Kyocera NET VIEWER User Guide

Legal Notes

Unauthorized reproduction of all or part of this guide is prohibited.

The information in this guide is subject to change without notice.

We cannot be held liable for any problems arising from the use of this product, regardless of the information herein.

Regarding Trademarks

KYOCERA Net Viewer is a trademark of KYOCERA Document Solutions Inc.

Microsoft®, Windows®, and Internet Explorer are registered trademarks of Microsoft Corporation in the U.S. and/or other
countries.

All other brand and product names herein are registered trademarks or trademarks of their respective companies.

Examples of the operations given in this guide support the Microsoft Windows Server 2008 R2 and Server 2012 printing
environments. Essentially the same operations are used for Microsoft Windows Server 2003, Server 2008, XP, Vista,
Windows 7, and Windows 8 environments.

The features described in this guide vary depending on your device model.

© 2013 KYOCERA Document Solutions Inc.

Table of Contents

Chapter 1 Quick Start

Starting and Logging In ................................................................................................................. 1-1

Editing Authentication Options ...................................................................................................... 1-1

Device Discovery .......................................................................................................................... 1-2

Adding Devices ....................................................................................................................... 1-2

Automatic Device Discovery .................................................................................................... 1-2

Excluded Devices .................................................................................................................... 1-3

Host Discovery .............................................................................................................................. 1-3

Activating Host Services .......................................................................................................... 1-4

Adding Hosts ........................................................................................................................... 1-5

Automatic Host Discovery ....................................................................................................... 1-6

Excluded Hosts ....................................................................................................................... 1-6

User Interface ................................................................................................................................ 1-7

Main Menu ............................................................................................................................... 1-7

My Views ................................................................................................................................. 1-7

Default Views .......................................................................................................................... 1-7

Toolbar .................................................................................................................................... 1-7

List View .................................................................................................................................. 1-7

Closing the Application Window .................................................................................................... 1-8

Chapter 2 View Management

View As ......................................................................................................................................... 2-1

Default Views ................................................................................................................................ 2-1

Map View ................................................................................................................................. 2-2

My Views ....................................................................................................................................... 2-3

Adding a New Folder to My Views ........................................................................................... 2-3

Renaming a Folder or View ..................................................................................................... 2-3

Removing a Device, Account, or Host from View .................................................................... 2-4

Updating and Saving a View .................................................................................................... 2-4

Duplicating a View ................................................................................................................... 2-4

Renaming a View .................................................................................................................... 2-4

Deleting a View ........................................................................................................................ 2-5

Dynamic View ............................................................................................................................... 2-5

Adding a Dynamic View ........................................................................................................... 2-5

Manual View .................................................................................................................................. 2-5

Adding a Manual View Using Selection ................................................................................... 2-6

Exporting a View to a File .............................................................................................................. 2-6

Exporting a List to a File ................................................................................................................ 2-6

Exporting Device Information to a File ........................................................................................... 2-6

Resizing the View Areas ............................................................................................................... 2-7

Refresh ......................................................................................................................................... 2-7

Folder Reports .............................................................................................................................. 2-7

Creating and Exporting a Folder Report .................................................................................. 2-7

Searches ....................................................................................................................................... 2-8

Searching ................................................................................................................................ 2-8

KYOCERA Net Viewer 5.3 i

Advanced Searching ............................................................................................................... 2-8

Chapter 3 Device

Device Properties .......................................................................................................................... 3-1

Displaying Device Properties ................................................................................................... 3-1

Displaying Device Home Page ...................................................................................................... 3-2

Administrator Login ....................................................................................................................... 3-2

Address Book ................................................................................................................................ 3-2

Adding Contacts ...................................................................................................................... 3-3

Adding Groups ........................................................................................................................ 3-3

Adding a Contact to a Group ................................................................................................... 3-3

Deleting Contacts and Groups ................................................................................................ 3-4

Editing Contacts and Groups ................................................................................................... 3-4

One Touch Keys ...................................................................................................................... 3-4

Copying Contacts and Groups ................................................................................................ 3-5

Exporting an Address Book List ............................................................................................... 3-6

Searching the Address Book ................................................................................................... 3-6

Device View Printer Installation ..................................................................................................... 3-7

Installing Printer Drivers in Device View .................................................................................. 3-7

Upgrading Printer Drivers in Device View ................................................................................ 3-7

Uninstalling Printer Drivers in Device View .............................................................................. 3-8

Device Users ................................................................................................................................. 3-8

Adding Device Users ............................................................................................................... 3-8

Searching the Device User List ............................................................................................... 3-9

Setting a Simple Login Key .................................................................................................... 3-10

Searching the Simple Login Key List ..................................................................................... 3-10

Jobs ............................................................................................................................................ 3-11

Showing Job Detail ................................................................................................................ 3-11

Exporting the Job Log ............................................................................................................ 3-11

Searching a Job List .............................................................................................................. 3-11

Stored Jobs ................................................................................................................................. 3-12

Viewing Stored Jobs .............................................................................................................. 3-12

Printing Stored Jobs .............................................................................................................. 3-12

Printing a Stored Job List ....................................................................................................... 3-12

Deleting Stored Jobs ............................................................................................................. 3-13

Searching Stored Jobs .......................................................................................................... 3-13

Document Box ............................................................................................................................. 3-13

Viewing and Editing a Document Box .................................................................................... 3-13

Adding a Document Box ........................................................................................................ 3-14

Exporting a Document Box List ............................................................................................. 3-15

Viewing Document Properties ............................................................................................... 3-15

Viewing a Document .............................................................................................................. 3-16

Downloading a Document ..................................................................................................... 3-16

Searching a Document Box ................................................................................................... 3-16

Moving Documents Between Document Boxes ..................................................................... 3-16

Virtual Mailbox ............................................................................................................................. 3-17

Viewing Virtual Mailboxes ...................................................................................................... 3-17

Deleting Virtual Mailboxes ..................................................................................................... 3-17

Exporting a Virtual Mailbox List ............................................................................................. 3-18

Advanced Virtual Mailbox Options ......................................................................................... 3-18

Adding a New Virtual Mailbox ................................................................................................ 3-19

Editing a Virtual Mailbox ........................................................................................................ 3-19

Device Notification Settings ........................................................................................................ 3-19

Setting a Device Notification ................................................................................................. 3-19

Advanced Menu .......................................................................................................................... 3-20

Authentication Settings .......................................................................................................... 3-21

Network Groups .................................................................................................................... 3-24

ii User Guide

TCP/IP Send Data ................................................................................................................. 3-25

Device Applications ..................................................................................................................... 3-26

Installing an Application on Multiple Devices ......................................................................... 3-26

Installing an Application on One Device ................................................................................ 3-27

Activating an Installed Application on Multiple Devices ......................................................... 3-27

Activating an Installed Application on One Device ................................................................. 3-28

Viewing Installed Applications ............................................................................................... 3-29

Searching Applications .......................................................................................................... 3-29

Chapter 4 Account

Administrator Login ....................................................................................................................... 4-1

Adding Account Devices ............................................................................................................... 4-1

Creating a New Account ................................................................................................................ 4-1

Account Properties ........................................................................................................................ 4-2

Device Accounts ........................................................................................................................... 4-3

Account Devices ........................................................................................................................... 4-3

Viewing Accounts and Devices ..................................................................................................... 4-3

Exporting Accounting Information to a File .................................................................................... 4-3

Counter Reports ............................................................................................................................ 4-4

Automatic Counter Reset ........................................................................................................ 4-4

Creating a Counter Report ...................................................................................................... 4-4

Viewing and Changing Counter Report Settings ..................................................................... 4-4

Manage Device ............................................................................................................................. 4-5

Managing an Accounting Device ............................................................................................. 4-5

Hiding or Showing Unmanaged Devices ................................................................................. 4-5

Reset Counters ............................................................................................................................. 4-5

Resetting Job Accounting Counters ........................................................................................ 4-5

Accounting Notification Settings .................................................................................................... 4-5

Setting an Accounting Notification .......................................................................................... 4-6

Device Accounting Settings .......................................................................................................... 4-6

Accessing Device Accounting Settings ................................................................................... 4-6

Enabling or Disabling Job Accounting ..................................................................................... 4-6

Selecting Media Type Counters .............................................................................................. 4-7

Handling Errors ....................................................................................................................... 4-7

Setting Permit Processing and Copy Counter ......................................................................... 4-8

Accounting Multi-Set ..................................................................................................................... 4-8

Setting Multiple Accounting Devices ....................................................................................... 4-8

Selecting Accounting Settings in Multi-Set .............................................................................. 4-8

Selecting Accounting Source Settings ..................................................................................... 4-9

Export .......................................................................................................................................... 4-10

Exporting Account ID List ...................................................................................................... 4-11

Exporting Counter Information ............................................................................................... 4-11

Exporting Accounting Information .......................................................................................... 4-11

Chapter 5 Host

Adding Queues ............................................................................................................................. 5-1

Common Settings Options ....................................................................................................... 5-2

Conflicts Options ..................................................................................................................... 5-2

Editing a Queue Name .................................................................................................................. 5-3

Host View Printer Installation ........................................................................................................ 5-3

Allowing the Print Spooler to Access Client Connections ........................................................ 5-3

Allowing a Remote Administration Exception .......................................................................... 5-3

Installing Printer Drivers in Host View ...................................................................................... 5-4

Upgrading Printer Drivers in Host View ................................................................................... 5-4

Uninstalling Printer Drivers in Host View ................................................................................. 5-5

Installing Additional Drivers ..................................................................................................... 5-5

KYOCERA Net Viewer 5.3 iii

Viewing a List of Printer Drivers .................................................................................................... 5-6

Viewing a List of Print Queues ...................................................................................................... 5-6

Selecting Host Login Settings ....................................................................................................... 5-6

Selecting Domain Administrator Login Settings ............................................................................ 5-7

Exporting Host Information to a File .............................................................................................. 5-7

Configuring Printer Settings .......................................................................................................... 5-7

Available Printer Settings Options ................................................................................................. 5-8

Chapter 6 Communication Settings

Setting Device Communications ................................................................................................... 6-1

Network Interface Settings ............................................................................................................ 6-1

TCP/IP Port ............................................................................................................................. 6-2

Secure Protocol Settings ............................................................................................................... 6-2

Login Settings ............................................................................................................................... 6-2

Account Polling Settings ............................................................................................................... 6-2

Device Polling Settings ................................................................................................................. 6-3

Chapter 7 Multi-Set

Quick Mode ................................................................................................................................... 7-1

Custom Mode ................................................................................................................................ 7-1

Creating Settings From a Device ............................................................................................. 7-2

Creating Settings From a File .................................................................................................. 7-3

Creating New Settings ............................................................................................................. 7-4

Overwriting Settings ...................................................................................................................... 7-5

Chapter 8 Firmware Upgrade

Firmware Upgrade Risks ............................................................................................................... 8-1

Upgrading the Firmware ................................................................................................................ 8-1

Finishing Options .......................................................................................................................... 8-2

Chapter 9 Workspaces

Adding a New Workspace ............................................................................................................. 9-1

Opening an Existing Workspace ................................................................................................... 9-1

Import and Export Workspaces ..................................................................................................... 9-2

Importing a File to a New Workspace ...................................................................................... 9-2

Exporting a Workspace to a File .............................................................................................. 9-2

Viewing Recent Workspaces ........................................................................................................ 9-2

Chapter 10 Options

Editing E-mail Options ................................................................................................................. 10-1

Editing Authentication Options .................................................................................................... 10-1

Editing Device Polling Options .................................................................................................... 10-2

Editing SNMP Trap Options ........................................................................................................ 10-2

Editing Account Polling Options .................................................................................................. 10-3

iv User Guide

1 Quick Start

You can organize and monitor network device information with many different
features that are available, through default views, as well as custom views that
you can create. To get started, you must log in and set up a workspace by
discovering devices and hosts on your network.

Starting and Logging In

Open the application.

1

If you have administrator rights, your last saved workspace appears and you

2

can proceed with your tasks.

If you just installed the application, and it is the first time you are starting it, the
Select a KYOCERA Net Viewer Workspace dialog box appears. Proceed to
step 4.

If you do not have administrator rights, the network administrator must set up a
user login password for you. Proceed to step 3.

Type your password in the login text box, and then click OK. If your submitted

3

password is accepted, your last saved workspace appears.

If it is the first time you are logging in as a user without administrator rights,
proceed to step 4.

Type or browse your workspace folder, and then click OK. The Add Devices

4

wizard appears and you can add network devices to your workspace.

Editing Authentication Options

You can set up a password for other Windows users to log on to the application.
This feature is only available for administrators.

In the Edit menu, click Options.

1

In the Options dialog box, click Authentication.

2

Select the Enable local password check box.

3

In the New password text box, type a password for a local user. A password is

4

a maximum of 32 characters. A blank password is allowed.

In the Confirm password text box, type the password again.

5

Click OK.

6

KYOCERA Net Viewer 5.3 1-1

Quick Start

Device Discovery

Adding Devices

1

2

Discovery is a process that checks networks for printing devices. If new

devices are found, then the application updates its database with information
about the device. This process can be performed manually for single or multiple
devices, or it can be scheduled to run automatically according to a set schedule.
It is also possible to exclude devices from being discovered.

When the application is launched for the first time, or when a new workspace is
opened, the Add Devices wizard automatically launches.

You can use the Add Devices wizard to add devices to the view list.

In the Device menu, click Discovery > Add devices.

In the Add Devices wizard, select a method for adding devices:

Express

Uses predefined communication settings to find devices in the local network.

Custom

Lets you select settings to find devices on any network.

For the selected method, complete the wizard and click Finish to begin

3

discovery.

Custom Options for Adding Devices

With Custom selected in the Add Devices wizard, you can select the discovery
process to run on your local network, a specific IP address, or a range of IP
addresses. Continue through the wizard to select the following options:

On your local network

Select the discovery type. Click Next to select communication settings and a
discovery schedule, and confirm discovery settings.

By IP address

Type an IPv4 or IPv6 address or host name and click Add to include the
entry in the Selected targets list. You can also click Import to use an IP
address list (.CSV or .TXT). To remove an IP address or host name from the
Selected targets list, select the IP address and click Remove. Click Next to
select communication settings and a discovery schedule, and confirm
discovery settings.

By IP address range

Type a starting and ending IPv4 or IPv6 address and click Add to include the
entry in the Selected network segments list. To remove an IP address
range from the Selected network segments list, select the IP address and
click Remove. Click Next to select communication settings and a discovery
schedule, and confirm discovery settings.

Automatic Device Discovery

You can set up a regular schedule for performing the discovery process. If
devices are frequently added to or removed from the network, performing
discovery on a regular basis keeps the device database up to date.

1-2 User Guide

Scheduling Automatic Device Discovery

You can set a schedule for device discovery.

In the Device menu, click Discovery > Automatic discovery.

1

In the Scheduled Discovery dialog box, choose from these options:

2

Click Properties to edit an existing discovery mode. Make your selections in
the window to set up a recurring schedule, and click Apply changes.

Click Add to create a new discovery mode. In the Add Devices wizard,
make your selections in the window to set up a recurring schedule. On the
Confirm discovery page, click Finish to save your changes.

Click Delete to remove a discovery schedule.

3

Click Close to save your changes and close the Scheduled Discovery dialog

4

box.

Excluded Devices

A device can be excluded from the discovery process. You can remove the
device from view for security purposes.

You can restore a device to the device list with the Include device option.

Quick Start

Host Discovery

Excluding a Device from Discovery

You can exclude a device from the discovery process. This option removes the
device from the device list, and displays it in the Excluded Devices window.
Information about the device is not deleted from the application.

