JVC RX-5040B Parts List

PARTS LIST

[ RX-5040B ]

* All printed circuit boards and its assemblies are not available as service parts.

Area suffix

E ----------- Continental Europe

MB173

- Contents -

Exploded view of general assembly and parts list (Block No.M1)

Electrical parts list (Block No.01~04)

Packing materials and accessories parts list (Block No.M3)

3- 2
3- 4
3-13

3-1

Exploded view of general assembly and parts list

4

7

9

P

m

59

72

58

B

60

61

Block No.

68

F206

M

1

Power transformer
board

69

F203

67

F202

66

M

F207

M

Power transfor
board

44

57

7

HS4

7

C

34

HS

36

31

D

A

39

65

A

41

F205

43

41

E

61

Headphone jack
board

20

41

Main board

18

21

22

11

BK701

84

12

11

11

11

BK702

83

Power switch board

16

4

5

1

10

8

6

82

84

2

7

3-2

System control board

8

9

3

13

63

15

62

Speaker terminal board

45

B

46

70

55

wer transformer

board

44

HS402

79

HS434

36

31

D

42

Power/Fuse
board

Front board

77

33

78

64

F201

76

HS403

75

HS401

HS404

71

Relay board

80

HS405

81

HS435

29

56

73

47

54

14

Video
board

48

53

51

46

50

49

52

Front board

38

Power amp.

board

74

74

DVD
board

46

38

io input board

Aud

DSP board

74

Power amp. board

a

37

Front board

40

35

40

29

35

40

28

32

A

19

30

25

34

27

33

E

36

24

24

23

Wire protection
board

23

C

a

23

23

D

17

26

A

27

3-3

General Assembly

Block No. [M][1][M][M]



Symbol No.

1 LV10756-021A FRONT PANEL
2 LV43338-001A JVC MARK
3 LV34003-001A LENS
4 LV34000-001A PUSH BUTTON(POW
5 LV42096-001A INDICATOR
6 LV21419-001A PUSH BUTTON(50)
7 LV21421-001A PUSH BUTTON(FM)
8 LV34001-001A 3-BUTTON (x2)
9 LV34002-001A 4-BUTTON
10 QYSBSF2608Z TAPPING SCREW 2.6mm x 8mm(x2)
11 QYSBSF2608Z TAPPING SCREW 2.6mm x 8mm(x9)
12 QUQ412-1415CJ FFC WIRE
13 QUQ412-2729CJ FFC WIRE
14 QUQ412-1110CJ FFC WIRE
15 QYSDSG3008Z TAP SCREW M3 x 8mm(x4)
16 QYSBSG3008Z TAPPING SCREW 3mm x 8mm(x3)
17 LV10873-002A CHASSIS BASE
18 LV10458-003A FRONT BRACKET
19 QYSDSG3008Z TAP SCREW M3 x 8mm(x7)
20 LV43304-001A BKT(PHONES)
21 QYSBSG3008Z TAPPING SCREW 3mm x 8mm
22 VKZ4150-001 SPECIAL NUT
23 E68587-223SM CB BKT (x4)
24 QYSBST3006Z TAPPING SCREW 3mm x 6mm(x4)
25 QZF6018-001 FOOT 60mm x 18mm(x2)
26 E47227-036 FOOT (x2)
27 QYSBST3010Z TAPPING SCREW 3mm x 10mm(x4)
28 LV20916-003A HEAT SINK
29 QYSBSG3012Z TAP SCREW M3 x 12mm(x3)
30 LV34704-001A PACK BRACKET
31 LV34705-001A H.S BRACKET(L)
32 LV34706-001A H.S BRACKET(R)
33 QYSBSG3008Z TAPPING SCREW 3mm x 8mm(x4)
34 QYSBST3006Z TAPPING SCREW 3mm x 6mm(x2)
35 QYSBSG3008Z TAPPING SCREW 3mm x 8mm(x2)
36 QYSBST3006Z TAPPING SCREW 3mm x 6mm(x2)
37 QYSBSG3008Z TAPPING SCREW 3mm x 8mm
38 E65923-003 TAPPING SCREW
39 E65923-003 TAPPING SCREW
40 QYSBSG3008Z TAPPING SCREW 3mm x 8mm(x3)
41 QYSBSG3008Z TAPPING SCREW 3mm x 8mm(x3)
42 QYSBSG3008Z TAPPING SCREW 3mm x 8mm



43 QQT0421-001 POWER TRANSF
44 QYSDSTL4008Z ASSY SCREW 4mm x 8mm(x4)
45 LV20915-075A REAR PANEL
46 QYSBSGY3008M SPECIAL SCREW 3mm x 8mm(x3)
47 QYSBSGY3008M SPECIAL SCREW 3mm x 8mm
48 QYSBSGY3008M SPECIAL SCREW 3mm x 8mm(x2)
49 QYSBSGY3008M SPECIAL SCREW 3mm x 8mm(x4)
50 QYSBSGY3008M SPECIAL SCREW 3mm x 8mm(x2)
51 QYSBSGY3008M SPECIAL SCREW 3mm x 8mm(x2)
52 QYSBSGY3008M SPECIAL SCREW 3mm x 8mm(x3)
53 QYSBSGY3008M SPECIAL SCREW 3mm x 8mm(x2)
54 QYSBSGY3008M SPECIAL SCREW 3mm x 8mm(x2)



55 QMPK250-205-JV POWER CORD(EU) 2.05m BLACK



56 QZW0033-001 STRAIN RELIEF
57 LV30225-0H3A SPACER (x2)
58 LV21649-003A/S/ TOP COVER
59 LV30077-004A PROTECT SHEET
60 QYSBSGY3008M SPECIAL SCREW 3mm x 8mm(x3)
61 E406308-003 SPECIAL SCREW (x4)
62 LV43463-001A VOL KNOB ASSY
63 LV43458-001A JOG KNOB ASSY



64 QMF51W2-2R5-J8 FUSE F201 2.5A AC250V



65 QMF51E2-R10-J1 FUSE F205 0.1A AC250V



66 QMF51W2-2R0-J8 FUSE F202 2A AC250V



67 QMF51W2-2R0-J8 FUSE F203 2A AC250V



68 QMF51W2-5R0-J8 FUSE F206 5A AC250V



69 QMF51W2-5R0-J8 FUSE F207 5A AC250V
70 QQR0491-001 FERRITE CORE FL1 TDK (GRAY)
71 E307572-001 FASTENER
72 E409396-003 CAUTION LABEL
73 QAU0347-001 TUNER
74 QYSBSG3008E TAPPING SCREW 3mm x 8mm(x7)

Part No. Part Name Description Local



Symbol No.

75 E70306-001 HEAT SINK HS401
76 E70306-001 HEAT SINK HS403
77 E70306-001 HEAT SINK HS402
78 E70306-001 HEAT SINK HS404
79 E70306-001 HEAT SINK HS434
80 E70306-001 HEAT SINK HS405
81 E70306-001 HEAT SINK HS435
82 LV42093-001A FL HOLDER(L) BK701
83 LV42092-001A FL HOLDER(R) BK702
84 LV30225-0S7A SPACER (x2)

Part No. Part Name Description Local

3-4

Electrical parts list

Power amp. board

Block No. [0][1][0][0]



Symbol No.



