Konica Minolta bizhub C70hc User Manual

Contents

1 Introduction

1.1 Welcome .......................................................................................................................................... 1-2

1.1.1 Composition of User's Guide............................................................................................................. 1-2

1.2 Forgery Preventention Function .................................................................................................... 1-2

2 Precautions for Installation and Use

2.1 Safety Information........................................................................................................................... 2-2

2.1.1 Disassemble and Modification........................................................................................................... 2-3

2.1.2 Power Cord........................................................................................................................................ 2-3

2.1.3 Power Source .................................................................................................................................... 2-3

2.1.4 Power Plug......................................................................................................................................... 2-4

2.1.5 Grounding .......................................................................................................................................... 2-4

2.1.6 Installation.......................................................................................................................................... 2-4

2.1.7 Ventilation .......................................................................................................................................... 2-5

2.1.8 Actions in Response to Troubles....................................................................................................... 2-5

2.1.9 Consumables ..................................................................................................................................... 2-5

2.1.10 When Moving the Machine ................................................................................................................ 2-6

2.1.11 Before Successive Holidays .............................................................................................................. 2-6

2.1.12 Paper.................................................................................................................................................. 2-6

2.1.13 Paste Pellet ........................................................................................................................................ 2-6

2.1.14 Perfect Binder .................................................................................................................................... 2-7

2.1.15 Authentication Unit (IC Card Type) AU-201 ....................................................................................... 2-7

2.2 Regulation Notices.......................................................................................................................... 2-8

2.2.1 Laser Safety ....................................................................................................................................... 2-8

2.2.2 Ozone Release................................................................................................................................... 2-9

2.2.3 Electromagnetic Interference............................................................................................................. 2-9

2.3 Warning and Caution Labels........................................................................................................ 2-11

2.3.1 Caution Label on Fusing Part of Fixing Conveyance Unit ............................................................... 2-11

2.3.2 Caution Label on Fixing Conveyance Unit....................................................................................... 2-12

2.3.3 Caution Label on Toner Recovery Box............................................................................................ 2-13

2.3.4 Caution Label on Perfect Binder PB-503......................................................................................... 2-14

2.3.5 Caution Label on Finisher FS-531/Finisher FS-612......................................................................... 2-15

2.3.6 Caution Label on Large Capacity Unit LU-202 ................................................................................ 2-16

2.3.7 Caution Labels on Multi Punch GP-501 .......................................................................................... 2-17

2.4 Installation Space.......................................................................................................................... 2-18

2.5 Operation Precautions.................................................................................................................. 2-31

2.5.1 Power source................................................................................................................................... 2-31

2.5.2 Operating environment .................................................................................................................... 2-31

2.5.3 Storage of printed materials ............................................................................................................ 2-31

2.5.4 Ozone release .................................................................................................................................. 2-31

2.5.5 Direct sunlight .................................................................................................................................. 2-31

2.5.6 Precaution for use of Folding Unit and Finisher............................................................................... 2-32

bizhub PRESS C70hc contents-1

MEMO

contents-2 bizhub PRESS C70hc

1

Introduction

1

1 Introduction

1.1 Welcome

Thank you for purchasing this machine.

This User's Guide describes the functions, operating instructions, precautions for correct operation, and sim­ple troubleshooting guidelines of this machine. In order to obtain maximum performance from this product
and use it effectively, please read this User's Guide as necessary.

1.1.1 Composition of User's Guide

Printed manual Overview

[Safety Information] This guide provides precautions and requests that

Welcome

should be followed to ensure safe usage of this ma­chine.
Please be sure to read this guide before using the ma­chine.

1.1

User's guide CD manuals Overview

[User's Guide - Main Body] This guide describes an outline of the machine and

printing operations. It also provides you with detailed
information on machine management and how to cus­tomize the machine according to your daily use.

• Configuration and specifications of the main body
and options

• Turning on/off the machine

• Paper information

• Supplies, disposals, and handling of output paper

•Quality Adjustment

• Application, Output Setting, and Job List

• Troubleshooting

• Both Sides Adjustment, Curl Adjustment

• Controller Settings

• Adjustment, Utility Menu Screen

• Network Settings, PageScope Web Connection

• Web Utilities

[User's Guide - Printer (IC-601)] This guide describes the setting of the printer drivers

[User's Guide - Security] This guide describes the security functions.

[Trademarks/Copyrights] This guide describes trademarks, licenses, and copy-

and utility tool of IC-601.

• Adobe PS driver

• PostScript3 Plug-in driver

• XPS driver

• PageScope Web Connection

Please refer to this guide for how to use the Enhanced
Security mode, and for detailed machine operation in
Enhanced Security mode.

rights concerning this machine.
Please be sure to read this guide before using the ma­chine.

1.2 Forgery Preventention Function

This machine provides the forgery prevention function in order to prevent financial instruments from being
printed illegally.

We appreciate your understanding that printed images may infrequently have some noise or image data may
not be stored under certain circumstances due to this forgery prevention function.

1-2 bizhub PRESS C70hc

2

Precautions for
Installation and Use

2

2 Precautions for Installation and Use

2.1 Safety Information

This section contains detailed instructions on the operation and maintenance of this machine. To achieve op­timum utility of this device, all operators should carefully read and follow the instructions in this manual.

