JVC RX-6010VBK, RX-6018VBK Instruction Manual

Download

DIGITAL

AUDIO/VIDEO CONTROL RECEIVER

RX-6010VBK / RX-6018VBK

POWER

SLEEP

VCR

SURROUND

– SUBWOOFER +TEST

SURROUND

EFFECT

– CENTER +

MODE

– REAR•L + – VCR CH +

SOUND

7/P

CD-DISC

TV/VIDEO

– REAR•R +

DVD

TV SOUND

VCR

TAPE/CDR

TV VOL

VOLUME

–

TV CH

–

RM-SRX6010J

REMOTE CONTROL

A/V CONTROL RECEIVER

AUDIO

ANALOG/DIGITAL

FM/AM

MUTING

+10

ENTER

PHONES

STANDBY

POWER

FM/AM TUNING

DIGITAL

SURROUND

SURROUND ON/OFF

DSP MODE

FM/AM PRESET FM MODE

DIGITAL

INPUT ATT

SPEAKERS ON/OFF

MEMORY

INPUT DIGITALINPUT ANALOG

AUDIO/VIDEO CONTROL RECEIVER

DVD VCR TV SOUND

CD TAPE/CDR

SOURCE NAME

FM/AM

ADJUST

DOWN UP

MASTER VOLUME

SETTING

CONTROL

INSTRUCTIONS

For Customer Use:

Enter below the Model No. and Serial No. which are located either on the rear, bottom or side of the cabinet. Retain this information for future reference.

Model No. Serial No.

LVT0578-001A

[J]

Warnings, Cautions and Others/ Mises en garde, précautions et indications diverses

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK. DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

CAUTION

To reduce the risk of electrical shocks, fire, etc.:

1. Do not remove screws, covers or cabinet.

2. Do not expose this appliance to rain or moisture.

ATTENTION

Afin d’éviter tout risque d’électrocution, d’incendie, etc.:

1. Ne pas enlever les vis ni les panneaux et ne pas ouvrir le coffret de l’appareil.

2. Ne pas exposer l’appareil à la pluie ni à l’humidité.

Caution –– POWER switch!

Disconnect the mains plug to shut the power off completely. The POWER switch in any position does not disconnect the mains line. The power can be remote controlled.

Attention –– Commutateur POWER!

Déconnecter la fiche de secteur pour couper complètement le courant. Le commutateur POWER ne coupe jamais complètement la ligne de secteur, quelle que soit sa position. Le courant peut être télécommandé.

For Canada/pour Le Canada

THIS DIGITAL APPARATUS DOES NOT EXCEED THE CLASS B LIMITS FOR RADIO NOISE EMISSIONS FROM DIGITAL APPARATUS AS SET OUT IN THE INTERFERENCE-CAUSING EQUIPMENT STANDARD ENTITLED “DIGITAL APPARATUS,” ICES-003 OF THE DEPARTMENT OF COMMUNICATIONS. CET APPAREIL NUMERIQUE RESPECTE LES LIMITES DE BRUITS RADIOELECTRIQUES APPLICABLES AUX APPAREILS NUMERIQUES DE CLASSE B PRESCRITES DANS LA NORME SUR LE MATERIEL BROUILLEUR; “APPAREILS NUMERIQUES”, NMB-003 EDICTEE PAR LE MINISTRE DES COMMUNICATIONS.

For Canada/pour le Canada

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE

BLADE OF PLUG TO WIDE SLOT, FULLY INSERT ATTENTION: POUR EVITER LES CHOCS ELECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQUAU FOND

For U.S.A.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help.

Caution: Proper Ventilation

T o avoide risk of electric shock and fire and to protect from damage. Locate the apparatus as follows: Front: No obstructions open spacing. Sides: No obstructions in 10 cm from the sides. Top: No obstructions in 10 cm from the top. Back: No obstructions in 15 cm from the back Bottom: No obstructions, place on the level surface. In addition, maintain the best possible air circulation as illustrated.

Spacing 15 cm or more Dégagement de 15 cm ou plus

Wall or obstructions Mur, ou obstruction

Attention: Ventilation Correcte

Pour éviter les chocs électriques, l’incendie et tout autre dégât. Disposer l’appareil en tenant compte des impératifs suivants Avant: Rien ne doit gêner le dégagement Flancs: Laisser 10 cm de dégagement latéral Dessus: Laisser 10 cm de dégagement supérieur Arrière: Laisser 15 cm de dégagement arrière Dessous: Rien ne doit obstruer par dessous; poser l’appareil

sur une surface plate. Veiller également à ce que l’air circule le mieux possible comme illustré.

Front

RX-6010VBK/

Avant

RX-6018VBK

Stand height 15 cm or more Hauteur du socle: 15 cm ou plus

Floor Plancher

Parts Identification ...................................... 2

Getting Started ........................................... 3

Before Installation ......................................................................3

Checking the Supplied Accessories ........................................... 3

Connecting the FM and AM Antennas....................................... 3

Connecting the Speakers ............................................................ 4

Connecting Audio/Video Components....................................... 5

Connecting the Power Cord ....................................................... 7

Putting Batteries in the Remote Control .................................... 7

Basic Operations ......................................... 8

Turning the Power On and Off (Standby) .................................. 8

Selecting the Source to Play....................................................... 8

Adjusting the Volume ................................................................. 9

Listening Only with Headphones............................................... 9

Muting the Sound....................................................................... 9

Adjusting the Subwoofer Output Level.................................... 10

Attenuating the Input Signal .................................................... 10

Adjusting the Tone ................................................................... 10

Basic Settings........................................... 11

Recording a Source .................................................................. 11

Adjusting the Front Speaker Output Balance........................... 11

Setting the Subwoofer Information .......................................... 11

Changing the Source Name...................................................... 11

Setting the Speakers for the DSP Modes ................................. 12

Digital Input (DIGITAL IN) Terminal Setting......................... 14

Selecting the Analog or Digital Input Mode ............................ 14

Storing the Basic Settings and Adjustments............................. 15

Using the Sleep Timer .............................................................. 15

Receiving Radio Broadcasts ........................ 16

Tuning in Stations Manually .................................................... 16

Using Preset Tuning ................................................................. 16

Selecting the FM Reception Mode........................................... 17

Using the DSP Modes ................................ 18

What are the DSP Modes? ....................................................... 18

Reproducing the Sound Field................................................... 19

Available DSP Modes According to the Speaker Arrangement .. 20

Adjusting the Surround Modes ................................................ 21

Adjusting the DAP Modes ....................................................... 23

Activating the DSP Modes....................................................... 24

COMPU LINK Remote Control System ......... 25

Operating JVC’s Audio/Video Components ... 26

Operating Audio Components .................................................. 26

Operating Video Components .................................................. 27

Troubleshooting ......................................... 28

Specifications ............................................ 29

Parts Identification

Become familiar with the buttons and controls on the receiver before use. Refer to the pages in parentheses for details.

1 2

5 6

7 8

STANDBY

POWER

PHONES

SLEEP

SURROUND

MODE

SOUND

TV/VIDEO

DVD

TV VOL

–

TV CH

–

A/V CONTROL RECEIVER

FM/AM TUNING

DIGITAL

SURROUND

SURROUND ON/OFF

DSP MODE

POWER

VCR

– SUBWOOFER +TEST

VOLUME

–

– CENTER +

– REAR•L + – VCR CH +

– REAR•R +

VCR

EFFECT

7/P

CD-DISC

TV SOUND

TAPE/CDR

RM-SRX6010J

REMOTE CONTROL

FM/AM PRESET FM MODE

MEMORY

INPUT ATT

SPEAKERS ON/OFF

ret

AUDIO

+10

ENTER

ANALOG/DIGITAL

FM/AM

MUTING

INPUT DIGITALINPUT ANALOG

AUDIO/VIDEO CONTROL RECEIVER

DVD VCR TV SOUND

TAPE/CDR

SOURCE NAME

Remote Control

1 POWER buttons (8, 27)

TV, VCR, A UDIO

2 SLEEP button (15) 3 SURROUND button (21, 24, 26) 4 SURROUND MODE button

(22 – 24, 26)

5 SOUND button (10, 21 – 23, 26) 6 TV/VIDEO button (27) 7 CD-DISC button (27) 8 Source selecting buttons (8, 9, 15)

DVD, TV SOUND, VCR, CD, TAPE/CDR, FM/AM

9 TV VOL +/– buttons (27) p TV CH +/– buttons (27) q • 10 keys for selecting preset channels

(17)

• 10 keys for adjusting sound (21 – 23, 26)

• 10 keys for operating audio/video components (26, 27)

w ANALOG/DIGITAL button (15) e MUTING button (9) r VOLUME +/– buttons (9) t Operating buttons for audio/video

components (26, 27)

FM/AM

ADJUST SETTING

CONTROL

DOWN UP

MASTER VOLUME

Front Panel

1 POWER button and STANDBY lamp

(8)

2 FM/AM TUNING 5/∞ buttons (16) 3 FM/AM PRESET 5/∞ buttons (16, 17) 4 FM MODE button (17) 5 MEMORY button (16) 6 Display (8) 7 ADJUST button (10, 11, 21 – 23) 8 Remote sensor (7) 9 SETTING button (11 – 14) p MASTER VOLUME control (9) q PHONES jack (9) w SURROUND ON/OFF button (21, 24) e DSP MODE button (22 – 24) r SPEAKERS ON/OFF button (9) t INPUT ANALOG button (15)

INPUT ATT button (10)

y INPUT DIGITAL button (14) u Source selecting buttons (8, 9, 14)

DVD, VCR, TV SOUND, CD, TAPE/CDR, FM/AM

i SOURCE NAME button (11)

TAPE/CDR button also functions as

the SOURCE NAME button

o CONTROL UP 5/DOWN ∞ buttons

Getting Started

ANTENNA

LOOP

FM 75

COAXIAL

EXT

M E

TENNA

ANTENNA

This section explains how to connect audio/video components and speakers to the receiver, and how to connect the power supply.

Before Installation

General

• Be sure your hands are dry.

• Turn the power off to all components.

• Read the manuals supplied with the components you are going to connect.

Locations

• Install the receiver in a location that is level and protected from moisture.

• The temperature around the receiver must be between –5˚C and 35˚C (23˚F and 95˚F).

• Make sure there is good ventilation around the receiver. Poor ventilation could cause overheating and damage the receiver.

Handling the receiver

• Do not insert any metal object into the receiver.

• Do not disassemble the receiver or remove screws, covers, or cabinet.

• Do not expose the receiver to rain or moisture.

Checking the Supplied Accessories

Check to be sure you have all of the following items, which are supplied with the receiver. The number in the parentheses indicates the quantity of the pieces supplied.

• Remote Control (1)

• Batteries (2)

• AM Loop Antenna (1)

• FM Antenna (1)

If anything is missing, contact your dealer immediately.

Connecting the FM and AM Antennas

FM Antenna Connections

FM Antenna

Extend the supplied FM antenna horizontally.

Outdoor FM Antenna Cable

A. Using the Supplied FM Antenna

The FM antenna provided can be connected to the FM 75 Ω COAXIAL terminal as temporary measure.

