LINKSYS SRW2008, SRW2008P, SRW2008MP User Manual

8-Port 10/100 Ethernet Switch with Webview

USER GUIDE

BUSINESS SERIES

Model: SRW2008/SRW2008P/SRW2008MP (EU)

About This Guide

Icon Descriptions

While reading through the User Guide you may see various icons that call attention to specific items. Below is a description of these icons:

NOTE: This check mark indicates that there is

a note of interest and is something that you should pay special attention to while using the product.

WARNING: This exclamation point indicates

that there is a caution or warning and it is something that could damage your property or product.

About This Guide

WEB: This globe icon indicates a noteworthy

website address or e-mail address.

Online Resources

Website addresses in this document are listed without http:// in front of the address because most current web browsers do not require it. If you use an older web browser, you may have to add http:// in front of the web address.

Resource Website

Linksys Europe www.linksys.eu

Linksys International www.linksys.com/international

Linksys www.linksys.com

Glossary www.linksys.com/glossary

Network Security www.linksys.com/security

Linksys is a registered trademark or trademark of Cisco Systems, Inc. and/ or its affiliates in the U.S. and certain other countries. Copyright © 2008 Cisco Systems, Inc. All rights reserved. Other brands and product names are trademarks or registered trademarks of their respective holders.

8-Port 10/100/1000 Gigabit Switch with Webview

Table of Contents

Chapter 1: Introduction 1

Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Chapter 2: Product Overview 2

SRW2008 - Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

SRW2008P/SRW2008MP - Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Back Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Chapter 3: Installation 4

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Positioning the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Placement Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Desktop Placement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Rack-Mount Placement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Wall-Mount Placement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Chapter 4: Conguration Using the Console Interface 8

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Conﬁguring the HyperTerminal Application. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Connecting to the Switch through a Telnet Session . . . . . . . . . . . . . . . . . . . . . . . . 8

Conﬁguring the Switch through the Console Interface. . . . . . . . . . . . . . . . . . . . . . 9

Switch Main Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

System Conﬁguration Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Port Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Port Conﬁguration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Chapter 5: Advanced Conguration 17

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Accessing the Web-based Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Setup > Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Device Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

System Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

PoE Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Setup > Network Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Identiﬁcation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

IP Conﬁguration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Setup > Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Set Time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Local Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Daylight Saving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

8-Port 10/100 Ethernet Switch with Webview

Table of Contents

SNTP Servers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Port Management > Port Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Port Conﬁguration Detail. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Port Management > Link Aggregation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Link Aggregation Detail. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Port Management > LACP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Port Management > PoE Power Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

VLAN Management > Create VLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Single VLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

VLAN Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

VLAN Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

VLAN Management > Port Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

VLAN Management > Ports to VLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

VLAN Management > VLAN to Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Join VLAN Detail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

VLAN Management > GVRP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Statistics > RMON Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Statistics > RMON History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

Log Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

RMON History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

Statistics > RMON Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

Statistics > RMON Events. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

Add Event . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

Statistics > Port Utilization. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Statistics > 802.1x Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Statistics > GVRP Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

ACL > IP based ACL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

ACL > MAC based ACL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

Security > ACL Binding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

Security > RADIUS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

Security > TACACS+ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

Security > 802.1x Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

Setting Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

Security > Ports Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

Security > Multiple Hosts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

Security > Storm Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

QoS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

QoS > CoS Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

CoS Default . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

QoS > Queue Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

QoS > DSCP Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

QoS > Bandwidth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

QoS > Basic Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

8-Port 10/100 Ethernet Switch with Webview

iii

Table of Contents

QoS > Advanced Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

Out of Proﬁle DSCP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

Policy Name . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

New Class Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

New Aggregate Policer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40

Spanning Tree. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40

Spanning Tree > STP Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40

Spanning Tree > Global STP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41

Global Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41

Bridge Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41

Spanning Tree > STP Port Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

Spanning Tree > RSTP Port Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

Spanning Tree > MSTP Properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

Spanning Tree > MSTP Instance Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

Spanning Tree > MSTP Interface Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

Multicast > IGMP Snooping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

Multicast > Bridge Multicast. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46

Multicast > Bridge Multicast Forward All . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46

SNMP > Global Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46

SNMP > Views. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47

SNMP > Group Proﬁle. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48

SNMP > Group Membership. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48

SNMP > Communities. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49

Base Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49

Advanced Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50

SNMP > Notiﬁcation Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50

SNMP > Notiﬁcation Recipient . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50

