OWNER’S MANUAL GUIDE D’UTILISATION

19” CLASS WIDE LED TV WITH DVD PLAYER TÉLÉVISEUR DEL GRAND ÉCRAN CATÉGORIE 19 PO ET LECTEUR DVD

LT-19D610

If you purchase a universal remote control from your local retailer, please contact the remote manufacturer for the required programming code. Si vous utilisez avec cet appareil une télécommande universelle (autre que celle vendue avec ce téléviseur), consultez la documentation accompagnant la télécommande universelle afin de connaître le code numérique correspondant au téléviseur.

(19” classe/18,50 diagonale)

ATTENTION ATTENTION

(19” class/18.50 diagonal)

FRANÇAIS ENGLISH

AIR/CABLE MODE SELECTION

When shipped from the factory, the Signal Type option is set to the “Cable” (Cable Television) mode. If not using Cable TV, set this menu option to the “Air” position. Lorsque l’appareil sort de l’usine, l’option « Signal Type » est en mode « Cable » (câblodistribution). Si vous n’utilisez pas la câblodistribution, sélectionnez l’option « Air ».

Before operating the unit, please read this manual thoroughly.

Avant de faire fonctionner l’appareil, veuillez lire le présent guide attentivement.

SÉLECTION DU MODE AIR/CABLE

ENGLISH

The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock.

CAUTION: TO REDUCE THE RISK OF ELECTRIC

SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN

TO PREVENT THE SPREAD OF FIRE, KEEP CANDLES OR OPEN FLAMES AWAY

OR MOISTURE.

FROM THIS PRODUCT AT TIMES.

CAUTION: TO PREVENT ELECTRIC SHOCK, DO NOT USE THIS POLARIZED PLUG WITH AN

EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE.

WARNING: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

CAUTION: Changes or modifications not expressly approved by the partly responsible for compliance with the FCC Rules

CAUTION:

THIS DIGITAL VIDEO PLAYER EMPLOYS A LASER SYSTEM. TO ENSURE PROPER USE OF THIS PRODUCT, PLEASE

READ THIS OWNER'S MANUAL CAREFULLY AND RETAIN FOR FUTURE REFERENCE. SHOULD THE UNIT REQUIRE MAINTENANCE, CONTACT AN AUTHORIZED SERVICE LOCATION-SEE SERVICE PROCEDURE.

USE OF CONTROLS, ADJUSTMENTS OR THE PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

TO PREVENT DIRECT EXPOSURE TO THE LASER BEAM, DO NOT TRY TO OPEN THE ENCLOSURE. RADIATION MAY BE PRESENT WHEN THE ENCLOSURE IS OPENED. DO NOT STARE INTO THE BEAM.

to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

could void the user’s authority to operate this equipment.

CLASS 1 LASER PRODUCT

Location of the required Marking

The rating sheet and the safety caution are on the rear of the unit.

CERTIFICATION: COMPLIES WITH FDA RADIATION PERFORMANCE STANDARDS, 21 CFR SUBCHAPTER J.

Complies with FDA performance standards for laser products except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007.

Important Note:

In the spaces below, enter the model and serial number of your television (located at the rear of the television cabinet). Staple your sales receipt or invoice to the inside cover of this guide. Keep this user’s guide in a convenient place for future reference. Keep the carton and original packaging for future use.

Serial number _______________________________ Model number ______________________________

15) Apparatus should not be exposed to dripping or splashing, and objects filled with liquids, such

NEC-NATIONAL

as vases, should not be placed on the apparatus.

16) An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits, as contact with them might be fatal.

17) Do not overload wall outlets and extension cords, as this can result in a risk of fire or electric shock.

18) Do not push objects through any openings in this unit, as they may touch dangerous voltage points or short out parts that could result in fire or electric shock. Never spill or spray any type of liquid into the unit.

19) If an outside antenna or cable system is connected to the unit, be sure the antenna or cable system is grounded to provide some protection against voltage surges and built-up static charges, Section 810 of the National Electrical Code, ANSI/NFPA 70, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection to

ELECTRICAL CODE S2898A

EXAMPLE OF ANTENNA GROUNDING AS PER THE

NATIONAL ELECTRICAL CODE

GROUND

CLAMP

ELECTRIC SERVICE

EQUIPMENT

ANTENNA LEAD IN WIRE

ANTENNA DISCHARGE UNIT (NEC SECTION 810-20) GROUNDING CONDUCTORS (NEC SECTION 810-21)

GROUND CLAMPS POWER SERVICE GROUNDING

ELECTRODE SYSTEM (NEC ART 250, PART H)

grounding electrodes, and requirements for the grounding electrode.

20) When replacement parts are required, be sure the service technician uses replacement parts specified by the manufacturer or those that have the same characteristics as the original part.

Unauthorized substitutions may result in fire, electric shock or other hazards.

21) Upon completion of any service or repairs to this unit, ask the service technician to perform safety checks to determine that the unit is in proper operating condition.

22) Keep your fingers clear of the disc slot as it is closing. It may cause injury.

ENGLISH

IMPORTANT SAFETY INSTRUCTIONS (continued)

23) When you connect the product to other equipment, turn off the power and unplug all of the equipment from the wall outlet. Failure to do so may cause an electric shock and serious personal injury. Read the owner's manual of the other equipment carefully and follow the instructions when making any connections.

24) Reduce the volume to the minimum level before you turn on the product. Otherwise, sudden high volume sound may cause hearing or speaker damage.

25) Do not allow the product to output distorted sound for an extended period of time. It may cause speaker overheating and fire.

26) When you use the headphones, keep the volume at a moderate level. If you use the headphones continuously with high volume sound, it may cause hearing damage.

27) Do not look into the opening of the disc slot or ventilation opening of the product to see the source of the laser beam. It may cause eye damage.

28) Do not use a cracked, deformed, or repaired disc. These discs are easily broken and may cause serious personal injury and product malfunction.

29) This reminder is provided to call the cable TV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.

30) The socket-outlet must be installed near the unit and easily accessible.

CONDENSATION

Moisture will form in the operating section of the player if the player is brought from cool surroundings into a warm room or if the temperature of the room rises suddenly. When this happens, player's performance will be impaired. To prevent this, let the player stand in its new surroundings for about an hour before switching it on, or make sure that the room temperature rises gradually. Condensation may also form during the summer if the player is exposed to the breeze from an air conditioner. In such cases, change the location of the player.

HOW TO HANDLE THE LCD PANEL

Do not press hard or jolt the LCD panel. It may cause the LCD panel glass to break and injury may occur.

•

If the LCD panel is broken, make absolutely sure that you do not touch the liquid in the panel. This may cause

•

skin inflammation. If the liquid gets in your mouth, immediately gargle and consult with your doctor. Also, if the liquid gets in your eyes or touches your skin, consult with your doctor after rinsing for at least 15 minutes or longer in clean water.

CHILD SAFETY: It Makes A Difference How and Where You Use Your Flat Panel Display

Congratulations on your purchase! As you enjoy your new product, please keep these safety tips in mind:

THE ISSUE

The home theater entertainment experience is a growing trend and larger flat panel displays are popular purchases. However, flat panel displays are not always supported on the proper stands or installed according to the manufacturer’s recommendations. Flat panel displays that are inappropriately situated on dressers, bookcases, shelves, desks, speakers, chests or carts may fall over and cause injury.

THIS MANUFACTURER CARES!

The consumer electronics industry is committed to making home entertainment enjoyable and safe.

TUNE INTO SAFETY

One size does NOT fit all. Follow the manufacturer’s recommendations for the safe installation and use of your flat panel display. Carefully read and understand all enclosed instructions for proper use of this product. Don’t allow children to climb on or play with furniture and television sets. Don’t place flat panel displays on furniture that can easily be used as steps, such as a chest of drawers. Remember that children can become excited while watching a program, especially on a “larger than life” flat panel display. Care should be taken to place or install the display where it cannot be pushed, pulled over, or knocked down. Care should be taken to route all cords and cables connected to the flat panel display so that they cannot be pulled or grabbed by curious children.