B. Using the Standard Type Connector (Not Supplied)

A standard type connector should be connected to the FM 75 Ω COAXIAL terminal.

Note:

If reception is poor, connect an outdoor antenna. Before attaching a 75 going to an outdoor antenna), disconnect the supplied FM antenna.

Ω

coaxial cable (the kind with a round wire

AM Antenna Connections

FRONT

SPEAKERS

RIGHT LEFT

CENTER

SPEAKER

REAR

SPEAKERS

RIGHT LEFT

Basic connecting procedure

ANTENNA

FM 75

COAXIAL

LOOP

AM EXT

Snap the tabs on the loop into the slots of the base to assemble the AM loop.

AM Loop Antenna

Outdoor single vinyl-covered wire (not supplied)

Turn the loop until you have the best reception.

1 Cut, twist and remove the insulation at the end of

each speaker signal cable (not supplied).

2 Open the terminal and then insert the speaker

signal cable.

3 Close the terminal.

Connecting the front speakers

Connect front speakers to the FRONT SPEAKERS terminals.

Left speaker Right speaker

Notes:

• If the AM loop antenna wire is covered with vinyl,

remove the vinyl by twisting it as shown in the diagram.

• Make sure the antenna conductors do not touch any

other terminals, connecting cords and power cord. This could cause poor reception.

• If reception is poor, connect an outdoor single vinyl-covered wire to

the AM EXT terminal. (Keep the AM loop antenna connected.)

Connecting the Speakers

You can connect the following speakers:

• One pair of front speakers to produce normal stereo sound.

• One pair of rear speakers to enjoy the surround effect.

• One center speaker to produce more effective surround effect (to

emphasize human voices).

• One subwoofer to enhance the bass.

IMPORTANT:

After connecting the speakers listed above, set the speaker setting information properly to obtain the best possible DSP effect. For details, see page 12.

For each speaker (except for a subwoofer), connect the (+) and (–) terminals on the rear panel to the (+) and (–) terminals marked on the speakers. For connecting a subwoofer, see page 5.

Connecting the rear and center speakers

Connect rear speakers to the REAR SPEAKERS terminals and a center speaker to the CENTER SPEAKER terminals.

Center speaker

Left rear speaker

Right rear

speaker

CAUTION:

Use speakers with the SPEAKER IMPEDANCE indicated by the speaker terminals.

Connecting the subwoofer speaker

PHONO

AUDIO

TV SOUND

VCR

OUT

(REC)

(PLAY)

RIGHT LEFT

TAPE

CDR

OUT

(REC)

You can enhance the bass by connecting a subwoofer. Connect the input jack of a powered subwoofer to the SUBWOOFER OUT jack on the rear panel, using a cable with RCA pin plugs (not supplied).

SUBWOOFER

Powered subwoofer

OUT

Connecting Audio/Video Components

You can connect the following audio/video components to this receiver. Refer also to the manuals supplied with your components.

Audio Components Video Components

• CD player* • DVD player*

• Cassette deck • TV* or CD recorder* • VCR

You can connect these components using the methods described in “Analog connections” (below) or in “Digital connections” (see page

7).

Cassette deck or CD recorder

Cassette deck

To audio input

CD recorder

To audio output

To audio outputTo audio input

Analog connections

Audio component connections

Use the cables with RCA pin plugs (not supplied). Connect the white plug to the audio left jack, and the red plug to the audio right jack.

CAUTION:

If you connect a sound-enhancing device such as a graphic equalizer between the source components and this receiver, the sound output through this receiver may be distorted.

CD player

OUT

(REC)

To audio output

TAPE

CDR

(PLAY)

OUT

(REC)

VCR

(PLAY)

TV SOUND

RIGHT LEFT

AUDIO

Note:

You can connect either a cassette deck or a CD recorder to the TAPE/ CDR jacks. When connecting a CD recorder to the TAPE/CDR jacks, change the source name, which will be shown on the display when selected as the source, to “CDR.” See page 11 for details.

If your audio components have a COMPU LINK jack

See also page 25 for detailed information about the connection and the COMPU LINK remote control system.

Video component connections

Use the cables with RCA pin plugs (not supplied). Connect the white plug to the audio left jack, the red plug to the audio right jack, and the yellow plug to the video jack.

To audio output

OUT

(REC)

TAPE

CDR

(PLAY)

OUT

(REC)

VCR

(PLAY)

TV SOUND

RIGHT LEFT

AUDIO

MONITOR

OUT

DVD

OUT

(REC)

VCR

(PLAY)

VIDEO

To video input

Connect the TV to the MONITOR OUT jack to view the playback picture from the other connected video components.

DVD player



RIGHT

DVD player

DVD

MONITOR

OUT

LEFT

DVD

OUT

(REC)

VCR

(PLAY)

VIDEO

DVD

AUDIO

Å To front left/right channel audio output (or to audio mixed

output if necessary)

ı To video output

Note:

To enjoy the software encoded with Dolby Digital or DTS Digital Surround, you must connect the DVD player using the digital terminal on the rear of this receiver. (See “Digital connections” on page 7.)

VCR

OUT

(REC)

TAPE

CDR

(PLAY)

OUT

(REC)

VCR

(PLAY)

TV SOUND

RIGHT LEFT

AUDIO

MONITOR

Å To left/right channel audio output ı To left/right channel audio input Ç To video output Î To video input

OUT

DVD

OUT

(REC)

VCR

(PLAY)

VIDEO

Digital connections

This receiver is equipped with two DIGITAL IN terminals — one digital coaxial terminal and one digital optical terminal. You can connect any component to one of the digital terminals using a digital coaxial cable (not supplied) or digital optical cable (not supplied).

IMPORTANT:

• When connecting the DVD player or digital TV broadcast tuner using the digital terminal, you also need to connect it to the video jack on the rear. Without connecting it to the video jack, you can view no playback picture.

• After connecting the components using the DIGITAL IN terminals, set the following correctly if necessary. – Set the digital input (DIGITAL IN) terminal setting correctly. For

details, see “Digital Input (DIGITAL IN) Terminal Setting” on page

14.

– Select the digital input mode correctly. For details, see “Selecting

the Analog or Digital Input Mode” on page 14.

Digital TV

DVD player

DVD

CD player CD recorder

Connecting the Power Cord

Before plugging the receiver into an AC outlet, make sure that all connections have been made.

Plug the power cord into an AC outlet.

Keep the power cord away from the connecting cables and the antenna. The power cord may cause noise or screen interference. We recommend that you use a coaxial cable to connect the antenna, since it is wellshielded against interference.

Note:

The preset settings such as preset channels and sound adjustment may be erased in a few days in the following cases:

– When you unplug the power cord. – When a power failure occurs.

CAUTIONS:

• Do not touch the power cord with wet hands.

• Do not pull on the power cord to unplug the cord. When unplugging the cord, always grasp the plug so as not to damage the cord.

Putting Batteries in the Remote Control

Before using the remote control, put two supplied batteries first. When using the remote control, aim the remote control directly at the remote sensor on the receiver.

When the component has a digital coaxial output terminal, connect it to the DIGITAL 1 (DVD) terminal, using the digital coaxial cable (not supplied).

DIGITAL 1

When the component has a digital

(DVD)

optical output terminal, connect it to the DIGITAL 2 (CD) terminal, using the digital optical cable (not supplied).

DIGITAL 2 ( CD )

Before connecting a digital optical cable, unplug the

DIGITAL IN

protective plug.

Notes:

• When shipped from the factory, the DIGITAL IN terminals have been set for use with the following components. – DIGITAL 1 (coaxial): For DVD player – DIGITAL 2 (optical): For CD player

• When you want to operate the CD player or CD recorder using the COMPU LINK remote control system, connect the target component also as described in “Analog connections” (see page 5).

1. On the back of the remote control, remove the battery cover.

2. Insert batteries. Make sure to match the polarity: (+) to (+) and (–) to (–).

3. Replace the cover.

If the range or effectiveness of the remote control decreases, replace the batteries. Use two R6P(SUM-3)/AA(15F) type dry-cell batteries.

CAUTION:

Follow these precautions to avoid leaking or cracking cells:

• Place batteries in the remote control so they match the polarity: (+)

to (+) and (–) to (–).

• Use the correct type of batteries. Batteries that look similar may

differ in voltage.

• Always replace both batteries at the same time.

• Do not expose batteries to heat or flame.

Basic Operations

The following operations are commonly used when you play any sound source.

Turning the Power On and Off (Standby)

On the front panel:

To turn on the power, press POWER. The STANDBY lamp goes off. The name of the current source (or station frequency) appears on the display.

Current source name appears

SPK

ANALOG

Current volume level is shown here

To turn off the power (into standby mode),

press POWER again. The STANDBY lamp lights up. A small amount of power is consumed in standby mode. To turn the power off completely, unplug the AC power cord.

From the remote control:

To turn on the power, press AUDIO in the POWER section. The STANDBY lamp goes off. The name of the current source (or station frequency) appears on the display.

STANDBY

POWER

VOLUME

STANDBY

POWER

AUDIO

Selected source name appears

DIGITAL AUT O

ANALOG

LINEAR PCM

DIGITAL

SPK

PRO LOGIC DSP H.PHONE AUTO MUTING TUNED STEREO

S.WFR

LFE

LS RS

CH-

INPUT ATT SLEEP

VOLUME

DVD Select the DVD player. TV SOUND Select the TV sound. VCR Select the video component connected to the

VCR jacks.

CD * Select the CD player. TAPE/CDR * Select the cassette deck (or the CD recorder). FM/AM * Select an FM or AM broadcast.

• Each time you press the button, the band alternates between FM and AM.

Notes:

• When connecting a CD recorder (to the TAPE/CDR jacks), change the source name that appears on the display. See page 11 for details.

• When you have connected some digital source components using the digital terminals (see page 7), you need to select the digital input mode.

• When you press one of the source selecting buttons on the remote control marked above with an asterisk (*), the receiver automatically turns on.

To turn off the power (into standby mode),

press AUDIO in the POWER section again. The STANDBY lamp lights up.

Selecting the Source to Play

Press one of the source selecting buttons.

On the front panel:

DVD VCR TV SOUND

CD TAPE/CDR

SOURCE NAME

From the remote control:

DVD

TV SOUND

VCR

TAPE/CDR

FM/AM

Signal and speaker indicators on the display

The signal indicators light up in the following cases:

• Only the indicators for the incoming signals light up.

• When analog input is selected, “L” and “R” always light up.

The speaker indicators light up only —:

• When the corresponding speaker is activated.

AND

• When the corresponding speaker is required for the DSP mode

selected currently.

Signal indicators light up in red:

RCL

S.WFR

LS RSS

LFE

Speaker indicators light up in white:

RCL

S.WFR

LS RSS

LFE

L:•When digital input is selected: Lights up when the left

channel signal comes in.

• When analog input is selected: Al ways lights up.

R:•When digital input is selected: Lights up when the right

channel signal comes in.

• When analog input is selected: Al ways lights up.

