Mamiya M645 Pro TL Instructions Manual

Instructions

Congratulations on your purchase of the Mamiya 645 PRO TL

Mamiya pioneered the 6 x 4.5 film format and introduced the world’s first 645

SLR in 1975. The 645 PRO TL is the latest masterpiece in this series and

Incorporates all the latest mechanical, electronic and optical advances. Its
external appearance, too, has been modernized and its ergonomic design

further enhanced.

We are

sure

that you will enjoy the many advantages this camera and its
accessories offer and want to particularly mention :
The 645 PRO TL has a built-in self-timer (delayed shutter release) which will
also facilitate time exposures. Attaching special leaf shutter lenses will
automatically set the focal plane shutter to 1/8 sec. Heavy duty gears connect
to the improved Power Drive Grip

WG401,

This grip also automatically cocks
the leaf shutter lenses and permits remote control.
The AE Prism Finder

FE401,

specially created for this camera, automates

exposure and shows LED safety signals. 35mm film holders now

come

with

panoramic adapters. A super fast 300mm

f/2.8

APO lens was also designed
for this camera.
We are

convinced

that your camera will serve you well, because we have

designed it for

heavy

professional use. However, we ask you to please read all
operating instructions carefully before you put your equipment to work, in
order to ensure proper operation and maximum results

This manual covers the basic
camera.

Separate instructions
are supplied with all system
accessories,

including lenses,

finders, film holders, etc.

For additional information

please feel

free to contact your
authorized Mamiya dealer or
the Mamiya importer in your

country.

Contents

Special Features of the Mamiya 645 PRO TL

.......

3

Names and Functions of Parts

..............................

7

Attaching andRemovingLenses

........................

10
Attaching and Removing the Roll Film Holders. 11
Attaching and Removing the Viewfinder

............

12
Removing and Attaching the Film Advance

Crank

......................................................................

13
Insertingthe

Battery

.............................................

14
BatteryCheck

........................................................

15

Shutter Release Selector......................................

16

Shutter Performance Test....................................

17
Before Film Loading

.............................................

16
FilmLoading

..........................................................

19
Advancing the Film to the First Frame..

..............

21

Shutter Speed Settings.........................................

22
ApertureRing/Stop-down

Operation..

.................

23
Focusing

................................................................

24

DepthofField

........................................................

25

Film Advance and Unloading Exposed Film

......

26

Using the Self-timer/Delayed Shutter Release..

27

Time

Exposures

....................................................

26

MultipleExposures

...............................................

26

MirrorLock-up

Photography..

..............................

29

Infrared Photography..

..........................................

30

Using a Tripod

.......................................................

30

Flash

Photography..

..............................................

31

Holding the Camera Steady and Securely..

........

35

Attaching and Removing the Neck Strap..

..........

36

Basic Accessories

................................................

37

SystemChart

.........................................................

39

Trouble Shooting

..................................................

40

Mamiya 645

PROTL

Specifications

....................

41

ThingstoWatch

....................................................

43

Common Sense Camera Care and Practice

.......44

Special Features of the Mamiya 645 PRO TL

1.

Image Area about 3X larger than 35mm

Format

3.

Interchangeable Rollfilm Holder System

-

Bigger is better --

The

6X4.5cm

image size is about

3x larger than 35mm

and therefore produces far superior results. It is large
enough to be viewed without magnifier and its aspect

ratio of about 1.25 (long side :

short

side)

matches

the
standard 8 x 10 inch “ideal format”, the most popular in
photography and industrial use. It requires minimum
cropping and gives maximum film utilization. (15 or 30
exposures on 120 or 220 film respectively)

-120, 220, 35mm,

35mm

Panoramic and

Polaroid --

Permits quick film change, even in mid-roll. Many fail
safe features prevent accidental exposures or film waste.

2.

Rugged, Versatile and Reliable Camera

Body

-

Built for professional

use

--

Mamiya pioneered the 645 SLR camera system in 1975
to create medium format image quality with 35mm

handling ease. New models have periodically followed
over the years to keep in step with mechanical, optical
and electronic advances

4

.

Interchangeable Viewfinders

1. AE Prism Finder FE401

The AE (automatic exposure) Prism Finder FE401
features three modes of TTL metering, including
automatic switching from center-weighted averaging
to spot metering. It also has a

+3EV

exposure

compensation adjustment.

2. AE Finder FK402

Light weight, Keplerian (non prism) AE aperture
priority finder offers an unreversed, upright image

Features telescoping eyepiece with diopter

adjustment from

+5

to -5.

3. Prism Finder

PF401

The Prism Finder

PF401

is without metering

electronics and designed for manual photography

mode. Both Prism Finders show an unreversed,
upright image and are ideal for eyelevel photography.

4. Waist Level Finder N

The Waist level Finder N is desirable for low angle
photograhpy and particularly for horizontal
composition.

A self erecting hood with built-in magnifier shields
groundglass from all ambient light. A built-in
sportsfinder permits eyelevel viewing and is ideal for
action photography.

5.

Interchangeable Focusing Screens

The camera

comes

with a Type E, bright, split image,
micro prism screen, useful for most applications. Five
other types, for all specialized requirements, are also
available.

6.