WALL MOUNTING: IF YOU DECIDE TO WALL MOUNT YOUR FLAT PANEL DISPLAY, ALWAYS:

Use a mount that has been recommended by the display manufacturer and/or listed by an independent laboratory (such as UL, CSA, ETL). Follow all instructions supplied by the display and wall mount manufacturers. If you have any doubts about your ability to safely install your flat panel display, contact your retailer about professional installation. Make sure that the wall where you are mounting the display is appropriate to support the weight of the unit/ product and wall mount. If you are unsure, contact a professional installer. A minimum of two people are required for installation. Flat panel displays can be heavy.

SAFETY PRECAUTIONS

The unit emits heat when in operation. Do not place any covers or blankets on the unit, this may cause overheating. Do not block ventilation holes, or set up near radiators. Do not place in direct sunshine. When placing on a shelf leave 10 cm (4 inches) free space around the entire unit.

10cm

Notes when mounting the LCD TV/DVD on a wall

If the unit is to be mounted on the wall, contact the retailer where you purchased the LCD TV/DVD for advice, and have the equipment professionally installed. Incomplete or improper installation may cause injury to you, and/or damage to the LCD TV/DVD.

To hang the television on a wall, remove these screws and then remove a stand. Before performing work spread cushioning over the base area to lay the TV on.

IMPORTANT NOTICE

Possible Adverse Effects on LCD Panel: If a fixed (non-moving) pattern remains on the LCD Panel for

long periods of time, the image can become permanently engrained in the LCD Panel and cause subtle but permanent ghost images. This type of damage is NOT COVERED BY YOUR WARRANTY. Never leave your LCD Panel on for long periods of time while it is displaying the following formats or images:

•

Fixed Images, such as stock tickers, video game patterns, TV station logos, and websites.

•

Special Formats that do not use the entire screen. For example, viewing letterbox style (16:9) media on a normal (4:3) display (black bars at top and bottom of screen); or viewing normal style (4:3) media on a widescreen (16:9) display (black bars on left and right sides of screen).

ENGLISH

The following symptoms are not signs of malfunction but technical limitation. Therefore we disclaim any responsibility for these symptoms.

•

LCD Panels are manufactured using an extremely high level of precision technology, however sometimes parts of the screen may be missing picture elements or have luminous spots.

This is not a sign of a malfunction.

•

Do not install the LCD Panel near electronic equipment that produces electromagnetic waves. Some equipment placed too near this unit may cause interference.

•

Effect on infrared devices – There may be interference while using infrared devices such as infrared cordless headphones.

How to attach the stand

NOTE:

• Unplug the AC cord from the AC INPUT terminal.

• Before beginning this process, assure that TV is laid on a clean, safe, and cushioned space to avoid any

damage to the unit.

• Do not touch or press the TV-screen, glass might break under pressure.

Place the TV on its back onto a table. Align the stand’s bottom-plate (supplied) as seen here. It will ﬁ t in only one direction. Hold the unit and attach the stand slowly, as shown in Figure 1.

LCD PANEL SIDE

Fig. 1

Fig. 2

Finally secure the bottom-plate with 2 screws (supplied) as indicated by the arrows in Figure 2.

Be sure to follow the instructions. Incorrect installation of the stand will not support your unit correctly, and

•

could result in damage or injury.

How to remove the stand

When you transport this product, remove the stand and pack ﬂ at against the back of the unit in the carton. To remove the stand, perform these steps in reverse order.

For wall mounting, the base must be removed. To disconnect the base/stand remove the two (2) screws from the back (see page 5).

Features

•

LED Backlight System - It realize thin profile, low power consumption, eco-friendly Hg-less design and high

contrast picture.

LCD color TV With DVD/CD player

Unique space saving design combines a 19” LCD color TV and a DVD/CD player. A DVD disc has much more capacity, but is the same size as an audio CD disc. The Picture/Audio quality of a DVD exceeds other software. The picture quality is higher than Super VHS video cassettes. The audio quality is higher than an audio CD. The DVD also has special options; audio language selection, subtitle language selection, or multi-angle, etc. The DVD PLAYER can play back both audio CDs and MP3/WMA/JPEG CDs. LED Backlight System - It realize thin profile, low power consumption, eco-friendly Hg-less design and high contrast picture.

Compatible with a wide range of DVD audio outputs

Digital Audio Jack (Coaxial)

•

When a component with a built-in Dolby Digital decoder is connected, Dolby Digital sound can produce the effect of being in a movie theater or a concert hall.

•

Surround standard is different from Dolby Digital. This format is already in use in many theaters. By connecting this unit to a DTS decoder or an AV amplifier with a built-in DTS decoder, the DTS audio of DVD discs recorded in this format can be enjoyed. However, audio will not be output from the analog audio output jacks.

•

By connecting this unit to an AV amplifier with a built-in MPEG decoder, the MPEG audio of DVD discs recorded in this format can be enjoyed.

•

The Linear PCM sound of a 48 kHz/24 bit through 96 kHz/24 bit exceeds audio CD sound.

Convenience Features

Direct selection of your desired scenes using Title/Chapter/Time/Track - You can play back from the

desired scene.

Recalling Up to 12 Scenes Frame Advance - The PAUSE/STILL and SEARCH moves one frame at a time. Slow Motion - The SLOW moves you back and forth through the program by 4 steps of 1/16-1/2 times. Repeat Playback - You can repeat chapter, track, title, sides or material between two selected points. Program Playback (Audio CD/MP3/WMA) - You can play back tracks in programmed sequences. Zoom - You can zoom in the selected subject on the screen during playback.

Note: Make sure that discs are suitable for the following functions. Multi-Language - Maximum 32 language subtitles and maximum 8 language soundtracks can be played back

for movies or programs. Multi-Angle - Pictures of Sports or a Live Concert are recorded with many cameras. When you play such a disc, you can change the angles during playback. Parental Control - You can limit the play back of scenes or sounds of DVD discs that have a rating level encoded on the disc.

Video Aspect Ratio - You can change the aspect ratio of the screen for your monitor.

TV Features

Integrated Digital Tuner - You can view digital broadcasts without using a Digital TV Set-Top Box. Closed Caption Decoder With Full Text Mode - Displays text captions or full screen text on the screen for

hearing impaired viewers. Picture Adjustments Using The Remote Control - The On-Screen display allows precise remote control adjustment of BRIGHTNESS, CONTRAST, COLOR, TINT and SHARPNESS. Programmable TV Sleep Timer - Operable from the remote control, the TV can be programmed for up to 120 minutes to turn off automatically. On-Screen 3 Language Display - You can select one of 3 languages, English, Spanish or French for onscreen programming. V-Chip - The V-Chip function can read the rating of a TV program or movie content if the program is encoded with this information. V-Chip will allow you to set a restriction level.

* This product incorporates copy protection technology that is protected by U.S. and other intellectual

property rights. The use of Rovi Corporation’s copy protection technology in the product must be authorized by Rovi Corporation. Reverse engineering or disassembly is prohibited.

is a trademark of DVD Format/Logo Licensing Corporation.

* Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of

Dolby Laboratories.

* Manufactured under license under U.S. Patent #: 5,451,942 & other U.S. and worldwide patents issued

* HDMI, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or registered trademarks

of HDMI Licensing LLC in the United States and other countries.

You can program up to 12 scenes in memory and recall the marked scenes.