In any Device view or Accounting devices view, select the device to exclude.

1

Right-click on the selected device, and click Delete device.

2

Including a Device

A device that was excluded can be included again. When a device is included, it
appears in the next discovery process.

In the Device menu, click Discovery > Show excluded devices.

1

In the Excluded Devices list, select an excluded device to include.

2

Click Include device.

3

Discovery is a process that checks networks for host computers. If new hosts

are found, the application updates its database with information about the host.
This process can be performed manually for single or multiple hosts, or it can be
scheduled to run automatically according to a set schedule. It is also possible to
exclude hosts from being discovered.

KYOCERA Net Viewer 5.3 1-3

Quick Start

Activating Host Services

For the application to discover hosts, Windows Management Instrumentation
(WMI) and Remote Procedure Call (RPC) services must be active on the host
and target computers.

Installing Certificates for Signed Drivers

For Windows Vista and later, digital signatures are required for hardware­related drivers. Before installing a signed driver, Windows requires a certificate
it trusts. For Microsoft-signed drivers, the certificate is already installed, for
manufacturer-signed drivers, you have to install the certificate on the target host
first.

Select the Security Catalog (.CAT) file from the driver package.

1

In the Security Catalog dialog box > General tab, click View Signature.

2

In the Digital Signature Details dialog box > General tab, click View

3

Certificate.

In the Certificate dialog box > General tab, click Install Certificate.

4

In the Certificate Import Wizard dialog box, click Next.

5

On the Certificate Store page, select Place all certificates in the following

6

store and click Browse.

In the Select Certificate Store dialog box, select Trusted Publishers and click

7

OK.

Click Next, then click Finish.

8

WMI

On the host and target computers, go to Start > Control Panel > System and

1

Security > Administrative Tools > Computer Management.

In the Computer Management dialog box, click Services and Applications.

2

Right-click WMI Control to view Properties.

3

In the WMI Control Properties dialog box, click the Security tab.

4

Click Security.

5

In the Group or user names list, select Administrators.

6

In the Permissions list, select the Allow check box for Remote Enable.

7

1-4 User Guide

RPC

On the host and target computers, go to Start > Control Panel > System and

1

Security > Administrative Tools > Computer Management.

In the Computer Management dialog box, click Services and Applications >

2

Services.

Right-click Remote Procedure Call (RPC), then click Start.

3

Adding Hosts

You can use the Add Hosts wizard to add host computers to the view list.

In the Host menu, click Discovery > Add hosts.

1

In the Add Hosts wizard, select a method for discovering host computers.

2

For the selected method, complete the settings. On the Confirm discovery

3

page, click Finish. If you selected Start immediately on the previous page, the
discovery begins. If you set up a recurring schedule, it is added to the
Scheduled Host Discovery dialog box.

Quick Start

Note: If you are adding hosts for the first time, the Domain Administrator
Login dialog box appears.

You can remove a host by selecting it in Host view and clicking Delete host.
Driver and queue information is also removed. The host is added to the

Excluded Hosts list.

Options for Adding Hosts

In the Add Hosts wizard, you can select from the following options:

Search current domain

Discover hosts on your network. Click Next to select a discovery schedule
and confirm discovery settings.

Browse Active Directory

Select a location in the Active Directory. Click Next to select a discovery
schedule and confirm discovery settings.

Specify IP address range

Type a starting and ending IPv4 or IPv6 address and click Add to include the
entry in the Selected network segments list. To remove an IP address
range from the Selected network segments list, select the IP address and
click Remove. Click Next to select a discovery schedule and confirm
discovery settings.

Specify IP address

Type an IPv4 or IPv6 address or host name and click Add to include the
entry in the Selected targets list. You can also click Import to use an IP
address list (.CSV or .TXT). To remove an IP address or host name from the
Selected targets list, select the IP address and click Remove. Click Next to
select a discovery schedule and confirm discovery settings.

KYOCERA Net Viewer 5.3 1-5

Quick Start

Automatic Host Discovery

You can set up a regular schedule for performing the discovery process. If hosts
are frequently added to or removed from the network, performing discovery on a
regular basis keeps the host database up to date.

Scheduling Automatic Host Discovery

You can set a schedule for host discovery.

In the Host menu, click Discovery > Automatic discovery.

1

In the Scheduled Host Discovery dialog box, choose from these options:

2

Click Properties to edit an existing discovery mode. Make your selections in
the window to set up a recurring schedule, and click Apply changes.

Click Add to create a new discovery mode. In the Add Hosts wizard, make
your selections in the window to set up a recurring schedule. On the
Confirm discovery page, click Finish to save your changes.

Click Delete to remove a discovery schedule.

3

Click Close to save your changes and exit the Scheduled Host Discovery

4

dialog box.

Excluded Hosts

A host can be excluded from the discovery process. You can remove the host
from view for security purposes.

You can restore a host to the host list with the Include host option.

Excluding a Host from Discovery

You can exclude a host from the discovery process. This option removes the
host from the host list, and displays it in the Excluded Hosts window.
Information about the host is not deleted from the application.

In Host view, select the host to exclude.

1

Right-click on the selected host, and click Delete.

2

Including a Host

A host that was excluded can be included again. After a host is included, it
appears in the next Host Discovery.

In the Host menu, click Discovery > Show excluded hosts.

1

In the Excluded Hosts list, select an excluded host to include.

2

Click Include Host.

3

1-6 User Guide

User Interface

Quick Start

The user interface displays the information you need about your network
devices, device accounts, and host computers where the device drivers are
installed.

The screen is divided into two panes. In the navigation pane, you can select
which view appears in the list of the other pane. Each view displays data in a
specified organization of columns and rows (list), or on a layout (map).

The application offers two types of views: custom views that are listed under My
Views, and standard Default Views defined by the application to monitor your
environment.

Main Menu

The main menu is located at the top of the window. Basic operations that affect
the application are in this menu.

My Views

My Views are lists or maps you can create from Default Views or other My
Views. You can customize the type of information you want to see. My Views

are organized in a tree structure that displays folders and My Views nodes.
When you select a custom view under My Views, the application displays the
view (list or map) in the other pane. You can create folders to organize and
manage My Views. You can also add information to My Views by going to the

View menu and clicking Add dynamic view or Add manual view using
selection.

Default Views

Default Views are standard list or map views.

When you select a particular default view, the application displays the view (list
or map) in the other pane. Some Device view options are only available from list
views and not map views.

In Default Views, six standard Device views, two standard Account views, and
three Host views are available. They cannot be removed.

Toolbar

Each view displays a toolbar below the main menu. The toolbar contains icons
for the most common tasks for each view, including managing and editing
devices, accounts, and hosts. You can move your mouse cursor over each icon
to view its corresponding task.

List View

A list of devices, accounts, or hosts display on the window depending on the
selected view. This customizable list provides information that you can
organize. You can expand each row in any Device list view to display more
information. A Map view is also available and displays your devices on a custom
map background.

Identifying Status Icons

In the device or host list view, status icons provide quick information about the
condition of each device. Click the triangle icon to expand the row and see a
description of the condition.

KYOCERA Net Viewer 5.3 1-7

Quick Start

Customizing List Views

You can arrange the information in a device, account, or host list view saved
under My Views. You can update changes to My Views by clicking Update
view in the toolbar. Changes made to Default Views are not saved after you
leave the view.

Showing or Hiding Columns

Right-click on a column heading to open the selection list of columns. Click on a
column name from the list to add to the view. To remove a column from the list
view, click any column heading to open the selection list of columns. Click on a
column name that has a check mark next to it to remove it.

Changing the Width of a Column

To adjust the width of a column, position the cursor over the column divider until
you see the double-headed arrow. Click and drag the arrow for the desired
column size.

Changing the Position of a Column

To move a column to another position in the list view, click on the desired
column heading, then drag it to the desired location.

Sorting Rows in List View

You can sort the information in a list view. Click the column heading to change
the sort order of the rows in the view, using the data in that column as the sort
criteria. An upward triangle indicates rows sorted in ascending order; a
downward triangle indicates rows sorted in descending order.

Expanding a Row in a Device List View

You can expand a row in a Device list view to display more information about a
device. Click the triangle icon to display a 3D image of the device and all
installed options. Other information about the device is displayed, including
model, status, IP address, and print speed.

To collapse the row, click the triangle icon again.

Closing the Application Window

You can close the application window so that it is no longer visible on the
screen, but the application continues to run in the system tray. This is useful if
you want to reduce the number of open windows on your desktop, or if you are
running a task that does not need visual monitoring. To close the application
window, go to the File menu, and then click Close window. To reopen the
application window, double-click the icon in the system tray; or right-click the
icon, and click Restore.

To exit the application, go to the File menu, and click Exit. The application
saves the currently displayed workspace before exiting. This saved workspace
appears the next time the same user opens the application.

1-8 User Guide

View As

2 View Management

The application offers two types of views: custom views that are listed in My
Views, and standard views defined by the application that are listed in Default
Views. The default views are:

Device

General view, Capability view, Counter view, Firmware view, Asset
view, Map view

Accounting

Accounting devices view, Accounts view

Host

Host view, Host driver view, Host queue view

You can create, change, or delete views in My Views. In the Default Views, you
can customize the appearance of the lists, but the changes are not saved after
you leave the view. You cannot make permanent changes to the views in
Default Views.

Default Views

You can switch to a different view by using the View as feature in the View
menu. Select the view you want to change, click View > View as, and click the
new view from the list.

If the original view is in Default Views, the view switches to the selected
default view.

If the original view is in My Views, the view itself changes to the selected
view. To save the view, click Update view.

This feature is not available for Account views or Host views.

The application provides standard views in Default Views that cannot be
removed or edited.

In any view except Map view, you can add or remove columns from the list
temporarily. Right-click on the column heading and select or clear the desired
item. The modified views are not saved when you switch to a different view.

The following default Device views are available:

General view

Displays general information, such as display name, IP address, host name,
toner level, description, location, and model name.

Capability view

Displays support for various device capabilities, such as color or black &
white, print speed, duplex, total memory, HDD/SSD (storage device), scan,
FAX, staple, punch, address book, document box, user list, and job log.

Counter view

KYOCERA Net Viewer 5.3 2-1

View Management

Displays the device counters for total printed pages, copier printed pages,
printer printed pages, FAX/i-FAX printed pages, black & white printed pages,
single color printed pages, full color printed pages, total scanned pages,
copier scanned pages, FAX scanned pages, and other scanned pages.

Firmware view

Displays firmware information, including system firmware, engine firmware,
scanner firmware, FAX firmware (Ports 1 and 2), panel firmware, and NIC
firmware version.

Asset view

Displays asset information, including MAC address, serial number, and
asset number.

Map view

Displays printing devices on a background map of your office.

The following default Account views are available:

Accounting devices view

Displays general information and counters for devices that support
accounting.

Accounts view

Displays account information for managed devices, such as counter totals
for print, copy, FAX, and scan.

The following default Host views are available:

Host view

Displays general information about network host computers.

Host driver view

Displays printer drivers installed on host computers.

Host queue view

Displays the printer queues of host computers.

Map View

Use Map view to display printing devices on a background map of your office.
Printing device properties can be viewed and managed from Map view. The use
of an office map helps to visualize the location of devices throughout an office.

In Default Views, click Map view. The initial map view displays all devices as
icons against a white background. You can import an image of your office layout
to appear in the background, then click and drag each device icon to its office
location. The map is shared by all map views in the current workspace.

Information about a device can be viewed by moving the pointer over the icon.

Importing a Map Background

You can import an image of your office layout to appear in the map view
background.

In Default Views, select Map view.

1

In the View menu, click Map > Import map background.

2

In the Import Map Background dialog box, click Browse to select an image file

3

(.BMP or .JPG), and then click Open.

2-2 User Guide

My Views

View Management

Click OK.

4

Adjusting the Map Size

You can change the size of the map image within the view window.

Use any of the following selections in the Zoom box to change the image size:

Click Zoom in to increase the size of the image one step.

Click Zoom out to decrease the size of the image one step.

Click Zoom to fit to place the entire image within the screen. If you change
the screen size, click Zoom to fit again.

Type a percentage between 50% and 300% in the Zoom box and press

Enter.

Clearing a Map Background

You can remove the background image from the map view. All device icons
retain their position after the change.

In the View menu, select Map > Clear map background.

You can set up custom views in My Views. You can also create folders to
organize the custom views.

In My Views, you can customize the devices, accounts, or hosts being
displayed, as well as column order, number of columns, and other view settings.
You can create a custom view by manual selection (Manual view), or by
matching the current display on the window (Dynamic view). You can save your
changes after modifying the view by going to the View menu and clicking
Update view. You can also click the Manage views icon in My Views to open a
menu for more options.

Adding a New Folder to My Views

You can create folders for your custom views.

In the File menu, click New folder.

1

Type a new name into the text box.

2

To save the new folder name, click outside the text box, or press Enter.

3

Renaming a Folder or View

You can change the name of a folder or view.

In My Views, click to highlight the folder or view you want to rename.

1

In the Edit menu, click Rename.

2

Type the new name, replacing the old name in the text box.

3

To save the new name, click outside the text box, or press Enter.

4

KYOCERA Net Viewer 5.3 2-3

View Management

Removing a Device, Account, or Host from View

You can remove a device, account, or host so that it does not appear in a
custom view. This does not delete the item from the database.

In My Views, select a manual view.

1

In the list view, select a device, an account, or a host to be removed from view.

2

You can select multiple items in the view.

In the Edit menu, click Remove from view.

3

Note: There is no confirmation dialog box after you click Remove from view.

Updating and Saving a View

When any view in My Views changes, an asterisk appears after its name in the
title bar until it is saved. To save the updated view, go to the View menu and
click Update view. Use this feature after any of the following:

Changing the column width or column order, adding or removing columns.

Using View > View as to change the view type.

Sorting the information in list columns.

Duplicating a View

You can create a copy of a view. This is useful if you want to create a new view
that is only slightly different from an existing view.

In My Views, select a view to be copied.

1

In the My Views toolbar, click the Manage views icon and then select

2

Duplicate.

Type the new name, up to 64 characters, and press Enter.

3

Modify the new view, as needed.

4

Renaming a View

You can change the name of a view. Default views cannot be renamed.

In My Views, select the view to be renamed.

1

In the Edit menu, click Rename.

2

Type the new name, up to 64 characters, replacing the old name in the text box.

3

To save the new name, click outside the text box, or press Enter.

4

2-4 User Guide

Dynamic View

View Management

Deleting a View

You can delete a custom view. A deleted view cannot be restored. Default views
cannot be deleted.

In My Views, select the view to be deleted.

1

In the Edit menu, click Delete.

2

Note: There is no confirmation dialog box after you click Delete.

A dynamic view is a copy of a default or custom view that you create in My
Views. A dynamic view matches the current display on the screen:

Device

General view, Capability view, Counter view, Firmware view, Asset
view, Map view

Accounting

Accounting devices view, Accounts view

Host

Host view, Host driver view, Host queue view

Once created, you can name and modify the dynamic view as desired.

A dynamic view cannot be created when a manual view is selected in My

Views.

Manual View

Adding a Dynamic View

You can modify an existing view and save it as a custom view in My Views.

Select a view in Default Views or My Views, except a manual view.

1

Modify the view as desired, then click View > Add dynamic view.

2

Type the name of the new view, up to 64 characters.

3

A manual view is a custom view that includes devices, accounts, or hosts
selected from an existing view.

Device

General view, Capability view, Counter view, Firmware view, Asset
view, Map view

Accounting

Accounting devices view, Accounts view

Host

Host view, Host driver view, Host queue view

Once created, you can name and modify the manual view as desired.
Advanced Search is unavailable for a manual view. A device or account can be

KYOCERA Net Viewer 5.3 2-5

View Management

added to a manual view by selecting it in another view and dragging it to the
manual view.