Large Selection of World-Class Mamiya

Lenses

Mamiya’s in-house optical engineering and
manufacturing department produces lenses specially
designed for the medium format, of unsurpassable
resolution, contrast and

color

fidelity. From

24mm Fisheye

to 500mm telephoto, plus macro,

zoom

and APO lenses,

these lenses have become the choice of the pros.

7

. Motorized Power Drive Grips

Two accessory motorized drives, interchangeable with
the manual film advance crank, are incorporated into an
ergonomically designed grips for easy, right handed
camera operation.

Model WG 401 requires 6 AA batteries and features
multiple exposure switch, cable release socket, battery
check and continuous shooting. It also can be used with
leaf shutter

lenses.

Model WG402, a simplified version, permits only
individual exposures, uses one 6 Volt lithium battery and
is much lighter.

8.

A Broad Accessory System

For Specialized Applications

A useful accessory system to serve the specialized
needs of the photographer. It includes Auto Bellows and
Auto Extension Rings for close-up and copying work;
Infrared Remote Control for studio and nature
photography; External Battery Case for operating in cold
surroundings; Camera Grips for convenient holding and
more.

<Self-timer>

Self-timer for delayed shutter release. When activated it
will light a red pilot lamp in the front of the camera for
eight seconds and will blink for two seconds before
triggering the shutter.

<Time

Exposure>

Time exposures are made by utilizing the Self-timer and
the

"B"

shutter setting. A new power saving circuit

design switches the battery off and extends is life.

9

TTL (through-the-lens) Flash Exposure

. Automation

The light that hits the film surface during exposure is

reflected to a photoreceptor within the camera body

which automatically adjusts the flash output to the

required level.

10

.

Other Features

<Mirror Lock-up>

After focusing, the mirror can be locked up before
making an exposure. This is convenient when the
camera is used at slow shutter speeds and is mounted
on a tripod for telephotography, copywork, etc.,
since even a very small amount of vibration should
be eliminated.

<Self-timer>

Shutter will be released 10 seconds after shutter
button is pressed.

<Time Exposure>

When making time exposures, the battery circuit is
automatically disconnected, to save battery power.
This is especially useful for

astrophotography.

Names and Functions of Parts

@

Focusing Screen

N

Aperture Ring

Coupling

This pin is fitted into the E

Meter Coupler of the

l

transmit the aperture dat

AE Prism Finder.

Battery Check Lamp

13 Gold Plated Contacts

These contacts interface the AE

Prism Finder with the

IS0

dial on
the film holder and the shutter
speeds.

Hot-shoe (X contact)

A cordless flash can be used with

Focusing Screen Release Pin

When you want to change the
screen, slide this pin to the left
and

remove the screen.

Shutter Release Selector

Align the white index dot on the
selector collar with the white
square dot in the center for normal

use.

When the

collar

is turned to
the red dot, the release is locked.
To use the

Self-timer, set

it to

e..

this shoe.

Flash Sync Terminal

Flash cord and optional Terminal
Adapter

RA401

can be connected

to this terminal.

Shutter Release

Button

Mirror

l Never touch the

surface

of the

mirror

left, the contact appears. This
contact is used for connections of
external releases such as a

Battery Check Button

/

LED displays the present battery

condition.

\

tro’ u”it.

6-

Pin Coupling Connector for

dedicated TTL flash

0

automation. (Such as

Metz

SCA396)

Finder Coupling Panel (Front)

tl

Shutter Speed

Dial

Lock

Release

Button

Finder Coupling Panel (Rear)

’

This

button is used for unlocking

/

the Shutter Speed Dial from an
AE

position

This contact receives film sensi­tivity data from the film holder.

Film Holder Mount

Shutter

Curtain

Exposures

are

controlled by
opening and closing the curtain:

a

Never touch the surface of this

curtain.

Film Transport Gear

-

Film Holder Mounting Bracket

Multiple Exposure Lever

When this lever is set at

"MULTI",
film is not advanced even when
the Film Advance Crank is turned,
thus allowing multiple exposures
on the same film frame.

Tripod Socket

1/4’

tripod

socket.

To

convert

to

a 3/8’ socket,

remove the small
screw in the base of the socket.
Then remove the bushing. See

page 32.

Distance Scale

The camera to subject distance
can be set or confirmed with this
scale

Lens Alignment Dot

Depth-of-field Scale

Provides a quick reading of depth-

of-field for various

apertures

and

distances.

Exposure Meter Coupler

This coupler is engaged with the
Aperture Ring Coupling Pin, trans-

mitting diaphragm information to
the AE Prism
Finder.

@

Attaching and Removing Lenses

0

Removing the Front Body Cap
and Rear

Cover

Attaching

the Lens

First remove the Front Body Cap in

the direction of the

arrow,

while push-

ing the Lens Release Button

8

backwards as indicated by arrow.
Rear Body Protective Cover can be
readily removed by depressing the
part of

@

as shown in the illustra-

tion.

Line up red Lens Alignment Dot

0

against red camera Alignment Dot

$3

and gently insert the lens into the
camera body. Then turn the lens

clock wise, as indicated by arrow,
until it clicks into place. Make sure

that the

Aperture

Ring Coupler Pin is
engaged with the Exposure Meter
Coupling Pin

@I,,

which sticks out
under the Mamiya name plate of the
camera.

Removing the Lens.

While pushing lens release button

@

backwards, turn lens counter­clockwise. (Same procedure as
removing body cap).