Please read the following section before connecting the machine to the supply. It contains important infor­mation related to user safety and preventing equipment problems.

Please keep this manual in a handy place near the machine.

Make sure you observe all of the precautions appear in each section of this manual.

d Reference

Some parts of the contents of this section may not correspond with the purchased product.

Warning and precaution symbols

The following indicators are used on the warning labels or in this manual to categorize the level of safety warn­ings.

Safety Information

2.1

Meaning of symbols

A triangle indicates a danger against which you should take precaution.

This symbol warns against cause burns.

A diagonal line indicates a prohibited course of action.

This symbol warns against dismantling the device.

A solid circle indicates an imperative course of action.

This symbol indicates you must unplug the device.

Ignoring this warning could cause serious injury or even death.

Ignoring this caution could cause injury or damage to property.

2-2 bizhub PRESS C70hc

2.1 Safety Information

2.1.1 Disassemble and Modification

Do not attempt to remove the covers and panels which have
been fixed to the product. Some products have a high-volt­age part or a laser beam source inside that could cause an
electrical shock or blindness.

Do not modify this product, as a fire, electrical shock, or
breakdown could result. If the product employs a laser, the
laser beam source could cause blindness.

2.1.2 Power Cord

Do not scratch, abrade, place a heavy object on, heat, twist,
bend, pull on, or damage the power cord. Use of a damaged
power cord (exposed core wire, broken wire, etc.) could re­sult in a fire or breakdown.
Should any of these conditions be found, immediately turn
OFF the power switch, unplug the power cord from the pow­er outlet, and then call your authorized service representa­tive.

2

2.1.3 Power Source

Use only the power source voltage specified on the machine.
Failure to do that could result in a fire or electrical shock.

Do not use a multiple outlet adapter to connect any other ap­pliances or machines. Use of a power outlet for more than the
marked current value could result in a fire or electrical shock.

Do not use an extension cord in principle. Use of an exten­sion cord could cause a fire or electrical shock. Contact your
authorized service representative if an extension cord is re­quired.

The outlet must be near the equipment and easily accessible.
Otherwise you can not pull out the power plug when an emer­gency occurs.

bizhub PRESS C70hc 2-3

2

2.1.4 Power Plug

Do not unplug and plug in the power cord with a wet hand,
as an electrical shock could result.

Plug the power cord all the way into the power outlet. Failure
to do this could result in a fire or electrical shock.

Do not tug the power cord when unplugging. Pulling on the
power cord could damage the cord, resulting in a fire or elec­trical shock.

Remove the power plug from the outlet more than one time a
year and clean the area between the plug terminals. Dust that
accumulates between the plug terminals may cause a fire.

Do not place any objects around the power plug, as the pow­er plug may be difficult to pull out when an emergency oc­curs.

Safety Information

2.1

2.1.5 Grounding

Connect the power cord to an electrical outlet that is
equipped with a grounding terminal.

2.1.6 Installation

Do not place a flower vase or other container that contains
water, or metal clips or other small metallic objects on this
product. Spilled water or metallic objects dropped inside the
product could result in a fire, electrical shock, or breakdown.
Should a piece of metal, water, or any other similar foreign
matters get inside the product, immediately turn OFF the
power switch, unplug the power cord from the power outlet,
and then call your authorized service representative.

Do not use flammable sprays, liquids, or gases inside or near
this machine. Do not clean the inside of this machine using a
flammable gas duster. A fire or explosion could result.

After installing this product, mount it on a secure base. If the
unit moves or falls, it may cause personal injury.

Do not place the product in a dusty place, or a site exposed
to soot or steam, near a kitchen table, bath, or a humidifier.
A fire, electrical shock, or breakdown could result.

Do not place this product on an unstable or tilted bench, or
in a location subject to a lot of vibration and shock. It could
drop or fall, causing personal injury or mechanical break­down.

Do not let any object plug the ventilation holes of this prod­uct. Heat could accumulate inside the product, resulting in a
fire or malfunction.

2-4 bizhub PRESS C70hc

2.1 Safety Information

2.1.7 Ventilation

Using this product in a poorly ventilated room for a long time
or producing a large volume of copies or prints may cause
the odor of exhaust air from the machine. Ventilate the room
well.

2.1.8 Actions in Response to Troubles

Do not keep using this product, if this product becomes inor­dinately hot or emits smoke, or unusual odour or noise. Im­mediately turn OFF the power switch, unplug the power cord
from the power outlet, and then call your authorized service
representative. If you keep on using it as is, a fire or electrical
shock could result.

Do not keep using this product, if this product has been
dropped or its cover damaged. Immediately turn OFF the
power switch, unplug the power cord from the power outlet,
and then call your authorized service representative. If you
keep on using it as is, a fire or electrical shock could result.

2

The inside of this product has areas subject to high temper­ature, which may cause burns.
When checking the inside of the unit for malfunctions such as
a paper misfeed, do not touch the locations (around the fus­ing unit, etc.) which are indicated by a "Caution HOT" caution
label.

