inputs 1 (video-2)
S-video inputs 1 (video-1)
Composite video inputs 1 (video-1)

HD component/RGB HV input 1 (RGB-2)
RGB input (D-sub 15) 1 (RGB-1)
Audio inputs (stereo)

4 (video-1, video-2, RGB-1, RGB-2)
Speaker terminals 1 (stereo)
External control input (RS232C) 1

General:

Sound output 8W+8W at 6ohm
Power supply AC100-120V 50/60Hz
Current rating 5.0A(maximum)
Power consumption 450W(typical)
Dimensions 41"W x 25.5"H x 3.5"D

1048mm x 648mm x 89mm
Weight 75lbs/34kg
*1DVD/HD/DTV input signals supported on
this system
480P (60Hz) 480I (60Hz)
525P (60Hz) 525P (60Hz)
625P (50Hz) 625P (50Hz)
720P (60Hz) 720P (60Hz)

1080I (60Hz)

*2It doesn't cope with copy protection.

Note: The specifications and design of this product are

subject to change without notice.

440 Medinah Road ~ Roselle, Illinois 60172 ~ phone [phone] fax [phone]

Locate an authorized dealer in your area at: www.marantz.com

Macintosh is a registered trademark of Apple Computer, Inc.

Windows 95/98 and Windows NT are registered trademarks of the Microsoft Corporation.

DTV is a registered trademark of ATSC Laboratories.