C: Lights up when the center channel signal comes in. LS: Lights up when the left rear channel signal comes in. RS: Lights up when the right rear channel signal comes in. S: Lights up when the monaural rear channel signal comes in. LFE: Lights up when the LFE channel signal comes in.

Note:

When “SUBWOOFER” is set to “YES” (see page 11),

S.WFR

lights up.

Selecting different sources for picture and sound

MUTING

You can watch picture from a video component while listening to sound from another component. Press one of the audio source selecting buttons (CD, TAPE/CDR, FM/AM), while viewing the picture from a video component such as the VCR or DVD player, etc.

On the front panel:

CD TAPE/CDR

SOURCE NAME

FM/AM

From the remote control:

TAPE/CDR

FM/AM

Adjusting the Volume

On the front panel:

To increase the volume, turn MASTER VOLUME clockwise. To decrease the volume, turn it counterclockwise.

• When you turn MASTER VOLUME rapidly, the volume level also changes rapidly.

• When you turn MASTER VOLUME slowly, the volume level also changes slowly.

From the remote control:

To increase the volume, press VOLUME +. To decrease the volume, press VOLUME –.

CAUTION:

Always set the volume to the minimum before starting any source. If the volume is set at its high level, the sudden blast of sound energy can permanently damage your hearing and/or ruin your speakers.

MASTER VOLUME

VOLUME

–

Listening Only with Headphones

You must turn off speakers when you listen with headphones.

1. Connect a pair of headphones to the PHONES jack on the front panel.

2. Press SPEAKERS ON/OFF so that the SPK indicator disappears from the display. This cancels the DSP mode currently selected, and activates the HEADPHONE mode (see below).

• “HEADPHONE” appears and H. PHONE indicator lights

up on the display.

HEADPHONE mode:

This mode can reproduce the LFE channel signals, mixing them with the front channel signals. So you will not miss the subwoofer sounds even if you listen to a source using the headphones.

Notes:

• While in the HEADPHONE mode, you cannot use any DSP modes

(see page 18.)

• Activating the speaker cancels the HEADPHONE mode and turns

on the DSP mode previously selected.

CAUTION:

Be sure to turn down the volume before connecting or putting on headphones, as high volume can damage both the headphones and your hearing.

Muting the Sound

From the remote control ONLY:

Press MUTING to mute the sound through all speakers and headphones connected.

“MUTING” appears on the display and the volume turns off (the volume level indicator goes off).

To restore the sound, press MUTING again so that “OFF” appears on the display.

• Turning MASTER VOLUME on the front panel or pressing

VOLUME +/– on the remote control also restores the sound.

Note:

The volume level can be adjusted within the range of “0” (minimum) to “80” (maxim um).

Adjusting the Subwoofer Output Level

CONTROL

DOWN UP

ADJUST SETTIN

You can adjust the subwoofer output level if you have selected “YES” for the “SUBWOOFER” (see page 11). Once it has been adjusted, the receiver memorizes the adjustment.

ANALOG

SPK

H.PHONE

INPUT ATT

Before you start, remember...

• There is a time limit in doing the following steps. If the setting is canceled before you finish, start from step 1 again.

• When the front speakers are deactivated, the subwoofer level cannot be adjusted.

On the front panel:

1. Press ADJUST repeatedly until

ADJUST SETTIN

“SUBWFR LEVEL” appears on the display.

The display changes to show the current setting.

SPK

L S.WFR

CONTROL

DOWN UP

ANALOG

2. Press CONTROL UP 5/DOWN ∞

to adjust the subwoofer output level (+10 dB to –10 dB).

SPK

L S.WFR

SOUND

ANALOG

From the remote control:

1. Press SOUND.

The 10 keys are activated for sound adjustments.

SPK

ANALOG

H.PHONE

Notes:

• This function is available only for the sources connected using the analog terminals.

• This function does not take effect when digital input is selected.

Adjusting the Tone

You can adjust the treble and bass sounds as you like. Once it has been adjusted, the receiver memorizes the adjustment.

Before you start, remember...

• There is a time limit in doing the following steps. If the setting is

canceled before you finish, start from step 1 again.

On the front panel ONLY:

1. Press ADJUST repeatedly until

“BASS” or “TREBLE” appears on the display.

• Select “BASS” to adjust the bass sound level.

• Select “TREBLE” to adjust the treble sound level.

SPK

ANALOG

2. Press SUBWOOFER +/– to adjust

– SUBWOOFER +

the subwoofer output level (+10 dB to –10 dB).

Attenuating the Input Signal

When the input level of the playing source is too high, the sounds will be distorted. If this happens, you need to attenuate the input signal level to prevent the sound distortion. Once it has been adjusted, the receiver memorizes the adjustment.

On the front panel ONLY:

Press and hold INPUT ATT so that the INPUT ATT indicator lights up

INPUT ANALOG

INPUT ATT

on the display.

• Each time you press and hold the button, the Input Attenuator mode turns on (“INPUT ATT ON”) or off (“INPUT NORMAL”).

SPK

ANALOG

2. Press CONTROL UP 5/DOWN ∞ to adjust the bass or treble sound level (+10 dB to –10 dB).

• Each time you press the button, the sound

level changes by ± 2 steps.

Basic Settings

CONTROL

DOWN UP

TAPE/CDR

SOURCE NAME

Some of the following settings are required after connecting and positioning your speakers in your listening room, while others will make operations easier.

Recording a Source

You can record any source playing through the receiver to a cassette deck (or a CD recorder) connected to the TAPE/CDR jacks and the VCR connected to the VCR jacks at the same time.

While recording, you can listen to the selected sound source at whatever sound level you like without affecting the sound levels of the recording.

Note:

The output volume level, tone adjustment (see page 10), and DSP modes (see page 18) cannot affect the recording.

Adjusting the Front Speaker Output Balance

If the sounds you hear from the front right and left speakers are unequal, you can adjust the speaker output balance. Once it has been adjusted, the receiver memorizes the adjustment.

Before you start, remember...

• There is a time limit in doing the following steps. If the setting is canceled before you finish, start from step 1 again.

Setting the Subwoofer Information

Before you start, remember...

• There is a time limit in doing the following steps. If the setting is canceled before you finish, start from step 1 again.

On the front panel ONLY:

1. Press SETTING repeatedly until

SETTING

“SUBWOOFER” appears on the display.

The display changes to show the current setting.

2. Press CONTROL UP 5/DOWN ∞

to register whether you have connected a subwoofer or not.

• Each time you press the button, the subwoofer setting alternates between “YES” and “NO.”

YES: Select this when a subwoofer is used.

up on the display (see page 8.)

NO: Select this when no subwoofer is used.

S.WFR

lights

On the front panel ONLY:

1. Press ADJUST repeatedly until “L/R BALANCE” appears on the display.

The display changes to show the current setting.

2. Press CONTROL UP 5/DOWN ∞ to adjust the balance.

• Pressing CONTROL UP 5 decreases the

left channel output from CNTR (Center) to –21.

• Pressing CONTROL DOWN ∞ decreases

the right channel output from CNTR (Center) to –21.

ADJUST SETTIN

CONTROL

DOWN UP

Changing the Source Name

When you have connected the CD recorder to the TAPE/CDR jacks on the rear panel, change the source name shown on the display when you select the CD recorder as the source.

On the front panel ONLY:

When changing the source name from “TAPE” to “CDR”:

1. Press TAPE/CDR.

• Make sure “TAPE” appears on the display.

2. Press and hold SOURCE NAME (TAPE/CDR) until “ASSGN. CDR” appears on the display.

To change the source name from “CDR” to “TAPE,”

repeat the same procedure above (in step 1, make sure “CDR”

appears on the display

Note:

Without changing the source name, you can still use the connected components. How ever, there may be some inconvenience. – “TAPE” will appear on the display when you select the CD

recorder. – You cannot use the digital input (see page 14) for the CD recorder. – You cannot use the COMPU LINK remote control system (see page

25) to operate the CD recorder.

Setting the Speakers for the DSP Modes

CONTROL

DOWN UP

CONTROL

DOWN UP

To obtain the best possible surround sound of the DSP (Digital Signal Processor) modes (see page 18), you have to register the information about the speakers arrangement after all connections are completed.

Before you start, remember...

• There is a time limit in doing the following steps. If the setting is canceled before you finish, start from step 1 again.

Front, Center, and Rear Speaker Setting

• When you change your speakers, you need to register the information about the speakers again.

Center Delay Time Setting

Register the delay time of the sound from the center speaker, comparing to that of the sound from the front speakers. If the distance from your listening point to the center speaker is equal to that to the front speakers, select 0 msec. As the distance to the center speaker becomes shorter, the delay time increases .

• 1 msec increase (or decrease) in delay time corresponds to

/16 inches (30 cm) decrease (or increase) in distance.

• When shipped from the factory, delay time is set to 0 msec.

On the front panel ONLY:

1. Press SETTING repeatedly until

T SETTING

“CENTER DELAY” appears on the display.

The display changes to show the current setting.

On the front panel ONLY:

1. Press SETTING repeatedly until

SETTING

“FRONT SPK” (Front Speaker), “CENTER SPK” (Center Speaker), or “REAR SPK” (Rear Speaker) appears on the display.

The display changes to show the current setting.

2. Press CONTROL UP 5/DOWN ∞

CONTROL

DOWN UP

to select the appropriate item about the speaker selected in the above step.

• Each time you press the button, the display changes to show the following:

LARGE

LARGE: Select this when the speaker size is relatively large. SMALL: Select this when the speaker size is relatively small. NO: Select this when you have not connected a speaker.

(Not selectable for the front speakers)

SMALL NO

3. Repeat steps 1 and 2 to select the appropriate items for the other speakers.

Notes:

• Keep the following comment in mind as reference when adjusting.

– If the size of the cone speaker unit built in your speaker is greater

than 4 3/4 inches (12 cm ), select “LARGE,” and if it is smaller than 4 3/4 inches (12 cm ), select “SMALL.”

• If you have selected “NO” for the subwoofer setting, you can only

select “LARGE” for the front speaker setting.

• If you have selected “SMALL” for the front speaker setting, you

cannot select “LARGE” for the center and rear speaker settings.

2. Press CONTROL UP 5/DOWN ∞ to select the delay time of the center speaker output.

• Pressing CONTROL UP 5 increases the

delay time from 0 msec (“C_DELAY 0MS”) to 5 msec (“C_DELAY 5MS”).

• Pressing CONTROL DOWN ∞ decreases the

delay time from 5 msec (“C_DELAY 5MS”) to 0 msec (“C_DELAY 0MS”).

Note:

You cannot adjust the center delay time when you have set “CENTER SPK” to “NO.”

Rear Delay Time Setting

Register the delay time of the sound from the rear speakers, comparing to that of the sound from the front speakers. If the distance from your listening point to the rear speakers is equal to that to the front speakers, select 0 msec. As the distance to the rear speakers becomes shorter, the delay time increases.

• 1 msec increase (or decrease) in delay time corresponds to

/16 inches (30 cm) decrease (or increase) in distance.

• Rear delay time for Dolby Digital and DTS Digital Surround is to

be set to 5 msec.