2.1.9 Consumables

Do not throw the toner bottle or toner into an open flame. The
hot toner may scatter and cause burns or other damage.

Do not leave toner-related parts (toner bottles or drum units)
within easy reach of children. Licking any of these parts or in­gesting toner could damage your health.

Do not store toner-related parts (developing units) near de­vices susceptible to magnetism, such as precision equip­ment and data storage devices. They could cause these
products to malfunction.

bizhub PRESS C70hc 2-5

2

2.1.10 When Moving the Machine

Whenever moving this product, be sure to disconnect the
power cord and other cables. Failure to do this could damage
the cord or cable, resulting in a fire, electrical shock, or
breakdown.

Do not move this product. If it is moved or falls, it may cause
severe personal injury.

2.1.11 Before Successive Holidays

Unplug the product when you will not use the product for
long periods of time.

2.1.12 Paper

Safety Information

2.1

Do not use stapled paper, conductive paper (such as silver
paper or carbon paper) or treated heat-sensitive/inkjet paper,
otherwise a fire may result.

2.1.13 Paste Pellet

Do not put paste pellets close to fire. Paste pellets are flam­mable and easy to catch on fire.

Do not swallow paste pellets. Should you swallow any, drink
large amount of water or milk to vomit, and immediately con­sult a doctor.

Keep out of reach of children in order to avoid unexpected
accidents.

2-6 bizhub PRESS C70hc

2.1 Safety Information

2.1.14 Perfect Binder

Do not use the perfect binder without ventilation for an ex­tended period of time. Ensure to ventilate the room on a reg­ular basis. It is recommended that the perfect binder should
be installed in a place with a local exhaust system. Using the
perfect binder in a room without appropriate ventilation could
pose health hazard.

Handle melted hot paste carefully. If it gets in the eye, do not
rub nor tray to open the eye, but cool it with cold water im­mediately and consult a doctor.

Do not touch melted hot paste as it may cause burn injury. If
it sticks on your skin, cool that part of the skin with cold water
immediately and consult a doctor.

Do not touch the paste tank unit immediately after you turned
off the machine to avoid burn injury. Wait until the unit is no
longer hot when you handle it directly with your hands.

Do not put the paste hopper and the paste tank unit close to
fire. Paste is flammable and easy to catch on fire.

Do not get close to the vapor emitted from melted hot paste.
If you have irritation in or around your eyes, nose or throat,
move to an area where you can get fresh air.

Do not block up the vent for the fan on the back of the perfect
binder. This will prevent the discharge of heat, and may
cause fire or breakdown.

Do not change the temperature setting for the paste tank
unit. This may cause fire or breakdown.

2

2.1.15 Authentication Unit (IC Card Type) AU-201

Do not use this product near water, otherwise it may be dam­aged.

Do not cut, damage, modify or forcefully bend the USB cable.
A malfunction may occur as a result of a damaged or cut UBS
cable.

Do not diassembly this device, otherwise it may be damaged.

Do not store the IC card within 40 mm of the card scanning
area.

bizhub PRESS C70hc 2-7

2

2.2 Regulation Notices

2.2.1 Laser Safety

This product employs a Class 3B laser diode having maximum power of 15 mW and wavelength of 785-800
nm.

This product is certified as a Class 1 laser product. Since the laser beam is concealed by protective housings,
the product does not emit hazardous laser radiation as long as the product is operated according to the in­structions in this manual.

Regulation Notices

2.2

2-8 bizhub PRESS C70hc

2.2 Regulation Notices

- For Denmark Users

ADVARSEL

Usynlig laserstråling ved åbning, når sikkerhedsafbrydere er ude af funktion.

Undgå udsættelse for sråling.

Klasse 1 laser produkt der opfylder IEC 60825-1 sikkerheds kravene.

Dansk: Dette er en halvlederlaser. Laserdiodens højeste styrke er 15 mW og bølgelængden er 785-800 nm.

- For Norway Users

ADVARSEL

Dersom apparatet brukes på annen måte enn spesifisert I denne bruksanvisning, kan brukeren utsettes for
usynlig laserstråling som overskrider grensen for laser klass 1.

Dette en halvleder laser. Maksimal effekt till laserdiode er 15 mW og bøkgelengde er 785-800 nm.

- For Finland, Sweden Users

LUOKAN 1 LASERLAITE

KLASS 1 LASER APPARAT

VAROITUS!

Laitteen käyttäminen muulla kuin tässä käyttöohjeessa mainitulla tavalla saattaa altistaa käyttäjän turvallisu­usluokan 1 ylittävälle näkymättömälle lasersäteilylle.

Tämä on puolijohdelaser. Laserdiodin suurin teho on 15 mW ja aallonpituus on 785-800 nm.

VARNING!

Om apparaten används på annat sätt än I denna bruksanvisning specificerats, kan användaren utsättas för
osynlig laserstrålning, som överskrider gränsen för laserklass 1.

Det här är en halvledarlaser. Den maximala effekten för laserdioden är 15 mW och våglängden är 785-800 nm.