IC101 STK412-430 IC



IC102 STK413-430 IC
IC402 TC9164AN IC
IC403 NJM4580L-D IC

Q1131 KTC3200/GL/-T TRANSISTOR
Q1132 KTC3200/GL/-T TRANSISTOR
Q1171 KTC3200/GL/-T TRANSISTOR
Q1172 KTA1268/GL/-T TRANSISTOR
Q1173 KTC3199/GL/-T TRANSISTOR



Q1175 KTA1046/Y/ TRANSISTOR
Q1185 KTA1268/GL/-T TRANSISTOR
Q1231 KTC3200/GL/-T TRANSISTOR
Q1232 KTC3200/GL/-T TRANSISTOR
Q1261 KTC3200/GL/-T TRANSISTOR



D1101 UF304G-F82 FR DIOAE



D1102 UF304G-F82 FR DIOAE



D1103 UF304G-F82 FR DIOAE



D1104 UF304G-F82 FR DIOAE



D1105 UF304G-F82 FR DIOAE



D1106 UF304G-F82 FR DIOAE



D1107 UF304G-F82 FR DIOAE



D1108 UF304G-F82 FR DIOAE
D1121 MTZJ15C-T2 Z DIODE
D1122 MTZJ15C-T2 Z DIODE
D1129 1SS119-041-T2 DIODE
D1130 1SS119-041-T2 DIODE
D1141 MTZJ36C-T2 Z DIODE
D1171 1SS119-041-T2 DIODE
D1221 MTZJ15C-T2 Z DIODE
D1222 MTZJ15C-T2 Z DIODE
D1229 1SS119-041-T2 DIODE
D1230 1SS119-041-T2 DIODE
D1261 1SS119-041-T2 DIODE
D1352 1SS119-041-T2 DIODE
D1353 1SS119-041-T2 DIODE
D1354 1SS119-041-T2 DIODE

C419 QCBB1HK-223Y C CAPACITOR 0.022uF 50V K
C420 QCBB1HK-223Y C CAPACITOR 0.022uF 50V K
C421 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C422 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C423 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C424 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C425 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C426 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C427 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C428 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C429 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C430 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C431 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C432 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C433 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C434 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C435 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C436 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C440 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C441 QETN1EM-106Z E CAPACITOR 10uF 25V M
C442 QETN1EM-106Z E CAPACITOR 10uF 25V M
C443 QETN1EM-476Z E CAPACITOR 47uF 25V M
C444 QETN1EM-476Z E CAPACITOR 47uF 25V M
C445 QCBB1HK-223Y C CAPACITOR 0.022uF 50V K
C446 QCBB1HK-223Y C CAPACITOR 0.022uF 50V K
C451 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C452 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C460 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C1101 QFLC1HJ-471Z M CAPACITOR 470pF 50V J
C1102 QFLC1HJ-471Z M CAPACITOR 470pF 50V J
C1103 QENC1HM-475Z BP E CAPACITOR 4.7uF 50V M
C1104 QENC1HM-475Z BP E CAPACITOR 4.7uF 50V M
C1105 QETN1AM-227Z E CAPACITOR 220uF 10V M

Part No. Part Name Description Local



Symbol No.

C1106 QETN1AM-227Z E CAPACITOR 220uF 10V M
C1107 QCS31HJ-3R0Z C CAPACITOR 3pF 50V J
C1108 QCS31HJ-3R0Z C CAPACITOR 3pF 50V J
C1111 QEZ0679-688 E CAPACITOR 6800uF
C1112 QEZ0679-688 E CAPACITOR 6800uF
C1113 QEZ0691-478 E CAPACITER 4700uF
C1114 QEZ0691-478 E CAPACITER 4700uF
C1115 QFZ9076-104Z MM CAPACITOR 0.1uF
C1116 QCE22HP-103 C CAPACITOR 0.01uF 500V P
C1117 QCE22HP-103 C CAPACITOR 0.01uF 500V P
C1118 QFZ9076-104Z MM CAPACITOR 0.1uF
C1119 QCE22HP-103 C CAPACITOR 0.01uF 500V P
C1120 QCE22HP-103 C CAPACITOR 0.01uF 500V P
C1121 QETN2AM-107Z E CAPACITOR 100uF 100V M
C1122 QETN2AM-107Z E CAPACITOR 100uF 100V M
C1123 QCS31HJ-101Z C CAPACITOR 100pF 50V J
C1124 QCS31HJ-101Z C CAPACITOR 100pF 50V J
C1131 QCBB1HK-222Y C CAPACITOR 2200pF 50V K
C1132 QCBB1HK-222Y C CAPACITOR 2200pF 50V K
C1141 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C1142 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C1143 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C1144 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C1171 QEKC1EM-106Z E CAPACITOR 10uF 25V M
C1172 QEKC1CM-476Z E CAPACITOR 47uF 16V M
C1185 QETN2AM-106Z E CAPACITOR 10uF 100V M
C1191 QETN1HM-476Z E CAPACITOR 47uF 50V M
C1201 QFLC1HJ-471Z M CAPACITOR 470pF 50V J
C1202 QFLC1HJ-471Z M CAPACITOR 470pF 50V J
C1203 QENC1HM-475Z BP E CAPACITOR 4.7uF 50V M
C1204 QENC1HM-475Z BP E CAPACITOR 4.7uF 50V M
C1205 QETN1AM-107Z E CAPACITOR 100uF 10V M
C1206 QETN1AM-107Z E CAPACITOR 100uF 10V M
C1207 QCS31HJ-3R0Z C CAPACITOR 3pF 50V J
C1208 QCS31HJ-3R0Z C CAPACITOR 3pF 50V J
C1221 QETN2AM-107Z E CAPACITOR 100uF 100V M
C1222 QETN2AM-107Z E CAPACITOR 100uF 100V M
C1223 QCS31HJ-101Z C CAPACITOR 100pF 50V J
C1224 QCS31HJ-101Z C CAPACITOR 100pF 50V J
C1241 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C1242 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C1243 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C1244 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C1261 QFLC1HJ-471Z M CAPACITOR 470pF 50V J
C1262 QENC1HM-475Z BP E CAPACITOR 4.7uF 50V M
C1263 QETN1AM-107Z E CAPACITOR 100uF 10V M
C1264 QCS31HJ-3R0Z C CAPACITOR 3pF 50V J
C1265 QCS31HJ-101Z C CAPACITOR 100pF 50V J
C1266 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C1267 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C1268 QCBB1HK-223Y C CAPACITOR 0.022uF 50V K
C1359 QCS32HJ-221Z C CAPACITOR 220pF 500V J
C1360 QCS32HJ-221Z C CAPACITOR 220pF 500V J
C1361 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C1362 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C1363 QCS32HJ-221Z C CAPACITOR 220pF 500V J
C1364 QCS32HJ-221Z C CAPACITOR 220pF 500V J
C1365 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C1366 QCS32HJ-221Z C CAPACITOR 220pF 500V J
C1367 QCS32HJ-221Z C CAPACITOR 220pF 500V J
C1368 QCS32HJ-221Z C CAPACITOR 220pF 500V J
C1368 QCS32HJ-221Z C CAPACITOR 220pF 500V J
C1369 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C1370 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C1371 QCS32HJ-221Z C CAPACITOR 220pF 500V J
C1372 QCS32HJ-221Z C CAPACITOR 220pF 500V J
C1373 QCS32HJ-221Z C CAPACITOR 220pF 500V J
C1374 QCS32HJ-221Z C CAPACITOR 220pF 500V J
C1375 QCS32HJ-221Z C CAPACITOR 220pF 500V J
C1376 QCS32HJ-221Z C CAPACITOR 220pF 500V J
C1377 QCS32HJ-221Z C CAPACITOR 220pF 500V J
C1378 QCS32HJ-221Z C CAPACITOR 220pF 500V J

R421 QRE141J-471Y C RESISTOR 470Ω 1/4W J
R422 QRE141J-471Y C RESISTOR 470Ω 1/4W J
R423 QRE141J-471Y C RESISTOR 470

Part No. Part Name Description Local

Ω

1/4W J

3-5



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

R424 QRE141J-471Y C RESISTOR 470Ω 1/4W J
R425 QRE141J-471Y C RESISTOR 470Ω 1/4W J
R426 QRE141J-471Y C RESISTOR 470Ω 1/4W J
R429 QRE141J-471Y C RESISTOR 470Ω 1/4W J
R430 QRE141J-471Y C RESISTOR 470Ω 1/4W J
R431 QRE141J-471Y C RESISTOR 470
R432 QRE141J-471Y C RESISTOR 470
R435 QRE141J-471Y C RESISTOR 470Ω 1/4W J
R436 QRE141J-471Y C RESISTOR 470Ω 1/4W J
R440 QRE141J-102Y C RESISTOR 1kΩ 1/4W J
R441 QRE141J-104Y C RESISTOR 100kΩ 1/4W J
R442 QRE141J-104Y C RESISTOR 100kΩ 1/4W J
R443 QRE141J-104Y C RESISTOR 100kΩ 1/4W J
R444 QRE141J-104Y C RESISTOR 100kΩ 1/4W J
R445 QRE141J-104Y C RESISTOR 100kΩ 1/4W J
R446 QRE141J-104Y C RESISTOR 100kΩ 1/4W J



R449 QRJ146J-271X UNF C RESISTOR 270Ω 1/4W J



R450 QRJ146J-271X UNF C RESISTOR 270Ω 1/4W J
R451 QRE141J-471Y C RESISTOR 470Ω 1/4W J
R452 QRE141J-471Y C RESISTOR 470Ω 1/4W J
R1101 QRE141J-221Y C RESISTOR 220
R1102 QRE141J-221Y C RESISTOR 220
R1103 QRE141J-104Y C RESISTOR 100kΩ 1/4W J
R1104 QRE141J-104Y C RESISTOR 100kΩ 1/4W J