Admin > User Authentication. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51

Admin > Static Address. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51

Query . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52

Admin > Dynamic Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52

Query . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52

Admin > Logging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52

Admin > Port Mirroring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53

Admin > Cable Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53

Admin > Save Conﬁguration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54

Via TFTP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54

Via HTTP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54

Backup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54

Admin > Firmware Upgrade. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54

Admin > Reboot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55

Admin > Factory Defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55

Admin > Server Logs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55

8-Port 10/100 Ethernet Switch with Webview

Table of Contents

Admin > Memory Logs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56

Admin > Flash Logs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56

Appendix A: About Gigabit Ethernet and Fiber Optic Cabling 57

Gigabit Ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57

Fiber Optic Cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57

Appendix B: Introduction 58

Startup Menu Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58

Appendix C: Glossary 60

Appendix D: Specications 64

Appendix E: Warranty Information 69

Exclusions and Limitations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69

Obtaining Warranty Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69

Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70

Appendix E: Regulatory Information 71

FCC Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .71

Safety Notices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .71

Industry Canada Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .71

Avis d’ Industrie Canada . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .71

EC Declaration of Conformity (Europe) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .71

User Information for Consumer Products Covered by EU Directive 2002/96/EC on Waste

Electric and Electronic Equipment (WEEE) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72

Appendix I: Contact Information 76

8-Port 10/100 Ethernet Switch with Webview

Chapter 1

Introduction

Chapter 1: Introduction

Welcome

This guide covers three product models.

SRW2008 • 8-port 10/100/1000 Ethernet Switch with

WebView. Includes 8 10/100/1000 RJ-45 ports and 2 shared MiniGBIC slots.

SRW2008MP • 8-port 10/100/1000 Ethernet Switch

with WebView and Maximum POE (Power over Ethernet) Includes 8 10/100/1000 RJ-45 ports and 2 shared MiniGBIC slots.

SRW2008P • 8-port 10/100/1000 Ethernet Switch with

WebView and POE (Power over Ethernet) Includes 8 10/100/1000 RJ-45 ports and 2 shared MiniGBIC slots.

For the purpose of this manual, whenever a feature applies to all models, the model number will be referenced as SRW2008x. If a specific model number is mentioned, then the feature is specific to that model.

The rich management functionality of the WebView switches includes SNMP, RMON, Telnet, and HTTP Management options, allowing you to flexibly integrate and manage these devices in your network.

The SRW2008P and SRW2008MP support Automatic Load Sensing - Power control circuitry automatically detects Power over Ethernet on access point before providing power. Power feeding of Ethernet limited for fixed 10/100 Base-T/TX ports. The SRW2008MP can provide maximum output power per PoE port up to 15.4W on 8 ports simultaneously. while the SRW2008P can provide maximum output power on 4 ports simultaneously or 8 ports at half power.

The Linksys WebView Managed switch allows you to expand your network securely. Configuration of the Switch is secured using SSL for web access. User control is secured using 802.1x security using a RADIUS authentication mechanism and can also be controlled using MAC-based filtering.

Extensive QoS features makes the solution ideal for realtime applications like Voice and Video. The 4 priority queues together with the Weighted Round Robin and Strict Priority scheduling techniques facilitate efficient coexistence of real-time traffic with data traffic allowing them each to meet their QoS needs. Individual users or applications can be prioritized above others using various Class of Service options - by port, layer 2 priority (802.1p), and Layer 3 priority (TOS or DSCP). Intelligent Broadcast, and Multicast storm control minimizes and contain the effect of these types of traffic on regular traffic. IGMP Snooping limits bandwidth-intensive video traffic to only the requestors without flooding to all users. Incoming traffic can be policed and outgoing traffic can be shaped allowing you to control network access and traffic flow.

There are features that allow you to expand and grow your network of switches. Link aggregation allows multiple high-bandwidth trunks between switches to be setup. This also provides a level of reliability in that the system continues to operate if one of the links break. Spanning Tree (STP), Fast Spanning Tree, and Rapid Spanning Tree (RSTP) allow you to build a mesh of switches increasing the availability of the system.

8-Port 10/100/1000 Gigabit Switch with Webview

Chapter 2

Product Overview

Chapter 2: Product Overview

SRW2008 - Front Panel

The LEDs and ports are located on the front panel of the Switch.

Front Panel

LEDs

SYSTEM (Green) The system LED lights up to

indicate that the Switch is powered on.