2

2.2.2 Ozone Release

During print operation, a small quantity of ozone is released. This amount is not large enough to harm anyone
adversely. However, be sure the room where the machine is being used has adequate ventilation, especially
if you are printing a high volume of materials, or if the machine is being used continuously over a long period.

2.2.3 Electromagnetic Interference

This product must be used with a shielded network cable and shielded USB interface cable.

The use of non-shield cables is likely to result in interference with radio communications and is prohibited
under CISPR 22 and local rules.

For European Users

This product complies with the following EU directives:

2004/108/EC and 2006/95/EC

This declaration is valid for the areas of the European Union (EU) or EFTA only.

This device must be used with a shielded network cable and shielded USB interface cable. The use of non­shielded cables is likely to result in interference with radio communications and is prohibited under
2004/108/EC rules.

For German Users

Maschinenlarminformations -Verordnung - 3. GPSGV, 06.01.2004:

Der Höchste Schalldruckpegel beträegt 85 dB(A) oder weniger nach ISO 7779.

Notification for US only

Contains Mercury in the LCD control panel backlighting lamp, and/or in the scanning unit lamp. Dispose Ac­cording to Local, State or Federal Laws.

Notification for California Customers

This product uses a CR Lithium Battery which contains perchlorate material.

bizhub PRESS C70hc 2-9

2

Regulation Notices

This perchlorate warning applies to perchlorate-containing lithium batteries sold or distributed in California,
USA.

"Perchlorate Material - Special handling may apply, See www.dtsc.ca.gov/ hazardouswaste/perchlorate

CE Marking (Declaration of Conformity) for Users of the European Union (EU)

This product complies with the following EU directives:

2004/108/EC and 2006/95/EC directives.

This declaration is valid for the area of the European Union.

This device must be used with a shielded network (10 Base-T/100 Base-TX) cable and a shielded parallel ca­ble. The use of non-shielded cables is likely to result in interference with radio communications and is pro­hibited under CISPR rules and local rules.

USER INSTRUCTIONS FCC PART 15 - RADIO FREQUENCY DEVICES (For U.S.A. Users)

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.

NOTE:

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful interference when the equipment
is operated in a commercial environment. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause harmful interfer­ence to radio communications. Operation of this equipment in a residential area is likely to cause harmful in­terference in which case the user will be required to correct the interference at his own expense.

WARNING:

The design and production of this unit conform to FCC regulations, and any changes or modifications must
be registered with the FCC and are subject to FCC control. Any changes made by the purchaser or user with­out first contacting the manufacturer will be subject to penalty under FCC regulations.

This device must be used with a shielded network (10 Base-T/100 Base-TX) cable and a shielded parallel ca­ble. The use of non-shielded cables is likely to result in interference with radio communications and is pro­hibited under FCC rules.

INTERFERENCE-CAUSING EQUIPMENT STANDARD (ICES-003 ISSUE 5) (For Canada Users)

This Class A digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.

This device complies with Canadian RSS-Gen.
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this
device must accept any interference, including interference that may cause undesired operation of this de­vice.

Cet appareil est conform à la norme CNR-Gen du Canada.

2.2

."

L’utilisation de ce dispositif est autorisée seulement aux deux conditions suivantes : (1) il ne doit pas produire
de brouillage, et (2) l’utilisateur du dispositif doit être prêt à accepter tout brouillage radioélectrique reçu,
même si ce brouillage est susceptible de compromettre le fonctionnement du dispositif.

For Users in countries not subject to Class B regulations

WARNING:

This is a Class A product. In a domestic environment this product may cause radio interference in which case
the user may be required to take adequate measures.

This device must be used with a shielded network (10 Base-T/100 Base-TX) cable and a shielded parallel ca­ble. The use of non-shielded cables is likely to result in interference with radio communications and is pro­hibited under CISPR rules and local rules.

2-10 bizhub PRESS C70hc

2.3 Warning and Caution Labels

2.3 Warning and Caution Labels

This machine has warning label, caution labels and indicators for safety precaution in the following location.
These labels and indicators advise you to pay special attention to avoid any dangerous situations or serious
injury when you replace the units.

7 CAUTION

Do not remove warning or caution labels!

- Should any warning or caution label be removed, you may fail to check a specific part to be alert for

unexpected trouble or injury. If you find any warning or caution label removed or illegible due to soilage,
please contact your service representative.

2.3.1 Caution Label on Fusing Part of Fixing Conveyance Unit

7 CAUTION

DO NOT touch the fusing part of the fixing conveyance unit. Otherwise, you may get burned.

- Please be especially careful in withdrawing the fixing conveyance unit or opening the fusing part.

2

bizhub PRESS C70hc 2-11

2

2.3.2 Caution Label on Fixing Conveyance Unit

7 CAUTION

DO NOT put your hand or arm between the main body and the fixing conveyance unit.

- Touching connecting terminals of electric parts may damage the machine or cause unexpected trouble.

Please do not try to work yourself, but contact your service representative.

Warning and Caution Labels

2.3

2-12 bizhub PRESS C70hc

2.3 Warning and Caution Labels

2.3.3 Caution Label on Toner Recovery Box

7 WARNING

NEVER throw the toner recovery box into a fire.