R1105 QRJ146J-391X UNF C RESISTOR 390Ω 1/4W J



R1106 QRJ146J-391X UNF C RESISTOR 390Ω 1/4W J
R1107 QRE141J-104Y C RESISTOR 100kΩ 1/4W J
R1108 QRE141J-104Y C RESISTOR 100kΩ 1/4W J
R1109 QRE141J-333Y C RESISTOR 33kΩ 1/4W J



R1121 QRJ146J-471X UNF C RESISTOR 470Ω 1/4W J



R1122 QRJ146J-471X UNF C RESISTOR 470Ω 1/4W J



R1123 QRL017J-152 OMF RESISTOR 1.5kΩ 1W J



R1124 QRL017J-152 OMF RESISTOR 1.5kΩ 1W J



R1125 QRZ0224-R22 EMIT RESISTOR 0.22



R1126 QRZ0224-R22 EMIT RESISTOR 0.22
R1127 QRE141J-102Y C RESISTOR 1kΩ 1/4W J
R1128 QRE141J-102Y C RESISTOR 1kΩ 1/4W J
R1129 QRE141J-183Y C RESISTOR 18kΩ 1/4W J
R1130 QRE141J-183Y C RESISTOR 18kΩ 1/4W J
R1131 QRE141J-473Y C RESISTOR 47kΩ 1/4W J
R1132 QRE141J-473Y C RESISTOR 47kΩ 1/4W J



R1133 QRJ146J-101X UNF C RESISTOR 100Ω 1/4W J



R1134 QRJ146J-2R2X UNF C RESISTOR 2.2Ω 1/4W J



R1135 QRJ146J-2R2X UNF C RESISTOR 2.2Ω 1/4W J



R1136 QRJ146J-2R2X UNF C RESISTOR 2.2Ω 1/4W J



R1137 QRJ146J-2R2X UNF C RESISTOR 2.2Ω 1/4W J
R1141 QRJ146J-330X UNF C RESISTOR 33Ω 1/4W J
R1142 QRJ146J-330X UNF C RESISTOR 33Ω 1/4W J



R1143 QRL027J-100 OMF RESISTOR 10Ω 2W J



R1144 QRL027J-100 OMF RESISTOR 10Ω 2W J
R1171 QRE141J-104Y C RESISTOR 100kΩ 1/4W J
R1172 QRE141J-823Y C RESISTOR 82k
R1173 QRE141J-104Y C RESISTOR 100k
R1174 QRE141J-104Y C RESISTOR 100kΩ 1/4W J
R1175 QRE141J-104Y C RESISTOR 100k
R1176 QRE141J-104Y C RESISTOR 100k
R1177 QRE141J-104Y C RESISTOR 100kΩ 1/4W J
R1178 QRE141J-103Y C RESISTOR 10k
R1179 QRE141J-103Y C RESISTOR 10kΩ 1/4W J
R1185 QRE141J-103Y C RESISTOR 10k
R1186 QRE141J-104Y C RESISTOR 100k



R1191 QRZ9005-680X F RESISTOR 68



R1192 QRJ146J-562X UNF C RESISTOR 5.6kΩ 1/4W J
R1201 QRE141J-102Y C RESISTOR 1k
R1202 QRE141J-102Y C RESISTOR 1kΩ 1/4W J
R1203 QRE141J-104Y C RESISTOR 100k
R1204 QRE141J-104Y C RESISTOR 100k



R1205 QRJ146J-751X UNF C RESISTOR 750Ω 1/4W J



R1206 QRJ146J-751X UNF C RESISTOR 750Ω 1/4W J
R1207 QRE141J-104Y C RESISTOR 100kΩ 1/4W J
R1208 QRE141J-104Y C RESISTOR 100k
R1209 QRE141J-333Y C RESISTOR 33k
R1210 QRE141J-101Y C RESISTOR 100Ω 1/4W J



R1221 QRJ146J-471X UNF C RESISTOR 470Ω 1/4W J



R1222 QRJ146J-471X UNF C RESISTOR 470Ω 1/4W J



R1223 QRL017J-152 OMF RESISTOR 1.5kΩ 1W J



R1224 QRL017J-152 OMF RESISTOR 1.5kΩ 1W J



R1225 QRZ0224-R22 EMIT RESISTOR 0.22

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω
Ω

Ω

1/4W J

Ω
Ω

Ω

Ω

1/4W J

Ω

1/4W J

Ω

Ω
Ω

1/4W J

Ω
Ω

Ω

Ω

1/4W J

Ω

1/4W J

1/4W J
1/4W J

1/4W J

1/4W J
1/4W J

1/4W J



R1226 QRZ0224-R22 EMIT RESISTOR 0.22
R1227 QRE141J-102Y C RESISTOR 1kΩ 1/4W J
R1228 QRE141J-102Y C RESISTOR 1kΩ 1/4W J
R1229 QRE141J-183Y C RESISTOR 18kΩ 1/4W J
R1230 QRE141J-183Y C RESISTOR 18kΩ 1/4W J
R1231 QRE141J-473Y C RESISTOR 47k
R1232 QRE141J-473Y C RESISTOR 47k



R1233 QRJ146J-101X UNF C RESISTOR 100Ω 1/4W J



R1234 QRJ146J-2R2X UNF C RESISTOR 2.2Ω 1/4W J



R1235 QRJ146J-2R2X UNF C RESISTOR 2.2Ω 1/4W J



R1236 QRJ146J-2R2X UNF C RESISTOR 2.2Ω 1/4W J



R1237 QRJ146J-2R2X UNF C RESISTOR 2.2Ω 1/4W J
R1241 QRJ146J-330X UNF C RESISTOR 33Ω 1/4W J
R1242 QRJ146J-330X UNF C RESISTOR 33Ω 1/4W J



R1243 QRL027J-100 OMF RESISTOR 10Ω 2W J



R1244 QRL027J-100 OMF RESISTOR 10Ω 2W J
R1261 QRE141J-102Y C RESISTOR 1kΩ 1/4W J
R1262 QRE141J-623Y C RESISTOR 62kΩ 1/4W J



R1263 QRJ146J-301X UNF C RESISTOR 300Ω 1/4W J
R1264 QRE141J-623Y C RESISTOR 62kΩ 1/4W J



R1265 QRZ0224-R22 EMIT RESISTOR 0.22
R1266 QRE141J-102Y C RESISTOR 1kΩ 1/4W J
R1267 QRE141J-183Y C RESISTOR 18kΩ 1/4W J
R1268 QRE141J-473Y C RESISTOR 47kΩ 1/4W J
R1269 QRJ146J-330X UNF C RESISTOR 33Ω 1/4W J



R1270 QRL027J-100 OMF RESISTOR 10Ω 2W J



R1352 QRJ146J-680X UNF C RESISTOR 68Ω 1/4W J



R1353 QRJ146J-680X UNF C RESISTOR 68Ω 1/4W J



R1354 QRJ146J-680X UNF C RESISTOR 68Ω 1/4W J



R1370 QRJ146J-3R9X UNF C RESISTOR 3.9Ω 1/4W J



R1371 QRJ146J-3R9X UNF C RESISTOR 3.9Ω 1/4W J



R1372 QRJ146J-3R9X UNF C RESISTOR 3.9Ω 1/4W J



R1373 QRJ146J-3R9X UNF C RESISTOR 3.9Ω 1/4W J



R1374 QRJ146J-3R9X UNF C RESISTOR 3.9Ω 1/4W J

L1141 QQLZ005-R45 COIL 0.45uH
L1142 QQLZ005-R45 COIL 0.45uH
L1241 QQLZ005-R45 COIL 0.45uH
L1242 QQLZ005-R45 COIL 0.45uH
L1269 QQLZ005-R45 COIL 0.45uH
L1351 QQLZ005-R45 COIL 0.45uH
L1352 QQLZ005-R45 COIL 0.45uH
L1353 QQLZ005-R45 COIL 0.45uH
L1354 QQLZ005-R45 COIL 0.45uH
L1355 QQLZ005-R45 COIL 0.45uH

CN151 QJK012-051903 WIRE
CN171 QJP001-031801 SHI CR C-B WIRE
CN272 QJP002-021201 SHI CR C-B WIRE
CN273 QJP001-031001 SHI CR C-B WIRE
CN401 QGB2510K1-14 CONNECTOR B-B (1-14)
CN451 QGB2510K1-11 CONNECTOR B-B (1-11)
EP101 QNZ0136-001Z EARTH PLATE
FW141 QUM215-16DGZ4 WIRE
FW301 QUM215-25Z4Z4 PARA RIBON WIRE
FW302 QUM216-25Z4Z4 PARA RIBON WIRE
FW303 QUM214-26DGZ4 PARA RIBON WIRE
J402 QNN0478-001 SURROUND JACK
J403 QNN0478-001 SURROUND JACK
J404 QNN0389-001 PIN JACK
J406 QNN0060-001 PIN JACK
PW601 QUB220-22HPHP WIRE



RY302 QSK0109-001 RELAY



RY303 QSK0109-001 RELAY



RY304 QSK0109-001 RELAY
ST301 QNB0188-001 SPEAKER TERMINA

Ω

Ω
Ω

Ω

1/4W J
1/4W J

3-6

Front board

Block No. [0][2][0][0]



Symbol No.