LINK/ACT (Green) The LINK/ACT LED lights up

to indicate a functional network link through the corresponding port (1 through 8) with an attached device. It flashes to indicate that the Switch is actively sending or receiving data over that port.

Gigabit (Orange) The Gigabit LED lights

up to indicate a Gigabit connection on the corresponding port (1 through 8).

miniGBIC1/2 The mini-GBIC (gigabit interface

converter) port is a connection point for a mini-GBIC expansion module, so the Switch can be uplinked via fiber to another switch. Each MiniGBIC port provides a link to a high-speed network segment or individual workstation at speeds of up to 1000Mbps.

Use the Linksys MGBT1, MGBSX1, or MGBLH1 mini-GBIC modules with the Switch. The MGBSX1 and the MGBLH1 require fiber cabling with LC connectors, while the MGBT1 requires a Category 5e Ethernet cable with an RJ-45 connector.

SRW2008P/SRW2008MP - Front Panel

The LEDs and ports are located on the front panel of the Switch.

Front Panel

LEDs

SYSTEM (Green) The system LED lights up to

indicate that the Switch is powered on.

Ports

1-8 The Switch is equipped with 8 auto-

sensing, Ethernet network ports, which use RJ-45 connectors. The Fast Ethernet ports support network speeds of 10Mbps, 100Mbps, or 1000Mbps. They can operate in half and full-duplex modes. Auto-sensing technology enables each port to automatically detect the speed of the device connected to it (10Mbps, 100Mbps, or 1000Mbps), and adjust its speed and duplex accordingly.

Console The Console port is where you can

connect a serial cable to a PC’s serial port for configuration using your PC’s HyperTerminal program. Refer to Chapter 4: Using the Console Interface for Configuration for more information.

LINK/ACT (1-8) (Green) The LINK/ACT LED

lights up to indicate a functional network link through the corresponding port (1 through 8) with an attached device. It flashes to indicate that the Switch is actively sending or receiving data over that port.

PoE (Orange) The PoE LED lights up to indicate

a device is connected utilizing Power over Ethernet on the corresponding port (1 through

8).

Ports

1-8 The Switch is equipped with 8 auto-

sensing, Ethernet network ports, which use RJ45 connectors. The Fast Ethernet ports support network speeds of 10Mbps or 100Mbps.

They can operate in half and full-duplex modes. Auto-sensing technology enables each port to automatically detect the speed of the device connected to it (10Mbps or 100Mbps), and adjust its speed and duplex accordingly.

8-Port 10/100/1000 Gigabit Switch with Webview

Chapter 2

miniGBIC1/2 The mini-GBIC (gigabit interface

Console The Console port is where you can

connect a serial cable to a PC’s serial port for configuration using your PC’s HyperTerminal program. Refer to Chapter 4: Using the Console Interface for Configuration for more information.

Product Overview

Back Panel

The console and power ports are located on the back panel of the Switch.

Back Panel

POWER The Power port is where you will

connect the AC power.

8-Port 10/100/1000 Gigabit Switch with Webview

Chapter 3

Installation

Chapter 3: Installation

Overview

This chapter will explain how to connect network devices to the Switch. The following diagram shows a typical network configuration.

Internet

Cable/

DSL

Modem Router

Wireless

Access

Point

Desktop Notebook

Typical Network Configuration

Uplink via Fiber to Switch

Administrator’s Notebook

1U high rack for rack-mount placement, or horizontally on the wall.

Desktop Placement

Attach the rubber feet to the recessed areas on the 1. bottom of the Switch.

Place the Switch on a desktop near an AC power 2. source.

Keep enough ventilation space for the Switch and 3. check the environmental restrictions mentioned in “Appendix D: Specifications” as you are placing the Switch.

Connect the Switch to network devices according to 4. the Hardware Installation instructions below.

When you connect your network devices, make sure you don’t exceed the maximum cabling distance of 100 meters (328 feet).

Positioning the Switch

Before you choose a location for the Switch, observe the following guidelines:

Make sure that the Switch is accessible and that the • cables can be connected easily.

Keep cabling away from sources of electrical noise, • power lines, and fluorescent lighting fixtures.

Position the Switch away from water and moisture • sources.

To ensure adequate air flow around the Switch, be • sure to provide a minimum clearance of two inches (50mm).

Do not stack free-standing Switches more than four • units high.