Attaching and Removing the Roll Film Holder

Removing the Rear Body Cap

Rear Body Protective Cover can be
readily removed by depressing the

part

of 0 as shown in the illustration.

*After removing the rear cap, be

careful not to touch the shutter

blind. This can cause breakage of

shutter.

Attaching the Roll Film Holder

*

Remove the Roll Film Holder

Cover.

1. While spanning the Roll Film Holder

between your thumb and middle fin­ger, holding it on the rubberized fin­ger rests, carefully align its Film
Holder Mounting Bracket with the
corresponding center clip of the cam­era body.

2. While keeping this alignment, press
the upper part of the Roll Film Holder
against the camera body, so that it
clicks into place by engaging the
spring loaded twin camera catch.

Attaching and Removing the Viewfinder

Removing the Roll Film Holder

1. Insert the Dark slide into the slot

marked by White Lines on the side of
the holder.

2. Push the lower one of the Film
Holder Detaching Lock Release
Button

@

downward, while simulta­neously pushing the Film Holder
Detaching Button

@$

inward.

*

If the Dark Slide is not inserted,
the safety lock will prevent the
holder from being removed.

Attaching the Finder.

Lift the Upper Cover from the camera
body.
Insert the Attaching Latches of the

finder into the Finder Coupling Panel

@I

in the front wall of the body. Press
the finder down until the rear latch
locks securely in place.

Removing the Finder

Spanning the finder with your fin­gers, push the button on its right side

marked with a downward pointing
arrow

@ @I,

downward, while
pushing the other button, on the left
side

@ 0,

inward.

Removing and Attaching the Film Advance Crank

Removing the Crank

Attaching the Crank

Push the lock Lever

‘&>

on its bottom

in a forward direction as far as it will

With the flat part, having a White

go (see illustration).

Index Line, on top, line the Crank up
against its mounting plate on the side
of the body and push Film Advance
Crank Lock Lever backward.

You may choose six different crank
starting positions to suit your prefer­ence. The orientation of the crank

proper against its base, before it is
attached to the camera, will be main­tained when the entire assembly is

locked into place.

0

Inserting the Battery

The camera will not function with­out a battery

With your fingernail, pull the Battery
Chamber Cover latch, on the bottom
of the camera body, as indicated by
the arrow in the illustration. Lift the
cover off. The camera requires a

6V
alkaline, silver oxide or lithium bat­tery. It is a good idea to wipe the

battery terminals before insertion to
assure proper contact. Observe

po-

larity. Q

position is marked in battery

cavity. Insert the G side first at a

steep angle and then push entire

battery into place, making sure that

the lift ribbon wraps around battery.

Close cover by inserting twin-prong
end first and pushing it down.

*

Be particularly careful not to let

the lift ribbon cover the c”

termi-

nal.

Batterv Check

Press Battery Check Button “B.C.”

8

on lower front of the camera.

Battery Check Lamp @I on top oppo­site side should light. Bright light indi­cates good condition. Blinking light
means replace battery. No light
means

battery

is dead or improperly

inserted.

Important:

1. The sealed, new battery which is

supplied with this camera may have
been subject to storage conditions
which have reduced its service life.
Therefore it is desirable to replace it
with a fresh battery as soon as
possible.

2. Carefully wipe the battery contacts
before inserting into the chamber.
Failure to do so may result in poor

electrical contact and consequent

malfunctioning of the camera.

3. Always

remove

battery when
camera is not used for a while. Always
carry spare batteries.

4. Battery life differs, depending on
type, age. storage condition, ambient
temperature, frequency Of

use

etc.

Battery strength will be indicated
by whether the light:

Glows ... Battery stength is

sufficient.

Blinks ... Battery capacity has

dropped below the

allowable level.

(Replace the

battery.)

Does not light

.,.....

The camera

will

not work.

(Replace

the battery.)

Shutter Release Selector

For normal operation set the White
Dot of the Shutter Release Selector

(8

against the White Square Dot

0.

When set to the Red Dot 0, the

Release Button is locked.

*

Select this mode if the camera

will be idle for a period and to

prevent accidental shutter release.

Also when the Power Drive Grip is

used.

When set to the yellow clock symbol

3. After releasing the shutter, the

ti’

the self-timer is operative. See Film Advance Crank will automati-

page 27 and 28 for further instruc-

cally

unlock and be ready to advance

tions.

the film.

Operating the Shutter Release
Button

1. The Shutter Release Button

SJ

functions in two steps. Gentle pres­sure will light the metering informa­tion display if the AE Prism Finder is
used. Continued pressure will release
the electromagnetic shutter.

2. If the film is not completely ad­vanced, if the Dark Slide is not with­drawn or if the battery is dead, the
shutter will not function, even when
the Shutter Release Button is
pressed. This will also be the case if
the Shutter Speed Dial is set to

“A”

or

“AEL”

when the AE Prism Finder is

not attached.

a3

Shutter Performance Test

1. Attach the Roll Film Holder to the

camera body.

2. Pull out the Dark Slide and place it
into its Storage Slot.

3. Set the Shutter Speed Dial to any
other position than

‘A”or “AEL”.