IC423 TC9162AF-X IC
IC427 NJM4565M-WE IC
IC428 BD3814FV-X IC
IC431 BU1924F-X IC
IC701 MN101C35DMW IC(1-TIME)
IC702 IC-PST9139-T IC
IC703 GP1UM281XK IR DETECT UNIT 38kHz

Q701 UN2214-X TRANSISTOR
Q702 UN2215-X TRANSISTOR
Q703 KRC109S-X TRANSISTOR
Q707 UN2214-X TRANSISTOR
Q708 UN2214-X TRANSISTOR
Q709 UN2214-X TRANSISTOR
Q711 UN2113-X TRANSISTOR



Q1401 KTA1046/Y/ TRANSISTOR



Q1402 2SD2394/EF/ TRANSISTOR



Q1403 2SD2394/EF/ TRANSISTOR



Q1404 2SD2394/EF/ TRANSISTOR



Q1405 2SD2394/EF/ TRANSISTOR



Q1406 KTC3203/OY/-T TRANSISTOR



Q1407 KTC3203/OY/-T TRANSISTOR



Q1408 KTA1271/OY/-T TRANSISTOR
Q1413 2SC3576-JVC-T TRANSISTOR
Q1414 2SC3576-JVC-T TRANSISTOR
Q1417 2SC3576-JVC-T TRANSISTOR
Q1418 2SC3576-JVC-T TRANSISTOR
Q1419 2SC3576-JVC-T TRANSISTOR
Q1420 KRA104M-T DIGI TRANSISTOR
Q1421 2SC3576-JVC-T TRANSISTOR
Q1422 2SC3576-JVC-T TRANSISTOR
Q1423 KRA104M-T DIGI TRANSISTOR
Q1424 KRA104M-T DIGI TRANSISTOR
Q1425 2SC3576-JVC-T TRANSISTOR
Q1426 2SC3576-JVC-T TRANSISTOR
Q1427 2SC3576-JVC-T TRANSISTOR
Q1428 2SC3576-JVC-T TRANSISTOR
Q1429 KRA104M-T DIGI TRANSISTOR



Q1434 2SD2394/EF/ TRANSISTOR



Q1435 2SD2394/EF/ TRANSISTOR

D701 1SS355-X SI DIODE
D703 SB007-03CP-X SB DIODE
D719 SLR-343VC/NPQ-T LED
D1401 MTZJ13C-T2 Z DIODE
D1402 MTZJ6.2C-T2 Z DIODE
D1403 MTZJ5.6B-T2 Z DIODE
D1404 MTZJ5.6C-T2 Z DIODE
D1405 MTZJ13C-T2 Z DIODE
D1406 MTZJ10C-T2 Z DIODE
D1407 MTZJ7.5C-T2 Z DIODE
D1408 MTZJ7.5C-T2 Z DIODE
D1409 MA152WK-X SI DIODE
D1411 1SS355-X SI DIODE
D1412 1SS355-X SI DIODE
D1413 1SS355-X SI DIODE
D1414 1SS355-X SI DIODE
D1415 1SS355-X SI DIODE

C101 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C102 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C701 QEKC0JM-107Z E CAPACITOR 100uF 6.3V M
C702 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C703 QEKC1HM-225Z E CAPACITOR 2.2uF 50V M
C704 NCB31CK-223X C CAPACITOR 0.022uF 16V K
C705 QEKC0JM-107Z E CAPACITOR 100uF 6.3V M
C706 NCB21HK-331X C CAPACITOR 330pF 50V K
C707 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C708 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C709 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C710 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C713 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C714 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C715 NCB21HK-103X C CAPACITOR 0.01uF 50V K

Part No. Part Name Description Local



Symbol No.

C716 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C717 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C718 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C719 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C720 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C721 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C722 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C723 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C724 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C725 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C730 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C731 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1401 QETN1HM-476Z E CAPACITOR 47uF 50V M
C1402 QETN1EM-107Z E CAPACITOR 100uF 25V M
C1403 QETN1EM-107Z E CAPACITOR 100uF 25V M
C1404 QETN1EM-107Z E CAPACITOR 100uF 25V M
C1405 QETN1EM-107Z E CAPACITOR 100uF 25V M
C1406 QETN1EM-107Z E CAPACITOR 100uF 25V M
C1407 QCF31HZ-223Z C CAPACITOR 0.022uF 50V Z
C1408 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1409 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1422 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1423 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C1424 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C1425 QEKC1CM-106Z E CAPACITOR 10uF 16V M
C1432 NCB31CK-223X C CAPACITOR 0.022uF 16V K
C1433 QETN1CM-106Z E CAPACITOR 10uF 16V M
C1436 NCB31CK-223X C CAPACITOR 0.022uF 16V K
C1437 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C1439 QFLC1HJ-562Z M CAPACITOR 5600pF 50V J
C1440 QFLC1HJ-562Z M CAPACITOR 5600pF 50V J
C1444 NCB31CK-223X C CAPACITOR 0.022uF 16V K
C1445 NCB31CK-223X C CAPACITOR 0.022uF 16V K
C1446 NCB31HK-221X C CAPACITOR 220pF 50V K
C1447 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C1453 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1459 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1460 NCB31CK-223X C CAPACITOR 0.022uF 16V K
C1461 NCB31CK-223X C CAPACITOR 0.022uF 16V K
C1463 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1464 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1465 QENC1HM-106Z BP E CAPACITOR 10uF 50V M
C1470 NDC31HJ-820X C CAPACITOR 82pF 50V J
C1471 NDC31HJ-470X C CAPACITOR 47pF 50V J
C1472 QETN1CM-106Z E CAPACITOR 10uF 16V M
C1473 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C1474 NCB31HK-561X C CAPACITOR 560pF 50V K
C1475 NCB31HK-331X C CAPACITOR 330pF 50V K
C1476 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C1477 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1480 QETN1VM-477Z E CAPACITOR 470uF 35V M



R101 QRL027J-471 OMF RESISTOR 470Ω 2W J



R102 QRL027J-471 OMF RESISTOR 470Ω 2W J
R475 NRSA63J-163X MG RESISTOR 16k
R476 NRSA63J-103X MG RESISTOR 10k



R477 QRZ9006-4R7X FUSI RESISTOR 4.7Ω 1/4W J



R478 QRJ146J-2R2X UNF C RESISTOR 2.2Ω 1/4W J



R479 QRJ146J-2R2X UNF C RESISTOR 2.2Ω 1/4W J
R480 NRSA63J-512X MG RESISTOR 5.1k
R483 NRSA63J-562X MG RESISTOR 5.6k
R484 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R485 NRSA63J-202X MG RESISTOR 2k
R486 NRSA63J-473X MG RESISTOR 47k
R487 NRSA63J-202X MG RESISTOR 2kΩ 1/16W J
R488 NRSA63J-473X MG RESISTOR 47k
R489 NRSA63J-101X MG RESISTOR 100
R490 NRSA63J-101X MG RESISTOR 100
R491 NRSA63J-512X MG RESISTOR 5.1k
R701 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R702 NRSA63J-223X MG RESISTOR 22k
R704 NRSA63J-471X MG RESISTOR 470
R705 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R707 NRSA63J-103X MG RESISTOR 10k
R708 NRSA63J-103X MG RESISTOR 10k
R709 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R710 NRSA63J-103X MG RESISTOR 10k
R711 NRSA63J-104X MG RESISTOR 100k