Placement Options

There are three ways to physically install the Switch, either set the Switch on its four rubber feet for desktop placement, mount the switch in a standard-sized, 19-inch

8-Port 10/100/1000 Gigabit Switch with Webview

Chapter 3

Installation

Rack-Mount Placement

When rack-mounting the Switch, please observe the following guidelines:

Elevated Operating Ambient • If installed in a closed

or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than room ambient. Therefore, consideration should be given to installing the equipment in an environment compatible with the maximum ambient temperature (Tma) specified by the manufacturer.

Reduced Air Flow • Installation of the equipment

in a rack should be such that the amount of air flow required for safe operation of the equipment is not compromised.

Mechanical Loading • Mounting of the equipment in

the rack should be such that a hazardous condition is not achieved due to uneven mechanical loading.

Circuit Overloading • Consideration should be given

to the connection of the equipment to the supply circuit and the effect that overloading of the circuits might have on overcurrent protection and supply wiring. Appropriate consideration of equipment nameplate ratings should be used when addressing this concern.

Make sure the brackets are properly attached to the 3. Switch.

Use the appropriate screws (not included) to securely 4. attach the brackets to your rack.

Mounting in Rack

Reliable Earthing • Reliable earthing of rack-mounted

equipment should be maintained. Particular attention should be given to supply connections other than direct connections to the branch circuit (e.g. use of power strips).

To rack-mount the Switch in any standard 19-inch rack, follow the instructions described below.

Place the Switch on a hard flat surface with the front 1. panel facing you.

Attach a rack–mount bracket to one side of the Switch 2. with the supplied screws. Then attach the other bracket to the other side.

WARNING: Make sure you use the screws

supplied with the mounting brackets. Using the wrong screws could damage the Switch and would invalidate your warranty.

Attaching the Brackets

8-Port 10/100/1000 Gigabit Switch with Webview

Chapter 3

Installation

Print this page at 100% size, cut along the dotted line and place on the wall to drill precise spacing.

Wall-Mount Placement

When mounting the Switch on the wall, the Switch should be mounted horizontally. The front panel should face either up or down. The unit should not be positioned vertically when mounted. You will need two suitable screws to mount the Switch. Use the template above to plan your installation.

sturdy and make sure the location is within reach of the power outlet.

Drill two holes into the wall. Make sure the holes are 2.

3.7 inches (94 mm) apart. You can print the template from this page.

Insert a screw into each hole, and leave 3 mm (0.12 in) 3. of its head exposed.

Maneuver the Switch so the wall-mount slots line up 4. with the two screws.

Place the wall-mount slots over the screws and slide 5. the Switch down until the screws fit snugly into the wall-mount slots.

Proper Wall-Mount Orientation (Horizontal)

NOTE: Linksys is not responsible for damages

incurred by insecure wall-mounting hardware.

Determine where you want to mount the Switch. 1. Ensure that the wall you use is smooth, flat, dry and

8-Port 10/100/1000 Gigabit Switch with Webview

Incorrect Wall-Mount Orientation (Vertical)

Congratulations! The wall-mount installation of the Switch is complete.

Chapter 3

Hardware Installation

To connect network devices to the Switch, follow these instructions:

Make sure all the devices you will connect to the Switch 1. are powered off.

For 10/100Mbps devices, connect a Category 5 Ethernet 2. network cable to one of the numbered ports on the Switch. For a 1000Mbps device, connect a Category 5e Ethernet network cable to one of the numbered ports on the Switch.

Connect the other end to a PC or other network 3. device.

Repeat steps 2 and 3 to connect additional devices.4.

If you are using the mini-GBIC port, then connect the 5. mini-GBIC module to the mini-GBIC port. For detailed instructions, refer to the module’s documentation.

Installation

If you will use the Switch’s console interface to 6. configure the Switch, then connect the supplied serial cable to the Switch’s Console port, and tighten the captive retaining screws. Connect the other end to your PC’s serial port. (This PC must be running the VT100 terminal emulation software, such as HyperTerminal.)

Connect the supplied power cord to the Switch’s power 7. port, and plug the other end into an electrical outlet.

WARNING: Make sure you use the power

cord that is supplied with the Switch. Use of a different power cord could damage the Switch.

Power on the network devices connected to the 8. Switch. Each active port’s corresponding Link/Act LED will light up on the Switch. If a port has an active Gigabit connection, then its corresponding Gigabit LED will also light up.