When
the AE Prism Finder is not mounted
on the camera, the shutter will not

release if the Shutter Speed Dial is in

the

“A”

or

“AEL”

position,

the film holder is supplied with a
vinyl tube. When placed in the
take-up compartment it engages
the film sensor and makes the

holder function as if it is loaded

with film. Please remove the tube

4. Set the Multiple Exposure Lever
on the body to the “MULTI” position.

Before Film Loading

5. Set the Shutter Release Selector

to " 0 " (normal mode), and press the
Shutter Release Button.

6. After the shutter has been re­leased, advance the Film Advance
Crank one complete revolution and
the next frame will be ready.

Film

Speed Index Speed Index

of

film

holderholder

Film Speed

(ISO)

Dial

Memo Clip

r

L

!

I

,I-

-

The Memo Clip on the back of the
Roll Film Holder Cover accepts the
box top of the film carton and can
also be used for other reminders.

Each film holder has this important
feature. It electronically interfaces the
film holder with the AE Prism Finder,
the focal plane shutter and the lens
diaphragm, for exposure automation.
This eliminates the need of having to
manually reset the meter, every time
you change film holders loaded with
different films. Therefore make it a
routine to always set this dial with the
speed of the loaded film.

IS0
25 50 100 50 100

200

400 400

800 1600 3200800 1600 3200

64006400

(32)(40)(32)(40) (64)(80)(64)(80)

(125)(1601(125)(1601

(X0)(320)(X0)(320)

(5001(6401(10001(1250)(5001(6401(10001(1250) (2ooo)c25oo,(4oao)(sooo)(2ooo)c25oo,(4oao)(sooo)

00

Film Loading

1. While pushing the Back Cover

Lock Release Button

8

downward,

press the Back Cover Opening But-

ton

@;:,

and the Back Cover will

open.

2. While squeezing in on both sides

3. Align the right-hand side of this

of the Release Latch

CQ,

pull the Roll

empty spool with the lower Spool

Film Insert

out

of the camera body. At

Stud

‘8

(convex). Slide the spool into

that time, move the empty spool in

position making sure that the

left-

the upper part down to the lower

side of the spool is properly held

by

spool

compartment

the Spool Clip.

When you load film for the first
time, remove and discard the
protective paper cover which is

attached to the film rails in the

roll

film holder.

4. In

the same manner, insert a

roll

of
film in the upper compartment. At
that time, check that the film leader

paper is set as shown in the photo
above. (The leader paper inside is
facing outward on the pressure plate.

Note that the film direction is wrong if
the leader paper is facing inward.)

5. Pull out some of the leader paper.
Insert

the tip of the leader paper into

the slot of the lower Take-up Spool.

6. Gently rotate the take-up spool as
shown in the photo until the start
mark on the leader paper is aligned
with the start mark

(a)

on the spool

clip.

*

Correctly align the start marks
with each other, making sure that
the film feeds properly. When im-

proper feeding occurs, the proper
number of exposures may not be

taken.

*

Avoid exposing the film to di-

rect sunlight when inserting or

re-

moving film.

@I

*

220 Film Loading Caution
220 films have two types of Start
Mark Lines across the paper

leader. Always use the second one,

a solid line with the legend “Start

Mark for standard cameras”,
located

about 14cm (5

1/2”),

behind the first, dotted Mark line.

DO NOT use the dotted line for a
start mark.

Advancing the Film to the First Frame

7. Insert the loaded Roll Film Insert

into the holder, the film

roll

on top,
while squeezing on both sides of the
Release Latch Cc as shown in
illustration. Make sure that is been
properly seated and is locked in place.
Then close cover by firmly pressing
its top against the Roll Film Holder.

*

To close the Back Cover, firmly

press

the top of the back cover on

both sides.

1 . While spanning the Roll Film Holder

between

your thumb and middle

,.

finger holding

itit on the rubberized

finger rests, carefully align its Film

Holder Mounting Bracket with the
corresponding center clip of the
camera body.

2. While keeping this alignment, press

the upper part of the Roll Film Holder

against the camera body, so that it

clicks into place by engaging the

spring loaded

twin

camera catch.

Set the multiple exposure switching

lever A to the white square mark

0

(normal mode).

Shutter Speed Settings

I

/

I

I

3. Wind up.

How to set the Shutter Speed Dial

Wind up the crank handle until it 1. Set the desired shutter speed

stops. In

the

film counter window, the

against the white index line (A) on the
number 1 appears, and the film and shutter speed dial.
shutter are set.

2. At the red “A" (for Automatic) and
AEL (for Automatic Lock) settings,
the shutter speed dial is locked

between these two positions. These

settings will only function if an AE

Finder is mounted on the camera. To
release this lock push button (B) while

turning dial.

3. All while numbers are fractional
seconds.

(i.e.

30

=1/30 sec).

@

The yellow 2 and 4 are full seconds.

“B”

(shutter stays open as long as it

is depressed) is also yellow.

4. Red 60 is

1/60

sec. It is colored red
to remind you that it is the fastest
speed useable with electronic flash.

5. Note: When a

Metz

Electronic Flash
Unit, together with SCA 396 module,
is attached to the camera, the camera

sets itself automatically to

1/60

sec.,

irrespective of the dial setting.

*

When manually selected shutter
speeds are set on the shutter speed
dial, the intermediate shutter
speeds available in the AE

operation are not obtainable.