Part No. Part Name Description Local

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

3-7



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

R712 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R713 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R715 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R716 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R717 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R718 NRSA63J-103X MG RESISTOR 10k
R719 NRSA63J-221X MG RESISTOR 220
R720 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R721 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R722 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R723 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R724 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J
R725 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J
R726 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R727 NRSA63J-272X MG RESISTOR 2.7kΩ 1/16W J
R728 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R729 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R730 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R731 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J
R732 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J
R733 NRSA63J-222X MG RESISTOR 2.2k
R734 NRSA63J-272X MG RESISTOR 2.7k
R736 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R737 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R738 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R739 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J
R740 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J
R741 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R743 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R744 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R745 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R746 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J
R747 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J
R748 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R749 NRSA63J-272X MG RESISTOR 2.7kΩ 1/16W J
R750 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R751 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R752 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R753 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J
R754 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J
R757 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R758 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R759 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R760 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R761 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R762 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R763 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R768 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R769 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R770 NRSA63J-102X MG RESISTOR 1k
R772 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R773 NRSA63J-272X MG RESISTOR 2.7k
R775 NRSA63J-103X MG RESISTOR 10k
R778 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J
R779 NRSA63J-103X MG RESISTOR 10k
R781 NRSA63J-221X MG RESISTOR 220
R782 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R783 NRSA63J-221X MG RESISTOR 220
R784 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R785 NRSA63J-221X MG RESISTOR 220
R786 NRSA63J-221X MG RESISTOR 220
R787 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R788 NRSA63J-221X MG RESISTOR 220
R790 NRSA63J-221X MG RESISTOR 220
R791 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R792 NRSA63J-221X MG RESISTOR 220
R794 NRSA63J-221X MG RESISTOR 220
R795 NRSA63J-221X MG RESISTOR 220
R796 NRSA63J-221X MG RESISTOR 220
R797 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R798 NRSA63J-221X MG RESISTOR 220
R799 NRSA63J-221X MG RESISTOR 220
R874 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R875 NRSA63J-103X MG RESISTOR 10k
R876 NRSA63J-103X MG RESISTOR 10k
R877 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R878 NRSA63J-103X MG RESISTOR 10k
R879 NRSA63J-221X MG RESISTOR 220

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

R880 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R881 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R882 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R883 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R884 NRSA63J-221X MG RESISTOR 220Ω 1/16W J



R1401 QRZ9005-100X F RESISTOR 10



R1402 QRJ146J-182X UNF C RESISTOR 1.8kΩ 1/4W J



R1403 QRZ9005-120X FUSI RESISTOR 12



R1404 QRJ146J-272X UNF C RESISTOR 2.7kΩ 1/4W J



R1405 QRZ9005-120X FUSI RESISTOR 12



R1406 QRK126J-682X UNF C RESISTOR 6.8kΩ 1/2W J



R1407 QRZ9006-4R7X FUSI RESISTOR 4.7Ω 1/4W J



R1408 QRZ9006-4R7X FUSI RESISTOR 4.7Ω 1/4W J



R1409 QRJ146J-272X UNF C RESISTOR 2.7kΩ 1/4W J



R1410 QRZ9006-4R7X FUSI RESISTOR 4.7Ω 1/4W J



R1411 QRJ146J-182X UNF C RESISTOR 1.8kΩ 1/4W J



R1412 QRZ9005-100X F RESISTOR 10



R1413 QRJ146J-102X UNF C RESISTOR 1kΩ 1/4W J



R1414 QRZ9005-100X F RESISTOR 10



R1415 QRJ146J-222X UNF C RESISTOR 2.2kΩ 1/4W J



R1416 QRZ9005-100X F RESISTOR 10



R1417 QRJ146J-222X UNF C RESISTOR 2.2kΩ 1/4W J



R1418 QRZ9005-680X F RESISTOR 68



R1419 QRZ9005-680X F RESISTOR 68
R1435 NRSA63J-154X MG RESISTOR 150kΩ 1/16W J
R1436 NRSA63J-154X MG RESISTOR 150kΩ 1/16W J
R1437 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1438 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1439 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1440 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1444 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1445 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1446 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R1447 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1448 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1449 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1450 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1451 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R1452 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R1453 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1457 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J
R1458 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J



R1459 QRZ9005-680X F RESISTOR 68



R1460 QRZ9005-680X F RESISTOR 68
R1461 QRJ146J-2R2X UNF C RESISTOR 2.2Ω 1/4W J
R1462 QRJ146J-2R2X UNF C RESISTOR 2.2Ω 1/4W J
R1464 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R1465 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1470 NRSA63J-201X MG RESISTOR 200Ω 1/16W J
R1471 NRSA63J-201X MG RESISTOR 200
R1472 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1473 NRSA63J-103X MG RESISTOR 10k
R1474 NRSA63J-102X MG RESISTOR 1k
R1475 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R1477 NRSA63J-102X MG RESISTOR 1k
R1478 NRSA63J-102X MG RESISTOR 1k
R1480 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R1485 NRSA63J-102X MG RESISTOR 1k
R1486 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1487 NRSA63J-103X MG RESISTOR 10k
R1488 NRSA63J-103X MG RESISTOR 10k
R1490 NRSA63J-133X MG RESISTOR 13kΩ 1/16W J
R1492 NRSA63J-102X MG RESISTOR 1k
R1493 NRSA63J-102X MG RESISTOR 1k
R1494 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1495 NRSA63J-103X MG RESISTOR 10k
R1496 NRSA63J-103X MG RESISTOR 10k
R1498 NRSA63J-511X MG RESISTOR 510
R1499 NRSA63J-511X MG RESISTOR 510
R1500 NRSA63J-474X MG RESISTOR 470kΩ 1/16W J
R1571 NRSA63J-0R0X MG RESISTOR 0
R1572 NRSA63J-0R0X MG RESISTOR 0
R1573 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1574 NRSA63J-102X MG RESISTOR 1k
R1575 NRSA63J-0R0X MG RESISTOR 0
R1576 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R1579 NRSA63J-301X MG RESISTOR 300
R1580 NRSA63J-0R0X MG RESISTOR 0

Ω
Ω
Ω

Ω
Ω
Ω
Ω

Ω

Ω
Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

3-8



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

R1581 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R1582 NRSA63J-162X MG RESISTOR 1.6kΩ 1/16W J
R1583 NRSA63J-561X MG RESISTOR 560Ω 1/16W J
R1584 NRSA63J-561X MG RESISTOR 560Ω 1/16W J

CN101 QGD2504C1-03Z CONNECTOR (1-3)
CN402 QGF1205C1-27 CONNECTOR FFC/FPC (1-27)
CN403 QGA2001C1-02 CONNECTOR W-B (1-2)
CN411 QGF1205C1-11 CONNECTOR FFC/FPC (1-11)
CN421 QGB2510J1-14 CONNECTOR B-B (1-14)
CN431 QGB2510J1-11 CONNECTOR B-B (1-11)
CN441 QGB2510J1-07 CONNECTOR B-B (1-7)
CN471 QGA2501C1-03 CONNECTOR W-B (1-3)
CN472 QGA2501C1-02 CONNECTOR W-B (1-2)
CN473 QGA2501C1-03 CONNECTOR W-B (1-3)
CN481 QGB2510J1-14 CONNECTOR B-B (1-14)
CN482 QGB2510J1-07 CONNECTOR B-B (1-7)
CN491 QGB2510J1-04 CONNECTOR B-B (1-4)
CN701 QGF1205F1-14 CONNECTOR FFC/FPC (1-14)
CN702 QGF1205F1-27 CONNECTOR FFC/FPC (1-27)
CN703 QJK021-024004 SIN CR C-B WIRE
CN704 WJS0020-002A SKT.WIRE ASSY
CN714 QGA2001F1-03 CONNECTOR W-B (1-3)
DI701 QLF0132-001 FL TUBE
EP401 QNZ0136-001Z EARTH PLATE
FL401 QQR1372-001 LPF
FL402 QQR1372-001 LPF
J101 QNS0022-001 JACK
JS701 QSW1017-002 JOG VOLUME
JS702 QSW1051-001 ROTARY ENCODER
PW501 QUB220-18DMHP SIN TWIST WIRE
PW502 QUB220-14DMHP SNAPIN-RINGWIRE
S721 QSW0683-001Z PUSH SW
S722 QSW0683-001Z PUSH SW
S723 QSW0683-001Z PUSH SW
S724 QSW0683-001Z PUSH SW
S725 QSW0683-001Z PUSH SW
S726 QSW0683-001Z PUSH SW
S727 QSW0683-001Z PUSH SW
S728 QSW0683-001Z PUSH SW
S729 QSW0683-001Z PUSH SW
S730 QSW0683-001Z PUSH SW
S731 QSW0683-001Z PUSH SW
S732 QSW0683-001Z PUSH SW
S734 QSW0683-001Z PUSH SW
S735 QSW0683-001Z PUSH SW
S737 QSW0683-001Z PUSH SW
S740 QSW0683-001Z PUSH SW
S741 QSW0683-001Z PUSH SW
S742 QSW0683-001Z PUSH SW
S743 QSW0683-001Z PUSH SW
S745 QSW0683-001Z PUSH SW
S746 QSW0683-001Z PUSH SW
S750 QSW0683-001Z PUSH SW
S751 QSW0683-001Z PUSH SW
S752 QSW0683-001Z PUSH SW
S756 QSW0683-001Z PUSH SW
X701 QAX0246-001Z C RESONATOR 8.00MHz
X1401 QAX0263-001Z CRYSTAL 4.332MHz

Main board

Block No. [0][3][0][0]



Symbol No.