ENGLISH

Before using your unit

IMPORTANT SAFETY INSTRUCTIONS ...........3

SAFETY PRECAUTIONS .................................5

IMPORTANT NOTICE .......................................5

How to attach the stand ....................................6

How to remove the stand ..................................6

Features ............................................................7

Contents ...........................................................8

Disc...................................................................9

Location of controls .........................................11

Remote control ...............................................12

Power source ..................................................13

Antenna connections ......................................14

Cable TV connections ..................................... 14

TV operation

Starting setup .................................................15

TV operation ...................................................15

Quick guide for menu operation ......................16

Convenience functions ...................................17

Memorizing channels ......................................18

Checking the digital signal strength ................19

Labeling channels ...........................................19

Labeling video inputs ......................................19

Setting the V-Chip ...........................................20

Closed Caption ...............................................21

CC advanced ..................................................21

Setting the picture size .................................... 22

DVD operation

Preparation .....................................................23

Status display of disc ......................................23

Playback procedure ........................................23

Special playback ............................................. 24

Zooming ..........................................................24

Locating desired scene ...................................24

A-B Repeat playback ......................................24

Marking desired scenes ..................................25

Changing angles .............................................25

Changing soundtrack language ......................25

Subtitles .......................................................... 25

Using HOME MENU .......................................26

Play mode .......................................................26

Audio Settings menu ....................................... 27

Video Adjust menu .......................................... 28

Quick guide for DVD menu operation ..............28

Function Setup ................................................29

Parental Control ..............................................30

Additional information

Language Code List ........................................ 31

Country/Area Code List ..................................31

Connections to other equipment .....................32

Reception disturbances ..................................35

Problems and troubleshooting ........................36

Specifications ................................................38

LIMITED WARRANTY .................................... 39

Disc

Playable discs

Disc type and logo mark content

Audio

DVD Video

CD-DA

The following discs are also available.

DVD-R/RW discs of DVD video format and MP3/

• WMA/JPEG. CD-R/RW discs of MP3/WMA/JPEG.

•

Video

(moving

pictures)

Audio

CAUTION:

•

Only the left types of discs can be played on this unit. DVD-ROM, CD-ROM, SVCD, CVD, VCD, etc. cannot be played.

•

8cm discs can be played directly. If an 8cm disc adapter is used it will cause errors.

•

If you insert an irregular shaped disc, it may get stuck and cause a malfunction.

•

The use of a ring protector or other disc accessories will cause errors.

•

This unit is to be used exclusively with the NTSC color system. PAL and SECAM system discs cannot be used with this unit.

•

Some CD-R/RWs and DVD-R/RW cannot be played back depending on the recording conditions.

Region Number

Region number (Regional restriction code) is built-in to the unit and DVD video discs. Region number “1” or “ALL” of DVD video discs can be used on this unit.

Title

When two or more movies are recorded on a disc, the disc is divided into two or more sections. Each section is called a “TITLE”.

TITLE 1 TITLE 2

CHAPTER 1

DVD DISC

CHAPTER 2 CHAPTER 2 CHAPTER 3CHAPTER 1

Chapter

The titles can be subdivided into many sections. Each section is called a “CHAPTER”.

Track

An Audio CD can contain several items. These are assigned to the tracks.

TRACK 1 TRACK 2 TRACK 3 TRACK 4 TRACK 5

Audio - CD

ENGLISH

ALL

Removing Disc from Case

Be sure to hold the edge of disc. Do not touch the surface of the disc. Pick up the disc gently from the case.

•

Do not scratch the disc.

•

Do not get dirt on the surface of the disc.

•

Do not stick a label or adhesive tape on the disc.

•

Do not drop or bend the disc.

Storing Disc

•

Store the disc in the case to avoid risk of scratches, dirt or damage.

•

Do not leave disc exposed to direct sunlight or in hot or humid places.

Cleaning Disc

Wipe the disc with a clean, dry cloth from center to edge.

•

Do not wipe the disc in a circular motion.

•

Do not use liquid or aerosol cleaners.

Disc (continued)

■ Title/Chapter/Track PC-created disc

• You may not be able to play discs recorded using a personal computer or recorder for disc compatibilities, scratches or marks on the disc, dirty lenses of the unit or condensation and so on.

• Discs recorded using a personal computer may not be playable in this unit due to the setting of the application software used to create the disc. In these particular instances, check with the software publisher for more detailed information.

■ Playable files

• ISO 9660 Level 1 or 2 compliant.

Romeo and Joliet file systems are both compatible

with this player.

• DRM (Digital Rights Management) protected files will not play in this player.

For detailed information, please see the instruction

manuals or help files that came with your PC and/or software.

• File structure (may differ): Up to 299 folders on a disc; up to 648 files within each folder

• Folder and file names can be displayed as long as they are typed in alphabets and numbers. If folder and file names are other than alphabets and numbers, they may be replaced and displayed like as “_”. Garbled characters may also be displayed in this case.

■ Playing image files

JPEG files recorded in DVD-R/-RW and CD-R/-RW can be played.

■ JPEG file compatibility

• Image files should be saved in JPEG format.

• Files recorded in Fuji Colour CD, Kodak Picture CD or CD-R/-RW can be played.

• Compatible formats: Baseline JPEG and EXIF 2.2* still image files up to a resolution of 3072 x 2048.

*File format used by digital still cameras.

• Files with extensions .jpg or .JPG can be played.

• Progressive JPEG formatted files do not work.

• It may take some more time to start to play larger files than usual.

• JPEG files with different aspect ratio may be displayed with black bands (either vertical or horizontal).

■ Windows Media Audio (WMA) compatibility

• WMA is an acronym for Windows Media Audio and refers to an audio compression technology developed by Microsoft Corporation.

• You can encode your files by using Windows Media Player Ver.7, 7.1, Windows Media Player for Windows XP or Windows Media Player 9 Series.

• When encoding your files, use only applications approved by Microsoft Corporation. If you use nonapproved application, it may not work properly.

• This unit is compatible with audio files recorded with the following sampling frequency: 32 kHz, 44.1 kHz and 48 kHz.

• It is not compatible with loss-less encoding.

• Files with extensions .wma or .WMA can be played.

■ Playing MP3 (MPEG-1 Audio Layer-3) files

• This unit is compatible with audio files recorded with the following sampling frequency: 32 kHz, 44.1 kHz and 48 kHz.

• Files with extensions .mp3 or .MP3 can be played.

• For the best quality of sound, 128 kbps or higher bit rate is recommended.

■ Copy Control CD (CCCD)

This product is designed to conform to CD-DA (Compact Disc Digital Audio). Any other discs than CD-DA are not guaranteed with their operation and performance in this product.

Note on copyright

• Unauthorized recording of copyrighted television programs, films, video cassettes and other materials may infringe the rights of copyright owners and be contrary to copyright laws.

■ Playing Audio files

WMA and MP3 files recoded in DVD-R/-RW, CD-R/RW can be played.

Left side

Location of controls

HDMI IN jack

Front

VIDEO IN jacks (VIDEO/AUDIO

(L (MONO)/R))

DIGITAL AUDIO

COAXIAL OUT jack

COMPONENT

IN jacks

(Y/Pb/Pr/ AUDIO

(L (MONO)/R))

RF (ANT.) IN jack

HEADPHONE jack

POWER indicator Red : Standby Blue : On

To display the menu screen. Touch MENU button to display the menu screen.

CH (CHANNEL) +/– buttons and INPUT/ENTER button can be used

to select the desired setting during the menu screen operations.

/ buttons,

Remote sensor

VOL (VOLUME) +/– buttons

CH (CHANNEL)

VOL (VOLUME)

/ buttons

MENU button

INPUT/ENTER button

PC/DVI AUDIO IN jack

POWER button

ENGLISH

EJECT ( ) button

) button

PLAY (

STOP (

) button

AC INPUT jack

Right side

Rear

Service connector cover: Please do not open this cover. There is a socket only for service purpose inside.