- Otherwise, the toner may ignite and cause a dangerous situation.

2

bizhub PRESS C70hc 2-13

2

2.3.4 Caution Label on Perfect Binder PB-503

7 CAUTION

DO NOT touch the paste tank unit. Otherwise, you may get burned.

- Please be especially careful if you push the paste tank unit backward in place.

Warning and Caution Labels

2.3

2-14 bizhub PRESS C70hc

2.3 Warning and Caution Labels

2.3.5 Caution Label on Finisher FS-531/Finisher FS-612

7 CAUTION

DO NOT put your hand on the top of printed sheets when removing them from the primary (main) tray.

- Failure to do so may cause unexpected injury, such as getting your fingers squeezed between the main

body and the primary (main) tray going upward. Be sure to hold both front and rear sides of paper
when removing printed sheets from the tray.

2

bizhub PRESS C70hc 2-15

2

2.3.6 Caution Label on Large Capacity Unit LU-202

7 CAUTION

DO NOT put your hand into the three holes on the tray bottom plate.

- Failure to do so may cause unexpected injury, such as getting your hand squeezed. Be especially care-

ful when loading paper.

Warning and Caution Labels

2.3

2-16 bizhub PRESS C70hc

2.3 Warning and Caution Labels

2.3.7 Caution Labels on Multi Punch GP-501

7 WARNING

- This safety message means you could get an electrical shock because disconnecting power from this

section does not cut off power from adjacent sections of the machine.

7 WARNING

- This safety message means that you might get seriously hurt or killed if you open the product and ex-

pose yourself to hazardous voltage. NEVER remove the screws on covers. ALWAYS refer service re­quirements to qualified service personnel.

2

bizhub PRESS C70hc 2-17

2

410

2216

RU-509 - Main body - PF-602

760 946

100

1041

1639

1478

1041

1639

1478

410

410

1988

760 718

100

1041

477

1639 1639

1478

RU-509 - Main body - LU-202

1120

Main body - MB-506 OT-502 - Main body - MB-506

1020

100

(unit: mm)

410305

2831

RU-506 - GP-501 - RU-509 - Main body - PF-602

760 946

100

1041

1639

1478

(unit: mm)

(unit: mm)

410305310

2603

760 718

100

1041

477

1478

RU-506 - GP-501 - RU-509 - Main body - LU-202

(unit: mm)

(unit: mm)

1041

1639

1478

1530

RU-509 - Main body - MB-506

1020

100

(unit: mm)

1041

1639

1478

1561

100100

(unit: mm)

1046

315

310

2.4 Installation Space

Allow sufficient space for facilitating print operation, changing parts, and periodic inspection. Leave an ade­quate space behind the machine to let hot air out from the rear fan.

The whole machine may weigh approx. 1,372 kg (3,024.69 lb) at maximum, depending on the combination
of options. Be sure to choose a level and solid floor for the installation place.

Installation Space

2.4

2-18 bizhub PRESS C70hc

2.4 Installation Space

y (

Total width (except Image Controller IC-306/IC-307)
3,101 : LS-505 - (RU-509 - Main body - PF-602)
2,873 : LS-505 - (RU-509 - Main body - LU-202)
2,415 : LS-505 - (RU-509 - Main body)

Total width (except Image Controller IC-306/IC-307)
3,100 : FD-503 - (RU-509 - Main body - PF-602)
2,872 : FD-503 - (RU-509 - Main body - LU-202)
2,414 : FD-503 - (RU-509 - Main body)

1020

1231

1639

400267

117100

1020

1639

785

100

(unit: mm)

(unit: mm)

2

(unit: mm)

950 993

2143

RU-509 - Main body (+ IC-601 + HD-514) - PF-602

200

1041

1478

1639

766

950 993

SD-506 - RU-509 - Main bod

(unit: mm)

2143

200

+ IC-601 + HD-514) - PF-602

1639

1478

1041

bizhub PRESS C70hc 2-19

2

)

1639

1020

(unit: mm)

Installation Space

2.4

100

1639

1020

100 117

785 785

Total width (except Image Controller IC-306/IC-307)
3,886 : LS-505 x 2 - (RU-509 - Main body - PF-602)
3,658 : LS-505 x 2 - (RU-509 - Main body - LU-202)
3,200 : LS-505 x 2 - (RU-509 - Main body)

(unit: mm)

544254

Total width (except Image Controller IC-306/IC-307)
3,231 : FS-521 - (RU-509 - Main body - PF-602)
3,003 : FS-521 - (RU-509 - Main body - LU-202)
2,545 : FS-521 - (RU-509 - Main body)
3,846 : FS-521 - (RU-506 - GP-501 - RU-509 - Main body - PF-602)
3,618 : FS-521 - (RU-506 - GP-501 - RU-509 - Main body - LU-202

(unit: mm)

1639

1020

100

Total width (except Image Controller IC-306/IC-307)
3,486 : SD-506 - (RU-509 - Main body - PF-602)
3,258 : SD-506 - (RU-509 - Main body - LU-202)
2,800 : SD-506 - (RU-509 - Main body)

1170

2-20 bizhub PRESS C70hc

2.4 Installation Space

)

