R

Model DR4050 User Guide

Compact Disc Recorder

Recordable

ReWritable

DR4050N cover 1-4

Page 1

00.7.11, 10:37 PM Adobe PageMaker 6.5J/PPC

DR4050U (GENERAL)

Page 10

00.7.11, 10:14 PM Adobe PageMaker 6.5J/PPC

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product.

WARNING

T O R E D U C E T H E R I S K O F F I R E O R E L E C T R I C S H O C K , DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

ATTENTION: POUR ÉVITER LES CHOCS ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPON DANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.

NOTE:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

NOTE:Changes or modifications may cause this unit to fail to comply with Part 15 of the FCC Rules and may void the user's authority to operate the equipment.

LASER SAFETY

This unit employs a LASER. Only a qualified service person should remove the cover or attempt to service this device, due to possible eye injury.

CAUTION-USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURE OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

This Class B digital apparatus meets all requirements of the Canadian InterferenceCausing Equipment Regulations.

Cet appareil numérique de la Classe B respecte toutes les exigences du Règlement sur le materiel brouilleur du Canada.

INPORTANT SAFETY

INSTRUCTIONS

READ BEFORE OPERATING EQUIPMENT

This product was designed and manufactured to meet strict quality and safety standards. There are, however, some installation and operation precautions which you should be particularly aware of.

1.Read Instructions — All the safety and operating instructions should be read before the appliance is operated.

2.Retain Instructions — The safety and operating instructions should be retained for future reference.

3.Heed Warnings — All warnings on the appliance and in the operating instructions should be adhered to.

4.Follow Instructions — All operating and use instructions should be followed.

5.Water and Moisture — The appliance should not be used near water — for example, near a bathtub, wash-bowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool, etc.

6.Carts and Stands — The appliance should be used only with a cart or stand that is recommended by the manufacturer.

7.An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn.

8.Wall or Ceiling Mounting — The appliance should be mounted to a wall or ceiling only as recommended by the manufacturer.

9.Ventilation — The appliance should be situated so that its location or position does not interfere with its proper ventilation. For example, the appliance should not be situated on a bed, sofa, rug, or similar surface that may block the ventilation openings; or, placed in a built-in installation, such as a bookcase or cabinet that may impede the flow of air through the ventilation openings.

10.Heat — The appliance should be situated away from heat sources such as radiators, heat registers, stoves, or other appliances (including amplifiers) that produce heat.

11.Power Sources — The appliance should be connected to a power supply only of the type described in the operating instructions or as marked on the appliance.

12.Grounding or Polarization — The precautions that should be taken so that the grounding or polarization means of an appliance is not defeated.

AC POLARIZED PLUG

13.Power-Cord Protection — Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance.

14.Cleaning — The appliance should be cleaned only as recommended by the manufacturer.

15.Nonuse Periods — The power cord of the appliance should be unplugged from the outlet when left unused for a long period of time.

16.Object and Liquid Entry — Care should be taken so that objects do not fall and liquids are not spilled into the enclosure through openings.

17.Damage Requiring Service — The appliance should be serviced by qualified service personnel when:

A.The power-supply cord or the plug has been damaged; or

B.Objects have fallen, or liquid has spilled into the appliance; or

C.The appliance has been exposed to rain; or

D.The appliance does not appear to operate normally or exhibits a marked change in performance; or

E.The appliance has been dropped, or the enclosure damaged.

18.Servicing — The user should not attempt to service the appliance beyond that described in the operating instructions. All other servicing should be referred to qualified service personnel.

TABLE OF CONTENTS

Table of contents



GENERAL INFORMATION AND DISCS



Unpacking.....................................................................

6

Setup ............................................................................

6

Compact discs ..............................................................

6

Maintenance ................................................................

7

About this manual........................................................

7

CONTROLS AND CONNECTIONS



Controls on the front....................................................

8

Connections at the back ..............................................

9

DISPLAY



DISPLAY indications.....................................................

9

DISPLAY messages ....................................................

10

MENU messages........................................................

11

INSTALLATION



Connections general ..................................................

11

Analog connections CD recorder & CD player ..........

12

Analog connections CD player deck ..........................

12

Digital coaxial connections CD recorder ...................

13

Digital optical connections CD recorder....................

13

Power supply..............................................................

14

Setup recommendations ............................................

14

Inserting batteries in the remote control ..................

14

REMOTE CONTROL



Remote control commands ........................................

15

Inserting discs ............................................................

15

RECORDING



Remarks about recording...........................................

16

Recording modes........................................................

16

High speed recording from internal CD player..........

17

Listen mode recording from internal CD player ........

18

Manual recording from external CD player...............

19

Autostart recording from external



CD player - CD-SYNC.................................................

20

Finalizing CDR & CDRW discs ...................................

21

Unfinalizing CDRW discs ...........................................

21

Erasing CDRW discs ..................................................

22

PLAYING



Play a 2-disc changer (Changer mode) ......................

23

Playing CDs on Deck 1 and/or Deck 2 (DJ mode) .....

23

Selecting a track ........................................................

24

Search ........................................................................

24

Shuffle (random order) play .......................................

25

Repeat CD, track or program .....................................

25

PROGRAMMING



Remarks about programming.....................................

26

MENU MODE/CD TEXT INPUT



Remarks about Menu mode.......................................

27

General operation of Menu .......................................

27

A.Text input ...............................................................

28

B. Erasing text ............................................................

28

C. Reviewing CD Text memory...................................

29

D.Auto track increment..............................................

30

E. Balance...................................................................

30

FIXING PROBLEMS



Troubleshooting .........................................................

31

English

5

GENERAL INFORMATION

English

Congratulations on the acquisition of your CD-Recorder. This CDRecorder now enables you to record, play and erase your own audio Compact Discs. Naturally the recorder can also be used to play all pre-recorded CDs.

With the exception of legal restrictions pertaining to copying, you can now create your own high-quality audio recordings on CD. The discs used to record must bear the logos shown below. Copyright fees have been paid on these discs in some countries. Recording on other types of discs (e.g. CD-R for professional recordings) is not possible.