• When shipped from the factory, delay time is set to 5 msec.

On the front panel ONLY:

1. Press SETTING repeatedly until “REAR DELAY” appears on the display.

The display changes to show the current setting.

2. Press CONTROL UP 5/DOWN ∞ to select the delay time of the rear speaker output.

• Pressing CONTROL UP 5 increases the

delay time from 0 msec (“R_DELAY 0MS”) to 15 msec (“R_DELAY 15MS”).

• Pressing CONTROL DOWN ∞ decreases the

delay time from 15 msec (“R_DELAY 15MS”) to 0 msec (“R_DELAY 0MS”).

Note:

You cannot adjust the rear delay time when you have set “REAR SPK” to “NO.”

Crossover Frequency Setting

CONTROL

DOWN UP

CONTROL

DOWN UP

Small speakers cannot reproduce the bass sound very well. So, if you have used a small speaker for any of the front, center, and rear channels, this receiver automatically reallocates the bass elements, originally assigned to the channel for which you have connected the small speaker, to another channel (for which you have connected the large speaker). If you have selected “LARGE” for all speakers (see page 12), this function will not take effect. To use this function properly, you need to set this crossover frequency level according to the size of the small speaker connected.

Low Frequency Effect Attenuator Setting

If the bass sound is distorted while playing back a source using Dolby Digital or DTS Digital Surround, follow the procedure below.

On the front panel ONLY:

1. Press SETTING repeatedly until

T SETTING

“LFE ATT” (Low Frequency Effect Attenuator) appears on the display.

The display changes to show the current setting.

On the front panel ONLY:

1. Press SETTING repeatedly until

SETTING

“CROSSOVER FRQ” (Crossover Frequency) appears on the display.

The display changes to show the current setting.

2. Press CONTROL UP 5/DOWN ∞

CONTROL

DOWN UP

to select the crossover frequency level according to the size of the small speaker connected.

• Each time you press the button, the display changes to show the following:

80HZ

• Use the following comments as reference when adjusting.

80HZ: Select this when the cone speaker unit built in the

speaker is about 4

100HZ: Select this when the cone speaker unit built in the

speaker is about 3

120HZ: Select this when the cone speaker unit built in the

speaker is about 3 3/16 inches (8 cm).

Note:

Crossover frequency is not valid for the HEADPHONE mode.

100HZ 120HZ

/4 inches (12 cm).

/16 inches (10 cm).

2. Press CONTROL UP 5/DOWN ∞ to select the low frequency effect attenuator level.

• Each time you press the button, the display

changes to show the following:

0dB 10dB

0dB: Normally select this. 10dB: Select this when the bass sound is distorted.

Note:

This function takes effect only when the subwoofer (LFE) signals come in, (with “SUBWOOFER” set to “YES.”)

Dynamic Range Compression Setting

You can compress the dynamic range (difference between maximum sound and minimum sound) of the reproduced sound. This is useful when enjoying surround sound at night.

• This function takes effect only when playing back a source using

Dolby Digital.

On the front panel ONLY:

1. Press SETTING repeatedly until

SETTING

“D_RANGE COMP” (Dynamic Range Compression) appears on the display.

The display changes to show the current setting.

2. Press CONTROL UP 5/DOWN ∞ to select the appropriate item about the compression level.

• Each time you press the button, the

display changes to show the following:

OFF MID MAX

OFF: Select this when you want to enjoy surround with its

full dynamic range. (No effect applied.)

MID: Select this when you want to reduce the dynamic

range a little. (Factory setting.)

MAX: Select this when you want to apply the compression

effect fully. (Useful at night.)

Note:

Dynamic Range Compression is not valid for the DTS Digital Surround.

Digital Input (DIGITAL IN) Terminal

DIGIT AL A UT O

LINEAR PCM

INPUT DIGITAL

Setting

When you use the digital input terminals, you have to register what components are connected to which terminals (DIGITAL IN 1/2).

Before you start, remember...

• There is a time limit in doing the following steps. If the setting is canceled before you finish, start from step 1 again.

On the front panel ONLY:

1. Press SETTING repeatedly until

SETTING

“DIGITAL IN” appears on the display.

The display changes to show the current setting.

Selecting the Analog or Digital Input Mode

When you have connected digital source components using both the analog connection (see page 5) and the digital connection methods (see page 7), you need to select the input mode correctly.

On the front panel :

1. Press one of the

DVD VTR TV SOUND

source selecting buttons (DVD, TV SOUND, CD, or

CD TAPE/CDR

SOURCE NAME

FM/AM

TAPE/CDR)* for which you want to change the input mode.

DIGITAL 2 terminal setting

DIGITAL 1 terminal setting

2. Press CONTROL UP 5/DOWN ∞

CONTROL

DOWN UP

to select the appropriate digital terminal setting.

• Each time you press the button, the display changes to show the following:

1 DVD 2 CD “ 1 DVD 2 TV “ 1 DVD 2 CDR“ 1 CD 2 DVD “ 1 CD 2 TV “ 1 CD 2 CDR “ 1 TV 2 DVD “ 1 TV 2 CD “ 1 TV 2 CDR “ 1 CDR 2 DVD “ 1 CDR 2 CD “ 1 CDR 2 TV “ (back to the beginning)

Note:

When shipped from the factory, the DIGITAL IN terminals can be used as the digital input for the following components.

• DIGITAL 1 (coaxial): For DVD player

• DIGITAL 2 (optical): For CD player

Note:

Among the sources listed above, you can select the digital input only for the sources which you have selected the digital input terminals for. (See “Digital Input (DIGITAL IN) Terminal Setting.”)

2. Press INPUT DIGITAL to select the digital input mode (AUTO).

The DIGITAL AUTO indicator lights up on the display, and the digital signal indicator for the detected signals also light up.

• When “AUTO” is selected, the receiver automatically detects

the incoming signal format.

SPK

DIGITAL AUTO

“AUTO” appears for about 4 seconds.

* The followings are the analog/digital signal indicators on the

display to indicate what type of the signal comes into the receiver.

: Lights up when “AUTO” is selected as

the digital input mode.

ANALOG

: Lights up when the analog input is

selected.

: Lights up when Linear PCM signals

come in.

DIGIT AL

: Lights up when Dolby Digital signals

come in.

: Lights up when DTS Digital Surround

signals come in.

Continued to the next page.

When playing a software encoded with the DTS Digital

2010 30 40 50 60 70 80 90

(Canceled)

Surround, “AUTO” may not work properly and the following symptoms may occur:

• Sound does not come out at the beginning of playback.

• Noise comes out while using the searching or skipping function.

In this case, press CONTROL UP 5/ DOWN ∞ to select “DTS” while “AUTO”

CONTROL

DOWN UP

is lit on the display.

• Each time you press the button, the input mode changes as follows:

AUTO

(Digital)

DTS

(Digital)

The DIGITAL AUTO indicator does not light up on the display while “DTS” is selected.

To change the input mode back to “AUTO,” press CONTROL UP 5/DOWN ∞ while “DTS” is lit on the display after pressing INPUT DIGITAL. If

flashes while “DTS” is selected as the input mode, select

“AUTO.”

Note:

When you turn off the power or select another source, “DTS” setting is canceled and the digital input mode is automatically reset to “AUTO.”

Storing the Basic Settings and Adjustments

You can assign and store different sound settings for each different playing source. By using this function, you do not have to change the settings every time you change the source. The stored settings for the newly selected source are automatically recalled.

The following can be stored for each source:

• Subwoofer output level (see page 10)

• Input attenuator mode (see page 10)

• Tone adjustment (see page 10)

• Balance (see page 11)

• DSP modes – Surround mode (see page 21) – DAP mode (see page 23)

The above settings are stored automatically in the following cases:

• When you turn on the power.

• When you change the source.

• When you assign the source name.

Notes:

• You cannot assign and store different settings for digital input mode

and analog input mode.

• If the source is FM or AM, you can assign a different setting for

each band.

To change the input mode back to analog input, press INPUT ANALOG.

“ANALOG” appears on the display for a while.

From the remote control:

1. Press the source selecting button (DVD, TV SOUND, CD, or

INPUT ANALOG

INPUT ATT

DVD

TV SOUND

TAPE/CDR

TAPE/CDR)* for which you want to change the input mode.

Note:

Among the sources listed above, you can select the digital input only for the sources which you have selected the digital input terminals for. (See “Digital Input (DIGITAL IN) Terminal Setting.”)

2. Press ANALOG/DIGIT AL to

ANALOG/DIGITAL

change the input mode.

• Each time you press the button, the input

mode changes as follows:

ANALOG

When playing a software encoded with the DTS Digital Surround, “AUTO” may not work properly. In this case, press

CONTROL UP 5/DOWN ∞ on the front panel to select “DTS.” (See above.)

AUTO

(Digital)

Using the Sleep Timer

Using the Sleep Timer, you can fall asleep to music and know the receiver will turn off by itself rather than play all night.

From the remote control ONLY:

Press SLEEP repeatedly.

The SLEEP indicator lights up on the display, and the shut-off time changes as follows (in minutes):

When the shut-off time comes

The receiver turns off automatically.

To check or change the time remaining until the shut-off time

Press SLEEP once. The remaining time until the shut-off time appears in minutes.

• To change the shut-off time, press SLEEP repeatedly.

To cancel the Sleep Timer

Press SLEEP repeatedly until “SLEEP 00 MIN.” appears on the display. (The SLEEP indicator goes off.)

• Turning off the power also cancels the Sleep Timer.

SLEEP

Note:

You can only select “ANALOG” and “AUTO” using the remote control.

Receiving Radio Broadcasts

MEMORY

FM/AM PRESET

MEMORY

You can browse through all the stations or use the preset function to go immediately to a particular station.

Tuning in Stations Manually

On the front panel ONLY:

1. Press FM/AM to select the band

FM/AM

(FM or AM).

• Each time you press the button, the band

alternates between FM and AM.

SPK

ANALOG

2. Press FM/AM TUNING 5/ ∞

TUNED

VOLUME

FM/AM TUNING

until you find the frequency you want.

• Pressing FM/AM TUNING 5 increases

the frequency.

• Pressing FM/AM TUNING ∞ decreases

the frequency.

Notes:

• When you hold FM/AM TUNING 5/ ∞ in step 2, the frequency

keeps changing until a station is tuned in.

• When a station of sufficient signal strength is tuned in, the TUNED

indicator lights up on the display.

• When an FM stereo program is received, the STEREO indicator

also lights up.

Using Preset Tuning

2. Press MEMORY.

SPK

ANALOG

CH-

TUNED

VOLUME

“CH-” appears and the channel number position starts flashing on the display for about 5 seconds.

3. Press FM/AM PRESET 5/ ∞ to select a channel number while the channel number position is flashing.

SPK

ANALOG

CH-

TUNED

VOLUME

Note:

You can use the 10 ke ys on the remote control to select the preset number. When using the 10 keys, be sure that they are activated for the tuner, not for the CD and others. (See page 26.)

4. Press MEMORY again while the selected channel number is flashing on the display.

The selected channel number stops flashing. The station is assigned to the selected channel number.