Aperture Ring/Stop-down Operation

Set the desired f/stop on the aper­ture Ring 6) by aligning the f/number

The effect the set f/stop will have

upon the picture area can be

con-

with the red reference dot

SC@

in the

firmed on the Finder Screen.

center of the Scale Ring. The Aper-

Move the AM Lever on the lens so

ture

Ring has a click stop for each

f/

that “M” becomes visible-the lens

stop. In-between settings can also

then can be stopped down

to

the

be used.

preselected aperture.

*

When the AE Finder is used, be

sure

to return the

A/M

lever to “A”
(Auto), after having checked the
effect of the manually set aperture.
The AE finder measures the
required exposure through the
lens at maximum aperture and will
give false results if lever is left in
“M”

position.

0

Focusing

4B

While looking through the viewfinder,
turn the lens Focusing Ring until the

most important subject part appears
sharp and clear.

Focusing with the Standard Focusing Screen N Type E

r-

1.

The camera comes equipped with
a bright, Type E, Rangefinder/Micro­prism Focusing Screen. It features a
center, split-image rangefinder spot
and the subject is in sharp focus
when the split

images combine into

one.

2. The microprism ring around the

split-image center further facilitates

focusing. The microprisms disappear

only when the subject is in sharp

focus.

3. The rest of the ground glass area
can also be used for focusing.

*Interchangeable Focusing

Screens
There are five additional focusing
screens available for specialized
applications. They are easy to
interchange and come with in­structions.

Depth of Field

Reading the Depth of Field Scale

Depth of field is defined as the

zone

of sharpness before and behind the

plane of focus. It depends on camera
subject/distance, focal length of lens,
aperture setting and distance the lens

is focused at.

~11

16 22

1

I

In

addition

to visual observation, the
Depth of Field can be determined by
using the Depth of Field Scale on
each lens. f/stop numbers

appear on
both the right and left side of the red
index mark in the center of the scale
ring. Simply read the figures which
appear above the f/stop numbers on
the distance scale of the lens.

For example, with the 80mm

f/2.8N

lens focused at 3m and the aperture

set at f/22, the depth of field scale

indicates that the zone of sharp

focus

will extend from about 2m to

6m.

Film Advance and Unloading Exposed Film

Film Advance

1.

Giving the Film Advance Crank
one complete turn, will cock the shut­ter and mirror and ready the camera

2. When the film is completely ex-

posed (15 exposures on 120, 30 on

for the next exposure.

220 film), the crank stop will disen­gage. Continue turning until the pa­per trailer is completely wound onto
the take-up spool. (About five turns

after the last exposure.)

Unloading Exposed Film

*

Move the empty spool from the
top to the lower (take-up)
compartment, ready for loading

the next film roll.
*Never load, unload or handle film
in direct sunlight.

3.

Open the Back Cover, and

remove

the Roll Film Insert. The Exposure

Counter will return to S (start)
automatically.

4. Pull the Spool Clip on the

roll

film

insert out to

remove

the film.

5. Remove the film from the roll film
insert; make sure that the film on the

roll does not loosen, and seal
immediately.

Using the Self-Timer/Delayed Shutter Release

To use the Self-Timer, set the Shut­ter Release Selector to

@

and press

the Shutter Release Button.

The Battery Check Lamp will light for
8 seconds and blink for 2 seconds,
whereupon the shutter will go off.

*

After using the self-timer mode,
be sure to return the Shutter Re­lease Selector to the White Square.
(Normal mode.)

-k

To override the self-timer, after
having pressed the release, move
the selector back to the white
square.

*

The Self-Timer can also be over­ridden by inserting the Dark Slide
into the Film Holder or setting the
camera Shutter Speed Dial to “B”.

Please note:

If you want to use the self-timer

with the shutter speed dial set at

“A” or “AEL” and there is no AE

Finder attached to the camera, it

will not release the shutter even

though the light goes on for 10

seconds. However, when the dial

is set to manual speeds, the self-

timer will function.

Time Exposures

Multiple Exposures

For time exposures set the Shutter
Release

Selector to c, the self-timer
mode, and set the Shutter Speed
Dial to

"B".

Press the shutter release
and both mirror and shutter will stay
open until the shutter release is
pressed again. You may also use a
cable release together with the cable
release adapter. (The battery circuit
will automatically switch off to save
power.)

*

"B" can be terminated by shift-

ing the Shutter Release Selector
from

23

or the Shutter Speed Dial

from

"B"

Aligning the white dot of the Multiple

Exposure Lever with the yellow
“MULTI” square, disengages the mul­tiple exposure prevention mecha­nism, and the film will not advance
after an exposure is made and the

Film Advance Crank is turned.

However, the shutter will be

recocked,
thus making multiple exposures
possible. In this mode the Exposure
Counter will not advance.

Mirror Lock-up Photography

*

To override the multiple expo­sure mode or to return to normal
operation, be sure to return the
lever’s White Dot against the white
square and then advance the film.
(If you forget you will continue to
make multiple exposures on the
same

frame.)

This is an important feature when the
tripod mounted camera is used at

slow or long exposure times and
particularly also with use of long

telephoto lenses. It eliminates the

possibility of even the slightest “mir­ror bounce” which may affect image
sharpness.
Move the Mirror look-up Lever to the

yellow ”M.UP”

square, after you

have

composed and focused your picture.

This will raise the mirror and the

viewfinder image will be blacked

out.