IC501 NJM2246D IC

Q202 KRC105M-T DIGI TRANSISTOR



Q203 KTC3203/OY/-T TRANSISTOR
Q205 KTC3200/GL/-T TRANSISTOR
Q206 KRC105M-T DIGI TRANSISTOR
Q208 KRC105M-T DIGI TRANSISTOR
Q209 KRC105M-T DIGI TRANSISTOR
Q210 KRC105M-T DIGI TRANSISTOR

Part No. Part Name Description Local

Q502 KTC3199/GL/-T TRANSISTOR
Q503 KRC101M-T TRANSISTOR
Q505 KTC3199/GL/-T TRANSISTOR



D201 10DDA20-FD DIODE



D202 11ES2-T4 DIODE



D203 10DDA20-FD DIODE



D204 11ES2-T4 DIODE



D206 11ES2-T4 DIODE



D207 11ES2-T4 DIODE



D208 11ES2-T4 DIODE



D209 11ES2-T4 DIODE
D210 1SS133-T2 DIODE
D211 MTZJ6.8C-T2 Z DIODE
D212 11ES2-T4 DIODE
D217 MTZJ8.2C-T2 Z DIODE
D218 1SS133-T2 DIODE
D219 11ES2-T4 DIODE
D220 11ES2-T4 DIODE
D221 1SS133-T2 DIODE

C201 QFLC2AJ-104Z M CAPACITOR 0.1uF 100V J
C202 QFLC2AJ-104Z M CAPACITOR 0.1uF 100V J
C203 QFLC2AJ-104Z M CAPACITOR 0.1uF 100V J
C204 QETM1VM-228 E CAPACITOR 2200uF 35V M
C205 QETM1VM-108 E CAPACITOR 1000uF 35V M
C206 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C207 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C208 QFLC2AJ-472Z M CAPACITOR 4700pF 100V J
C209 QETN1EM-477Z E CAPACITOR 470uF 25V M



C210 QCZ9104-472 C CAPACITOR 4700pF
C212 QETN1CM-477Z E CAPACITOR 470uF 16V M
C213 QETN0JM-228Z E CAPACITOR 2200uF 6.3V M
C218 QETN1HM-105Z E CAPACITOR 1uF 50V M
C221 QCBB1HK-471Y C CAPACITOR 470pF 50V K
C501 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C503 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C504 QCS31HJ-470Z C CAPACITOR 47pF 50V J
C505 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C506 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C507 QCS31HJ-470Z C CAPACITOR 47pF 50V J
C511 QETN1CM-108Z E CAPACITOR 1000uF 16V M
C512 QCBB1HK-223Y C CAPACITOR 0.022uF 50V K
C521 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C522 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z



R201 QRJ146J-2R2X UNF C RESISTOR 2.2Ω 1/4W J



R204 QRJ146J-821X UNF C RESISTOR 820Ω 1/4W J



R208 QRJ146J-100X UNF C RESISTOR 10Ω 1/4W J
R209 QRE141J-104Y C RESISTOR 100k



R210 QRJ146J-680X UNF C RESISTOR 68Ω 1/4W J



R221 QRJ146J-100X UNF C RESISTOR 10Ω 1/4W J
R501 QRE141J-331Y C RESISTOR 330
R502 QRE141J-750Y C RESISTOR 75Ω 1/4W J
R505 QRE141J-750Y C RESISTOR 75
R506 QRE141J-473Y C RESISTOR 47k
R507 QRE141J-331Y C RESISTOR 330Ω 1/4W J
R508 QRE141J-750Y C RESISTOR 75
R509 QRE141J-750Y C RESISTOR 75Ω 1/4W J
R510 QRE141J-473Y C RESISTOR 47k
R512 QRE141J-181Y C RESISTOR 180
R513 QRE141J-751Y C RESISTOR 750Ω 1/4W J
R515 QRE141J-181Y C RESISTOR 180
R521 QRE141J-221Y C RESISTOR 220
R522 QRE141J-471Y C RESISTOR 470Ω 1/4W J



T202 QQT0433-001 POWER TRANSF

CN201 QGF1205C1-14 CONNECTOR FFC/FPC (1-14)
CN203 QGD2504C1-04Z CONNECTOR (1-4)
CN241 QGD2504C1-05Z CONNECTOR (1-5)
CN251 QGA3901F2-05 CONNECTOR W-B (1-5)
CN291 QGB2510J1-04 CONNECTOR B-B (1-4)
CN292 QGB2510K1-04 CONNECTOR B-B (1-4)
CN492 QGB2510K1-04 CONNECTOR B-B (1-4)
CN501 QGB2510K1-07 CONNECTOR B-B (1-7)
EP1 E409182-001SM GRAND TERMINAL
EP201 QNZ0136-001Z EARTH PLATE

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

3-9



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

FC211 QNG0020-001Z FUSE CLIP
FC212 QNG0020-001Z FUSE CLIP
FC221 QNG0020-001Z FUSE CLIP
FC222 QNG0020-001Z FUSE CLIP
FC231 QNG0020-001Z FUSE CLIP
FC232 QNG0020-001Z FUSE CLIP
FC251 QNG0020-001Z FUSE CLIP
FC252 QNG0020-001Z FUSE CLIP
FC261 QNG0020-001Z FUSE CLIP
FC262 QNG0020-001Z FUSE CLIP
FC271 QNG0020-001Z FUSE CLIP
FC272 QNG0020-001Z FUSE CLIP
FW201 QUM215-14Z4Z4 PARA RIBON WIRE
FW251 QUM213-08DGZ4 PARA RIBON WIRE
J501 QNN0011-001 PIN JACK
J502 QNN0011-001 PIN JACK
J521 QNS0089-001 3.5 JACK
PW101 QUB112-14PPPP SIN TWIST WIRE
PW102 QUB116-16PPPP PIN WIRE
PW103 QUB112-26PPPP SIN TWIST WIRE
PW104 QUB111-30PPPP SIN TWIST WIRE
PW105 QUB116-30PPPP SIN TWIST WIRE



RY202 QSK0142-001 RELAY



RY203 QSK0109-001 RELAY
TA201 QNZ0079-001Z TAB
TA202 QNZ0079-001Z TAB

DSP board



Symbol No.