2

(unit: mm)

1639

1223

1020

1639

100

Total width (except Image Controller IC-306/IC-307)
3,676 : PB-503 - (RU-509 - Main body - PF-602)
3,448 : PB-503 - (RU-509 - Main body - LU-202)
2,990 : PB-503 - (RU-509 - Main body)

1020

100

Total width (except Image Controller IC-306/IC-307)
3,501 : LS-505 - FD-503 - (RU-509 - Main body - PF-602)
3,273 : LS-505 - FD-503 - (RU-509 - Main body - LU-202)
2,815 : LS-505 - FD-503 - (RU-509 - Main body)

1360

(unit: mm)

785 400

(unit: mm)

1639

1020

100

Total width (except Image Controller IC-306/IC-307)
3,886 : SD-506 - FD-503 - (RU-509 - Main body - PF-602)
3,658 : SD-506 - FD-503 - (RU-509 - Main body - LU-202
3,200 : SD-506 - FD-503 - (RU-509 - Main body)

1170 400

bizhub PRESS C70hc 2-21

2

)

1639

1020

(unit: mm)

Installation Space

2.4

100 117

1639

1020

100

544 400254

Total width (except Image Controller IC-306/IC-307)
3,631 : FS-521 - FD-503 - (RU-509 - Main body - PF-602)
3,403 : FS-521 - FD-503 - (RU-509 - Main body - LU-202)
2,945 : FS-521 - FD-503 - (RU-509 - Main body)
4,246 : FS-521 - FD-503 - (RU-506 - GP-501 - RU-509 - Main body - PF-602)
4,018 : FS-521 - FD-503 - (RU-506 - GP-501 - RU-509 - Main body - LU-202

(unit: mm)

1170 785 400

Total width (except Image Controller IC-306/IC-307)
4,671 : SD-506 - LS-505 - FD-503 - (RU-509 - Main body - PF-602)
4,443 : SD-506 - LS-505 - FD-503 - (RU-509 - Main body - LU-202)
3,985 : SD-506 - LS-505 - FD-503 - (RU-509 - Main body)

(unit: mm)

1639

1020

100 117

Total width (except Image Controller IC-306/IC-307)
4,416 : FS-521 - LS-505 - FD-503 - (RU-509 - Main body - PF-602)
4,188 : FS-521 - LS-505 - FD-503 - (RU-509 - Main body - LU-202)
3,730 : FS-521 - LS-505 - FD-503 - (RU-509 - Main body)

544254

785 400

2-22 bizhub PRESS C70hc

2.4 Installation Space

1360

100

Total width (except Image Controller IC-306/IC-307)
4,861 : PB-503 - LS-505 - FD-503 - (RU-509 - Main body - PF-602)
4,633 : PB-503 - LS-505 - FD-503 - (RU-509 - Main body - LU-202)
4,175 : PB-503 - LS-505 - FD-503 - (RU-509 - Main body)

1639

1223

1020

(unit: mm)

1639

1020

544 1170254

100 117

Total width (except Image Controller IC-306/IC-307)
4,801 : FS-521 - SD-506 - FD-503 - (RU-509 - Main body - PF-602)
4,573 : FS-521 - SD-506 - FD-503 - (RU-509 - Main body - LU-202)
4,115 : FS-521 - SD-506 - FD-503 - (RU-509 - Main body)

(unit: mm)

1360

100

Total width (except Image Controller IC-306/IC-307)
5,246 : PB-503 - SD-506 - FD-503 - (RU-509 - Main body - PF-602)
5,018 : PB-503 - SD-506 - FD-503 - (RU-509 - Main body - LU-202)
4,560 : PB-503 - SD-506 - FD-503 - (RU-509 - Main body)

1639

1223

1020

(unit: mm)

785 400

400

1170 400

2

bizhub PRESS C70hc 2-23

2

1639

1020

Installation Space

(unit: mm)

2.4

100 117

1639

1020

100

544254

Total width (except Image Controller IC-306/IC-307)
6,161 : FS-521 - PB-503 - SD-506 - FD-503 - (RU-509 - Main body - PF-602)
5,933 : FS-521 - PB-503 - SD-506 - FD-503 - (RU-509 - Main body - LU-202)
5,475 : FS-521 - PB-503 - SD-506 - FD-503 - (RU-509 - Main body)

(unit: mm)

785 785 400

Total width (except Image Controller IC-306/IC-307)
4,286 : LS-505 x 2 - FD-503 - (RU-509 - Main body - PF-602)
4,058 : LS-505 x 2 - FD-503 - (RU-509 - Main body - LU-202)
3,600 : LS-505 x 2 - FD-503 - (RU-509 - Main body)

11701360 400

1639

1020

100

Total width (except Image Controller IC-306/IC-307)
4,271 : SD-506 - LS-505 - (RU-509 - Main body - PF-602)
4,043 : SD-506 - LS-505 - (RU-509 - Main body - LU-202)
3,585 : SD-506 - LS-505 - (RU-509 - Main body)

1170 785

2-24 bizhub PRESS C70hc

2.4 Installation Space

(

y)

2

(unit: mm)