After use, return lever to normal (white

*When

using the AE Prism

Finder, set the Shutter Speed Dial

to “AEL”. Press the shutter re-

lease halfway and then lock the
mirror up. If set to “A” and the
mirror is locked up, “LT” (long

time) will appear in the finder dis-

play and correct exposure cannot
be obtained.

*

When using a Leaf Shutter Lens,

be

sure

to read the instructions

accompanying it.

square) position.

@

Infrared Photography

@

Using aTripod

@

Infrared light rays-being of longer

wavelength - focus at a slightly dif-

ferent plane and require the follow­ing adjustment:

1. Note the Red Index Mark against
which you read your distance scale.
The red infrared index mark is slightly
to its right.

2. After focusing in the usual manner,
read the distance scale and move it

to the right to line up with the infrared
index mark.

1414

56 8 56 8

11 11

16211621

The 300mm and 500mm APO lenses
for Mamiya 645 cameras, being also
corrected for infrared light rays, do

not need an index mark for infrared.

*

For proper filter and exposure

information be sure to consult the
instructions enclosed with infra­red film.

The Mamiya 645 PRO TL Tripod

Socket accepts a standard

1/4”

tripod

mounting screw. For use with tripods

having

3/8”

mounting screws, first
unscrew the small black philips head
retaining screw in the center of the

tripod socket. Then

remove

the

1/4"

bushing with a thin coin. To re-install

the

1/4

bushing, reverse the proc-

ess.

Flash Photography

In addition to its standard flash sync system, the Mamiya
645 PRO TL features TTL (through the lens), off the film

(OTF),

electronic flash exposure automation. A flash

sensor located inside the camera body reads the flash

reflected from the film surface at the moment of exposure.
The .sensw is connected via coilcords to a dedicated
electronic Metz SCA 396 thyristor module, which is
attached to the flash shoe of the camera. The module has
an

IS0

dial on which the speed of the film in use is set. The

resulting flash exposure automation determines correct
flash exposure and automatically adjusts the output of the
flash. It also automatically corrects for exposure
compensation ordinarily required when using filters, close-

up bellows or extension tubes. However, as all TTL

systems, it requires manual compensation

for differences

in film surface reflection characteristics. Compensation is

made by adjusting the film speed selector setting an SCA
396 module. The amount of compensation is determined

by experimentation.

Important:

Read Operating Instructions which are supplied with
flash unit before use.
Always turn off camera’s

power

switch when attaching

or

removing flash units.

Attaching Metz Flash Units

Metz flash

60CT-4/45CL-4

Various optional accessories are
needed to attach different

Metz

Flash

Units to the Mamiya 645 TL

Metz shoe mount flash type Metz flash

50MZ-5

This table shows accessories required with various Metz Flash Uunits

I

Metz

Flash Units

SCA396 adapter

IF?

SCA300

adapter

3

Bracket AD401

E’

Double shoe

adapter

AD402 0‘

--.-.-__~-_---.-

-_----.__---. _---

_-.-.~---~_-~- -.

_.-

--

Shoe

60CT-4

Yes No No No

mount

50MZ-5 Yes Yes No Yes

flash

45CL-4 Yes No

No No

_---_---~.--

40MZ-3

Yes No No No

“,“;$;

40MZ-2 Yes

flash

32MZ-3
32Z-2

Yes
Yes

No No No
No No

No

m

TTL Flash Photography with

Metz

Flash Units

1. Attach a Metz flash unit which

features TTL function to the camera.

Attach the SCA396 module to the
camera’s flash shoe. Connect the
module’s coiled cables to the camera
and the flash unit.
Set the film speed dial on the SCA396
module to the

IS0

rating for the film

in use. The range of

IS0

is 25 to

1250.

2. Move the flash unit’s power switch
to ON and the mode selector to TTL.

3. Turn the camera’s shutter release
selector switch to ON. When the
charge cycle is completed you will
see an illuminated green

5

readylight

in the middle of the right side of the

0

0

finder. When the SCA396 module is
connected, the camera’s focal plane
shutter will automatically set at

1/60

sec,

and ignore the settings on the

shutter speed dial between

1/60

to

1/1000, including A and AEL. Slower

shutter speed settings, however,

(1/30

to 4 sec.) are not affected and

will allow flash synchronization.

4. Set lens to the desired f/stop and
shoot. After the exposure is made,
the illuminated green

f

blinks,
confirming proper flash exposure. If
the illuminated green f does not blink
after exposure, it is possible that

aperture selected is not within the
exposure/distance range of the flash.
In this case, select a wider aperture
setting. When using flash at
maximum distance, which requires

the full power of theflash

unit, recyling
time will be longer. Wait for the
readylight to go on before firing the
next frame. Exposure Compensation
with TTL Flash Automation.

Because TTL Flash automation reads
the light reflecting off the subject,
exposure may require manual

adjusment in cases where subject

and background are predominantly
white or black (e.g. bride in white

dress against white background;

bridegroom in tuxedo against dark

background.) In these instances, the

resulting

TrL

exposure will either be

under-exposed or over-exposed. For

such situations, adjustment of about

1 to 1

l/2

f/stops, plus or minus, may

be

requiredthroughexperimentation.

Alternatively, a hand held incident
flash meter reading will show proper

exposure in these cases.