There are two types of recordable AUDIO discs:

CD-R(W) discs have a compatibility to play/record on the CDRecorders based on the ORENGE BOOK Part II/III. But the discs might not be able to be played/recorded properly depending on the combinations of the discs and CD-Recorders.

1CD Recordable Audio (record once):

Fully recorded and subsequently finalized audio CD-R discs can be played on all CD players and recorders that are suitable for CD-R discs. A CD-R disc can be recognized by the following logo:

Recordable

Recordable



2CD ReWritable Audio (multiple recording):

Recorded and finalized audio CD-RW discs can be played on all CD players and recorders that are suitable for CD-RW discs. An increasing number of players and recorders will be suitable for these discs in the future. A CD-RW disc can be recognized by the following logo:

ReWritable

ReWritable

The CD-R(W)disc for ‘DIGITAL AUDIO’ can be both recording and playing on this CD-Recorder. In addition, this CD-Recorder can play the CD-R(W) disc for ‘PROFESSIONAL RECORDING’, but cannot record it.

Once you start using the recorder, you will discover how easy it is to ‘make’ your own CDs. Nevertheless, we recommend that you use an erasable (CD-RW) digital audio disc on your first attempt, while following the instructions given here.

Attention!

Recordings may only be made for personal use.

It is forbidden to copy material protected by copyright, including computer programs, films, television and audio recordings. This appliance may not be used for applications of this type.

Note: Some CD players can not play the finalized CD-R(W) discs because of the low reflectivity of such discs.

Because of laser power differences, some DVD players cannot play the finalized CD-R(W) discs.

Read the text carefully and keep the instructions close at hand so that you can refer to them if necessary.

6

Unpacking

First check the contents of the packaging. It should contain the following:

-CD-Recorder DR4050

-Remote control with batteries packaged separately

-Audio cables (2 - with red and white plugs)

-Power cord

-Instructions

-Guarantee

If one of these components is missing, please inform your supplier immediately. Save the packaging material it may come in handy if you move the appliance.

Setup

-Place the recorder on a strong, vibration-free surface.

-Do not use the recorder under extremely damp conditions.

-If the recorder is placed in a cabinet, make sure that a 2.5 cm space remains free on all sides of the recorder for proper ventilation.

Attention!

If the appliance is not used or operated in accordance with the instructions, this may result in exposure to dangerous radiation or other risks.

Only authorized technicians are allowed to open the appliance casing or to perform repairs or maintenance.

Compact discs

The glossy side shining like a rainbow is the front side of the disc, and the side on which the label is printed is the back.

Unlike conventional turntables for playing analog discs, the DR4050 reads the information recorded on the disc from underneath without contacting it using a beam of laser light. Therefore, the performance of a compact disc will not degrade like conventional analog records.

Handle discs carefully so as not to damage or scratch the front side.

To protect the disc, avoid placing it in the following locations:

-In direct sunlight or near a source of heat like a heater.

-In a place which is damp or dirty.

-In a place which could be exposed to rain, such as near a window.

Always keep the disc surface clean.

Up to six billion data units are recorded on the front side of the disc. When cleaning the disc surface, always be sure to use a special compact disc cleaner and wipe as shown below.

Do not use conventional record cleaner for analog records, as this will adversely affect the disc surface.

Store discs properly by placing them in their disc cases.

DR4050U (GENERAL)

Page 6

00.7.11, 10:14 PM Adobe PageMaker 6.5J/PPC

GENERAL INFORMATION AND DISCS

Do not attach a piece of paper or sticker on the label side of disc. When a disc has a piece of plastic tape or rental CD label with paste protruded from the edge or when a disc has a trace of such a sticky object, do not attempt to play the disc. If such a disc is played on the CD player, impossibility of taking out the disc or other malfunction may result.

Write only on the printed side of a CD-R or CD-RW, and only with a soft felt-tipped pen.

Do not use a disc with a special shape.

Do not attempt to play a disc with a special shape such as a heartshaped disc or octagonal disc. Otherwise the equipment malfunction may result.

About this manual

This manual gives instructions for operating this CD recorder where:

-the figures (1) throughout the text indicate a sequence of actions necessary to perform a certain operation;

-the arrows ( ) indicate the reaction from the recorder;

-the dots (•) indicate remarks, advice or special options within a sequence of actions. The dot-marked instructions are not necessary for the required operation.

English

Maintenance

Clean the CD-Recorder with a soft, slightly dampened lint-free cloth.

Do not use any cleaning agents as they may have a corrosive effect.

Do not expose the CD-Recorder, batteries or CDs to humidity, rain, sand or excessive heat (caused by heating equipment or direct sunlight).

If the CD-Recorder cannot read CDs correctly use a commonly available cleaning CD to clean the lens before taking the CD player to be repaired. Other cleaning methods may destroy the lens. Always keep the tray closed to avoid dust on the lens.

The lenses may cloud over when the CD-Recorder is suddenly moved from cold to warm surroundings. It is not possible to play a CD then. Leave the CD-Recorder in a warm environment until the moisture evaporates.

7

DR4050U (GENERAL)

Page 7

00.7.11, 10:14 PM Adobe PageMaker 6.5J/PPC

CONTROLS AND CONNECTIONS

English

4

5

6

7

8

9

10

11

12

13





14



15



16

17 18 19

20

21

22



































EASY JOG

























CD RECORDER DR4050























+

STORE

CANCEL













OPEN/CLOSE PLAY/PAUSE

STOP































PLAY/PAUSE

STOP

OPEN/CLOSE









REC TYPE

REC

FINALIZE ERASE

SOURCE

CD-R









CD











/MENU

/DELETE

































































































PUSH ENTER























ON/OFF































































































PHONES













STANDBY









PROG

SHUFFLE DISPLAY SCROLL

REPEAT DJ MODE































3

1



2









31 30 29 28 27 26

















24





25

23







MAINS

















CD





CDR

CDR

CDR



CDR



CDR



































CD



CD















































































L





L





L









































R





R





R









































OUT

OUT





IN

OUT

IN





OUT



IN































ANALOG DIGITAL





ANALOG

DIGITAL



OPTICAL











1















2





3

4



5

6





7



8





Controls on the front

CD recorder



1 ON/OFF ........................

turns the CD recorder ON or OFF (if



the recorder is in Standby mode,



any key press will activate the CD

2 Standby indicator

recorder)