NOTE: If you need to reset the Switch, unplug

the power cord from the back of the Switch. Wait a few seconds and then reconnect it.

8-Port 10/100/1000 Gigabit Switch with Webview

Chapter 4

Configuration Using the Console Interface

Chapter 4: Configuration Using the Console Interface

Overview

The Switch features a menu-driven console interface for basic configuration of the Switch and management of your network. The Switch can be configured using CLI through the console interface or through a telnet connection. This chapter describes console interface configuration. Configuration can also be performed through the web utility, which is covered in the next chapter.

Configuring the HyperTerminal Application

Click the 1. Start button.

Select 2. Programs > Accessories > Communications > HyperTerminal.

Select a port to communicate with the switch. Select 4. COM1, COM2, or TCP/IP.

HyperTerminal Connect To Screen

Set the serial port settings as follows, then click 5. OK.

Bits per Second: 38400

Databits: 8

Parity: None

Stop bits: 1

Start > Programs > Accessories > Communications > HyperTerminal

Enter a name for this connection. In the example, the 3. name of the connection is SRW2008. Select an icon for the application, then click OK.

HyperTerminal Connection Description Screen

Flow control: None

HyperTerminal Properties Screen

Connecting to the Switch through a Telnet Session

8-Port 10/100/1000 Gigabit Switch with Webview

Open a command line editor and enter 1. telnet

192.168.1.254. Then, press the Enter key.

The 2. Login screen will now appear. The first time you open the CLI interface, select Edit and hit Enter. Enter admin in the User Name field. Leave the Password field blank.

Chapter 4

Press the Esc button and you will return to the login screen. Use the right arrow button to navigate to Execute and press the Enter button to enter the CLI interface.

Configuration Using the Console Interface

System Configuration Menu

Configuring the Switch through the Console Interface

The console screens consist of a series of menus. Each menu has several options, which are listed vertically. You select a menu option when you highlight it; pressing the Enter key activates the highlighted option.

To navigate through the menus and actions of the console interface, use the up or down arrow keys to move up or down, and use the left or right arrow keys to move left or right. Use the Enter key to select a menu option, and use the Esc key to return to the previous selection. Menu options and any values entered or present will be highlighted. The bottom of the screen lists the actions available.

Switch Main Menu

The Main Menu screen displays six menu choices: System Configuration Menu, Port Status, Port Configuration, Help, and Log Out.

System Configuration Menu options:

System Information1.

Management Settings2.

User and Password Settings3.

Security Settings4.

IP Configuration5.

File Management6.

Restore System Default Settings7.

Reboot System8.

0. Back to Main Menu.

System Information

From the System Information screen you can check current firmware versions and other general switch information.

Main Menu

8-Port 10/100/1000 Gigabit Switch with Webview

System Information

Chapter 4

Configuration Using the Console Interface

Versions

The Versions screen displays the Boot Version, Software Version, Loader Version and the Hardware Version.

Versions

Boot Version This file runs when the Switch is turned on.

It performs power-on diagnostics and loads the operating system for the Switch.

Software Version This file contains the programming

code that runs the Switch.

Hardware Version The current hardware setup of the

Switch.

General System Information

The General System Information screen displays the System Description, System Up Time, System Mac Address, System Contact, System Name and System Location.

Management Settings

From the Management Settings screen, you can set Serial Port Session Configuration, Telnet Session Configuration, or Secure Telnet (SSH) Configuration.

Management Settings

Serial Port Configuration

On the Serial Port Configuration screen, the Switch’s baud rate is displayed.

Select Edit and press the Enter key to make changes. Toggle to the desired speed and when your changes are complete, press the Esc key to return to the Action menu. Select Save and press the Enter key to save your changes. To exit, select Quit and press the Enter key.

Select Edit and press the Enter key to make changes. When your changes are complete, press the Esc key to return to the Action menu. Select Save and press the Enter key to save your changes. To exit, select Quit and press the Enter key.

General Information

Serial Port Configuration

Telnet Configuration

On the Telnet Configuration screen, the time-out is displayed. The value is entered in seconds. If you do not want the Telnet session to timeout, you may enter a value of 0 sec.

8-Port 10/100/1000 Gigabit Switch with Webview

Chapter 4

Configuration Using the Console Interface

Telnet Configuration

SSH Configuration

On the SSH Configuration screen, you can select SSH Server Configuration, SSH Server Status, SSH Crypto Key Generation, and SSH Keys Fingerprints.