PC MONITOR IN jack

Remote control

POWER Power On/Off DISPLAY/– Call TV information

TV/DVD Switch between TV and DVD

(EJECT) Eject a disc

0-9 Direct channel selection of TV

VOL +/– Adjust volume of TV MUTING Switch off the sound SLEEP Sleep timer SETUP/

TV MENU DVD MENU Display DVD menu

CH ▲▼◀▶ Cursor buttons ENTER Enter information in the menu EXIT/

CANCEL TOP MENU Select title SEARCH Fast Forward/Review playback PLAY Playback SKIP Skip chapter to forward or reverse direction SUBTITLE Set subtitle STOP Stop SLOW Forward/Reverse- slow motion PAUSE/

STILL PLAY MODE Select playback mode AUDIO Change soundtrack language RETURN Remove DVD setup menu REPEAT A-B Repeat playback between A and B ANGLE Change playback angle SCREEN SIZE Display Picture Size menu MARKER Index CCD/

JUMP RECALL/

ZOOM INPUT SELECT Display source selection menu

Call DVD information Input “–” for digital channels

Input setting Enter a password

TV mode - Display menu of TV DVD mode - Call up initial setup mode

Select channel of TV

Exit from On-Screen menu Reset information in the menu

Pause CD sound Still picture of DVD

Closed Caption Locating desired scene

Switch between present/last channel Zoom

Remote control (continued)

Inserting Batteries

Open the battery compartment

cover in the direction of the arrow.

Operation

Aim the remote control at the remote sensor and press control

• buttons to operate. Operate the remote control within a 30° angle on either side of

• the remote sensor, up to a distance of approximately 15 feet.

NOTE:

•

Do not leave the remote control unit exposed to direct sunlight or in hot or humid places.

•

The remote control unit uses infrared beams to transmit signals, so sunlight or fluorescent light on the remote sensor may shorten operating distance. Incorrect use of batteries may cause them to leak or burst. Read the battery warnings and use the batteries

• properly. Do not mix old and new batteries.

• Do not mix alkaline, standard (carbon-zinc), or rechargeable, (ni-cad, ni-mh, etc) batteries.

• Remove batteries if the remote control will not be operated for an extended period of time.

•

If this symbol is shown, it is only valid in the European union.

Install two “AAA” batteries,

paying attention to the polarity diagram in the battery compartment.

Replace the compartment cover.

Approximately 15 feet

Power source

TO USE AC POWER

Connect the AC cord plug into this unit’s AC IN jack.

1. Connect the AC cord into an AC outlet.

ENGLISH

AC Outlet

Wider Hole and Blade

AC 120V, 60Hz

NOTE:

Please make sure to insert the cord securely at both the LCD TV/DVD and the wall outlet.

• The AC Cord has a polarized type AC line plug. If the supplied AC cord does not match your AC outlet,

• contact a qualified electrician.

WARNING:

DO NOT CONNECT THIS UNIT TO THE POWER USING ANY DEVICE OTHER THAN THE SUPPLIED AC

• CORD. THIS COULD CAUSE FIRE, ELECTRICAL SHOCK, OR DAMAGE. DO NOT USE WITH A VOLTAGE OTHER THAN THE POWER VOLTAGE SPECIFIED. THIS COULD CAUSE

• FIRE, ELECTRICAL SHOCK, OR DAMAGE.

CAUTION:

WHEN THIS UNIT IS NOT USED FOR A LONG TIME, (E.G., AWAY ON A TRIP) IN THE INTEREST OF

• SAFETY, BE SURE TO UNPLUG IT FROM THE AC OUTLET. DO NOT PLUG/UNPLUG THE AC CORD WHEN YOUR HANDS ARE WET. THIS MAY CAUSE ELECTRICAL

• SHOCK. IF YOU NEED TO REPLACE THE SUPPLIED AC ADAPTER OR AC CORD, THE SPECIFIED ONE IS

• RECOMMENDED. CONTACT CUSTOMER SERVICE AT U.S.A. 1-800-252-5722/Canada 1-800-964-2650.

AC cord (supplied)

Antenna connections

If you are using an indoor or outdoor antenna, follow the instructions below that correspond to your antenna system. If you are using a Cable TV service, see “Cable TV connections”.

Combination VHF/UHF Antenna (Single 75 ohm cable)

Antenna

Jack

75 ohm Coaxial Cable

Connect the 75 ohm cable from the combination VHF/UHF antenna to the antenna jack.

Cable TV connections

This TV has an extended tuning range and can tune most cable channels without using a Cable TV Converter box. Some cable companies offer “premium pay channels” where the signal is scrambled. Descrambling these signals for normal viewing requires the use of a descrambler device which is generally provided by the Cable TV company.

For subscribers to basic Cable TV service

75 ohm

Antenna

Jack

Coaxial Cable

For subscribers to scrambled Cable TV service

If you subscribe to a Cable TV service which requires the use of a Converter/Descrambler box, connect the incoming 75 ohm Coaxial Cable to the Converter/Descrambler box. Using another 75 ohm Coaxial Cable, connect the output jack of the Converter/Descrambler box to the Antenna Jack on the TV. Follow the connections shown below. Set the TV to the output channel of the Converter/Descrambler box (usually channel 3 or 4) and use the Converter/Descrambler box to select channels.

Incoming 75 ohm Cable TV Cable

Converter/

Descrambler

For basic Cable TV service not requiring a Converter/ Descrambler box, connect the 75 ohm Coaxial Cable directly to the Antenna Jack on the back of the TV.

Antenna

Jack

75 ohm Cable to TV

For subscribers to unscrambled Cable TV service with scrambled premium channels

If you subscribe to a Cable TV service in which basic channels are unscrambled and premium channels require the use of a Converter/Descrambler box, you may wish to use a signal Splitter and an A/B Switch box (available from the Cable TV company or an electronics supply store). Follow the connections shown below. With the switch in the “B” position, you can directly tune any nonscrambled channels on your TV. With the switch in the “A” position, tune your TV to the output of the Converter/Descrambler box (usually channel 3 or 4) and use the Converter/Descrambler box to tune scrambled channels.

Incoming 75 ohm Cable TV Cable

Splitter

Converter/

Descrambler

A/B Switch

75 ohm Cable to TV

Antenna

Jack

Starting setup

The Auto Setup menu appears the first time you turn on the TV, and assists you to specify the Air/Cable setting, and program your channels automatically.

IMPORTANT: Make sure that the antenna or cable TV system connection is made!

To turn on the TV, press POWER (POWER

indicator on the front of the unit changes blue. It may take approx. 10 seconds for a picture to appear on screen.). The starting setup function begins.

Auto Setup

Signal Type Cable

Automatic Search Start

: Adjust

: Select

Press ◀ or ▶ to select “Cable” or “Air”.

Press ▲ or ▼ to select “Automatic Search”, then

press ▶ or ENTER.

Now the “Auto Setup” starts. After the starting

setup is completed, the TV channel appears on the screen.

•

Depending on the reception condition, it may

take from 15 minutes to 30 minutes to complete memorizing digital cable channels. Please be patient.

NOTE:

If you press EXIT/CANCEL in the process of “Auto

• Setup”, the Starting Setup stops and changes to the normal screen.

When you make a menu selection, your changes

• occur immediately. You do not have to press EXIT/

CANCEL to see your changes.

TV operation

To turn on the TV, press POWER.

(POWER indicator on the front of the unit changes blue. It may take approx. 10 seconds for a picture to appear on screen.)

Adjust the volume level by pressing VOL + or – .

The volume level will be indicated on the screen by blue bars. As the volume level increases, so do the number of bars. If the volume decreases, the number of blue bars also decreases.