IC601 NJM4565M-WE IC
IC602 NJM4565M-WE IC
IC611 NJM4565M-WE IC
IC612 NJM4565M-WE IC
IC613 NJM4565M-WE IC
IC615 NJM4565M-WE IC
IC621 NJM4565M-WE IC
IC622 NJM4565M-WE IC
IC631 NJM2120M-X IC
IC632 NJM4565M-WE IC
IC633 NJM4565M-WE IC
IC634 NJM4565M-WE IC
IC661 DSPA56370AF IC
IC662 SN74LVC1GU04K-X IC
IC667 CS42518-CQZ-C-X IC(DIGITAL)
IC671 UPD784217AGC257 IC(FLASH MICOM)
IC672 SN74AHCT1G32K-X IC
IC673 SN74LVC1G04K-X IC
IC691 BA3259HFP-W IC

Q2101 2SD2114K/VW/-X TRANSISTOR
Q2102 2SD2114K/VW/-X TRANSISTOR
Q2141 2SD601A/RS/-X TRANSISTOR
Q2142 2SD601A/RS/-X TRANSISTOR
Q2201 2SD2114K/VW/-X TRANSISTOR
Q2202 2SD2114K/VW/-X TRANSISTOR
Q2221 2SD2114K/VW/-X TRANSISTOR
Q2222 2SD2114K/VW/-X TRANSISTOR
Q2301 2SD2114K/VW/-X TRANSISTOR
Q2341 2SD601A/RS/-X TRANSISTOR
Q2401 2SD2114K/VW/-X TRANSISTOR
Q2421 2SD2114K/VW/-X TRANSISTOR
Q2701 UN2214-X TRANSISTOR
Q2702 UN2214-X TRANSISTOR
Q2703 UN2214-X TRANSISTOR
Q2704 UN2114-X TRANSISTOR
Q2705 UN2114-X TRANSISTOR
Q2706 UN2114-X TRANSISTOR
Q2708 UN2114-X TRANSISTOR
Q2709 UN2114-X TRANSISTOR
Q2710 UN2214-X TRANSISTOR

Part No. Part Name Description Local

Block No. [0][4][0][0]

C2001 QETN1EM-475Z E CAPACITOR 4.7uF 25V M
C2002 QETN1EM-475Z E CAPACITOR 4.7uF 25V M
C2005 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2006 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2009 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2010 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2013 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2014 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2018 QETN1AM-476Z E CAPACITOR 47uF 10V M
C2019 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2020 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2101 NCB31HK-332X C CAPACITOR 3300pF 50V K
C2102 NCB31HK-332X C CAPACITOR 3300pF 50V K
C2109 QETN1HM-226Z E CAPACITOR 22uF 50V M
C2110 QETN1HM-226Z E CAPACITOR 22uF 50V M
C2111 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2112 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2113 NCB31HK-102X C CAPACITOR 1000pF 50V K
C2114 NCB31HK-102X C CAPACITOR 1000pF 50V K
C2115 NCB31HK-822X C CAPACITOR 8200pF 50V K
C2116 NCB31HK-822X C CAPACITOR 8200pF 50V K
C2129 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2131 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2132 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2133 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2134 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2139 QETN1EM-475Z E CAPACITOR 4.7uF 25V M
C2140 QETN1EM-475Z E CAPACITOR 4.7uF 25V M
C2141 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2142 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2143 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2144 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2149 QETN1EM-475Z E CAPACITOR 4.7uF 25V M
C2150 QETN1EM-475Z E CAPACITOR 4.7uF 25V M
C2181 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2182 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2183 NCB31HK-681X C CAPACITOR 680pF 50V K
C2184 NCB31HK-681X C CAPACITOR 680pF 50V K
C2185 NCB31HK-681X C CAPACITOR 680pF 50V K
C2186 NCB31HK-681X C CAPACITOR 680pF 50V K
C2187 NCB31HK-682X C CAPACITOR 6800pF 50V K
C2188 NCB31HK-682X C CAPACITOR 6800pF 50V K
C2201 NCB31HK-182X C CAPACITOR 1800pF 50V K
C2202 NCB31HK-182X C CAPACITOR 1800pF 50V K
C2209 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C2210 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C2229 QETN1HM-105Z E CAPACITOR 1uF 50V M
C2230 QETN1HM-105Z E CAPACITOR 1uF 50V M
C2241 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2242 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2243 NCB31HK-562X C CAPACITOR 5600pF 50V K
C2244 NCB31HK-562X C CAPACITOR 5600pF 50V K
C2245 NCB31HK-182X C CAPACITOR 1800pF 50V K
C2246 NCB31HK-182X C CAPACITOR 1800pF 50V K
C2249 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C2250 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C2281 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2282 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2283 NCB31HK-471X C CAPACITOR 470pF 50V K
C2284 NCB31HK-471X C CAPACITOR 470pF 50V K
C2285 NCB31HK-471X C CAPACITOR 470pF 50V K
C2286 NCB31HK-471X C CAPACITOR 470pF 50V K
C2287 NCB31HK-682X C CAPACITOR 6800pF 50V K
C2288 NCB31HK-682X C CAPACITOR 6800pF 50V K
C2301 NCB31HK-272X C CAPACITOR 2700pF 50V K
C2309 QETN1HM-226Z E CAPACITOR 22uF 50V M
C2323 NCB31HK-562X C CAPACITOR 5600pF 50V K
C2325 NCB31HK-182X C CAPACITOR 1800pF 50V K
C2341 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2342 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2343 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2349 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C2381 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2382 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2383 NCB31HK-681X C CAPACITOR 680pF 50V K
C2385 NCB31HK-681X C CAPACITOR 680pF 50V K
C2387 NCB31HK-682X C CAPACITOR 6800pF 50V K
C2401 NCB31HK-561X C CAPACITOR 560pF 50V K

3-10



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

C2409 QETN1HM-226Z E CAPACITOR 22uF 50V M
C2411 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2412 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2421 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2422 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2423 NCB31CK-823X C CAPACITOR 0.082uF 16V K
C2425 QFN31HJ-333Z M CAPACITOR 0.033uF 50V J
C2429 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2433 NCB31CK-823X C CAPACITOR 0.082uF 16V K
C2435 QFN31HJ-333Z M CAPACITOR 0.033uF 50V J
C2449 QETN1EM-475Z E CAPACITOR 4.7uF 25V M
C2483 NCB31HK-471X C CAPACITOR 470pF 50V K
C2485 NCB31HK-471X C CAPACITOR 470pF 50V K
C2487 NCB31HK-332X C CAPACITOR 3300pF 50V K
C2601 QETN0JM-107Z E CAPACITOR 100uF 6.3V M
C2606 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2607 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2608 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2611 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2612 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2613 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2614 NCB31HK-102X C CAPACITOR 1000pF 50V K
C2621 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2622 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2623 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2631 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2632 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2633 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2641 NDC31HJ-100X C CAPACITOR 10pF 50V J
C2642 NDC31HJ-100X C CAPACITOR 10pF 50V J
C2643 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2671 QETN1CM-106Z E CAPACITOR 10uF 16V M
C2672 QETN1CM-106Z E CAPACITOR 10uF 16V M
C2673 QETN1CM-106Z E CAPACITOR 10uF 16V M
C2674 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2675 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2676 NCB31HK-221X C CAPACITOR 220pF 50V K
C2677 NCB31HK-221X C CAPACITOR 220pF 50V K
C2678 QETN1EM-475Z E CAPACITOR 4.7uF 25V M
C2679 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2680 QETN0JM-107Z E CAPACITOR 100uF 6.3V M
C2681 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2682 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2683 NCB31CK-223X C CAPACITOR 0.022uF 16V K
C2684 NCB31HK-102X C CAPACITOR 1000pF 50V K
C2685 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2686 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2687 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2688 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C2689 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C2690 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C2691 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C2692 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C2701 QETN0JM-107Z E CAPACITOR 100uF 6.3V M
C2702 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C2703 NDC31HJ-101X C CAPACITOR 100pF 50V J
C2721 NDC31HJ-101X C CAPACITOR 100pF 50V J
C2731 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2751 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2771 QETN1AM-476Z E CAPACITOR 47uF 10V M
C2861 NDC31HJ-101X C CAPACITOR 100pF 50V J
C2862 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2871 NDC31HJ-270X C CAPACITOR 27pF 50V J
C2873 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C2881 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C2882 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C2901 QETN1CM-106Z E CAPACITOR 10uF 16V M
C2902 QETN1CM-106Z E CAPACITOR 10uF 16V M
C2903 QETN1AM-476Z E CAPACITOR 47uF 10V M
C2911 QETN0JM-227Z E CAPACITOR 220uF 6.3V M
C2912 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2921 QETN0JM-107Z E CAPACITOR 100uF 6.3V M
C2922 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2923 QETN0JM-107Z E CAPACITOR 100uF 6.3V M
C2924 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2925 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2951 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C2952 NCF31AZ-105X C CAPACITOR 1uF 10V Z

C2953 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C2954 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C2955 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C2956 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2957 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z