SSH Configuation

SSH Server Configuration

On the SSH Server Configuration screen, the SSH Server can be enabled or disabled by navigating to the SSH Server option and using the SPACE bar to toggle the option. The SSH Server Port can be modified by entering in the value.

SSH Server Configuration

SSH Status

The SSH Status screen displays whether the SSH Server is enabled, the RSA and DSA key status, and any open SSH sessions.

Select Refresh to update the screen if necessary. To exit, select Quit and press the Enter key.

SSH Status

SSH Crypto Key Generation

On the SSH Crypto Key Generation screen, the SSH Public Key Algorithm can be toggled between RSA and DSA using the SPACE bar to toggle the option. The SSH Public Key Length cannot be modified.

8-Port 10/100/1000 Gigabit Switch with Webview

Chapter 4

SSH Crypto Key Generation

SSH Keys Fingerprints

On the SSH Keys Fingerprints screen, the RSA and DSA keys will be displayed if they have been generated.

Select Refresh to update the screen if necessary. To exit, select Quit and press the Enter key.

Configuration Using the Console Interface

NOTE: The Username & Password Settings screen

can also be used to set passwords for other users.

Security Settings

The Security Settings screen enables you to configure security settings on the Switch, as well as generate and display the certificate.

SSH Keys Fingerprints

User & Password Settings

From this screen, you can administer the user names and passwords of those accessing the Switch.

Security Settings

SSL Certificate Generation

Use the Certificate Generation screen to specify a devicegenerated certificate.

The following fields are specified:

Public Key Length Specifies the SSL RSA key length.

(Range: 512 - 2048)

Organization Name Specifies the organization name.

(Range: 1 - 64)

Locality or City Name Specifies the location or city name.

(Range: 1 - 64)

State or Province Name Specifies the state or province

name. (Range: 1 - 64)

Country Name Specifies the country name. (Range:

2 - 2)

Validity Term Specifies number of days certification is

valid. (Range: 30 - 3650)

User & Password Settings

8-Port 10/100/1000 Gigabit Switch with Webview

Chapter 4

Configuration Using the Console Interface

SSL Certificate Generation

Show Certificate

Use the Show Certificate screen to display the internal certificate.

SSL Certificate

Disable Active Management Profile

Selecting this option will prompt you to confirm that you want to disable the Active Management Profile.

IP Address Configuration

The IP Address Settings screen allows you to set the IP information for the Switch.

IP Address Configuration

IP Address The IP Address of the Switch is displayed. (The

default IP address is 192.168.1.254.) Verify that the address you enter is correct and does not conflict with another device on the network.

Subnet Mask The subnet mask of the Switch is

displayed.

IP Configuration

The IP Configuration screen displays these choices: the Switch’s IP Address Settings, HTTP, HTTPS Configuration and Network Configuration.

Default Gateway The IP address of your network’s

default gateway is displayed.

Management VLAN The VLAN ID number is displayed.

DHCP client The status of the DHCP client is displayed.

If you want the Switch to be a DHCP client, then select ENABLE. If you want to assign an static IP address to the Switch, then enter the IP settings and select DISABLE.

Select Edit to make changes. When your changes are complete, press the Esc key to return to the Action menu, and select Save to save your changes.

HTTP

The HTTP screen displays the status and port number of the HTTP Server.

IP Configuration

8-Port 10/100/1000 Gigabit Switch with Webview

Chapter 4

HTTP

HTTPS Configuration

Use the HTTPS Configuration screen to configure HTTPS settings. You can enable or disable the HTTPS server and configure the port on which the session is enabled.

Configuration Using the Console Interface

Ping

The Ping screen displays the IP address of the location you want to contact.

Select Edit to change the IP address, and select Execute to begin the ping test.

After the ping test is complete, the Ping screen displays the IP address, status, and statistics of the ping test.

HTTPS

Nework Configuration

The Network Configuration screen offers a choice of two tests, Ping and TraceRoute.

Network Configuration

Traceroute

The TraceRoute screen displays the IP address of the address whose route you want to trace.

Select Edit to change the IP address, and select Execute to begin the traceroute test.

After the traceroute test is complete, the TraceRoute screen displays the IP address, status, and statistics of the traceroute test.