Once a station is assigned to a channel number, the station can be quickly tuned. You can preset up to 30 FM and 15 AM stations.

To store the preset stations

Before you start, remember...

• There is a time limit in doing the following steps. If the setting is canceled before you finish, start from step 1 again.

On the front panel ONLY:

1. Tune in the station you want to preset (see

“Tuning in Stations Manually”).

If you want to store the FM reception mode for this station, select the FM reception mode you want. See “Selecting the FM Reception Mode” on page 17.

SPK

ANALOG

TUNED

VOLUME

SPK

ANALOG

CH-

TUNED

VOLUME

5. Repeat steps 1 to 4 until you store all the stations you want.

To erase a stored preset station

Storing a new station on a used number erases the previously stored one.

FM MODE

To tune in a preset station

On the front panel:

1. Press FM/AM to select the band (FM or AM).

• The last received station of the selected

band is tuned in.

FM/AM

Selecting the FM Reception Mode

When an FM stereo broadcast is hard to receive or noisy

You can change the FM reception mode while receiving an FM broadcast.

• You can store the FM reception mode for each preset station.

SPK

ANALOG

TUNED

2. Press FM/AM PRESET 5/ ∞ until you find the channel you want.

• Pressing FM/AM PRESET 5 increases the

channel numbers.

• Pressing FM/AM PRESET ∞ decreases the

channel numbers.

From the remote control:

1. Press FM/AM.

• Each time you press the button, the band

alternates between FM and AM.

SPK

ANALOG

TUNED

2. Press 10 keys to select a preset channel number.

• For channel number 5, press 5.

• For channel number 15, press +10 then 5.

• For channel number 20, press +10 then 10.

• For channel number 30, press +10, +10,

then 10.

VOLUME

FM/AM PRESET

FM/AM

VOLUME

– SUBWOOFER +TEST

EFFECT

7/P

– CENTER +

– REAR•L + – VCR CH +

– REAR•R +

On the front panel ONLY:

Press FM MODE.

• Each time you press the button, the FM reception mode alternates between “AUTO” and “MONO.”

SPK

AUTO MUTING TUNED STEREO

you will hear stereo sound; when in monaural, you will hear monaural sounds. This mode is also useful to suppress static noise between stations. The AUTO MUTING indicator lights up on the display.

will lose the stereo effect. In this mode, you will hear noise while tuning into the stations. The AUTO MUTING indicator goes off from the display.

+10

ENTER

ANALOG

AUTO: When a program is broadcasted in stereo,

MONO: Reception will be improved although you

TUNED

Note:

When you use the 10 keys on the remote control, be sure that they are activated for the tuner, not for the CD and others. (See page 26.)

Using the DSP Modes

DOLBY SURROUND

The built-in Surround Processor provides two types of the DSP (Digital Signal Processor) mode — Surround mode and DAP (Digital Acoustic Processor) mode.

What are the DSP Modes?

Surround modes

With this receiver, you can use three types of the Surround mode.

Following modes cannot be used when only the front speakers are connected to this receiver (without the rear speakers or center speaker).

Dolby Surround (Dolby Digital and Dolby Pro Logic)

Used to watch the soundtracks of software encoded with Dolby Digital (bearing the mark (bearing the mark

DOLBY SURROUND

DIGITAL

) or with Dolby Surround

). Dolby Surround encoding format records the left front channel, right front channel, center channel, and rear channel (total 4 channels) signals into 2 channels. The Dolby Pro Logic decoder built in this receiver decodes these 2 channel signals into original 4 channel signals — matrix-based multichannel reproduction, and allows you to enjoy the realistic stereo sounds in your listening room. On the other hand, Dolby Digital encoding method (so called discrete 5.1 channel digital audio format) records and compresses the left front channel, right front channel, center channel, left rear channel, right rear channel, and LFE channel (total 6 channels, but LFE channel is counted as 0.1 channel, therefore called 5.1 channels) signals digitally. Each channel is completely independent from other channel signals to avoid interference, therefore, you can obtain much better sound quality with much stereo and surround effects. The Dolby Digital decoder built in this receiver can create much more realistic sound field in your listening room. You may feel as if you were in a real theater. In addition, Dolby Digital enables stereo rear sounds, and sets the cutoff frequency of the rear treble at 20 kHz, compared to 7 kHz for Dolby Pro Logic. These facts enhance the sound movement and being-there feelings much more than Dolby Pro Logic.

• To enjoy the software encoded with Dolby Digital, you must

connect the source component using the digital terminal on the rear of this receiver. (See page 7.)

DTS Digital Surround

DTS Digital Surround is another discrete 5.1 channel digital audio format available on CD, LD, and DVD software. Compared to Dolby Digital, audio compression rate is relatively low. This fact allows DTS Digital Surround format to add breadth and depth to the reproduced sounds. As a result, DTS Digital Surround features natural, solid and clear sound.

• To enjoy the software encoded with DTS Digital Surround, you must connect the source component using the digital terminal on the rear of this receiver. (See page 7.)

JVC Theater Surround

In order to reproduce a more realistic sound field in your listening room while playing soundtracks of software encoded with Dolby Surround (bearing the mark

), you can use JVC

Theater Surround.

Notes:

• The DSP modes have no effect on monaural sources.

• The

PRO LOGIC

decoder built in this receiver is activated.

indicator lights up when the Dolby Pro Logic

Manufactured under license from Dolb y Laboratories. “Dolby,” “Pro Logic,” and the double-D symbol are trademarks of Dolby Laboratories. Confidential Unpublished Works. ©1992–1997 Dolby Laboratories, Inc. All rights reser ved.

Manufactured under license from Digital Theater Systems, Inc. US Pat. No. 5,451,942 and other world-wide patents issues and pending. “DTS” and “DTS Digital Surround” are trademarks of Digital Theater Systems, Inc. ©1996 Digital Theater Systems, Inc. All rights reserved.

DAP modes

The sound heard in a concert hall or club consists of direct sound and indirect sound — early reflections and reflections from behind. Direct sounds reach the listener directly without any reflection. On the other hand, indirect sounds are delayed by the distances of the ceiling and walls. These direct sounds and indirect sounds are the most important elements of the acoustic surround effects. The DAP mode can create these important elements, and gives you a real “being there” feeling. This mode can be used when the front

speakers are connected to this receiver (without respect to the rear/center speaker connection).

You can select one of the following to your preference.

LIVE CLUB: Gives the feeling of a live music club with a low

ceiling.

DANCE CLUB:Gives a throbbing bass beat. HALL: Gives clear vocal and the feeling of a concert hall. PA VILION: Gives the spacious feeling of a pavilion with a high

ceiling.

Reproducing the Sound Field

The sound heard in a concert hall or club consists of direct sound and indirect sound — early reflections and reflections from behind. Direct sounds reach the listener directly without any reflection. On the other hand, indirect sounds are delayed by the distances of the ceiling and walls. These direct sounds and indirect sounds are the most important elements of the acoustic surround effects. JVC Theater Surround and DAP modes can create these important elements, and give you a real “being there” feeling.

Reflections from

Early reflections

Direct sounds

behind

Available DSP modes according to the input mode

䡬: Possible ⳯: Impossible

* You can also use SURROUND on the remote control to activate the surround mode.

BUTTON

(On the remote control)

BUTTON

(On the front panel)

MODE SURROUND ON THEATER LIVE CLUB DANCE CLUB HALL PAVILION

ANALOG 䡬

(2 CH) (DOLBY PRO LOGIC)

ANALOG ⳯

(5.1 CH) (DOLBY PRO LOGIC)

LINEAR PCM

INPUT

DOLBY DIGITAL

DTS

*1When 2 channel signal comes in, DOLBY PRO LOGIC is selected. When other signals come in, DOLBY DIGITAL is selected. *2When 2 channel signal comes in, DOLBY PRO LOGIC is selected. When other signals come in, DTS SURROUND is selected.

SURROUND ON/OFF* DSP MODE

䡬䡬䡬䡬䡬䡬

⳯⳯ ⳯⳯⳯ ⳯

䡬

(DOLBY PRO LOGIC)

䡬 *

(DOLBY DIGITAL)

䡬 *

(DTS SURROUND)

䡬䡬䡬䡬䡬䡬

⳯⳯ ⳯⳯⳯ 䡬

SURROUND MODE

(SURROUND OFF)

DSP OFF

Available DSP Modes According to the Speaker Arrangement

Available DSP modes will vary depending on how many speakers are used with this receiver.

Make sure that you have set the speaker information correctly (see page 12).

Front

speaker

Rear

speaker

Front

speaker

Rear

speaker

Speaker arrangements

Center speaker

Front

speaker

Rear

speaker

Front

speaker

Rear

speaker

Available DSP modes

Each time you press DSP MODE on the front panel or SURROUND MODE on the remote control, the DSP modes change as follows:

By pressing DSP MODE:

• THEATER

• LIVE CLUB

• DANCE CLUB

• HALL

• PAVILION

• DSP OFF (DSP mode is canceled)

To activate the Surround mode, press SURROUND ON/

OFF on the front panel.

By pressing SURROUND MODE:

• SURROUND ON (DOLBY PRO LOGIC, DOLBY DIGITAL, or DTS SURROUND)

• THEATER

• LIVE CLUB

• DANCE CLUB

• HALL

• PAVILION

• DSP OFF (DSP mode is canceled)

To activate the Surround mode, you can also press

SURROUND on the remote control.

Front

speaker

Center speaker

Front

speaker

Each time you press DSP MODE on the front panel or SURROUND MODE on

Each time you press DSP MODE on the front panel or SURROUND MODE on the remote control, the DSP modes change as follows:

the remote control, the DSP modes change as follows:

By pressing DSP MODE:

• THEATER

• DSP OFF (DSP mode is canceled)

To activate the Surround mode, press SURROUND ON/

OFF on the front panel.

By pressing SURROUND MODE:

• SURROUND ON

(DOLBY PRO LOGIC, DOLBY DIGITAL, or DTS SURROUND)

• DSP OFF (DSP mode is canceled)

To activate the Surround mode, you can also press

SURROUND on the remote control.

TEST

Adjusting the Surround Modes

DIGITAL

ADJUST SETTING

CONTROL

DOWN UP

Once you have adjusted the Surround modes, the adjustment is memorized for each Surround mode.

Dolby and DTS Surround adjustments

Before you start, remember...

• Make sure that you have set the speaker information correctly (see page 12).

• There is a time limit in doing the following steps. If the setting is canceled before you finish, start from step 3 again.

• You cannot adjust the rear speaker output levels when you have set “REAR SPK” to “NO.” See page 12.

• You cannot adjust the center speaker output level when you have set “CENTER SPK” to “NO.” See page 12.

From the remote control:

1. Select and play a sound source.

• To enjoy Dolby Pro Logic, play back a software encoded with Dolby Surround and labeled with

DOLBY SURROUND

mark.

• To enjoy Dolby Digital, play back a software encoded with Dolby Digital and labeled with

mark.

• To enjoy DTS Digital Surround, play back a software encoded with DTS Digital Surround and labeled with

2. Press SURROUND to activate an

mark.