Adding a Manual View Using Selection

You can create and save a custom view of selected devices, accounts, or hosts.

With any view displayed, select one or more devices, accounts, or hosts from

1

the list or map.

In My Views, click the Manage views icon and select Add manual view using

2

selection.

Type the name of the new view, up to 64 characters.

3

Exporting a View to a File

You can export all view information to a .CSV or .XML file. The .CSV export
uses UTF-8 encoding.

In any view, click the File menu, and then click Export > View.

1

In the Export View to CSV/XML dialog box, type or select a file name and

2

select a file extension (.CSV or .XML).

Click Save.

3

Exporting a List to a File

You can export all list information to a .CSV or .XML file. The .CSV export uses
UTF-8 encoding.

With any Device or Account list view displayed, click the File menu, and then

1

click Export > List.

In the Export List to CSV/XML dialog box, type or select a file name and select

2

a file extension (.CSV or .XML).

Click Save.

3

Exporting Device Information to a File

You can export current information for all workspace devices to a .CSV or .XML
file. The .CSV export uses UTF-8 encoding.

In any Device view, click the File menu, and then click Export > Devices.

1

In the Export Devices to CSV/XML dialog box, type or select a file path. The

2

file must have an extension of .CSV or .XML.

Click Save.

3

2-6 User Guide

Resizing the View Areas

If many views have been saved in My Views, or if your views have long names,
you can see the view list more easily by changing the size of the viewing area.

To change the width of a pane, click the border between the two panes and
drag it right or left.

To change the height of the My Views area, click the top of the Default

Views border and drag it up or down.

Refresh

Device, account, and host information are automatically updated according to
the polling schedules. At any time, you can manually update this information for
one or more devices. The following Refresh options are available:

Refresh

Select one or more devices and click View > Refresh to update the selected
devices.

Refresh all

Click View > Refresh all to update all views.

View Management

Folder Reports

Folder reports provide detailed information about accounts or accounting
devices for all views in a custom folder. The folder must contain custom views
created from Accounting devices view or Accounts view. Once a folder
report is created, it can be exported and saved in .CSV or .XML format.

Accounts Folder Report

This report can be created if the folder contains at least one Accounts view.
Only the accounts selected in the Accounts Folder Report dialog box are
included in the exported report.

Accounting Devices Folder Report

The report can be created if the folder contains at least one Accounting
devices view. Only the devices selected in the Accounting Devices Folder
Report dialog box are included in the exported report.

Creating and Exporting a Folder Report

After creating a folder in My Views and adding custom views from Accounting
devices view or Accounts view, you can create and export an accounts or

accounting devices report.

Right-click on the desired folder and select Folder report, then select

1

Accounts or Accounting devices.

In the Accounts Folder Report or Accounting Devices Folder Report dialog

2

box, select one or more accounts or devices to include in the report.

Click Export.

3

In the Export View to CSV/XML dialog box, select the format type, name the

4

report, and click Save.

KYOCERA Net Viewer 5.3 2-7

View Management

Searches

Two types of searches are available for finding devices, accounts, or hosts with
particular characteristics. Search finds data in the currently displayed view.
Entries are not saved when you move from view to view. Advanced Search
finds all devices, accounts, or hosts in the database for the values selected in
the search dialog box.

Searching

Search will look in columns that have been removed from view. The results are
not saved when you move from view to view, or perform an Advanced Search.
Search does not check the expanded information area of the devices.

The search can find exact matches for full or partial terms in the following
columns or in Map view:

Device search: Display name, IP address, Host name, Model name

Account search: Account ID

Host search: Host name, Driver name, Queue name, IP address, OS

information

Type an alphanumeric search term (64 character maximum) in the text box. As

1

you type, the search examines the data of all the devices, accounts, or hosts in
the original view.

To clear the search term, click the icon next to the Search text box. This

2

removes any text in the text box, and restores the view to the original list of
devices, accounts, or hosts before the search.

Advanced Searching

You can use the Advanced Search feature to find all printing devices,
accounts, or hosts in the database that match your selected criteria. Up to six
properties can be defined for the search. The search results are displayed until
you change to another view or perform another search.

In Default Views, select a view.

1

Note: Advanced search is not available for Host driver view and Host
queue view.

In the Edit menu, click Advanced search.

2

In the Advanced Search dialog box, select a search logic:

3

Match all criteria

This option searches for devices, accounts, or hosts that meet all the search
terms specified in Criteria.

Match any criteria

This option searches for devices, accounts, or hosts that meet at least one of
the search terms specified in Criteria.

In Criteria, select features or properties to find in the search.

4

Property

2-8 User Guide

View Management

Select one property per property list. There are six property lists available.
Properties vary by device model.

Condition

Available conditions depend on the selected property.

Value

Type or select a value in the box.

Click OK. The application searches through all devices, accounts, or hosts and

5

displays those that match the selected criteria. In Map view, the search result
devices appear in their saved position in the office map.

KYOCERA Net Viewer 5.3 2-9

Device Properties

3 Device

The Device menu is used for finding devices and managing device settings.

The Properties dialog box displays settings and status information about the
selected device. To open device properties, select a device, and click the
Properties icon. Settings may differ depending on your selected device. The
settings can include:

Basic device settings

This area shows the Display name, Model, Status, IP address, Host
name, Location, and Description of the printing device. The Panel
message box shows the information currently displayed on the device
operation panel. Display name, Location, and Description can be edited.

Device alert

This area describes alerts that are currently occurring, and any
troubleshooting measures that can be taken.

Media input

This area shows the trays and cassettes that are currently installed, their
capacity, and roughly how much paper they currently contain.

Capabilities

This area shows some of the key specifications of the currently selected
device.

Counters

This area shows a variety of counters for different types of paper or media
and output.

Firmware versions

This area lists the versions of firmware for various parts of the system.

Memory

This area shows the space available on the storage devices, on the optional
ROM and on the RAM disk.

Asset

This area shows the MAC address of the network adapter in the device, the
Serial number of the device itself, and the Asset number which may be

assigned by your organization.

Displaying Device Properties

You can view the properties of a device.

In any Device view, select a device.

1

Click Properties to display information about the selected device.

2

3-1 User Guide

Click Refresh to update any settings that might have been changed on the

3

device while this dialog box was open.

Displaying Device Home Page

Printing devices that contain web servers can display a web page containing
information about the device's current status and settings. The layout and
information shown on this page differs by printing device model. Click Device >

Device home page to display this web page.

Administrator Login

For some models, administrator authentication is required to access selected
features in the Device and Account menus. Available features vary by model.
When you select the feature from a menu, you are prompted to type one of the
following in the Administrator Login dialog box:

Command Center password

Administrator login and Administrator password (with optional Use local
authentication)

Accounting administrator code

Operations on multiple devices do not prompt for the administrator login. Login
options must be configured in the Login section of the Communication
Settings dialog box.

Device

Address Book

The Address Book is a list of individuals and their contact information that is
stored on the device. Each entry for an individual is called a contact, and
contacts can be organized into groups. This contact and group information is
stored on the device, and is used for faxing and scanning operations.

Note: If authentication is set, accessing the address book requires the correct
Login user name and Password in the Communication Settings for the

device. If authentication is not set, the login dialog box may appear, depending
on your model.

The information that can be stored for each contact includes:

Number

Name (and furigana, if applicable)

Cover page (recipient, company, department). This information is

transmitted on a Network FAX.

E-mail

FTP (File Transfer Protocol)

SMB (Server Message Block)

FAX

Internet FAX

You can create One Touch keys to let you access address book entries by
pressing one key on the printing system's operation panel.

KYOCERA Net Viewer 5.3 3-2

Device

Adding Contacts

You can add individuals to the address book stored on a device.

In any Device view, select a device.

1

In the Device menu, click Address book.

2

In the Address Book dialog box, click Add contact.

3

In the Contact Settings dialog box, type the name of the contact in the Name

4

text box. (If applicable, type the furigana in the Furigana text box.)

Type your remaining selections, and then click OK to save the new address

5

book entry.

Adding Groups

Contacts in the address book can be organized into groups. This is useful when
the device sends out notifications of certain types of events, for example.

In any Device view, select a device.

1

In the Device menu, click Address book.

2

In the Address Book dialog box, click Add group.

3

In the Group Settings dialog box, type the name of the new group. The name

4

does not have to be unique.

Click OK.

5

Adding a Contact to a Group

You can search for contacts and add them to an existing group. Each step
requires communication with the device, which may be slow depending on
network conditions.

In any Device view, select a device.

1

In the Device menu, click Address book.

2

In the Address Book dialog box, select a group, and then click Properties.

3

In the Group Settings dialog box, click Add members. The contact list is

4

downloaded from the device and appears in the dialog box.

In the Add Group Members dialog box, select one or more contacts to add,

5

and then click Add.

Click OK in all dialog boxes.

6

3-3 User Guide

You can delete a contact by selecting it from the Group Settings dialog box
and clicking the Remove members icon in the toolbar.

Deleting Contacts and Groups

Contacts and groups can be deleted from the address book when they are no
longer needed.

In any Device view, select a device.

1

In the Device menu, click Address book.

2

In the Address Book dialog box, select one or more contacts or groups.

3

Click Delete, and then click Yes to confirm.

4

The updated information is sent to the device.

Editing Contacts and Groups

The information saved in the Address Book dialog box for each contact or
group can be edited, if necessary.

Device

In any Device view, select a device.

1

In the Device menu, click Address book.

2

In the Address Book dialog box, select a contact or group, and click

3

Properties.

Edit the information in the Contact Settings or Group Settings dialog box, and

4

then click OK to save the changes.

One Touch Keys

You can access Address Book entries for contacts or groups by pressing one
key on the printing system’s operation panel.

The number of One Touch keys that can be created varies depending on your
device. The application does not support this feature on all devices.

Adding One Touch Keys

You can create a list of One Touch keys for an Address Book.

In any Device view, select a device.

1

In the Device menu, click Address book.

2

In the Address Book dialog box, click Show One Touch keys, and then click

3

Add One Touch key.

In the Add One Touch Key dialog box, select settings:

4

Key name

KYOCERA Net Viewer 5.3 3-4

Device

Type a name, to a maximum of 24 characters.

Number

Select a number, to a maximum of 1000 (the maximum number varies by
model), or select Auto to choose the next available number.

Destination

Click Add destination. In the One Touch Key Destination dialog box,
select a contact or group.

Click OK in all dialog boxes.

5

To delete an entry from the One Touch Key dialog box, select the entry in the
list and click the Delete One Touch key icon in the toolbar.

Viewing and Editing One Touch Key Properties

You can view and edit information about One Touch keys for contacts and
groups.

In any Device view, select a device.

1

In the Device menu, click Address book.

2

In the Address Book dialog box, click Show One Touch keys.

3

In the One Touch Key dialog box, select a list item and click One Touch key

4

properties to view the One Touch key details.

In the One Touch Key Properties dialog box, you can edit the Key Name and

5

Destination.

Click OK in all dialog boxes.

6

Searching One Touch Keys

In the One Touch Key dialog box, you can search by Number, Name, Address
number, and Address type. In the One Touch Key Destination dialog box,

you can search by Number, Address type, Name, and Destination.

In any Device view, select a device.

1

In the Device menu, click Address book > Show One Touch keys.

2

In the One Touch Key dialog box, choose an option from the Searchable

3

fields list and type the text you want to find in the Search text box.

To clear the search results and display the entire list again, click the Clear

4

search icon in the toolbar.

Copying Contacts and Groups

You can copy contacts and groups from existing entries.

3-5 User Guide

In any Device view, select a device.

1

In the Device menu, click Address book.

2

In the Address Book dialog box, select the contact or group to copy, and click

3

Copy.

Click Paste.

4

Modify the new contact or group, as needed.

5

Click Close.

6

Exporting an Address Book List

You can export contacts, groups and One Touch lists to a file. Once saved, it
can be imported to the Multi-Set feature.

In any Device view, select a device.

1

Device

In the Device menu, click Address book.

2

In the Address Book dialog box, click Export.

3

Type the file name for the list (.CSV or .XML).

4

Click Save.

5

All contacts, groups and One Touch lists that exist on the device will be
exported to a file.

Searching the Address Book

You can search the device address book to update contact or group
information. Address book information can be searched by Number, Name, E-
mail, FTP, SMB, FAX number or Internet FAX address.

In any Device view, select a device.

1

In the Device menu, click Address book.

2

In the Address Book dialog box, choose an option from the Searchable fields

3

list and type the text you want to find in the Search text box. You can also
search for furigana, if applicable.

To clear the search results and display the entire address book again, click the

4

Clear search icon in the toolbar.

KYOCERA Net Viewer 5.3 3-6

Device

Device View Printer Installation

The printer driver software provides settings to customize output from your
device. You can install printer drivers from the Device menu. Once installed,
drivers can be upgraded or uninstalled.

Installing Printer Drivers in Device View

You can use the Driver Installation wizard to install printer drivers.

In any Device view, select a device.

1

In the Device menu, click Advanced > Install driver.

2

In the Driver Installation wizard, select the host computer where the drivers will

3

be installed. Click Next. If one or more hosts cannot be accessed, a message
appears.

Select one or more printer models to install. Click Next.

4

Click Have disk and browse to find a valid .INF file for each driver being

5

installed. Click Next.

On the Printer settings page, select available settings for each printer driver.

6

The port cannot be changed. The following options open another dialog box for
selecting settings:

You can click Common settings and apply settings to all selected devices.

You can click Conflicts and select from available options.

You can click Import and select a configuration settings file (.KVP).

You can click Export and save current configuration settings in a .KVP file.

Click Next.

On the Confirm settings page, review your selections.

7

Click Finish to install the printer drivers. When installation is finished, you can

8

click Export to save a log file (.TXT).

Click OK.

9

Upgrading Printer Drivers in Device View

You can upgrade printer drivers to a later version.

In any Device view, select a device.

1

In the Device menu, click Advanced > Upgrade driver.

2

In the Driver Upgrade wizard, select the host computers where the drivers are

3

currently installed. Click Next.

3-7 User Guide

Select the drivers to be upgraded, then click Next. Click Have disk and browse

4

to find a valid .INF file for each driver being upgraded.

On the Confirm settings page, review your selections.

5

Click Finish to begin the upgrade process. When upgrade is finished, you can

6

click Export to save an upgrade log file (.TXT).

Click OK.

7

Uninstalling Printer Drivers in Device View

You can use the Driver Uninstallation wizard to uninstall printer drivers.

In any Device view, select a device.

1

In the Device menu, click Advanced > Uninstall driver.

2

In the Driver Uninstallation wizard, select a host or hosts. Click Next.

3

Device

Device Users

Select the check box next to each driver to uninstall. Select at least one driver

4

under each host. Click Next.

On the Confirm settings page, review your selections.

5

Click Finish to begin the uninstallation process. When uninstallation is finished,

6

you can click Export to save an uninstallation log file (.TXT).

Click OK.

7

Device users who are authorized to use a device are on a user list with their
login information and passwords. When user authentication is set, only users
who are administrators on the device are able to use the various functions of the
device.

Note: To access the user list of a device, the correct Login user name and
Password must be in Communication Settings for the device. If an

administrator password is set for the device, then only an administrator can
change the user list.

Adding Device Users

You can add users to the user list located on the device. The Device User List
can be used to control which users are able to operate or access the device.

In any Device view, select a device.

1

In the Device menu, click Users.