Set the Signal Type option to the appropriate

position (see “Air/Cable selection” on page 18). Press the Direct Channel Selection (0-9, –)

buttons to select the channel. (If you press only channel number, channel selection will be delayed for a few seconds.)

TO SELECT ANALOG CHANNELS

1-9: Press 1-9 as needed. Example, to

10-99: Press the 2 digits in order. Example,

100-135: Press the 3 digits in order. Example, to

TO SELECT DIGITAL CHANNELS

Press the first 3 digits, then press the – button, followed by the remaining number. Example, to select channel 15-1, press 1, 5, –, 1, then press ENTER.

•

VHF/UHF/CABLE CHANNELS

VHF 2-13

UHF

14-69

NOTE:

If a channel with no broadcast is selected, the

• sound will automatically be muted. It may take a few seconds for a digital channel

• picture to appear on screen after being selected.

To select the video input source

To view a signal from another device connected to your LCD TV, such as a VCR player, press INPUT

SELECT, then press ▲/▼ or corresponding Number buttons (0-5), then press ENTER. You can select TV,

Video, Component, HDMI, PC or DVD depending on which input jacks you used to connect your devices.

0.TV

1.Video

2.Component

3.HDMI

4.PC

5.DVD

[0-5]:Select

CH /

Press and release CH / . The channel automatically stops at the next channel set into memory. For proper operation, before selecting channels, they should be set into the memory. See “Memorizing channels” on page 18.

select channel 2, press 2, then press ENTER.

to select channel 12, press 1, 2, then press ENTER.

select channel 120, press 1, 2, 0, then press ENTER.

If a channel is selected with only audio content, “Audio only” will be displayed on the screen. If a channel is selected with a weak digital signal, “Digital channel signal strength is low” will be displayed on the screen. The same program may be available on either an analog channel or a digital channel. You may choose to watch either format. If a channel is selected to which you have not subscribed, be displayed on the screen.

Air Cable

Input Select

“Digital channel is encrypted” will

VHF 2-13

STD/HRC/IRC 14-36 (A) (W) 37-59 (AA) (WW) 60-85 (AAA) (ZZZ) 86-94 (86) (94) 95-99 (A-5) (A-1) 100-135 (100) (135) 01 (4A)

ENGLISH

DISPLAY

Press DISPLAY to display the current information on the screen.

When the TV receives a digital signal, the digital information will appear.

62-1 HDTV Moving Picture1

CH-1 TV-MA

Digital Air

No Program Information is available

Full

1080i

Sleep Timer

Off

English

Channel number• Station name•

Broadcast program name

Channel label (if preset)•

• V-Chip rating• Signal type• Sleep timer• Audio language• Program guide• Picture size• Resolution•

When the TV receives an analog signal, the analog information will appear.

Analog Cable

Mono

480i

Full

Sleep Timer

Off

Channel number• Channel label (if preset)• V-Chip rating• Signal type• Sleep timer• Picture size• Audio information

• Resolution• (Stereo, SAP or Mono)

Press DISPLAY again to clear the call display.

NOTE:

•

After a few seconds, DISPLAY screen will return to normal TV-operation automatically.

RECALL

This button allows you to go back to the last channel selected by pressing RECALL. Press RECALL again to return to the last channel you were watching.

MUTING

Press MUTING to switch off the sound. The TV’s sound will be silenced and “Muting” will appear on the screen. The sound can be switched back on by pressing this button again or the VOL + or –.

SLEEP

To set the TV to turn off after a preset amount of time, press SLEEP on the remote control. The clock will count up 10 minutes for each press of the SLEEP button (Off, 0h 10m, 0h 20m, ..., 2h 0m). After the sleep time is programmed, the display will appear briefly every ten minutes to remind you that the sleep timer is operating. To confirm the sleep timer setting, press SLEEP and the remaining time will be displayed for a few seconds. To cancel the sleep timer, press SLEEP repeatedly until the display turns to Off.

Quick guide for menu operation

Call menu and for example: Select Language.

Press INPUT SELECT to select TV mode.

Press SETUP/TV MENU. The TV menu screen

will appear.

Main Menu


Audio

Channel

Lock

Setup

: Select ENTER:Set

Press ▲ or ▼ to select “Setup”, then press ▶ or

ENTER.

Press ▲ or ▼ to select “Language”, then press

◀ or ▶ to select the desired language. …on the following pages the menu can be called in the same way as here.

Press EXIT to return to the normal screen.

NOTE:

If no buttons are pressed for more than about 60

• seconds, the menu screen will return to normal operation automatically.

Convenience functions

You can change the default settings by pressing the SETUP/TV MENU button on your remote, then select the one of the icons at the left of the menu - follow the On-Screen prompts to set your preferences.

Icon Selected Items Setup hint

Picture Picture

Setting

Brightness / Contrast / Sharpness / Color / Tint

Color Temperature

Backlight The Backlight feature adjusts the screen brightness for improved picture clarity.

You can adjust the picture quality to your preference.

Bluish (Cool) / Neutral (Standard) / Reddish (Warm)

ENGLISH

Dynamic Gamma

Picture Preference

Picture Size See page 22. Film Mode On/Off A smoother motion may be obtained by setting the Film Mode to “On” when you

PC Setting Hor Position / Ver

Audio Bass / Treble / Balance You can adjust the sound quality to your preference.

Channel Add / Delete See page 18.

Lock See page 20. Setup Closed Caption See page 21.

DNR On/Off DNR (Digital Noise Reduction) can reduce the roughness of the picture.

MTS Stereo / SAP /

Surround On/Off The dynamic presence and sound created offers a thoroughly enjoyable

Audio Language When two or more audio languages are included in a digital signal, you can

HDMI Audio HDMI When you connect the HDMI device to the TV, select this setting.

DTV Signal See page 19. Auto Ch Memory See page 18. Ch Label See page 19.

Language You can choose from three different languages (English, Français (French) and

Video Label See page 19. On Timer

Auto Shut Off*

Power On/Off Sound

Power On LED

Reset

On/Off The Dynamic Gamma feature produces greater picture detail in dark or

Sports Bright and dynamic picture (factory-set) Standard Standard picture quality (factory-set) Movie Movie-like picture setting (factory-set) Memory Your personal preferences (set by you; see “Picture Setting”).

Position Clock To minimize any vertical bars or stripes visible on the screen background. Phase This must be adjusted after the frequency has been set optimize picture quality. Auto Adjust To adjust the all PC settings automatically.

Mono

DVI

Off / 0h30m / 1h00m / 1h30m / 2h00m / 3h00m⋅⋅⋅12h00m

On/Off If the Auto Shut Off feature is On, a station being viewed stops broadcasting and

On/Off When you turn on/off the TV, sound will output from TV. You can select On or Off.

On/Off When you turn on the TV, Power indicator on the front of the TV will light. You

bright scene areas.

view a DVD. To adjust the horizontal / vertical position of the image on the PC Monitor

screen. Each video standard will require a different value for this setting.

The multi-channel TV sound (MTS) feature provides high-fidelity stereo sound. MTS also can transmit a second audio program (SAP) containing a second language or other audio information. When the TV receives a stereo or SAP broadcast, the word “Stereo” or “SAP” displays on-screen every time you press DISPLAY.

listening experience.

select one of the audio languages. (This function is available only for digital broadcast.)

When you connect the DVI device to the TV with analog audio cords, select this setting.

Español (Spanish)) for the on-screen displays. Select the language you prefer first, then proceed with the other menu options.

You can set the On Timer to automatically turn on the TV. To cancel the On Timer select “Off”.

the TV is not operated, the TV will automatically shut itself off after 15 minutes.

can select On or Off. The Reset function returns your Picture/Audio settings to the factory settings.

“Picture Setting”, “Dynamic Gamma”, “Picture Preference”, “Film Mode”, “PC Setting”, “DNR”, “Bass”, “Treble”, “Balance” and “Surround” can be reset by this function.