3 Disc tray



4 OPEN/CLOSE /..........

opens/closes disc tray

5 PLAY/PAUSE 2 ; ......

starts play/interrupts play or

6 STOP 9

recording

stops/clears a program

7 REC(ord) TYPE ............

selects recording modes

8 REC(ord) ......................

starts recording, finalizing, erasing

9 FINALIZE ....................

selects finalize mode

0 ERASE..........................

selects erasing mode (disc or track)

! SOURCE ......................

selects external input source

@ CDR ............................

selects CD recorder deck



display/keys

CD player



$ CD ..............................

selects CD player deck

) PLAY/PAUSE 2 ;

display/keys

starts play/interrupts play

Á STOP 9........................

stops/clears a program

ª OPEN/CLOSE /..........

opens/closes disc tray

£ Disc tray



General



# Display..........................

information screen

% Q ............................

- searches backward



- cursor control in Menu/Prog.



review mode

^ R ............................

- searches forward



- cursor control in Menu/Prog.



review mode

& – EASY JOG + ........

- previous/next track (Play and

(rotate)

Program mode)



- recording level control (recording)

PUSH ENTER

- selects settings (menu on)

- plays selected tracks



- selects settings in Menu mode

* STORE/MENU

- programs track numbers

- stores Menu settings



- enters Menu mode

(CANCEL/DELETE ......- deletes tracks from a program

-deletes text in Menu mode

-returns to a higher level in the menu

² IR sensor ....................

receives signals from the remote

° PHONES

control

socket for headphones

¤ DJ MODE ....................

separate play of CD recorder deck

³ REPEAT

and CD player deck

repeats play (All, program or track)

¥ SCROLL........................

activates scrolling of text over the

» DISPLAY

display (once)

selects display information,

¼ SHUFFLE

permanent text scrolling and time

plays CD(RW) or program in

Ú PROG(ram)

random order

opens/closes program memory

Note: Unless stated otherwise, all controls are on the front of the CD recorder. When provided on the remote control, you can also use the corresponding buttons, after selecting the CD recorder deck or CD player deck by pressing CDR or CD.

8

CONTROLS AND CONNECTIONS

DISPLAY

Connections at the back

1 Connection to mains



2 ANALOG OUT (CD)

....connects CD player deck to the



line input of an amplifier (left and

3 DIGITAL OUT (CD)

right)

....connects CD player deck to the



digital coaxial input of e.g.

4 ANALOG IN (CDR)

amplifier or recording device

connects to the line output of an



amplifier (left and right)

5 ANALOG OUT (CDR & CD)

......................................

connects to the line input of an

6 DIGITAL IN (CDR)

amplifier (left and right)

connects to the digital coaxial



output of an external CD player

7 DIGITAL OUT (CDR & CD)

......................................

connects to the digital coaxial



input of e.g. amplifier or recording

8 OPTICAL IN (CDR)

device

connects to the digital optical



output of an external CD player

DISPLAY indications





1



2



3

4



5



6





REM

REC

TIME TRACK



TOTAL REM

TRACK TIME





STEP



27























7

1 2

3 4

5

6 7

8

9 10 11 12 13 14 15 16 17 18 19 20



+

8

26



SYNC MANUAL









RECORD



PROG





9

25















DIGITAL I





CD





CHANGER

CD

SHUFFLE

ALL



24









10

OPTICAL I





RW







RW

REPEAT

TRACK



ANALOG















SCAN





23

22 21 20 19 18

17 16

15 14 13 12 11







1 REM/REC TIME

..........remaining time/remaining

2 TRACK

recording time/recording time

track number

3 FE..............................

balance (lights during balance

4 TOTAL REM

adjustment)



TRACK TIME ..............

total or remaining time of disc or



track

5 }................................

remote control active

6 STEP ............................

indicates the number of tracks in a

7 Track bar

program

indicates:

-tracks on a disc or in a program

-track in play

8 + 20 ..............................

disc or program contains more

9 PROG(ram)

than 20 tracks

flashes during programming/lights



in program mode

0 REPEAT TRACK/ALL..lights up when a track/ complete

! SCAN

disc (or program) is repeated

lights up when the first 10

@ SHUFFLE

seconds of each track are played

plays tracks in random order

# s ..............................

CD player deck selected

$ c..............................

CD inserted (a pre-recorded CD or

% fRECORDg

finalized CDR or CDRW disc)

lights during recording from the

^ L/R ; ;

internal CD

record/play level bar. Indicates the



audio signal level

& j k ........................

DJ mode selected

* iCHANGERh ........

changer mode selected

( ; ..................................

pause function active

) B ................................

lights during play

Á R(W) ............................

unfinalized CDR(W) disc inserted

ª 0 ................................

lights during recording

£ ANALOG......................

- analog input selected for



external recording

² OPTICAL I

- analog recording

optical input I selected for external

° DIGITAL I

recording

digital input I selected for external

¤ SYNC

recording

automatic or synchronised start of

³ MANUAL

external recording

manual start of external recording

English

9

English

DISPLAY

DISPLAY messages

Messages, as listed and explained here, may appear on the display for your guidance.

General

reading disc information

READING..........................

OPEN..................................

during tray opening

CLOSE ..............................

during tray closing

NO DISC..........................

no disc inserted, disc unreadable



or disc inserted upside down

PROG FULL ....................

program full

INSERT DISC ..............

insert disc or insert disc in correct



way

WRONG DISC..................

inserted disc is not an audio CD

UNFINALIZED ..............

unfinalized CDR(W) disc

MEMORY XX•............

indicates the amount of text



memory used for unfinalized discs

Recording



WAIT..................................