1639

1020

1639

1223

100 117

Total width (except Image Controller IC-306/IC-307)
4,016 : FS-521 - LS-505 - (RU-509 - Main body - PF-602)
3,788 : FS-521 - LS-505 - (RU-509 - Main body - LU-202)
3,330 : FS-521 - LS-505 - (RU-509 - Main body)
4,631 : FS-521 - LS-505 - (RU-506 - GP-501 - RU-509 - Main body - PF-602)
4,403 : FS-521 - LS-505 - (RU-506 - GP-501 - RU-509 - Main body - LU-202)

1020

100

Total width (except Image Controller IC-306/IC-307)
4,461 : PB-503 - LS-505 - (RU-509 - Main body - PF-602)
4,233 : PB-503 - LS-505 - (RU-509 - Main body - LU-202)
3,775 : PB-503 - LS-505 - (RU-509 - Main body)
5,076 : PB-503 - LS-505 - (RU-506 - GP-501 - RU-509 - Main body - PF-602)
4,848 : PB-503 - LS-505 - (RU-506 - GP-501 - RU-509 - Main body - LU-202)

544254

1360 785

785

(unit: mm)

(unit: mm)

1639

1020

100 117

Total width (except Image Controller IC-306/IC-307)
5,186 : FS-521 - SD-506 - LS-505 - (RU-509 - Main body - PF-602)
4,958 : FS-521 - SD-506 - LS-505 - (RU-509 - Main body - LU-202)
4,500 : FS-521 - SD-506 - LS-505 -

544254

1170 785

RU-509 - Main bod

bizhub PRESS C70hc 2-25

2

1639

1223

1020

Installation Space

(unit: mm)

2.4

100

1639

1020

100 117

1360

Total width (except Image Controller IC-306/IC-307)
5,631 : PB-503 - SD-506 - LS-505 - (RU-509 - Main body - PF-602)
5,403 : PB-503 - SD-506 - LS-505 - (RU-509 - Main body - LU-202)
4,945 : PB-503 - SD-506 - LS-505 - (RU-509 - Main body)

544254

Total width (except Image Controller IC-306/IC-307)
5,376 : FS-521 - PB-503 - LS-505 - (RU-509 - Main body - PF-602)
5,148 : FS-521 - PB-503 - LS-505 - (RU-509 - Main body - LU-202)
4,690 : FS-521 - PB-503 - LS-505 - (RU-509 - Main body)

1170 785

1360

(unit: mm)

(unit: mm)

785

1639

1020

100

Total width (except Image Controller IC-306/IC-307)
5,056 : SD-506 - LS-505 x 2 - (RU-509 - Main body - PF-602)
4,828 : SD-506 - LS-505 x 2 - (RU-509 - Main body - LU-202)
4,370 : SD-506 - LS-505 x 2 - (RU-509 - Main body)

1170 785 785

2-26 bizhub PRESS C70hc

2.4 Installation Space

(

)

2

(unit: mm)

1639

1020

1639

100 117

1223

1020

100

544254

Total width (except Image Controller IC-306/IC-307)
4,801 : FS-521 - LS-505 x 2 - (RU-509 - Main body - PF-602)
4,573 : FS-521 - LS-505 x 2 - (RU-509 - Main body - LU-202)
4,115 : FS-521 - LS-505 x 2 - (RU-509 - Main body)

1360 785 785

Total width (except Image Controller IC-306/IC-307)
5,246 : PB-503 - LS-505 x 2 - (RU-509 - Main body - PF-602)
5,018 : PB-503 - LS-505 x 2 - (RU-509 - Main body - LU-202)
4,560 : PB-503 - LS-505 x 2 - (RU-509 - Main body)

785 785

(unit: mm)

(unit: mm)

1639

1020

100 117

Total width (except Image Controller IC-306/IC-307)
4,401 : FS-521 - SD-506 - (RU-509 - Main body - PF-602)
4,173 : FS-521 - SD-506 - (RU-509 - Main body - LU-202)
3,715 : FS-521 - SD-506 - (RU-509 - Main body)
5,016 : FS-521 - SD-506 - (RU-506 - GP-501 - RU-509 - Main body - PF-602)
4,788 : FS-521 - SD-506 -

544 1170254

RU-506 - GP-501 - RU-509 - Main body - LU-202

bizhub PRESS C70hc 2-27

2

(

)

1639

1223

1020

(unit: mm)

Installation Space

2.4

100

1639

1020

100 117

1360

Total width (except Image Controller IC-306/IC-307)
4,846 : PB-503 - SD-506 - (RU-509 - Main body - PF-602)
4,618 : PB-503 - SD-506 - (RU-509 - Main body - LU-202)
4,160 : PB-503 - SD-506 - (RU-509 - Main body)

544254

Total width (except Image Controller IC-306/IC-307)
5,761 : FS-521 - PB-503 - SD-506 - (RU-509 - Main body - PF-602)
5,533 : FS-521 - PB-503 - SD-506 - (RU-509 - Main body - LU-202)
5,075 : FS-521 - PB-503 - SD-506 - (RU-509 - Main body)

1170

1360

(unit: mm)

(unit: mm)