SURROUND

appropriate Surround mode — PRO LOGIC, DOLBY DIGITAL

SURROUND

MODE

or DTS SURROUND.

When “PRO LOGIC” is selected, the PRO LOGIC indicator lights up on the display.

• Each time you press the button, the Surround mode turns on and off alternately.

Note:

You can also press SURROUND MODE to activate an appropriate Surround mode — PRO LOGIC, DOLBY DIGITAL, or DTS.

3. Press SOUND.

The 10 keys are activated for sound adjustments.

SOUND

5. Adjust the speaker output levels.

• To adjust the center speaker level, press

– CENTER +

CENTER +/– (from +10 dB to –10 dB).

• To adjust the left rear speaker level, press REAR•L +/– (from +10 dB to –10 dB).

• To adjust the right rear speaker level, press REAR•R +/– (from +10 dB to –10 dB).

– REAR•L +

– REAR•R +

+10

ENTER

6. Press TEST again to stop the test tone.

On the front panel:

You can also use the buttons on the front panel to adjust the Surround modes. However, no test tone is available when using the buttons on the front panel. So, make adjustments while listening to the sound of the source played back.

1. Select and play a sound source.

• To enjoy Dolby Pro Logic, play back a software encoded with

Dolby Surround and labeled with

DOLBY SURROUND

mark.

• To enjoy Dolby Digital, play back a software encoded with

Dolby Digital and labeled with

• To enjoy DTS Digital Surround, play back a software encoded

DIGITAL

with DTS Digital Surround and labeled with

2. Press SURROUND ON/OFF to

mark.

SURROUND ON/OFF

activate an appropriate Surround mode — PRO LOGIC, DOLBY DIGITAL or DTS SURROUND.

When “PRO LOGIC” is selected, the PRO LOGIC indicator lights up on the display.

• Each time you press the button, the Surround mode turns on

and off alternately.

4. Press TEST to check the speaker

TEST

output balance.

“TEST TONE L” starts flashing on the display, and a test tone comes out of the speakers in the following order:

TEST TONE L

(Left front speaker)

TEST TONE LS

(Left rear speaker)

TEST TONE C

(Center speaker)

TEST TONE R

(Right front speaker)

TEST TONE RS

(Right rear speaker)

Notes:

• You can adjust the speaker output levels without outputting the test tone.

• No test tone comes out of the center speaker when “CENTER SPK” is set to “NO” (see page 12).

• No test tone comes out of the rear speakers when “REAR SPK” is set to “NO” (see page 12).

3. Adjust the speaker output levels.

1) Press ADJUST repeatedly until one of the following indications appears on the display.

“CENTER LEVEL”:

To adjust the center speaker level.

“REAR L LEVEL”:

To adjust the left rear speaker level.

“REAR R LEVEL”:

To adjust the right rear speaker level.

2) Press CONTROL UP 5/DOWN ∞ to adjust the selected speaker output level (from +10 dB to –10 dB).

3) Repeat 1) and 2) to adjust the other speaker output levels.

CONTROL

DOWN UP

ADJUST SETTIN

CONTROL

DOWN UP

JVC Theater Surround adjustments

DSP MODE

ADJUST SETTING

Before you start, remember...

• Make sure that you have set the speaker information correctly (see page 12).

• There is a time limit in doing the following steps. If the setting is canceled before you finish, start from step 2 again.

• You cannot adjust the rear speaker output levels when you have set “REAR SPK” to “NO.” See page 12.

• You cannot adjust the center speaker output level when you have set “CENTER SPK” to “NO.” See page 12.

6. Press EFFECT to select an effect level you want.

• Each time you press the button, the effect

level changes as follows:

DSP EFFECT 1 DSP EFFECT 2 DSP EFFECT 3

DSP EFFECT 4DSP EFFECT 5

As the number increases, JVC Theater Surround becomes stronger (normally set it to “DSP EFFECT 3”).

EFFECT

From the remote control:

1. Press SURROUND MODE

SURROUND

repeatedly until “THEATER” appears on the display.

The PRO LOGIC and DSP indicators also light up on the display.

2. Press SOUND.

The 10 keys are activated for sound adjustments.

3. Press TEST to check the speaker

SURROUND

MODE

SOUND

TEST

output balance.

“TEST TONE L” starts flashing on the display, and a test tone comes out of the speakers in the following order:

TEST TONE L

(Left front speaker)

TEST TONE C

(Center speaker)

TEST TONE LS

(Left rear speaker)

Notes:

• You can adjust the speaker output levels without outputting the test tone.

• No test tone comes out of the center speaker when “CENTER SPK” is set to “NO” (see page 12).

• No test tone comes out of the rear speakers when “REAR SPK” is set to “NO” (see page 12).

4. Adjust the speaker output levels.

• To adjust the center speaker level, press

CENTER +/– (from +10 dB to –10 dB).

• To adjust the left rear speaker level, press

REAR•L +/– (from +10 dB to –10 dB).

• To adjust the right rear speaker level, press

REAR•R +/– (from +10 dB to –10 dB).

TEST TONE R

(Right front speaker)

TEST TONE RS

(Right rear speaker)

– CENTER +

– REAR•L +

On the front panel:

1. Press DSP MODE repeatedly until “THEATER” appears on the display.

The PRO LOGIC and DSP indicators also light up on the display.

2. Adjust the speaker output levels.

1) Press ADJUST repeatedly until one of

the following indications appears on the display.

“CENTER LEVEL”:

To adjust the center speaker level.

“REAR L LEVEL”:

To adjust the left rear speaker level.

“REAR R LEVEL”:

To adjust the right rear speaker level.

2) Press CONTROL UP 5/DOWN ∞ to

adjust the selected speaker output level (from +10 dB to –10 dB).

3) Repeat 1) and 2) to adjust the other

speaker output levels.

3. Adjust the effect level.

1) Press ADJUST repeatedly until “DSP

EFFECT” appears on the display.

The display changes to show the current setting.

2) Press CONTROL UP 5/DOWN ∞ to

select the effect level.

• Each time you press the button, the effect level changes as follows:

5. Press TEST again to stop the test tone.

– REAR•R +

TEST

+10

ENTER

DSP EFFECT 1 DSP EFFECT 2 DSP EFFECT 3

DSP EFFECT 4DSP EFFECT 5

As the number increases, JVC Theater Surround becomes stronger (normally set it to “DSP EFFECT 3”).

Adjusting the DAP Modes

Once you have adjusted the DAP modes, the adjustment is memorized for each DAP mode.

Before you start, remember...

• Make sure that you have set the speaker information correctly (see page 12).

• There is a time limit in doing the following steps. If the setting is canceled before you finish, start from step 1 again.

• You cannot adjust the rear speaker output level when you have set “REAR SPK” to “NO.” See page 12.

On the front panel:

1. Press DSP MODE repeatedly until

DSP MODE

the DAP mode — LIVE CLUB, DANCE CLUB, HALL, or PAVILION — appears on the display.

The DSP indicator also lights up on the display.

2. Adjust the rear speaker output levels.

1) Press ADJUST repeatedly until one of the following indications appears on the display.

“REAR L LEVEL”:

To adjust the left rear speaker level.

“REAR R LEVEL”:

To adjust the right rear speaker level.

2) Press CONTROL UP 5/DOWN ∞ to adjust the selected speaker output level (from +10 dB to –10 dB).

3) Repeat 1) and 2) to adjust the other speaker output level.

ADJUST SETTI

CONTROL

DOWN UP

3. Adjust the effect level.

1) Press ADJUST repeatedly until “DSP EFFECT” appears on the display.

The display changes to show the current setting.

2) Press CONTROL UP 5/DOWN ∞ to select the effect level.

• Each time you press the button, the

effect level changes as follows:

ADJUST SETTIN

CONTROL

DOWN UP

From the remote control:

1. Press SURROUND MODE repeatedly until the DAP mode — LIVE CLUB, DANCE CLUB, HALL, or PAVILION — appears on the display.

The DSP indicator also lights up on the display.

2. Press SOUND.

The 10 keys are activated for sound adjustments.

3. Adjust the rear speaker output levels.

• To adjust the left rear speaker level, press

REAR•L +/– (from +10 dB to –10 dB).

• To adjust the right rear speaker level, press

REAR•R +/– (from +10 dB to –10 dB).

4. Press EFFECT to select an effect level you want.

• Each time you press the button, the effect

level changes as follows:

DSP EFFECT 1 DSP EFFECT 2 DSP EFFECT 3

DSP EFFECT 4DSP EFFECT 5

As the number increases, the selected DAP mode becomes stronger (normally set it to “DSP EFFECT 3”).

SURROUND

MODE

SOUND

– REAR•L +

– REAR•R +

EFFECT

+10

ENTER

DSP EFFECT 1 DSP EFFECT 2 DSP EFFECT 3

DSP EFFECT 4DSP EFFECT 5

As the number increases, the selected DAP mode becomes stronger (normally set it to “DSP EFFECT 3”).

DSP MODE

Activating the DSP Modes

DIGITAL

For the other DSP modes

You can use only one DSP mode at a time. When a DSP mode is activated, another DSP mode is canceled if in use.

For Dolby Pro Logic, Dolby Digital, and DTS Digital Surround

On the front panel:

1. Press SURROUND ON/OFF.

SURROUND ON/OFF

• Each time you press the button, the Dolby/ DTS Surround mode turns on and off alternately.

2. Select and play a sound source.

• To enjoy Dolby Pro Logic, play back a software encoded with Dolby Surround and labeled with

• To enjoy Dolby Digital, play back a software encoded with Dolby Digital and labeled with

• To enjoy DTS Digital Surround, play back a software encoded with DTS Digital Surround and labeled with

To cancel the Dolby/DTS Surround mode

Press SURROUND ON/OFF again. (“SURROUND OFF” appears on the display.)

DOLBY SURROUND

mark.

SURROUND ON/OFF

mark.

On the front panel:

1. Press DSP MODE repeatedly until the mode you want appears on the display.

• Each time you press the button, the DSP

modes change. (See page 20 for more details.)

2. Select and play a sound source.

• To enjoy JVC Theater Surround, play back a software encoded

with Dolby Surround and labeled with

DOLBY SURROUND

To cancel the DSP mode

Press DSP MODE repeatedly until “DSP OFF” appears on the display.

From the remote control:

1. Press SURROUND MODE

SURROUND

repeatedly until the DSP mode you want appears on the display.

• Each time you press the button, the DSP

modes change.

SURROUND

MODE

mark.

From the remote control:

1. Press SURROUND.

SURROUND

• Each time you press the button, the Dolby/DTS Surround mode turns on and off alternately.

SURROUND

MODE

• You can also turn on Dolby/DTS Surround mode by pressing SURROUND MODE.

2. Select and play a sound source.

• To enjoy Dolby Pro Logic, play back a software encoded with Dolby Surround and labeled with

• To enjoy Dolby Digital, play back a software encoded with Dolby Digital and labeled with

• To enjoy DTS Digital surround, play back a software encoded with DTS Digital Surround and labeled with

To cancel the Dolby/DTS Surround mode

Press SURROUND again. (“SURROUND OFF” appears on the display.)

