6955 VALJEAN AVE, VAN NUYS, CA 91406
PH: (818)994-6498 / FAX: (818)994-6458
/ www.louroe.comtechsupport@louroe.com
DESCRIPTION
Louroe Model E-ML is an omni-directional, mic level low
impedance, electret condenser microphones. It can pick up
normal sounds approximately 15’ away if mounted to a wall,
or within a 30’ circle if ceiling mounted. The microphone is
mounted inside a single Bell Box for outdoor of in a moist
environment. The unit comes with with pre-made 20’ cable
with stereo plug for direct connect to the audio input of the IP
camera.
APPLICATION
The Model E-ML Microphones can be used in
situations such as:
E-ML
MICROPHONES
TECHNICAL DATA SHEET
MODEL E-ML MICROPHONE
Parking structures
Secured walkways
Maintenance yards
IMPORTANT NOTICE
When this equipment is used as part of an
audio monitoring system, the law requires
that the public be given notice of AUDIO
MONITORING ON THE PREMISES. A
deca l noti ce is includ ed with each
microphone shipped.
Federal Law References:
Federal Regulations, US Code, Title 18.
Crime and Criminal Procedure, Sec 2510.
MONITORING
These Premises
Building peripherals
Entry gates
Gas Stations
Any area requiring protection
from weather
R
U
T
C
A
F
U
N
A
M
AUDIO
On
®
FEATURES
Easy connection to an IP camera
Microphone can pick up normal sounds 15' away
Mounts inside a standard single gang Bell Box for
surface mounting
May be located up to 20' from IP Camera or pre-amp.
Used in moist or damp environment
E
D
I
N
SPECIFICATIONS
T
H
E
Sensitivity
Frequency response
Output Impedance
Current drain
Supply voltage
Microphone faceplate Stainless steel
Dimensions
Weight
Shipping Weight
-45 dB/pa
50 Hz to 8 kHz
1kW
0.8mA
1.8Vdc to 4.5Vdc
2 3/4” W x 4 1/2” H
15.5 oz
1 lb
D-ML_specs 12/14