2

KYOCERA Net Viewer 5.3 3-8

Device

In the Users dialog box, click Add user.

3

Type information about the user in the dialog box.

4

Click Select to choose from available account IDs.

5

Select Allow administrator access to give the user permission to change

6

device settings. If the check box is cleared, the user only has user access.

Click Advanced to select additional options. Available options vary by model.

7

Language

Select the default operation panel language for the user.

Default screen

Select the default operation panel screen that appears when a user selects

Device System Settings on the device.

Default screen for Send/FAX

Select the default operation panel screen that appears when a user selects

Device System Settings > Send Settings on the device.

Address book type

Select the local address book or an external address book for the user.

Default screen for Favorites/Application

Select the default operation panel screen that appears when a user selects
Device System Settings > Program/Favorites (or Application) on the
device.

Default application

Select the application that appears when a user first logs on to the physical
device.

ID card information

Type the unique alphanumeric value of the ID card for the user.

Authorization

Select permissions for each available printing feature.

Click OK to create the new device user.

8

You can edit a device user by selecting it from the list and clicking Properties.

You can delete a device user by selecting it from the list and clicking Delete

user.

Searching the Device User List

You can search the Users dialog box by Login user name or User name.

In any Device view, select a device.

1

In the Device menu, click Users.

2

3-9 User Guide

In the Users dialog box, choose an option from the Searchable fields list and

3

type the text you want to find in the Search text box. You can also search for
furigana, if applicable.

To clear the search results and display the entire list again, click the Clear

4

search icon in the toolbar.

Setting a Simple Login Key

You can select Simple Login settings for your device.

In any Device view, select a device.

1

In the Device menu, click Users.

2

In the Users dialog box, click Show Simple Login keys.

3

In the Simple Login Keys dialog box, click Add Simple Login key.

4

In the Add Simple Login Key dialog box, select an icon and type a name to a

5

maximum of 32 characters.

Device

Select a Specific number from 1 to 20, or select Next available number to set

6

the number automatically.

Select an Authentication mode.

7

If Use local authentication is selected, click Select from user list. Select a
login user name, and click OK.

If Use network authentication is selected, type a Login user name and
Login password.

For Password login, select On to require a password at login. Select Off to

8

disable the password requirement.

Click Add to create the Simple Login key.

9

You can edit a Simple Login key by selecting it and clicking Properties.

You can remove an entry from the Simple Login Keys dialog box by selecting it
and clicking Delete Simple Login key.

Searching the Simple Login Key List

You can search the Simple Login Keys dialog box by Simple Login key
number or Simple Login key name.

In any Device view, select a device.

1

In the Device menu, click Users.

2

KYOCERA Net Viewer 5.3 3-10

Device

Jobs

In the Users dialog box, choose an option from the Searchable fields list and

3

type the text you want to find in the Search text box.

To clear the search results and display the entire list again, click the Clear

4

search icon in the toolbar.

With Jobs, you can view information about jobs currently in the queue for the
device. Job logs display information about recent jobs that were processed.

Four types of status are available: Print jobs status, Send job status,
Store job status, and Scheduled job status.

Three types of job logs are available: Print job log, Send job log, and Store

job log.

Showing Job Detail

You can view detailed information about a particular job. The information
displayed depends on the type of job.

In any Device view, select a device.

1

In the Device menu, click Jobs.

2

In the Jobs dialog box, click View as, and select a job status or job log.

3

In the job list, select a job and click Properties.

4

In the Job Detail dialog box, view the job information and then click Close when

5

finished.

Exporting the Job Log

Job logs can be exported to files for use in other applications.

In any Device view, select a device.

1

In the Device menu, click Jobs.

2

In the Jobs dialog box, click Export and select a job log to export.

3

Click Browse and specify the file name and location to save the file.

4

In Maximum entries, select or enter the number of lines to save in the log.

5

Click OK.

6

Searching a Job List

You can search a Job list by Job name or User name to find a specific job.

3-11 User Guide

Stored Jobs

In any Device view, select a device.

1

In the Device menu, click Jobs.

2

In the Jobs dialog box, choose an option from the Searchable fields list and

3

type the text you want to find in the Search text box.

To clear the search results and display the entire list again, click the Clear

4

search icon in the toolbar.

With Stored Jobs, you can view Temporary and Permanent print jobs stored
on the hard disk. Stored print jobs can be printed or deleted from hard disk
memory. You can also print a list of stored jobs. This feature is supported for
some devices with a hard disk installed.

Viewing Stored Jobs

You can view information about Temporary or Permanent print jobs stored on
the hard disk.

Device

In any Device view, select a device.

1

In the Device menu, click Stored jobs.

2

At any time, click Refresh to update the view.

3

Printing Stored Jobs

You can print selected Temporary or Permanent jobs stored on the hard disk.

In any Device view, select a device.

1

In the Device menu, click Stored jobs.

2

In the Stored Jobs dialog box, select a job to print.

3

Click Print and select Print selected jobs.

4

Click Yes in the confirmation dialog box to print.

5

Printing a Stored Job List

You can print a list of Temporary or Permanent jobs stored on the hard disk.

In any Device view, select a device.

1

In the Device menu, click Stored jobs.

2

KYOCERA Net Viewer 5.3 3-12

Device

In the Stored Jobs dialog box, click Print and select Print temporary job list

3

or Print permanent job list.

Deleting Stored Jobs

You can delete one or more Temporary or Permanent print jobs from hard disk
memory.

In any Device view, select a device.

1

In the Device menu, click Stored jobs.

2

In the Stored Jobs dialog box, select a delete option in the toolbar:

3

Select a print job from the list. Click Delete > Delete selected jobs.

For Temporary jobs, click Delete > Delete temporary jobs.

For Permanent jobs, click Delete > Delete permanent jobs.

For all jobs stored in the device, select Delete all jobs.

Click Yes in the confirmation dialog box to finish.

4

Document Box

Searching Stored Jobs

You can search the stored jobs list by Job name or Owner to find a specific job.

In any Device view, select a device.

1

In the Device menu, click Stored jobs.

2

In the Stored Jobs dialog box, choose an option from the Searchable fields

3

list and type the text you want to find in the Search text box.

To clear the search results and display the entire list again, click the Clear

4

search icon in the toolbar.

A Document Box is a type of virtual mailbox on a device. It is used by
individuals and groups to manage files that are stored on the device.

Note: If authentication is set, accessing the document box requires the
correct Login user name and Password in the Communication Settings for
the device. If authentication is not set, the login dialog box may appear,
depending on your model.

Viewing and Editing a Document Box

You can view and edit information about jobs stored in document boxes on the
storage device.

In any Device view, select a device.

1

3-13 User Guide

In the Device menu, click Document box.

2

In the Document Box dialog box, select a box.

3

In the toolbar, click Box properties.

4

In the Box Properties dialog box, you can view and edit selected information.

5

Available options vary by model.

Name

Type the new box name.

Type

View the document box type.

Number

Select an available box number.

Owner

Select a new owner from the list.

Owner setting

Select the type of owner from the list.

Domain

Select a domain.

Usage

Shows the current usage in megabytes.

Restrict usage (MB)

Set the value from 1 to 30000 MB.

Automatically delete files delay (days)

Select the time the file is saved in device memory, from 1 to 31 days.

Shared

Select to enable the box for multiple users.

Password change

You can set or change your password for the box, if desired.

Overwrite setting

Select to permit a new document to replace an existing document with the
same name.

Subaddress

Type the subaddress. Available with subaddress boxes.

Delete after printed

Select this option to permanently remove a document from the box after it is
printed.

Device

Adding a Document Box

You can create a new document box on the storage device. A maximum of 1000
document boxes is supported.

KYOCERA Net Viewer 5.3 3-14

Device

In any Device view, select a device.

1

In the Device menu, click Document box.

2

In the Document Box dialog box, click Add box.

3

In the Add Box dialog box, type the Name for the new box.

4

Note: The default box type is Custom box. Some devices also support a FAX
box or Subaddress box for receiving faxes.

Type a password if you want to create a password-protected document box.

5

Specify values or use the default values for the other settings.

6

Click OK.

7

You can delete a document box by selecting it from the list and clicking Delete
box.

Exporting a Document Box List

You can save the document box list to your computer or network. Once saved, it
can be imported to the Multi-Set feature.

In any Device view, select a device.

1

In the Device menu, click Document box.

2

In the Document Box dialog box, select a box from the list.

3

In the toolbar, click Export.

4

Name and save the file (.CSV or .XML).

5

Viewing Document Properties

You can view the properties of a document by displaying an image of the
document in the document box.

In any Device view, select a device.

1

In the Device menu, click Document box.

2

In the Document Box dialog box, select the document you want to see.

3

In the toolbar, click Document properties.

4

Click OK.

5

3-15 User Guide

Viewing a Document

You can display a thumbnail and preview image of a document in a document
box.

In any Device view, select a device.

1

In the Device menu, click Document box.

2

In the Document Box dialog box, select a document box and click View.

3

You can choose from these options:

Thumbnail

You can view icons of document images.

Preview pane

You can view an image of a document, and if needed, select the options in

View > Preview to refine your view.

Note: Support for these options varies by model.

Device

Downloading a Document

You can download a document from a document box to your local computer.

In any Device view, select a device.

1

In the Device menu, click Document box.

2

In the Document Box dialog box, select a document to download.

3

Click Download document.

4

In the Save As dialog box, select a location to save the file to, type a file name,

5

select PDF, TIF, JPG, or XPS file type, and click Save.

Searching a Document Box

In a document box, you can search by name to find a specific file.

In any Device view, select a device.

1

In the Device menu, click Document box.

2

In the Document Box dialog box, choose an option from the Searchable fields

3

list and type the text you want to find in the Search text box.

To clear the search results and display the entire list again, click the Clear

4

search icon in the toolbar.

Moving Documents Between Document Boxes

You can drag documents between document boxes on the same device.

KYOCERA Net Viewer 5.3 3-16

Device

Virtual Mailbox

In any Device view, select a device.

1

In the Device menu, click Document box.

2

In the Document Box dialog box, under Custom box, select the document box

3

containing the file to move.

Select one or more files, and move them by dragging from the list view to the

4

destination document box under Custom box.

Click Yes in the confirmation dialog box to finish.

5

With Virtual Mailboxes, you can view the details of virtual mailboxes created
on the hard disk.

This feature is supported for some models with a hard disk installed. A
maximum of 255 virtual mailboxes can be created.

Viewing Virtual Mailboxes

You can view information about virtual mailboxes on the hard disk.

In any Device view, select a device.

1

In the Device menu, click Virtual mailboxes.

2

In the Virtual Mailboxes dialog box, choose an option from the Searchable

3

fields list and type the text you want to find in the Search text box.

To clear the search results and display the entire list again, click the Clear

4

search icon in the toolbar.

At any time, click Refresh all to update the list.

5

Deleting Virtual Mailboxes

You can delete a virtual mailbox from hard disk memory. Only one virtual
mailbox can be deleted at a time.

In any Device view, select a device.

1

In the Device menu, click Virtual mailboxes.

2

In the Virtual Mailboxes dialog box, select a virtual mailbox.

3

Click Delete mailbox, then click Yes to confirm.

4

If a password was set, type the password. If the typed password is not correct,
the virtual mailbox is not deleted.

3-17 User Guide

Exporting a Virtual Mailbox List

You can save the virtual mailbox list to your computer or network. Once saved,
it can be imported into the printer driver.

In any Device view, select a device.

1

In the Device menu, click Virtual mailboxes.

2

In the Virtual Mailboxes dialog box, select a virtual mailbox and click Export

3

list.

Name and save the file.

4

Advanced Virtual Mailbox Options

You can change the following virtual mailbox settings if you have administrator
privileges:

Maximum VMB size

A numerical value, varying by model, can be set from 0 to 9999 MB. Select
"0" to prevent use of the virtual mailbox.

Change master password

A numerical value can be set from 1 to 65535, or the password can be
removed. An administrator can use the master password to override or
change virtual mailbox passwords.

Delete all virtual mailboxes

Erases all virtual mailbox data from the hard disk.

Device

Selecting Advanced Virtual Mailbox Options

You can change selected virtual mailbox options.

Select a device.

1

Select Device > Virtual mailboxes.

2

In the Virtual Mailboxes dialog box, click Advanced. If a password has been

3

set, enter the password and click OK.

Select the desired settings:

4

Maximum VMB size

Enter a value for virtual mailbox size, or click the up or down arrow buttons to
select the value.

Change master password

Click Password, then enter the old and new passwords, and reenter the new
password. To remove the password, leave the New password and Confirm

new password boxes blank.

Delete all virtual mailboxes

Click Delete all, then click Yes to confirm.

KYOCERA Net Viewer 5.3 3-18

Device

Click OK in the Advanced dialog box.

5

Click Close in the Virtual Mailbox dialog box.

6

Adding a New Virtual Mailbox

You can create a new virtual mailbox on the hard disk. A maximum of 255 virtual
mailboxes is supported.

Select a device.

1

Select Device > Virtual mailboxes.

2

In the Virtual Mailboxes dialog box, click New mailbox.

3

Enter a new ID, name, and password. Retype the password to confirm, and

4

click OK. The same name cannot be used for more than one virtual mailbox.

Editing a Virtual Mailbox

You can set the name and password of a virtual mailbox stored on the hard
disk. Click Refresh all to refresh all virtual mailboxes.

Select a device.

1

Select Device > Virtual mailboxes.

2

In the Virtual Mailboxes dialog box, select a virtual mailbox and click Mailbox

3

properties.

In the Mailbox Properties dialog box, type a new Name, and type a password

4

from 1 to 65535. In Confirm new password, type the password again.

Click OK.

5

Device Notification Settings

The Notification feature informs users of changes in the status of the printing
device. There are three types of notifications available: a pop-up window,
opening of the Windows event log, or an e-mail to a specified list of e-mail
addresses.

To send e-mail notifications, TCP port 25 must be available and not blocked by
a firewall or virus scanner. Also, the e-mail sending feature must be configured
in Edit > Options > Mail settings.

Several types of events can trigger a device notification, depending on the
device model. For example, a paper jam can be set to trigger a notification.

Setting a Device Notification

You can select devices from the device list for displaying alerts about printing
device activity. The Notification Settings dialog box provides the alert option
for the selected devices.

3-19 User Guide

1

2

3

4

5

6

Advanced Menu

Device

In any Device view, select one or more devices.

In the Device menu, click Notification settings.

In the Notification Settings dialog box, under Actions, select how the
notification will be communicated.

If you select Send e-mail to, type one or more e-mail addresses, to a maximum
of three.

Under Notifications, select the events that will trigger a notification.

Click OK.

In the Device menu, click Advanced. You can also right-click on a device and
select Advanced. The following selections appear:

Set multiple devices

This sends configuration parameters to multiple devices at the same time.

Manage applications

This wizard guides you to install applications on printing devices.

Upgrade firmware

This wizard guides you to install the most current firmware on devices.

Device default settings

This sets the default settings of the selected device, such as duplex, print
quality, paper input and output; plus copy, scan, and FAX settings. Only one
device may be selected at a time. Settings vary by model.

Device system settings

This sets the default settings of the selected device, such as operation panel
language, timer settings, and panel lock. Only one device may be selected at
a time. Settings vary by model.

Device network settings

This sets the network settings of the selected device, such as IP address, e­mail settings, SNMP settings, FTP and SMB client settings, and protocol
settings. Only one device may be selected at a time. Settings vary by model.

Install driver

This wizard guides you to install printer drivers on devices.

Upgrade driver

This wizard guides you to upgrade printer drivers to a later version.

Uninstall driver

This wizard guides you to uninstall printer drivers.