DOLBY SURROUND

mark.

SURROUND

MODE

2. Select and play a sound source.

• To enjoy JVC Theater Surround, play back a software encoded with Dolby Surround and labeled with

To cancel the DSP mode

Press SURROUND MODE repeatedly until “DSP OFF” appears on the display.

DOLBY SURROUND

SURROUND

MODE

mark.

COMPU LINK Remote Control System

The COMPU LINK remote control system allows you to operate JVC audio components through the remote sensor on the receiver.

To use this remote control system, you need to connect JVC audio components through the COMPU LINK (SYNCHRO) jacks (see below) in addition to the connections using cables with RCA pin plugs (see page 5).

• Make sure that the AC power cords of these components are unplugged before connection. Plug the AC power cords only after all connections are complete.

Cassette deck

CD recorder

COMPU LINK-4

(SYNCHRO)

CD player

Notes:

• There are four versions of COMPU LINK remote control system.

This receiver is equipped with the fourth version — COMPU LINK-

4. This version is added systematic operations with the CD recorder to the previous version — COMPU LINK-3.

• If your audio component has two COMPU LINK jacks, you can use

either one. If it has only one COMPU LINK jack, connect it so that it is the last item in the series of components. (For example, the CD player in the diagram above.)

• To operate the cassette deck or CD recorder using the COMPU

LINK remote control system, set the source name correctly. (See page 11.)

• Refer also to the manuals supplied with your audio components.

This remote control system allows you to use four functions listed below.

Remote Control through the Remote Sensor on the Receiver

You can control the connected audio components through the remote sensor on the receiver using this remote control. Aim the remote control directly at the remote sensor on the receiver. For details, see pages 26 and 27.

Automatic Power On/Off (Standby): only possible with the COMPU LINK-3 and COMPU LINK-4 connection

Both the CD player and cassette deck (or CD recorder) turn on and off (standby) along with the receiver. When you turn on the receiver, the CD player or cassette deck (or CD recorder) will turn on automatically, depending on which component has been previously selected. When you turn off the receiver, both the CD player and cassette deck (or CD recorder) will turn off (standby).

Synchronized Recording

Synchronized recording means the cassette deck starts recording as soon as a CD or a record begins playing.

To use synchronized recording, follow these steps:

1. Put a tape in the cassette deck and a disc in the CD player.

2. Press the record (¶) button and the pause (8) button on the cassette deck at the same time.

This puts the cassette deck into recording pause. If you do not press the record (¶) button and pause (8) button at the same time, the synchronized recording feature will not operate.

3. Press the play (3) button on the CD player.

The source changes on the receiver, and as soon as play starts, the cassette deck starts recording. When the play ends, the cassette deck enters recording pause, and stops about 4 seconds later.

Notes:

• During synchronized recording, the selected source cannot be

changed.

• If the power of any component is shut off during synchronized

recording, the COMPU LINK remote control system may not operate properly. In this case, you must start again from the beginning.

Automatic Source Selection

When you press the play ( on its own remote control, the receiver automatically turns on and changes the source to the component. On the other hand, if you select a new source on the receiver or on the remote control, the selected component begins playing immediately. In both cases, the previously selected source continues playing without sound for a few seconds.

3) button on a connected component or

Operating JVC’s Audio/Video Components

You can operate JVC’s audio and video components with this receiver’s remote control, since control signals for JVC components are preset in the remote control.

Operating Audio Components

IMPORTANT:

To operate JVC’s audio components using this remote control:

• You need to connect JVC audio components through the COMPU LINK (SYNCHRO) jacks (see page 25) in addition to the connections using cables with RCA pin plugs (see page 5).

• Aim the remote control directly at the remote sensor on the receiver.

• If you use the buttons on the front panel, the remote control will not operate that source. To operate a source with the remote control, the source must be selected using source selecting buttons on the remote control.

• To operate the cassette deck or CD recorder using the COMPU LINK remote control system, set the source name correctly. (See page 11.)

• Refer also to the manuals supplied with your components.

POWER

SLEEP

SURROUND

MODE

SOUND

TV/VIDEO

DVD

EFFECT

7/P

CD-DISC

TV SOUND

VCR

– SUBWOOFER +TEST

– CENTER +

– REAR•L + – VCR CH +

– REAR•R +

VCR

AUDIO

+10

ENTER

ANALOG/DIGITAL

Tuner

After pressing FM/AM, you can perform the following operations:

FM/AM: Alternates between FM and AM. 1 – 10, +10: Selects a preset channel number directly.

For channel number 5, press 5. For channel number 15, press +10, then 5. For channel number 20, press +10, then 10.

Sound control section (Amplifier)

You can always perform the following operations: SURROUND: Turns on or off the Surround modes —

Dolby Pro Logic, Dolby Digital, and DTS Digital Surround.

SURROUND MODE: Selects the DSP modes. After pressing SOUND, you can perform the following operations:

SUBWOOFER + / –: Adjusts the subwoofer output level. CENTER + / –: Adjusts the center speaker output level. REAR•L + / –: Adjusts the left rear speaker output level. REAR•R + / –: Adjusts the right rear speaker output level. EFFECT: Selects the effect level. TEST: Turns on or off the test tone output.

Note:

After adjusting sounds, press the corresponding source selecting button or CD-DISC to operate your target source by using the 10 keys; otherwise, the 10 keys cannot be used for operating your target source.

TAPE/CDR

TV VOL

VOLUME

–

TV CH

–

RM-SRX6010J

REMOTE CONTROL

A/V CONTROL RECEIVER

FM/AM

MUTING

–

CD player

After pressing CD, you can perform the following operations on the CD player:

3: Starts playing.

33 44

4: Returns to the beginning of the current

(or previous) track.

¢¢

¢: Skips to the beginning of the next track.

¢¢ 77

7: Stops playing.

77 88

8: Pauses playing. To release it, press

1 – 10, +10: Selects a track number directly.

For track number 5, press 5. For track number 15, press +10, then 5. For track number 20, press +10, then 10. For track number 30, press +10, +10, then 10.

CD changer

After pressing CD-DISC, you can perform the following operations on a CD changer:

3: Starts playing.

33 44

4: Returns to the beginning of the current (or previous)

track.

¢¢

¢: Skips to the beginning of the next track.

¢¢ 77

7: Stops playing.

77 88

8: Pauses playing. To release it, press

1 – 6, 7/P: Selects the number of a disc installed in a CD

changer.

If your CD changer is of 200-disc loading capability (except for XL-MC100 and XL-MC301),

you can do the following operations using the number buttons after pressing CD.

• The 10 button can function as 0.

1. Select a disc number.

2. Then select a track number (always enter two digits).

3. Start playback.

Ex. Selecting disc number 3, track number 2, and start playback. Press 3, then, 10, 2, then 3.

Selecting disc number 10, track number 5, and start playback. Press 1, 10, then, 10, 5, then 3.

Operating Video Components

IMPORTANT:

To operate JVC’s video components using this remote control:

• Some JVC VCRs can accept two types of the control signals — remote code “A” and “B.” Before using this remote control, make sure that the remote control code of the VCR connected to the VCR jacks is set to code “A.”

• When using the remote control: – For the DVD player, TV and VCR operations, aim the remote

control directly at the remote sensor on each component, not on the receiver.

VCR

You can always perform the following operations: VCR: Turns on or off the VCR.

(in the POWER section) After pressing VCR, you can perform the following operations on

the VCR:

3: Starts playing. 1: Rewinds a tape. ¡: Fast winds a tape. 7: Stops operations. 8: Pauses playing. To release it, press 3.

VCR CH +/–: Changes the TV channels on the VCR.

Selecting disc number 105, track number 12, and start playback. Press 1, 10, 5, then 1, 2 then 3.

Cassette deck

After pressing TAPE/CDR, you can perform the following operations on a cassette deck:

3: Starts playing.

1: Fast winds the tape from right to left.

11 ¡¡

¡: Fast winds the tape from left to right.

¡¡

7: Stops operations. 8: Pauses playing. To release it, press 3.

Note:

Before starting the above operations, make sure that you have changed the source name correctly. See page 11.

CD recorder

After pressing TAPE/CDR, you can perform the following operations on the CD recorder:

3: Starts playing. 4: Returns to the beginning of the current (or previous)

track.

¢: Skips to the beginning of the next track. 7: Stops playing. 8: Pauses playing. To release it, press 3.

DVD player

After pressing DVD, you can perform the following operations on a DVD player:

3: Starts playing. 4: Returns to the beginning of the current (or previous) track. ¢: Skips to the beginning of the next track. 7: Stops playing. 8: Stops playing temporarily. To release it, press 3.

EFFECT

– SUBWOOFER +

– CENTER +

– REAR•R +

– REAR•L +

+10

ENTER

After pressing DVD, these buttons can be used for the DVD menu operations.

Note:

For detailed menu operations, refer to the instructions supplied with the discs or the DVD player.

You can always perform the following operations: TV: Turns on or off the TV.

(in the POWER section)

TV/VIDEO: Sets the input mode (either TV or VIDEO). TV VOL +/–: Adjusts the volume. TV CH +/–: Changes the channels.

Note:

Before starting the above operations, make sure that you have changed the source name correctly. See page 11.

Troubleshooting

Use this chart to help you solve daily operational problems. If there is any problem you cannot solve, contact your JVC service center.

PROBLEM

The display does not light up.

No sound from speakers.

Sound from one speaker only.

Continuous hiss or buzzing during FM reception.

POSSIBLE CAUSE

The power cord is not plugged in.

Speaker signal cables are not connected.

The SPEAKERS ON/OFF button is not set correctly.

An incorrect source is selected.

Muting is activated.

An incorrect input mode (analog or digital) is selected.

Connections are incorrect.

Speaker signal cables are not connected properly.

The balance is set to one extreme.

Incoming signal is too weak.

The station is too far away.

SOLUTION

Plug the power cord into an AC outlet.

Check speaker wiring and reconnect if necessary.

Press SPEAKERS ON/OFF button correctly.

Select the correct source.

Press MUTING to cancel the mute.

Select the correct input mode (analog or digital).

Check connections. For analog connections, see page 5. For digital connections, see page 7.

Check speaker wiring and reconnect if necessary.

Adjust the balance properly (see page 11).

Connect an outdoor FM antenna or contact your dealer.

Select a new station.

Occasional cracking noise during FM reception.

“OVERLOAD” starts flashing on the display.

“DSP MICON NG” starts flashing on the display.

The STANDBY lamp lights up after turning on the power, but soon the receiver turns off (into standby mode).

An incorrect antenna is used.

Antennas are not connected properly.

Ignition noise from automobiles.

Speakers are overloaded because of high volume.

Speakers are overloaded because of short circuit of speaker terminals.

The built-in microcomputer is not functioning correctly.

The receiver is overloaded because of a high voltage.

Check with your dealer to be sure you have the correct antenna.

Check connections.

Move the antenna farther from automobile traffic.