- when STOP 9 is pressed during



recording



- when STOP 9 is pressed during



recording the first 4 seconds of a



track

UPDATE ..........................

updating disc contents

DISC FULL ....................

no more recording possible

DIGITAL 1 ....................

digital coaxial input 1 selected

OPTICAL ........................

digital optical input selected

ANALOG ............................

analog input selected

COPY PROTECT ............

no digital recording can be made



of the external source

NOTFINALIZED ............

when opening the tray with an



unfinalized disc inserted



(CD recorder)

RECORD FAST ..............

high speed recording selected

REC LISTEN..................

listen speed recording selected

MAKE CD..........................

high speed recording of a



complete disc and Auto Finalize



function selected

REC EXT DISC ............

synchronised start of recording



from external source selected

REC EXT MAN................

manual start of recording from



external source selected

_XX DB ............................

level is being adjusted

DOES NOT FIT ............

time left on CDR(W) disc is not



enough for proposed recording

ANALOG REC..................

copy prohibited track found during



recording. Track will be copied



analog (Copy Protection



Regulations)

ERASE TRACK ..............

when erasing one or more tracks

ERASE DISC..................

when erasing a disc

FINALIZE CD ..............

when finalizing a disc

FINALIZED ....................

when trying to finalize an already



finalized disc

CHECK INPUT ..............

when RECORD is pressed while no



digital source is detected

XX XX ERASE................

time countdown when erasing a



track or a disc

XX XX FINAL................

time countdown when finalizing a



disc

PRESS RECORD ............

to start manual recording,



finalizing or erasing

START SOURCE ............

to start synchronised recording



from a source (e.g. CD player)

FINALIZED CD ............

when trying to record on a



finalized CDR or a prerecorded CD

UNFINALIZE/ ................

when trying to record on a

PRESS ENTER

finalized CDRW

PROF SOURCE ..............

when a professional source is



connected

REC TEXT ......................

when reading CD text from source



disc for recording

TEXT PROTECT ............

when CD text of source disc is



subjected to copy protection (CD



text will not be recorded)

Play

CD changer-mode selected

CHANGER MODE ............

DJ MODE..........................

DJmode selected when recording



keys are pressed in DJ-mode

PROGRAM..........................

program mode selected

ALBUM TITLE ..............

will be followed by album title

TRACK TITLE ..............

will be followed by track title

ALBUM ARTIST ............

will be followed by artist name

TRACK ARTIST ............

will be followed by track artist



name

Others

when the recorder enters a data

NO AUDIO TR................



track during recording

FINALIZE CD ..............

laser power calibration performed



96 times, finalize disc needed

INITIALIZING ............

during laser power calibration for



unfinalized discs

DISC RECOVER ............

during disc recovering after power



failure

OPC ERROR ....................

OPC failure during OPC procedure



(OPC = Optimum Power



Calibration)

RECORD ERROR ............

recording error in menu mode

DISC ERROR..................

when trying to record on or finalize



a recovered disc

MEMORY FULL/ ..............

when text memory is full. To add a

FINALIZE CD

CD to the list, first finalize or



erase another disc from the list

NOT POSSIBLE ............

when trying to erase a CDR

10

DISPLAY

INSTALLATION

MENU messages - See Menu mode

REM

REC

TIME TRACK

TOTAL REM

TRACK

TIME





STEP

























EASY JOG





















+

STORE

CANCEL





















/MENU

/DELETE



















PUSH ENTER





SYNC MANUAL



RECORD





PROG











DIGITAL I



CD

CHANGER



CD

SHUFFLE

ALL







OPTICAL I



RW





RW

REPEAT

TRACK







ANALOG







SCAN























Menu messages

when attempting to edit text for a

NO TRACKS ....................



disc which has no tracks

TEXT EDIT ....................

when entering Text Edit mode

ALBUM ARTIST ............

when editing or erasing an artist



name

ALBUM TITLE ..............

when editing or erasing a title

ARTIST TR N................

when editing or erasing an artist



name per track

TITLE TR N ..................

when editing or erasing a title per



track

TEXT ERASE..................

when entering Text Erase mode

ALL TEXT ......................

when entering All Text mode

ERASE OK ......................

when confirmation for erasing has



to be given with ENTER key

ERASE ALL OK ............

when confirmation for erasing has



to be given with ENTER key

ERASE MEMORY ............

when waiting for confirmation



when erasing a disc

MEMORY VIEW ..............

when selecting text review per



unfinalized disc in memory

MEMORY EMPTY ............

when REVIEW is selected while no



text is in memory

AUTO TRACK..................

when selecting auto track



increment ON or OFF

ON ......................................

auto track increment on

OFF ....................................

auto track increment off

SET BALANCE ..............

when selecting BALANCE

NO TEXT..........................

no text stored for disc

Connections general

For playback on the CD recorder (and/or CD player deck) the following outputs are present:

-Digital coaxial output (CD & CDR);

-Analog output (CD & CDR).

We advise you to connect these to the TAPE or CDR input on your amplifier.

For external recording the following inputs are present:

-Digital optical input;

-Digital coaxial input;

-Analog input.

For playback of CD player deck separately (DJ mode) from the CD recorder the following outputs are present:

-Digital coaxial output (CD);

-Analog output (CD).

We advise you to connect these to the CD input on your amplifier.

The connections you make will depend upon the possibilities your audio equipment offers. Please refer to the user manuals for your other audio equipment first.

Digital recordings (optical or coaxial) give the best performance in audio and usability (e.g. auto-track).

(The digital optical connection is less sensitive to external disturbances).

If your equipment does not offer digital connections, the high quality Analog-Digital-Convertor of your CD recorder will ensure very good audio performance when recordings are made from the analog input.

Playback via the digital coaxial output of the CD recorder gives the best audio performance.

If your equipment does not offer digital connections, the high quality Digital-Analog-Convertor of the CD recorder ensures a very good sound quality via the analog output.

We advise you to always establish both digital and analog connections. In this way you can always make analog recordings when digital recording is not possible.

We have described the most common ways of connecting the CD recorder. If you still have difficulties with the connections you can always contact the Marantz Consumer Service desk in your country.