Authentication settings

This sets the authentication settings of the selected device, such as user
login and LDAP settings, and permitting jobs with unknown IDs. Only one
device may be selected at a time. Settings vary by model.

KYOCERA Net Viewer 5.3 3-20

Device

Network groups

This manages certain user access properties for an entire group of devices.

TCP/IP Send Data

This sends data directly to the interface of one or more selected devices.

Authentication Settings

Authentication Settings provides a convenient way for administrators to

manage user authentication and network user properties. Only one
Authentication Settings dialog box can be opened per device. A maximum of
three dialog boxes can be open (for three different devices) at the same time.

Setting User Authentication

With Authentication Settings, an administrator can configure some MFP
devices to require a user login before it is accessed. If you select Use local
authentication, the device uses the Device User List to authenticate the login
user. If you select Use network authentication, the device uses the domain
server to authenticate the login user. Support varies by model.

Select a device from the device list.

1

Click Device > Advanced > Authentication settings.

2

If you want to set user authentication as a device setting, click Enable user

3

login.

Select the authentication mode.

4

If you select Use local authentication, go to Step 9.

If you selected Use network authentication, the related text boxes below it
become available. Only ASCII characters are allowed in the text boxes.

Type a domain name in the Domain name text box to a maximum of 256

5

characters, depending on the format of the firmware file used on your device.

For some models, multiple domains can be selected from a list of registered
domains. If more than one domain is specified, select one for the default.

Select a Server type from the list. If the server type is not Ext., only Server

6

type and Host name settings are available.

Type a host name or IP address in the Host name text box.

7

Type a Port number, if available. The valid range is 1-65535.

8

You can proceed through the rest of the dialog box, or you can click OK to save

9

your settings and close the dialog box.

Permitting Jobs with Unknown IDs

If you want a device to have no user restrictions and accept print jobs without a
user login and password, you can select the Permit jobs with unknown IDs
check box. The check box is cleared by default.

3-21 User Guide

In any Device view, select a device.

1

In the Device menu, click Advanced > Authentication settings.

2

In the Authentication Settings dialog box, select the Permit jobs with

3

unknown IDs check box and then click OK.

If you want to restrict the device with a user login, clear the Permit jobs with
unknown IDs check box. In the printer properties for the device, you must also

click the Device Settings tab, click Administrator, and select the User Login
check box. Type the user name and password for a specific user, or choose to
have the device prompt for the user name.

Enabling Local Authorization

You can prohibit job use by specific users on a device that supports this feature.

In any Device view, select a device.

1

In the Device menu, click Advanced > Authentication settings.

2

If authentication is required, enter a login and password.

Device

In the Authentication Settings dialog box, select the Local authorization

3

check box.

Click OK.

4

Enabling Simple Login

You can enable Simple Login for a device. Support for this feature varies by
model.

In any Device view, select a device.

1

In the Device menu, click Advanced > Authentication settings.

2

If authentication is required, enter a login and password.

In the Authentication Settings dialog box, select the Simple Login check box.

3

Click OK.

4

Setting ID Card Login

You can select ID card login settings for your device. ID card login varies by
model and is available when an ID card authentication kit is activated. Support
for this feature varies by model.

In any Device view, select a device.

1

In the Device menu, click Advanced > Authentication settings.

2

If authentication is required, enter login and password information.

KYOCERA Net Viewer 5.3 3-22

Device

In the Authentication Settings dialog box, under ID card login settings,

3

select the Allow keyboard login check box to enable keyboard login. Clear the
check box to disable this feature.

If Allow keyboard login is selected, you can select the Password login check

4

box to require a password.

Click OK.

5

Setting Network User Properties

An administrator can set network user properties as a device setting. Settings
for user properties vary by model.

In any Device view, select a device.

1

In the Device menu, click Advanced > Authentication settings.

2

In the Authentication Settings dialog box, click Network user properties.

3

In the Network User Properties dialog box, select the Obtain network user

4

properties check box. Only ASCII characters are allowed in the text boxes.

Type the server name in the Server name text box, to a maximum of 64

5

characters.

Select the Port number from the list. Available port numbers range from 1 to

6

65535.

Select the Search timeout (seconds) from the list. The range is from 5 to 255.

7

Select an Encryption type from the list. The LDAP encryption can be saved to

8

SSL/TLS, STARTTLS, or it can be set to Off.

Select an Authentication type from the list. You can select from Simple or

9

SASL.

The device uses the Acquisition of user information settings for search and

10

retrieval of login user information from the LDAP server.

Type a valid user name in the Name 1 text box, to a maximum of 32 characters.

Type another valid user name in the Name 2 text box, to a maximum of 32
characters.

Type a valid e-mail address in the E-mail address text box, to a maximum of 32
characters.

Click OK.

11

3-23 User Guide

Network Groups

You can add, delete, edit, authorize, and search for groups. The maximum
number of groups that can be added to the list is 20.

Network Groups List

The device display name and IP address appearing in the title at the top of the
Network Groups dialog box represent the selected device. Below the title, a
toolbar with icons lets you add, delete, edit, authorize, and search for groups.
The list of groups can be refreshed to show the latest additions and deletions.
The number of groups currently selected and the total number of groups are
shown at the bottom of the dialog box. The dialog box can be resized
horizontally and vertically, minimized, maximized, or restored.

The Network Groups list occupies most of the dialog box. It contains up to 20
groups, plus the Other group which is needed by the application. The
information for this group is displayed in bold font, and represents standard
authorization. The columns in the list contain the ID and Name assigned to each
of your groups when added or last edited. The list can be sorted by either
column in ascending or descending order by clicking one of the column
headers.

Adding or Editing a Network Group

You can add a new network group, or edit the information of an existing group.

Device

In the Device menu, click Advanced > Network groups.

1

In the Network Groups dialog box, you can add a group by clicking Add

2

group, or to edit an existing group, select a group and click Properties.

The Add Group dialog box and the Edit Group dialog box contain the same

3

settings. For the group named Other, the Group ID and Group name cannot
be edited, but the Access level and Job authorization settings can be edited.

In Group information, type an identifying number of up to 10 numeric

4

characters in the Group ID text box.

In the Group name text box, type a name for the group. The maximum number

5

of alphanumeric characters is 32.

For Access level, select either User or Administrator. User is selected by

6

default.

In Job authorization settings, make your selection from the list.

7

To permit all the options, including duplex, pages per sheet, and EcoPrint
printing options, click Permit all at the top of the list. The default for Duplex
restriction, Combine restriction, and EcoPrint restriction is Off.

To prohibit all options, click Prohibit all at the top of the list. Available options
vary by model.

After making your changes, click OK to save all your changes. The new group is

8

added to the group list for the selected device, or your edits are saved to the
existing group.

KYOCERA Net Viewer 5.3 3-24

Device

You can delete a network group by selecting it in the list and clicking Delete
group. The group named Other is used by the application and cannot be

deleted.

Setting Group Authorization

Group authorization means all users can operate within permissions set for

the group. You can activate or deactivate Group authorization for all groups
listed in the Network Groups dialog box.

Click Device > Advanced > Network groups.

1

Click the Authorize groups icon.

2

Click On to activate group authorization. Click Off to deactivate group

3

authorization. Click OK to save your choice.

Searching the Group List

In the Network Groups dialog box, you can search by ID or Name to find a
specific group.

In any Device view, select a device.

1

In the Device menu, click Advanced > Network groups.

2

In the Network Groups dialog box, choose an option from the Searchable

3

fields list and type the text you want to find in the Search text box.

To clear the search results and display the entire list again, click the Clear

4

search icon in the toolbar.

TCP/IP Send Data

With TCP/IP Send Data, you can send data (files, text, or device commands)
directly to the interface of one or more selected devices.

Warning: This is an advanced feature. Incorrect use can cause the device to
be inoperable.

Sending TCP/IP Data

To send data to the device interface:

In any Device view, select one or more devices.

1

In the Device menu, click Advanced > TCP/IP Send Data.

2

In the TCP/IP Send Data dialog box, select the TCP port or IPPS path. You can

3

select the Default TCP port or a Specified TCP port as the transmission
method. The port number must match one of the logical printers defined on the
print device’s home page. The range is 1-65535. If you want to transmit with
IPPS, select IPPS and type a valid Path into the text box.

3-25 User Guide

To send data as text, select Text and type the text in the box. Use this option to

4

send PRESCRIBE commands. Click History to access any of the last 10 sent
text strings.

To send data from a file to the device, select File, click the Browse button, and
select the file. Use this option to send macros or printable files, such as PDF or
PRN.

Note: If you select both the Text and File check boxes, the application sends
text data first and then file data. The application sends {#FILE#} commands
and text in the order they appear in the Text box. Binary data can appear in text
as bytes in hexadecimal form with the string 0x prepended to it. Support varies
by model.

Click Send to send the data.

5

Device Applications

You can install applications on one or more devices by using the Manage
Applications feature. You can also uninstall applications and activate and

deactivate applications remotely. Available features vary by model.

Before you install and activate an application, you must enable SSL and IPP
over SSL on the device. You must also enter the correct login and password in
the Communication Settings for the device.

Applications are created by dealers or third-party companies to enhance
printing, copying or accounting features.

Device

Installing an Application on Multiple Devices

You can install applications remotely on one or more devices using the Manage
Applications wizard. Once an application is installed, you can choose to start

the application immediately.

In any Device view, select multiple devices.

1

In the Device menu, click Advanced > Manage applications.

2

In the Manage Applications wizard, select Install application. You can select

3

the check box to activate the application after installation. Click Next.

Click Browse to find a valid application package file (.PKG), and click Open.

4

Click Next.

If the Activate application after installation check box was selected and the

5

selected application requires a license key, the Apply license keys page
appears. Select a method to choose license keys provided to you from your
administrator:

Activate without a license key

Activate the application without a license key.

Use the following license key

Select a device, and then type the 20-digit license key, separated by a
hyphen for each 4 digits.

KYOCERA Net Viewer 5.3 3-26

Device

Import license keys

Browse to find a valid license key file (.CSV) for your device, and click Open.

If the application is not being activated during this installation, the Apply
license keys page does not appear.

Click Next.

On the Confirmation page, review your settings.

6

Click Finish to install the application.

7

When installation is finished, you can click Save log to save an installation log

8

file (.CSV or .XML).

To remove an application, select a device, open the Manage Applications
wizard, select Uninstall application, then continue with the steps in the wizard.

If you only want to deactivate the application, open the Manage Applications
wizard, select Deactivate application and continue with the steps in the
wizard. Available features vary by model.

Installing an Application on One Device

You can install applications remotely on one device using the Applications
dialog box.

In any Device view, select a device.

1

In the Device menu, click Applications.

2

In the Applications dialog box, click Install New.

3

In the Open dialog box, browse to find a valid application package file (.PKG),

4

and click Open, and then click Yes to confirm.

To remove an application, select a device, open the Applications dialog box,
select the application to be removed and select Uninstall.

If you only want to deactivate the application, open the Applications dialog box,
select the application to be deactivated and click Deactivate. Available features
vary by model.

Activating an Installed Application on Multiple Devices

If an application was installed on one or more devices without starting the
application, you can activate it using the Manage Applications wizard.

In any Device view, select multiple devices.

1

In the Device menu, click Advanced > Manage applications.

2

In the Manage Applications wizard, select Activate application. Click Next.

3

3-27 User Guide

On the Select a method for specifying the application to be activated page,

4

select how to choose the application:

Specify application package

Click Next, then browse to find a valid installation package file (.PKG). Click
Next. Continue to step 7.

Specify application installed on the device

Click Next and continue to step 5.

On the Select source device page, select one device. Click Next.

5

On the Select the application to be activated page, make your selection.

6

Click Next.

The Apply license keys page appears when the application requires a license

7

key. For each device, select a method to choose license keys provided to you
from your administrator:

Activate without a license key

Activate the application without a license key.

Use the following license key

Select a device, and then type the valid 20-digit license key, separated by a
hyphen for each 4 digits.

Import license keys

Browse to find a valid license key file (.CSV) for your device, and click Open.

Click Next.

Device

On the Confirmation page, review your settings.

8

Click Finish to activate the application.

9

When activation is finished, you can click Save log to save an activation log file
(.CSV or .XML).

To remove an application, select a device, open the Manage Applications
wizard, select Uninstall application, then continue with the steps in the wizard.

If you only want to deactivate the application, open the Manage Applications
wizard, select Deactivate application and continue with the steps in the
wizard. Available features vary by model.

Activating an Installed Application on One Device

If an application was installed on one device without starting the application, you
can activate it using the Applications dialog box.

In any Device view, select a device.

1

In the Device menu, click Applications.

2

In the Applications dialog box, select the application and click Activate.

3

KYOCERA Net Viewer 5.3 3-28

Device

In the License Key Settings dialog box, select a license key option:

4

Activate without a license key

Activate the application without a license key.

Use the following license key

Select a device, and then type the 20-digit license key, separated by a
hyphen for each 4 digits.

Click OK, and then click Close.

5

To remove an application, select a device, open the Applications dialog box,
select the application to be removed and click Uninstall.

If you only want to deactivate the application, open the Applications dialog box,
select the application and click Deactivate. Available features vary by model.

Viewing Installed Applications

You can view information about the applications installed on a device. Name,
version, and license information is displayed.

In any Device view, select a device.

1

In the Device menu, click Applications.

2

At any time, click Refresh to update the view.

3

If desired, you can select and manage one or more applications:

4

Click Install New to install a new application.

Click Activate to activate an installed application.

Click Deactivate to deactivate an installed application. Support varies by
model.

Click Uninstall to remove an installed application.

Searching Applications

In the Applications dialog box, you can search by Name or Version.

In any Device view, select a device.

1

In the Device menu, click Applications.

2

In the Applications dialog box, choose an option from the Searchable fields

3

list and type the text you want to find in the Search text box.

To clear the search results and display the entire list again, click the Clear

4

search icon in the toolbar.

3-29 User Guide

4 Account

The Account menu is used to find accounts and manage account settings.

Administrator Login

For some models, administrator authentication is required to access selected
features in the Device and Account menus. Available features vary by model.
When you select the feature from a menu, you are prompted to type one of the
following in the Administrator Login dialog box:

Command Center password

Administrator login and Administrator password (with optional Use local
authentication)

Accounting administrator code

Operations on multiple devices do not prompt for the administrator login. Login
options must be configured in the Login section of the Communication

Settings dialog box.

Adding Account Devices

You can add network devices to an existing account. Only managed devices
can be added.

In Accounts view, select an account.

1

In the Account menu, click Add devices to account.

2

In the Add Devices to Account dialog box, select one or more available

3

devices.

Click OK.

4

Creating a New Account

You can create an account for a device.

In Accounting devices view, select one or more managed devices.

1

In the Account menu, click New account.

2

In the New Account dialog box, type an Account ID up to 8 digits and a Name

3

up to 32 characters. If applicable, type furigana up to 32 characters.

Click OK.

4

KYOCERA Net Viewer 5.3 4-1

Account

Account Properties

The Account Properties dialog box contains information about counters and
usage restrictions for an account. The device must be managed before the
properties can be displayed. To view the dialog box, click Account > View

accounts on this device, and then select Account properties.

General

ID number and name of the account (and furigana, if applicable).

Counters by function

Counters for number of pages printed, copied, or faxed.

Counters by media

Counters for number of pages used of various media types or sizes.

Counters by duplex/combine

Counters for single-sided, double-sided, and combined printing (2 in 1 and 4
in 1).

Counters for scanned pages

Counters for number of pages scanned for the copy, FAX, or other functions.

Counters for FAX transmission

Counters for number of pages transmitted, and the total transmission time.