NOTE:

* If there is no input signal in the HDMI or PC mode, after 1 minute Auto Shut Off will be activated.

Memorizing channels

This TV is equipped with a channel memory feature which allows channels to skip up or down to the next channel set into memory, skipping over unwanted channels. Before selecting channels, they must be programmed into the TV’s memory. To use this TV with an antenna, set the Signal Type option to the Air mode. When shipped from the factory, this menu option is in the Cable mode.

Air/Cable selection

Select “Channel”, then press ▶ or ENTER.

Press ▲ or ▼ to select “Auto Ch Memory”, then

press ▶ or ENTER.

Press ▲ or ▼ to select “Signal Type”.

Press ◀ or ▶ to select “Air” or “Cable”.

Air - VHF/UHF channels Cable - CABLE TV channels

Auto Ch Memory

Signal Type Cable Automatic Search Start

: Adjust

: Select

CABLE CHART

The chart below is typical of many cable system channel allocations.

The TV will begin memorizing all the channels

available in your area.

It may take from 15 minutes to 30 minutes to

• complete memorizing digital cable channels. Depending on the reception condition, a bar display may not advance for several minutes, please be patient.

NOTE:

•

Memorizing channels is best accomplished during evening “PRIMETIME” hours, as more stations are broadcasting digital signals. Memorizing channels can only be accomplished while a station is broadcasting a digital signal to set that channel into memory. If you are unsure of the digital channels available

• in your area, you may visit www.antennaweb.org to receive a list based on your address or zip code. Should you require further assistance you may call our toll-free customer service line at U.S.A. 1-800252-5722/Canada 1-800-964-2650. New digital channels may be added to your area

• periodically, it is recommended to perform the “Automatic Search” procedure regularly.

Adding Channel

If you find a new digital channel unregistered, you can add the new channel into the channel memory.

Tune in the new channel.

Select “Channel”, then press ▶ or ENTER.

Press ▲ or ▼ to select “Add/Delete”, then press ▶

or ENTER.

Add/Delete

Adding Channel >>

Add/Delete >>

Clear All >>

NOTE:

It may take a few seconds for a digital channel

• picture to appear on screen after being selected.

Automatic Search

Select “Channel”, then press ▶ or ENTER.

Press ▲ or ▼ to select

press ▶ or ENTER.

Press ▲ or ▼ to select “Automatic Search”, then

press ▶ or ENTER.

Auto Ch Memory

Signal Type Cable Automatic Search Stop

Analog Channel Found : 7 Digital Channel Found : 5

Programming Now

: Select

ENTER:Cancel

“Auto Ch Memory”, then

: Select ENTER:Set

Press ▲ or ▼ to select “Adding Channel”, then

press ▶ or ENTER. The new channel will be added into the channel memory.

Add/Delete channel

You can select the channel that you want to skip.

Select “Channel”, then press ▶ or ENTER.

Press ▲ or ▼ to select “Add/Delete”, then press

▶ or ENTER.

Press ▲ or ▼ to select “Add/Delete”, then press

▶ or ENTER. Press ▲ or ▼ to select the channel that you want

to skip.

Add/Delete

CH Signal

2 Analog

3 Analog Add

3-1 Digital Delete

3-2 Digital Add

4 Analog Delete

: Select

Press ◀ or ▶ to select “Add” or “Delete”,

whichever function you want to perform. Repeat steps 4 - 5 for other channels you want to

add or delete.

Add

: Adjust

Clear All

All channels are deleted from the channel memory.

Select “Channel”, then press ▶ or ENTER.

Press ▲ or ▼ to select “Add/Delete”, then press ▶

or ENTER.

Press ▲ or ▼ to select “Clear All”, then press ▶ or

ENTER.

Add/Delete

Adding Channel >>

Add/Delete >>

Clear All >>

: Select ENTER:Set

Checking the digital signal strength

This TV will allow you to view the digital signal meter for digital channels.

Select “Channel”, then press ▶ or ENTER.

Press ▲ or ▼ to select “DTV Signal”.

Press ▶ or ENTER to check the digital signal

strength. The digital signal strength screen will appear. If necessary, adjust the direction of the antenna to obtain the maximum signal strength.

DTV Signal

0 50 100

Signal Level

NOTE:

Signal meter feature is not available for analog

• channels. After 240 seconds, DTV Signal screen will return to

• normal TV-operation automatically.

Labeling channels

Channel label appear with the channel number display each time you turn on the TV, select a channel, or press DISPLAY. You can choose any four characters to identify a channel.

To create channel labels

Select “Channel”, then press ▶ or ENTER.

Press ▲ or ▼ to select “Ch Label”, then press ▶

or ENTER. The Ch Label menu will appear.

Press ◀ or ▶ to select a channel you want to

label, then press ▼.

Ch Label

Channel Number 15-1

Ch Label

Label Clear >>

Press ◀ or ▶ repeatedly until the character you

want appears in the first space.

Ch Label

Channel Number 15-1

Ch Label A

Label Clear >>

: Adjust

: Select

The characters rotation as follows:

If the character which you desire appears, press ENTER. Repeat this step to enter the rest of the characters. If you would like a blank space in the label name, you must choose the empty space from the list of characters.

Repeat steps 3-4 for other channel. You can

assign a label to each channel. When you finish inputting the label name, press

EXIT to return to the normal screen.

ENTER:Set

SPACE

, () @ / + =

To clear a Ch Label

After step 3 above, press ▲ or ▼ to select “Label Clear”, then press ▶ or ENTER.

NOTE:

•

The channel labels will be reset after “Automatic Search” on page 18.

Labeling video inputs

The Video Label feature allows you to label each input source for your TV.

Select “Setup”, then press ▶ or ENTER.

Press ▲ or ▼ to select “Video Label”, then press

▶ or ENTER. Press ▲ or ▼ to select an input which you want to

label. Press ◀ or ▶ to select the desired label for that

input source.

Video Label

Video -

Component -

HDMI -

: Adjust

: Select

– : Uses the default label name

VCR : Video cassette recorder DVD : DVD video DTV : Digital TV set-top box SAT : Satellite box CBL : Cable box HD : HDMI device (only for HDMI inputs)

ENGLISH

: Select

: Adjust

Setting the V-Chip

An age limitation can be set to restrict children from viewing or hearing violent scenes or pictures that you may choose to exclude. The restriction applies to “TV Rating” and “Movie Rating” if this data is transmitted. You may set this restriction separately. To use the V-Chip function, you must register a password.

To register a password

Select “Lock”, then press ▶ or ENTER.

Select and enter your password (4 digits) using

Number buttons (0-9), then press ENTER.

Lock

New Password

[0-9]

: Select ENTER:Set

“ ” appears instead of the number.

Enter the same password again to confirm, then

press ENTER. The password is now registered.

NOTE:

If you forget the password, contact Customer

• Service at U.S.A. 1-800-252-5722/Canada 1-800964-2650 for assistance. Your original remote control will be required. To avoid forgetting the password, write it down and

• keep in a safe place.

To set the V-Chip

Select “Lock”, then press ▶ or ENTER.

Use Number buttons (0-9) to enter your

password, then press ENTER. The Lock menu will appear.

Press ◀ or ▶ to set “V-Chip” to “On” .

Press ▲ or ▼ to select “V-Chip Set”, then press

▶ or ENTER. The V-Chip Set menu appears.

Press ▲ or ▼ to select which rating will be used,

then press ▶ or ENTER. Each rating below will appear.

TV Rating

TV-Y

TV-Y7

TV-G

TV-PG

TV-14

TV-MA

You can set the rating using age level and genre.