Photography with

Non-TTL

Flash Units

<Caution>
When using the Hot-shoe,

be sure to put an appropriate
Safety Cover over the X-sync
terminal so that you won’t

receive a high voltage
electric shock if the terminal

is accidentally touched. (A

Safety Cover is put on the

X­sync terminal when the
camera leaves the factory.)

1. When using an electronic flash,

plug the synchronization cord into
the Sync Teminal and set the Shutter
Speed Dial to

1/60

sec. or slower.

*

The Mamiya 645 PRO has an

X-

sync terminal.

Attach a shoe-mount flash to the

hot­shoe of the camera or the Left Hand
Grip GL401 (optional).

Flash

synchronization

Chart

*

Do not use a flash unit
specifically dedicated for another
camera. It may damage your 645
PRO.
*

If you use a flash unit whose

flash duration is slower than

1/

1000 sec., set the shutter speed

dial to

1/30

sec. or slower.

@

Holding the Camera Steady and Securely

h

Eye-level Operation Waist Level Operation

Hold the camera as shown in the
illustration, with its base resting on

your left hand, the right hand sup-

porting it from the side and top. Press

both elbows against your body and
activate the shutter release with a
smooth, steady pressure.

For waist level

operation,

it is deslr­able to have the Neck Strap attached
and adjusted for your size. During
exposure keep it taut and press the

camera firmly against your body.

*

Handholding the camera is even

easier using the Power Drive Grip
WG401 or Left Hand Grip GL401.

Attaching and Removing the Neck Strap

Attaching the Strap to the Camera

1. While pushing down, pull out the

Neck Strap Fastener @ of the attach­ing clip.

2. Place the hole of the strap fastener

@I

over the Neck Strap on the cam­era body as illustrated, and pull until
it clicks and locks into place.

With your fingers, pull the Neck Stra

P

Fastener @I of the attaching clip up­ward and push part @I in the direction
of the arrow. The strap can now be
removed.

*

When attaching the Strap to the
Neck Strap Lug on the side of the
camera with the Film Advance

Crank, insert the neck strap fas-

tener

@

into the lower part of the

double slot.

Basic Accessories

The AE Prism Finder FE401

The Mamiya AE (Automatic Exposure) Prism Finder

FE401

pentaprism guarantees a true, upright image and
features built-in electronic shutter control which ensures
aperture-priority,

TTL

automatic exposure metering while

in the A or AEL mode.
<3-Way

Metering System>

The FE401 comes with three metering modes: average

metering

(AV),

spot metering (SP). and AV-SP metering

capable of automatically selecting AV or SP according to

subject conditions.
The LED display in the viewfinder indicates correct
exposure.

If you forget to extract the Dark Slide when the finder is
being used with the 645 PRO TL, an LED will flash a
warning.

Power Drive Grip WG401

The motorized film transport mechanism is placed in an
ergonomically designed handgrip for speedy (2 f.p.s)
and

continuous shooting. Features include

cable

release
socket, shutter release lock, multi-exposure switch, first
frame advance, battery check, and power connector
socket for leaf shutter lenses. Uses 6 AA 1.5 V. batteries.

AE Reflex Finder

FK402

This aperture priority, Keplerian type, automatic (AE)

reflex finder features TTL auto or manual exposure with

center weighted averaging. It offers upright,

eyelevel

viewing with unreversed image.

Exposure is indicated by red and green LEDs.. A built-in
adjustable diopter eyepiece can be set from

+/-5

for

viewing convenience without eyeglasses.

Power Drive Grip WG 402

This simplified, compact, lightweight grip

uses

one 6 V.

lithium battery. It has a shutter release with lock and

offers single frame exposure mode.

/

Roll Film Holders

I

Interchangeable Lenses

120 Roll Film Holder HA401
220 Roll Film Holder

HE401

135 Roll Film Holder HC401

(with Panoramic Adapter)

Polaroid Land Pack Film Holder HP401

Metz TTL Flash Unit

Shoe Mount

60CT-4
etc.

Flash Bracket AD401

Handle Mount

40MZ-3

etc.

Wide-angle Lenses

:

35mm

f/3.5N.

45mm

f/2.8N,

55mm f/2.8N

Telephoto

Lenses

:

150mm f/3.5N,

A150mm
f/2.8, 210mm f/4N
ULD300mmf/5.6N,A200mm
f/2.8 APO,

A300mm

f/2.8APO,

A500mm

f/4.5

APO/500mm

f/5.6

Standard Lenses

::

80mm

f/1.

.9N, 80mm f/2.8N,

Zoom Lenses : Zoom 55 - 110mm f/4.5N,

Zoom

ULD105 1

210mm

f/4.5

Special Effect Lenses :

Fish-eye ULD24mmf/4

Shift

50mm

f/4.

Macro 80mm f/4N

Macro

120mm

f/4M

Leaf Shutter Lenses : A55mmf/2.8N/L,A80mm

f/2.8N/L, A150mm f/3.8N/L

Tele-Converter

:

2

x Tele-Converter

System Chart

PnSm

FiIlder

FP40,

AE Fl”&l FK402

wa,st

Level

Fin&i

N

Trouble Shooting

*

If the camera should fail to function properly,

please check the following:

1. The Shutter Release Button cannot be depressed.

Push the Battery Check Button.

If the lamp does not light, check:
Is a Battery in the camera?
If yes, is it correctly inserted? (Polarity)
Is it dead?