Timestamp

The date and time when the counters were last updated.

Usage restriction by print

Limits the number of pages allowed for printing in full color or single color.

Usage restriction by copy

Limits the number of pages allowed for copying in full color or single color.

Usage restriction by scan

Limits the number of pages allowed for scanning.

Usage restriction by FAX

Limits the number of pages allowed for sending by FAX.

Reset counters

Resets all of the above counters to zero.

Usage Restrictions

Restrictions can be placed on individual accounts on a given device to limit the
number of pages that can be output. Restrictions can be specified for each
function of the device, such as printing and copying, and limited to the number
of full color or single color pages output, or to the total number of pages output.

The three options include the following:

Off

The usage is not restricted.

Counter limit

The administrator sets the usage limits and resets the limits if the maximum
is reached.

Reject usage

The usage is restricted.

4-2 User Guide

Device Accounts

Account Devices

Account

To view the Device Accounts, select a device in Accounting devices view
and click Account > View accounts on this device.

This dialog box displays information about accounts associated with this device.
Accounts can be created on the device, and existing accounts can be added or
deleted. Reports can be made about this account, including the account ID list,
counter information, and accounting information. A Search text box is also
available to search the list of device accounts.

To view the Account Devices dialog box, select an account in Accounts view
and click Account > View devices for this account.

The dialog box displays a list of the various devices that are associated with this
account. The information shown includes the model name of each device, its
network information and counter information. Devices can be added to or
removed from this account. Reports can be made about this account, including
the account ID list, counter information, and accounting information. A Search

text box is also available to search the list of printing devices.

Viewing Accounts and Devices

You can view the accounts on each device and the devices associated with
each account. Only managed devices can be displayed.

Select a device or account:

1

In Accounts view, select an account.

In Accounting devices view, select a managed device.

In the Account menu, select View devices for this account or View accounts

2

on this device.

Exporting Accounting Information to a File

With any Accounting view displayed, you can export account information to a
.CSV or .XML file. Account IDs can only be exported to a .CSV file. The .CSV
export uses UTF-8 encoding.

In any Accounting view, select an account.

1

In the File menu, click Export > Accounts, and select an export option:

2

Account IDs

Exports the account ID list that is saved in the printer driver.

Counters

Exports device counter information.

Information

Exports device accounting information.

In the Export dialog box, type or select a file path. Depending on the file type,

3

the file must have an extension of .CSV or .XML.

KYOCERA Net Viewer 5.3 4-3

Account

4

Counter Reports

Automatic Counter Reset

Name and save the file.

Counter reports provide detailed counter information about devices in the
current view. Counter reports require Mail settings be set in Edit > Options.
Reports can be sent to multiple recipients and scheduled for a specified time
and day.

The report contains the same printer system and counter information that is
shown in the view. Each view can have one counter report, and a total of 5
counter reports can be created.

The counter report has a user-specified name, and can be sent to the e-mail
addresses specified in a list. The report can be sent daily, weekly, or monthly.
The e-mail can contain a user-specified message in the subject line. The
attached file can be in CSV or XML format.

This function resets the counters on a device to zero when a counter report is
successfully sent. If the counter report is not successfully sent, the reset is not
performed.

Creating a Counter Report

You can create a counter report for a selected Account view.

In My Views, select an account view.

1

In the Account menu, click Add counter report.

2

In the Add Counter Report dialog box, change the default settings, as needed.

3

Click OK.

4

Viewing and Changing Counter Report Settings

You can view and change counter report settings.

In My Views, select an Account view.

1

In the Account menu, click Show counter reports.

2

In the Counter Reports dialog box, select a report and click Properties.

3

In the Counter Report Properties dialog box, change any settings as needed.

4

Click OK.

5

4-4 User Guide

Manage Device

You can use notification and reporting features, create and view accounts, and
reset counters when an accounting device is managed. A device that is not
managed uses only a limited set of features.

Managing an Accounting Device

To manage an accounting device, follow these steps:

In Accounting devices view, select a device that is not managed.

1

In the Account menu, click Manage device.

2

You may be prompted to enter a password.

3

To change a device from managed to not managed, select the device, click

Account > Don’t manage device, then click Yes to confirm.

Hiding or Showing Unmanaged Devices

In Accounting devices view, you can view all account devices or view only the
managed devices.

In the toolbar, click Hide unmanaged devices to hide the devices from view.

In the toolbar, click Show unmanaged devices to display all devices again.

Account

Reset Counters

The job accounting counters of one or more devices can be reset to zero. To
use this feature, the device must be set as managed in Accounting devices

view.

Resetting Job Accounting Counters

You can reset job accounting counters.

In Accounts view or Accounting devices view, select one or more accounts

1

or managed devices, respectively.

In the Account menu, click Reset counters.

2

Click Yes to confirm.

3

Accounting Notification Settings

Notification Settings are used to inform users of changes in the counter status

of the printing device. The types of notifications are: opening a pop-up window
or the Windows event log, and sending an e-mail to up to three recipients. To
send e-mail notifications, TCP port 25 must be available and not blocked by a
firewall or virus scanner. The sender’s e-mail must be specified in Edit >

Options > Mail settings. If it is not, the Send e-mail to option in Notification
Settings is unavailable.

KYOCERA Net Viewer 5.3 4-5

Account

Setting an Accounting Notification

You can select devices from the account list for displaying alerts about printing
device activity. The Notification Settings dialog box provides the alert option
for the selected devices.

In Accounting devices view, select a managed device.

1

In the Device menu, click Notification settings.

2

In the Notification Settings dialog box, under Actions, select how the

3

notification will be communicated.

If you select Send e-mail to, type one or more e-mail addresses to a maximum

4

of three.

Under Notifications, select the events that will trigger a notification.

5

Click OK.

6

Device Accounting Settings

The Device Accounting Settings dialog box provides options for controlling or
monitoring a device. To connect to the selected device, either the Login user
name and Password, or the Accounting administrator code must be set
correctly, depending on the type of authorization method used by the device.
Information is read from the device and displayed at the top of the dialog box
under General. Click on the other list name rows to view other options.

Options can be specified for Job accounting, Media type, Error handling, and
Additional settings. Options not supported on the selected device do not
appear.

Accessing Device Accounting Settings

You can open a dialog box that provides options for controlling and monitoring
devices.

In Accounting devices view, right-click on a managed device, and click

1

Device accounting settings in the menu.

In the Device Accounting Settings dialog box, you can view or select these

2

options for the selected device:

General

Job accounting

Media type

Error handling

Additional

Enabling or Disabling Job Accounting

You can enable or disable job accounting settings to keep count of certain
functions on a selected device.

4-6 User Guide

In Accounting devices view, right-click on a managed device, and click

1

Device accounting settings in the menu.

In the Device Accounting Settings dialog box, click Job accounting.

2

Select to enable Job accounting, and enable or disable counts from the

3

available options:

Job accounting for copying

Job accounting for printing

Job accounting for scanning

Job accounting for FAX

If you are finished selecting Job accounting options, you can select other

4

options in the dialog box, or you can save all your selections by clicking OK. If
you do not want to save any of your selections, click Cancel.

Selecting Media Type Counters

You can select counters to track the number of pages by size and type of media
for a device.

Account

In Accounting devices view, right-click on a managed device, and click

1

Device accounting settings in the menu.

In the Device Accounting Settings dialog box, click Media type.

2

For each desired counter, select a page Size and Type from the lists.

3

If you are finished selecting Media type options, you can select other options in

4

the dialog box, or you can save all your selections by clicking OK. If you do not
want to save your selections, click Cancel.

Handling Errors

You can select how to handle the job when an error has occurred.

In Accounting devices view, right-click on a managed device, and click

1

Device accounting settings in the menu.

In the Device Accounting Settings dialog box, click Error handling.

2

You can print reports for one or both of the following errors:

3

Print report on illegal account error

Print report on exceeded counter limit

You can cancel the job, or issue a warning, for the following errors:

4

Cancel job on illegal account error

Cancel job on exceeded counter limit

From each of the lists, select Subsequently, Immediately, or Alert only.

KYOCERA Net Viewer 5.3 4-7

Account

If you are finished selecting Error handling options, you can select other

5

options in the dialog box, or you can save all your selections by clicking OK. If
you do not want to save any of your selections, click Cancel.

Setting Permit Processing and Copy Counter

You can permit or prohibit processing jobs without an account ID.

In Accounting devices view, right-click on a managed device, and click

1

Device accounting settings in the menu.

In the Device Accounting Settings dialog box, click Additional.

2

If you want to require that an account ID be submitted before job processing,

3

select Reject from the list. If you want to allow job processing without an
account ID, select Permit.

If you want the count of copy pages separate from the count of print pages,

4

select Individual. If you want the count of copy and print pages added together,
select Total.

If you are finished selecting Additional options, you can select other options in

5

the dialog box, or you can save all your selections by clicking OK. If you do not
want to save any of your selections, click Cancel.

Accounting Multi-Set

With Accounting Multi-Set, you can send configuration parameters for device
accounting to multiple devices simultaneously.

Setting Multiple Accounting Devices

To start the accounting Multi-Set, follow these steps:

In Accounting devices view, select one or more devices to receive settings.

1

In the Device menu, click Advanced > Set multiple accounting devices.

2

The Multi-Set wizard appears.

On the Device group page, the application has filtered the selected devices by

3

those Multi-Set supports. The devices are organized by product group.

Select one group to apply settings to, and then click Next.

Selecting Accounting Settings in Multi-Set

The following options may vary on the Settings page, depending upon the
destination device:

Device Accounting Settings

These are settings for job accounting, media type, error handling, permitting
job processing without an account ID, and copy counter.

Account List

4-8 User Guide

This is a list of device accounts with information about print, copy, scan and
FAX counts.

On the Settings page, select the category of settings to copy to the destination
devices. Only one category of settings can be selected for each Multi-Set
process. Click Next.

Selecting Accounting Source Settings

You can select different ways to create settings for your destination device.

Warning: When Account List is selected in Settings, if the check box
labeled Overwrite settings on target device at the bottom of the Method
page is selected, the source device settings will be copied over the destination
device settings. Clear this check box to preserve the destination device
settings.

Creating Settings From a Device

You can copy settings from the source device.

On the Method page, click Create from device. Click Next.

1

Click on one source device from the list. Click Next.

2

Account

The Confirmation page shows a list of the settings you have made. You can

3

click Edit settings to open a dialog box to make changes to the settings. If you
want to save your settings to a file, click Save to file. The settings are saved to
a file with the extension .CSV or .XML. Click Finish.

If the process completes successfully, the properties or settings are copied from
the source device to the destination device. Click Close.

If the process does not complete successfully, you can click Details to see a list
of the errors. If you want to save the error list, click Export to open a dialog box
for saving to a log file. Browse or type a file name with an extension of .CSV.
Click Save, and then click Close.

Creating Account Settings From a File

You can create a settings template from an existing file.

On the Method page, click Create from file. Click Next.

1

Type a file path, or click Browse to locate and select a file you want to use. You

2

have the option to open the following format:

Multi-Set template from the current software version (.CSV or .XML)

Note that a .CSV file for importing accounting settings into Multi-Set must
include a numeric account ID and an account name. The column headers of the
file include Account ID, Account Name, Account subname, if applicable and
Print (total). The order of these headings can be rearranged, if desired. The
data format for the .CSV file is:

Account ID 1, Account name 1, Account subname 1, Print (total)…

Account ID 2, Account name 2, Account subname 2, Print (total)…

An example of the data format for the .CSV file is:

1, Account1a, Account1b, 1(500)

KYOCERA Net Viewer 5.3 4-9

Account

2, Account2a, Account2b, 1(500)

In this example, 1 and 2 are the account IDs, Account1a and Account2a are the
account names, Account1b and Account2b are the account subnames, and
1(500) are the usage restriction applied to print counters. (A value of 0 indicates
you can print without restrictions, 1(500) indicates you can print 500 pages, and
2 indicates there is no printing allowed for that account.)

Click Open, and then click Next.

3

The Confirmation page shows a list of the settings you have made. You can

4

click Edit settings to open a dialog box to make changes to the settings. If you
want to save your settings to a file, click Save to file. The file is saved in .CSV
or .XML format.

Click Finish.

5

If the process completes successfully, the properties or settings are copied from
the file to the destination device. Click Close.

If the process does not complete successfully, you can click Details to see a list
of the errors. If you want to save the error list, click Export to open a dialog box
for saving to a log file. Browse or type a file name with an extension of .CSV.
Click Save, and then click Close.

Creating New Settings

You can create a new settings template.

On the Method page, click Create new. Click Next. A dialog box opens

1

containing settings for the option you selected on the Settings page. Make your
changes to the settings.

When you are done making settings, click OK or Close.

2

The Confirmation page shows a list of the settings you have made. You can

3

click Edit settings to open a dialog box to make changes to the settings. If you
want to save your settings to a file, click Save to file. The settings are saved to
a file with the extension .CSV or .XML.

Click Finish.

4

If the process completes successfully, the new properties or settings are copied
to the destination device. Click Close.

If the process does not complete successfully, you can click Details to see a list
of the errors. If you want to save the error list, click Export to open a dialog box
for saving to a log file. Browse or type a file name with an extension of .CSV.
Click Save, and then click Close.

Export

When viewing device accounts or accounting devices, the displayed information
can be exported and saved to a .CSV or .XML file on your computer or network.
The following export options are available:

Account IDs: Displays the account ID list. This file can be imported into a
printer driver.

4-10 User Guide

Counters: Displays job accounting counters by account ID.

Information: Displays all accounting counters.

Exporting Account ID List

You can export a device’s account ID list to a .CSV file.

In My Views or Default Views, select an account or select a device that

1

supports accounting:

Accounts view: select the desired account

Accounting devices view: select a managed device

Depending on the selection in step 1, in the Account menu, select View

2

devices for this account or View accounts on this device.

Select one or more devices or accounts.

3

In the toolbar, click Export > Account IDs.

4

Account

Name and save the file.

5

Exporting Counter Information

You can export a device’s counter information to a .CSV or .XML file.

In My Views or Default Views, select an account or a device that supports

1

accounting:

Accounts view: select the desired account

Accounting devices view: select a managed device

Depending on the selection in step 1, in the Account menu, select View

2

devices for this account or View accounts on this device.

Select one or more devices or accounts.

3

In the toolbar, click Export > Counters.

4

Select .CSV or .XML as the file type.

5

Name and save the file.

6

Exporting Accounting Information

You can export a device’s accounting information to a .CSV or .XML file.

In My Views or Default Views, select an account or a device that supports

1

accounting:

Accounts view: select the desired account

Accounting devices view: select a managed device

KYOCERA Net Viewer 5.3 4-11

Account

Depending on the selection in step 1, in the Account menu, select View

2

devices for this account or View accounts on this device.

Select one or more devices or accounts.

3

In the toolbar, click Export > Information.

4

Select .CSV or .XML as the file type.

5

Name and save the file.

6

4-12 User Guide

Adding Queues

1

2

3

5 Host

The Host menu is used for managing printer drivers and print queues. In host
views, you can install, upgrade, or uninstall printer drivers on host computers,
and select login settings. You can also remotely install printer drivers onto a
host computer.

You can use the Create Queue wizard to add queues to the Host queue view
list.

In Host queue view, click Host > New queue.

In the Create Queue wizard, select one or more hosts. Click Next.

If prompted, specify a valid domain login, then click OK to continue.

Select a printer model. Click Next.

Click Have disk, browse for a valid 32-bit or 64-bit .INF file (or both) for the

4

printer model, and click OK. Click Next.

Change available settings for each host. Clicking some options opens an

5

additional dialog box.