English

11

English

INSTALLATION

Analog connections CD recorder & CD player



Analog connections CD player deck

This connection must be made for playback on the CD

This connection is only required if you want to playback on

recorder deck as well as the CD player deck (cable 2).

the CD player deck seperately from the CD recorder deck. This

Cable 1is only required if you want to make recordings from

will be the case in DJ-mode.

an external analog source.

































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































Use the audio cables supplied. Connect the red plugs to the R sockets, and the white plugs to the L sockets.

1 For recording, connect cable 1between the ANALOG INsockets on the CD recorder and the CDR LINEor TAPE OUTsockets of an amplifier.

Note: For recording directly from a CD player, the analog input of the CD recorder should be connected to the analog output of the CD player.

2 For playback, connect cable 2between the ANALOG OUTsockets on the CD recorder and the input sockets of an amplifier e.g. TAPE IN, CDR or AUX.

Note: Never use the PHONO input.

1 For separate playback on the CD player deck, connect a third cable 3(not supplied) between the ANALOG OUT sockets of the CD recorder and the input sockets of an amplifier e.g. CD, or AUX.

(Connect the red plugs to the R sockets, and the white plugs to the L socket.)

Note:

-Never use the PHONO input.

-Your CD recorder/player is equipped with a digital coaxial output for the CD player deck. This output can be used for digital playback.

12

INSTALLATION

Digital coaxial connections CD recorder

This connection is only required if you want to make recordings from an external CD player with a digital coaxial output.

Use the optional digital coaxial cable.

1 For external recording, connect the cable 4between the DIGITAL IN-socket on the CD recorder and the DIGITAL OUTsocket of an external CD player.

Note: Your CD recorder is equipped with a digital coaxial output (common output for CD recorder & CD player deck). This output can be used for digital playback.

Digital optical connections CD recorder

This connection is only required if you want to make recordings from an external CD player with a digital optical output.

When connecting the Digital Optical cable, make sure it is fully inserted until

there is a click.

1 Remove the dust caps from the digital optical connection. (We recommend you save the cap.)

2 For external recording, connect a fibre-optic cable 5 between the digital optical input of the CD recorder and the digital-optical output of an external CD player.

Note: For playback, the digital coaxial outputs or analog outputs of the CD Player and CD recorder should be connected to an amplifier.

English

13

English

INSTALLATION

Power supply

Inserting batteries in the remote control

1 Plug the power cord supplied into the MAINS connector on the CD recorder, then into a mains socket.

2 Press ON/OFF.

The CD recorder will switch on.

Note:

-If the CD recorder is in Standby mode (red led on), press any key to activate the recorder.

-The CD recorder will automatically adjust to the local mains voltage.

-When the CD recorder is in the ‘OFF’ position, it is still consuming some power. If you wish to disconnect your player completely from the mains, withdraw the plug from the AC outlet.

Setup recommendations

-Place the CD recorder on a solid, vibration free surface.

-Do not place the CD recorder near a source of heat or in direct sunlight.

-Do not use the CD recorder under extremely damp conditions.

-If the CD recorder is placed in a cabinet, make sure that a 2.5 cm space remains free on all sides of the CD recorder

for proper ventilation.

Important:

-Do not put the CD recorder on top of other equipment that heats up the CD recorder (e.g. receiver or amplifier).

1 Open the battery compartment cover.

2 Insert 2 batteries (“AA”, LR-6 or UM-3; as supplied) as shown.

3 Replace the cover.

Note: We recommend you use 2 batteries of the same type and condition.

Batteries contain chemical substances, so they should be disposed of properly.

14

REMOTE CONTROL

Remote control commands

SCAN

SHUFFLE

REPEAT

ABC

DEF

GHI

1

2

3

JKL

MN

OPQ

4

5

6

RST

UVW

XYZ

7

8

9

TRACK INCR.

SPACE

SCROLL



0



CDR



CD

2

° ¤

9

56



;



MENU/

ENTER CANCEL

PROG.

STORE





REMOTE CONTROLLER





RC4050DR



STANDBY B....................

switches to Standby/On

SCAN ................................

plays the first 10 seconds of each

SHUFFLE

track

plays CD(RW) or program in

REPEAT

random order

repeat play

Number/alphabet keys 0 - 9

......................................

- selects a track by number

TRACK INCR(ement)

- selects character for text input

increases track numbers during

SPACE

recording

inserts a space character during

SCROLL

text input

activates scrolling of text over the

CDR

display

selects CD recorder deck

CD ......................................

selects CD player deck

2 ......................................

starts CD(RW) play

° ......................................

- previous track (Play and Program



mode)



- cursor control in Menu/Prog.



review mode

¤ ......................................

- next track (Play and Program



mode)



- cursor control in Menu/Prog.



review mode

9 ......................................

stops CD(RW) and clears a



program

Q....................................

searches backward

R....................................

searches forward

; ......................................

interrupts CD(RW) play/recording

MENU/STORE ..................

- enters Menu mode

PROG.(ram)

- stores Menu settings

opens/closes program memory

ENTER ................................

- selects settings in Menu mode



- programs track numbers

CANCEL

- starts playback of selected track

- deletes tracks from a program



- deletes text in Menu mode



- returns to a higher level in the



menu

Inserting discs

1 Press OPEN/CLOSE to open the disc tray.OPEN lights up.

2 Insert a CD, CDR or CDRW in the appropriate recess in the tray, label side up.

3 Press OPEN/CLOSE to close the tray (see also Playing a CD).CLOSE lights up, followed by READING and the

display will show the type of disc you inserted.

REM REC

TIME TRACK

TOTAL REM

TRACK TIME

STEP

SYNC MANUAL



RECORD



PROG

DIGITAL I

CD

CHANGER

CD

SHUFFLE ALL

OPTICAL I

RW



RW

REPEAT

ANALOG



SCAN TRACK







•If you insert a blank or partly-recorded CDR or unfinalized CDRW, the CD recorder will calibrate the disc for optimum recording. During this process the display will first show INITIALIZING and then the number of audio tracks. Calibration can take up to 25 seconds.