Age: TV-Y : All children TV-Y7 : 7 years old and above TV-G : General audience TV-PG : Parental guidance TV-14 : 14 years old and above TV-MA : 17 years old and above

* * *

ALL D L S V FV

ENTER:Set

: Select

Genre: ALL : All D : Dialogue L : Language S : Sex V : Violence FV : Fantasy Violence

Movie Rating

PG-13

NC-17

: Select

G : All ages PG : Parental guidance PG-13 : Parental guidance

R : Under 17 years old parental guidance

NC-17 : 17 years old and above X : Adult only

Press ▲/▼/◀/▶ to select the desired rating, then

press ENTER.

Press EXIT to return to the normal screen.

V-Chip function is activated now.

To use the TV after the TV is protected.

When a program is received that is blocked by the VChip, press MUTING, then enter your password. The protection will be temporarily overridden. If the TV is turned off or the channel is changed, the V-Chip restriction will be reactivated.

NOTE:

•

The V-Chip function is activated only on programs and input sources that include a rating signal.

ENTER:Set

less than 13 years old

suggested

To change the password

Select “Lock”, then press ▶ or ENTER.

Use Number buttons (0-9) to enter your password,

then press ENTER. The Lock menu will appear.

Press ▲ or ▼ to select “Change Password”, then

press ▶ or ENTER. The Change Password screen will appear.

Enter a new password using Number buttons

(0-9), then press ENTER.

Enter the same password again to confirm, then

press ENTER. The password is now registered.

Downloading the additional V-Chip rating system

As a supplement to the standard V-Chip rating system, your television will be able to download an additional rating system, if such a system becomes available in the future.

To download the additional V-Chip rating system (when available)

Select “Lock”, then press ▶ or ENTER.

Use Number buttons (0-9) to enter your password,

then press ENTER. The Lock menu will appear.

Press ◀ or ▶ to set “V-Chip” to “On”.

Press ▲ or ▼ to select “V-Chip Set (DTV)”, then

press ▶ or ENTER. If the TV is not storing the additional rating

system, the TV will begin downloading it, which may take some time to be completed.

Set your preferred content rating limits for the

additional rating system. You also need “Update” procedure to update

rating information.

NOTE:

You can only download the additional V-Chip rating

•

system when your TV is receiving a digital signal. When you download the additional rating system, it

•

may take some time for the download to occur. The V-Chip rating information and system are not

•

determined or controlled by the TV. The standard V-Chip rating system is available

•

whether your TV is receiving a digital signal or not, and will block both analog and digital programs. To set the restriction level using the standard V-Chip rating system, select V-Chip Set in step 4. The downloadable V-Chip rating system is an

•

evolving technology, and availability, content, and format may vary. You cannot select this feature if the TV is not

•

receiving a digital signal for the current station.

To clear the all V-Chip settings

Select “Lock”, then press ▶ or ENTER.

Use Number buttons (0-9) to enter your password,

then press ENTER. The Lock menu will appear.

Press ▲ or ▼ to select “V-Chip Clear”, then press

▶ or ENTER. The V-Chip Clear screen will appear.

Use Number buttons (0-9) to enter your

password, then press ENTER. All your settings return to the factory settings.

Closed Caption

WHAT IS CLOSED CAPTIONING?

This television has the capability to decode and display Closed Captioned television programs. Closed Captioning will display text on the screen for hearing impaired viewers or it will translate and display text in another language.

Captions: This Closed Caption Mode will display text on the screen in English or another language. Generally, Closed Captions in English are transmitted on C1 and Closed Captions in other languages are transmitted on C2. Text: The Text Closed Caption Mode will usually fill 1/2 of the screen with a programming schedule or other information.

Select “Setup”, then press ▶ or ENTER.

Press ▲ or ▼ to select “Closed Caption”, then

press ▶ or ENTER. The Closed Caption menu will appear.

Press ◀ or ▶ to set “CC Setting” to “On”.

On: Captions will be displayed on the screen. Off: Captions will not be displayed on the screen.

Press ▲ or ▼ to select “Analog Caption” or “Digital

Caption”. When you select “Analog Caption”, you can

choose from C1, C2, C3, C4, T1, T2, T3 and T4. When you select “Digital Caption”, you can

choose from CS1, CS2, CS3, CS4, CS5 and CS6.

Press ◀ or ▶ to select the desired Closed

Caption mode for both Digital and Analog Caption.

Press ▲ or ▼ to select “CC Priority”, then press

◀ or ▶ to select “Digital CC” or “Analog CC”.

NOTE:

Depending on the broadcast signal, some

• Analog Captions will function with a Digital broadcast signal. This step prevents two types of captions from overlapping.

NOTE:

•

If the program or video you selected is not closedcaptioned, no captions will display on-screen.

•

If text is not available in your viewing area, a black rectangle may appear on-screen. If this happens, set the CC Setting to “Off”.

•

When selecting Closed Captions, the captioning will be delayed approx. 10 seconds.

•

If no caption signal is received, no captions will appear, but the television will remain in the Caption Mode.

•

Misspellings or unusual characters may occasionally appear during Closed Captioning. This is normal with Closed Captioning, especially with live programs. This is because during live programs, captions are also entered live. These transmissions do not allow time for editing.

•

When Captions are being displayed, on-screen displays, such as volume and mute may be seen but may interfere with Closed Captions.

•

Some cable systems and copy protection systems may interfere with the Closed Captioned signal.

•

If using an indoor antenna or if TV reception is very poor, the Closed Caption Decoder may not appear or may appear with strange characters or misspelled words. In this case, adjust the antenna for better reception or use an outdoor antenna.

CC advanced

When you have selected Custom as the display method, you can adjust the various setting listed below as follows:

This feature is designed to customize Digital Captions only.

Select “Setup”, then press ▶ or ENTER.

Press ▲ or ▼ to select “Closed Caption”, then

press ▶ or ENTER. The Closed Caption menu will appear.

Press ◀ or ▶ to set “CC Setting” to “On”.

ENGLISH

Press ▲ or ▼ to select “Digital CC Preset”, then

press ◀ or ▶ to select “Custom”.

Press ▲ or ▼ to select “CC Advanced”, then

press ▶ or ENTER. The CC Advanced menu will appear.

Press ▲ or ▼ to select the desired item, then

press ◀ or ▶ to change the setting.

CC Advanced

Text Size Auto

Text Type Auto

Text Edge Auto

Text Color Auto

Text Opacity Auto

Background Color Auto

Background Opacity Auto

: Adjust

: Select

You can select from among the following items and parameters.

Text Size: Auto, Small, Standard, Large Text Type: Auto, Style1, Style2, Style3, Style4,

Style5, Style6, Style7

Text Edge: Auto, None, Raised, Depressed,

Uniform, Left Shadow, Right Shadow

Text Color: Auto, Black, White, Red, Green,

Blue, Yellow, Magenta, Cyan

Text Opacity: Auto, Solid, Transparent,

Translucent, Flashing

Background Color:

Background Opacity:

Auto, Black, White, Red, Green, Blue, Yellow, Magenta, Cyan

Auto, Solid, Transparent, Translucent, Flashing

NOTE:

•

You cannot set both “Text Color” and “Background Color” as a same color.

•

You cannot set both “Text Opacity” and “Background Opacity” to “Transparent”.

Natural

In some cases, this image will display the size of standard 4:3 with a black side bar.

Cinema Wide1 (for 4:3 format programs)

To fill the screen, the right and left edges are extended, however; the center of the picture remains near its former ratio. The top and bottom edges of the picture may be hidden.

Cinema Wide2 (for letter box programs)

The entire picture is uniformly enlarged—it is stretched the same amount both wider and taller (retains its original proportion).

The top and bottom edges of the picture may be hidden.

Cinema Wide3 (for letter box programs with subtitles)

To fill the width of the screen, it is extended horizontally. However; it is only slightly extended at the top and the bottom.

The top and bottom edges of the picture may be hidden.