You can click Import to browse for a settings file (.KVP) for the selected driver,

6

or save your current settings by clicking Export.

You can click Common settings and apply settings to all selected printer

7

models.

Click Conflicts, and select from available options to resolve any conflicts that

8

may occur during installation.

After you have finished making changes on the Printer settings page, click

9

Next.

On the Confirm settings page, confirm your selections.

10

Click Finish to create the new queue. You can create an export file by clicking

11

Export, or click OK to close the dialog box.

You can remove a queue by selecting it from the list and clicking Delete queue.

KYOCERA Net Viewer 5.3 5-1

Host

Common Settings Options

When creating a new queue or installing a printer, you can apply some settings
to all selected printer models by using the Common Settings feature. This is for
printing system drivers only.

On the Printer settings page of the Create Queue wizard, click Common
settings, and select available options:

Under Factory Default, select Yes or No. With Yes selected, browse to find
a profile (.KXP), and then click Upload.

Under Plug-ins, select from the available plug-ins to install.

In the Comments box, type your comment.

You can click Open and browse for a .KVP file containing saved
configuration settings for printer drivers.

You can click Save and save current configuration settings in a .KVP file.

Conflicts Options

You can set resolutions to potential printer conflicts during installation. You can
modify settings for an existing printer, an existing driver, a printer name that
already exists and keep or change a port number. When creating a new queue
or installing a printer, you can select from the following options:

Printer exists:

Keep settings

The current printer settings remain the same and the printer will not be
installed.

Override

The current printer settings will be overridden by the user selected
properties.

Driver exists:

Does nothing

The settings for the existing driver are not changed and a new driver is not
installed.

Upgrade

The driver can be upgraded to a later version.

Share name exists:

Add suffix

The new printer name contains extra characters.

Fail

The new printer is not installed.

No share

The printer is not shared.

Port is not available:

File

The port is set as File.

LPT1

The port is set as LPT1.

Fail

5-2 User Guide

The printer is not installed.

Editing a Queue Name

You can change the name of a queue.

In Host queue view, select a queue to rename.

1

Right-click on the queue and select Rename.

2

In the Rename dialog box, type the new name in the box and click Edit.

3

When renaming is finished, click Finish.

4

Host View Printer Installation

The printer driver software provides settings to customize output from your
device. You can remotely install printer drivers onto a host computer. Once
installed, drivers can be upgraded or uninstalled.

Host

Allowing the Print Spooler to Access Client Connections

The administrator can set policies that are applied to the computer for any user
who logs on. The Allow Print Spooler to accept client connections policy
manages access to the print spooler.

In the Local Group Policy Editor, click Computer Configuration >

1

Administrative Templates > Printers.

From the Setting list, double-click the Allow Print Spooler to accept client

2

connections policy.

Select Enabled so the print spooler will always accept client connections.

3

Click OK.

4

Restart the print spooler for changes to this policy to take effect.

5

Allowing a Remote Administration Exception

The administrator can set policies that are applied to the computer for any user
who logs on. The Allow inbound remote administration exception policy
manages exceptions to accessing remote connections when the firewall is on.
This feature allows remote administration of the computer using Windows
Management Instrumentation (WMI).

In the Local Group Policy Editor, click Computer Configuration >

1

Administrative Templates > Network > Network Connections > Windows
Firewall.

If the computer is on the domain, double-click Domain Profile. If the computer

2

is not on the domain, double-click Standard Profile.

KYOCERA Net Viewer 5.3 5-3

Host

Double-click Windows Firewall: Allow inbound remote administration

3

exception.

Select Enabled to allow remote administration for the computer.

4

Click OK.

5

Installing Printer Drivers in Host View

You can use the Driver Installation wizard to install printer drivers.

In Host view, select one or more host computers.

1

In the Host menu, click Install driver.

2

In the Driver Installation wizard, select whether to install with or without a

3

device:

Select Install driver with device if the physical printing devices appear in
the Device view and available on the network. Click Next to display a list of
all available devices. Select one or more printer models to install, and click
Next. Click Have disk, browse to find a valid .INF file for each driver being
installed, and then click Open. Click OK to exit the dialog box, and then click
Next to proceed.

Select Install driver without device if the physical printing devices are not
available on the network. Click Next, and then click Have disk and browse
to find a valid .INF file for each driver being installed. Click OK to exit the

Have disk dialog box, and then select one or more drivers to install. Click
Next.

On the Printer settings page, select available settings for each printer driver.

4

The following options open another dialog box for selecting settings:

You can click Common settings and apply settings to all selected devices.

You can click Conflicts and select from available options.

You can click Import and select a configuration settings file (.KVP).

You can click Export and save current configuration settings in a .KVP file.

Click Next.

On the Confirm settings page, review your selections.

5

Click Finish to install the printer drivers. When installation is finished, you can

6

click Export to save a log file (.TXT).

Click OK.

7

Upgrading Printer Drivers in Host View

You can upgrade installed printer drivers to a later version.

In Host view, select one or more host computers.

1

5-4 User Guide

In the Host menu, click Upgrade driver.

2

In the Driver Upgrade wizard, select printer drivers to be upgraded. Select at

3

least one driver under each host. Click Next.

On the Select the INF file for each driver page, click Have disk, browse to

4

find a valid .INF file for each driver (32-bit or 64-bit) that is being upgraded, and
click OK. Click Next.

On the Confirm settings page, review your selections.

5

Click Finish to begin the upgrade process. When upgrade is finished, you can

6

click Export to save an upgrade log file (.TXT).

Click OK.

7

Uninstalling Printer Drivers in Host View

You can uninstall printer drivers from a host computer.

Host

In Host view, select one or more host computers.

1

In the Host menu, click Uninstall driver.

2

In the Driver Uninstallation wizard, expand the list of printer drivers under

3

each host.

Select the check box next to each driver or queue to uninstall. Select at least

4

one driver under each host. Selecting a driver also selects the associated
queue. Click Next.

On the Confirm settings page, review your selections.

5

Click Finish to begin the uninstallation process. When uninstallation is finished,

6

you can click Export to save an uninstallation log file (.TXT).

Click OK.

7

Installing Additional Drivers

With 32-bit or 64-bit printer drivers installed on a host computer, you can install
an additional driver of the other version (64-bit or 32-bit, respectively). This is
useful in a client/server environment when the client system and driver are the
other version. This is for printing system drivers only.

In Host queue view, select one or more queues.

1

Right-click on the queue or queues, and in the menu, click Install additional

2

driver.

In the Additional Driver Installation wizard, click Have disk.

3

KYOCERA Net Viewer 5.3 5-5

Host

Browse for a 32-bit or 64-bit .INF file for the printer model, and then click OK.

4

Click Next.

On the Confirm settings page, review your selections.

5

Click Finish. You can click Export to create and save an installation log file

6

(.TXT).

Click OK. The added printer driver does not appear in host views, but can be

7

upgraded or uninstalled.

Viewing a List of Printer Drivers

You can view detailed information about installed printer drivers for a selected
host.

In Host view, select a host.

1

In the Host menu, click Show printer drivers.

2

The Host Printer Drivers dialog box displays a list of printer drivers.

3

Click Refresh to update the list or click OK.

4

Viewing a List of Print Queues

You can view detailed information about print queues for a selected host.

In Host view, select a host.

1

In the Host menu, click Show print queues.

2

The Host Print Queues dialog box displays a list of print queues.

3

Click Refresh to update the list or click OK.

4

Selecting Host Login Settings

You can change the login information for the host administrator.

In the Host menu, select a host.

1

In Host view, click Host login settings.

2

In the Host Administrator Login dialog box, select the Use this login to

3

access the host check box.

Type the User name and Password.

4

5-6 User Guide

Select a Domain from the drop-down list.

5

Click OK.

6

Selecting Domain Administrator Login Settings

You can select administrator login rights for retrieving host and queue
information and for configuring the remote computer.

In any Host view, click Host > Domain administrator login settings.

1

In the Domain Administrator Login dialog box, select a domain option:

2

Use the current Windows login settings

Select to use your Windows login.

Specify a domain administrator user name and password

Enter the User name and Password, and select the login domain.

Click OK.

3

Host

If administrator login rights have not been set, the Domain Administrator
Login dialog box appears when adding hosts and when installing, upgrading, or

uninstalling printer drivers. For security purposes, this information is cleared
when you exit the application.

Exporting Host Information to a File

With any Host view displayed, you can export host information to an .XML file.

Click File > Export > Hosts.

1

In the Export Hosts dialog box, type or select a file path. The file must have an

2

extension of .CSV or .XML.

Click Save.

3

Configuring Printer Settings

You can view and change selected settings for installed printer drivers.

In any Host view, click Host > Printing settings.

1

If the Configure Printer Settings wizard was accessed from Host view, select

2

one or more installed printer drivers. Click Next.

Click on the available options under each selected driver to change the settings.

3

When finished making your changes, click Next.

On the Confirm settings page, review your selections.

4

KYOCERA Net Viewer 5.3 5-7

Host

Click Finish to begin the configuration process. When configuration is finished,

5

you can click Export to save a configuration log file (.TXT).

Click OK.

6

Available Printer Settings Options

You can modify the settings of the installed printer driver. Available options
include:

Administrator Settings

Login User Name List

You can add, delete, or edit login user names and passwords stored in the
driver. After a login user name list is created, the list can be exported as a
group by saving it as a .CSV file in your computer or network. You can import
an existing .CSV file and save it in your driver, but it overwrites the current
settings.

Account ID List

You can add, delete, or edit account IDs stored in the driver. After an
account ID list is created, the list can be exported as a group by saving it as
a .CSV file in your computer or network. You can import an existing .CSV file
and save it in your driver, but it overwrites the current settings.

Custom Box Settings

Custom Box Settings

You can add, delete, or edit custom boxes stored in the driver. After a
custom box list is created, the list can be exported as a .CSV file in your
computer or network. You can import an existing .CSV file and save it in your
driver, but it overwrites the current settings.

5-8 User Guide

6 Communication Settings

Communication Settings control the network communications with each

device. Available settings vary depending on the model and can include

Network interface settings, Secure protocol settings, Login, Account
polling settings, and Device polling settings.

Note: If authentication is enabled on the device, the Login user name and
Password must be set correctly in the Communication Settings dialog box
for access to device features, such as Address Book, Users, or Document
Box.

Setting Device Communications

You can view or change the network interface settings, polling and protocol
settings, and login information in the Communication Settings dialog box for
the selected device.

In any Device view or Accounting devices view, select a device.

1

In the Device menu, click Communication settings.

2

In the Communication Settings dialog box, type or modify the available

3

settings.

Click OK.

4

Network Interface Settings

This section displays settings for each network interface card attached to the
device. You can select the primary network card and edit select settings
including TCP/IP port, communication timeout, administrator password and
SNMP communication settings.

You can enter the communication settings for the devices from the following
options. Available options vary by model.

TCP/IP port

Type the value that matches what is set on the device. The valid range for
port numbers is 1024 to 65535.

Communication timeout (seconds)

The number of seconds the application tries to establish a connection with
the device.

SNMP communication retries

The number of retries to establish communication with the device after a
communication failure.

Command Center administrator password

KYOCERA Net Viewer 5.3 6-1

Communication Settings

TCP/IP Port

Type a password to a maximum of 32 characters.

Use SNMPv1/v2

Type the Read community name for the device that will be used in
requesting information. Type the Write community name for the device to
be used for changing its configuration. The Read community and Write
community are sent with all SNMP receive and send requests, and must
match the community values on the device.

Use SNMPv3

Type a User name and Password set on the device.

Click the Authentication check box and select the HASH method (MD5 or
SHA1). Click the Privacy check box and select an Encryption method (DES
or AES).

Some operations send a command or command file via logical printer port. The
default logical printer port numbers begin with 9100. The valid range for port
numbers is 1024 to 65535. The number must match the port number of one of
the logical printers defined for a device. Set the port number on the print
device’s home page. This procedure varies by model.

Secure Protocol Settings

Secure Sockets Layer (SSL) is a cryptographic protocol that provides security
for network communications. SSL support varies by model.

Select SSL to use HTTPS for device communication.

Clear SSL to use HTTP for device communication.

Login Settings

In the Login section, you can set user login information. The feature can be set
if at least one selected device supports the user login feature.

For an account device, select Apply same user information as Device

Management (available when user information is stored in Communication
Settings) or Use another user’s information. If Use another user’s
information is selected, enter the Login user name and Password for the

device.

For some models, select local or device authentication.

Account Polling Settings

The application polls devices at specific intervals to check for account counter
information. When you select a device from an Accounting devices view, you
see the following polling mode:

Account counter polling

Gathers information about the counters for each account, including total
number of prints, copies, FAX, scans, page sizes, duplex pages, and pages
per sheet. Select an interval, a day or date, and time of day.

6-2 User Guide

Device Polling Settings

The application polls devices at specific intervals to check for error conditions,
operational status, and low toner levels. When you select a device from a

Device view, you see the following polling modes:

Status polling

Gathers information about the current operational state of the device, such
as error conditions, panel messages, and operating mode. The available
range is between 5 and 300 seconds.

Counter polling

Gathers information about the values held by various counters in the device,
such as number of color pages printed, number of black and white pages,
number of faxes received, and so on. The available range is between 1 and
10000 minutes.

Toner level polling

Gathers information about the current level of toner in the device. The
available range is between 1 and 10000 minutes.

Communication Settings

KYOCERA Net Viewer 5.3 6-3

Quick Mode

7 Multi-Set

With Multi-Set, you can send configuration parameters to multiple devices
simultaneously.

With this mode, you can copy settings to one or more device groups. Certain
default settings are automatically applied when you use this mode.

In any Device view, select one or more devices.

1

In the Device menu, click Advanced > Set multiple devices.

2

On the Multi-Set Mode page, select Quick mode and then click Next.

3

On the Device group page, select one or more groups to apply settings to and

4

then click Next.

Custom Mode

On the Source Device page, select a device and then click Next.

5

Note: If local authentication is on, an administrator must type a login user

name and password in the Login section of the communication settings for the
device. All settings and passwords for the source and destination devices must
be correct in Communication Settings for a successful Multi-Set completion.

On the Confirmation page, you can see a list of your settings.

6

Note: In Quick mode, the current selections automatically save over the

existing settings on the destination device.

Click Back to make any changes or click Finish.

If the device must be restarted to save settings, a message appears. Click OK
to close.

With this mode, you can customize and copy settings to a single device group.
You can select the settings you want to copy and the method that you will use to
copy settings. The following options may vary on the Settings page depending
upon the destination device.

Device System Settings

Basic device settings including operation panel language, timers, and
security options including panel and interface locks. Some functions may
require the device to be restarted.

7-1 User Guide

Multi-Set

Device Network Settings

Basic settings for TCP/IP, security and network configurations. Some
functions may require the device or the network to be restarted.

Device Default Settings

Settings that define default behavior for print, copy, scan and FAX jobs
including paper size, print and scan quality, and default media types.

Device Authentication Settings

Settings that define local or network authorization for accessing a device.
These settings vary by device.

Device User List

Login user name, user name (and furigana, if applicable), password, e-mail
address, account name, account ID on the device, and administrator access
permission.

Device Address Book

Number, name, furigana (if applicable), e-mail, FTP address, SMB address,
FAX, internet FAX addresses, and address groups.

Device Document Box

Users' custom and FAX boxes.

Device Network Groups

Creation of groups used for group authorization, and enabling/disabling of
groups. The availability of these settings depends upon the device.

Device Virtual Mailbox

Virtual mailboxes, including ID, name, and maximum VMB size are included.

Creating Settings From a Device

You can copy settings from the source device.

In any Device view, select one or more devices.