REM REC

TIME TRACK

TOTAL REM

TRACK TIME

STEP

SYNC MANUAL



RECORD



PROG

DIGITAL I

CD

CHANGER

CD

SHUFFLE ALL

OPTICAL I

RW



RW

REPEAT

ANALOG



SCAN TRACK







If a CDR(W) is finalized it will show CD on the display.

If CD-text is available the TITLE/ARTIST will scroll by.

REM

REC

TIME TRACK





TOTAL

REM TRACK

TIME

STEP

1

2

3

4

5

6

7

8

9

10

11

12

13 14

15





SYNC MANUAL















RECORD





PROG

DIGITAL I









CD







CHANGER



CD

SHUFFLE ALL

OPTICAL I







RW















RW

REPEAT

ANALOG





















SCAN TRACK



























Note:

-Only Audio CDs will be accepted. If a non-audio disc is inserted, the display shows WRONG DISC/

USE AUDIO CD.

-Reading an unfinalized disc in the CD recorder deck could take approximately 1 minute.

-For recording it is important that the blank disc is completely free from dust particles or scratches. (see maintenance).

English

15

English

RECORDING

Remarks about recording

Recording modes

You will soon discover how easy it is to make your own CDs. Nevertheless, it is advisable to use a CDRW disc for your first try.

We will describe:

-Recording from internal CD player deck: high speed or listen mode.

-Recording from an external CD player deck: syncronized start with CD player or manual start. (analog or digital).

•If the disc is a CDRW and is already finalized you must unfinalize it first.

•The recording procedure is the same for CDRs and CDRWs.

•If the disc already contains recordings, the CD recorder will automatically search for the end of the last track, so that recording can start from there.

•CD text can be added to a recording in Stop mode and during recording.

•CD text can not be recorded from an external CD player. (Text information is not available on the output of the CD player.)

•The CD recorder deck is able to record CD text from the internal CD player deck. (If not subjected to copy protection.) This may take up to 2 minutes.

•There must be at least 7 seconds of recording time left on the disc, otherwise you will not be able to enter record standby mode. DOES NOT FIT then lights up.

•If the display indicates COPY PROTECT, no digital recording can be made of the source material. Recording will not start.

•The Serial Copy Management System (SCMS) only allows digital recording under specific conditions:

-This means that it is not possible to make a digital copy from a digital copy.

-Analog recording is always possible!

-The number of recordings from the original is unlimited.

•A maximum of 99 tracks can be recorded on a disc. Minimum allowable track length is 4 seconds.

•Recordings from DAT or DCC players will not always stop automatically.

Important:

If you want to play the recorded CDR disc on any regular CD player, it must first be finalized. See finalizing discs.

Finalized CDRW discs play only on CDRW compatible CD players.

The CD-Recorder records the text memory simultaneously when using the internal CD-deck. Some discs are prohibited to copy the text memory. If such a disc is copied, no text memory will be recorded.

Your recorder offers several recording modes.

For recording from internal CD-deck:

-RECORD FAST (high speed digital recording) - fast recording of a disc or programmed tracks.

-REC LISTEN (normal speed digital recording) - listening to a recording while making it.

-MAKE CD (high speed digital recording and auto-finalize) - fast recording of a disc or programmed tracks. Recording will be finalized automatically.

Warning: No more recording possible after finalizing CDR disc!

REM REC

TIME TRACK

TOTAL REM

TRACK TIME

STEP

SYNC MANUAL



RECORD



PROG









DIGITAL I

CD

CHANGER

CD

SHUFFLE ALL

OPTICAL I

RW



RW

REPEAT

ANALOG



SCAN TRACK







For recording from external sources:

-REC EXT DISC (automatic start of recording) - to make an automatic recording of an external source simply by starting the source.

-REC EXT MAN (manual start of recording) - to start a manual recording from an external source.

Some remarks on recording:

-During high speed recording, the original recording quality will be maintained.

-When Auto track is on (default setting), track numbers will automatically be increased during recording.

-By programming tracks first, a compilation can be recorded.

-If a finalized CD rewritable disc is inserted in the CD recorder, UNFINALIZE and PRESS ENTER will be displayed when the REC TYPE is pressed. If ENTER is pressed, the disc will be unfinalized. -

-When you copy a special disc such as HDCD or DTS, you have to

•set the sampling frequency at 44.1kHz. •use the digital connection.

•set the digital rec-volume of the CD-Recorder at 0 dB.

-When you copy the tracks from a DAT recorded by different sampling frequencies, noise might be recorded in the disc. Please set a sampling frequency for every track in a DAT.

-This CD-Recorder can record about 17 seconds of a pause time, which decreases the time count just before music start in a track on the display. If you record a track including more than 17-seconds-pause time by digital recording, the pause time will be recorded the different length of time from original. However, the entire track time will not be changed and be able to listen to the music as same as original.

Note: If during recording ANALOG REC appears, the track will be recorded as analog, at normal speed. All other tracks will be copied normally (at double speed).

16

RECORDING

High speed recording from internal CD player

CD RECORDER DR4050















STOP



















REC TYPE

REC

FINALIZE

ERASE

SOURCE

CD-R







EASY JOG



















+

STORE

CANCEL

PLAY/PAUSE

STOP

















/MENU

/DELETE









PUSH ENTER















PROG

SHUFFLE

DISPLAY

SCROLL

REPEAT

DJ MODE





•If DOES NOT FIT appears on the display, there is not enough recording space left on the CDR(W) disc.

You can press RECORD: only complete tracks that still fit on the CDR(W) will recorded.

or

You can press PROG to select one or more tracks for recording (see programming):

-rotate the EASY JOG/ENTER key to the required track number, then press the key (or ENTER on the remote control)

or

-directly select the track number via the 10-keypad on the remote control then press the ENTER key to confirm your selection and go to the next step.

During high speed recording the sound is not audible.

Preparing for high speed recording

1 Make sure that the recording disc is absolutely free of scratches and dust particles.

2 Press REC TYPE to choose the type of recording:

once: to select ‘RECORD FAST’ if you wish to make a fast recording of a disc or programmed tracks;

three times: to select ‘MAKE CD’ if you wish to make a fast recording of a disc or programmed tracks and to automatically finalize the recording.