Setting the picture size

You can view 480i and 480p format programs in a variety of picture sizes— Natural, Cinema Wide1, Cinema Wide2, Cinema Wide3, Full and Native.

Selecting the picture size

Select “Picture”, then press ▶ or ENTER.

Press ▲ or ▼ to select “Picture Size”, then press

▶ or ENTER to display Picture Size menu. Press ▲/▼ or corresponding Number buttons (0-4)

select the desired picture size, as described below.

Picture Size

0.Natural

1.Cinema Wide1

2.Cinema Wide2

3.Cinema Wide3

4.Full

[0-4]:Select

NOTE:

Selectable picture sizes may vary depending on the

• input source or broadcast signal. Picture Size menu also can be displayed by

• pressing SCREEN SIZE on the remote control.

A B C D E F G - - - - - - - - - - - - - - - -

A B C D E F G - - - - - - - - - - - - - - - - - - - - - - - - - -

Full (for 16:9 source programs)

Full will display the picture at the maximum size.

Native (for PC mode only)

Detects the resolution of the signal of the image and it will be shown on the screen with same amount of pixels.

NOTE:

Some High Definition and/or Digital broadcasts may not

• allow you to change the picture size.

•

In HDMI or COMPONENT mode with a scanning rate of 720p, 1080i or 1080p (only HDMI) only the Cinema Wide2 and Full picture size feature is available.

•

In PC mode, only the Natural, Full and Native picture size features are available. In PC mode (WXGA), only the Full and Native picture size features are available.

Preparation

The following pages describe the setup/ operation in DVD mode.

Preparation

Before DVD/CD operation, please make the following preparations.

Insert the AC cord plug into a standard 120V

60Hz polarized AC outlet.

If the AC cord plug is plugged in for the first

• time, wait for about 5 seconds before pressing

POWER.

NOTE:

When connecting to other equipment, unplug

• the unit from the AC outlet.

Press POWER on the unit or on the remote

control to turn on the unit. The POWER indicator will change to green.

Each time you turn the unit ON, the TV/DVD

• starts from the TV mode. When using an amplifier, switch on the amplifier.

•

Press TV/DVD to select DVD mode.

The DVD startup screen will appear on the screen.

NOTE:

If the unit does not operate properly:

•

Static electricity, etc., may affect the player’s operation. Disconnect the AC power cord once, then connect it again.

About inserting disc:

•

If the unit is slanted or moved while inserting disc, the disc may get damage.

Status display of disc

Press DISPLAY. The status display of the disc will appear on the screen

Display messages may change at every time when

•

you press DISPLAY for some discs or files.

To make the status display screen disappear, press

DISPLAY again.

Playback procedure

Press TV/DVD to select DVD mode.

Place the disc in the

disc slot with the label side facing forward. (If the disc has a label.) Hold the disc without touching either of its surfaces, align it with the guides, and place it in position.

On the screen, “ ” changes to “Loading” and then

playback will commence.

A menu screen may appear on the TV screen,

• if the disc has a menu feature. In this case, press ▲, ▼, ◀, ▶ or ENTER to operate a menu feature.

Press STOP () to end playback.

The unit can record where you stop a video, but it

• depends on a disc you are using. Press PLAY

()

to resume a playback point. The unit can store a memory of stopped point of last five discs that you have played. When one of these discs is next loaded, you can resume playback from where you stopped playing last time. If you press STOP

• appears on the screen) the unit will clear the stopped point. You cannot save a stopped point for some discs.

• If a number of discs played and stored in the unit exceeds five, a new memory will overwrite the old stored memory.

Press (EJECT).

Remove the disc and then press POWER. The unit turns off.

When you eject the disc, you may hear

• mechanism noise, but it is not malfunction.

NOTE:

•

If a non-compatible disc is loaded, “Can’t play disc” or “Incompatible disc region number Can’t play disc” will appear on the TV screen according to the type of loaded disc. In this case, check your disc again (see page 9).

•

Some discs may take a minute or so to start playback.

•

If an 8 cm disc is placed into the disc slot and picture playback or menu display does not begin automatically, press PLAY ().

•

A prohibition message “Depending on the disc, this operation may be prohibited” or “This operation can’t be performed” may appear at the screen. This message means either the feature you tried is not available on the disc, or the unit cannot access the feature at this time. This does not indicate a problem with the unit.

•

When you set a single-faced disc label downwards (i.e. the wrong way up) “Loading” will appear on the display and then “Can’t play disc” will be displayed. Some playback operations of DVDs may be

• intentionally fixed by software producers. Since this unit plays DVDs according to the disc content recorded, some playback features may not be available. Also refer to the instructions supplied with the DVDs.

)

(

again (“Resume off”

ENGLISH

Special playback

Fast Forward Playback

Press SEARCH (uu) during normal playback. Each press of SEARCH (uu) will increase the speed of the search.

• To resume normal playback, press PLAY

Review Playback

Press SEARCH (tt) during normal playback. Each press of SEARCH (tt) will increase the speed of the search.

• To resume normal playback, press PLAY ().

Still Playback

Press PAUSE/STILL () during normal playback to pause playback.

• To resume normal playback, press PLAY

PAUSE/STILL ().

Frame Advance

Press PAUSE/STILL One frame is advanced each time you press SEARCH (tt) or SEARCH (uu).

• To resume normal playback, press PLAY ().

Slow-motion Playback

Press SLOW ( playback or still playback. Each press of SLOW will change the speed of the slow.

• To resume normal playback, press PLAY ().

• To resume the still playback, press PAUSE/STILL

()

Locating a chapter or track

Press SKIP( ) Forward or SKIP( ) Reverse during playback to locate a chapter/track that you want to watch. Each time you press the button, a chapter or track is skipped.

NOTE:

The TV/DVD is capable of holding a still video image

• or On screen display image on your television screen indefinitely. If you leave the still video image or On screen display image displayed on your TV for an extended period of time, you risk permanent damage to your television screen.

(

)

during normal playback.

) or SLOW ( ) during normal

(

)

(

)

Zooming

This TV/DVD will allow you to zoom in on the frame image. You can then make selections by switching the position of the frame.

Press ZOOM during playback.

The center part of the image will be zoomed in. Each press of ZOOM will change the ZOOM magnification Zoom 2× and Zoom 4×.

Press ▲/▼/◀/▶ to view a different part of the

frame. You may move the frame from the center position UP, DOWN, LEFT or RIGHT.

In the zoom mode press ZOOM repeatedly to

return to a 1:1 view.

NOTE:

•

You can select the Still Playback or Fast Forward (Review) Playback in the zoom mode.

•

Some discs may not respond to zoom feature.

Locating desired scene

Use the title, chapter and time recorded on the disc to locate the desired point to play back.

Press JUMP during playback.

Press ▲/▼ to select the “Title Search”, “Chapter

Search”, “Time Search” or “Track Search”. Then press ▶ or ENTER.

Press Number buttons (0–9) to input the number.

If you input a wrong number, press CANCEL.

• Refer to the package supplied with the disc to

• check the numbers.

Press ENTER.

Playback starts.

• When you change the title, playback starts from

• Chapter 1 of the selected title. Some discs may not work in the above

• operation.

A-B Repeat playback

A-B repeat playback allows you to repeat material between two selected points.

Press REPEAT A-B during playback.

The start point is selected.

Press REPEAT A-B again.

The end point is selected. Playback starts at the point that you selected. Playback stops at the end point, returns to Point A automatically, then starts again.

To resume normal playback press REPEAT A-B

• again.

NOTE:

In A-B Repeat mode, subtitles near the A or B

• locations may not be displayed. You may not be able to set A-B Repeat during

• certain scenes of the DVD. A-B Repeat does not work with an interactive DVD,

• MP3/WMA/JPEG-CD.

+ 56 hidden pages
