Linksys One IP Phone
Model PHB1100
QUICK INSTALLATION GUIDE
Linksys One IP Phone Model PHB1100
Linksys One IP Phone Model PHB1100
New Call Redial more
1
2
3
DEF
ABC
6
5
4
MNO
JKL
GHI
9
8
7
WXYZ
TUV
PQRS
REDIAL TRANSFER HOLD
#
0
OPER
TION GUIDE
ALLA
QUICK INST
One IP Phone
®
Linksys
Model PHM1200
Linksys One IP Phone Model PHB1100
159386
1
10/100 SW 10/100 PC
DC48V
Linksys One IP Phone Model PHB1100
45
o
OR
60
o
92645
10/100 SW 10/100 PC
DC48V
2
Linksys One IP Phone Model PHB1100
137369
3
10/100 SW 10/100 PC
DC48V
Linksys One IP Phone Model PHB1100
(Optional; Not included)
137370
Optional
4
10/100 SW 10/100 PC
DC48V
Linksys One IP Phone Model PHB1100
137713
Linksys One IP Phone Model PHB1100
5
10/100 SW 10/100 PC
DC48V
Optional
144610
6
Linksys One IP Phone Model PHB1100
Linksys One IP Phone Model PHB1100
PHB1100 IP Phone Regulatory Compliance and
Safety Information
The Linksys One PHB1100 IP Phone meets the following regulatory compliance and safety standards:
Specification Description
Regulatory Compliance Products with the CE Marking indicate compliance with the 89/336/EEC and 73/23/EEC directives,
which include the safety and EMC standards listed below.
Safety UL 60950
CSA-C22.2 No. 60950
EN 60950
IEC 60950
EMC FCC Part 15 (CFR 47) Class B
ICES-003 Class B
EN55022 Class B
CISPR22 Class B
EN55024
EN50082-1
EN 61000-3-2
EN 61000-3-3
EN 61000-6-1
Telecom (IP Phones) FCC Part 68 (HAC)
FCC Part 15 Class B Compliance
This Equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC rules. These
limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Canada Class B Notice
The Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulation. Cet appareil numerique
de la class B respecte toutes les exigences du Reglement sur le materiel brouilleur du Canada.
FCC Part 15 - Radio Frequency Devices
This device complies with FCC Part 15B. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received including interference that may cause undesired operation.
Linksys One IP Phone Model PHB1100
Safety Information
The following statements are warnings or safety guidelines. A warning means danger. You are in a situation that could cause
bodily injury. Before working on equipment, be aware of the hazards involved with electrical circuitry and standard safety
practices to prevent accidents.
Linksys One IP Phone Model PHB1100
Warning
Warning
IMPORTANT SAFETY INSTRUCTIONS
This warning symbol means danger. You are in a situation that could cause bodily injury. Before you
work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar with
standard practices for preventing accidents. Use the statement number provided at the end of each
warning to locate its translation in the translated safety warnings that accompanied this device.
SAVE THESE INSTRUCTIONS
FCC Part 15 Class B Warning
A shielded-type power cord is required in order to meet FCC emission limits and also to prevent
interference to the nearby radio and television reception. It is essential that only the supplied power
cord be used. Use only shielded cables to connect I/O devices to this equipment. You are cautioned
that changes or modifications not expressly approved by the party responsible for compliance could
void your authority to operate the equipment.
Warning
Work During Lightning Activity
Do not work on the system or connect or disconnect cables during periods of lightning activity.
Warning
Warning
Warning
Installation Instructions
Read the installation instructions before connecting the system to the power source.
SELV Circuit
To avoid electric shock, do not connect safety extra-low voltage (SELV) circuits to telephone-network
voltage (TNV) circuits. LAN ports contain SELV circuits, and WAN ports contain TNV circuits. Some
LAN and WAN ports both use RJ-45 connectors. Use caution when connecting cables.
Equipment Installation
Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
Linksys One IP Phone Model PHB1100
Warning
Comply with Local National Electrical Codes
Installation of the equipment must comply with local and national electrical codes.
Linksys One IP Phone Model PHB1100
Warning
Telephone Receiver Warning
Telephone receivers produce a magnetic field that can attract small magnetic objects such as pins and
staples. To avoid the possibility of injury, do not place the handset where such objects may be picked
up.
Warning
Product Disposal
Ultimate disposal of this product should be handled according to all national laws and regulations.
Caution Inline power circuits provide current through the communication cable. Use the Linksys-provided cable or a
minimum 24AWG communication cable.
Power Supply Safety Warnings
When using the PHB1100 IP Phone with the optional external power supply, observe the following safety warnings:
Warning
Warning
Warning
TN Power
The device is designed to work with TN power systems.
Ground Conductor Warning
Never defeat the ground conductor or operate the equipment in the absence of a suitably installed
ground conductor. Contact the appropriate electrical inspection authority or an electrician if you are
uncertain that suitable grounding is available.
Power Supply Installation Warning
The power supply must be placed indoors.
Linksys One IP Phone Model PHB1100
Warning
Circuit Breaker
This product relies on the building’s installation for short-circuit (overcurrent) protection. Ensure that
the protective device is rated not greater than: 120 VAC, 15A U.S. (240 VAC, 10A international)
Linksys One IP Phone Model PHB1100
Warning
Main Disconnecting Device
The plug-socket combination must be accessible at all times, because it serves as the main
disconnecting device.
Caution Only use the Linksys-specified power supply. Refer to the installation manual provided with this product.
Cell Phone Interference Caution
Using a cell, mobile, or GSM phone, or two-way radio in close proximity to a Linksys IP phone might cause interference. For more
information, refer to the manufacturer's documentation of the interfering device.
Using External Devices with Your PHB1100 IP Phone
The following information applies when you use external devices with the PHB1100 IP Phone:
Linksys recommends the use of good quality external devices (speakers, microphones, and headsets) that are shielded (screened) against
unwanted radio frequency (RF) and audio frequency (AF) signals.
Depending on the quality of these devices and their proximity to other devices such as mobile phones or two-way radios, some audio noise
may still occur. In these cases, Linksys recommends that you take one or more of the following actions:
• Move the external device away from the source of the RF or AF signals.
• Route the external device cables away from the source of the RF or AF signals.
• Use shielded (screened) cables for the external device, or use cables with a better shield (screen) and connector.
• Shorten the length of the external device cable.
• Apply ferrites or other such devices on the cables for the external device.
Linksys cannot guarantee the performance of the system because Linksys has no control over the quality of external devices, cables, and
connectors. The system will perform adequately when suitable devices are attached using good quality cables and connectors.
Caution In European Union countries, use only external speakers, microphones, and headsets that are fully compliant
with the EMC Directive [89/336/EC].
Linksys One IP Phone Model PHB1100
Linksys One IP Phone Model PHB1100