The display first shows the selection.

The fRECORDg label starts blinking. After 3 seconds the display shows the remaining CDR(W) recording time on the left and total time of source on the right. (every 2 seconds PRESS RECORD is displayed.) The left

selection indicator is lit.

REM

REC

TIME TRACK

TOTAL REM

TRACK

TIME



STEP

SYNC MANUAL

RECORD





PROG

















DIGITAL I

CD

CHANGER



CD

SHUFFLE ALL

OPTICAL I

RW





RW

REPEAT

TRACK

ANALOG







SCAN











REM

REC

TIME TRACK

TOTAL REM

TRACK

TIME



STEP

SYNC MANUAL



RECORD





PROG















ALL

DIGITAL I



CD

CHANGER



CD

SHUFFLE

OPTICAL I



RW





RW

REPEAT



ANALOG







SCAN TRACK











Start high speed recording

1 Press RECORD to start recording.

WAIT lights up. The display shows the total remaining time for the selected recording. High speed recording starts. fRECORDg lights continuously.

•To check the track number and track time, press DISPLAY. This can be done during recording.

•Recording will stop automatically.

Note: Copy prohibited tracks will be copied analog. ANALOG REC is displayed.

2 To stop recording manually, press STOP.

UPDATE lights up, fRECORDg goes out and recording stops. (Minimal track length must be 4 seconds otherwise silence will be added to the track.)

•If STOP was pressed within 3 seconds after RECORD, no recording will take place.

After recording, the display shows UPDATE for several seconds. The Total time indications can differ slightly. However, no music information is lost.

Note: In this Recording mode, the Pause function is not operative.

REM

REC

TIME TRACK

TOTAL REM

TRACK

TIME





STEP

SYNC MANUAL



RECORD





PROG



















ALL

DIGITAL I



CD

CHANGER



CD

SHUFFLE

OPTICAL I



RW





RW

REPEAT

TRACK

ANALOG







SCAN











Important:

If you want to play the recorded CDR disc on any regular CD player, it must first be finalized. See finalizing discs.

Finalized CDRW discs play only on CDRW compatible CD players.

English

17

English

RECORDING

Listen mode recording from internal CD player

CD RECORDER DR4050















STOP



















REC TYPE

REC

FINALIZE

ERASE

SOURCE

CD-R







EASY JOG



















+

STORE

CANCEL

PLAY/PAUSE

STOP

















/MENU

/DELETE









PUSH ENTER















PROG

SHUFFLE

DISPLAY

SCROLL

REPEAT

DJ MODE





During Listen mode recording you listen to the recording while you are making it.

Preparing for Listen mode recording

1 Make sure that the recording disc is absolutely free of scratches and dust particles.

2 For recording, press REC TYPE twice:

The display first shows the selection.

The fRECORDg label starts blinking. After 3 seconds the display shows the remaining CDR(W) recording time on the left and total time of source on the right. (every 2 seconds PRESS RECORD is displayed) The left

selection indicator is lit.

REM

REC

TIME TRACK

TOTAL REM

TRACK

TIME



STEP

SYNC MANUAL

RECORD





PROG

















DIGITAL I

CD

CHANGER



CD

SHUFFLE ALL

OPTICAL I

RW





RW

REPEAT

TRACK

ANALOG







SCAN











REM

REC

TIME TRACK

TOTAL REM

TRACK

TIME



STEP

SYNC MANUAL



RECORD





PROG















ALL

DIGITAL I



CD

CHANGER



CD

SHUFFLE

OPTICAL I



RW





RW

REPEAT



ANALOG







SCAN TRACK











REM

REC

TIME TRACK

TOTAL REM

TRACK

TIME





STEP

SYNC MANUAL



RECORD





PROG



















ALL

DIGITAL I



CD

CHANGER



CD

SHUFFLE

OPTICAL I



RW





RW

REPEAT

TRACK

ANALOG







SCAN











•If DOES NOT FIT appears on the display, there is not enough recording space left on the CDR(W) disc.

You can press RECORD: only complete tracks that still fit on the CDR(W) will recorded.

or

You can press PROG to select one or more tracks for recording (see programming):

-rotate the EASY JOG/ENTER key to the required track number, then press the key (or ENTER on the remote control)

or

-directly select the track number via the 10-keypad on the remote control then press the ENTER key to confirm your selection and go to the next step.

3 Play the source first to set the optimal recording level on the CD recorder.

4 Rotate the EASY JOG/ENTER key until, on the Record/Play Level bar, all the blue segments are alight, but the red segments do not light continuously during the loudest passages.

Display shows _XX DB (Decibel, e.g. -3DB).

5 Stop the source.

Start Listen mode recording

1 To start recording, press RECORD.

WAIT lights up. fRECORDg lights continuously and the selected track or program is copied at normal speed. The track number and the recording time left will appear.

•To check the track time, press DISPLAY. This can be done during recording.

•Recording will stop automatically.

Note: Copy prohibited tracks will be copied analog. ANALOG REC is displayed.

2 To stop recording, press STOP.

UPDATE lights up, fRECORDg goes out and recording stops. (Minimal track length must be 4 seconds otherwise silence will be added to the track.)

•If STOP was pressed within 3 seconds after RECORD, no recording will take place.

After recording, the display shows UPDATE for several seconds. The Total time indications can differ slightly. However, no music information is lost.

Note: In this Recording mode, the Pause function is not operative.

Important:

If you want to play the recorded CDR disc on any regular CD player, it must first be finalized. See finalizing discs.

Finalized CDRW discs play only on CDRW compatible CD players.

18

RECORDING

Manual recording from external CD player

CD RECORDER DR4050















STOP



















REC TYPE

REC

FINALIZE

ERASE

SOURCE

CD-R







EASY JOG



















+

STORE

CANCEL

PLAY/PAUSE

STOP

















/MENU

/DELETE









PUSH ENTER















PROG

SHUFFLE

DISPLAY

SCROLL

REPEAT

DJ MODE





Important:

-Recording from CD-changers should always be started in the Auto-Start mode.

-Only make analog recordings when digital recording is not possible.