1170

1639

1020

100 117

Total width (except Image Controller IC-306/IC-307)
4,591 : FS-521 - PB-503 - (RU-509 - Main body - PF-602)
4,363 : FS-521 - PB-503 - (RU-509 - Main body - LU-202)
3,905 : FS-521 - PB-503 - (RU-509 - Main body)
5,206 : FS-521 - PB-503 - (RU-506 - GP-501 - RU-509 - Main body - PF-602)
4,978 : FS-521 - PB-503 -

544254

1360

RU-506 - GP-501 - RU-509 - Main body - LU-202

2-28 bizhub PRESS C70hc

2.4 Installation Space

(

)

1639

1130

2

(unit: mm)

990

1639

100
116

Total width (except Image Controller IC-306/IC-307)
3,106.5 : FS-612 - PI-502 - (RU-509 - Main body - PF-602)
2,878.5 : FS-612 - PI-502 - (RU-509 - Main body - LU-202)
2,420.5 : FS-612 - PI-502 - (RU-509 - Main body)
2,010.5 : FS-612 - PI-502 - (Main body)
2,696.5 : FS-612 - PI-502 - (Main body - PF-602)
2,468.5 : FS-612 - PI-502 - (Main body - LU-202)

990

100
116

Total width (except Image Controller IC-306/IC-307)
3,106.5 : FS-612 - (RU-509 - Main body - PF-602)
2,878.5 : FS-612 - (RU-509 - Main body - LU-202)
2,420.5 : FS-612 - (RU-509 - Main body)
2,010.5 : FS-612 - (Main body)
2,696.5 : FS-612 - (Main body - PF-602)
2,468.5 : FS-612 -

424

250.5

424

250.5

(unit: mm)

Main body - LU-202

bizhub PRESS C70hc 2-29

2

1639

1130

990

(unit: mm)

Installation Space

2.4

1639

100
116

Total width (except Image Controller IC-306/IC-307)
3,106.5 : FS-531 - PI-502 - (RU-509 - Main body - PF-602)
2,878.5 : FS-531 - PI-502 - (RU-509 - Main body - LU-202)
2,420.5 : FS-531 - PI-502 - (RU-509 - Main body)
2,010.5 : FS-531 - PI-502 - (Main body)
2,696.5 : FS-531 - PI-502 - (Main body - PF-602)
2,468.5 : FS-531 - PI-502 - (Main body - LU-202)

990

100
116

Total width (except Image Controller IC-306/IC-307)
3,106.5 : FS-531 - (RU-509 - Main body - PF-602)
2,878.5 : FS-531 - (RU-509 - Main body - LU-202)
2,420.5 : FS-531 - (RU-509 - Main body)
2,010.5 : FS-531 - (Main body)
2,696.5 : FS-531 - (Main body - PF-602)
2,468.5 : FS-531 - (Main body - LU-202)

424

250.5

424

250.5

(unit: mm)

2-30 bizhub PRESS C70hc

2.5 Operation Precautions

2.5 Operation Precautions

To ensure the optimum performance of this machine, observe the precautions described below.

2.5.1 Power source

The power source requirements are as follows.

Destination North America Europe, Southeast Asia Australia

Voltage 208 V to 240 V AC 220 V to 240 V AC 240 V AC

Frequency 60 Hz 50-60 Hz 50 Hz

Use a power source with as little voltage or frequency fluctuations as possible.

2.5.2 Operating environment

The environmental requirements for correct operation of the machine are as follows.

- Operating temperature: 10°C (50°F) to 30°C (86°F)

- Humidity: 10% to 80%

2

2.5.3 Storage of printed materials

To store printed materials, follow the recommendation listed below.

- Printed materials that are to be kept for a long time should be stored where they are not exposed to

light or high temperature in order to prevent them from fading or sticking together.

- Adhesive that contains solvent (e.g., spray glue) may dissolve the toner on printed paper.

2.5.4 Ozone release

During print operation, a small quantity of ozone is released. This amount is not large enough to harm anyone
adversely. However, be sure the room where the machine is being used has adequate ventilation, especially
if you are printing a high volume of materials, or if the machine is being used continuously over a long period.

2.5.5 Direct sunlight

Do not install the machine and its options in a place exposed to direct sunlight, otherwise the machine per­formance may be degraded or any trouble may be caused.

bizhub PRESS C70hc 2-31

2

2.5.6 Precaution for use of Folding Unit and Finisher

The primary (main) tray of Folding Unit FD-503, Finisher FS-521, Finisher FS-531, or of Finisher FS-612
gradually goes down while printed materials output. DO NOT allow any object to interfere with the operation
of the tray on the left side of the staple finisher, as any interference may cause damage to the staple finisher.

Operation Precautions

2.5

2-32 bizhub PRESS C70hc

2.5 Operation Precautions

MEMO

2

bizhub PRESS C70hc 2-33

2

MEMO

Operation Precautions

2.5

2-34 bizhub PRESS C70hc

2.5 Operation Precautions

MEMO

2

bizhub PRESS C70hc 2-35

2

MEMO

Operation Precautions

2.5

2-36 bizhub PRESS C70hc