8-Port 10/100/1000 Gigabit Switch with Webview

Chapter 4

Configuration Using the Console Interface

File Management

The File Management screen allows you to upload or download files, such as the startup configuration, boot, or image file, using a TFTP server.

Select Edit to change the settings. When your changes are complete, press the Esc key to return to the Action menu, and select Execute to upload or download the designated file. After you download a new image file, the device should be rebooted.

If you are downloading a new boot image, please follow these steps:

Reboot System

Select Reboot System and press the Enter key if you want to restart the Switch. You will be asked if you want to continue. Press the y key to reboot the Switch, or press the n key to cancel. After the Switch has rebooted, the Switch Main Menu screen will appear.

Reboot System

Back to Main Menu

Select Back to Main Menu if you want to return to the main menu.

Port Status

Download the new boot code. DO NOT RESET THE 1. DEVICE.

Download the new software image. 2.

Reset the device now.3.

NOTE: When downloading a configuration file,

be sure that it is a valid configuration file. If you have edited the file, ensure that only valid entries have been configured.

Restore System Default Settings

To restore the Switch back to the factory default settings, select Restore System Default Settings and press the Enter key. You will be asked if you want to continue. Press the y key to restore the Switch’s default settings, or press the n key to cancel.

On the Switch Main Menu screen, select Port Status and press the Enter key if you want to view the status information for the Switch’s ports.

The Port Status screen displays the port numbers, their status, Link status, speed and duplex mode, and status of flow control, which is the flow of packet transmissions.

If you want to change any settings for a port, you must use the Port Configuration screen.

Port Status

Port Configuration

Restore Default

8-Port 10/100/1000 Gigabit Switch with Webview

On the Switch Main Menu screen, select Port Configuration and press the Enter key if you want to configure the Switch’s ports.

Chapter 4

The Port Configuration screen displays the port numbers, their status, auto-negotiation status, speed and duplex mode, and status of flow control, which is the flow of packet transmissions.

Configuration Using the Console Interface

Help

Select Help and press the Enter key if you want to view the help information. This screen explains how to navigate the various screens of the console interface.

8-Port 10/100/1000 Gigabit Switch with Webview

Chapter 5

Advanced Configuration

Chapter 5: Advanced Configuration

Overview

This chapter describes the features included in the Webbased Utility. All of the features shown in this chapter, unless specifically identified, are included in the all of Fast Ethernet switches. Additional features for specific switches are noted.

Accessing the Web-based Utility

NOTE: The web-based utility is optimized for

viewing with a screen resolution of 1024 x

768. Internet Explorer version 5.5 or above is recommended.

Open your web browser and enter 192.168.1.254 into the Address field. Press the Enter key and the login screen will appear.

NOTE: The LEDs displayed in the web-based

utility are not the same as the LEDs on the front panel of the Switch. The front panel LEDs display different status information, which is described in Chapter 2: Overview.

The LEDs on the Setup Summary screen display status information about their corresponding ports. A green LED indicates a connection, while a grey LED indicates no connection. An orange LED indicates the port has been closed down by the administrator. When you click a port’s LED, the statistics for that port are displayed.

NOTE: After configuring values using the

web-based utility, you may be required to refresh the page to see the updated configuration.

Setup > Summary

The Summary screen provides device and system information about the Switch.

NOTE: The default IP address of the device

is 192.168.1.254. If you have modified this address, enter the correct IP address. The device should be on the same subnet as the management station used to configure the device. .

The first time you open the web-based utility, enter admin in the User Name field, and leave the Password field blank. Click the OK button. You can set a password later from the System Password screen.

The first screen that appears is the Setup Summary screen. Twelve main tabs are accessible from the web-based utility: Setup, Port Management, VLAN Management, Statistics, ACL, Security, QoS (Quality of Service), Spanning Tree, Multicast, SNMP, Admin, and Logout. Click one of the main tabs to view additional tabs.

Setup > Summary

Device Information

System Name Displays the name for the Switch, if one

has been entered on the Setup > Network Settings tab.

IP Address The IP address of the Switch is displayed here

(configurable from Setup > Network Settings tab).

Subnet Mask The Subnet Mask of the Switch is displayed

here (configurable from Setup > Network Settings tab).

8-Port 10/100/1000 Gigabit Switch with Webview

DNS Servers The DNS Servers are displayed here

(configurable from Setup > Network Settings tab).

Default Gateway The Default Gateway is displayed here

(configurable from Setup > Network Settings tab).