1. Press POWER on the front panel to turn off the receiver.

2. Stop the playback source.

3. Turn on the receiver again, and adjust the volume.

Press POWER on the front panel, then check the speaker wiring. If “OVERLOAD” does not disappear, unplug the AC power cord, then plug it back again. If speaker wiring is not short-circuited, contact your dealer.

Press POWER on the front panel to turn off the receiver. After unplugging the power cord, consult your dealer.

Remote control does not work.

Remote control does not operate intendedly.

There is an obstruction in front of the remote sensor on the receiver.

Batteries are weak.

An incorrect remote control operation mode is selected.

Remove the obstruction.

Replace batteries.

Select the correct remote control operation mode. (See page 26).

Specifications

Amplifier

Output Power

At Stereo operation: Front channels:

100 W per channel, min. RMS, driven into 8 Ω, 40 Hz to 20 kHz with no more than 0.8% total harmonic distortion.

At Surround operation: Front channels: 100 W per channel, min. RMS, driven into 8 Ω at 1 kHz with no

more than 0.8% total harmonic distortion.

Center channel: 100 W, min. RMS, driven into 8 Ω at 1 kHz, with no more than

0.8% total harmonic distortion.

Rear channels: 100 W per channel, min. RMS, driven into 8 Ω at 1 kHz, with no

more than 0.8% total harmonic distortion.

Audio

Audio Input Sensitivity/Impedance (1 kHz): CD, TAPE/CDR, TV SOUND, VCR, DVD:

Audio Input (DIGITAL IN)* : Coaxial: DIGITAL 1 (DVD): 0.5 V (p-p)/75 Ω

Optical: DIGITAL 2 (CD): –21 dBm to –15 dBm (660 nm ±30 nm) * Corresponding to Linear PCM, Dolby Digital, and DTS Digital Surround

(with sampling frequency — 32 kHz, 44.1 kHz, 48 kHz).

Audio Output Level: TAPE/CDR, VCR: 220 mV

Signal-to-Noise Ratio (’66 IHF/’78 IHF): CD, TAPE/CDR, TV SOUND, VCR, DVD: 87 dB/67 dB

220 mV/47 k Ω

Video

Frequency Response (8 Ω): CD, TAPE/CDR, TV SOUND, VCR, DVD: 20 Hz to 20 kHz (±1 dB)

Tone Control: Bass (100 Hz): ±10 dB

Treble (10 kHz): ±10 dB

Video Input Sensitivity/Impedance:

Composite video: VCR, DVD: 1 V (p-p)/75 Ω

Video Output Level:

Composite video: VCR, MONITOR OUT: 1 V (p-p)/75 Ω

Synchronization: Negative

Signal-to-Noise Ratio: 45 dB

FM tuner (IHF)

Tuning Range: 87.5 MHz to 108.0 MHz

Usable Sensitivity: Monaural: 12.8 dBf (1.2 µV/75 Ω)

50 dB Quieting Sensitivity: Monaural: 21.3 dBf (3.2 µV/75 Ω)

Stereo: 41.3 dBf (31.5 µV/75 Ω)

Signal-to-Noise Ratio (IHF-A weighted): Monaural: 78 dB at 85 dBf

Stereo: 73 dB at 85 dBf

Total Harmonic Distortion: Monaural: 0.4% at 1 kHz

Stereo: 0.6% at 1 kHz

Stereo Separation at REC OUT: 35 dB at 1 kHz

Alternate Channel Selectivity: 45 dB: (±400 kHz)

Frequency Response: 30 Hz to 15 kHz: (+0.5 dB, –3 dB)

AM tuner

Tuning Range: 530 kHz to 1 710 kHz

Usable Sensitivity: Loop antenna 400 µV/m

Signal-to-Noise Ratio: 50 dB (100 mV/m)

General

Power Requirements: AC 120V , 60 Hz

Power Consumption: 180 W/230 VA (at operation)

2 W (in standby mode)

Dimensions (W x H x D): 435 mm x 146.5 mm x 416 mm

Mass: 8.6 kg (19.0 lbs)

(17

/16 in. x 5 13/16 in. x 16 7/16 in.)

Designs & specifications are subject to change without notice.

QUALITY SERVICE

HOW TO LOCATE YOUR JVC SERVICE CENTER

TOLL FREE : 1-800-537-5722

http://www.jvcservice.com

Dear customer: In order to receive the most satisfaction from your purchase, read the instruction booklet before operating the unit. In the event that repair

is necessary, or for the address nearest your location, please refer to the factory service center list below or within the Continental United States, Call 1-800-537-5722 for your authorized servicer. Remember to retain your Bill of Sale for Warranty Service.

—JVC

JVC SERVICE & ENGINEERING

COMPANY OF AMERICA

DIVISION OF JVC AMERICAS CORP.

FACTORY SERVICE CENTER LOCATIONS

10 New Maple Avenue Pine Brook, NJ 07058-9641 (973) 396-1000

5665 Corporate Avenue Cypress, CA 90630-0024 (714) 229-8011

13 Cummings Park Woburn, MA 01801 (781) 376-9100

Sophisticated electronic products may require occasional service. Just as quality is a keyword in the engineering and production of

the wide array of JVC products, service is the key to maintaining the high level of performance for which JVC is world famous. The JVC service and engineering organization stands behind our products.

1500 Lakes Parkway Lawrenceville, GA 30243-5857 (770) 339-2582

2969 Mapunapuna Place Honolulu, HI 96819-2040 (808) 833-5828

8192 State Road 84 Davie, FL 33324 (954) 472-1960

NATIONAL HEADQUARTERS

JVC SERVICE & ENGINEERING COMPANY OF AMERICA

DIVISION OF JVC AMERICAS CORP.

1700 Valley Road

Wayne, NJ 07470

If you ship the product • • •

Pack your JVC unit in the original carton or one of equivalent

size and strength. Enclose, with the unit, a letter stating the problem or symptom that exists and also a copy of the receipt or bill of sale you received when you purchased your JVC unit. Print your home return address on the outside and the inside of the carton. Send to the appropriate JVC Factory Service Center as listed above.

To prevent electrical shock, do not open the cabinet. No user

serviceable parts inside.

Refer servicing to qualified service personnel.

705 Enterprise Street Aurora, IL 60504-8149 (630) 851-7855

10700 Hammerly, Suite 110 Houston, TX 77043 (713) 935-9331

890 Dubuque Avenue South San Francisco, CA 94080-1804 (650) 871-2666

Don’t service it yourself.

CAUTION

(1099)

ACCESSORIES

To purchase accessories for your JVC product, you may contact your local JVC Dealer.

Or from the 48 Continental United States call toll free : 800-882-2345

LIMITED WARRANTY AUDIO-2

JVC COMPANY OF AMERICA warrants this product and all parts thereof, except as set forth below ONLY TO THE ORIGINAL PURCHASER AT RETAIL to be FREE FROM DEFECTIVE MATERIAL AND WORKMANSHIP from the date of original retail

purchase for the period as shown below. (“The Warranty Period.”)

PARTS LABOR

THIS LIMITED WARRANTY IS VALID ONLY IN THE FIFTY(50) UNITED STATES, THE DISTRICT OF COLUMBIA AND IN COMMONWEALTH OF PUERTO RICO.

WHAT WE WILL DO:

If this product is found to be defective, JVC will repair or replace defective parts at no charge to the original owner. Such repair and replacement services shall be rendered by JVC during normal business hours at JVC authorized service centers. Parts used for replacement are warranted only for the remainder of the Warranty Period. All products and parts thereof may be brought to a JVC authorized service center on a carry-in basis except for Television sets having a screen size 25 inches and above which are covered on an in-home basis.

WHAT YOU MUST DO FOR WARRANTY SERVICE:

Return your product to a JVC authorized service center with a copy of your bill of sale. For your nearest JVC authorized service center, please call toll free: (800)537-5722. If service is not available locally , box the product carefully, preferably in the original carton, and ship, insured, with a copy of your bill of sale plus and letter of explanation of the problem to the nearest JVC Factory Service Center, the name and location of which will be given to you by the toll-free number. If you have any questions concerning your JVC Product, please contact our Customer Relations Department.

WHAT IS NOT COVERED:

This limited warranty provided by JVC does not cover:

1. Products which have been subject to abuse, accident, alteration, modification, tampering, negligence, misuse, faulty

installation, lack of reasonable care, or if repaired or serviced by anyone other than a service facility authorized by JVC to render such service, or if affixed to any attachment not provided with the products, or if the model number or serial number has been altered, tampered with, defaced or removed;

2. Initial installation and installation and removal for repair;

3. Operational adjustments covered in the Owner’s Manual, normal maintenance, video and audio head cleaning;

4. Damage that occurs in shipment, due to act of God, and cosmetic damage;

2YR 2YR

5. Signal reception problems and failures due to line power surge;

6. V ideo Pick-up Tubes/CCD Image Sensor, Cartridge, Stylus(Needle) are covered for 90 days from the date of purchase;

7. Accessories;

8. Batteries (except the Rechargeable Batteries are covered for 90 days from the date of purchase); There are no express warranties except as listed above.

THE DURA TION OF ANY IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTY OF MERCHANTABILITY, IS LIMITED TO THE DURATION OF THE EXPRESS WARRANTY HEREIN.

JVC SHALL NOT BE LIABLE FOR THE LOSS OF USE OF THE PRODUCT, INCONVENIENCE, LOSS OR ANY OTHER DAMAGES, WHETHER DIRECT , INCIDENTAL OR CONSEQUENTIAL (INCLUDING, WITHOUT LIMITATION, DAMAGE TO TAPES, RECORDS OR DISCS) RESULTING FROM THE USE OF THIS PRODUCT, OR ARISING OUT OF ANY BREACH OF THIS WARRANTY. ALL EXPRESS AND IMPLIED WARRANTIES, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE, ARE LIMITED TO THE WARRANTY PERIOD SET FORTH ABOVE.

Some states do not allow the exclusion of incidental or consequential damages or limitations on how long an implied warranty last, so these limitations or exclusions may not apply to you. This warranty gives you specific legal rights and you may also have other rights which vary from state to state.

JVC COMPANY OF AMERICA 1700 Valley Road

DIVISION OF JVC AMERICAS CORP. Wayne, NJ 07470

REFURBISHED PRODUCTS CARRY A SEPARATE WARRANTY, THIS WARRANTY DOES NOT APPLY. FOR DETAILS OF REFURBISHED PRO DUCT WARRANTY, PLEASE REFER TO THE REFURBISHED PRODUCT WARRANTY INFORMATION P ACKAGED WITH EACH REFURBISHED PRODUCT.

For customer use:

Enter below the Model No. and Serial No. which is located either on the rear, bottom or side of the cabinet. Retain this

information for future reference.

Model No.: Serial No.: Purchase date: Name of dealer:

VICTOR COMPANY OF JAPAN, LIMITED

0101NHMMDWJEIN

JVC

JVC RX-6010VBK, RX-6018VBK Instruction Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Table of Contents

Parts Identification

Getting Started

Basic Operations

Basic Settings

Receiving Radio Broadcasts

Using the DSP Modes

COMPU LINK Remote Control System

Operating JVC’s Audio/Video Components

Troubleshooting

Specifications