1

In the Device menu, click Advanced > Set multiple devices.

2

On the Multi-Set Mode page, select Custom mode and then click Next.

3

On the Device group page, select one group to apply settings to and then click

4

Next.

On the Settings page, select one or more settings to copy to the destination

5

devices.

On the Method page, click Create from device and then click Next.

6

On the Source Device page, click on one device from the list and then click

7

Next.

On the Confirmation page, you can see a list of your settings.

8

Click Edit settings to open a dialog box to make changes to the settings, if
needed.

KYOCERA Net Viewer 5.3 7-2

Multi-Set

Click Save to file if you want to save your settings to a file. The settings are
saved to a file in .CSV, .XML or .ZIP format. If you select more than one setting,
this file is saved as a .ZIP file.

Note: Multi-Set Template (.ZIP) files consist of XML files generated by this
application only.

Click Back to make any changes.

Click Finish.

9

If the device must be restarted to save the settings, a message appears. Click
OK to close.

If the process completes successfully, the properties or settings are copied from
the source device to the destination device. Click Close.

If the process does not complete successfully, you can click Details to see a list
of the errors. If you want to save the error list, click Export to open a dialog box
for saving to a log file in .CSV format.

Creating Settings From a File

You can create a settings template from an existing file.

In any Device view, select one or more devices.

1

In the Device menu, click Advanced > Set multiple devices.

2

On the Multi-Set Mode page, select Custom mode.

3

On the Device group page, select one group to apply settings to and then click

4

Next.

On the Settings page, select one or more settings to copy to the destination

5

devices.

On the Method page, click Create from file. Click Next.

6

Type a file path, or click Browse to locate and select a file you want to use. You

7

have the option to open the following formats:

Multi-Set template from the current software version (.CSV, .XML or .ZIP)

Account list file (.CSV or .XML)

Address Editor data file (.AED)

Address Editor for FAX data file (.FED)

Address Book for Network FAX (.FDT). Support varies by model.

Address Book data file (.ABF or .CSV)

User list export file (.CSV)

Click Open, and then click Next.

8

On the Confirmation page, you can see a list of your settings.

9

7-3 User Guide

Click Edit settings to open a dialog box to make changes to the settings, if
needed.

Click Save to file if you want to save your settings to a file. The settings are
saved to a file in .CSV, .XML or .ZIP format. If you select more than one setting,
this file is saved as a .ZIP file.

Note: Multi-Set Template (.ZIP) files consist of XML files generated by this
application only.

Click Finish.

10

If the device must be restarted to save the settings, a message appears. Click
OK to close.

If the process completes successfully, the properties or settings are copied from
the file to the destination device. Click Close.

If the process does not complete successfully, you can click Details to see a list
of the errors. If you want to save the error list, click Export to open a dialog box
for saving to a log file in .CSV format.

Creating New Settings

You can create a new settings template.

Multi-Set

In any Device view, select one or more devices.

1

In the Device menu, click Advanced > Set multiple devices.

2

On the Multi-Set Mode page, select Custom mode.

3

On the Device group page, select one group to apply settings to and then click

4

Next.

On the Settings page, select one or more settings to copy to the destination

5

devices.

On the Method page, click Create new and then click Next.

6

In the Select Setting Group for View and Edit dialog box, make any changes

7

to your settings and click OK or Close.

On the Confirmation page, you can see a list of your settings.

8

Click Edit settings to open a dialog box to make changes to the settings, if
needed.

Click Save to file if you want to save your settings to a file. The settings are
saved to a file in .CSV, .XML or .ZIP format. If you select more than one setting,
this file is saved as a .ZIP file.

Note: Multi-Set Template (.ZIP) files consist of XML files generated by this
application only.

KYOCERA Net Viewer 5.3 7-4

Multi-Set

Click Back to make any changes.

Note: Address book can be saved as a .CSV file.

Click Finish.

9

If the device must be restarted to save the settings, a message appears. Click
OK to close.

If the process completes successfully, the new properties or settings are copied
to the destination device. Click Close.

If the process does not complete successfully, you can click Details to see a list
of the errors. If you want to save the error list, click Export to open a dialog box
for saving to a log file in .CSV format.

Overwriting Settings

You can overwrite certain settings on the destination device.

In any Device view, select one or more devices.

1

In the Device menu, click Advanced > Set multiple devices.

2

On the Multi-Set Mode page, select Custom mode.

3

On the Device group page, select one group to apply settings to, and then click

4

Next.

On the Settings page, select from one or more of these settings to copy to the

5

destination devices:

Device User List

Device Address Book

Device Document Box

Device Network Groups

Device Virtual Mailbox

The Overwrite settings on target device check box appears on the Method
page. If you select this check box, the settings template saves over the current
destination device settings. Clear this check box to ensure that only settings that
do not overlap with existing settings are written.

Continue with your procedure.

6

7-5 User Guide

8 Firmware Upgrade

This section describes how to install firmware on supported devices. From a
master file, you can install firmware on a single device or groups of devices.
When upgrading multiple devices or a group, the process bypasses any devices
that do not match the models for the selected firmware. If there are no matching
devices that require a version upgrade, a message appears.

The firmware file is provided by an administrator or dealer. If the firmware file
version is older than the installed version on the device, then the firmware is
downgraded.

Before performing a firmware upgrade, ensure TCP ports 800-810 are available
and not blocked by a firewall.

Note: If local authentication is on, an administrator must type a login user
name and password in Device > Communication Settings > Login. For some
models, logging in with a user name and password is not supported. You must
enter the administrator password in the communication settings before you
perform a firmware upgrade. All settings and passwords for the source and
destination devices must be correct in Communication Settings for a
successful Firmware Upgrade completion.

The Start of Job String must be blank for the logical printer used. You can
check or modify this setting on the print device’s home page.

Firmware Upgrade Risks

Using this wizard poses a risk of damaging the device. When preparing to
upgrade firmware, remember to review the process with your administrator or
dealer and establish contingency plans. The wizard requires that you
acknowledge and accept the potential risk of firmware installation.

Warning: If a device is turned off or loses power at a critical point during the
upgrade, the device could become inoperable and require servicing to replace
damaged components.

Upgrading the Firmware

You can use the wizard to install firmware on devices. If the firmware file version
is older than the installed version on the device, then the firmware is
downgraded. A maximum of five devices can be processed at a time.

In any Device view, select one or more devices.

1

In the Device menu, click Advanced > Upgrade firmware.

2

On the Warning page, select the check box to acknowledge and accept risk.

3

Click Next.

KYOCERA Net Viewer 5.3 8-1

Firmware Upgrade

4

5

6

7

Finishing Options

On the Select Firmware page, type the path for the firmware file, or click
Browse to find a valid firmware file and click Open. Click Next.

Note: Firmware files are not provided with this application. Consult your

dealer.

On the Confirm your selections page:

If the firmware file cannot be validated, click Back and select another
firmware file.

If valid firmware and device information is displayed, click Upgrade.

You can click Cancel to abort an upgrade that has not yet started. This does not
stop upgrades that are currently processing.

When upgrades are finished, you can view or save a copy of the log, or click
Close.

While an upgrade is in progress, several features are available on the final page
of the wizard:

Log

Displays detailed upgrade information for each device.

Search

Type the value or part of the value of an IP address or Host name in the
Search text box. To clear the search results and display the entire list again,
click the Clear search icon in the toolbar.

Counters

Displays the number of devices by current upgrade status.

Save log

Click to save a .CSV log file containing information about the upgrade.

Close / Cancel

Displays Close or Cancel, depending on the upgrade status. Cancel quits
the process for devices that are still in queue. It does not affect the devices
that are already being upgraded. Close indicates all upgrades are
completed.

8-2 User Guide

9 Workspaces

A workspace is a collection of files including device information and view
settings. The workspace data appears in the device list or map, and the
navigation pane of the screen.

A workspace is identified with a user name and password. When a user opens
the application, the last workspace from that user's history is automatically
opened. When the user closes the application, the workspace is automatically
saved. Normally, a user needs only one workspace, but if there is more than
one location, with a list of different devices, additional workspaces can be
defined.

You can import a file into a workspace, or export a workspace to a file. A
workspace can also be exported to another filename for backup purposes. A list
(current view) can be exported to a file, and current workspace devices can be
exported to a file.

Adding a New Workspace

You can create a new workspace on your computer or network.

In the File menu, click New workspace.

1

In the Browse For Folder dialog box, go to the desired location for the new

2

workspace folder.

Select an existing folder or click Make New Folder.

3

Type a name for the new folder, and click OK.

4

The current workspace is saved and closed before opening the new workspace.

Opening an Existing Workspace

You can open a workspace that has been created on your computer or network.
A workspace created for an older version of the application (5.x) is converted for
the newer version and cannot be changed back.

In the File menu, click Open workspace.

1

In the Browse For Folder dialog box, go to the location of an existing

2

workspace and click that workspace folder.

Click OK.

3

The current workspace is saved and closed before opening the selected
workspace.

KYOCERA Net Viewer 5.3 9-1

Workspaces

Import and Export Workspaces

A workspace is a collection of files including device and UI information. You can
bring in a workspace from a different version of the application or from another
user.

The file extension of a workspace imported from version 4.x is .KV3.

The file extension of a workspace imported from version 5 or later is .KVX.

The file extension of a workspace imported from KM-Net for Accounting is
.XML.

To make it possible to reuse the device data and UI information created in the
older version, you can import and convert the older workspace to the new
workspace.

You can also share a workspace with another user. To protect the integrity of
the data, other users--even administrators--cannot access your workspace. To
copy a workspace to another user, you must export the workspace, then the
other user must import it. The workspace is identified with a user name and
password.

Importing a File to a New Workspace

You can import a workspace from another user or from the 4.x version of the
application. You can also import from a KM-Net for Accounting database.

In the File menu, click Import to new workspace.

1

In the Import To New Workspace dialog box, under File, type a file path or

2

click Browse to select a workspace file. The file must have an extension of
.KVX, .XML, or .KV3.

Under Workspace folder, type a file path or click Browse to select a folder to

3

save the workspace file in.

Click OK. The application automatically saves the current workspace, and

4

opens the one you have selected to import.

Exporting a Workspace to a File

You can copy a workspace from a user or from the application version 5.x to a
file that can be imported to another user or a newer version.

In the File menu, click Export > Workspace.

1

In the Export Workspace dialog box, type a filename and specify a destination

2

for the export.

Click Save and then click OK.

3

Viewing Recent Workspaces

You can view and use recently opened workspaces. The last five workspaces
appear in the list.

In the File menu, click Open recent.

1

9-2 User Guide

Select the desired workspace from the list. If another workspace is already

2

open, the application automatically saves and closes it before opening the
selected workspace.

Workspaces

KYOCERA Net Viewer 5.3 9-3

10 Options

You can choose settings for certain system authentication and communications
options, set or change a local password for users who do not have administrator
rights on a computer, and configure the application to send e-mail notifications
to users about certain device conditions. You can set default device or account
polling settings for new devices and choose settings for the trap server, the
SNMP trap packet receiver that runs in the application.

Editing E-mail Options

You can configure the application to send e-mail notifications to users about
certain device or counter conditions, such as cover open, paper jam, or counter
exceeding the limit.

In the Edit menu, click Options.

1

In the Options dialog box, click Mail settings.

2

In the Host text box, type the SMTP (e-mail) server name, and in Port, type the

3

port number.

To use authentication, select Require authentication. In the User name text

4

box, type the user name needed to log in to the SMTP server, and in
Password, type the user password needed to log in to the SMTP server.

In the Sender name text box, type the sender's name, and in the Sender

5

address, type the sender's e-mail address.

To test the connection to the SMTP server, click Test connection. A message

6

appears to indicate whether the application was able to successfully connect to
the SMTP server. If necessary, correct the host name and port number and test
the connection again.

Note: Test connection does not check the validity of the user name and
password.

Click OK.

7

Editing Authentication Options

You can set up a password for other Windows users to log on to the application.
This feature is only available for administrators.

In the Edit menu, click Options.

1

10-1 User Guide

In the Options dialog box, click Authentication.

2

Select the Enable local password check box.

3

In the New password text box, type a password for a local user. A password is

4

a maximum of 32 characters. A blank password is allowed.

In the Confirm password text box, type the password again.

5

Click OK.

6

Editing Device Polling Options

You can set default device polling settings for new devices. These settings
determine the initial values of the Communication Settings when a device is
added. The settings do not affect devices that already have been added.

In the Edit menu, click Options.

1

Options

In the Options dialog box, click Default device polling settings.

2

Select Status polling if you want to track the condition of devices, such as

3

whether a device is offline, or has a cover open. Type the number of seconds or
click the up and down arrows to select a polling Interval (seconds). The
available range is between 5 and 300 seconds. The default value is 60 seconds.

Select Counter polling if you want to count pages, such as total printed pages,

4

or printed color pages. Type the number of minutes or click the up and down
arrows to select a polling Interval (minutes). The available range is between 1
and 10000 minutes. The default value is 60 minutes.

Select Toner level polling if you want to track the amount of toner available in

5

the devices. The toner level column in the device lists shows the relative
amount of toner in a rectangular icon. If the toner is empty, an exclamation mark
shows in the icon. Toner level polling shows the amount of black toner for
black and white devices. For color devices the polling shows the amounts of
black, cyan, magenta, and yellow toners.

Type the number of minutes or click the up and down arrows to select a polling
Interval (minutes). The available range is between 1 and 10000 minutes. The
default value is 1440 minutes.

Click OK.

6

Editing SNMP Trap Options

The SNMP protocol provides and transfers management information within the
network environment. Should an error occur, such as Add paper, the device
automatically generates a trap. The trap sends an error message to one or two
predetermined trap recipients. The trap server is the SNMP trap packet receiver
which runs in the application. To receive trap packets, the user has to start the
trap server and then configure the SNMP trap on the device as described in the

KYOCERA Net Viewer 5.3 10-2

Options

device documentation. TCP port 162 must be available and not blocked by a
firewall.

In the Edit menu, click Options.

1

In the Options dialog box, click Trap.

2

Server status shows if the trap server is running. If the trap server is not

3

running, you can click Start.

If a connection cannot be made with the trap server, a message appears. See
the log file at C:\Program Files\Kyocera\NetViewer\KNV\log for an error
message as to why the trap server failed to start. Correct the error, and try again
to start the trap server.

If the trap server is running, you can click Stop to halt it. The server status
changes to indicate it is not running.

If you want to allow the receipt of SNMP trap packets that have the same

4

community name as the trap community (which is stored in the application),
type the trap community name in the Trap community text box. The default is
public.

If you want to start the trap server whenever the application is started, select

5

Automatically run trap server when the program starts. The default is for

the option to be cleared: to not allow the trap server to start automatically.

Click OK.

6

Editing Account Polling Options

You can specify settings for default account counter polling for new devices.

In the Edit menu, click Options.

1

In the Options dialog box, click Default account polling settings.

2

Select the Default account counter polling for new devices check box.

3

For the Account counter polling interval, select Daily, Weekly or Monthly

4

from the list.

In the Time text box, type a valid time that you want polling to occur, or use the

5

up-and-down arrows to select a time.

If you selected Weekly for the Account counter polling interval, select the

6

day of the week you want polling to occur from the Day list.

If you selected Monthly for the Account counter polling interval, select the
numeric day of the month you want polling to occur from the Date list.

10-3 User Guide

Select a Warning level. The polling action issues a warning when either 60% or

7

more of available accounts are counted, or 80% or more of available accounts
are counted. The default is 80%.

Click OK.

8

Options

KYOCERA Net Viewer 5.3 10-4

Rev. 5.3 2013.06