Preparing for manual recording

1 Make sure the disc is absolutely free of scratches and dust particles.

2 Press SOURCE repeatedly until (depending on the connection used):

DIGITAL I, OPTICAL I or ANALOG lights up and

DIGITAL 1, OPTICAL or ANALOG appears on the display.

REM REC TIME TRACK

TOTAL REM TRACK TIME

STEP

SYNC MANUAL

RECORD

PROG

MANUAL starts to flash and the display shows REC EXT MAN followed by WAIT. After a few seconds PRESS RECORD followed by the remaining time and track number appear on the display.

REM REC TIME TRACK

TOTAL REM TRACK TIME

STEP

SYNC MANUAL

RECORD

PROG





ALL

4 Play the source first to set the optimal recording level on the CD recorder.

5 Rotate the EASY JOG/ENTER key until, on the Record/Play Level bar, all the blue segments are alight, but the red segments do not light continuously during the loudest passages.

Display shows _XX DB (Decibel, e.g. -3DB).

6 Stop the source.

Start manual recording

1 To start recording, press RECORD on the CD recorder and

immediately start the source (from Pause or Stop-mode).

d lights continuously. The track number and recording time left appear on the display.

•If CHECK INPUT message also flashes, the digital connection is incorrect.

•To record a 3-second silence at the start of a track, press PAUSE on the CD recorder before starting the source.

•To check the total remaining recording time, press DISPLAY on the CD recorder. (This can also be done during the recording.)

•When Auto Track is On (default setting), track numbers will automatically be increased during recording.

•To switch off the Auto Track function you have to enter Menu mode.

If you wish to increase track numbers manually, press TRACK INCR(ement) on the remote control. For further instructions see Menu mode.

ON (Auto): The track increments are automatically taken over from the digital source material or after 2.7 seconds silence during analog recording.

OFF (Manual): While recording track numbers can be incremented manually by pressing TRACK INCR(ement) on the remote control. (Minimum track length is 4 sec.) (This can also be done in Auto track ON mode.)

• Track numbers cannot be changed after recording.

Note: Auto track works only with Consumer Sources with a digital output signal according to the IEC 958 (consumer part) audio standard.

3 With the recorder stopped, press REC TYPE five times to

enter the Manual Record standby mode.

2 To stop recording, press STOP on the CD recorder.

UPDATE lights up and d goes out.

If STOP was pressed within 3 seconds after RECORD, no recording will take place.

To interrupt recording, press PAUSE on the CD recorder. d starts to flash. Press PAUSE again to restart recording. ( A new track will always be made.)

After recording the display will show UPDATE for several seconds.

Note: With AUTO TRACK ON, the recorder will stop and go to REC STANDBY for 1 minute and then goes to Stop mode automatically. Recordings from DAT, DCC or recordings made analogously will stop after 20 seconds silence. With AUTO TRACK OFF, the auto stop mode is disabled.

Important:

If you want to play the recorded CDR disc on any regular CD player, it must first be finalized. See finalizing discs.

Finalized CDRW discs play only on CDRW compatible CD players.

For recording from CD changers always use REC EXT

19

English

English

RECORDING

DISC.

Autostart recording from external CD player CD-SYNC

PLAY/PAUSE

STOP

CD RECORDER DR4050





























REC TYPE REC



FINALIZE

ERASE

SOURCE

CD-R



PROG

SHUFFLE

DISPLAY

SCROLL

REPEAT

DJ MODE



•If, however, you start the source during a track, CD-SYNC recording starts at the beginning of the next track or after 2.7 seconds of silence in analog recordings.

•To check the remaining recording time on the CDR(W), press DISPLAY. (This can also be done during recording.)

•The EASY JOG/ENTER key can be used to adjust the recording level.

•The recorder stops automatically.

The CD-SYNC feature enables you to make fast and easy recordings of a CD. Track increments are automatically detected from the source material. Track increments cannot be added manually. In analog source material a silence of 2.7 seconds or more is automatically detected as a track increment.

Preparing for autostart recording

1 Make sure the disc is absolutely free of scratches and dust particles.

2 Press SOURCE repeatedly until (depending on the digital connection used):

DIGITAL I, OPTICAL I or ANALOG lights up and

DIGITAL 1, OPTICAL or ANALOG appears on the display.

REM REC

TIME TRACK

TOTAL REM

TRACK TIME

STEP

SYNC MANUAL



RECORD



PROG

DIGITAL I

CD

CHANGER

CD

SHUFFLE ALL

OPTICAL I

RW



RW

REPEAT

ANALOG



SCAN TRACK







3 With the CD recorder stopped, press REC TYPE four times:

if you wish to record a complete disc or program.

d and SYNC start to flash and the display shows REC EXT DISCand WAIT followed by the track number, the total remaining time and START SOURCE.

REM

REC

TIME TRACK

TOTAL REM

TRACK

TIME





STEP

SYNC MANUAL



RECORD





PROG



ALL

DIGITAL I



CD

CHANGER



CD

SHUFFLE

OPTICAL I



RW





RW

REPEAT

TRACK

ANALOG







SCAN











•If input label (DIGITAL I) flashes, the digital connection is incorrect.

2 To stop recording manually, press STOP on the CD recorder.

UPDATE lights up and SYNC and d go out.

•If STOP 9 was pressed within 3 seconds after pressing PLAY, no recording will take place.

•To interrupt recording, press PAUSE on the CD recorder.d starts to flash. (Autostart recording is disabled.) To

resume, press RECORD on the CD recorder.

After recording the display will show UPDATE for several seconds.

Note:

-Recordings from DAT, DCC or analog sources will only stop after 20 seconds silence.

-Auto track is always active.

Important:

If you want to play the recorded CDR disc on any regular CD player, it must first be finalized. See finalizing discs.

Finalized CDRW discs play only on CDRW compatible CD players.

For recording from CD changers always use REC EXT DISC.

Start autostart recording

1 To start recording, press PLAY on the selected source.

The CD recorder automatically starts to record and d lights continuously. The track number and track time appear on the display.

20

+ 44 hidden pages