If the lamp does light, check:

Has the Film Holder Dark Slide been pulled?
Is the Shutter Release Selector in the locked
(Red Dot) position?
If so, move it to the White Square and try again.
Is the Shutter Speed Dial in the “A”

or

“AEL”

position?
If so, turn to other setting and try again.

2. The finder is black or very dark.

Has the Lens Cap been removed?
Is the Mirror-up Lever in the

“M.UP”

position?

If so, turn the lever to the White Square.

Is the “AM” setting on the lens at

“M”

(Depth of
Field Preview)?
If so,

move

it to

“A”.

3. The Roll Film Holder cannot be removed from the
camera body.

Insert the Dark Slide.

4. The developed film has fewer exposures than

Speci-

fied.

Most likely the

Start

Mark had not been aligned
properly when the film was loaded. (See load
ing instructions page 20)

5. The Film Advance Crank continues to turn and does
not stop.

Was the Roll Film Insert placed in the Roll Film

Holder?
Was the empty fim spool left in the upper
compartment?

Mamiya 645 PRO TL Specifications

Camera type

6X4.5cm electronically focal-plane shutter SLR

Actual negative site

56mm X41.5mm

Film type

120 roll film

(15

exposures)

220 roll film (30 exposures)

Film loading
Standard lenses

Lens mount
Shutter
Shutter speed

Shutter release

Mirror
Viewfinder

Focusing screen

Field of view

Polaroid pack film (Polaroid 100, 600 series)
135 roll film in film cartridge

Daylight loading

-

interchangeable film holders with film speed dial

Mamiya-Sekor C 80mm

f/2.8N

Mamiya-Sekor C 80mm f/1

.9N

M645

bayonet mount (applicable to all M645 lenses)
Moving coil, electronic controlled focal-plane shutter
(Manual) 4 sec.

-1/1000

sec., B (T)

(Auto) 8 sec. -

1/1000

sec. (When the AE Finder is used.)

Electromagnetic release.
Selectable release lock or self-timer mode.

Instant return, front coated mirror, with mirror lock-up capability.
Interchangeable (Waist Level Finder N, Prism Finder FP401, AE Prism Finder FE401 and AE Finder FK402)

.

Standard: Rangefinder

Spot/Microprism

with Fresnel Lens,accessory screens available.

(Same as the M645 Super)
94%

Things to Watch

*

When using the AE Prism Finder FE401

When using this finder it is imperative that the Film

Speed Dial on the Roll Film Holder is properly set for

the

IS0

number of the loaded film, as it interfaces with

this finder. If not done, wrong exposures may result.

* When the mirror is locked in the up position.

The Focal Plane Shutter Curtain may be damaged if

the camera faces strong light sources, especially the
sun. Return mirror to normal position or use lens cap
to prevent such damage.

Common Sense Camera Care and Practice

Your Mamiya 645 PRO TL is a precision mechanical-

+

Do not store camera at temperatures exceeding 40%

optical-electronic instrument, built for heavy and reliable

(lOYF)and-lO’C(15”F)andprotect

it against humid

professional use. It will reward you with a long service life or

sea air environment.

if properly treated and maintained. Please observe these

*

Periodically exercise your camera and lenses by

common sense

rules:

making blind exposures at various shutter speeds.

Read instructions before using camera.

Also move the diaphragm ring and focusing mounts of
Protect camera against shocks and falls. Use all lenses repeatedly.
neckstrap supplied with it, whenever possible.
Protect camera against rain and moisture. If it gets

wet, wipe it with a soft, clean cloth.

Do not touch lens or mirror surfaces. To

remove

dust
use air blower or lens tissue. To remove fingerprints
use lens tissue and lens cleaning fluid if necessary.
Do not touch gold plated contacts on camera body,
lenses, rollfilm holders and AE Finders. If necessary.
wipe them with a clean, dry cloth.
Operate the film advance lever with even, measured
strokes, to assure proper spacing.
Always test your equipment before going on important
assignments.

Battery Advice

:

*

The battery

supplied

with the camera by the factory
may have been subject to storage conditions which
have reduced its service

life. Check

it before use and
always carry spare batteries.
Be sure to wipe battery contacts before inserting it, in
order to insure proper contact.
Be sure to observe proper polarity. (Match +pole of
battery with

+mark

in battery chamber.)
Battery life varies, depending on make, frequency of
use, age, storage condition and ambient temperature.
(Place battery in External Battery Case accessory
which you wear inside your clothing, when
photographing in cold climates)
Always remove the battery when camera is not used
for longer than a few weeks and store it in a cool,

dry

place.

Storage

*

*

When storing camera

:

Turn shutter release selector dial to the red dot. (Off

position)
Leave shutter and mirror in uncocked position.

The same applies to leaf shutter lenses.

@

Special Advice To Professional Photographers

Your Mamiya 645 PRO TL is designed for heavy
professional use and will give you a long

service

life if
properly maintained. Your camera and lenses have
many moving parts which require periodic lubrication. Its
electronic components, too, are subject to wear and tear
and are affected by ambient conditions like dust, sand,
sea air, heat and moisture.

If cameras had odometers like automobiles. it would be
easier to specify servicing schedules. May we suggest

that if you shoot thousands of film rolls

per

year, you send

your equipment annually for servicing by the Mamiya

distributor in your country