R2001 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R2002 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R2003 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R2004 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R2007 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R2008 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R2011 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R2012 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R2013 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R2014 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R2017 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R2018 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R2021 NRSA63J-331X MG RESISTOR 330Ω 1/16W J
R2022 NRSA63J-331X MG RESISTOR 330Ω 1/16W J
R2023 NRSA63J-331X MG RESISTOR 330
R2024 NRSA63J-331X MG RESISTOR 330
R2101 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R2102 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R2103 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R2104 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R2109 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R2110 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R2111 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R2112 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R2113 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R2114 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R2115 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R2116 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R2121 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R2122 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R2123 NRSA63J-243X MG RESISTOR 24kΩ 1/16W J
R2128 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R2129 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R2130 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R2131 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R2132 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R2133 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J
R2134 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J
R2135 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R2136 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R2137 NRSA63J-912X MG RESISTOR 9.1kΩ 1/16W J
R2138 NRSA63J-912X MG RESISTOR 9.1kΩ 1/16W J
R2139 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R2140 NRSA63J-104X MG RESISTOR 100k
R2141 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R2142 NRSA63J-103X MG RESISTOR 10k
R2143 NRSA63J-683X MG RESISTOR 68k
R2144 NRSA63J-683X MG RESISTOR 68kΩ 1/16W J
R2145 NRSA63J-562X MG RESISTOR 5.6k
R2146 NRSA63J-562X MG RESISTOR 5.6k
R2147 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R2148 NRSA63J-103X MG RESISTOR 10k
R2149 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R2150 NRSA63J-104X MG RESISTOR 100k
R2181 NRSA63J-472X MG RESISTOR 4.7k
R2182 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R2183 NRSA63J-181X MG RESISTOR 180
R2184 NRSA63J-181X MG RESISTOR 180
R2185 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R2186 NRSA63J-472X MG RESISTOR 4.7k
R2187 NRSA63J-181X MG RESISTOR 180
R2188 NRSA63J-181X MG RESISTOR 180
R2189 NRSA63J-472X MG RESISTOR 4.7k
R2190 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R2191 NRSA63J-472X MG RESISTOR 4.7k
R2192 NRSA63J-472X MG RESISTOR 4.7k
R2201 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R2202 NRSA63J-103X MG RESISTOR 10k
R2203 NRSA63J-102X MG RESISTOR 1k
R2204 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R2209 NRSA63J-104X MG RESISTOR 100k
R2210 NRSA63J-104X MG RESISTOR 100k

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

3-11



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

R2221 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J
R2222 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J
R2223 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R2224 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R2241 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R2242 NRSA63J-102X MG RESISTOR 1k
R2243 NRSA63J-102X MG RESISTOR 1k
R2244 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R2249 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R2250 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R2281 NRSA63J-752X MG RESISTOR 7.5kΩ 1/16W J
R2282 NRSA63J-752X MG RESISTOR 7.5kΩ 1/16W J
R2283 NRSA63J-181X MG RESISTOR 180Ω 1/16W J
R2284 NRSA63J-181X MG RESISTOR 180Ω 1/16W J
R2285 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R2286 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R2287 NRSA63J-181X MG RESISTOR 180Ω 1/16W J
R2288 NRSA63J-181X MG RESISTOR 180Ω 1/16W J
R2289 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R2290 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R2291 NRSA63J-752X MG RESISTOR 7.5k
R2292 NRSA63J-752X MG RESISTOR 7.5k
R2301 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R2303 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R2309 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R2321 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R2323 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R2341 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R2343 NRSA63J-753X MG RESISTOR 75kΩ 1/16W J
R2345 NRSA63J-303X MG RESISTOR 30kΩ 1/16W J
R2347 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R2349 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R2381 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R2383 NRSA63J-181X MG RESISTOR 180Ω 1/16W J
R2385 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R2387 NRSA63J-181X MG RESISTOR 180Ω 1/16W J
R2389 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R2391 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R2401 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R2403 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R2409 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R2411 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R2412 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R2421 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R2422 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R2423 NRSA63J-100X MG RESISTOR 10Ω 1/16W J
R2424 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R2425 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R2433 NRSA63J-100X MG RESISTOR 10Ω 1/16W J
R2434 NRSA63J-103X MG RESISTOR 10k
R2435 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R2449 NRSA63J-104X MG RESISTOR 100k
R2481 NRSA63J-183X MG RESISTOR 18k
R2483 NRSA63J-181X MG RESISTOR 180Ω 1/16W J
R2485 NRSA63J-472X MG RESISTOR 4.7k
R2487 NRSA63J-181X MG RESISTOR 180
R2489 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R2491 NRSA63J-183X MG RESISTOR 18k
R2601 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R2602 NRSA63J-221X MG RESISTOR 220
R2603 NRSA63J-221X MG RESISTOR 220
R2604 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R2605 NRSA63J-102X MG RESISTOR 1k
R2606 NRSA63J-102X MG RESISTOR 1k
R2607 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R2608 NRSA63J-102X MG RESISTOR 1k
R2611 NRSA63J-103X MG RESISTOR 10k
R2613 NRSA63J-102X MG RESISTOR 1k
R2614 NRSA63J-102X MG RESISTOR 1k
R2621 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R2622 NRSA63J-103X MG RESISTOR 10k
R2623 NRSA63J-103X MG RESISTOR 10k
R2624 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R2625 NRSA63J-103X MG RESISTOR 10k
R2626 NRSA63J-105X MG RESISTOR 1M
R2627 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R2628 NRSA63J-102X MG RESISTOR 1k
R2631 NRSA63J-103X MG RESISTOR 10k

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

R2632 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R2633 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R2634 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R2635 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R2636 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R2637 NRSA63J-103X MG RESISTOR 10k
R2638 NRSA63J-103X MG RESISTOR 10k
R2639 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R2640 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R2641 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R2642 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R2647 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R2671 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R2673 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R2681 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R2682 NRSA63J-331X MG RESISTOR 330Ω 1/16W J
R2683 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R2684 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R2685 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R2686 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R2687 NRSA63J-221X MG RESISTOR 220
R2688 NRSA63J-221X MG RESISTOR 220
R2705 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J
R2706 NRSA63J-432X MG RESISTOR 4.3kΩ 1/16W J
R2707 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R2711 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R2713 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R2714 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R2715 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R2716 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R2721 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R2722 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R2723 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R2724 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J
R2725 NRSA63J-432X MG RESISTOR 4.3kΩ 1/16W J
R2726 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J
R2727 NRSA63J-432X MG RESISTOR 4.3kΩ 1/16W J
R2728 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R2731 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R2732 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R2733 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R2734 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R2735 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R2736 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R2738 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R2739 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R2743 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R2744 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R2745 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R2751 NRSA63J-102X MG RESISTOR 1k
R2752 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R2761 NRSA63J-105X MG RESISTOR 1M
R2762 NRSA63J-105X MG RESISTOR 1M
R2763 NRSA63J-105X MG RESISTOR 1MΩ 1/16W J
R2771 NRSA63J-102X MG RESISTOR 1k
R2772 NRSA63J-105X MG RESISTOR 1M
R2773 NRSA63J-105X MG RESISTOR 1MΩ 1/16W J
R2861 NRSA63J-221X MG RESISTOR 220
R2862 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J
R2871 NRSA63J-750X MG RESISTOR 75
R2872 NRSA63J-102X MG RESISTOR 1k
R2921 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J
R2922 NRSA63J-112X MG RESISTOR 1.1k

CN671 QGF1205C1-06 CONNECTOR FFC/FPC (1-6)
CN681 QGB2510K1-07 CONNECTOR B-B (1-7)
CN683 QGB2510K1-14 CONNECTOR B-B (1-14)
EP681 E409182-001SM GRAND TERMINAL
J681 QNN0481-001 SURROUND JACK
K2861 NQR0269-004X FERRITE BEADS
UN682 GP1FA553RZ OPT RECEIVER
X661 QAX0722-001Z CRYSTAL 24.576MHz
X671 QAX0719-001Z C RESONATOR 6.144MHz

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

3-12

Packing materials and accessories parts list

Block No.

A1

A2

M

3

M

M

P2

P4

2/2

P6

A3 A4 A5
A6 A7

P3

2/2

P4

P2

1/2

P3

1/2

P5

Packing and Accessories

Block No. [M][3][M][M]



Symbol No.

A 1 RM-SRX5040R REMOCON
A 2 LV30256-014A SHEET
A 3 ------------ BATTERY (x2)
A 4 LVT1140-008A INST BOOK GER FRE DUT
A 5 EWP503-001C ANT.WIRE
A 6 QAL0014-001 AM LOOP ANT
A 7 BT-54013-7 WARRANTY CARD
P 1 LV21650-003A CARTON BOX
P 2 LV32034-009A SHEET (x2)

Part No. Part Name Description Local

P1



Symbol No.

P 3 LV21634-003A CUSHION
P 4 LV21635-002A CUSHION
P 5 QPC06507015P POLY BAG 65cm x 70cm
P 6 QPA02503505P POLY BAG 25cm x 35cm

Part No. Part Name Description Local

3-13