Chapter 5

Advanced Configuration

Address Mode Indicates whether the Switch is configured

with a Static or Dynamic IP address (configurable from Setup - Network Settings tab).

Base MAC Address This is the MAC address of the

Switch.

System Information

Serial Number The serial number of the Switch is

displayed.

Model Name The model name of the Switch is

displayed.

Hardware version The current hardware version is

displayed.

Boot Version The current boot version is displayed.

Firmware Version The current software version is

displayed.

System Location The system location is displayed here

(configurable from Setup > Network Settings tab).

System Contact The contact person for this Switch

is displayed here (configurable from Setup > Network Settings tab).

System Uptime This displays the amount of time that

has elapsed since the Switch was last reset.

Current Time The system time is displayed here

(configurable from Setup > Time tab).

PoE Information

Maximum Available Power Indicates the maximum

amount of power the device can supply.

System Operation Status Indicates whether the PoE

function is on or off.

Mainpower Consumption Displays how much power is

currently used.

Setup > Network Settings

The Network Settings screen allows you to assign DHCP or static IP settings to interfaces and assign default gateways.

Identification

System Name This field allows you to assign a system

name.

System Location This field is used for entering a

description of where the Switch is located, such as 3rd floor.

System Contact Enter the administrative contact person

in this field.

System Object ID The system object identifier is

displayed here.

Base MAC Address This is the MAC address of the

Switch.

8-Port 10/100/1000 Gigabit Switch with Webview

IP Configuration

Management VLAN This drop-down allows you to select

the Management VLAN.

IP Address Mode This drop-down allows you to select

Static or Dynamic IP address configuration.

Host Name Enter the DHCP Host Name here.

IP Address If using a static IP address, enter the IP address

here.

Subnet Mask Enter the subnet mask of the currently

configured IP address.

Default Gateway Enter the IP address of the Default

Gateway.

Chapter 5

Advanced Configuration

DNS Server Enter the primary DNS Server information.

Click the Save Settings button to save your changes or click Cancel Changes to discard the information.

Setup > Time

The Time screen allows you to configure the time settings for the Switch.

Setup > Time

Set Time

Use System Time When this option is selected, the local

hardware clock is utilized.

Use SNTP Time When this option is selected, the time is

synchronized to an SNTP (Simple Network Time Protocol) server..

Daylight Saving

Daylight Saving Select Daylight Saving to enable it on

the Switch. If the Switch should use US daylight savings, then select USA. If the Switch should use EU daylight savings, then select European. If it should use another kind of daylight savings, then select Custom and complete the From and To fields.

Time Set Offset (1-1440) For non-US and European

countries, specify the amount of time for daylight savings. The default is 60 minutes.

From If you selected Other for the Daylight Saving

setting, then enter the date and time when daylight savings begins.

To If you selected Other for the Daylight Saving setting,

then enter the date and time when daylight savings ends.

Recurring If you selected Other for the Daylight Saving

setting and daylight savings has the same start and end dates and times every year, then select Recurring.

From If you selected Recurring, then enter the date and

time when daylight savings begins.

To If you selected Recurring, then enter the date and time

when daylight savings ends.

SNTP Servers

Server1 Enter the primary SNTP server here.

Server2 Enter a secondary SNTP server here.

SNTP Polling Interval (60-86400) The value defined

here determines the amount of time (in seconds) before the Switch polls the SNTP server. The default value is every 1024 seconds (approx. 17 minutes).

Local Time

Hours The hour can be entered here.

Minutes The minutes can be entered here.

Seconds The seconds can be entered here.

Month The month can be entered here.

Day The day can be entered here.

Year The year can be entered here.

Time Zone Enter the difference between Greenwich

Mean Time (GMT) and local time.

8-Port 10/100/1000 Gigabit Switch with Webview

Click the Save Settings button to save your changes or click Cancel Changes to discard the information.

Port Management > Port Settings

The Port Management > Port Settings screen shows you the settings for each of the Switch’s ports.

Port The number of the port. To use an SFP module, click

on the Detail button of the appropriate port (G1, G2).

Description Displays a brief description of the port (can

be entered by clicking on the Detail button).

Administrative Status The port can be taken offline by

selecting the Down option. When Up is selected, the port can be accessed normally.

Link Status Up indicates a port has an active connection,

Down indicates there is no active connection or the port has been taken offline by an Administrator.
